Instruction manual
DSC
Digital Spy Camera
Content
Introduction . . . . . . . . . . . . . . . . . 31
Scope of delivery . . . . . . . . . . . . . . 31
Batteries . . . . . . . . . . . . . . . . . . . 32
Operating controls
and components . . . . . . . . . . . . . . . 32
How to use your MINOX DSC . . . . . . . . 33
Increasing the camera memory
capacity with a microSD card . . . . . . . . 34
Connecting the fl ash module
(DSC Flash) to the camera (DSC) . . . . . . 35
Switching on the MINOX DSC . . . . . . . . 36
Using Flash/Display Unit . . . . . . . . . . 36
Use the Flash . . . . . . . . . . . . . . . . 37
Selecting the menu language . . . . . . . . 38
30
Shooting photos . . . . . . . . . . . . . . . 38
Taking videos . . . . . . . . . . . . . . . . 39
Playback mode . . . . . . . . . . . . . . . 40
Deleting images . . . . . . . . . . . . . . . 41
Transferring images
to your computer . . . . . . . . . . . . . . 42
Fastening the safety chain . . . . . . . . . 44
Adjusting your camera settings . . . . . . . 44
Camera maintenance . . . . . . . . . . . . 46
Trouble shooting . . . . . . . . . . . . . . . 48
Technical data . . . . . . . . . . . . . . . . 52
Conditions of Warranty . . . . . . . . . . . 54
Disclaimer of liability . . . . . . . . . . . . 55
Introduction
Congratulations on the purchase of your new
MINOX DSC (Digital Spy Camera). Like all other
MINOX products this digital camera boasts
the traditional values fostered by the house of
MINOX. It combines functionality in the smallest
possible space with maximum quality.
Simple and fast operation make the MINOX DSC
ideal for digital photography. It also guarantees
unlimited photographic fun with its distinguished
and striking looks. The MINOX DSC is now set
to become your permanent companion, ready to
capture wonderful memories in a modern way.
This manual is to help you get the maximum
benefi t from all functions of your MINOX DSC.
Enjoy your new camera!
Get to know your camera
Please take enough time to read all operating
instructions and the Safety and Maintenance information in the last section of the manual.
Scope of delivery
• MINOX DSC
• Flash module with integrated monitor
• User manual
• USB cable/charging cable fl ash unit
• Safety chain
• Soft leather cases (camera/fl ash unit)
Accessories (optionally available)
AC Adaptor
EU version 606-350.000-120
UK version 606-350.000-220
US version 606-350.000-320
31
4 2 3 1 5 9 8 7
11
6
12 10
Batteries
Your MINOX DSC and the fl ash module that is
included in the scope of delivery are both fi tted
ex-works with a powerful lithium-ion battery.
The removal and replacement of the batteries
is only to be carried out by authorized service
personnel. MINOX GmbH shall not warranty for
any damage to the batteries that is caused by
incorrect removal or insertion of the batteries.
Operating controls and components*
On the DSC (camera)
1
On/Off button
2
Mode dial
3
Up/ Down buttons
4
Shutter release
5
LED display
The multicolor LED display indicates the following:
Blue:
you are in Photo
or Video mode
Green:
you are in Play mode
Off:
during the photo shoot
Red:
during the video shoot
Red fl ashing:
Blue fl ashing:
Violet (red and blue):
6
Safety eye
memory is full
battery nearly empty
integrated fl ash activated
(for attaching the safety chain)
On the fl ash module
7
Monitor
8
On/Off button
9
Ready display (fl ash)
32
* see schematic diagram on the opened out side
10
Connector (contacts)
11
Engaging notches
12
Sliding lock
How to use your MINOX DSC
Before using the DSC for the fi rst time you have
to fully charge the integrated batteries.
Note: When charging for the fi rst time the batteries must be fully charged to ensure maximum
performance. Do not interrupt the charging process before the green light goes out, indicating
that the charging process has fi nished.
Charging the batteries
Charging the battery in the camera (DSC)
Use the provided power supply cable (mini USB to
USB) to connect the DSC to the USB port of your
switched-on computer. Charging starts automatically.
To charge the battery of the
DSC without the computer you
can use an optionally available
AC Adaptor (Order number
see: Accessories).
Mini USB
port
A green LED lights up while the battery is
charging. Charging is complete when the green
light goes out.
Charging the battery in the
fl ash module (DSC Flash)
Use the provided power supply cable (mini jack to
USB) to connect the fl ash to the USB port of your
switched-on computer. Charging commences automatically.
33
To charge the battery of the fl ash module without
the computer you can use an optionally available power adapter (Order number see: Accessories).
A green LED lights up while the internal battery
is charging. Charging is complete when the green
light goes out.
Increasing the camera memory
capacity with a microSD card
The MINOX DSC is equipped ex-works with a 128
MB internal memory, capable of storing approx.
37 images.
An additional microSD card (Secure Digital) substantially increases the memory capacity of your
DSC.
The MINOX DSC supports microSD cards with a
capacity of up to 16 GB. MicroSD cards are available from photo dealers and electronics stores.
34
Inserting a microSD card
Open the battery compartment cover of the
DSC and insert the microSD card the right way
up (with the gold contacts facing upward) into
the microSD card slot. The SD symbol appears
on the monitor.
Important: Inserting the microSD card blocks
the internal memory. All new photo and video
shootings will now be stored on the microSD card.
The internal memory is only available until you
remove the microSD card.
microSD card slot
Connecting the fl ash module
(DSC Flash) to the camera (DSC)
Switch both the camera and the fl ash module off
before connecting the external fl ash to the DSC.
Hold the fl ash module with the monitor facing
upward next to the DSC with the camera controls
facing upward. Now join the two units so that
the connector of the fl ash fi ts into the socket of
the camera and the safety chain eye of the DSC
fi ts into the mating opening on the fl ash module.
To connect the two devices simultaneously press
down and gently squeeze the engaging notches.
When doing so, the notches of the fl ash must engage in the corresponding openings on the DSC.
Now move the slide lever on the bottom of the
fl ash fully to the right (into the position “lock”),
until you hear this audibly engage. The fl ash module is now fi rmly connected and engaged with
the DSC camera.
To separate the fl ash module and camera again
you must fi rst switch off both units. Move the slide
lever on the bottom of the fl ash into the position
Slide lever Engaging notches
35
“unlock”. Now carefully press with a fi nger on one
of the two engaging notches (top or bottom) between the two devices. This disengages the locking action of the fl ash module with the camera.
Note: Before connecting the external fl ash with
the camera you must remove the safety chain
from the camera (DSC), if attached.
36
Switching on the MINOX DSC
To switch the DSC on press the On/Off button
and hold it down until the LED lights up blue (in
the Photo/Video mode) or green (in the Playback
mode).
The switching on of the DSC takes effect with a
delay of a few seconds to avoid any unintentional
switching on of the MINOX DSC.
Using Flash/Display Unit
The followings operations can only be done after the Flash Unit is connected to the Spycam
properly. Otherwise the Flash Unit is in poweroff state.
Switch On the Display
Switch the Display On/Off button to the ON side
and switch on the Spycam. You can see the preview on the Display.
Switch Off the Display
Switch the Display On/Off button to the OFF side.
The Display will turn off but the Spycam remains
in power-on state.
Use the Flash
Charge the Flash
Switch on the Spycam in Camera mode. Press the
UP button on the Spycam once to enable the fl ash
and press again to disable the Flash. The green
LED located on the upper side of the fl ash unit is
fl ashing during charging process.
Trigger the Flash
When the fl ash is fully charged the green LED
lights on and shows the readiness of the fl ash.
Press the Shutter button on the Spycam to trigger the fl ash.
Notes
1. The Display On/Off button enable the display
on/off only and has no effect on fl ashing.
2. The Flash Unit have no fl ashing and display if
it is not connected to the Spycam.
Technical data
Flash Unit
Voltage supply to the Flash Unit 4V
Flash Display Current drain (mA)
Off On 130
Charging On 300
Charging Off 170
Measurement is made by using a Flash Unit with
a Spycam.
37
Selecting the menu language
The MINOX DSC menu items can be displayed in
several languages. If, after switching on the camera and the fl ash module, the menus are not shown
in your language, go to the section
camera settings
38
>
Selecting the language
Adjusting your
Shooting photos
Framing the subject and shooting the picture
Set the mode dial to the desired Photo mode. With connected and switched on fl ash
module the -symbol appears on the monitor.
Frame the subject you want to shoot through the
viewfi nder or in the monitor of the connected
fl ash module. Press the shutter release to capture
and save the picture.
The LED display extinguishes during the shot and
the respective saving process. The LED display
then lights up blue again to signal that the DSC
is ready to take the next shot.
Using the fl ash
Activate the fl ash function in the Photo mode
by pressing the Up button. The LED display now
lights up violet (red and blue) to indicate that
the fl ash is ready.
When switched on the fl ash is controlled automatically and only operates when there is insuffi c i e n t l i g h t .
If the fl ash is not connected the LED fl ash in the
camera is used. This is immediately ready for
use.
When the fl ash module is connected, this fl ash is
used instead of the internal LED fl ash.
After switching on the fl ash function the green
lamp (LED) on the fl ash module lights on to indicate that the fl ash is ready for operation. The time
it takes to signal that the fl ash is ready can vary,
depending on the charge status of the built-in
battery. Press the Up button again to deactivate
the fl ash function, the LED display lights up blue
again.
Taking videos
Framing the subject and shooting the video
Set the mode dial to the desired Video mode. With connected and switched on fl ash
the
signal appears on the
monitor. Frame the scene you
want to shoot through the
viewfi nder of the DSC or in the monitor of the
connected and switched-on fl ash module. Press
the shutter release to start shooting the video. The
LED display lights up red during the shooting. To
stop shooting press the shutter release again.
39
Playback mode
Viewing images or videos on the monitor
The images or video clips
stored on your camera can
be viewed on the monitor integrated in the fl ash module.
To do this, connect the DSC
fl ash module to your DSC as
described above and switch the monitor on.
Activate the Playback mode by turning the mode
dial to the corresponding position. The monitor
of the connected fl ash module now displays the
-symbol.
Press the Up or Down button to page through
your saved images or video clips.
Press the shutter release to start a selected video
clip. Press the shutter release again to stop the
playback.
40
Viewing details (only photos)
The zoom function allows you to view details of
your images.
When you are viewing an image press the
shutter release to enter the Playback menu.
Select
Zoom
and press
Playback
Zoom
4 Thumbnails
9 Thumbnails
Slide Show
the shutter release to confi rm this selection.
Pressing the Up or Down button enables you to
zoom in or zoom out. Press the shutter release
again to view the individual image details in
square sections. With the Up or Down button
you can select and view the individual details of
the image. Press the shutter release a third time
to exit the Zoom mode.
Playback
Zoom
4 Thumbnails
9 Thumbnails
Slide Show
Playback
Zoom
4 Thumbnails
9 Thumbnails
Slide Show
Viewing several images at once
(miniature images)
Press the shutter release in Playback mode to
enter the Playback menu. To show your saved images in thumbnail format select
9 Thumbnails
and confi rm this selection by press-
4 Thumbnails
or
ing the shutter release. The monitor now shows
all images in the desired format.
Select the desired image using the Up or Down
button and press the shutter release to display it
as a single image.
Viewing images in a slide show
The DSC can display your saved images on the
monitor in a slide show.
Playback
Zoom
4 Thumbnails
9 Thumbnails
Slide Show
Press the shutter release in Playback mode
to enter the Playback
menu, select
Show
and confi rm this
Slide
selection by pressing the shutter release. The
slide show commences. Press the shutter release
again to stop the slide show.
Deleting images
Important note!
Deleted images and video clips cannot be restored. In case of doubt make a copy of your
data before deleting images. MINOX GmbH shall
not be liable for data loss caused by incorrect
operation.
41
Playback
Delete One
Delete All
Setup
Exit
Playback
Delete One
Delete All
Setup
Exit
confi rm this selection by pressing the shutter release. Confi rm the safety question that appears
with Yes and press the shutter release again. All
images are now irrevocably deleted from the
memory of the camera.
Deleting a single image
In Playback mode select the image you want to
delete using the Up or Down button.
Press the shutter release to enter the Playback
menu, select
Delete One
and confi rm this selection by pressing the shutter release. Confi rm the
safety question that appears with Yes and press
the shutter release again. The selected image is
now irrevocably deleted from the memory of the
camera.
Deleting all images
In the Playback mode press the shutter release
to enter the Playback menu. Select
Delete all
and
42
Transferring images to your computer
The MINOX DSC supports the following operating systems:
• Windows 2000/ME/XP/
Vista
• Mac OS 9.x or OS X
Driver installation is not required. Older operating
systems are not supported.
Note: When connected to your switched-on
computer via the USB cable the MINOX DSC is
supplied with power and the battery is charged.
Refer also to section Charging the batteries.
Connecting your camera
to the computer
Always switch the DSC on before connecting it
to the computer. Then connect the camera to the
computer using the provided USB cable (connect
the smaller connector to the camera and the
larger one to the computer.)
When connecting the MINOX DSC to your computer for the fi rst time the computer will recognize
it as new hardware. You computer automatically
installs the drivers. Wait until your computer informs you that installation has been completed
before trying to access the images or video clips
stored in the camera or on the microSD card.
Note: If there is a microSD card installed in the
camera you can only access the data on this card.
To access any data in the internal memory of the
camera you must fi rst remove the SD card.
Transferring images to a Windows PC
Click on the symbol
puter. You will see a symbol with the designation
Removable media. Double click on the symbol and
open the folder
in which all your images are stored.
Transferring images to an Apple Mac
After connecting and switching on the camera a
new hard drive system appears on your desktop
with the designation
you will fi nd a folder
another folder
and video clips. You can rename the hard drive
MINOX to any name you choose.
Note: You can also use your camera to store or
download other fi les. To do this, open the above
mentioned folder and copy the respective fi le into
this folder to save it in the camera memory.
My Computer
DCIM
and then folder
MINOX
DCIM
100_ICAM
on your com-
100_ICAM
. On this hard drive
, and in this folder
with all your images
43
Fastening the safety chain
Attach the safety chain to the
provided safety chain eye on
the DSC. It is not possible to
connect the safety chain when
the DSC is connected to the
external fl ash module.
safety chain eye
Note: You must remove the safety chain before
connecting the external fl ash to the DSC.
44
Adjusting your camera settings
Adjusting the camera settings can only be carried
out with the fl ash module (DSC fl ash) connected.
The settings can only be carried out using the
monitor.
See section
Connecting the fl ash module (DSC
Flash) to the camera (DSC)
Opening the Setup menu
In Playback mode press the shutter release, the
Playback menu appears on the monitor. Use the
Up or Down button to change to the menu item
Setup
and confi rm this selection by pressing the
shutter release again.
Up button
Down button
Playback
Delete One
Delete All
Setup
Exit
Setup
Format
AutoOff
Frequency
Settings
Setup
Format
AutoOff
Frequency
Settings
Setup
Format
AutoOff
Frequency
Settings
Use the Up or Down button to select one of the
following options:
Format the internal camera memory
and micro SD card.
You can format the internal memory of the DSC
and micro SD card. In the Setup menu select
mat
and confi rm by pressing the shutter release.
In the Format menu select
Yes
and again press
For-
the shutter release to confi rm this selection. All
images, video clips and data in the memory are
irrevocably deleted.
Setting the Auto Off time
Select
Auto Off
and press the shutter release.
Use the Up or Down button to determine the
time after which you wish the camera to turn
itself off. Confi rm your selection by pressing the
shutter release.
Adjusting the mains frequency
To reduce fl icker in video mode when shooting in
artifi cial light (fl uorescent lamps) you can manually adjust the frequency. To do this select the
frequency 50 Hz or 60 Hz an d confi rm your selection by pressing the shutter release.
45
Setup
Format
AutoOff
Frequency
Settings
Setup
Language
Exit
Revert to default settings
If you want to reset your camera to the ex-works
settings, select
Settings
press the shutter release
to reset the settings.
Language selection
You can set the language used in the menus.
Select
Language
and press the shutter release.
Choose the language you wish and confi rm your
selection by pressing the shutter release.
46
Camera maintenance
Read the following information carefully to ensure correct use of your MINOX DSC.
Places to avoid
Do not store or use the camera in the following
environments:
• in very damp, soiled or dusty places.
• in places exposed to direct sun radiation or
extreme temperatures, such as inside a locked
car in the summertime.
• in extremely cold places.
• in places exposed to severe vibrations.
• in places exposed to smoke or steam.
• in places exposed to strong magnetic fi elds
(e.g. in the proximity of electrically operated
motors, transformers or magnets).
• in places where aggressive chemicals such as
pesticides, rubber or vinyl products are stored
on a long-term basis.
Note: Keep the MINOX DSC away from sand
and dust. As with all digital cameras the MINOX
DSC is also particularly susceptible to sand and
dust. When in sandy places always make sure
that the camera is not unprotected, especially
on beaches or in the desert where fi nd sand is
blown about by wind.
How to keep the DSC and the external
DSC fl ash
If you are not using your MINOX DSC for a longer
period of time, it is best to store it and the fl ash
module in a dry place.
Cleaning your DCC
Always use the optionally available MINOX
Cleaning Set (Order No. 69731). Use the small
brush to carefully remove dust from the lens and
the LCD surface of the display. Wipe the surface
gently with the special micro-fi ber cloth. If there
are any marks on the lens, put a drop of the liquid
lens cleaner onto the micro-fi ber cloth and gently
wipe the lens surface.
Never scratch any part of the camera or fl ash
module with hard objec ts. N ever use volatile sub stances such as solvents, benzene or insecticides,
as these may react with the camera body and
cause deformation or damage to the coating.
When fl ying
We do not recommend storing the camera in
your suitcase or baggage. Keep your MINOX DSC
safely in your hand luggage.
47
Trouble shooting
Problem Cause Remedy
The camera is not functioning The camera (DSC) is not switched on Hold the ON/OFF button down for a
Low battery voltage Recharge battery or use the power
Poor contact between camera (DSC)
and fl ash module (DSC-Flash)
The camera is not shooting
(images or videos)
The Mode dial is on Playback Turn the Mode dial to the appropriate
The fl ash is loading When the fl ash has loaded you can
moment
adapter (available optionally)
Order No.:
EU 606-350.000-120
UK 606-350.000-220
US 606-350.000-320
Clean the contacts with a soft cotton
wool tip
setting (photo or video)
release the shutter
48
Problem Cause Remedy
The camera is not shooting
(images or videos)
Battery cannot be charged Poor or missing contact between USB
Image is blurred or not sharp Camera shake Make sure not to move the camera
The microSD card is full Insert a new (empty) microSD card
Download all images and data from
the microSD card onto a computer, as
required, and then delete the images
or data from the SD card to make
space for new images
The SD card is not formatted correctly Format the microSD card. See „For-
port of the camera and the computer
or mains adapter
matting the internal camera memory
and microSD card”
If new formatting does not solve
the problem, the logic circuits of the
microSD card could be faulty. Contact
MINOX Customer Service
Make sure that the USB cable is fi rmly
connected and the computer is switched on, or that the mains adapter is
properly inserted in the socket
when pressing the shutter release
49
Problem Cause Remedy
The subject in the picture is too dark Not enough light for the shot Switch on the fl ash
The subject in the picture is too light Subject is too close, fl ash is too
White dots appear on the image The fl ash light is refl ected by dust
There are marks and imperfections
on the image
The fl ash does not trigger The fl ash is switched off Switch the fl ash on
strong
Light falling directly on the subject
or is refl ected from the subject onto
the camera
The fl ash is switched on and is
possibly not required
particles or insects in the air
Dirty lens Clean the lens using the MINOX
Increase the distance to the subject
Change the angle of the shot
Switch the fl ash of f
This is unfortunately a familiar effect
and is not due to faulty functioning of
the camera
(This is particularly evident when
shooting with fl ash)
Cleaning Set, Order No. 69731
50
Technical data
Image sensor 5.0 MP, CMOS Sensor (3.2 MP hardware resolution)
Image resolution Still: 2,560 x 1,920 pixels (interpolated)
Video clip: 640 x 480 pixels
File format Still: JPEG / Videoclips: AVI
Memory Internal: 128 MB NAND Flash memory
External: optional mini SD card up to 16 GB
Viewfinder Optical (Galileian-Style)
Display 1.5’’ TFT LCD display (integrated in DSC Flash module)
Flash DSC with LED fl ash
DSC Flash: electronic fl ash
Lens 8.7 mm Minoctar Lens / 4 elements glass lens with IR filter glass
Focal length 8.7 mm (corresponds to approx. 42 mm with 35 mm format)
Lens aperture F 3.0
52
Focus range 1 m, infinity
White balance Automatic
Shutter speed Automatic
Power supply Rechargeable Lithium-Ion-Battery/USB-cable
Support Windows ME/2000/XP/Vista / Mac OS compatible
System requirements min. 450 MHz, min. 128 MB RAM,
min. 800 MB free volume space, USB 2.0
Data transfer miniUSB cable (USB 2.0 high speed)
Dimensions DSC: 3.38 x 1.18 x 0.82 inch / 86 x 30 x 21 mm (W x L x H)
DSC Flash: 3.38 x 1.18 x 0.82 inch / 76 x 41 x 21 mm (W x L x H)
Weight DSC: 2.11 oz / 90 g
DSC Blitz-Modul (Flash): 2.82 oz / 80 g
53
Conditions of Warranty
With the purchase of this MINOX camera you have
acquired a product that has been manufactured
and inspected to stringent quality standards.
The statutory warranty of two years for this product is granted by us from the date of purchase
from an authorized dealer and is subject to the
following conditions:
1) During the warranty period we shall deal with
complaints based on faulty manufacture free
of charge by repair, replacement of defective
parts or full replacement with a fl awless product of the same kind, at our own discretion.
Consequential claims of whatever kind and
whatever the legal basis shall be excluded.
2) Claims under warranty shall be null and void if
the defect has been caused by improper handling – which can also include the use of external accessories -, if the product is serviced by
54
unauthorized persons and workshops or if the
serial number has been obliterated.
3) Warranty claims can only be ma de by submission of a typewritten sales slip of an authorized
dealer.
4) When submitting claims under warranty please
return the MINOX camera together with the
original typewritten warranty and a description of the complaint to the Customer Service
of MINOX GmbH or a country Agency.
5) People traveling abroad may make use of the
MINOX Agency of the respective country,
within the terms of the Warranty of MINOX
GmbH. A list of all current MINOX Agencies
abroad can be found under “Service” on the
MINOX website
www.minox.com
.
Disclaimer of liability
While every effort is made to ensure that the information given in this Manual is accurate and
complete, we accept no liability for any errors
or omissions.
MINOX reserves the right to change the herein
described hardware and software features at any
time without advance notice.
This Manual may not be reproduced, transferred,
copied, stored in information systems or translated into other languages, whether in whole or in
part, in whatever form or with whatever means,
unless expressly permitted by MINOX in writing
beforehand.
MINOX shall not accept damage claims resulting
from faulty or lost data based on incorrect operation or malfunction of the camera, software, SD
storage cards (SD cards), computers or auxiliary
equipment.
MINOX GmbH
Walter-Zapp-Str. 4
D-35578 Wetzlar
Tel.: +49 (0) 6441 / 917-0
Fax: +49 (0) 6441 / 917-612
eMail: info@minox.com
Internet: www.minox.com
55
Design subject to alterations without notice.
MINOX is a registered trademark of MINOX GmbH, Wetzlar.
MINOX GmbH
Walter-Zapp-Str. 4
D-35578 Wetzlar, Germany
Tel.: +49 (0) 6441 / 917-0
Fax: +49 (0) 6441 / 917-612
e-mail: info@minox.com
www.minox.com
99460
Loading...
