Minox DMP-1 DATASHEET

PRO D U C T INFORMATION

MIN OX DMP 1

A POCKET-SIZED DIGITAL PHOTO ALBUM, MP3-PLAYER/-RECORDER AND FM RADIO IN ONE TINY PACKAGE

The Minox DMP-1 weighs in at just 62 grams and
fits into almost any pocket thanks to its compact
dimensions of 75 x 52 x 15 mm. Incorporating a
digital photo album, MP3 player and recorder, FM
radio, digital sound equalizer, E-book facility for
storing and viewing text files and a selection of
pre-installed games to play.

The integrated flash memory of 512 MB and an
SD/MMC slot for cards of up to 1 GB capacity
give the Minox DMP-1 a maximum capacity for
storing up to 18 hours of music, or up to 3,000
digital photos. Images can be viewed on the 2
inch pin-sharp LCD display and paged through as
if using an electronic photo album, or the images

can be conveniently and automatically presented
A stylish metal body with practical and well­situated controls completes the attractive look of

using the slide mode – JPG, BMP or LGO files are

supported.
the DMP-1. A central thumb-controlled joystick
for easy menu navigation, and a surrounding
array of buttons gives the user full control over
all functions. The menu navigation on the display
is simple and intuitive.

Downloading or uploading of images and music

files is simple using the USB to PC interface thus

making it the equivalent of a mini portable hard

drive. The USB port and cable doubles as a means

of recharging the integrated battery simply by

TECH N IC A L DAT A

Features 64K COLOR Display; Built-in SD/MMC Card Slot, support up to 1GB Card ; Photo Browser; High Quality MP3

File support MPEG 1/2/2.5 Layer3; WMA (DRM Compatible); JPEG/BMP/LGO, TXT (ASCII/UNICODE)
OS support WIN98SE/ME/2000/XP
Display Type: 2.0“ LCD with LED Backlight

Audio Frequency scope: 20 Hz - 20 KHz / Headphone output: 4 mW x 2 / Signal to noise ratio: 80 dB
FM Radio FM frequency: Worldwide Band: 87.500 MHz -108.0000 MHz; Japanese Band: 76.000 MHz -108.0000 MHz
Recording Mic: MP3 Format; Line in: MP3 Format; Recording Length (128MB): Up to 540 minutes (24 KHZ / 32 Kbps) or

Music Format Bit Rate: MP3: 8 Kbps - 384 Kbps / WMA: 32 Kbps - 320 Kbps / EQ modes: 6 modes: Classic, Live, Pop, Rock, Bass,

E-Book Support Format: TXT in Unicode / ASCII format
Photo Browser Support Format: JPEG/BMP/LGO
Battery Built-in rechargeable Li-Ion battery, 740 mAh; max. playing time: 9 hours with half backlight power;

Language English, german, french, spanish, italian, japanese, chinese (traditional/simplied)
Dimensions 75 x 53 x 15.5 mm
Weight 62 g (battery weight included)
Storage media built in 512 MB Flash Memory / SD Card up to 1 GB (optional)
USB USB 2.0 Full Speed
Firmware Upgradeable with new functions
Transfer speed > 500 Kbps for both upload and download
Scope of delivery Earphones, USB-cable, Line-in cable, Quick reference guide, Installation CD-ROM
Order number 61603 with AC-DC adapter / 61602 without AC-DC adapter

and Secure WMA Music; MP3 Encoder / Mic & Direct Line-in; FM Radio / Direct Record; 30 Presets / Name
your own Radio Stations; E-Book / ASCII, Unicode, Txt; Synchronized Lyric Display (LRC); Games; Built-in
Rechargeable Battery (740 mAh)

Specication: 128 X 160 DOTS 65536 CSTN LCD

150 minutes (44.1 KHZ / 128 Kbps)

X-EQ / Tags: ID3 V1 Tag and ID3 V2 2.0 / ID3 V2 3.0 / ID3 V2 4.0

Charging: USB or AC Adapter charging takes 2-3 hours

plugging it into a laptop or desktop computer.
With a fully charged battery the DMP-1 is ready
to play music, record sound, play games or show
photos for up to 12 hours.

The DMP-1’s MP3 player and FM radio facility
offers a user-defined choice of listening through
the earphones supplied, and with the digital sound
equalizer it can be fine-tuned to the user’s liking.
Preset equalized modes include rock, classical, pop
and ‘live’ to name just a few. An on-board digital
recorder allows the recording of MP3 files and the
direct line-in socket allows radio programs to be
recorded and stored. The incorporated microphone
can be used for voice recordings.

Accessories accompanying the Minox DMP-1
include a USB and Line-In cable, earphones, Quick
reference guide and CD-ROM.

MINOX GmbH

Walter-Zapp-Str. 4
D- 35578 Wetzlar, Germany
Tel.: [phone] / 917-0
Fax: [phone] / 917-612
E-mail: [e-mail]

www.minox.com

Änderungen in Konstruktion, Ausführung, Angebot und Preis vorbehalten. Produkt-Information Bestell-Nr.: 99295 (d)(e) 09/05/L X/B
