MVS 31X
Call: +1 (714) 283-4200 · Fax: +1 (714) 283-4268
info@minipack.us · www.minipack.us
MVS 31X
Chamber & Seal Bars
Downloads
Performance
Product Sheet (pdf)
Table Top Vacuum Chamber Sheet (pdf)
Contact Us
Display & Controls
Request a Quote
Operational Features
Service
Housing & Dimensions
Optional Seal Bars
Wide Flat Seal (6mm + 1mm Cut-Off Seal)
Optional Features
*Depends on type of product, film and operator ability.
Specifications may chan ge without notice.
Chamber Width x Length 13.00" x 11.75"
Height (Chamber + Dome/Lid = Total) 4.50" + 2.00" = 6.50"
Number of Seal Bars (removable) 1
Position of Seal Bars Front
Seal Bar Length 12.25"
Distance between Seal Bars -
4 mm Seal + 1 mm Cut-Off Seal
Independent Power to each Seal Bar
Programmable Vacuum Time (%)
External Channel Bag Evacuation
Programmable Service Reminder
Unique Waffle-Pattern Se aling
Hygienic Seamless Cham ber
Pop-Out Seal Bars
Pump Type Busch Oil Rotary
Cycles per Minute* up to 3
Free Air Displacement @ 50Hz 8 m³/h
Free Air Displacement @ 60Hz 9.5 m³/h
Pump Power Rating 0.50 hp
Power Supply 120V / 7.5A
Water Resistant Digital Display
Electronic Millibar Sensor
Programmable Sealing Time
High Volume Density Plates
Dual Flat Seal (2 x 4 mm )
Dual Convex Seal (2 x 3,5 mm)
230V Single Phase @ 50/60Hz
LED Display
Customizable Programs 9
Extra Vacuum (30 sec)
Excess Bag Cut-Off
Indicating Display
1 Year Limited Warranty
Material Stainless 304
Lid Type
Width x Length 15.50" x 20.00"
Height (Lid open/closed) 27.00" / 14.00"
Recessed Lifting Cups -
Leveling Legs
Shipping Wt. 102 lbs
Top & Bottom Seal -
Inert Gas Flush Kit
Evacuation Filter Kit
Tray for Liquids
NSF 4" Legs -
Transparent with
Dome
