Mini Cooper 2002 Owner's Manual
OWNER'S MANUAL
Contents
From A to Z
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
MINI COOPER
MINI COOPER S
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
CONGRATULATIONS ON YOUR NEW MINI
This Owner's Manual should be considered a permanent part of this vehicle. It should stay with the
vehicle when sold to provide the next owner with important operating, safety and maintenance
information.
This manual is supplemented by a Service and Warranty Information Booklet for US models or a
Warranty and Service Guide Booklet for Canadian models.
We recommend that you read this publication thoroughly.
Your MINI is covered by the following warranties:
– New Vehicle Limited Warranty
– Limited Rust Perforation Warranty
– Federal Emissions System Defect Warranty
– Federal Emissions Performance Warranty
– California Emission Control System Limited Warranty
Detailed information about these warranties is listed in the Service and Warranty Information
Booklet for US models or in the Warranty and Service Guide Booklet for Canadian models.
We wish you an enjoyable driving experience.
CONTENTS
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
Using this Owner's Manual
Notes on the Owner's Manual 6
Symbols used 6
Symbol for vehicle parts 6
Your individual vehicle 6
Editorial notice 7
For your own safety 8
Reporting safety defects 9
© 2002 Bayerische Motoren Werke
Aktiengesellschaft
Munich, Germany
Reprinting, including excerpts, only with the
written consent of BMW AG, Munich.
Order No. 01 41 0 156 724
US English II/02
Printed in Germany
Printed on environmentally friendly paper
(bleached without chlorine, suitable for recycling).
At a glance
Cockpit 12
Display elements 13
Display elements with navigation
system 14
Indicator and warning lamps 15
Multifunction steering wheel MFL 18
Controls and features
Opening and closing:
Keys 22
Central locking system 23
Opening and closing – from outside 23
Opening and closing – from inside 26
Tailgate 27
Electric power windows 28
Sliding/tilt sunroof 29
Roller sun blind 30
Adjustments:
Correct sitting posture 31
Seats 31
Entry to the rear 33
Seat heating 34
Head restraints 34
Safety belts 35
Steering wheel 35
Mirrors 36
Airbags 37
Transporting children safely 38
Vehicle Memory 41
2
Driving:
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
Ignition lock 42
Starting the engine 42
Switching off the engine 43
Parking brake 44
Manual transmission 45
Continuously Variable automatic
Transmission (CVT) 46
Parking lamps/Low beams 49
Indicator/Headlamp flasher 49
Instrument lighting 50
Fog lamps 50
Interior lamps 50
Light-emitting diodes 51
Washer/Wiper system 51
Cruise control 53
Everything under control:
Odometer 55
Tachometer 55
Fuel gauge 55
Coolant temperature gauge 56
Service Interval Display 57
Clock 57
Computer 58
Technology for safety and driving
convenience:
Automatic Stability Control plus Traction
(ASC+T) 60
Dynamic Stability Control (DSC) 61
Flat Tire Monitor 62
Park Distance Control (PDC) 63
Controlling the climate for pleasant
driving:
Air conditioner system 64
Automatic climate control 67
Interior conveniences:
Glove compartment 70
Ashtray/Beverage holder 70
Cigarette lighter 70
Loading and transporting cargo:
Luggage compartment cover 71
Foldable rear backrest 71
Loading cargo 72
Roof-mounted luggage rack 73
Care and maintenance
Special operating instructions:
Break-in procedures 76
General driving notes 76
Refueling 77
Fuel specifications 78
Antilock Brake System (ABS) 78
Brake system 79
Wheels and tires:
Tire inflation pressure 80
Tire condition 82
Tire replacement 83
Wheel and tire combinations 84
Winter tires 85
Snow chains 85
OVERVIEWREPAIRS OPERATION CONTROLSDATAINDEX
3
CONTENTS
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
In the engine compartment:
Hood 86
Engine compartment –
MINI COOPER 87
Engine compartment –
MINI COOPER S 88
Washer fluid 89
Engine oil 89
Coolant 91
Brake fluid 92
Maintenance and care:
MINI Maintenance System 93
Caring for your vehicle 94
Vehicle immobilization 96
Laws and regulations:
OBD interface socket 96
Technical modifications 96
California Proposition 65 Warning 97
Owner Service Procedures
Replacement procedures:
Onboard tool kit 100
Windshield wiper blades 100
Lamps and bulbs 101
Repairing a flat tire 106
Changing tires – MINI
with space-saver spare tire 106
Flat tire – safety tires 110
Battery 111
Fuses 112
Giving and receiving assistance:
Warning triangle 113
First-aid kit 113
Jump-starting 113
Tow-starting and towing 115
Technical data
Engine data 120
Dimensions 121
Weights 122
Capacities 123
Electrical system 124
4
Index
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
Everything from A to Z 128
OVERVIEWREPAIRS OPERATION CONTROLSDATAINDEX
5
Notes on the Owner's Manual
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
In compiling this Owner's Manual we have
made every effort to furnish you with a
convenient reference source affording
quick access to all the essentials. The
fastest way to find detailed information on
any specific subject is to turn to the
comprehensive index at the back of the
manual. If you wish to gain an initial overview of your vehicle, you will find this in the
first chapter.
Should you wish to sell your MINI at some
time in the future, please remember to
hand over this Owner's Manual to the new
owner; it is an important part of the
vehicle.
If you have any additional questions, your
MINI center will be glad to advise you.
Symbols used
Indicates precautions that must
be followed precisely in order to
avoid the possibility of personal injury
and serious damage to the vehicle.
Contains information that will
assist you in gaining the optimum
benefit from your vehicle and enable you
to care more effectively for your vehicle.
Refers to measures that can be taken
to help protect the environment.
<
Marks the end of a specific item of
information.
Indicates special equipment, country-
*
specific equipment and optional extras.
Your individual vehicle
The manufacturer of your MINI is the
Bayerische Motoren Werke Aktiengesellschaft (BMW AG).
On purchasing your MINI, you have decided
in favor of a model with individualized
equipment and features. This Owner's
Manual describes the entire array of
options and equipment available with a
specific manufacturer model range.
We hope you will understand that equipment and features are included that you
might not have chosen for your vehicle. To
assist you in identifying possible variations
between your own vehicle and the
manual's contents, the passages describing
optional accessories and special equipment
are marked with an asterisk
*
.
6
Identifies systems or components,
which your MINI center can either
activate or adapt to suit an individual
driver's requirements ("Vehicle Memory"),
see page 41.
Symbol for vehicle parts
Indicates that you should consult
the relevant section of this Owner's
Manual for information on a particular part
or assembly.
If your MINI features equipment that is not
described in this Owner's Manual (a car
radio, for instance), we have enclosed additional Owner's Manuals. We ask you to
read these manuals as well.
Notes
Symbols
Your individual vehicle
Editorial notice
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
The manufacturer pursues a policy of
continuous, ongoing development that is
conceived to ensure that the MINI
continues to embody the highest quality
and safety standards combined with
advanced, state-of-the-art technology. For
this reason, it is possible that the features
described in this Owner's Manual could
differ from those on your vehicle. Nor can
errors and omissions be entirely ruled out.
You are therefore asked to appreciate that
no legal claims can be entertained on the
basis of the data, illustrations or descriptions in this Owner's Manual.
OVERVIEWREPAIRS OPERATION CONTROLSDATAINDEX
7
For your own safety
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
Use unleaded gasoline only. Fuels
containing up to and including
10% ethanol or other oxygenates with up
to 2.8% oxygen by weight (i.e. 15% MTBE or
3% methanol plus an equivalent amount
of co-solvent) will not void the applicable
warranties with respect to defects in materials or workmanship. Field experience has
indicated significant differences in fuel
quality (volatility, composition, additives,
others) among gasolines offered for sale in
the United States and Canada. The use of
poor-quality fuels may result in driveability,
starting and stalling problems especially
under certain environmental conditions,
such as high ambient temperature and
high altitude.
Should you encounter driveability problems which you suspect could be related to
the fuel you are using, we recommend that
you respond by switching to a recognized
high-quality brand.
Failure to comply with these recommendations may result in unscheduled maintenance.
Obey pertinent safety rules when you are
handling gasoline.<
Important safety information.
For your own safety, use genuine parts and
accessories approved by the manufacturer
of the MINI.
When you purchase accessories tested
and approved by the manufacturer of the
MINI and Original MINI Parts, you simultaneously acquire the assurance that they
have been thoroughly tested by the manufacturer of the MINI to ensure optimum
performance when installed on your
vehicle.
The manufacturer of the MINI warrants
these parts to be free from defects in material and workmanship.
The manufacturer of the MINI will not
accept any liability for damages resulting
from installation of parts and accessories
not approved by the manufacturer of the
MINI.
The manufacturer of the MINI cannot test
every product from other manufacturers to
verify if it can be used on a MINI safely and
without risk to either the vehicle, its operation, or its occupants.
Original MINI Parts, MINI Accessories and
other products approved by the manufacturer of the MINI, together with profes-
sional advice on using these items, are
available from all MINI centers.
Installation and operation of non-MINI
approved accessories such as alarms,
radios, amplifiers, radar detectors, wheels,
suspension components, brake dust
shields, telephones (including operation
of any portable cellular phone from within
the vehicle without using an externally
mounted antenna) or transceiver equipment (e.g. CB, walkie-talkie, ham radio or
similar) may cause extensive damage to
the vehicle, compromise its safety, interfere with the vehicle’s electrical system
or affect the validity of the MINI Limited
Warranty. See your MINI center for additional information.<
Maintenance, replacement, or repair
of the emission control devices and
systems may be performed by any automotive repair establishment or individual
using any certified automotive part.
<
8
The following only applies to vehicles owned and operated in the US.
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
REPORTING SAFETY DEFECTS
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately
inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying BMW of North America, LLC.,
P.O. Box 1227, Westwood, New Jersey 07675-1227, Telephone (201) 307-4000.
If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of
vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems
between you, your dealer or BMW of North America, LLC.
To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-800-424-9393 (or 366-0123 in Washington, D.C.
area) or write to: NHTSA, U.S. Department of Transportation, Washington, D.C. 20590. You can also obtain other information
about motor vehicle safety from the Hotline.
OVERVIEWREPAIRS OPERATION CONTROLSDATAINDEX
9
10
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
OVERVIEW
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
CONTROLS
OPERATION, CARE, MAINTENANCE
OWNER SERVICE PROCEDURES
TECHNICAL DATA
OVERVIEWREPAIRS OPERATION CONTROLSDATAINDEX
Overview
INDEX
11
COCKPIT
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
1>Parking lamps/Low beams 49
>
Turn signal indicators 49
>
Standing lamps 49
>
High beams 49
>
Headlamp flasher 49
>
Computer 58
12
2 Washer/Wiper system 51
3 Instrument lighting 50
4 Outside mirror adjustment 36
5 Hazard warning flashers
6 Hood release 86
7 Horn 18
8 Steering wheel adjustment 35
9 OBD interface socket 96
DISPLAY ELEMENTS
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
OVERVIEWREPAIRS OPERATION CONTROLSDATAINDEX
1 Tachometer 55
with indicator and warning lamps, see
from page 15
2 Display for computer 58
3 Speedometer with indicator and warning
lamps, see from page 15
4 Indicator for
>
Odometer 55
>
Trip odometer 55
>
Service Interval 57
>
Program display for Continuously
Variable Transmission (CVT) 48
5 Trip odometer, reset to zero 55
6 Fuel gauge 55
7 Engine coolant temperature gauge 56
13
DISPLAY ELEMENTS WITH NAVIGATION SYSTEM
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
*
1 Tachometer 55
with indicator and warning lamps, see
from page 15
2 Display for computer 58
14
3 Speedometer with indicator and warning
lamps, see from page 15
4 Trip odometer, reset to zero 55
5 Indicator for
>
Odometer 55
>
Trip odometer 55
>
Service Interval 57
>
Program display for Continuously
Variable Transmission (CVT) 48
INDICATOR AND WARNING LAMPS
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
Technology
that monitors itself
The system runs a check on the warning
and indicator lamps marked by "●" each
time you switch on the ignition. They each
light up once for different periods of time.
If a malfunction should occur in one of
these systems, the corresponding lamp
does not go out after the engine is started
or it lights up while the vehicle is moving.
You will see how to react correctly to this
below.
Red: stop immediately
Battery charge current
The battery is no longer being
charged. Indicates a defective alternator drive belt or a problem with the
charge circuit. Please contact the nearest
MINI center.
If this lamp lights up, the power-assist for
steering can be deactivated.
If the drive belt is defective, do not
continue driving. The engine could be
damaged due to overheating. When the
power-assist is deactivated, increased
steering effort is required.
Engine oil pressure
Stop immediately. Switch off
engine. Check the engine oil and
top up as required. Please contact the
nearest MINI center.
Do not continue driving, otherwise,
the engine could be damaged
because of inadequate lubrication.
●
<
●
<
Brake warning lamp
If the lamp comes on when the
parking brake is not engaged:
Check the brake fluid level. Before driving
further, be sure to comply with the information on pages 79, 57 and 92.
Brake warning lamp for Canadian
models.
With navigation system option:
Coolant temperature warning
lamp in the speedometer
If the lamp comes on while operating the vehicle, the engine has overheated. Switch off the engine immediately
and allow to cool down, see also page 56.
●
●
OVERVIEWREPAIRS OPERATION CONTROLSDATAINDEX
15
INDICATOR AND WARNING LAMPS
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
Yellow: stop immediately
Flat Tire Monitor
Flashes: tire failure.
Reduce speed immediately and
stop the vehicle.
With safety (run-flat) tires:
Reduce vehicle speed carefully to under
50 mph (80 km/h).
In both cases, avoid hard brake applications
and steering maneuvers. Check the tire
inflation pressures.
Conduct in the event of a flat tire, see
pages 106, 110.
General information on the system, see
page 62
●
Red and yellow: continue to drive;
drive cautiously
Brake warning lamp together with
yellow indicator lamps for ABS, EBV
and ASC+T/DSC:
The control system ABS, EBV and
ASC+T/DSC has failed. Drive
cautiously and defensively. Avoid
full brake applications. Please have
the system checked by your MINI
center as soon as possible.
More information on pages 60, 61
Brake warning lamp together with
the yellow indicator warning lamps
ABS, EBV and ASC+T/DSC for Cana-
dian models.
Red: an important reminder
Brake warning lamp
with parking brake applied.
More information on the parking
brake on page 44
Parking brake lamp for Canadian
models.
Fasten safety belts
Depending on model, with acoustic
signal
seconds or until the belt is engaged, depending on version.
More information on page 35
Depending on the level of equipment,
the indicator lamp is in the vicinity of
the navigation system.
Airbags
Please have the system inspected
at your MINI center.
More information on pages 31, 37
Depending on the level of equipment,
the indicator lamp is in the vicinity of
the navigation system.
●
. Lights up either for several
*
<
●
<
16
Hood/tailgate
Lights up when the hood and/or
tailgate are open.
More information on pages 27, 86
INDICATOR AND WARNING LAMPS
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
Yellow: check as soon as possible
Flat Tire Monitor ●
Stays lit: the system is defective.
Please have the system inspected
at your MINI center.
More information on page 62
Antilock Brake System (ABS)
ABS has been deactivated in
response to system malfunction.
Conventional braking efficiency is available. Please have the system inspected
at your MINI center.
More information on page 78
ABS indicator lamp for Canadian
models.
Automatic Stability Control plus
Traction (ASC+T)/Dynamic Stability
Control (DSC) ●
Indicator lamp flashes:
System active: drive and braking forces are
regulated.
The indicator lamp stays lit:
ASC+T/DSC switched off with button or
defective. In the event of a defect: please
have the system inspected at your MINI
center.
More information on pages 60, 61
●
Service Engine Soon
If the warning lamp comes on
either continuously or intermittently, this indicates a malfunction in the
emissions-related electronic systems.
Although the vehicle remains operational,
you should have the systems checked by
your MINI center at the earliest possible
opportunity.
"Service Engine Soon" warning
lamp for Canadian models
Engine electronics
Malfunction in the engine elec-
tronics. You can continue to drive
with reduced engine output or engine
speed. Please have the system inspected at
your MINI center.
●
.
*
●
Green: for your information
Turn signal indicators
Flashes when turn signal indicator
is on, also for trailer towing.
Rapid flashing: the system is defective.
More information on page 49
Cruise control
Lights up when the cruise control is
activated. Operation via the multifunction steering wheel.
More information on page 53
*
Blue: for your information
High beams
Comes on when the high beams
are on or the headlamp flasher is
actuated.
More information on page 49
OVERVIEWREPAIRS OPERATION CONTROLSDATAINDEX
17
MULTIFUNCTION STEERING WHEEL MFL
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
*
The control buttons integrated within the
MFL multifunction steering wheel have
been designed to allow you to operate a
number of accessories both quickly and
safely, without taking your eyes from the
road:
>
Some audio source functions
>
Cruise control.
The illustration shows the possible full
equipment level. For further details, please
consult the description of the relevant item
of equipment.
18
Buttons facing the driver
1 Cruise control: activate/interrupt/
deactivate
2 Continue cruise control
3 Horn
4 Cruise control: store and accelerate (+)
5 Cruise control: store and decelerate (–)
Buttons facing away from the driver
Left:
1>Radio
Press briefly: scans for stations in FM
band
Extended pressure: station tuning
>
CD
Press briefly: jump to next track
Extended pressure: fast forward in track
>
Cassette
Press briefly: stop track scan or fast
forward
Extended pressure: fast forward/
rewind
Right:
1 Volume
2 Switch between radio, cassette and CD
OVERVIEWREPAIRS OPERATION CONTROLSDATAINDEX
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
19
20
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
OVERVIEW
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
CONTROLS
OPERATION, CARE, MAINTENANCE
OWNER SERVICE PROCEDURES
TECHNICAL DATA
OVERVIEWREPAIRS OPERATION CONTROLSDATAINDEX
Controls
INDEX
21
KEYS
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
Depending on the equipment fitted, your
MINI has up to three key variations:
1 Master key with remote control and
battery
If the battery is discharged, please
consult your MINI center. Battery
changing, see next column.
2 Door and ignition key
This key can only be used to open the
doors mechanically
3 Spare key for storage in a safe place, such
as in your wallet. This key is not intended
for constant use
<
Changing battery
Replace if it is no longer possible to unlock
the vehicle via the remote control.
Only use a battery of the type speci-
fied on the battery (CR 2032) and
make absolutely sure that it is fitted in the
correct position.
1. Apply a screwdriver at the recess
2. Use the screwdriver to lever out the
cover.
Return used batteries to a recycling
point or your MINI center.
<
<
Initializing the master key with remote
control
When you activate a master key with
remote control (replacement, additional
key or after a battery change), it must be
initialized.
This initialization can be performed in two
ways:
Press button 1 or button 2, see page 24,
four times in succession
or
if the vehicle is unlocked:
1. Switch the ignition on briefly (position 2)
and then off
2. Within 10 seconds, press button 1 and
button 2, see page 24, in succession.
In the event of a system malfunction,
please contact your MINI center. You
can also obtain replacement keys and
batteries there.
<
22
CENTRAL LOCKING SYSTEM OPENING AND CLOSING – FROM OUTSIDE
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
The concept
The central locking system is ready for
operation whenever the driver's door is
closed. The doors, the tailgate and the fuel
filler door are unlocked or locked.
The central locking system can be operated:
>
From outside via the remote control as
well as via the door lock
>
From inside by pressing a button.
If operated from outside, the anti-theft
system is activated at the same time. This
prevents the doors from being unlocked via
safety lock buttons or door handles.
In the event of an accident, the central
locking system unlocks automatically. The
hazard warning system and interior lamps
are also switched on.
Via remote control
The remote control gives you an exceptionally convenient method for unlocking and
locking your vehicle. It also offers another
function:
To open the tailgate, refer to page 24.
The tailgate will open slightly, regardless of
whether it was locked or unlocked.
Whenever you unlock (lock) the vehicle,
you simultaneously deactivate (activate)
the anti-theft system, and switch the interior lamps on (off).
If the vehicle has been properly locked
using the remote control, the hazard
warning system lights up once.
When the vehicle is unlocked, the hazard
warning system does not react.
Children might be able to lock the
doors from the inside. Always take
the vehicle keys with you so that the
vehicle can be opened again from the
outside at any time.
<
For US owners only
The transmitter and receiver units comply
with part 15 of the FCC (Federal Communication Commission) regulations. Operation
is governed by the following:
FCC ID: LX8765S
LX8765E
LX8CAS
Compliance statement:
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
>
This device may not cause harmful interference, and
>
this device must accept any interference
received, including interference that may
cause undesired operation.
Any unauthorized modifications or
changes to these devices could void
the user's authority to operate this equipment.
<
OVERVIEWREPAIRS OPERATION CONTROLSDATAINDEX
23
OPENING AND CLOSING – FROM OUTSIDE
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
1 Unlocking and opening the tailgate
2 Locking and securing
If the remote control does not react,
the battery is discharged.
In the event of a system malfunction,
please contact your MINI center. You can
also obtain replacement keys and batteries
from your MINI center.
Battery changing, see page 22.
<
To unlock
1. Press button 1 once to unlock the
driver's door only
2. Press button 1 a second time to unlock
the other door as well as the tailgate and
the fuel filler door.
When the vehicle is unlocked, the hazard
warning system does not react.
To open the tailgate
Hold button 1 pressed for approx. five
seconds.
The tailgate will open slightly, regardless
of whether it was previously locked or
unlocked.
Before and after a trip, be sure that
the tailgate was not opened uninten-
tionally.
<
To lock and secure
Press button 2.
The hazard warning system flashes once.
Do not lock the vehicle if there are
passengers still inside, because they
cannot unlock the doors.<
Non-MINI systems
External systems or devices may cause local
interference in the functions of the remote
control.
In this case, use the master key to unlock
the door lock.
24
OPENING AND CLOSING – FROM OUTSIDE
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
Via the door lock
1. One turn of the key in the driver's
door lock unlocks the driver’s door only
2. Turning the key a second time unlocks
the other door, the tailgate and the fuel
filler door.
If the vehicle has been properly locked, the
hazard warning system flashes once.
When the vehicle is unlocked, the hazard
warning system does not react.
Do not lock the vehicle if there are
passengers still inside, because they
cannot unlock the doors.<
Manual operation
(in the event of electrical malfunction)
Turn the key to the extreme left or right to
unlock/lock the door.
Convenience feature via door lock
You can also operate the power windows
and the sliding/tilt sunroof via the door
lock.
> To open: with the door closed, turn the
key to the "Unlock" position and hold it
> To close: with the door closed, turn the
key to the "Lock" position and hold it.
Watch during the closing process to
be sure that no one is injured.
Releasing the key stops the operation.<
OVERVIEWREPAIRS OPERATION CONTROLSDATAINDEX
25
OPENING AND CLOSING – FROM INSIDE
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
With this switch, you operate the central
locking system when the doors are closed.
The doors and tailgate are unlocked or
locked only.
The anti-theft system is not activated. Also,
the fuel filler door remains unlocked to
allow refueling.
If the remote control has been used
to unlock only the driver's door, see
page 24, and you touch the switch when
the driver's door is open, the other door,
the tailgate, and the fuel filler door are
unlocked.
If the driver's door is closed, touching the
switch locks it.<
The central locking system can be
locked automatically as soon as you
begin to drive if you desire. This can be
adjusted to be vehicle-specific.<
To unlock and open the doors
1. Touch the switch for the central locking
system
2. Pull the door handle above the armrest
or
pull the door handle for each door twice: to
unlock first and then open.
Convenience opening mode
From ignition key position 1:
Hold the switch in the "Unlock" position.
The windows and sliding/tilt sunroof open.
Convenience closing is not possible
by means of the central locking
system. You should therefore close all the
windows and the sliding/tilt sunroof individually.<
To lock
Touch the switch for the central locking
system
or
press the individual safety lock buttons
down.
Children might be able to lock the
doors from the inside. Always take
the vehicle's keys with you so that you can
open the vehicle again from the outside at
any time.<
26
TAILGATE
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
OVERVIEWREPAIRS OPERATION CONTROLSDATAINDEX
Opening from outside
Press the button in the handle.
The tailgate opens slightly.
Opening with the remote control, see
page 24.
Manual operation
In the event of an electrical malfunction,
you can also operate the tailgate manually.
3. Fold the rear seat bench upwards
4. Pull the ring.
The tailgate is unlocked.
Closing
The handle recesses in the interior trim
panel of the tailgate make it easier to pull
the lid down.
To avoid injuries, be sure that the
travel path of the tailgate is clear
when it is closed, as with all closing procedures.
Operate the vehicle only when the tailgate
is closed. Otherwise, exhaust fumes could
penetrate the interior of the vehicle.
Should it be absolutely necessary to
operate the vehicle with the tailgate open:
1. Close all windows. Shut the sliding/tilt
sunroof
2. Sharply increase the air supply for the air
conditioning or automatic climate
control, see pages 64 and/or 67.<
27
ELECTRIC POWER WINDOWS
Online Edition for Part No. 01 41 0 156 724 - © 01/02 BMW AG
Open and close windows
From ignition key position 1:
To open:
Press the switch downwards.
The window opens until you release the
switch
or
briefly press the switch downwards.
The window opens automatically.
Pressing the switch again stops the operation.
To close:
Press the switch upwards.
The window closes until you release the
switch
or
when the engine is running:
Briefly press the switch upwards.
The window closes automatically.
Pressing the switch again stops the operation.
The window on the front passenger
side cannot be closed automati-
cally.<
Watch during the closing process to
be sure that no one is injured.<
After the ignition has been switched off:
You can use the electric power windows as
long as no one opens any of the doors.
If a door is opened during operation, the
opening/closing process stops immediately.
When leaving the vehicle, always
remove the ignition key from the
lock and remember to close the doors to
prevent children from operating the power
windows and injuring themselves, etc.<
For the convenience mode via the door
lock, refer to page 25.
28
Loading...
