Milwaukee TEMP-GUN 2266-20 Calibration Manual

MILWAUKEE ELECTRIC TOOL CORPORATION – TEST & MEASUREMENT PRODUCT

REPAIR SERVICE INSTRUCTIONS — CALIBRATION
2266-20 Laser TEMP-GUN™ Thermometer

Environmental
Condition

Perform all calibration at an ambient temperature of 23°C ± 2°C / 73.4°F ± 3.6°F and relative
humidity of 80% - allow the TEMP-GUN™ thermometer to sit at this temperature for a
minimum of 30 minutes before proceeding.

REPAIR SERVICE

INSTRUCTIONS

Calibration

MILWAUKEE ELECTRIC TOOL CORPORATION

13135 WEST LISBON ROAD ● BROOKFIELD, WISCONSIN 53005-2550 ● USA

58-92-2266d1 04/2010

i

TABLE OF CONTENTS Page

Introduction 1

1 noitamrofnI ytefaS dna snoituacerP

Symbols 1

Safety 2

Specifications 3

General Specifications 3

Basic Maintenance 4

Loading / Changing the Batteries 4

Maintaining Tool 4

Cleaning the Laser Windows 4

Scope 5

Equipment Use 5

Testing Condition and Interference 5

Field calibration Procedure 5

IR Software Calibration Check 5

IR Software Calibration Check - continued 6

KTC Software Calibration Check using Temperature Calibration 7

1

Introduction

WARNING

To avoid shock or injury, do not perform the verification tests or calibration procedures

described in the manual unless you are qualified to do so.

The information provided in this document is for the use of qualified personnel only.

CAUTION

The 2266-20 contain parts that can be damaged by static discharge.

Follow the standard practices for handling static sensitive devices.

Precautions and Safety Information

Use the Laser TEMP-Gun™ only as described in the Operator’s Manual. If you do not do so, the

protection provided by the Laser TEMP-Gun™ may be impaired. Read the “Safety Information”

page before servicing this product. In this manual, a WARNING identifies conditions and actions

that pose hazard (s) to the user; a CAUTION identifies conditions and actions that may damage the

Gun or the test instruments.

The Symbols

The symbols used on the Laser TEMP-GUN™ and in this manual are explained in Table 1.

Table A. The Symbols

Symbol Meaning

Refer to the manual, Important information.

Battery

Do not discard this product or throw away.

++

Volts Direct Current

CAUTION Laser Light - Do Not Stare Into Beam

Laser Product - Avoid Exposure: Laser Radiation
Is Emitted From This Aperture
