Quick Start Guide
for heat pump tumble dryer
T 8929 WP
These short instructions are not a substitute
for the Operating instructions supplied with the appliance.
Please read the Operating instructions supplied with
your tumble dryer before using it for the first time and
take note of the Warning and Safety instructions as well
as the full descriptions on how to use your machine.
en - AU, NZ
M.-Nr. 09 148 210
Brief instructions
A Prepare the laundry
Make sure that objects e.g.
,
detergent dispensing balls have
been removed from the laundry.
Sort the laundry (e.g. according to
^
the drying level required, the type of
fibre or weave).
Pay attention to the manufacturers'
information on the care labels:
s Do not tumble dry.
r/q Suitable for all programmes.
D Turn the programme selector
B Switch on the tumble dryer with
the s button
C Load the tumble dryer
^ Press the Door button and open the
door.
^ Load the laundry loosely into the
drum.
^ Close the door.
Programmes with drying levels
Cottons
Extra dry
Duration: 2:21
O O O O O O
h
^ Select the drying level by pressing
the X or Y button.
Further programmes
Further programmes
Sportswear
Outerwear ,
^
Press the X or Y button until the
;
required programme appears in the
display.
^
Confirm with OK.
Check the laundry is right inside the
drum so that it cannot get trapped or
damaged when the door is shut.
Timed drying programmes
Cool air: 20 mins - 1 hour
Warm air: 20 mins - 2 hours
Basket programme: 40 min. - 2:30 hours
Warm air
0:20 h:min
(0:20 - 2:00 h)
Extend / Reduce the time by pressing
^
the X or Y button.
E Select Extras / Delay start (if
required)
Anti-crease
Buzzer
Freshen up
Gentle tumble
Automatic plus ##
Cottons ###
Express ##
Hygiene ##
Proofing ##
Denim ###
Standard pillows/Large
pillows
Basket programme #
Cool air ##
Warm air ## #
Shirts ###
Outerwear ##
Minimum iron ###
Gentle smoothing ##
Silks ##
Sportswear ## #
Delicates ##
Woollens #
# selectable
1
#
either Freshen up or Gentle tumble.
##
1#1
1#1
1#1
1#1
Brief instructions
Extra options can be selected by
^
pressing the relevant button.
Delay start button
^ Press the + button.
Delay start 8:20
Start time
Finish time
^ Press the Y button to select when
you want the programme to end.
^
Confirm by pressing the OK button.
F Start the programme by pressing
the Start button
G Removing the laundry at the end of
the programme
^
Press the Door button and open the
door.
^
Remove the laundry.
^
Switch off the tumble dryer with the
s button.
^
Clean the fluff filters.
^
Close the door.
^
Empty the condensed water
container.
8:20
9:39
Cleaning and care
Condensed water container
After every programme
(or if Empty the container* appears
in the display)
A remove B empty
* To delete the message in the display:
switch the dryer off and then back on
again.
Fluff filters
After every programme
Fine filter
Only clean if Clean plinth filter
appears in the display.*
A open B remove
C disassemble/
clean
D clean
A remove
1 = Fluff filter
2 = Clean seal
with a damp
cloth
B clean
C clean
E clean F Stick the handle
with the filter
attached onto
the two guide
pins:
yellow dot must
be on the left
* To delete the message in the display:
Press the OK button.
Programme chart
Cottons Max. load 7 kg*
Extra dry, Normal+, Normal
Fabric type Single and multi-layered cotton fabrics such as towelling, T-shirts,
underwear, flannelette bed linen.
Notes
Hand iron r, Hand iron rr, Machine iron
Fabric type Cotton or linen fabrics, e.g.: table linen, bed linen, starched
Note To prevent laundry from drying out, it should be rolled up until you
Minimum iron Max. load 3.5 kg*
Normal+, Normal, Hand iron r
Fabric type Minimum iron items made of cotton, synthetic or blended fabrics,
Delicates Max. load 2.5 kg*
Normal+, Normal, Hand iron r, Hand iron rr
Fabric type Delicate items made of synthetic fibres, easy care cotton or
* Weight of dry laundry
Select Extra dry for multi-layered and very thick fabrics.
–
Do not use Extra dry for loopknit fabrics (e.g. T-shirts, underwear,
–
baby clothes), as they have a tendency to shrink.
laundry.
are ready for ironing.
e.g.: dresses, trousers, skirts and table cloths.
blended fabrics, e.g. shirts, blouses, lingerie and appliquéd
garments.
Programme chart
Woollens Max. load: 2 kg*
Fabric
type
Notes
Automatic plus Max. load: 5 kg*
Normal+, Normal, Hand iron r
Fabric
type
Shirts Max. load: 2 kg*
Normal, Hand iron r
Fabric
type
Gentle smoothing Max. load: 1 kg*
Fabric
type
Notes – Suitable for dry and damp laundry/fabrics.
* Weight of dry laundry
Woollen fabrics. Fabrics containing wool blends.
Woollen garments are fluffed up.
–
Remove garments immediately at the end of the programme.
–
Mixed loads of garments suitable for the Cottons and Minimum iron
programmes. Sort according to colour.
Shirts and blouses.
– Cotton and linen fabrics.
– Minimum iron items made of cotton, synthetic or mixed fibres. For
example: trousers, anoraks, shirts.
Dry fabrics are time-controlled and damp fabrics are smoothed
using the Hand iron function.
–
Smoothes out creasing caused during the spin cycle in the washing
machine.
–
Remove garments as soon as the programme has finished so that
they are easy to iron.
Programme chart
Express Max. load: 3.5 kg*
Extra dry, Normal+, Normal,
Hand ironr, Hand iron rr, Machine iron
Fabric type Tougher fabrics for the Cottons programme.
Note Reduced programme duration.
Denim Max. load: 3 kg*
Normal, Hand iron r
Fabric type Denim garments, e.g. trousers, jackets, skirts or shirts.
Outerwear Max. load: 2.5 kg*
Normal, Hand iron r
Fabric type Outerwear which is suitable for drying in a tumble dryer.
Proofing Max. load: 2 kg*
Fabric type For drying microfibre fabrics, ski wear, fine, closeweave cotton
garments (poplin) or tablecloths which are suitable for drying in a
tumble dryer and have been treated to provide a water and dirt
resistant finish.
Notes – This programme contains an extra fixing phase for proofing.
– Only use proofing agents which are stated by the
manufacturer as being "suitable for use on membrane
textiles" as these contain fluorochemical compounds.
–
Do not dry items which have been treated with proofing
agents containing paraffin. Fire hazard!
Sportswear Max. load: 3 kg*
Normal+, Normal, Hand iron r
Fabric type Sportswear which is suitable for drying in a tumble dryer.
Silks Max. load: 1 kg*
Fabric type Silks (which are suitable for drying in a tumble dryer), e.g. blouses
and shirts.
Notes
* Weight of dry laundry
–
Smoothes out creasing.
–
Remove garments immediately at the end of the programme.
Programme chart
Hygiene Max. load: 3.5 kg*
Fabric type Cottons and linen fabrics, which will be in direct contact with the
skin, e.g. underwear, nappies, towelling, bed linen, pillow and
mattress covers.
Note The temperature is held constant for a longer period of time to
deactivate micro-organisms, e.g. germs or house dustmites and
also to reduce the number of allergens in the laundry.
This programme should not be interrupted as this would prevent the
micro-organisms from being deactivated.
Pillows 1-2 pillows up to 80 x 40 cm
Large pillows 1 pillow up to 80 x 80 cm
Normal
Fabric type Pillows suitable for drying in a tumble dryer, with feather, down or
synthetic fillings.
Note Pillows can still feel damp after being dried. You can use this
programme several times until the pillow feels dry.
Cool air Max. load: 7 kg*
Fabric type Any item which only needs airing.
Warm air Max. load: 7 kg*
Fabric type – "Voluminous" and multi-layered fabrics whose layers have
different drying characteristics, e.g. jackets, pillows.
–
For drying individual items, e.g. bath towels, swimwear, tea
towels and small loads.
Note
Basket programme Max. load for basket: 3 kg
Notes
* Weight of dry laundry
–
Do not select the longest drying time to start with. Check the
items as you are drying them to find the optimum time.
–
The drum does not rotate in this programme.
For this reason, airing and drying may only be carried out if the
Miele drying basket (optional accessory) is fitted in the drum.
–
See the operating instructions supplied with the drying basket.
