Miele KM 7200 FR, KM 7201 FR, KM 7210 FR, KM 7262 FR Operating instructions
Operating and installation
instructions
Induction hobs
To avoid the risk of accidents or damage to the appliance it is
essential to read these instructions before it is installed and used for
the first time.
en-GB M.-Nr. 11 184 710
Contents
Warning and Safety instructions...................................................................... 4
Caring for the environment .............................................................................. 15
Guide to the appliance...................................................................................... 16
Hob...................................................................................................................... 16
KM7200FR ................................................................................................... 16
KM7201FR ................................................................................................... 17
KM7210FR ................................................................................................... 18
KM7262FR ................................................................................................... 19
Controls and display ........................................................................................... 20
Cooking zones..................................................................................................... 22
Before using for the first time .......................................................................... 25
Cleaning the hob for the first time....................................................................... 25
Switching on the hob for the first time ................................................................ 25
Induction ............................................................................................................ 26
How it works........................................................................................................ 26
Pans..................................................................................................................... 26
Power management ............................................................................................ 28
Noises.................................................................................................................. 29
Tips on saving energy ...................................................................................... 30
Setting ranges.................................................................................................... 31
Operation............................................................................................................ 32
Using the appliance............................................................................................. 32
Switching on the hob .......................................................................................... 33
Setting the power level........................................................................................ 33
Changing the power level.................................................................................... 33
Switching off a cooking zone .............................................................................. 33
Residual heat indicator........................................................................................ 34
Power level setting - Extended setting range...................................................... 34
Auto heat-up ....................................................................................................... 35
Booster function.................................................................................................. 36
Keeping warm ..................................................................................................... 37
Timer................................................................................................................... 38
Minute minder ..................................................................................................... 38
Automatic cooking zone deactivation ................................................................. 39
Using both timer functions at the same time ...................................................... 40
2
Contents
Additional functions .......................................................................................... 41
Stop&Go............................................................................................................ 41
Recall................................................................................................................... 41
Demonstration mode........................................................................................... 42
Displaying hob data............................................................................................. 42
Safety features................................................................................................... 43
System lock/safety lock ...................................................................................... 43
Safety switch-off ................................................................................................. 44
Overheating protection........................................................................................ 45
Programming ..................................................................................................... 46
Note for test institutes ...................................................................................... 49
Cleaning and care ............................................................................................. 50
Problem solving guide ...................................................................................... 52
Optional accessories ........................................................................................ 55
After sales service............................................................................................. 56
Contact in the event of a fault ............................................................................. 56
Data plate ............................................................................................................ 56
Warranty .............................................................................................................. 56
Installation.......................................................................................................... 57
Safety instructions for installation ....................................................................... 57
Safety distances.................................................................................................. 58
Installation notes ................................................................................................. 62
Building-in dimensions ....................................................................................... 63
KM7200FR ................................................................................................... 63
KM7201FR ................................................................................................... 64
KM7210FR ................................................................................................... 65
KM7262FR ................................................................................................... 66
Installation ........................................................................................................... 67
Electrical connection ........................................................................................... 68
Product data sheets ......................................................................................... 71
3
Warning and Safety instructions
This hob complies with all relevant local and national safety
requirements. Inappropriate use can, however, lead to personal
injury and material damage.
Read the operating and installation instructions carefully before
using the hob. They contain important information on safety,
installation, use and maintenance. This prevents both personal
injury and damage to the hob.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow the instructions in the
chapter on installing the hob as well as the safety instructions and
warnings.
Miele cannot be held liable for injury or damage caused by noncompliance with these instructions.
Keep these instructions in a safe place and pass them on to any
future owner.
4
Warning and Safety instructions
Correct application
This hob is intended for domestic use and use in other similar
environments.
This hob is not intended for outdoor use.
It is intended for domestic use only to cook food and keep it
warm. Any other use is not supported by the manufacturer and could
be dangerous.
This hob is not intended for use by people with reduced physical,
sensory or mental capabilities or lack of experience and knowledge,
unless they have been given supervision and instruction concerning
its use by a person responsible for their safety. They may only use
the hob unsupervised if they have been shown how to use it in a
safe way. They must be able to recognise and understand the
dangers of misuse.
5
Warning and Safety instructions
Safety with children
Children under 8 years of age must be kept away from the hob
unless they are constantly supervised.
Children over 8years of age may use the hob without supervision
if its operation has been clearly explained to them and they are able
to use it safely. Children must be able to understand and recognise
the possible dangers caused by incorrect operation.
Children must not be allowed to clean the hob unsupervised.
Please supervise children in the vicinity of the hob and do not let
them play with it.
The hob gets hot when in use and remains hot for a while after
being switched off. Keep children well away from the hob until it has
cooled down and there is no danger of burning.
Danger of burning! Do not store anything which might arouse a
child's interest in storage areas above or behind the hob. Otherwise
they could be tempted into climbing onto the appliance with the risk
of burning themselves.
Risk of burning and scalding. Place pots and pans on the cooking
zone in such a way that children cannot pull them down and burn
themselves.
Danger of suffocation! Whilst playing, children may become
entangled in packaging material (such as plastic wrapping) or pull it
over their head with the risk of suffocation. Keep packaging material
away from children.
Activate the system lock to ensure that children cannot switch on
the hob inadvertently. Use the safety lock when the hob is in use to
prevent children from altering the settings selected.
6
Warning and Safety instructions
Technical safety
Unauthorised installation, maintenance and repairs can cause
considerable danger for the user. Installation, maintenance and
repairs must only be carried out by a Miele authorised technician.
Damage to the hob can compromise your safety. Check the hob
for visible signs of damage. Do not use the hob if it is damaged.
Reliable and safe operation of this hob can only be assured if it
has been connected to the mains electricity supply.
The hob must not be connected to the inverter of an autonomous
power supply such as e.g. a solar power system. When the hob is
switched on, power surges could result in a safety switch-off. This
could damage the electronic module.
The electrical safety of this hob can only be guaranteed when
correctly earthed. It is essential that this standard safety requirement
is met. If in any doubt please have the electrical installation tested by
a qualified electrician.
To avoid the risk of damage to the hob, make sure that the
connection data on the data plate (voltage and frequency) match the
mains electricity supply before connecting it to the mains.
Consult a qualified electrician if in doubt.
Do not connect the hob to the mains electrical supply by a multi-
socket adapter or extension lead. These are a fire hazard and do not
guarantee the required safety of the appliance.
For safety reasons, this hob may only be used after it has been
built in.
This hob must not be used in a non-stationary location (e.g. on a
ship).
7
Warning and Safety instructions
Never open the casing of the hob.
Touching or tampering with electrical connections or components
and mechanical parts is highly dangerous to the user and can cause
operational faults.
While the hob is under warranty, repairs should only be
undertaken by a Miele authorised service technician. Otherwise the
warranty is invalidated.
Miele can only guarantee the safety of the appliance when
genuine original Miele replacement parts are used. Faulty
components must only be replaced by Miele spare parts.
The hob is not intended for use with an external timer switch or a
remote control system.
The hob must be connected to the electricity supply by a qualified
electrician (see “Installation – Electrical connection”).
If the mains connection cable is damaged, it must be replaced
with a special mains connection cable by a qualified electrician (see
“Electrical connection” in the “Installation” chapter).
The hob must be disconnected from the mains electricity supply
during installation, maintenance and repair work. Ensure that power
is not supplied to the appliance until after it has been installed or
until any maintenance or repair work has been carried out.
Danger of electric shock. Do not use the hob if it is faulty, or if the
ceramic surface is cracked, chipped or damaged in any way. Switch
it off immediately. Disconnect the hob from the mains electricity
supply. Contact Miele Service.
If the hob is installed behind a cabinet door, do not close the door
while the hob is in use. Heat and moisture can build up behind the
closed door. This can result in damage to the hob, the housing unit
and the floor. Do not close the door until the residual heat indicators
go out.
8
Warning and Safety instructions
In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the appliance and
its surroundings clean at all times. Any damage caused by
cockroaches or other vermin will not be covered by the warranty.
9
Warning and Safety instructions
Correct use
The hob gets hot when in use and remains hot for a while after
being switched off. There is a danger of burning until the residual
heat indicators go out.
Oil and fat can overheat and catch fire. Do not leave the hob
unattended when cooking with oil and fat. If it does ignite do not
attempt to put the flames out with water.
Disconnect the hob from the mains and use a suitable fire blanket,
saucepan lid, damp towel or similar to smother the flames.
Do not leave the hob unattended whilst it is being used. It should
be continually monitored whilst boiling and flash frying.
Flames could set the grease filters of a cooker hood on fire. Do
not flambé under a cooker hood.
Spray canisters, aerosols and other inflammable substances can
ignite when heated. Therefore do not store such items or substances
in a drawer under the hob. Cutlery inserts must be heat-resistant.
Do not heat an empty pan.
Do not heat up food in closed containers e.g. tins or sealed jars
on the hob, as pressure can build up in the container, causing it to
explode.
Do not cover the hob, e.g. with a hob cover, a cloth or protective
foil. The material could catch fire, shatter or melt if the hob is
switched on by mistake or if residual heat is still present.
When the appliance is switched on either deliberately or by
mistake, or when there is residual heat present, there is the risk of
any metal items left on the hob heating up, with the danger of
burning. Depending on the material, other items left on the hob could
also melt or catch fire. Damp pan lids might adhere to the ceramic
surface and be difficult to dislodge. Do not use the appliance as a
resting place. Switch the cooking zones off after use.
10
Warning and Safety instructions
You could burn yourself on the hot hob. Protect your hands with
heat-resistant pot holders or gloves when handling hot pots and
pans. Do not let them get wet or damp, as this causes heat to
transfer through the material more quickly with the risk of scalding or
burning yourself.
When using an electrical appliance, e.g. a hand-held food blender,
near the hob, ensure that the cable of the electrical appliance cannot
come into contact with the hot hob. The insulation on the cable
could become damaged.
Grains of salt, sugar and sand (e.g. from cleaning vegetables) can
cause scratches if they get under pan bases. Make sure that the
ceramic surface is clean before placing pans on it.
Even a light object can cause damage in certain circumstances.
Do not drop anything on the ceramic surface.
Placing hot pans on the sensors and indicators could damage the
electronics underneath. Do not place hot pans on the sensors or
indicators.
Do not allow solid or liquid sugar, or pieces of plastic or aluminium
foil to get onto the hob when it is hot, as they can damage the
ceramic surface when it cools down. If this should occur, switch off
the appliance and scrape off all the sugar, plastic or aluminium
residues whilst still hot, using a shielded scraper blade suitable for
use on glass. Wear oven gloves when doing this. Allow the ceramic
surface to cool down and then clean it with a suitable ceramic hob
cleaning agent.
Pans which boil dry can cause damage to the ceramic glass. Do
not leave the hob unattended whilst it is being used.
Only use pots and pans with smooth bases. Rough bases will
scratch the ceramic glass.
Lift pans into position on the hob. Sliding them into place can
cause scuffs and scratches.
11
Warning and Safety instructions
Because induction heating works so quickly, the base of the pan
could, under certain circumstances, heat up to the temperature at
which oil or fat self-ignites within a very short time. Never leave the
hob unattended during use!
Heat oil or fat for a maximum of one minute. Never use the
Booster function to heat oil or fat.
For people fitted with a heart pacemaker: Please note that the
area immediately surrounding the hob is electromagnetically
charged. It is very unlikely to affect a pacemaker. However, if in any
doubt, consult the manufacturer of the pacemaker or your doctor.
To prevent damage to items which are susceptible to
electromagnetic fields, e.g. credit cards, digital storage devices,
pocket calculators, etc, do not leave them in the immediate vicinity
of the hob.
Metal utensils stored in a drawer under the hob can become hot if
the appliance is used intensively for a long time.
The hob is fitted with a cooling fan. If a drawer is fitted directly
underneath the hob, ensure that there is sufficient space between
the drawer and its contents and the underside of the hob in order to
ensure sufficient ventilation for the hob.
If a drawer is fitted directly underneath the hob, do not store any
pointed or small items, paper, serviettes, etc. in the drawer. They
could get in through the ventilation slots or be sucked into the casing
by the fan and damage the fan or impair cooling.
Do not use twopans on a cooking zone or extended zone at the
same time.
If the cookware only partially covers a cooking or extended zone,
the handle could become very hot.
Always place cookware in the middle of a cooking or extended zone!
12
Warning and Safety instructions
The induction generators could be damaged or even destroyed if
you use an induction adapter plate for cookware. Do not use
induction adapter plates.
13
Warning and Safety instructions
Cleaning and care
Do not use a steam cleaning appliance to clean this hob.
The steam could reach electrical components and cause a short
circuit.
If the hob is built in over a pyrolytic oven, the hob should not be
used whilst the pyrolytic process is being carried out, as this could
trigger the overheating protection mechanism on the hob (see
relevant section).
Miele will guarantee to supply functional spare parts for a
minimum of 10years and up to 15years following the
discontinuation of your hob.
14
Caring for the environment
Disposal of the packing material
The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also
reduces the amount of waste in landfill
sites.
Disposing of your old appliance
Electrical and electronic appliances
often contain valuable materials. They
also contain specific materials,
compounds and components, which
were essential for their correct function
and safety. These could be hazardous
to human health and to the environment
if disposed of with your domestic waste
or if handled incorrectly. Please do not,
therefore, dispose of your old appliance
with your household waste.
Please dispose of it at your local
community waste collection / recycling
centre for electrical and electronic
appliances, or contact your dealer or
Miele for advice. You are also
responsible for deleting any personal
data that may be stored on the
appliance being disposed of. Please
ensure that your old appliance poses no
risk to children while being stored prior
to disposal.
15
Guide to the appliance
Hob
KM7200FR
a
Cooking zone with TwinBooster
b
Cooking zone with TwinBooster
c
Cooking zone with TwinBooster
d
Controls and indicators
16
KM7201FR
Guide to the appliance
a
Cooking zone with TwinBooster
b
Cooking zone with TwinBooster
c
Cooking zone with TwinBooster
d
Cooking zone with TwinBooster
e
Controls and indicators
17
Guide to the appliance
KM7210FR
a
Cooking zone with TwinBooster
b
Cooking zone with TwinBooster
c
Extended zone with TwinBooster
d
Cooking zone with TwinBooster
e
Controls and indicators
18
KM7262FR
Guide to the appliance
a
Cooking zone with TwinBooster
b
Cooking zone with TwinBooster
c
Extended zone with TwinBooster
d
Cooking zone with TwinBooster
e
Controls and indicators
19
Guide to the appliance
Controls and display
Sensor controls
a
For switching the hob on and off
b
Numerical keybank
- For setting the power level
- For setting the timer
c
Timer
- For switching on and off
- For switching between timer functions
- For selecting a cooking zone (see “Switching a cooking zone off
automatically” in the “Timer” chapter)
d
Stop & Go
e
Cooking zone selection and display
Cooking zone ready for use
Keep-warm setting
to Power level
TwinBooster level 1
TwinBooster level 2
No pan on cooking zone or pan unsuitable (see “Pans” in the
“Induction” chapter)
Residual heat
Auto heat-up
20
Displays/indicator lights
f
Timer display
to Duration in minutes
System lock/safety lock activated
Demonstration mode activated
g
Automatic switch-off allocation of cooking zones
h
Extended power level range setting
i
Stop&Go activated
j
Timer
Guide to the appliance
21
Guide to the appliance
Cooking zones
Cooking
zone
Øin cm
1
KM7200FR
Max. rating
in watts for 230V
2
cooking
3
zone
Linked
14–28 Normal
TwinBooster, level 1
TwinBooster, level 2
14–19 Normal
TwinBooster, level 1
TwinBooster, level 2
10–16 Normal
TwinBooster, level 1
TwinBooster, level 2
2600
3300
5500
1850
2500
3000
1400
1700
2200
and
Total 7300
1
Cookware with a base diameter within the given range may be used.
2
The wattage quoted may vary depending on the size and material of the cookware used.
3
The cooking zone is linked to this cooking zone electrically so that the rating can be
increased; see “Operation – Power management”.
22
Cooking
zone
Øin cm
Guide to the appliance
KM7201FR
1
Max. rating
in watts for 230V
2
cooking
3
zone
Linked
16–22 Normal
TwinBooster, level 1
TwinBooster, level 2
10–16 Normal
TwinBooster, level 1
TwinBooster, level 2
14–19 Normal
TwinBooster, level 1
TwinBooster, level 2
14–19 Normal
TwinBooster, level 1
TwinBooster, level 2
2300
3000
3650
1400
1700
2200
1850
2500
3000
1850
2500
3000
Total 7300
1
Cookware with a base diameter within the given range may be used.
2
The wattage quoted may vary depending on the size and material of the cookware used.
3
The cooking zone is linked to this cooking zone electrically so that the rating can be
increased; see “Operation – Power management”.
23
Loading...
