Miele KFN 7714 F Operating instructions

Operating instructions Fridge-freezer
To avoid the risk of accidents or damage to the appliance it is essen- tial to read these instructions before it is installed and used for the first time.
en-GB M.-Nr. 11 733 220
Contents
Side-by-side combinations ............................................................................ 15
Climate range ................................................................................................. 15
Ventilation....................................................................................................... 16
Horizontal and vertical gaps........................................................................... 16
Weight of the furniture door ........................................................................... 17
Installation in a tall unit/side view................................................................... 18
Connections and ventilation........................................................................... 19
Moving the door shelf/bottle shelf.................................................................. 24
Adjusting or removing the bottle holder......................................................... 24
Moving the shelves......................................................................................... 24
Removing the fruit and vegetable drawer ...................................................... 24
Possible temperature settings ........................................................................ 29
Switching Holiday mode on and off ......................................................... 32
2
Contents
Maximum freezing capacity ........................................................................... 38
Making ice cubes ........................................................................................... 40
3

Warning and Safety instructions

This refrigeration appliance complies with current safety require­ments. Inappropriate use can, however, lead to personal injury and material damage.
Please read the operating and installation instructions carefully be­fore using the refrigeration appliance for the first time. They con­tain important information on safety, installation, use and mainten­ance. This is to protect yourself from injury, and from damaging your refrigeration appliance.
In accordance with standard IEC60335-1, Miele expressly and strongly advises that you read and follow all information provided on installing the refrigeration appliance, as well as the safety notes and warnings.
Miele cannot be held liable for injury or damage caused by non­compliance with these instructions.
Keep these operating and installation instructions in a safe place and pass them on to any future owner.

Correct application

This refrigeration appliance is intended for use in the home and in
similar environments, for example – in shops, offices and similar work settings – by the guests in hotels, motels, bed & breakfasts and other typical home settings. This refrigeration appliance is not intended for outdoor use.
This appliance is intended for domestic use only for cooling and
storing food and drink as well as for storing deep frozen food, freez­ing fresh food and for making ice. Any other usage is not supported by the manufacturer and could be dangerous.
4
Warning and Safety instructions
This refrigeration appliance is not suitable for storing and keeping
cool medicines, blood plasma, laboratory preparations or similar substances or products that are subject to the Medical Device Dir­ective. Incorrect use of the refrigeration appliance for such purposes may cause deterioration of the items stored. The refrigeration appli­ance is also not suitable for use in areas where there is a risk of ex­plosion. Miele cannot be held liable for damage caused by improper or incor­rect use or operation of the appliance.
The appliance can only be used by people with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, if they are supervised whilst using it, or have been shown how to use it in a safe way and recognise and understand the consequences of incorrect operation.

Safety with children

Children under 8 years of age must be kept away from the refri-
geration appliance unless they are constantly supervised.
Children 8 years and older may only use the appliance unsuper-
vised if they have been shown how to use it in a safe way and recog­nise and understand the consequences of incorrect operation.
Children must not be allowed to clean or maintain the appliance
unsupervised.
Please supervise children in the vicinity of the appliance and do
not let them play with it.
Danger of suffocation! Whilst playing, children could become en-
tangled in packaging (such as plastic wrapping) or pull it over their head and suffocate. Keep packaging material away from children.
5
Warning and Safety instructions

Technical safety

The coolant circuit has been checked for leaks. The refrigeration
appliance complies with statutory safety requirements and the ap­propriate EU directives.
This refrigeration appliance contains the refrigerant isobutane
(R600a), a natural gas which is environmentally friendly but flam­mable. The refrigerant does not damage the ozone layer and does not contribute to the greenhouse effect. The use of this refrigerant has, however, led to a slight increase in the noise level of the appliance. In addition to the noise of the com­pressor, you might be able to hear the refrigerant flowing around the cooling circuit. Unfortunately, this cannot be avoided, but it does not affect the performance of the refrigeration appliance. When transporting and installing the refrigeration appliance, ensure that no parts of the cooling circuit are damaged. Splashes of refri­gerant can damage the eyes. In the event of damage:
- Avoid naked flames or anything which creates a spark.
- Disconnect the refrigeration appliance from the mains electricity supply.
- Ventilate the room where the refrigeration appliance is located for several minutes.
- Contact the Miele Customer Service Department.
The more coolant there is in a refrigeration appliance, the larger
the room it should be installed in. In the event of a leakage, if the ap­pliance is in a small room, there is the danger of a combustible gas/ air mixture building up. For every 11g of coolant at least 1m3 of room space is required. The amount of coolant in the refrigeration appliance is stated on the data plate inside the appliance.
6
Warning and Safety instructions
To avoid the risk of damage to the appliance, make sure that the
connection data (fuse rating, frequency and voltage) on the data plate corresponds to the household supply. Check that this is the case before connecting the appliance. Consult a qualified electrician if in any doubt.
The electrical safety of this appliance can only be guaranteed
when correctly earthed. It is essential that this standard safety re­quirement is met. If in any doubt please have the electrical installa­tion tested by a qualified electrician.
Reliable and safe operation of this appliance can only be assured
if it has been connected to the mains electricity supply.
If the electrical connection cable is faulty it must only be replaced
by a Miele authorised service technician to protect the user from danger.
Do not connect the appliance to the mains electrical supply by a
multi-socket adapter or extension lead. These are a fire hazard and do not guarantee the required safety of the appliance.
If moisture gets into electrical components or into the mains con-
nection cable, it could cause a short circuit. Therefore, do not oper­ate this refrigeration appliance in areas which are exposed to mois­ture (e.g in a garage or utility room).
This appliance must not be used in a non-stationary location (e.g.
on a ship).
Do not use a damaged appliance. It could be dangerous. Check
the appliance for visible signs of damage.
For safety reasons, this appliance may only be used after it has
been built in.
The appliance must be isolated from the electricity supply during
installation, maintenance and repair work.
7
Warning and Safety instructions
Unauthorised installation, maintenance and repairs can cause
considerable danger for the user. Installation, maintenance and repairs must only be carried out by a Miele authorised technician.
While the appliance is under warranty, repairs should only be un-
dertaken by a Miele authorised service technician. Otherwise the warranty is invalidated.
Faulty components must only be replaced with genuine Miele ori-
ginal spare parts. Miele can only guarantee the safety standards of the appliance when Miele replacement parts are used.
This refrigeration appliance is supplied with a special lamp to
cope with particular conditions (e.g. temperature, moisture, chemical resistance, abrasion resistance and vibration). This lamp must only be used for the purpose for which it is intended. The lamp is not suit­able for room lighting. Replacement lamps may only be fitted by a Miele authorised technician or by the Miele Customer Service De­partment. This refrigeration appliance contains several light sources with energy efficiency class E.

Proper installation

When installing the refrigeration appliance, it is a mandatory re-
quirement to follow the installation instructions supplied with it.
Two people are required to install the refrigeration appliance.Change the door hinging (if necessary) as described in the install-
ation instructions supplied with the appliance.
The refrigeration appliance must be installed level. This is the only
way to ensure safe and proper operation.
Only install the refrigeration appliance in a solid, rectangular and
level housing unit, positioned on an even and level floor.
8
Warning and Safety instructions

Correct use

This refrigeration appliance is designed for use within specific am-
bient temperatures (climate range). Do not use in ambient temperat­ures for which it is not designed. The climate range is stated on the data plate in the interior cabinet of the refrigeration appliance. A lower ambient temperature will cause the compressor to switch off for longer periods, meaning that the refrigeration appliance is unable to maintain the required temperature.
Do not cover or block the air vents as this could impair the effi-
ciency of the appliance, increase the electricity consumption and could cause damage to the components.
If storing food which contains a lot of fat or oil in the appliance or
the door, make sure that it does not come into contact with plastic components as this could cause stress cracks or break the plastic.
Risk of fire and explosion. Do not store explosive materials in the
refrigeration appliance or any products containing propellants (e.g. spray cans). Electrical components can cause flammable mixes of gases to ignite.
Danger of explosion. Do not operate any electrical equipment (e.g.
an electric ice-cream maker) inside the refrigeration appliance. Danger of sparking and explosion.
Danger of injury and damage to the appliance. Do not store cans
or bottles containing carbonated drinks or liquids which could freeze in the freezer zone. Otherwise they could burst.
Danger of injury and damage to the appliance. When cooling
drinks quickly in the freezer zone, make sure bottles are not left in for more than one hour. Otherwise they could burst.
Danger of injury. Never handle frozen food or the metal parts of
the appliance with wet hands. Your hands may freeze to the frozen food or to the metal.
9
Warning and Safety instructions
Danger of injury. Do not take ice cubes out with your bare hands
and never place ice cubes or ice lollies in your mouth straight from the freezer zone. The very low temperature of the frozen food can cause frost burn to the lips and tongue.
Do not refreeze partially or fully defrosted food. Consume defros-
ted food as soon as possible, as it will lose its nutritional value and spoil if left for too long. Defrosted food may only be re-frozen after it has been cooked.
Observe the manufacturer's “use-by” dates and storage instruc-
tions given on food to avoid the risk of food poisoning. Storage times will depend on several factors, including the freshness and quality of the food, as well as the temperature at which it is stored.

Accessories and spare parts

Only use genuine original Miele accessories and spare parts with
this appliance. Using accessories or spare parts from other manu­facturers will invalidate the warranty, and Miele cannot accept liabil­ity.
Miele will guarantee to supply functional spare parts for a min-
imum of 10years and up to 15years following the discontinuation of your refrigeration appliance.
10
Warning and Safety instructions

Cleaning and care

Do not use any oils or grease on the door seals, as these will
cause the seals to deteriorate and become porous with time.
Do not use a steam cleaning appliance to clean or defrost this ap-
pliance. Steam could reach electrical components and cause a short circuit.
Sharp edged or pointed objects will damage the evaporator, caus-
ing irreversible damage to the appliance. Do not use sharp edged or pointed objects to
- remove frost and ice,
- separate frozen food or remove ice trays.
Do not place electric heaters or candles in the appliance to de-
frost it. These can damage the plastic parts.
Do not use defrosting sprays or de-icers, as they could contain
substances which could damage the plastic parts or which might cause the build-up of gases and pose a danger to health.
11
Warning and Safety instructions

Transport

Always transport the appliance in an upright position and in its ori-
ginal transport packaging to avoid damage in transit.
Danger of injury and damage to the appliance. The refrigeration
appliance is very heavy and must be transported by two people.

Disposal of your old appliance

If your old refrigeration appliance has a door lock, destroy it. This
will prevent the risk of children playing accidentally locking them­selves in and endangering their lives.
Splashes of coolant can damage the eyes. Be careful not to dam-
age any part of the pipework whilst awaiting disposal, e.g. by
- puncturing the coolant channels in the condenser,
- bending any pipework, or
- scratching the surface coating.

Symbol on the compressor (depending on model)

This information is only relevant for recycling. There is no risk during normal oper­ation.
The oil in the compressor can be fatal if swallowed or if it penet-
rates the airways.
12

Caring for the environment

Disposal of the packing mater­ial
The packaging is designed to protect the appliance from damage during transportation. The packaging materials used are selected from materials which are environmentally friendly for disposal and should be recycled.
Recycling the packaging reduces the use of raw materials in the manufactur­ing process and also reduces the amount of waste in landfill sites.
Disposing of your old appli­ance
Electronic and electrical appliances contain many valuable materials. They also contain certain materials, com­pounds and components which were essential for their correct functioning and safety. These could be hazardous to your health and to the environment if disposed of with general waste or if handled incorrectly. Please do not, therefore, dispose of your old appliance with general waste.
Instead, please make use of officially designated collection and disposal points to dispose of and recycle elec­trical and electronic appliances in your local community, with your dealer or with Miele. By law, you are solely re­sponsible for deleting any personal data from the appliance prior to disposal.
Take care not to damage your refrigera­tion appliance’s pipework before or dur­ing transportation to an authorised col­lection depot. This is to ensure that coolant in the cooling circuit and oil in the compressor is contained, and will not leak into the environment.
Please ensure that your old appliance poses no risk to children while being stored prior to disposal. For further in­formation, see “Warning and Safety in­structions” in these operating and in­stallation instructions.
13
*INSTALLATION*

Installation

Installation site

Risk of damage and danger of
injury due to the refrigeration appli­ance tipping over.
This refrigeration appliance is very heavy and can tip forwards when the appliance door is open.
Keep the appliance door(s) closed until the refrigeration appliance has been built in. The refrigeration appli­ance must be secured in its building­in niche in accordance with the oper­ating and installation instructions.
Fire risk and risk of damage from
appliances which give off heat. Appliances which give off heat can
catch fire and set fire to the refrigera­tion appliance.
This refrigeration appliance must not be installed underneath a hob.
Fire risk and danger of damage
from open flames. Open flames can set fire to the refri-
geration appliance. Keep open flames (e.g. a candle)
away from the refrigeration appli­ance.
This appliance should be installed in a dry, well-ventilated room.
When deciding on the installation site, please bear in mind that your refrigera­tion appliance will use more energy if installed near to a heater, a cooker or other appliance that gives off heat. Avoid direct sunlight. The higher the ambient temperature, the longer the compressor runs and the higher the energy consumption is.
Risk of damage due to high hu-
midity. In environments with high humidity,
condensation can build up on ex­ternal refrigeration appliance panels. This condensate can cause corrosion on external appliance panels.
Install the refrigeration appliance in a dry and/or air-conditioned room with sufficient ventilation.
After installation please make sure that the appliance door(s) closes (close) properly and the refrigeration appliance is installed in accordance with these installation instructions. It is essential to comply with the spe­cified ventilation cutout require­ments.
14
*INSTALLATION*
Installation

Side-by-side combinations

Risk of damage due to condens-
ation on external appliance panels. In environments with high humidity,
condensation can build up on ex­ternal appliance panels, which can cause corrosion.
Do not place different refrigeration appliance models directly next to or on top of one other.
If you want to place refrigeration ap­pliances without integrated heating units next to each other, a distance of 150mm must be maintained between them.

Climate range

This refrigeration appliance is designed for use within specific ambient temper­atures (climate range). Do not use in ambient temperatures for which it is not designed. A lower room temperature leads to the compressor switching off for longer periods. This can cause the internal temperature in the refrigeration appli­ance to rise with the risk of food deteri­orating and going off.
The climate range is stated on the data plate in the interior cabinet of the refri­geration appliance.
Climate range Ambient room
temperature
SN +10to +32°C
N +16to +32°C
ST +16to +38°C
T +16to +43°C
A refrigeration appliance from the SN climate range can operate without any difficulties in rooms with a cooler am­bient temperature (down to +5°C).
15
*INSTALLATION*
Installation

Ventilation

Risk of fire and damage due to
insufficient ventilation. If the refrigeration appliance is not
ventilated sufficiently, the com­pressor will run more frequently and for longer periods. This will result in increased energy consumption and a higher operating temperature for the compressor. This may, in turn, cause damage to the compressor.
Please ensure that there is adequate ventilation around the refrigeration appliance.
It is essential to observe the required ventilation gaps.
The ventilation gaps must not be covered or blocked in any way.
They must also be regularly dusted.
Air at the back of the refrigeration appli­ance gets warm. The appliance housing unit must therefore be constructed to allow sufficient space for ventilation (see “Installation dimensions” and the installation instructions provided).

Furniture door panel

Horizontal and vertical gaps

Depending on the style of kitchen fur­niture the thickness and edge radius of the furniture door panel and the gap that runs around the door, vertically and horizontally, are specified.
It is essential to pay attention to the following:
–Horizontal gap
The gap between the furniture door panel and the housing unit door above or below it must be at least 3mm.
–Vertical gap
If the gap between the refrigeration appliance furniture door panel and the adjoining housing unit door or wall on the hinged side is too small, the appliance door could collide with the adjoining housing unit door or wall when opened.
It may be necessary to adjust the size of this gap to suit the thickness and edge radius of the appliance fur­niture door.
16
This must be taken into consideration when planning your kitchen and when replacing an old refrigeration appliance with a new one to ensure the installation conditions required are met.
*INSTALLATION*
Installation
Appliance furniture door
Gap X [mm]
for different
edge radii B thickness A [mm]
R0 R1 R2 R3
≥16–19 2.5
20 3 3 2.5 2.5
21 3 3 2.5 2.5
22 4 3.5 3 3
Adjoining kitchen furniture front
A=Furniture front thickness B=Edge radius X=Gap

Weight of the furniture door

If the furniture door panel is too
heavy, this can cause damage. Fitting a furniture door panel which is
heavier than the maximum permitted weight could damage the hinges. This can cause subsequent func­tional problems.
The maximum permissible weights of the furniture doors in kg are:
Refrigeration appliance
KFN 7714 F 15 15
Upper furniture door panel
Lower furniture door panel
Adjoining side wall
A=Furniture front thickness B=Edge radius X=Gap
Tip: Fit a spacer between the housing unit carcase and the side wall. This way you will get a sufficiently wide gap.
17
Loading...
+ 39 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
