Miele G6827SCICLSTXXL User Manual

Download
Page 1
Operating instructions for dishwashers
To avoid the risk of accidents or damage to the appliance, it is essential to read these instructions as well as the installation plan before it is installed and used for the first time.
en-AU, NZ M.-Nr. 10 601 520HG05
Page 2
2
Page 3
Contents
Caring for the environment ................................................................................ 19
Energy-saving dishwashing................................................................................... 20
EcoFeedback consumption indicator.................................................................... 21
Before using for the first time ............................................................................ 22
Opening the door .................................................................................................. 22
Closing the door.................................................................................................... 22
Safety lock............................................................................................................. 22
Basic settings........................................................................................................ 23
Before using the appliance for the first time, you require: .................................... 25
Dishwasher salt ..................................................................................................... 25
Filling the salt reservoir..................................................................................... 26
Add salt reminder ............................................................................................. 27
Rinse aid................................................................................................................ 28
Adding rinse aid ...............................................................................................28
Add rinse aid reminder ..................................................................................... 29
Loading the dishwasher...................................................................................... 30
Notes ..................................................................................................................... 30
FlexAssist .............................................................................................................. 32
Upper basket......................................................................................................... 32
Adjusting the upper basket ..............................................................................35
Lower basket......................................................................................................... 36
Cutlery ................................................................................................................... 39
3D cutlery tray + (depending on model)........................................................... 39
Cutlery basket (depending on model) ..............................................................41
Loading examples ................................................................................................. 42
Dishwashers with cutlery tray........................................................................... 42
Dishwashers with cutlery basket......................................................................44
Comparison tests ................................................................................................ 46
Standard height with cutlery tray .......................................................................... 46
XXL height with cutlery tray................................................................................... 49
Operation.............................................................................................................. 52
Detergent............................................................................................................... 52
Adding detergent.............................................................................................. 54
3
Page 4
Contents
Switching on.......................................................................................................... 55
Selecting a programme ......................................................................................... 55
Starting the programme ........................................................................................ 56
Time display .......................................................................................................... 56
Energy management ............................................................................................. 57
At the end of the programme ................................................................................ 57
Switching off.......................................................................................................... 58
Unloading the dishwasher..................................................................................... 58
Interrupting a programme...................................................................................... 59
Changing a programme......................................................................................... 59
Programme options............................................................................................. 60
Options.................................................................................................................. 60
FlexiTimer .............................................................................................................. 61
DetergentAgent ..................................................................................................... 65
Programme chart ................................................................................................66
Further programmes ........................................................................................ 70
Cleaning and care ............................................................................................... 71
Cleaning the wash cabinet .................................................................................... 71
Cleaning the door and the door seal..................................................................... 71
Cleaning the door front ......................................................................................... 72
Checking the filters in the wash cabinet ............................................................... 73
Cleaning the filters................................................................................................. 73
Cleaning the spray arms........................................................................................ 75
Problem solving guide ........................................................................................76
Technical problems ............................................................................................... 76
Water inlet fault ..................................................................................................... 78
Water drainage fault .............................................................................................. 79
General problems.................................................................................................. 80
Noises.................................................................................................................... 82
Unsatisfactory washing result ............................................................................... 83
Maintenance ........................................................................................................86
Cleaning the water inlet filter................................................................................. 86
Cleaning the drain pump and non-return valve..................................................... 87
After sales service............................................................................................... 88
Repairs .................................................................................................................. 88
Warranty ................................................................................................................ 88
Optional accessories ..........................................................................................89
4
Page 5
Contents
Electrical connection ..........................................................................................91
Water connection ................................................................................................ 92
The Miele Waterproof system................................................................................ 92
Connection to the water supply ............................................................................ 92
Drainage ................................................................................................................ 94
Technical data...................................................................................................... 95
Technical data ....................................................................................................... 95
Settings menu...................................................................................................... 96
Opening the Settings menu................................................................................... 96
Language ........................................................................................................... 96
Time of day............................................................................................................ 97
Water hardness ..................................................................................................... 98
Rinse aid................................................................................................................ 99
Consumption (EcoFeedback)................................................................................ 99
5
Page 6

Guide to the appliance

Guide to the appliance

a
Upper spray arm (not visible)
b
Cutlery tray (depending on model)
c
Upper basket
d
Middle spray arm
e
Heat exchanger return (depending on
model)
f
Lower spray arm
6
g
Filter combination
h
Data plate
i
Rinse aid reservoir
j
Dual compartment detergent dispenser
k
Salt reservoir
Page 7

Control panel

Guide to the appliance
a
Programme selection
b
Display
c
Option buttons
d
Start button with indicator light
e
Arrow buttons 
These operating instructions apply to several different dishwasher models with different heights. The specific dishwasher models are referred to as follows: Standard = 80.5 cm high dishwashers (integrated) and 84.5 cm high dishwashers (freestanding) XXL = 84.5 cm high dishwashers (integrated)
f
OK button
g
button (FlexiTimer) with indicator light
h
Programme selector button
i
On/Off button
7
Page 8
Guide to the appliance

Display

General

The display is used to select or set the following:
– the programme
– the FlexiTimer (Delay start)
– the Settings menu
The display can show the following:
– the current time of day
– the stage the programme is at
– the estimated time left for the
programme to run
– the energy and water consumption
(EcoFeedback)
– any relevant fault messages and
information
To save energy, the dishwasher switches off after a few minutes if you do not press any buttons during this time. To switch the dishwasher back on again, press the button.

Settings menu

The Settings menu is used to alter the dishwasher's electronics to suit different requirements. You access the Settings menu by pressing a specific button combination (see "Settings menu").
The arrows in the display indicate further options. You can use the  arrow buttons underneath the display, as appropriate, to select these further options.
The OK button is used to confirm a message or setting and also to move to the next menu or another level.
The option which is selected will have a tick next to it.
To exit a sub-menu, use the  arrow buttons to select the Back  option in the display and confirm your selection with OK. If you do not press any of the buttons for several seconds, the display will return to the previous level. You may need to enter your settings again.
8
Page 9

Warning and Safety instructions

This dishwasher complies with current safety requirements. Inappropriate use can, however, lead to personal injury and damage to property.
To avoid the risk of accidents and damage to the dishwasher, please read the installation plan and the operating instructions carefully before it is installed and used for the first time. They contain important information on its installation, safety, use and maintenance.
Keep the installation plan and the operating instructions in a safe place and pass them on to any future owner.
Miele cannot be held liable for damage caused by non-compliance with this information.
9
Page 10
Warning and Safety instructions

Correct application

This appliance is designed for domestic use and for use in similar
environments by guests in hotel or motel rooms, bed & breakfasts and other typical living quarters. This does not include common/ shared facilities or commercial facilities within hotels, motels or bed & breakfasts.
This dishwasher is not suitable for outdoor use.It must only be used as specified in these operating instructions
for cleaning domestic crockery and cutlery. Any other usage is not supported by the manufacturer and could be dangerous.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning its use by a person responsible for their safety, and are able to recognise the dangers of misuse.
10
Page 11
Warning and Safety instructions

Safety with children

Young children must not be allowed to use this appliance.Older children may only use the appliance when its operation has
been clearly explained to them and they are able to use it safely, recognising the dangers of misuse.
Cleaning work may only be carried out by older children under the
supervision of an adult.
Children should be supervised to ensure that they do not play with
the appliance. Keep small children away from the appliance at all times to avoid the risk of injury. There is the risk that children may lock themselves in the dishwasher.
If the automatic door opening mechanism (depending on model) is
active, keep young children away from the area in which the door opens. Danger of injury in the unlikely event of a fault with the opening mechanism.
Danger of suffocation! Children may be able to wrap themselves in
packing material or pull it over their heads with the risk of suffocation. Keep children away from any packing material.
Keep detergent and other household agents out of the reach of
children at all times. Some dishwasher detergents are strongly alkaline and contain irritants and corrosive ingredients. They can be extremely dangerous if swallowed, and can cause burning in the mouth, nose and throat, or inhibit breathing. Avoid contact with the skin and eyes. Keep children away from the dishwasher when the door is open. There could still be detergent residues in the cabinet or dispenser. Check that the dispenser is empty after the completion of a programme. Seek medical advice immediately if your child has swallowed or inhaled detergent, e.g. Poisons Information Centre (Australia) or National Poisons Centre (NZ).
11
Page 12
Warning and Safety instructions

Technical safety

Repairs and other work by unqualified persons could be
dangerous. Installation, maintenance work and repairs to electrical appliances must only be carried out by a Miele approved service technician.
Before installation, check the dishwasher for visible signs of
damage. Under no circumstances should you use a damaged dishwasher. A damaged dishwasher could be dangerous.
The electrical safety of this appliance can only be guaranteed
when continuity is complete between it and an effective earthing system. It is most important that this basic safety requirement is present and regularly tested and, where there is any doubt, the electrical system in the house should be checked by a qualified electrician. Miele cannot be held liable for the consequences of an inadequate earthing system (e.g. electric shock).
Reliable and safe operation of this dishwasher can only be
assured if it has been connected to the mains electricity supply.
The dishwasher must only be plugged into the electricity supply
via a suitable switched socket. The electrical socket must be easily accessible after the dishwasher is installed so that it can be disconnected from the electricity supply at any time.
There must be no electrical sockets behind the dishwasher.
Danger of overheating and fire risk if the dishwasher were to be pushed up against a plug.
The dishwasher must not be installed under a cooktop. The high
radiant temperatures which are sometimes generated by a cooktop could damage the dishwasher. For the same reason, it should not be installed next to open fires or other appliances which give off heat, such as heaters etc.
12
Page 13
Warning and Safety instructions
To avoid the risk of damage to the dishwasher, make sure that the
connection data on the data plate (fuse rating, voltage and frequency) matches the mains electricity supply before connecting the dishwasher to the mains. Consult a qualified electrician if in any doubt.
Do not connect the dishwasher to the mains supply until it has
been fully installed and any adjustment has been made to the door springs.
The dishwasher may only be operated if the door opening
mechanism is working correctly. Otherwise there could be a risk of injury whilst the automatic door opening mechanism (depending on model) is active. To check that the door opening mechanism is working correctly:
– the door springs must be adjusted equally on both sides. They
are correctly adjusted when the door remains stationary when left half open (approx. 45° opening angle). It is also important that the door cannot fall open.
– the door locking pins automatically retract when the door opens
at the end of the drying phase.
Do not connect the appliance to the mains electricity supply by a
multi-socket adapter or an extension lead. These do not guarantee the required safety of the appliance (e.g. danger of overheating).
This appliance must not be installed and operated in mobile
installations (e.g. on a ship).
Do not install the dishwasher in a room where there is a risk of
frost. Frozen hoses may burst or split. The reliability of the electronic control unit may be impaired at temperatures below freezing point.
To avoid any damage to the appliance, the dishwasher must only
be operated when it is connected to a fully vented plumbing system.
The plastic housing of the water connection contains an electrical
valve. The housing must not be dipped in water.
13
Page 14
Warning and Safety instructions
There are electrical wires in the water inlet hose. Do not cut the
water inlet hose, even if it is too long.
The integrated Waterproof system offers protection from water
damage, provided the following conditions are met:
– The dishwasher is correctly installed and plumbed in.
– The dishwasher is properly maintained and parts are replaced
where it can be seen that this is necessary.
– The tap has been turned off when the appliance is not used for a
longer period of time (e.g. during holidays).
The Waterproof system will work even if the appliance is switched off. However, the appliance must remain connected to the electricity supply.
The water pressure (flow pressure at the connection point) must
be between 50 and 1000 kPa (0.5 and 10 bar).
A damaged appliance could be dangerous. If the dishwasher gets
damaged, switch it off at the mains and call Miele.
The manufacturer's warranty will be invalidated if the appliance is
not repaired by a Miele approved service technician.
Faulty components must only be replaced by genuine Miele spare
parts. The manufacturer can only guarantee the safety of the appliance when Miele replacement parts are used.
During installation, maintenance and repair work, the appliance
must be disconnected from the mains electricity supply.
If the mains connection cable is damaged, it must be replaced
with a special cable of the same type (available from Miele) by a Miele authorised service technician only in order to avoid a hazard.
14
Page 15
Warning and Safety instructions
This dishwasher is supplied with a special lamp (depending on
model) to cope with particular conditions (e.g. temperature, moisture, chemical resistance, abrasion resistance and vibration). This special lamp must only be used for the purpose for which it is intended. It is not suitable for room lighting. Replacement lamps may only be replaced by a Miele authorised technician.
In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the appliance and its surroundings in a clean condition at all times. Any damage which may be caused by cockroaches or other vermin will not be covered by the warranty.
15
Page 16
Warning and Safety instructions

Correct installation

The dishwasher must be installed and connected in compliance
with the installation instructions.
Be careful when installing the dishwasher. Wear
protective gloves to avoid injury on any sharp metal components.
The dishwasher must be correctly aligned to ensure problem-free
operation.
In order to ensure stability, built-under and integrated dishwashers
must only be installed under a continuous worktop which is secured to adjacent cabinetry.
If you want to convert your freestanding dishwasher to a built-
under ("U") model, you will need to order the appropriate conversion kit. If you remove the existing plinth, you must replace it with a U­model plinth. This is necessary to avoid the risk of injury caused by protruding metal parts.
The door springs on either side need to be evenly adjusted. They
are correctly adjusted if the half-opened door (approx. 45° door opening angle) remains in this position when it is released. The door must not fall down under its own weight. The appliance may only be used with correctly adjusted door springs.
16
Page 17
Warning and Safety instructions

Correct use

Do not use solvents in the dishwasher. Danger of explosion!Do not inhale or ingest dishwasher detergent. Some dishwasher
detergents are strongly alkaline and contain irritants or corrosive ingredients. They can be extremely dangerous if swallowed, and can cause burning in the nose, mouth and throat, or inhibit breathing. Avoid contact with the skin and eyes. Seek medical advice immediately if detergent has been swallowed or inhaled, e.g. Poisons Information Centre (Australia) or National Poisons Centre (NZ).
Avoid leaving the door open unnecessarily as someone could trip
over it and be injured by it.
Do not sit or lean on the opened door. This could cause the
dishwasher to tip and be damaged, and you could get injured.
Dishes can be very hot at the end of a programme. Allow them to
cool until they are comfortable enough to handle before unloading.
Only use detergent and rinse aid formulated for domestic
dishwashers. Do not use washing-up liquid.
Do not use commercial or industrial detergents as these may
cause damage, and there is a risk of a severe explosive chemical reaction (such as an explosive oxyhydrogen gas reaction).
Do not fill the rinse aid reservoir with powder or liquid detergent.
This will cause serious damage to the reservoir.
Inadvertently filling the salt reservoir with powder or liquid
dishwasher detergent will damage the water softener. Make sure you have picked up the correct packet of dishwasher salt before filling the salt reservoir!
Only use special coarse grained dishwasher salt for reactivation.
Do not use other salts such as cooking salt, agricultural grade or gritting salt. These may contain insoluble additives which can impair the functioning of the water softener.
17
Page 18
Warning and Safety instructions
In an appliance with a cutlery basket (depending on model) cutlery
is cleaned and dried more efficiently if placed in the basket with the handles downwards. However, to avoid the risk of injury, place knives and forks etc. with the handles upwards.
Plastic items which cannot withstand being washed in hot water,
such as disposable plastic containers, or plastic cutlery and crockery should not be cleaned in the dishwasher. The high temperatures in the dishwasher may cause them to melt or lose shape.
If you use the "FlexiTimer/Delay start" option (depending on
model), make sure that the dispenser is dry before adding detergent. Wipe dry if necessary. Detergent will clog if poured into a damp dispenser and may not be thoroughly dispersed.
Please observe the information given in "Technical data" regarding
the capacity of the dishwasher.

Accessories

Use only genuine original Miele spare parts. If spare parts or
accessories from other manufacturers are used, the warranty will be invalidated, and Miele cannot accept liability.

Disposal of your old dishwasher

Make the door lock inoperative so that children cannot
accidentally shut themselves in. Remove or destroy the locking bracket of the door lock, and make appropriate arrangements for the disposal of the appliance.
18
Page 19

Caring for the environment

Disposal of the packing material

The transport and protective packaging has been selected from materials which are environmentally friendly for disposal, and can normally be recycled.
Recycling the packaging reduces the use of raw materials in the manufacturing process and also reduces the amount of waste in landfill sites. Ensure that any plastic wrappings, bags etc. are disposed of safely and kept out of the reach of babies and young children. Danger of suffocation.

Disposing of your old appliance

Electrical and electronic appliances often contain valuable materials. They also contain specific materials, compounds and components, which were essential for their correct function and safety. These could be hazardous to human health and to the environment if disposed of with your domestic waste or if handled incorrectly. Please do not, therefore, dispose of your old appliance with your household waste.
Please dispose of it at your local community waste collection / recycling centre for electrical and electronic appliances. You are also responsible for deleting any personal data that may be stored on the appliance prior to disposal. Please ensure that your old appliance poses no risk to children while being stored prior to disposal.
19
Page 20
Caring for the environment

Energy-saving dishwashing

This dishwasher is exceptionally economical in its use of water and electricity. You can make the most of your appliance by following these tips:
– For most economical dishwashing,
make full use of the baskets without overloading the dishwasher.
– Choose the programme to suit the
type of crockery being washed and the degree of soiling.
– Select the ECO programme for
energy-saving dishwashing. This programme is the most efficient in terms of its combined energy and water consumption at cleaning normally soiled crockery.
– If your dishwasher is connected to a
hot water supply, select the SolarSave programme for washing a lightly to moderately soiled load. Because the water is not heated in this programme, crockery may still be slightly damper at the end of this programme than it would be with other programmes.
– Follow the detergent manufacturer's
recommendations on detergent dosage.
– When using powder or liquid
detergent you can use 1/3 less detergent if baskets are only half full.
You can find further tips on energy­saving dishwashing in "Miele's guide to dishwashing".
20
Page 21
Caring for the environment

EcoFeedback consumption indicator

The Consumption function is used for calling up information about the energy and water consumption of your dishwasher (see "Settings menu ­Consumption").
Three different types of information can be displayed:
– an estimate of the consumption
before the programme begins
– the actual consumption at the end of
the programme
– the total consumption of the
dishwasher

1. Consumption estimate:

After a programme has been selected, first the name of the programme and, after a few seconds, the estimated energy and water consumption will appear in the display.

2. Actual consumption

At the end of the programme you can call up the actual amount of energy and water used by the programme which has just been run.
Press OK when the Consumption (OK)
message appears in the display.
Switching the dishwasher off at the end of the programme will delete the actual consumption values for the programme which has just been run.

3. "Consumption" setting

The Consumption setting gives a total of the energy and water which has been used in all previous dishwasher programmes (see "Settings menu ­Consumption").
The estimated consumption levels will be displayed as a bar chart. The more bars () in the display, the more energy or water will be used.
The values are influenced by the programme selected and any programme options selected.
The display will change automatically to show the time remaining.
The consumption indicator is switched on as standard. However, you can also switch the indicator off (see "Settings menu - Consumption").
21
Page 22

Before using for the first time

Opening the door

At the end of programmes with a drying phase (see "Programme chart"), the door will open automatically a little in order to help the drying process. This function can be deactivated, if preferred (see "Settings menu ­AutoOpen").
To open the door, reach under the
door grip and pull.

Closing the door

Push the baskets right in.Then lift the door upwards and push
until it clicks into position.
Danger of injury!
Do not put your hand inside the door as it is closing.

Safety lock

The child safety lock can be used to prevent children opening the dishwasher. The door can then only be opened by using a lot of force.
Open the door fully so that the door
catch rail retracts again.
If the door is opened during operation, all functions are automatically interrupted.
Water in the dishwasher may be
hot. Danger of scalding! Only open the door during operation
if absolutely necessary and exercise extreme caution when doing so.
Keep the area around the door
free of obstructions.
22
To lock the door, push the slide
underneath the door grip to the right.
To unlock the door, push the slide to
the left.
Page 23
Before using for the first time

Basic settings

Switch the dishwasher on with the
button.
The welcome screen will appear when the dishwasher is switched on for the first time.

Language

The display will change automatically to the screen for setting the language.
Use the  arrow buttons to select
the language you want and also the country, if appropriate, and confirm your selection with OK.
To learn about the display, read the section with the same name.
A tick will appear next to the language that has been set.

Time of day

The display will then change to the screen for setting the time.
The time of day needs to be set before the "FlexiTimer" programme option can be used. You can also show the current time of day in the display.
Use the  arrow buttons to set the
hour and confirm with OK.
Then set the minutes and confirm
with OK.
Keeping the  arrow buttons pressed in will increase or decrease the time automatically.
The display will then change to the screen for setting the clock display.
Select whether or not the time of day
should appear in the display and confirm your selection with OK.
 If you have selected Display On,
confirm the message about higher energy consumption with OK.
23
Page 24
Before using for the first time

Water hardness

The display will change to the screen for setting the water hardness.
– The dishwasher must be
programmed to the correct water hardness for your area.
– Your local water authority will be able
to advise you of the water hardness level in your area.
– Where the water hardness fluctuates
e.g. between 1.8 and 2.7mmol/l (10­15°d - German scale), always programme the dishwasher to the higher value (2.7mmol/l or 15°d in this example).
In the event of a fault, it will help the service technician if you know the hardness of your local water supply.
Enter the water hardness below:
____________mmol/l
The dishwasher is programmed at the factory for a water hardness level of 0.2 mmol/l (1°d - German scale).
Finally, prompts will appear in the display.
After confirming these prompts with
OK, the messages Add salt andAdd rinse aid may appear.
Add salt and rinse aid if necessary
(see "Before using for the first time ­Dishwasher salt" and "Rinse aid").
Confirm the messages with OK.
The programme selected will appear briefly in the display and the appropriate indicator light will come on. Then, if applicable, the estimated energy and water consumption for the programme selected will appear for a few seconds. Finally, the display will show the estimated programme duration for the programme selected.
Use the  arrows to select the
hardness of your water supply and confirm with OK.
See "Settings menu - Water hardness" for more information.
24
Page 25
Before using for the first time

Before using the appliance for the first time, you require:

– approx. 1 kg dishwasher salt,
– domestic dishwasher detergent,
– rinse aid formulated for domestic
dishwashers.
Every dishwasher is tested at the factory. There will be residual water in the appliance from this test. It is not an indication that it has been used previously.

Dishwasher salt

In order to achieve good cleaning results, the dishwasher needs to operate with soft water. Hard water results in a build-up of calcium deposits on crockery and in the dishwasher. Mains water with a hardness level higher than 0.7mmol/l (4°d - German scale) needs to be softened. This takes place automatically in the integrated water softener. The water softener in the dishwasher is suitable for a water hardness level of up to 12.6 mmol/l (70°d - German scale).
If the water in your area is very soft and constantly lower than 0.9mmol/l (5°d - German scale), you do not have to add dishwasher salt. The prompt to add salt will be switched off automatically if the water softener has been programmed for this to happen.
Dishwasher detergent will
damage the water softener. Do not fill the salt reservoir with
powder or liquid detergent.
Only use special coarse grained
dishwasher salt for reactivation, as other salts (e.g. cooking salt,
agricultural grade or gritting salt) may contain insoluble additives which can impair the functioning of the water softener.
The water softener requires dishwasher salt. Depending on the water hardness level (< 3.8mmol/l, or 21°d - German scale), dishwasher salt is not required if combination tablets are being used (see "Operation, Detergent").
25
Page 26
Before using for the first time

Filling the salt reservoir When filling the salt reservoir only

open the door halfway to ensure
that all the salt gets into the reservoir.
Press the button on the lid of the salt
reservoir in the direction of the arrow.
The flap will spring open.
Do not fill the reservoir with water.
Add dishwasher salt only until the
reservoir is full or until water runs out of the opening. The salt reservoir holds approx. 1kg of salt, depending on the brand used.
Do not add any more than 1kg of salt.
As the salt reservoir is filled, displaced water may overflow.
Lift up the funnel.
26
Clean any excess salt from around
the reservoir opening and then close the flap.
Immediately after filling the salt
reservoir, run the QuickPowerWash programme with the Short option and without any crockery in the dishwasher to dissolve and remove any traces of salt from the cabinet.
Page 27
Before using for the first time

Add salt reminder

Fill the salt reservoir with dishwasher
salt for reactivation when Add salt appears in the display (If it appears during a programme, wait until the end of the programme).
Confirm with OK.
The refill reminder will go out.
Risk of corrosion!
Immediately after filling the salt reservoir, run the QuickPowerWash programme with the Short programme option selected and without any crockery in the dishwasher to remove any traces of salt from the cabinet.
After the salt reservoir has been filled, the refill reminder may still appear in the display if the salt concentration has not yet reached the correct level. If this is the case, confirm again with OK.
If you only ever use multi-function combination products in your dishwasher, you can switch off both refill reminders for salt and rinse aid if you wish (see "Settings menu ­Switching off the refill reminders").
If you switch to using detergent that does not contain salt or rinse aid, it is important to remember to add dishwasher salt and rinse aid and to switch the reminders back on.
The refill reminder will be switched off if you have programmed the dishwasher for a water hardness below 0.9mmol/l (5°d - German scale).
27
Page 28
Before using for the first time

Rinse aid

Rinse aid is necessary to ensure water does not cling and leave marks on crockery during the drying phase and helps crockery dry faster after it has been washed. Rinse aid is poured into the storage reservoir and the amount set is dispensed automatically.
Inadvertently filling the rinse aid
reservoir with powder or liquid detergent will damage the reservoir. Only pour rinse aid formulated for domestic dishwashers into the reservoir.
Alternatively, it is possible to use
– household vinegar with a max. 5%
acid content
or
– liquid citric acid up to 10% acid
content
If you only ever use combination products containing rinse aid in your dishwasher, you do not need to add rinse aid.

Adding rinse aid

Press the button on the lid of the
rinse aid reservoir in the direction of the arrow until the flap springs open.
The resulting rinsing and drying quality will not, however, be as good as when rinse aid is used.
Do not use vinegar with a higher
acid content (e.g. vinegar essence 25% acid).
This would damage the dishwasher.
28
Page 29
Add rinse aid only until it is visible in
the opening.
The rinse aid reservoir holds approx. 110 ml.
Close the flap firmly so that it clicks
into place. Otherwise water can enter the rinse aid reservoir during a programme.
Before using for the first time

Add rinse aid reminder

When the Add rinse aid message appears in the display, the reservoir contains sufficient rinse aid for 2 - 3 programmes only.
Add rinse aid in plenty of time.Confirm with OK.
The refill reminder will go out.
If you only ever use multi-function combination products in your dishwasher, you can switch off both refill reminders for salt and rinse aid if you wish (see "Settings menu ­Switching off the refill reminders").
If you switch to using detergent that does not contain salt or rinse aid, it is important to remember to add dishwasher salt and rinse aid and to switch the reminders back on.
Wipe up any spilled rinse aid. This
prevents over-foaming occurring during the next programme.
You can adjust the rinse aid dosage for best results (see "Settings menu ­Rinse aid").
29
Page 30

Loading the dishwasher

Notes

Remove coarse food residues from crockery.
There is no need to rinse items under running water.
Do not wash items soiled with
ash, sand, wax, lubricating grease or paint in the dishwasher. Ash does not dissolve and is distributed in the wash cabinet. Wax, sand, lubricating grease and paint cause damage to the dishwasher.
Crockery can be loaded anywhere in the baskets, but the following notes should be observed:
– Do not place crockery and cutlery
inside other pieces where they may be concealed.
– Load the crockery so that water can
access all surfaces. This ensures that they get properly cleaned.
– Make sure that all items are securely
positioned.
– The spray arms must not be blocked
by items which are too tall or hang through the baskets. If in doubt, test for free movement by manually rotating the spray arms.
– Make sure that small items cannot
fall through the holders in the baskets. Small items, e.g. lids, should therefore be placed in the cutlery tray or cutlery basket (depending on model).
Some foodstuffs may contain natural dyes, e.g. carrots, tomatoes or tomato sauce. Plastic items in the dishwasher may discolour if large quantities of these foodstuffs find their way into the dishwasher on the crockery. The stability of plastic items is not affected by this discolouration. Cleaning silver cutlery in the dishwasher may also cause plastic items to discolour.
– Hollow items such as cups, glasses,
pans, etc. must be inverted in the basket.
– Tall, narrow, hollow items, e.g.
champagne glasses, should be placed in the centre of the basket to ensure better water coverage.
– Wide based items should be placed
at an angle so that water can run off them freely.
30
Page 31
Loading the dishwasher

Items not suitable for dishwashers:

– Wooden cutlery and crockery or
items with wooden parts: these may discolour and fade. The glue used in these items is not dishwasher-proof and wooden handles may come loose after being washed in a dishwasher.
– Craft items, antiques, valuable vases
and decorative glassware are also not suitable for dishwashers.
– Plastic items which are not heat-
resistant: the high temperatures in the dishwasher may cause them to melt or lose shape.
– Copper, brass, tin and aluminium
items may discolour or become matt.
– Colours painted over a glaze may
fade after a number of washes.
– Delicate glassware and glassware
containing lead crystal: clouding may occur over time.
Please note
Silverware previously cleaned with a silver polish may still be damp or
spotted at the end of a programme, where water has not run off smoothly. It may need to be rubbed dry with a soft cloth.
Aluminium components (e.g.
rangehood grease filters) must not be cleaned with caustic alkaline commercial or industrial cleaning agents.
These may damage the material, or in extreme cases, there is a risk of a severe explosive chemical reaction (such as an explosive oxyhydrogen gas reaction).
Useful tip: When purchasing new crockery and cutlery, make sure they are dishwasher-proof.

Glass care

– Clouding may occur on glasses after
frequent washing. If delicate glassware is washed in the dishwasher, ensure that only very low temperatures are used (see programme chart), or a special glass­care programme is used (depending on model). This will reduce the risk of clouding.
– Purchase glassware which is
dishwasher-safe (e.g. Riedel glassware).
– Use detergents with glass protective
additives.
Silver which has been in contact with foods containing sulphur can discolour. These include egg yolk, onions, mayonnaise, mustard, pulses, fish, fish brine and marinades.
31
Page 32
Loading the dishwasher

FlexAssist

The yellow coded FlexAssist parts indicate which elements of the dishwasher baskets and cutlery tray are moveable. They also act as grips and have symbols embossed on them to show what the moveable parts are used for.

Upper basket

See "Loading the dishwasher ­Loading examples" for examples of how to load crockery and cutlery.
For safety reasons, do not
operate the dishwasher without the upper and lower baskets in place (except when running the Tall items programme, if available).
Use the upper basket for small,
lightweight and delicate items such as cups, saucers, glasses, dessert bowls, etc. Shallow pans or casserole dishes can also be placed in the upper basket.

Cup rack

Raise the rack upwards using the
yellow lever to make room for tall items.
Glasses can be arranged along the positioning rail of the cup rack to give them some support during the programme.
Lower the cup rack and lean the
glasses against it.
Long items such as soup ladles,
mixing spoons and long knives should be placed lying down across the front of the upper basket.
32
Page 33
Loading the dishwasher

Hinged spikes

The rows of spikes can be lowered to make more room for larger items such as casserole dishes.
Press the yellow lever downwards
and then lower the spikes .

Jumbo cup rack (depending on model)

The cup rack can be set at two different widths so that it can also accommodate large cups.
Pull the cup rack upwards and click it
back into position at the required width.
33
Page 34
Loading the dishwasher

Glass rail

This rail is designed to hold glasses with long stems securely.
Lower the rail with the yellow lever
and lean tall glasses against it.
You can also move one of the side
inserts in the cutlery tray to make more room for tall glasses (see "Cutlery, 3D cutlery tray").

Adjusting the height

You can set the glass rail at two different heights.
Pull the rail upwards and click it back
into position at the required height.
Use the low setting for small glasses and tumblers.
Use the high setting for tall glasses and glasses with stems.
34
Page 35
Loading the dishwasher

Adjusting the upper basket

In order to gain more space for taller pieces of crockery in the bottom or upper basket, the upper basket can be adjusted on three levels with 2 cm between each level.
The upper basket can also be set at an angle with one side high and the other side low. This can be useful to help prevent water being left in deep dishes etc. Ensure, however, that the basket can be inserted smoothly into the cabinet. It is better to adjust the basket before loading it.
Pull out the upper basket.
Depending on the setting of the upper basket, the following plate dimensions can be accommodated.

Dishwashers with cutlery basket

(see data plate for model number)
Upper
basket
level
Top 20 24 31 (35*)
Middle 22 26 29
Bottom 24 28 27

Dishwashers with cutlery tray

(see data plate for model number)
Upper
basket
level
Plate in cm
Upper basket Lower
Stand-
ard
Upper basket Lower
Stand-
ard
XXL
Plate in cm
XXL
basket
basket

To raise the upper basket:

Pull the basket up until it clicks into
place.

To lower the upper basket:

Pull upwards on the levers at either
side of the upper basket.
Adjust the basket to the desired
height and then push the levers securely back down into position.
Top 15 19 31 (35*)
Middle 17 21 29
Bottom 19 23 27
* When tilted, plates of up to 35 cm can be accommodated (see "Lower basket").
35
Page 36
Loading the dishwasher

Lower basket

See "Loading the dishwasher ­Loading examples" for examples of how to load crockery and cutlery.
For larger and heavier items such as
plates, serving platters, saucepans, bowls, etc. Glasses, cups and small items such as saucers can also be placed in the lower basket. Do not place thin, delicate glassware in the lower basket.

Removable MultiComfort insert

The rear section of the lower basket is used for washing cups, glasses, plates, pots and pans.
You can remove the MultiComfort insert to make more room for larger items such as pans and casserole dishes.

Removing the insert

Pull the yellow handle forwards and
remove the insert.

Refitting the insert

Place large platters and dishes in the
centre of the lower basket.
When tilted, plates up to 35cm in diameter can be accommodated.
36
Fit the insert into the lower basket
with the hooks going under the long cross-piece as illustrated.
Press down on the insert until it clicks
into position .
Page 37
Loading the dishwasher

FlexCare glass holder

Silicone padding in the FlexCare glass holder provides a stable and secure hold for delicate stemware.
Stem glassware, e.g. wine glasses or
champagne flutes, can be leaned against the glass holder or suspended from it.
The glass holder can be raised to
make more room for tall items.
You can set the glass holder at two different heights.

Glass rail

This rail is designed to hold glasses with long stems securely.
Lower the rail and lean tall glasses
against it.
Slide the glass holder to the desired
height until the catches click into place at the top or rest on the bottom.
37
Page 38
Loading the dishwasher

Hinged spikes

The spikes at the front are used for washing plates, soup bowls, platters, dessert bowls and saucers.
Both rows of spikes can be lowered to make more room for large items, e.g. pots, pans and dishes.
Press the yellow lever downwards,
and then lower the spikes.

Bottle holder

The bottle holder can be used to wash narrow items, e.g. milk and baby bottles.
If the bottle holder is not needed, lift
it up and fold the sides down , as illustrated.
38
Page 39
Loading the dishwasher

Cutlery

3D cutlery tray + (depending on model)

See "Loading the dishwasher ­Loading examples" for examples of how to load crockery and cutlery.
Arrange the cutlery in the tray as
shown.
To make unloading much easier, cutlery should be grouped in zones, one for knives, one for forks, one for spoons, etc.
Spoon heads should be placed in contact with at least one of the serrated retainers on the base of the cutlery tray to ensure that water runs off them freely.
The upper spray arm must not be blocked by items which are too big (e.g. cake servers).
The side sections of the tray can be moved into the middle using the yellow grips in order to accommodate tall items of crockery in the upper basket (see also "Upper basket, glass rail").
If spoon handles do not fit between the holders, then lay them the other way round.
For optimum cleaning results, arrange spoons with the inner part facing the centre of the cutlery tray.
39
Page 40
Loading the dishwasher
You can use the yellow slide to adjust the height of the middle section of the cutlery tray to make more room for large items of cutlery, such as serving spoons and ladles.
Both rows of spikes in the middle section of the cutlery tray can be flipped over to make room for larger pieces of cutlery.
Raise the spikes and then flip them
over.
40
Page 41

Cutlery basket (depending on model)

The cutlery basket can be placed anywhere on the front rows of spikes in the lower basket.
To avoid the risk of injury, knives and
forks should be placed with the handles upwards in the basket. However, cutlery placed handle down in the basket will come out cleaner and drier.
Loading the dishwasher
Fit it onto the cutlery basket if
required.
Place small items of cutlery in the
individual slots on three sides of the cutlery basket.

Cutlery insert for the cutlery basket

Use the insert supplied for heavily soiled items of cutlery. The insert separates the items so that they can be more easily accessed by water.
Insert cutlery with the handles facing
downwards.
Distribute them evenly along the
insert.
41
Page 42
Loading the dishwasher

Loading examples

Dishwashers with cutlery tray

Upper basket
Lower basket
42
Page 43
Cutlery tray
Heavily soiled items
Loading the dishwasher
43
Page 44
Loading the dishwasher

Dishwashers with cutlery basket

Upper basket
Lower basket
44
Page 45
Cutlery basket
Heavily soiled items
Loading the dishwasher
45
Page 46

Comparison tests

Standard height with cutlery tray

Test standard: AS/NZS 2007.1:2005, AS/NZS 2007.2:2005;
AS/NZS 6400:2005
Standard programme
for energy label comparison tests:
Capacity: 14 place settings
Detergent quantity: 32.5 g in Compartment II
Rinse aid dispensing: Setting 3
You can find information on adjusting the rinse aid dosage in the "Rinse aid" section of this booklet.
The door opens automatically during the drying phase. Do not close the door until the drying test has finished.
Upper basket level:
Position: Bottom
Jumbo cup rack (if available):
ECO
Outer position

Loading examples

Pictures illustrating how to load the dishwasher are shown on the following pages. Picture : Upper basket Picture : Lower basket Picture : Cutlery tray
Do not lower or remove the basket inserts.
Remove the bottle holder from the lower basket (if available).
46
Page 47

Capacity

14
Comparison tests
47
Page 48
Comparison tests
48
Page 49
Comparison tests

XXL height with cutlery tray

Test standard: AS/NZS 2007.1:2005, AS/NZS 2007.2:2005;
AS/NZS 6400:2005
Standard programme
for energy label comparison tests:
Capacity: 15 place settings
Detergent quantity: 33.7 g in Compartment II
Rinse aid dispensing: Setting 3
You can find information on adjusting the rinse aid dosage in the "Rinse aid" section of this booklet.
The door opens automatically during the drying phase. Do not close the door until the drying test has finished.
Upper basket level:
Position: Bottom
Jumbo cup rack (if available):
ECO
Outer position

Loading examples

Pictures illustrating how to load the dishwasher are shown on the following pages. Picture : Upper basket Picture : Lower basket Picture : Cutlery tray
Do not lower or remove the basket inserts.
Remove the bottle holder from the lower basket (if available).
49
Page 50
Comparison tests

Capacity

15
50
Page 51
Comparison tests
51
Page 52

Operation

Detergent

Only use detergents formulated
for domestic dishwashers. Do not use washing-up liquid.

Active ingredients

Modern detergents contain various active ingredients, the most important of which are:
– Complexing agents to prevent
calcification.
– Alkalis to aid the removal of dried on
soiling.
– Enzymes to break down starch and
loosen protein.
– Oxygen based bleaching agents to
remove coloured stains (e.g. tea, coffee, tomato sauce).
Most dishwasher detergents are mildly alkaline and contain enzymes and oxygen based bleaching agents.
You can also buy combination products (see "Programme options ­DetergentAgent", if applicable). In addition to detergent, these products contain rinse aid and salt substitutes. They are available as "3 in 1" or when they also contain other components such as glass and stainless steel protective additives and enhanced cleaning power, as "5 in 1", "7 in 1", "All in 1" etc. Refer to the manufacturer's packaging as to whether combination products are suitable for the water hardness level in your area. Please note that the cleaning and drying results of combination detergents can vary greatly.
For optimum cleaning and drying results, use Miele dishwasher detergent and add Miele salt and Miele rinse aid separately. See "Optional accessories".
Types of detergent:
– Powder and liquid gel detergents.
These detergents allow you to adjust the amount dispensed according to the amount of load and level of soiling.
– Tab detergents. These are suitable for
most levels of soiling.
52
Page 53
Operation

Detergent dosage

Follow the dosage recommended by
the manufacturer on the packaging.
Unless directed otherwise, use one
detergent tab or add 20 to 30ml detergent to compartmentII, depending on the level of soiling. With very heavy soiling you can also add a small amount of detergent to compartmentl.
Tabs may not dissolve completely
when the "QuickPowerWash" programme (if available) is used.
Failure to dispense the recommended amount of detergent may impair cleaning results.
Dishwasher detergents contain
irritant or corrosive ingredients which can cause burning in the nose, mouth and throat if swallowed, or inhibit breathing.
Avoid inhalation of powder detergents and do not ingest dishwasher detergent. Seek medical advice immediately if detergent has been swallowed or inhaled. Keep detergent and other household agents out of the reach of children at all times. Keep children away from the dishwasher when the door is open. There could still be detergent residues in the cabinet. To avoid the danger of children coming into contact with the dishwasher detergent, only add detergent just before starting the programme and close the door, activating the safety lock (if your dishwasher is fitted with one).
53
Page 54
Operation

Adding detergent

Press the opening catch on the
detergent dispenser. The flap will spring open.
The flap is always open at the end of a programme.
Add the required amount of detergent
and close the flap.
Make sure that the detergent
packaging is properly closed after use to avoid it getting damp and becoming lumpy.

For information

Compartment I holds max. 10 ml, Compartment II holds max. 50 ml.
54
There are marks in Compartment II to assist with dispensing: 20, 30. The marks indicate a level of approx. 20 or 30 ml when the door is open in a horizontal position.
Page 55
Operation

Switching on

Make sure the spray arms are not
obstructed.
Close the door.Turn on the tap if it is turned off.Press the button for at least
2seconds.
The programme selected will appear briefly in the display and the appropriate indicator light will come on. Then, if applicable, the estimated energy and water consumption for the programme selected will appear for a few seconds. Finally, the display will show the estimated programme duration for the programme selected.

Selecting a programme

Choose your programme according to the type of load and how dirty it is.
The different programmes and their uses are described in the Programme chart later on in this booklet.
Use the programme selector button
to select the programme required.
The indicator light next to the selected programme will come on.
Further programmes are selected via the Further option.
Use the programme selector button
to select the Further option.
The first of the further programmes will appear in the display.
Use the  arrow buttons to select
the programme required.
During the course of the programme you can use OK to display the name of the programme which is currently running.
You can now select programme options (see "Programme options").
If any programme options are selected, the appropriate indicator lights will also light up.
55
Page 56
Operation

Starting the programme

Press the Start or OK button.
The programme will begin.
The Start indicator light will come on.
A programme should only be cancelled in the first few minutes, if at all. Otherwise important programme stages could be omitted.

Time display

The estimated duration of the programme selected appears in hours and minutes in the display before the programme begins. During the programme, the time left until the end of the programme is displayed.
Each programme stage is indicated by a symbol:
Pre-wash / Soak Main wash Interim rinse Final rinse Drying Finish
The programme duration displayed may vary with the same programme. It is influenced by, among other things, the water temperature at each intake, the reactivation process, the water softener, the type of detergent, the amount of crockery and how dirty it is.
56
When a programme is selected for the first time, the display will show the average programme duration for a cold water intake.
The times shown in the Programme chart refer to standard test loads and temperatures.
Each time a programme is run, the electronic unit takes the new conditions into account, and calculates the time required.
Page 57
Operation

Energy management

To save energy, the dishwasher will switch off automatically a few minutes after the last time a button has been pressed or after the end of a programme.
Press the button to switch the
dishwasher back on.
The dishwasher will not switch off automatically if the time of day display has been activated (see "Settings menu
- Time of day").
The dishwasher will not switch off whilst a programme or the FlexiTimer is running or if there is a fault.

At the end of the programme

The programme has finished when Finished appears in the display and the door has opened slightly (if applicable).
In the QuickPowerWash programme the door will not open until a few minutes after the programme has finished.
If the Consumption programmable function is switched on, you can now call up the actual energy and water consumption of the programme which has just finished (see "Caring for the environment - EcoFeedback consumption indicator").
The drying fan may continue to run for a few minutes at the end of the programme.
Open the door fully so that the door
catch rail retracts again.
You can now empty the dishwasher.
If you have deactivated the
automatic door opening function (see "Settings menu - AutoOpen"), but would still like to open the door at the end of the programme, then make sure that you open the door fully.
Otherwise steam from the dishwasher could damage the edge of the worktop because the fan is no longer running.
57
Page 58
Operation

Switching off

At the end of a programme: The dishwasher can be switched off
at any time using the button.
Switching the dishwasher off during a programme cancels the programme.
Switching the dishwasher off during the run-up to a Delay start time (FlexiTimer) will also stop the process.
If the dishwasher is not going to be used for a longer period of time, e.g. whilst on holiday, the tap should be turned off.

Unloading the dishwasher

Dishes tend to break and chip more easily when they are hot. Allow the dishes to cool until they are comfortable enough to handle before unloading them.
If you open the door fully after switching off, the dishes will cool much faster.
First unload the lower basket, then the upper basket and finally the cutlery tray (depending on model). This will prevent water drops from the upper basket and cutlery tray from falling onto the dishes in the lower basket.
58
Page 59
Operation

Interrupting a programme

A programme is interrupted as soon as the door is opened. If the door is closed again, the programme will continue from the point it was at before the door was opened.
Water in the dishwasher may be
hot. Danger of scalding! Only open the door if absolutely
necessary and exercise extreme caution when doing so. Before closing the door again, leave it ajar for approx. 20 seconds. This will enable the temperature in the wash cabinet to settle. Then raise the door up and push until the catch engages.

Changing a programme

If the detergent dispenser flap has already opened, do not change the programme.
If a programme has already started and you wish to change it, proceed as follows:
Switch the dishwasher off with the
button.
Switch the dishwasher on again with
the button.
Select the programme you want, and
then start it.
59
Page 60

Programme options

Options

Options can be selected and deselected using the appropriate buttons and the display before starting the programme.
Switch the dishwasher on with the
button.
The Start indicator light will flash.
Select a programme.Press the button for the option you
want.
The indicator light for the relevant button will come on if the option is available for the programme selected.
If the option is not compatible with the programme selected, a message to this effect will appear in the display.
In this instance, confirm the message
with OK.
Press the Start button to start the
programme.
The option selected will remain active for that particular programme until the setting is changed.
When used in combination with the
QuickPowerWash programme, the Short option results in a wash
programme without drying or automatic opening of the door (if available).

Energy save

The Energy save option reduces the energy consumption of programmes in which this option is available by up to 20%.
In order to achieve optimum cleaning results, the programme duration is extended with this option.

Intensive lower basket

The Intensive lower basket option intensifies cleaning performance in the lower basket in programmes in which this option is available.
Energy and water consumption are increased slightly due to the extended wash duration in the lower basket.

Extra dry

The Extra dry option improves the drying performance in programmes in which this option is available.

Short

The Short option reduces the duration of programmes in which this option is available by up to 30% (see "Programme chart").
In order to achieve optimum cleaning results, energy consumption may increase slightly with this option.
60
Energy consumption is increased due to an extended fan running time and an increased final rinse temperature.
Page 61
Programme options

FlexiTimer

The FlexiTimer gives you three ways of starting the programme by means of delaying the start. You can set the start time or the finish time of a programme. You also have the option of taking advantage of time variable economy rates of electricity using the EcoStart or
SmartStart function.
When using the Delay start function, make sure that the detergent compartment is dry before adding detergent. Wipe dry with a cloth if necessary. If the compartment is wet, powder detergent can become lumpy and stick to the dispenser, with the result that it is not fully dispensed. Do not use liquid detergent when selecting Delay start, as it can run into the dishwasher before it is required.
To prevent children coming into
contact with dishwasher detergent: Do not fill the detergent dispenser
until just before starting the programme, i.e. before you activate
the FlexiTimer with OK. Also activate the door safety lock.
Switch the dishwasher on with the
button.
The Start indicator light will flash.
Select the required programme.Press the button.
You can use the  arrow buttons to select the Start at, Finish at, EcoStart function or SmartStart and Back .
Confirm selection of the function you
want with OK.
The current time of day will appear and the hour number block will be highlighted.
You can now enter the time you want using the  arrow buttons and confirm with OK.
If, while you are setting the time, you do not press any buttons for several seconds, the display will revert to the previous menu. You will then have to enter your settings again.
If the time of day (clock) display has been switched off (see "Settings menu, Time of day"), the display will go out after a few minutes if you have activated a Delay start time and only the Start indicator light will flash slowly.
Press any button to switch the display back on again for a few minutes.
61
Page 62
Programme options

Start at

With the Start at function, you set the exact time at which you want the programme to start.
Use the  arrow buttons to set the
hour and confirm with OK.
The hour will be saved and the minute number block will be highlighted.
Use the  arrow buttons to set the
minutes and confirm with OK.
The saved start time for the programme selected will appear in the display. The Start indicator light will come on.
When the set time is reached, the programme selected will start automatically. The time remaining will appear in the display, the indicator light will go out and the Start indicator light will light up.

Finish at

With the Finish at function, you set the time at which you wish the programme to end.
Use the  arrow buttons to set the
hour and confirm with OK.
The hour will be saved and the minute number block will be highlighted.
Use the  arrow buttons to set the
minutes and confirm with OK.
The estimated start time for the programme selected will appear in the display. The Start indicator light will come on.
A message will appear in the display if the programme cannot be completed by the set finish time because it has too long a running time.
When the estimated time is reached, the programme selected will start automatically. The time remaining will appear in the display, the indicator light will go out and the Start indicator light will light up.
62
Page 63
Programme options

EcoStart

The EcoStart function allows you to take advantage of time variable economy rates of electricity. Before you can use this option, you must set up to three electricity tariff time zones (see "Settings menu - EcoStart"). You then set the latest time at which the programme selected should end. The dishwasher will start automatically in the cheapest tariff zone within the time set.
Use the  arrow buttons to set the
hour and confirm with OK.
The hour will be saved and the minute number block will be highlighted.
Use the  arrow buttons to set the
minutes and confirm with OK.
The estimated start time of the programme selected will appear in the display. The and Start indicator lights will light up.
The programme selected will start automatically in the cheapest time zone and will finish at the latest at the finish time set. The time remaining will appear in the display, the indicator will go out and the indicator light for the Startbutton will light up.

SmartStart

(only functional in selected countries) The SmartStartfunction is used for
starting your dishwasher automatically at a time when your energy costs are most economical.
If the SmartStart option has been activated in the Settings  menu,
SmartStart will appear in the
"FlexiTimer" menu instead of
EcoStart (see "Settings, Miele@home,
SmartStart").
If your energy provider offers this service, they will send a signal to your dishwasher when energy costs are at their most economical. This signal will start the dishwasher.
You can set a time, by which the programme has to have finished by. The dishwasher will then calculate the latest possible start time for the programme selected and will wait until this start time for the signal from the energy provider.
63
Page 64
Programme options
Set the time, by which the selected programme has to be finished by.
Use the  arrow buttons to set the
hour and confirm with OK.
The hour will be saved and the minute number block will be highlighted.
Use the  arrow buttons to set the
minutes and confirm with OK.
The message Wait for SmartStart will appear in the display. The and Start indicator lights will light up.
The selected programme will start automatically as soon as the energy provider has sent the signal, or the latest calculated start time has been reached.
The time remaining will appear in the display, the indicator will go out and the Start indicator light will come on.

Changing or deleting set times

You can change the set times or the programme before the start time in the display is reached.
Press the sensor.Use the  arrow buttons to select
the setting you want to change and confirm with OK.
Use the  arrow buttons to select
the Change or Delete function and confirm with OK.
After confirming the Change function, you can change the set time.
After confirming the Delete function, the programme duration will appear in the display and the programme will start. The indicator light will go out and the Start indicator light will light up.
64
Page 65

DetergentAgent

For optimum cleaning results, the dishwasher automatically adjusts the programme sequence to the type of detergent being used. Depending on the programme, this can mean that the running time and energy consumption vary slightly.
If you only ever use multi-function combination products containing salt and rinse aid in your dishwasher, you can switch the reminders off if you wish (see "Settings menu - Refill reminders"). The DetergentAgent function will not be affected by this.
Ensure that you refill dishwasher salt and rinse aid and switch on the refill reminders again if you are not using combination products.
Programme options
65
Page 66

Programme chart

Programme Programme sequence
Pre-wash Main wash Interim rinse Final rinse Drying
°C °C
1)
ECO
Automatic Variable programme sequence,
Intensive 75°C
QuickPower Wash
Gentle X 45 X 58 X
Light soiling 55°C
Hygiene 69 2X 70 X
ExtraQuiet 46 X 60 X
SolarSave 2X X X X X
Tall items 65°C
Maintenance programme
X 48 X 34 X
sensor-controlled adjustment according to amount of crockery and soiling
If
required
2X 75 X 58 X
X 55 X 58 X
X 65 X 58 X
45-65 If
required
65 X 65 X
75 2X 70 X
57-70 X
1)
This programme is the most efficient in terms of its combined energy and water consumption for cleaning normally soiled crockery.
66
Page 67
Programme chart
Consumption
2)
Duration
2)
Electricity Water
Cold water Hot water Litres Cold water Hot water
15°C 55°C 15°C 55°C
kWh kWh h:min h:min
0.53 3) / 0.54
0.75 5) -1.05
4)
6)
0.32 3) / 0.34
0.50 5) -0.65
4)
6)
11.4 3) / 11.1
6.5 5) -15.0
4)
6)
2:49 2:41
1:54-2:52 1:37-2:47
1.35 0.90 14.5 2:59 2:49
1.30 0.80 11.5 0:58 0:58
0.95 0.45 13.5 2:06 1:51
1.05 0.60 13.5 2:17 2:03
1.55 1.15 13.0 2:31 2:27
1.00 0.70 9.5 4:20 4:11
0.06 27.0 2:30
1.10 0.55 14.0 1:54 1:42
2.05 1.25 22.0 2:11 1:47
2)
In practice there may be variations to these figures due to variable conditions and data recorded by the sensors. The durations displayed in your dishwasher will reflect your household conditions. Selecting programme options will also affect consumption levels and programme durations (see "Programme options").
3)
Standard height dishwashers
4)
XXL dishwashers
5)
Part load with light soiling
6)
Full load with heavy soiling
67
Page 68
Programme chart
Mixed crockery
Pots, pans, everyday porcelain
and cutlery
Items such as baby bottles,
chopping boards etc., that
need to be hygienically clean
Normal food deposits which
have begun to dry on
Fresh food deposits which
have begun to dry on
Burnt-on, stubborn, dried-
on food deposits containing
starch or protein
1)
Fresh food deposits which
have begun to dry on
Water and
energy saving programme
Shorter duration
Average programme values
Shorter duration
Maximum cleaning power
Shorter duration
Programme with special pa-
rameters for hygienic cleaning
1)
Food such as potatoes, pasta, rice or stews can leave starchy deposits. Deposits containing protein
can be left by food such as meat, fish or eggs and bakes.
Crockery Food deposits Programme
features
Mixed,
everyday crockery
Heat-sensitive glasses and
plastic
All fresh to dried-on food
deposits
Fresh, easily removed food
deposits
Variable, sensor-controlled
programme sequence
Shorter duration
Short programme with
duration less than 1 hour
3)
Gentle programme with
glass care
Shorter duration
No crockery
Residual salt after refilling the
salt container
Flushes out salt residues
68
Page 69
Programme chart
-
25 ml
or
1 tab
Automatic
+short
- 1 tab
3)
QuickPowerWash
-
20 ml
or
1 tab
Gentle
+short
-
25 ml
or
1 tab
ECO
+short
-
25 ml
or
1 tab
Light soiling 55°C
4)
+short
10 ml
25 ml
or
1 tab
Intensive 75°C
+short
-
25 ml
or
1 tab
Hygiene
2)
see "Detergent"
3)
best cleaning results are only achieved with Miele's quick dissolving UltraTab Multi
4)
in "Further " (depending on model)
Detergent
Compartment I
2)
Compartment II
2)
Programme
- -
QuickPowerWash
+short
69
Page 70
Programme chart

Further programmes

Hygiene

Special programme for items which need to be hygienically clean, e.g. baby bottles and chopping boards.

ExtraQuiet

Very quiet programme with a longer duration. Suitable for mixed loads of crockery, pots and pans with moderate, slightly dried on food residues.

SolarSave

This programme does not heat the water. To use it, the water intake temperature must be at least 45°C (see "Water connection - Connection to the water supply"). This programme is suitable for mixed loads of crockery and glassware with moderate, slightly dried on food residues.

Tall items 65°C

Programme for very large heat-resistant items, (e.g. very deep pans). In this programme the upper basket needs to be removed to make space for large items in the lower basket. This programme has a medium action to remove fresh to slightly dried on residues.

Maintenance programme

The wash cabinet is largely self­cleaning. However, if residues or soiling build up in the cabinet, they can be removed by running the "Maintenance programme" without a load. This programme is designed for cleaning the wash cabinet using care products such as Miele's dishwasher cleaner or conditioner (see "Optional accessories ­Dishwasher care products). Please follow usage instructions on the packaging.
70
Page 71

Cleaning and care

Check your dishwasher regularly (approx. every 4-6 months). This way faults and problems can be avoided.
The external surfaces of this
appliance are all susceptible to scratching.
Contact with unsuitable cleaning agents can alter or discolour the external surfaces.

Cleaning the wash cabinet

The wash cabinet is largely self­cleaning, provided that the correct amount of detergent is always used.
If there are nevertheless limescale or grease deposits in the cabinet, these can be removed with the Original Miele dishwasher conditioning agent (available from Miele or at www.miele­shop.com). Follow the dosage recommended by the manufacturer on the packaging.

Cleaning the door and the door seal

Mould could build up on the door seal and the sides of the dishwasher door as these surfaces are outside the wash cabinet and are not accessed and cleaned by the spray arm jets.
Wipe the door seals regularly with a
damp cloth to remove food deposits.
Wipe off any food or drink residues
which may have dripped onto the sides of the dishwasher door before closing it.
Using mainly low temperature programmes (below 50°C), could cause bacteria and unpleasant odours to build up in the wash cabinet. To avoid this, the dishwasher will increase the temperature in the final rinse of the selected programme automatically after several programmes using low temperatures have been run.
Clean the filters in the wash cabinet
regularly.
71
Page 72
Cleaning and care

Cleaning the door front

Soiling that is left too long might
become impossible to remove and could cause external surfaces to alter or discolour.
Remove any soiling immediately.
Clean the front with a solution of
warm water and a little washing-up liquid applied with a soft sponge. Wipe the surfaces dry using a soft cloth. For cleaning, you can also use a clean, damp microfibre cloth, such as the Original Miele all purpose microfibre cloth, without any cleaning agent.
To avoid damaging external surfaces, do not use:
– cleaning agents containing soda,
ammonia, acids or chlorides,
– cleaning agents containing descaling
agents,
– abrasive cleaning agents, e.g.
powder cleaners and cream cleaners,
– solvent-based cleaning agents,
– stainless steel cleaning agents,
– dishwasher cleaner,
– oven cleaner,
– glass cleaning agents,
– hard, abrasive brushes or sponges,
e.g. pot scourers, brushes or sponges which have been previously used with abrasive cleaning agents,
– dirt erasers,
– sharp metal scrapers,
72
– steel wool or metal scourers,
– steam cleaning appliances.
Page 73
Cleaning and care

Checking the filters in the wash cabinet

The filter combination in the base of the wash cabinet retains coarse soil from the suds solution, preventing it accessing the circulation system and re-entering the cabinet through the spray arms.
This dishwasher must not be
used without all the filters in place.
Collection of coarse soil may cause the filters to clog. The level of soiling and time it takes before the filters need cleaning will vary depending on use.
The message Check filters will appear in the display after every 50 programme cycles (factory default setting).
You can set the interval for this message to appear to between 30 and 60 programme cycles (see "Settings menu - Check filters").

Cleaning the filters

Switch the dishwasher off.
Turn the handle anti-clockwise to
release the filter combination .
Lift the filter combination out of the
dishwasher . Remove any coarse particles and rinse the filter well under running water. Use a nylon brush if necessary.
Check the filter combination.Clean it if necessary.Then confirm the message with OK.
The message will go out.
During cleaning ensure that
course soil doesn't get into the circulation system and cause a blockage.
73
Page 74
Cleaning and care
To clean the inside of the filter, the flap must be opened:
Press the catches together in the
direction of the arrows as shown, and open the filter .
Rinse all the filters under running
water.
Then close the flap so that the catch
engages.
Replace the filter combination so that
it lies flat in the base of the wash cabinet.
Then turn the handle clockwise until
both arrows point towards each other. This will lock the filter combination in place.
Take care when you are fitting
the filter combination that it is secured in position correctly.
Otherwise coarse soil could get into the circulation system and cause a blockage.
74
Page 75

Cleaning the spray arms

Particles of food can get stuck in the spray arm jets and bearings. The spray arms should therefore be inspected and cleaned regularly (approx. every 4 - 6 months).
Switch the dishwasher off.
Remove the spray arms as follows: Take out the cutlery tray (if your
dishwasher is fitted with one).
Push the top spray arm upwards to
engage the inner ratchet. Then unscrew the spray arm.
Cleaning and care
Pull the lower spray arm firmly
upwards to remove it.
Push the middle spray arm upwards
to engage the ratchet. Then unscrew the spray arm .
Remove the lower basket.
Use a pointed object to push food
particles into the spray arm jets.
Rinse thoroughly under running
water.
Refit the spray arms and check that
they rotate freely.
75
Page 76

Problem solving guide

With the help of the following guide, minor faults in the performance of the appliance, some of which may result from incorrect operation, can be put right without contacting Miele. This will save time and money.
Please note that a call-out charge will be applied to unnecessary service visits where the problem could have been rectified as described in these operating instructions.
Unauthorised or incorrect repairs could cause personal injury or damage to
the appliance. Repair work to electrical appliances must only be carried out by a suitably
qualified and competent person in strict accordance with current local and national safety regulations. The manufacturer cannot be held liable for unauthorised work.

Technical problems

Problem Possible cause and remedy
The display remains dark and the Start indicator light is not flashing after the dishwasher has been switched on with the button.
The dishwasher stops during a programme.
The time display is flashing with the door shut. The programme has not started.
The appliance is not plugged in. Insert the plug and switch on at the socket.
The mains fuse has tripped. Reset or replace the fuse (see data plate for
minimum fuse rating).
The mains fuse has tripped. Reset or replace the fuse (see data plate for
minimum fuse rating).
If the mains fuse trips again, call Miele.
The door has not closed properly, because it had not been fully opened after the door had been opened automatically.
Open the door fully so that the door catch rail
retracts again.
Then close the door.
76
Page 77
Problem solving guide
Problem Possible cause and remedy
One of the following messages appears in the display:
Fault FXX There may be a technical fault.
Waterproof The Waterproof system has reacted.
Fault F78 A fault has occurred in the circulation pump.
Before rectifying the problem, you must: Switch the dishwasher off with the button.
After a few seconds:
Switch the dishwasher back on.Select the programme you want.Press the Start button.
If the fault message appears again, there is a technical fault.
Call Miele.
Turn off the tap.Call Miele.
Switch the dishwasher off for at least 30 seconds
with the button.
Switch the dishwasher back on.Select the programme you want.Press the Start button.
If the fault message appears again, there is a technical fault.
Call Miele.
77
Page 78
Problem solving guide

Water inlet fault

Problem Possible cause and remedy
One of the following messages appears in the display:
Open stopcock The tap is turned off.
Turn on the tap fully.
Water intake Before rectifying the problem, you must:
Switch the dishwasher off with the button.
Water intake is restricted. Turn on the tap fully and start the programme
again.
Clean the water inlet filter (see "Maintenance").The water pressure at the intake is lower than 50
kPa (0.5 bar). Seek professional advice.
The following message appears in the display during the SolarSave programme: Intake temp. low
The intake water has not reached the required temperature of 45°C (see "Water connection ­Connection to the water supply").
Start the programme again.If the fault message appears again, select a
different programme.
78
Page 79
Problem solving guide

Water drainage fault

Problem Possible cause and remedy
The following fault message appears in the display: Drain
Before rectifying the problem, you must: Switch the dishwasher off with the button.
The water outlet is restricted. There might be water in the wash cabinet.
Clean the filter combination (see "Cleaning and
care - Cleaning the filters").
Clean the drain pump (see "Maintenance").Clean the non-return valve (see "Maintenance").Remove any kink or loop in the drain hose.
79
Page 80
Problem solving guide

General problems

Problem Possible cause and remedy
The indicator lights and display are dark.
The interior lighting doesn't switch on when the door is opened.
The following fault message appears in the display: Salt reservoir lid
Detergent residue is left in the dispenser at the end of a programme.
The detergent dispenser lid cannot be closed properly.
At the end of a programme there is a film of moisture on the inside of the door and the interior walls.
The display has switched off automatically to save energy.
Switch the dishwasher on again with the
button.
The interior lighting has been switched off permanently.
Switch the lighting back on again (see "Settings
menu - BrilliantLight").
The salt reservoir lid has not been closed properly. Close the salt reservoir lid.
If the salt reservoir lid has opened during a programme:
Switch the dishwasher off and on again with the
button.
Close the salt reservoir lid.Start the programme again.
The dispenser was still damp when detergent was added.
Make sure the dispenser is dry before adding
detergent.
Clogged detergent residue is blocking the catch. Clean the detergent from the catch.
This is caused by the drying system and does not indicate a fault. The moisture will dissipate after a while.
80
Page 81
Problem solving guide
Problem Possible cause and remedy
Water remains in the wash cabinet at the end of a programme.
Before rectifying the problem you must: Switch the dishwasher off with the button.
The filter combination in the wash cabinet is clogged. Clean the filter combination (see "Cleaning and
care - Cleaning the filters").
The drain pump or non-return valve may be blocked. Clean the drain pump or the non-return valve (see
"Maintenance").
The drain hose is kinked. Remove any kink from the drain hose.
81
Page 82
Problem solving guide

Noises

Problem Possible cause and remedy
Knocking noise in the wash cabinet.
Rattling noise in the wash cabinet.
Knocking noise in the water pipes.
A spray arm is knocking against an item in a basket. Interrupt the programme, and rearrange the items
which are obstructing the spray arm.
Items of crockery are insecure in the wash cabinet. Interrupt the programme, and rearrange the items
of crockery.
A foreign object (e.g. a cherry stone) has become lodged in the drain pump.
Remove the foreign object from the drain pump
(see "Maintenance - Cleaning the drain pump and non-return valve").
This may be caused by the on-site installation or the cross-section of the piping.
This has no influence on dishwasher function. If in
doubt, contact a suitably qualified plumber.
82
Page 83
Problem solving guide

Unsatisfactory washing result

Problem Possible cause and remedy
The dishes are not clean.
Smearing appears on glassware and cutlery, there is a bluish sheen on the surface of glassware; film can be wiped off.
The dishes were not loaded correctly. See notes in "Loading the dishwasher".
The programme was not powerful enough. Select a more intensive programme (see
"Programme chart").
There is some stubborn soiling although most of the crockery is only lightly soiled (e.g. with tea stains).
Use the Automatic programme option (see
"Settings menu - Automatic").
Not enough detergent was dispensed. Use more detergent, or change your detergent.
Items are blocking the path of the spray arms. Rearrange the items so that the spray arms can
rotate freely.
The filter combination in the base of the wash cabinet is not clean or is not correctly fitted. This may cause the spray arm jets to get blocked.
Clean and/or fit the filter combination correctly.Clean the spray arm jets if necessary (see
"Cleaning and care - Cleaning the spray arms").
The non-return valve is open and blocked. Dirty water has flowed back into the wash cabinet.
Clean the drain pump and the non-return valve
(see "Maintenance").
The rinse aid dosage is set too high. Reduce the dosage (see "Settings menu - Rinse
aid").
83
Page 84
Problem solving guide
Problem Possible cause and remedy
Dishes, cutlery and glasses are not dry or are flecked.
Glassware has a brown or blue tinge, and film cannot be wiped off.
Glassware is dull and discoloured; film cannot be wiped off.
Tea or lipstick stains have not been completely removed.
Plastic items are discoloured.
The amount of rinse aid may be insufficient, or the rinse aid reservoir is empty.
Replenish the reservoir, increase the dosage or
change the brand of rinse aid (see "Before using for the first time - Rinse aid").
Crockery was taken out of the cabinet too soon. Leave it in for longer (see "Operation").
Combination tabs have been used which have impaired drying performance.
Change your detergent, or replenish the rinse aid
(see "Before using for the first time - Rinse aid").
This may be caused by the detergent. Change your detergent.
The glassware is not dishwasher-proof. The surfaces are affected.
There is no remedy.
Purchase glassware which is dishwasher-proof.
The wash temperature of the selected programme was too low.
Select a programme with a higher wash
temperature.
The bleaching effect of the detergent used is too low. Change your detergent.
Natural dyes e.g. from carrots, tomatoes or tomato sauce may be the cause. The amount of detergent used or its bleaching effect was not sufficient to deal with natural dyes.
Use more detergent (see "Operation - Detergent").
Discolouration is irreversible.
84
Page 85
Problem solving guide
Problem Possible cause and remedy
White residue is visible on cutlery and crockery, clouding occurs on glassware; film can be wiped off.
There are rust stains on cutlery.
Not enough rinse aid was used. Increase the dosage (see "Settings menu - Rinse
aid").
There is no salt in the salt reservoir. Fill the salt reservoir (see "Before using for the first
time - Dishwasher salt").
An unsuitable combination detergent has been used. Change your detergent. Use a standard liquid,
tablet or powder detergent, and fill the salt and rinse aid reservoirs in the dishwasher.
The water softener is programmed to too low a water hardness level.
Programme the water softener to a higher water
hardness level (see "Settings menu - Water hardness").
The affected items are not corrosion resistant. There is no remedy.
Purchase cutlery which is dishwasher-proof.
A programme was not run after dishwasher salt was added. Traces of salt have got into the wash cycle.
Always run the QuickPowerWash programme with
the Shortprogramme option selected and without any crockery in the dishwasher after adding dishwasher salt.
85
Page 86

Maintenance

Cleaning the water inlet filter

A filter is incorporated in the screw connection of the valve on the water inlet hose. The filter must be cleaned when dirty, otherwise insufficient water flows into the wash cabinet.
The plastic housing of the water
connection contains an electrical component.
The housing must not be dipped in water.
Recommendation
If the mains water contains a large amount of insoluble substances, we recommend fitting a large-area filter in the connection between the tap and the water inlet hose threaded union. This filter is available from Miele.

Cleaning the filter:

Disconnect the dishwasher from the
mains supply. Switch off at the mains socket and withdraw the plug.
Turn off the tap.Unscrew the inlet hose.
Carefully remove the washer.Withdraw the filter using pointed
pliers and rinse clean under running water.
Replace the filter and washer, making
sure they are sitting correctly.
Reconnect the inlet hose to the tap,
making sure it goes on correctly and is not cross-threaded.
Turn on the tap.
If water leaks out, the inlet hose may not be connected securely or it may have been screwed on at an angle.
Unscrew and reconnect the inlet hose
correctly.
86
Page 87

Cleaning the drain pump and non-return valve

If the water has not been pumped away at the end of a programme, the drain pump or the non-return valve might be blocked. They are, however, easy to clean.
Disconnect the dishwasher from the
mains supply. Switch off at the mains socket and withdraw the plug.
Take the filter combination out of the
wash cabinet (see "Cleaning and care
- Cleaning the filters").
Scoop the water out of the cabinet
using a suitable container or utensil.
Maintenance
The drain pump is situated under the non-return valve (see arrow).
Remove all foreign objects from the
drain pump (watch out for glass or bone splinters which are particularly difficult to detect and could cause injury). Turn the drain pump impeller by hand to check that there are no more obstructions. You will feel a little resistance when you turn the impeller.
Press the catch for the non-return
valve inwards .
Tilt the non-return valve inwards until
it is released.
Rinse it thoroughly under running
water and remove any soiling from the non-return valve.
Carefully refit the non-return valve
and secure it with the catch.
Ensure that the catch engages
correctly.
Be careful not to damage any
delicate components when cleaning the drain pump and the non-return valve.
87
Page 88

After sales service

Repairs

In the event of any faults which you cannot remedy yourself, please contact Miele.
The contact details for Miele are given at the back of these instructions.
When contacting Miele, please quote the model and serial number of your dishwasher, both of which are shown on the data plate on the right-hand side of the door.

Warranty

The manufacturer's warranty for this appliance is 2 years.
For further information, please refer to your warranty booklet.
88
Page 89

Optional accessories

Dishwasher detergent and rinse aid, as well as cleaning and care products, are available as optional accessories. All the products are designed for use with Miele dishwashers.
These and many other useful products can be ordered from Miele or via the Miele Webshop (see end of this booklet for contact details).

Dishwasher detergent, rinse aid and salt

When you decided to buy a Miele dishwasher, you chose excellent quality and performance. Ensuring that your dishwasher always delivers the best possible results will also depend on your choice of dishwasher detergent, rinse aid and dishwasher salt, as cleaning results can vary depending on the brand used. With Miele cleaning products and detergents, you can be sure of optimum results as these products have been specially designed for Miele dishwashers.

Detergent tabs

– sparkling results even with stubborn
food deposits
– combination product with other
components such as rinse aid, salt and glass protection additives
– phosphate-free - safe for the
environment
– water-soluble wrapping - no need to
unwrap

Powder detergent

– with active oxygen for thorough
cleaning
– with enzymes which are effective
even in low temperature programmes
– with glass protection against
corrosion

Rinse aid

– for gleaming glasses
– helps crockery to dry
– with glass protection against
corrosion
– specially designed cap for precise,
easy dispensing

Dishwasher salt

– prevents limescale on crockery and
in the appliance
– extra coarse-grained
89
Page 90
Optional accessories

Dishwasher care products

Miele cleaning and care products provide optimum care for your dishwasher.

Dishwasher cleaner

– cleans the dishwasher effectively and
thoroughly
– removes grease, bacteria and
unpleasant odours
– ensures excellent dishwashing results

Dishwasher descaler

– removes heavy limescale deposits
– mild and gentle with natural citric
acid

Dishwasher conditioner

– removes odours, limescale and light
deposits
– maintains the elasticity and leak
tightness of the seals

Dishwasher freshener

– neutralises unpleasant odours
– fresh, pleasant lime and green tea
scent
– easy to attach to the dishwasher
basket
– very economical, lasts for 60 wash
cycles
90
Page 91

Electrical connection

This dishwasher is supplied with a mains cable with moulded plug ready for connection to an AC single phase supply, (230 - 240 V 50 Hz for NZ and Australia) via a suitable switched socket.
The electrical socket must be
easily accessible after the dishwasher has been installed. Do not connect the dishwasher to the mains electricity supply by an extension lead. Extension leads do not guarantee the required safety of the appliance (e.g. danger of overheating).
Do not connect the appliance solely to an inverter such as those used with an autonomous energy source e.g. solar power. When switched on, peak loads in the system can cause the safety switch-off mechanism to be triggered. This can damage the electronic unit. The machine must not be used with so­called energy-saving devices either. These reduce the amount of energy supplied to the machine, causing it to overheat.
Before connecting the appliance,
check that the connection data on the data plate (voltage, frequency, rated load and fuse rating) matches the mains electricity supply. If in any doubt, consult a qualified electrician.
The data plate is located on the right­hand side of the door.
All electrical work must be
carried out by a suitably qualified and competent person in strict accordance with current local and national safety regulations.
For extra safety, it is advisable to install a residual current device (RCD), with a trip current of 30mA.
91
Page 92

Water connection

The Miele Waterproof system

As long as your dishwasher has been installed correctly, the Miele waterproof anti-leak system will protect you from water damage.

Connection to the water supply

Water in the dishwasher must
not be used as drinking water.
– The dishwasher may be connected to
a cold or hot water supply, max. 60°C. We would only recommend connection to a hot water supply if it is economical, e.g. a solar powered supply. When connected to a hot water supply, all programmes will be carried out with hot water.
– The SolarSave programme (if
available) requires a hot water supply of between 45°C (minimum) and 60°C (maximum). The higher the water intake temperature, the better the cleaning and drying results.
92
Page 93
Water connection
– The inlet hose is approx. 1.5m long.
– A tap with a 3/4" male thread must
be provided on site.
– IMPORTANT: Australia and New
Zealand This appliance must be installed according to AS/NZS 3500.1. Back flow prevention is already integrated in the appliance.
– The water pressure (flow pressure at
the take-off point) must be between 50 and 1000 kPa (0.5 and 10 bar). If the water pressure is lower than this, the fault message Water intake will appear in the display (see "Problem solving guide"). If the water pressure is too high, a pressure reducer valve must be fitted.
After connecting the dishwasher to the water supply, check that all plumbing connections are watertight.
To avoid any damage to the
appliance, the dishwasher must only be operated when it is connected to a fully vented plumbing system.
The inlet hose must not be
shortened or damaged in any way as it contains electrical components (see illustration).
93
Page 94
Water connection

Drainage

– The appliance drainage system is
fitted with a non-return valve which prevents dirty water from flowing back into the dishwasher via the drain hose.
– The dishwasher is supplied with
approx. 1.5 m of flexible drain hose with an internal diameter of 22 mm.
– The drain hose can be extended
using a connection piece to attach a further length of hose. The drainage length must not be longer than 4 m, and the delivery head must not exceed 1 m.
– If the hose is to be directly fitted to
the drainage outlet on site, use the hose clip supplied (see installation diagram).
– The hose can be directed to the left
or the right of the appliance.
– The on-site connector for the drain
hose can be adapted to different widths of hose. If the connector protrudes too far into the drain hose, it will need to be shortened. Otherwise the drain hose may become blocked.

Venting the drainage system

If the on-site drain connection is situated lower than the guide path for the bottom basket rollers in the open door, the drainage system must be vented. Otherwise a siphoning effect during a programme can cause the appliance to empty itself of water.
To vent it: Open the dishwasher door
fully.
Pull the lower spray arm firmly
upwards to remove it.
Cut off the top of the vent valve in the
wash cabinet.
– The drain hose must not be
shortened.
Make sure that there are no kinks
in the hose, and that it is not squashed or stretched.
After commissioning the appliance, ensure that the water outlet does not leak.
94
Page 95

Technical data

Dishwasher model Standard XXL

Technical data

Height freestanding model 84.5 cm (adjustable +
3.5 cm)
Height built-in model 80.5 cm (adjustable +
6.5 cm)
Height of building-in recess Min. 80.5 cm (+ 6.5
cm)
Width 59.8 cm 59.8 cm
Width of building-in recess 60 cm 60 cm
Depth freestanding model 60 cm -
Depth built-in model 57 cm 57 cm
Weight Max. 64 kg Max. 56 kg
Voltage See data plate
Rated load See data plate
Fuse rating See data plate
Power consumption when switched off
Power consumption when not switched off
0.2 W 0.2 W
2.5 W 2.5 W
-
84.5 cm (adjustable +
6.5 cm)
Min. 84.5 cm (+ 6.5 cm)
Networked standby 0.6 W 0.6 W
Test certificates awarded See data plate
Water pressure (flow rate) 50 - 1000 kPa
(0.5 - 10 bar)
Hot water connection Up to max. 60 °C Up to max. 60 °C
Delivery head Max. 1 m Max. 1 m
Drainage length Max. 4 m Max. 4 m
Mains cable Approx. 1.9 m Approx. 1.9 m
Capacity 14 place settings 15 place settings
50 - 1000 kPa (0.5 - 10 bar)
95
Page 96

Settings menu

Settings menu for changing standard settings

Opening the Settings menu

Switch the dishwasher on with the
button if it is switched off.
Use the programme selector
button to select the Further option.
The first of the further programmes will appear in the display.
Select the Settings  option with the
arrow buttons and confirm with OK.
The first option in the Settings menu will appear in the display.
To learn about the display, read the section with the same name.
Use the  arrow buttons to select
the option you want to change and confirm your selection with OK.
Sub-menu options which have already been selected will have a tick beside them.
To exit a sub-menu, use the 
arrow buttons to select Back  and confirm with OK.
The display will revert to the menu above.

Language

The display can be set to appear in one of several different languages.
You can change the language in the display via the Language  sub-menu.
Select the language you want as well
as the country, if appropriate, and confirm with OK.
The flag after the word Language  acts as a guide if a language which you do not understand has already been set. If this is the case, keep selecting the option which has a flag after it until you reach the Language  sub-menu.
96
Page 97
Settings menu

Time of day

The dishwasher is delivered with the time of day (clock) display deactivated.
To save energy, the dishwasher will switch off automatically a few minutes after the last time a button has been pressed or after the end of a programme.

Setting the time of day (clock) display

When the time of day (clock) display has been activated, the current time of day will appear in the display a few minutes after the last time a button has been pressed or after the end of a programme. This increases energy consumption.
Select the Display option and confirm
with OK.
Select the setting you want and
confirm with OK.
If you have selected On, confirm the
message about higher energy consumption with OK.

Setting the clock format

You can select either a 24-hour or 12­hour clock.
Select the Clock format option.Select the setting you want and
confirm with OK.

Setting the time of day

You can set the current time of day. The current time of day must be set before you can use the "FlexiTimer" programme option.
Select the Set option.Set the hour with the  arrow
buttons and confirm with OK. Then set the minutes and confirm with OK.
The time of day has now been saved.
97
Page 98
Settings menu

Water hardness

This appliance is fitted with a water softener. The dishwasher must be programmed for the water hardness in your area.
– The dishwasher must be
programmed to the correct water hardness for your area.
– Your local water authority will be able
to advise you of the water hardness level in your area.
– Where the water hardness fluctuates
e.g. between 1.8 and 2.7mmol/l (10­15°d - German scale), always programme the dishwasher to the higher value (2.7mmol/l or 15°d in this example).
Select the water hardness level for
your area and confirm your selection with OK.
A tick will appear beside the water hardness which has been set.
°d mmol/l °f Display
1 0.2 2 1
2 0.4 4 2
3 0.5 5 3
4 0.7 7 4
5 0.9 9 5
6 1.1 11 6
7 1.3 13 7
8 1.4 14 8
9 1.6 16 9
10 1.8 18 10
°d mmol/l °f Display
11 2.0 20 11
12 2.2 22 12
13 2.3 23 13
14 2.5 25 14
15 2.7 27 15
16 2.9 29 16
17 3.1 31 17
18 3.2 32 18
19 3.4 34 19
20 3.6 36 20
21 3.8 38 21
22 4.0 40 22
23 4.1 41 23
24 4.3 43 24
25 4.5 45 25
26 4.7 47 26
27 4.9 49 27
28 5.0 50 28
29 5.2 52 29
30 5.4 54 30
31 5.6 56 31
32 5.8 58 32
33 5.9 59 33
34 6.1 61 34
35 6.3 63 35
36 6.5 65 36
37-45 6.6-8.0 66-80 37-45
46-60 8.2-10.7 82-107 46-60
61-70 10.9-12.5 109-125 61-70
98
Page 99
Settings menu

Rinse aid

You can adjust the rinse aid dosage for best results. The rinse aid dosage is set in stages from 0 to 6. It is set to 3 at the factory.
If the "Adjust Automatic" programme function (depending on model) has been activated, the amount of rinse aid dispensed in the Automatic programme can be higher than that set.
If spots appear on crockery and glassware:
– Increase the rinse aid dosage.
If clouding or smearing appears on crockery and glassware:
– Decrease the rinse aid dosage. Select the setting you want and
confirm your choice with OK.

Consumption (EcoFeedback)

You can programme the dishwasher so that the energy and water consumption of the currently selected programme appears in the display. The estimated consumption can be displayed before the programme starts and the actual consumption can be displayed after the programme has finished. In this menu you can also call up the total energy and water used in all previous dishwasher programmes (see "Caring for the environment ­EcoFeedback consumption indicator").

Consumption indicator

Select the Display option and confirm
with OK.
Select the setting you want and
confirm with OK.

Total consumption

Select the Total consumption option
and confirm with OK.
You can call up the values for Energy
and Water with the  arrow buttons.
You can also reset the values for the total consumption to 0.
Select the Reset option and confirm
with OK.
Select the Yes option and confirm
with OK.
Confirm the message with OK.
The values are now reset to 0.
99
Page 100
Settings menu

EcoStart

In order to run your dishwasher in the most economical way, you can use the
EcoStart option to take advantage of
your electricity supplier's time variable tariffs (see "Programme options ­FlexiTimer with EcoStart"). With this option selected, your dishwasher will start automatically at your electricity supplier's cheapest tariff times.
To use this option, you must first set up to three electricity tariff time zones in which the dishwasher can start. You can allocate different priorities to these time zones. The time with the cheapest electricity tariff will be given Priority 1.
Contact your electricity supplier to find out the times of the cheapest electricity tariffs.
Once the electricity tariff times have been set, you can use the EcoStart option to set the latest finish time required for each programme. The dishwasher will then start automatically in the cheapest electricity tariff time and the programme will end at the latest at the finish time set.

Setting the electricity tariff times

Before you can use the EcoStart option, you must set at least one electricity tariff time.
Use the  arrow buttons to select
the electricity tariff time (T1-T3) you want to set and confirm with OK.
The start of the electricity tariff time selected will appear in the display and the hour number block will be highlighted.
Use the  arrow buttons to set the
hours and minutes for the start time and confirm both with OK.
The end of the electricity tariff time selected will appear in the display and the hours number block will be highlighted.
Use the  arrow buttons to set the
hours and minutes for the end time and confirm both with OK.
The electricity tariff time will be saved and its priority will appear in the display.
Use the  arrow buttons to set the
priority you want and confirm with OK.
Confirm the message with OK.
100
The electricity tariff time will be activated.
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
