Miele G 5263 Operating instructions

Operating instructions Dishwasher
To avoid the risk of accidents or damage to the appliance, it is essential to read these instructions as well as the installation plan before it is installed and used for the first time.
en-AU, NZ M.-Nr. 11 693 880HG07
Contents
Displaying and setting the water hardness .................................................... 23
Filling the salt reservoir................................................................................... 25
Replenishing salt ............................................................................................ 26
Adding rinse aid ............................................................................................. 28
Refilling rinse aid ............................................................................................ 28
Loading the 3D MultiFlex tray......................................................................... 37
Loading the cutlery basket............................................................................. 38
Dishwashers with cutlery tray......................................................................... 39
Dishwashers with cutlery basket.................................................................... 41
3
Contents
4
Contents
5

Warning and Safety instructions

This dishwasher complies with all current local and national safety requirements. However, inappropriate use can lead to personal injury and damage to property.
Please observe the installation sheet and read the operating instructions carefully before setting up the dishwasher and using it for the first time. They both contain important information on the installation, safety, use, and maintenance of the machine. This prevents both personal injury and damage to the dishwasher.
In accordance with standard IEC 60335-1, Miele expressly and strongly advises that you read and follow the instructions in "Installation" and in "Warning and Safety instructions". Miele cannot be held liable for injury or damage caused by non­compliance with these instructions.
Keep the installation sheet and the operating instructions in a safe place and pass them on to any future owner.
6
Warning and Safety instructions

Correct application

This appliance is designed for domestic use and for use in similar
environments by guests in hotel or motel rooms, bed & breakfasts, and other typical living quarters. This does not include common/ shared facilities or commercial facilities within hotels, motels or bed & breakfasts.
This dishwasher is not suitable for outdoor use.The dishwasher is intended for use at altitudes of up to 4,000m
above sea level.
The dishwasher must only be used for cleaning domestic crockery
and cutlery. Any other use is not permitted.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning its use by a person responsible for their safety, and are able to recognise the dangers of misuse.
7
Warning and Safety instructions

Safety with children

Young children must not be allowed to use this appliance.Older children may only use the dishwasher if its operation has
been clearly explained to them and they are able to use it safely. They must be able to understand and recognise the possible dangers of misuse.
Cleaning work may only be carried out by older children under the
supervision of an adult.
Children should be supervised in the vicinity of the dishwasher.
Keep small children away from the appliance at all times to avoid the risk of injury. Ensure that they do not play with the appliance. There is a risk that children may lock themselves in the dishwasher.
If the automatic door opening mechanism is active (depending on
the model), keep young children away from the area in which the door opens. There is a danger of injury in the unlikely event of a fault with the opening mechanism.
Danger of suffocation! While playing, children may become
entangled in packaging material (such as plastic wrapping) or pull it over their head with the risk of suffocation. Keep packaging material away from children.
Keep detergents and other household cleaning agents out of
reach of children. Some dishwasher detergents are strongly alkaline and contain irritants and corrosive ingredients. They can be extremely dangerous if swallowed, and can cause severe skin burns and eye damage. They can cause burning in the mouth, nose and throat, or inhibit breathing. Avoid contact with the skin and eyes. Keep children away from the dishwasher when the door is open. There could still be detergent residues in the cabinet or dispenser. Check that the dispenser is empty after the completion of a programme. Seek medical advice immediately if a child has swallowed or inhaled any detergent. Contact a Poisons Information Centre (Australia) or the National Poisons Centre (NZ).
8
Warning and Safety instructions

Technical safety

Unauthorised installation, maintenance and repairs can cause
considerable danger for the user. Installation, maintenance, and repairs must only be carried out by a Miele authorised technician.
Damage to the dishwasher can compromise your safety. Before
using the dishwasher and in particular following transport, check it for any visible damage. Never use a damaged dishwasher.
The electrical safety of this dishwasher can only be guaranteed
when continuity is complete between it and an effective earthing system. It is most important that this basic safety requirement is present. If in doubt, the electrical installation should be checked by a qualified electrician. Miele cannot be held liable for the consequences of an inadequate earthing system (e.g. electric shock).
Reliable and safe operation of the dishwasher can only be assured
if it has been connected to the mains electricity supply.
The dishwasher must only be connected to the electricity supply
via a suitable switched socket. The socket must be easily accessible after the dishwasher is installed so that it can be disconnected from the electricity supply at any time.
There must be no electrical sockets concealed behind the
dishwasher because the building-in niche may be too small, creating a risk of overheating if the dishwasher were to be pushed up against the plug (fire hazard).
The dishwasher must not be installed underneath a cooktop. The
high temperatures radiated by cooktops could damage the dishwasher below. For the same reason, the dishwasher must not be installed next to open fires or other appliances that give off heat, such as heaters etc.
9
Warning and Safety instructions
Ensure that the connection data on the dishwasher’s data plate
(fuse rating, frequency and voltage) match the electricity supply to prevent damage to the dishwasher. Compare these before connecting the appliance to the mains electricity. If in any doubt, consult a qualified electrician.
Do not connect the dishwasher to the electricity supply until it has
been fully installed and any adjustment has been made to the door springs.
The dishwasher may only be operated if the door opening
mechanism is working correctly, as otherwise there could be a danger when the automatic door opening is activated (depending on the model). To check that the door opening mechanism is working correctly:
- The door springs must be evenly adjusted on both sides. They are correctly adjusted when the door remains stationary when left half open (approx. 45° opening angle). The door must not fall open on its own beyond this point.
- The door locking pins retract automatically after the drying phase when the door is opened.
Multi-socket adapters and extension leads do not guarantee the
required safety of the appliance (e.g. danger of overheating). Do not connect the dishwasher to the electricity supply using a multi-socket adapter or an extension cord.
The dishwasher must not be installed and operated in mobile
locations (e.g. on a ship).
Do not install the dishwasher in a room where there is a risk of
frost. Frozen hoses can break or burst. The reliability of the electronic control unit may be impaired at temperatures below freezing point.
To avoid any damage to the dishwasher, it must only be operated
when it is connected to a fully vented plumbing system.
10
Warning and Safety instructions
The plastic housing of the water connection contains an electrical
valve. The housing must not be dipped in water.
There are live wires in the water inlet hose. Do not cut the hose,
even if it is too long.
The integrated water protection system offers protection from
water damage, provided the following conditions are met:
- Installation has been carried out correctly.
- The dishwasher is properly maintained and parts are replaced when they are visibly damaged.
- The tap is turned off during longer absences from the home (e.g. whilst on holiday).
The Waterproof system will work even when the dishwasher is switched off. However, the dishwasher must remain connected to the electricity supply.
The water connection pressure needs to be between 50 and
1,000kPa.
A damaged dishwasher could be dangerous. If the dishwasher
gets damaged, switch it off at the mains immediately and contact Miele customer service.
The manufacturer’s warranty will be invalidated if the appliance is
not repaired by a Miele authorised service technician.
Defective components must be replaced with original parts. If
original Miele parts are installed correctly, Miele ensures full compliance with safety requirements and the warranty remains valid.
During installation, maintenance, and repair work, the dishwasher
must be disconnected from the electricity supply (switch it off and withdraw the plug from the socket).
If the mains connection cable is damaged, it must be replaced
with a special cable of the same type (available from Miele) by a Miele authorised service technician only in order to avoid a hazard.
11
Warning and Safety instructions
In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the appliance and its surroundings in a clean condition at all times. Any damage which may be caused by cockroaches or other vermin will not be covered by the warranty.

Correct installation

The dishwasher must be installed and connected in accordance
with the installation instructions and the supplied installation plan.
Be careful before and while installing the dishwasher.
Some metal parts pose a risk of injury/cutting. Wear protective gloves.
The dishwasher must be correctly aligned horizontally to ensure
trouble-free operation.
In order to ensure stability, built-under and integrated dishwashers
must only be installed under a continuous countertop which is secured to adjacent cabinetry.
The dishwasher must only be built into a tall unit if additional
safety precautions are taken. In order to safely install the appliance in a tall unit, please use the "Tall unit installation kit" and observe the installation plan provided. Otherwise there is the danger of the unit tipping over.
The door springs must be evenly adjusted on both sides. They are
correctly adjusted when the door remains stationary when left half open (approx. 45° opening angle). The door must not fall open on its own beyond this point. The appliance must only be operated with properly adjusted door springs. If the door cannot be adjusted properly, contact Miele customer service.
The maximum weight of the front panel that can be aligned with the factory fitted door springs is 10–12kg (depending on model).
12
Warning and Safety instructions

Correct use

Do not use solvents in the dishwasher. There is a danger of
explosion.
Do not inhale or ingest dishwasher detergent. Some dishwasher
detergents are strongly alkaline and contain irritants or corrosive ingredients. They can be extremely dangerous if swallowed, and can cause burning in the eyes, nose, mouth, and throat, or inhibit breathing. Avoid contact with the skin and eyes. Do not inhale powder detergents. Do not swallow dishwasher detergents. Seek medical advice immediately if detergent has been swallowed or inhaled. Contact a Poisons Information Centre (Australia) or the National Poisons Centre (NZ).
Avoid leaving the dishwasher door open unnecessarily. You could
injure yourself on the open door or trip over it.
Do not sit, stand, or lean on the open door. The dishwasher could
tip over. This could injure you or damage the dishwasher.
Dishes may be very hot at the end of the programme. Allow the
dishes to cool until they are comfortable enough to handle before unloading them.
Only use detergent and rinse aid formulated for domestic
dishwashers. Do not use washing-up liquid.
Do not use any commercial or industrial detergents. These may
cause material damage, and there is a risk of a severe explosive chemical reaction (such as an explosive oxyhydrogen gas reaction).
Do not fill the rinse aid reservoir with powder or liquid detergent.
This will cause serious damage to the rinse aid reservoir.
Do not fill the salt reservoir with powder or liquid detergent.
Dishwasher detergent will damage the water softener.
13
Warning and Safety instructions
Only use special coarse-grained dishwasher salt or other pure
evaporated salts for reactivation. Other types of salt (such as cooking salt, rock salt, agricultural grade or gritting salt) may contain insoluble components which can impair the functioning of the water softener.
In dishwashers with a cutlery basket (depending on model), knives
and forks should be placed with the handles upwards in the basket for safety reasons. Knives and forks placed with the handles downwards pose a danger of injury. However, cutlery placed handle down in the cutlery basket will come out cleaner and drier.
Plastic items which cannot withstand being washed in hot water,
such as disposable plastic containers or plastic cutlery, should not be cleaned in the dishwasher. The high temperatures in the dishwasher may cause them to melt or lose shape.
If you use the timer option (depending on model), the detergent
compartment must be dry. Wipe dry with a cloth first if necessary. The detergent will clump together if the detergent compartment is not dry, and it may not be fully rinsed out.
Please observe the information listed under Technical data
regarding the capacity of the dishwasher.

Accessories and spare parts

Only use original Miele accessories. If other parts are used,
warranty, performance, and, if applicable, product liability claims will be invalidated.
Miele will guarantee to supply functional spare parts for a
minimum of 10years and up to 15years following the discontinuation of your dishwasher.
14
Warning and Safety instructions

Transport

Damage to the dishwasher can compromise your safety. Before
using the dishwasher, check it for any visible transport damage. Never use a damaged dishwasher.
Only transport the dishwasher in an upright position so that no
water flows into the electrical controls, as this would cause faults.
If you wish to transport the dishwasher, empty it and securely
fasten all loose parts such as baskets, hoses, and cables.

Disposal of your old dishwasher

Make the door lock inoperative so that children cannot
accidentally shut themselves in. Remove or destroy the locking bracket of the door lock, and make appropriate arrangements for the disposal of the appliance.
15

Notes on the operating instructions

These operating instructions apply to several different dishwasher models of different heights. The different dishwasher models will be named as follows: Standard = dishwasher measuring
80.5cm high (built-in appliance) or
84.5cm high (freestanding appliance) XXL = dishwasher measuring 84.5cm high (built-in appliance).

Notes on the layout

Warnings

Information which is important
for safety is highlighted in a thick framed box with a warning symbol. This alerts you to the potential danger of injury to people or damage to property.
Read these warning notes carefully and observe the procedural instructions and codes of practice they describe.

Additional information and comments

Additional information and comments are highlighted in a box framed with a thin black line.

Instructions for the user

Instructions on how to operate the dishwasher are identified by marked operating steps. They explain the procedure step by step. Operating steps are indicated by a black square bullet point.
Example: Select the setting you want and press OK to confirm.

Notes

Notes contain information of particular importance that must be observed.
They are highlighted by a thick framed box.
16
The following items are supplied:
- Dishwasher
- Operating instructions for operating the dishwasher
- Installation sheet for installing the dishwasher
- Other installation accessories for installing the dishwasher (see installation sheet)
- Funnel for filling the dishwasher salt
- Additional printed matter and add­ons if required

Items supplied

17

Guide to the appliance

Appliance overview

a
Upper spray arm (not visible)
b
Cutlery tray (depending on model)
c
Upper basket
d
Middle spray arm
e
Aeration valve
f
Lower spray arm
18
g
Filter combination
h
Salt reservoir
i
Data plate
j
Rinse aid reservoir
k
Detergent compartment

Control panel

1
2
3 4
5
6
7

75 C°75 C°
65 C°65C°
45 C°45C°
Auto
ECO
Guide to the appliance
a
On/Off button For switching the dishwasher on and off.
b
Programme selection
ECO = ECO
Auto = Auto45–65°C45°C = Gentle45°C65°C = QuickPowerWash65°C75°C = Intensive75°C
c
Programme selection button For programme selection.
d
Time display
e
Timer button For selecting a later programme start.
f
Express button For reducing the programme duration.
g
Check/Refill indicators
/ = Inlet/Drain = Rinse aid = Salt
19

Caring for the environment

Disposal of the packing material

The transport and protective packaging has been selected from materials which are environmentally friendly for disposal, and can normally be recycled.
Recycling the packaging reduces the use of raw materials in the manufacturing process and also reduces the amount of waste in landfill sites. Ensure that any plastic wrappings, bags etc. are disposed of safely and kept out of the reach of babies and young children. Danger of suffocation.

Disposing of your old appliance

Electrical and electronic appliances often contain valuable materials. They also contain specific materials, compounds and components, which were essential for their correct function and safety. These could be hazardous to human health and to the environment if disposed of with your domestic waste or if handled incorrectly. Please do not, therefore, dispose of your old appliance with your household waste.
Please dispose of it at your local community waste collection / recycling centre for electrical and electronic appliances. You are also responsible for deleting any personal data that may be stored on the appliance prior to disposal. Please ensure that your old appliance poses no risk to children while being stored prior to disposal.
20

Using for the first time

Every dishwasher is tested at the factory. There will be residual water in the machine from this test. It is not an indication that the dishwasher has been used previously.

Opening the door

In some programmes the door automatically opens slightly to assist the drying process. This function can be deactivated, if preferred (see “Programme options – AutoOpen”).
Pull the handle to open the door.
Risk of scalding due to hot
water. During operation, water in the
dishwasher may be very hot. Only open the door if absolutely
necessary and exercise extreme caution when doing so.
Risk of injury due to door
opening automatically. The door may open automatically at
the end of a programme. Keep the area around the door free
of obstructions.

Closing the door

Push the baskets right in.Raise the door upwards until the
catch engages.
Risk of crushing due to the door
closing. When closing the door, you are at
risk of shutting your fingers in it. Do not put your hand inside the door
as it is closing.
Open the door fully to disengage the
locking mechanism.
At the end of the programme, if the AutoOpen function is on, the door locking pins automatically retract.
To prevent a technical fault, do not hold the door locking pins firmly when they are retracting.
If the door is opened during operation, all functions are automatically interrupted.
21
Using for the first time

Water softener

In order to achieve good cleaning results, the dishwasher needs to operate with soft (low limescale) water. Hard water results in the build-up of calcium deposits on crockery and in the appliance. Water with a hardness level higher than
0.9mmol/l (5°dH – German scale) must be softened. This occurs automatically in the integrated water softener. The water softener is suitable for a water hardness level of up to 12.5mmol/l (70°dH - German scale).
In order to be reactivated, the water softener requires dishwasher salt. Depending on the water hardness level (<3.8mmol/l, or <21°dH – German scale), dishwasher salt is not required if combination detergents are being used (see “Detergents - Types of detergents”).
- The dishwasher needs to be programmed to the correct water hardness for your area.
If the water hardness in your area is available in a unit other than °dH, you can convert the values as follows: 1°dH = 0.18mmol/l = 1.78°fH
The dishwasher is programmed at the factory for a water hardness level of
0.36mmol/l (2°dH - German scale).
If your water hardness level corresponds to this setting, you can skip to the next section.
However, if you have a different water hardness level, you must adjust the water softener to match your water hardness.
- Your local water authority will be able to advise you of the water hardness level in your area.
- Where the water hardness fluctuates, e.g. between 1.8 and 2.7mmol/l (10­15°dH - German scale), always programme the dishwasher to the higher value (2.7mmol/l or 15°dH in this example).
22
Using for the first time

Displaying and setting the water hardness

Open the door.Switch the dishwasher off with the
button, if it is switched on.
Press the button in and, while
holding it in, switch the dishwasher
on using the button. Keep the button pressed in for at least 4seconds until the indicator light comes on.
If this does not happen, start the procedure from the beginning again.
Press the programme selection
button 2 times.
The top left programme indicator light will flash rapidly 2 times at intervals.
The value set is shown as a figure after
in the time display.  will start flashing in the display.
A water hardness of 2.5mmol/l (14°dH – German scale) is set.
Use the button to set the water
hardness level for your area. The setting increases each time you press the button. When the highest value is reached, the setting starts again from the beginning.
The setting is now stored in memory. Switch the dishwasher off with the
button.
23
Using for the first time

Dishwasher salt

In order to maintain the functioning of the water softener, it must be reactivated regularly.
In order to be reactivated, the water softener requires dishwasher salt. Depending on the water hardness level (<3.8mmol/l, or <21°dH – German scale), dishwasher salt is not required if combination detergents are being used (see “Detergents - Types of detergents”).
If the water in your area is very soft and constantly lower than 0.9mmol/l (5 °dH - German scale) you do not need to add dishwasher salt. The salt refill indicator will automatically switch off after the water hardness has been set accordingly (see “Using for the first time – Displaying and setting the water hardness”).
Damage to the water softener
from detergents. Dishwasher detergent will damage
the water softener. Do not fill the salt reservoir with
powder or liquid detergent.
Damage caused by using
unsuitable salts. Other types of salt (such as cooking
salt, rock salt, agricultural grade or gritting salt) may contain insoluble components which can cause the water softener to malfunction.
Only use special coarse-grained dishwasher salt or other pure evaporated salts for reactivation.
If you only ever use combination detergent products containing salt and rinse aid in your dishwasher, you can switch off both refill reminders if you wish (see “Programme options – Switching off the refill reminders”).
24
Please make sure that if you stop using combination detergents, you refill the dishwasher salt and rinse aid. Switch the refill reminders back on if required.

Filling the salt reservoir

Before filling the salt reservoir for the first time, you must fill it with approx. 2litres of water to enable the salt to dissolve.
Once the dishwasher has been used, there is always sufficient water in the salt reservoir.
Remove the lower basket from the
wash cabinet and unscrew the salt reservoir cap.
Using for the first time
Risk of corrosion due to saline
solution. Water or saline solution will run out
of the reservoir when the cap is opened. Saline solution that runs out can cause corrosion in the wash cabinet and to the dishwasher load.
The salt reservoir should therefore only be opened to replenish the salt.
Fill the salt reservoir with approx. 2l
of water (first use only).
Place the funnel provided on the salt
reservoir and carefully fill with dishwasher salt until the reservoir is full. The salt reservoir holds up to 2kg of salt, depending on the type of salt used.
Clean off salt residues from around
the salt reservoir opening. Next, screw the salt reservoir cap on again firmly.
Immediately after filling the salt
container, run the 65 °C QuickPowerWash programme with the Express option and without any load in the dishwasher to dissolve and remove any traces of salt from the wash cabinet.
25
Using for the first time

Replenishing salt

When the Salt indicator lights up,
wait until the end of the programme and then refill the salt reservoir.
Risk of corrosion due to saline
solution. Saline solution that runs out can
cause corrosion in the wash cabinet and to the dishwasher load.
Each time you have opened the salt reservoir cap, immediately run the 65°C QuickPowerWash programme with the Express option and without any dishes. This will dissolve and remove any traces of salt from the wash cabinet.
After the salt reservoir has been filled, the refill reminder may still appear in the display if the salt concentration has not yet reached the correct level. It will go out once the salt concentration has reached the correct level.
The salt refill indicator is deactivated if the dishwasher is set to a water hardness below 0.9mmol/l (5°dH ­German scale).
26
Using for the first time

Rinse aid

Rinse aid is necessary to ensure water does not cling to and leave marks on crockery during the drying phase, and it helps crockery dry faster after it has been washed. Rinse aid is poured into the storage reservoir and the amount set is dispensed automatically.
Washing-up liquid or detergent
can cause damage. Washing-up liquid and dishwasher
detergent will damage the rinse aid reservoir.
Only fill it with rinse aid formulated for domestic dishwashers.
Alternatively, you can use liquid citric acid with up to 10% acid content. The dishes will, however, be more moist and stained than with rinse aid.
Risk of acid damage.
The dishwasher can be damaged by acids with a higher concentration.
Never use citric acid or vinegar with a higher acid content.
If you only ever use combination detergent products in your dishwasher, you do not need to fill the rinse aid reservoir. However, the best rinsing and drying results will be achieved by using a detergent together with separate dishwasher salt and rinse aid.
Please make sure that if you stop using combination detergents, you refill the dishwasher salt and rinse aid. Switch the refill reminders back on if required.
27
Using for the first time

Adding rinse aid

Lift the yellow button on the lid of the
rinse aid container .
The lid will open.
Wipe up any spilled rinse aid. This
prevents over-foaming occurring during the next programme.

Refilling rinse aid

When the Rinse aid refill reminder lights up in the display, the reservoir contains sufficient rinse aid for 2 to 3 programmes only.
Add rinse aid in good time.
The refill rinse aid reminder will go out.
If you only ever use combination detergent products containing salt and rinse aid in your dishwasher, you can switch off both refill reminders if you wish (see “Programme options – Switching off the refill reminders”).
Only add rinse aid until the fill level
indicator (see arrow) turns dark when the door is open horizontally.
The rinse aid reservoir holds approx. 110ml.
Close the flap firmly so that it clicks
into place. Otherwise water can enter the rinse aid reservoir during a programme.
28
Using for the first time

Setting the rinse aid dosage

You can adjust the rinse aid dosage for best results. The rinse aid dosage can be set from 0 to 6ml. 3ml is the factory default setting.
If spots appear on crockery and glassware:
- Increase the rinse aid dosage.
If clouding or smearing appears on crockery and glassware:
- Decrease the rinse aid dosage.
Open the door.Switch the dishwasher off with the
button, if it is switched on.
Press the button in and, while
holding it in, switch the dishwasher
on using the button. Keep the button pressed in for at least 4seconds until the indicator light comes on.
If this does not happen, start the procedure from the beginning again.
Press the programme selection
button 3 times.
The top left programme indicator light will flash rapidly 3 times at intervals.
The dosage set will appear in the display after .
 will start flashing in the display. Setting3 is set.
Use the button to select the
required setting. The setting increases each time you press the button. When the highest value is reached, the setting starts again from the beginning.
The setting is now stored in memory. Switch the dishwasher off with the
button.
29

Caring for the environment

Economical dishwashing

This dishwasher is exceptionally economical in its use of water and electricity. You can support the economical operation of your appliance by following these tips:
- Washing in a dishwasher generally uses less water and energy than washing dishes by hand.
- Pre-rinsing dishes under running water is not necessary and unnecessarily increases water and energy consumption.
- For the most economical dishwashing, make full use of the basket capacity without overloading the dishwasher. This results in the most economical use of the dishwasher in terms of energy and water consumption.
- Choose the programme to suit the type of crockery being washed and the degree of soiling (see “Programme chart”).
- You can connect the dishwasher to a hot water supply. A hot water connection is particularly suitable with energy-saving water heating sources, such as solar water heaters. If the water is heated by electricity, we recommend connection to cold water.
- Select the ECOprogramme for energy-saving dishwashing. This programme is the most efficient in terms of its combined energy and water consumption for cleaning dishes with a normal level of soiling.
- Follow the detergent manufacturer’s recommendations on detergent dosage.
- When using powder or liquid detergent, you can use 1/3 less
detergent if the baskets are only half full.
30
Loading...
+ 70 hidden pages
