Miele G 4220, G 4225 User Manual

Operating Instructions

Dishwasher G 4220 G 4225

To prevent accidents and appliance damage read these instructions

before

installation or use. M.-Nr. 09 510 191

en-US

Contents

IMPORTANT SAFETY INSTRUCTIONS.......4

Guide to the dishwasher ............................................7

Control panel ......................................................8

Caring for the environment..........................................9

Energy saving washing ..............................................9

Before using for the first time.......................................10

To open the door ..................................................10

To close the door ..................................................10

Child Safety Lock..................................................10

Rinse aid ........................................................11

Adding rinse aid ..................................................11

Rinse aid indicator .................................................11

Deactivating refill indicators .......................................12

Setting the rinse aid dosage .........................................13

Loading the dishwasher ...........................................14

Items not recommended for dishwashing ...............................15

Typical load for 10 place settings with cutlery tray ........................16

Typical load for 16 place settings with cutlery tray ........................17

Typical load for 10 place settings with cutlery basket......................18

Typical load for 13 place settings with cutlery basket......................19

Upper basket .....................................................20

Lower basket .....................................................22

Optional accessories..............................................25

Use ............................................................26

Detergent ........................................................26

Adding detergent..................................................27

Turning on .......................................................28

Selecting a program ...............................................28

Starting a program.................................................28

Time display......................................................30

Standby .........................................................30

At the end of a program.............................................31

Preparing your appliance for an extended vacation .......................31

Interrupting a program..............................................32

Changing a program ...............................................32

Contents

Additional options ................................................33

Turbo ...........................................................33

Delay start .......................................................34

Memory .........................................................36

Optimize Standby .................................................37

Factory defaults ...................................................38

Frequently asked questions ........................................39

Technical faults ...................................................39

Faults in the water intake or water drain ................................40

General problems with the dishwasher .................................41

Noises ..........................................................42

Poor cleaning results ...............................................43

After sales service ................................................46

User Maintenance Instructions......................................47

Cleaning and Care ................................................48

Triple filter system .................................................49

Cleaning the drain pump and non-return valve...........................52

Installation instructions ...........................................53

Electrical connection..............................................54

Plumbing........................................................56

Connection to the water supply .......................................56

Drainage ........................................................57

Noise measurement...............................................58

General requirements for measuring noise ..............................58

Installation requirements for measuring noise............................58

IMPORTANT SAFETY INSTRUCTIONS

WARNING –

When using your dishwasher, follow basic precautions, including the following:

Read the operating instructions and installation diagram carefully before installation or use of the dishwasher to prevent injury and machine damage.

Use the dishwasher only for its intended purpose. This appliance is intended for residential use only.

Keep these operating instructions in a safe place and pass them on to any future user.

Correct usage

The dishwasher is not designed for

commercial use. It is intended for use in domestic households and in similar working and residential environments such as, shops, offices and showrooms or guest houses.

The dishwasher is not intended for

outdoor use.

It must only be used as a domestic

appliance as specified in these operating instructions, for cleaning domestic cookware and cutlery. Any other usage is not supported by the manufacturer and could be dangerous.

Persons who lack physical, sensory

or mental abilities, or experience with the appliance should not use the dishwasher without supervision or instruction by a responsible person.

Electrical Safety

Before installation, make sure that

the voltage and frequency listed on the data plate correspond with the household electrical supply. This data must correspond to prevent injury and machine damage. Consult a qualified electrician if in doubt.

Before installation or service,

disconnect the power supply to the work area by unplugging the unit, "tripping" the circuit breaker or removing the fuse.

Do not use an extension cord to

connect this appliance to electricity. Extension cords do not guarantee the required safety of the appliance (e.g. danger of overheating).

Be certain your appliance is

properly installed and grounded by a qualified technician. To guarantee the electrical safety of this appliance continuity must exist between the appliance and an effective grounding system. It is imperative that this basic safety requirement be met. If there is any doubt, have the electrical system of the house checked by a qualified electrician.

If the supplied power cord is

damaged it must only be replaced by a Miele Service technician with a genuine Miele power cord.

The outlet must be accessible at all

times after installation to disconnect the dishwasher.

IMPORTANT SAFETY INSTRUCTIONS

Installation

The dishwasher must be installed

and connected in accordance with the installation instructions.

Installation and repair work should

be performed by a Miele authorized service technician. Work by unqualified persons could be dangerous and may void the warranty.

Do not install or use a damaged

dishwasher. A damaged appliance is dangerous. Unplug the machine and contact Miele Technical Service Department.

Ensure that any plastic wrappings,

bags, etc. are disposed of safely and kept out of the reach of children. Danger of suffocation!

This appliance must not be used in

a non-stationary location (e.g. on a boat).

, WARNING - Fire hazard!

Do not cover or crush the plug of the appliance. Ensure that the cabinet opening for the dishwasher provides ample space for the plug and cord. Installing the dishwasher in a tight space may crimp the power cord or put pressure on the plug which could cause overheating.

This dishwasher should only be

installed under a continuous counter top secured to adjacent cabinetry.

Do not install this dishwasher

beneath a cooking surface, oven or any appliance that radiates heat. High temperatures from these units may damage the dishwasher.

A toe-kick must be used with the

dishwasher. If the supplied toe-kick is not used, a cabinet matching toe-kick must be installed.

Do not install the dishwasher in an

area where it will be exposed to temperatures below freezing.

Do not cut the intake hose or

submerge it in liquid. This hose contains electrical components that could cause injury or property damage if cut or submerged.

Only power up the dishwasher when

all installation and plumbing work is complete.

Do not place hose or power cord

next to a heat source e.g. hot water pipes. Do not expose hose or power cord to corrosive substances. Damage of hose or power cord could cause electrical shock or water damage!

IMPORTANT SAFETY INSTRUCTIONS

Use

To reduce the risk of injury, do not

allow children to play in, on or near the dishwasher. It is possible for small fingers may be pinched in the door.

Only use the dishwasher if all panels

are properly in place.

Do not tamper with the controls.

Do not sit or stand on the door or

baskets of the dishwasher. Close the door when not in use.

Under certain conditions, hydrogen

gas may be produced in a hot water system that has not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not been used for such a period, turn on all hot water faucets and let water flow from each for several minutes before using the dishwasher. This will release any accumulated hydrogen gas. Do not smoke or use an open flame during this time.

Be sure that all items placed in the

dishwasher are "dishwasher safe". For items not labeled, check the manufacturer’s recommendations.

When loading tableware, place

sharp items away from the door to prevent damage to the seal. Load sharp items pointing downwards to prevent injuries.

Only use detergents and rinse aids

recommended for residential dishwashers. Keep all detergents and rinse aids out of the reach of children.

Do not inhale or swallow detergents.

Dishwasher detergents contain irritant and corrosive ingredients. They can cause burning in the mouth and throat if swallowed, or inhibit breathing. Consult a doctor immediately if detergent has been swallowed or inhaled.

Do not drink water from the

dishwasher! Harmful residues could be present.

Do not fill the rinse aid reservoir or

salt container with detergent. It will destroy the rinse aid compartment and water softener.

Dishes can be very hot at the end of

a program. Allow the dishes to cool until they are cool enough to handle before unloading them.

The water supply must be turned off

when the appliance is not used for a longer period of time (e.g. during vacations).

Disposal of an appliance

If the appliance is removed from its

installation site and will not be used, remove the doorlock to the wash cabinet to prevent children from locking themselves in the machine.

SAVE THESE

INSTRUCTIONS

Guide to the dishwasher

a Upper spray arm (not visible)

b Cutlery tray

c Upper basket

d Middle spray arm

e Air inlet for drying

(depending on model)

f Lower spray arm

g Triple filter system

h Data plate

i Child Safety Lock in the door handle

(not visible)

j Rinse aid reservoir

k Dual compartment detergent

dispenser

Guide to the dishwasher

Control panel

a Program selection

b Time display

c Check / Refill indicators

d Start/Stop button with indicator light

This operating instruction manual describes several dishwasher models with different indicated settings. The different dishwasher models are named : Standard = Dishwasher with 31 11/16" (80.5 cm) height (built-in)

or 33 1/4" (84.5 cm) height (stand-alone)

XXL = Dishwasher with 33 1/4" (84.5 cm) height.

e Delay start button with indicator light

f Turbo button with indicator light

g Program button

h K button (On/Off)

Caring for the environment

Energy saving washing

This dishwasher is economical in the use of water and electricity. For best results follow these tips:

^ For lowest energy consumption you

may connect the dishwasher to a cold water source.

^ Make full use of the baskets' capacity

without overloading the dishwasher. This ensures the most economical washing.

^ Choose a program that best suits the

degree of soiling and the type of dishes being washed.

^ Use the Economy program for energy

saving dishwashing. From the aspect of combined energy and water consumption, this program is the most efficient for washing normally soiled dishes.

^ Observe the detergent

manufacturer's recommendations for detergent dosage.

Disposal of the packing material

The cardboard box and packaging protect the appliance during shipping. These materials are biodegradable and recyclable. Please recycle.

Ensure that any plastic wrappings, bags etc. are disposed of safely and kept out of the reach of children. Danger of suffocation!

Disposal of an old machine

Old appliances may contain materials that can be recycled. Please contact your local recycling authority about the possibility of recycling these materials.

Ensure that the appliance presents no danger to children while being stored for disposal. Before discarding an old appliance, unplug it from the outlet, cut off its power cord and remove any doors to prevent hazards.

^ When using powder or liquid

detergent, reduce the amount to of the normal amount when washing a small load.

Before using for the first time

To open the door

^ Press the release catch inside the

door grip.

If the door is opened during operation, the dishwasher will stop running. Once the door is closed the program will restart.

To close the door

Child Safety Lock

The Child Safety Lock is designed to prevent children from opening the dishwasher.

^ To lock the door, push the slider

below the door grip to the right.

^ To unlock the door, push the slider to

the left.

^ Push the baskets in.

^ Lift the door and push until it clicks

into place.

Rinse aid

Rinse aid is needed to prevent spotting on dishes and glassware. The rinse aid is filled in the reservoir and the set amount will be automatically dosed.

Filling the rinse aid reservoir with

detergent will damage the reservoir. Only pour rinse aid formulated for residential dishwashers into the reservoir.

Before using for the first time

When using "Tab" detergents rinse aid is not needed.

Adding rinse aid

^ Press the button on top of the rinse

aid reservoir in the direction of the arrow. The flap will pop open.

^ Pour liquid rinse aid into the reservoir

until it

is visible on the surface of the

screen.

The rinse aid reservoir holds approx.

3.7 oz (110 ml).

^ Press on the flap until you hear it

click shut. Failure to close it all the way allows water to enter the reservoir during the wash program.

^ Clean any spilled rinse aid. The flap

will remain closed during normal operation.

Rinse aid indicator

When the Rinse aid indicator comes on, the reservoir only contains enough rinse aidfor2-3wash programs.

^ Add rinse aid soon.

Before using for the first time

Deactivating refill indicators

If you consistently use Tab detergents, you can deactivate the refill indicator if you wish.

^ Press the K button to turn the

dishwasher off.

^ Press and hold the Start/Stop button

and simultaneously turn the dishwasher on using the K button. Keep the Start/Stop button pressed for at least four seconds until the "Start/Stop" indicator light comes on.

If it does not come on, start over.

^ Press the Delay start button nine

times.

The Delay start indicator light flashes 9 times at short intervals.

The flashing in the time display indicates whether the refill indicators are activated or not.

– "p1": refill indicators are activated

– "p0": refill indicators are deactivated

^ Press the Start/Stop button if you

wish to change the setting.

The setting is immediately saved.

^ Press the K button to turn the

dishwasher off.

If you switch to a single-function detergent, it is important to remember to add rinse aid and to activate the indicator.

Before using for the first time

Setting the rinse aid dosage

You can adjust the rinse aid dosage to optimize the results.

The rinse aid dosage can be set at levels between 0 and 6 ml. The factory setting is 3 ml of rinse aid. This is just a recommendation.

If the dishes are spotty:

^ Use a higher rinse aid setting.

If the dishes are cloudy or streaky:

^ Use a lower rinse aid setting.

^ Press the K button to turn the

dishwasher off.

^ Press and hold the Start/Stop button

and simultaneously turn the dishwasher on using the K button. Keep the Start/Stop button pressed for at least four seconds until the "Start/Stop" indicator light comes on.

If it does not come on, start over.

^ Press the Delay start button three

times.

The Delay start indicator light flashes 3 times at short intervals.

The time display shows the flashing sequence p3.

The set value is shown in the time display after the P.

^ Select the desired dosage with the

Start/Stop button. Every touch of the button increases the level.

The setting is saved immediately.

^ Press the K button to turn the

dishwasher off.

Loading the dishwasher

Do not wash items soiled with

ash, sand, wax, grease or paint in the dishwasher. Ash and sand do not dissolve and will be distributed throughout the inside of the dishwasher. Wax, grease and paint will cause permanent discoloration and damage to the dishwasher.

^ Scrape food from dishes before

placing them in the dishwasher, rinsing is not necessary.

^ Some foods contain natural dyes,

e.g. carrots or tomatoes. Plastic items may discolor permanently if they come in contact with food dyes.

^ All items can be placed anywhere in

the baskets.

^ Load dishes so that water can reach

all surfaces. Do not place dishes or cutlery inside other pieces.

^ The spray arms must not be blocked

by items that are too tall or hang through the baskets. Check clearance by manually rotating the spray arms.

^ Place very small items in the cutlery

tray or basket so they do not fall to the bottom of the wash cabinet.

^ Food residue and spilled liquids

should be cleaned from the sides of the dishwasher door. These are outside of the wash cabinet and are not cleaned by water from the spray arms.

^ Make sure that all items are securely

positioned.

^ Hollow items such as cups and

glasses should be placed upside down in the baskets.

^ To ensure good water coverage, tall,

narrow and hollow items, i.e. vases or champagne glasses, should be placed in the center of the basket rather than in the corners.

^ Concave based items such as mugs

or bowls, should be placed at an angle so that water does not pool.

Loading the dishwasher

Items not recommended for dishwashing

– Cutlery with wooden handles

– Wooden cutting boards

– Glued items such as old knives with

handles glued together around the shank of the blade

– Handmade craft items, antique,

metal trimmed or decorative glassware

– Plastic items that are not heat

resistant

– Copper, brass, tin or aluminum

– Dishes with color painted over the

glaze. These dishes may fade over time

– Fine glassware and crystal items

should only be washed using the "China & Crystal" program*. Otherwise clouding or etching may occur after frequent washing.

– Cast iron pots and pans

* depending on model

Glassware:

– There are no standard guidelines for

washing glassware, when in doubt wash by hand.

– When purchasing new dishes,

glasses and cutlery, make sure they are dishwasher safe. Only wash items marked "dishwasher safe" in the dishwasher.

– If fine glassware is washed in the

dishwasher select the "China & Crystal" program*. This will reduce the risk of clouding.

Silver and aluminum:

– Silver or aluminum items may tarnish.

– Silverware previously cleaned with a

silver polish may be damp or spotted at the end of a program where water has adhered to the polish. This can be rubbed off with a soft, dry cloth. Silver that has been cleaned in an immersion dip is usually dry at the end of a program, but may tarnish.

– If left to dry, foods containing sulfur

can discolor silver. These include egg yolk, onions, mayonnaise, mustard, fish and marinades.

If unsure whether your china and crystal are dishwasher safe, please check with the manufacturer. The China & Crystal program*, although extremely gentle and thorough can cause the china and crystal to "wear" if they are not dishwasher safe.

– Silverware may tarnish or pit if

washed next to stainless steel. Leave space between these metals.

– Clean aluminum items, e.g. grease

filters, with domestic dishwasher detergent only.

Loading the dishwasher

Typical load for 10 place settings with cutlery tray

Upper basket Lower basket

Cutlery tray

Loading the dishwasher

Typical load for 16 place settings with cutlery tray

Upper basket Lower basket

Cutlery tray

Loading the dishwasher

Typical load for 10 place settings with cutlery basket

Upper basket Lower basket

Cutlery basket

+ 42 hidden pages
