Midea VC-35A1Q3 User Manual

Midea Vacuum Cleaner

User Manual

VC-35A1Q3

Please keep the User Manual in good custody for reference.

Please read the User Manual carefully before using the product.

1

Welcome to use Midea vacuum cleaner. For your own safety, please read this user
manual (note: this manual only applies to VC-35A1Q3 products) carefully before any
operation. Keep this manual in a secure place for future reference.

I. Safety Precautions
II. Components & Sketch
III. Circuit Diagram
IV. Before Use
V. How to Use
VI. Cleaning, Maintenance and Storage
VII. Troubleshooting

Safety Precautions

This is an electric appliance. It shall be used under normal operating conditions.

Never leave it running without human attendance.

- This appliance is not intended for use by persons(included children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliance by a

person responsible for their safety.

- Children should be supervised to ensure that they do not play with the appliance.

This appliance is intended to be used in household and similar applications as:

- Staff kitchen areas in shops, offices and other working environments;

- Farm houses;

- By clients in hotels, motels and other residential type environments;

- Breakfast type environments.

Do not use the vacuum cleaner to pick up the following objects, otherwise it may

damage the vacuum cleaner or cause a fire and bodily injuries, etc.

A． Hot objects, e.g., charcoal fire, cigarette butt.

B． Large sharp debris, e.g., glass.

C． Hazardous objects (solvents, corrosives), aggressive agents (acids, detergents)

and liquids such as water.

D． Explosives and flammables such as gasoline or alcoholic products.

To clean or repair the vacuum cleaner or put it idle, disconnect it from the power

2

supply. When disconnecting, never pull the cord but hold the plastic part of the

plug and take it out with care.
Do not pull or fold the hose forcibly to prevent deformation or damage.
Check and make sure the rated voltage of the vacuum cleaner complies with the
local power supply.
Do not insert the power cord of the vacuum cleaner through any sharp objects to
avoid damages.
Do not immerse the machine into water, approach it to heaters or expose it to
sunshine, otherwise, it may catch a fire.
Do not attempt to move the machine by dragging the power cord.
Do not allow children to tamper with or operate the machine to prevent accidents.
Do not press the dust bag release button when handling the machine; otherwise,
it may detach from the machine and cause damage.
It is not recommended to use this machine to pick up lime, ash concrete or any
other construction waste because it may damage the motor or the machine.
Do not operate the machine in any case of the following:
A. The machine is apparently damaged or does not work properly after falling

off.

B. The power cord is damaged.

In case of the above situations, do not turn on the machine. Send it to our
repair centre for repair immediately.
Do not have the machine operate for prolonged period of time when the inlet
is clogged to prevent damage to the motor or deformation of the machine due
to overheating.
The machine uses Y connection, therefore, in case the power cord is
damaged, for safety, please ask a specialist from the manufacturer, its service
department for replacement.

3

Main Body

4 5 3 1 7 6 8

1. Floor brush

2. Hose assembly

3. Connecting tube

4. Main body

5. Cord rewind button

6. Speed control button

7. Switch button

8. Round brush

9. Bedsheets brush

10. Flat nozzle

9

2

10

4

Circuit Diagram
