Microsoft Xbox 360 Pro Operating Instructions

1 English

26 Français

52 Español

English

Warning

Failure to properly set up, use, and care for

the Xbox 360 video game and entertainment system can increase the risk of serious injury or death, or damage to the Xbox 360 video game and entertainment system. Read this manual and the manuals of any accessories for important safety and health information. Keep all manuals for future reference. For replacement manuals, go to www.xbox.com/support or call the Xbox Customer Support number provided on the back cover.

Before allowing children to use the Xbox

360 video game and entertainment system:

1 Determine how each child can use the

Xbox 360 console (playing games, connecting to Xbox LIVE, replacing batteries, making electrical, AV cable, and network connections) and whether they should be supervised during these activities.

2 If you allow children to use the Xbox 360

console without supervision, be sure to explain all relevant safety and health information and instructions.

The Xbox 360 console will not play copied

or “pirated” games or other unauthorized media. Attempting to defeat the Xbox 360 anti-piracy protection system may cause your Xbox 360 console to stop working permanently. It will also void your Limited Warranty, and may make your Xbox 360 console ineligible for authorized repair, even for a fee.

You must accept the terms and conditions

of the Limited Warranty and this manual to use your Xbox 360 console. If you do not accept these terms and conditions, do not set up or use your Xbox 360 console and return it to Microsoft for a refund.

This symbol identies safety and health

messages in this manual and Xbox 360 accessories manuals.

For your warranty and other important information, see the Xbox 360 Warranty manual.

2 Your Xbo

3 Select a Loc

4 Connect to Yo

6 Connect to Po

8 The Xbox 360 Wireless Controller

8 Set Up Your Wireless Controller

10 Xbox 360 Family Settings

11 Using the Disc Drive

12 Important Health Warnings About

13 Play Gam

13 Connect to Xbox LIVE

18 Watch Movies

18 Play CDs

19 Share Media from an Audio Player

20 Share Med

21 Storage

22 Add Wireless Controllers

23 Connect Additional Accessories

24 Troubleshooting

81 Customer Support

x 360 Video Game

and Entertainment System

ation for Your

Console

ur TV and

Audio System

wer

Playing Video Games

or Camera

ia from Your PC

english

Power Cord Power Supply

Xbox 360 Console

and Wireless Controller

Ethernet Cable

AA Batteries

Component

HD AV Cable

Instruction Manual (2)

Headset

Removable Hard Drive

YOUR XBOX 360 VIDEO GAME AND ENTERTAINMENT SYSTEM

english

Thanks for purchasing your Xbox 360™ video game and entertainment system from Microsoft. You’re now at the center of a customizable experience that brings your games, your friends, and your digital entertainment together in one powerful package.

e Xbox 360 video game and

• Th entertainment system lets you play Xbox 360 games, DVD movies, and audio CDs.

• With high-speed Internet service, connect to millions of gamers on Xbox LIVE Instantly be a part of a community where you can play together, talk to your friends, and download new content.

• Stream pictures, music, and more to your Xbox 360 console by connecting to your

Microsoft devices such as digital cameras and portable music players.

• Enjoy music and other content pre-installed with your Xbox 360 Hard Drive. For more information about the Xbox 360 Hard Drive, go to www.xbox.com.

Windows®-based PC or other

SELECT A LOCATION FOR YOUR CONSOLE

Prevent the Console from Falling

If the Xbox 360 console falls and hits

someone, especially a small child, it could cause serious injury. To reduce the risk of such injuries and damage to the Xbox 360 console, set up the Xbox 360 console according to these instructions. Place the console on a surface that:

• Is at and level.

• Is stable and not likely to tip over.

• Allows all four feet of the console to be in contact with the surface.

• Is not likely to allow the console to slip or slide off.

• Is clean and free of dust and debris.

If the surface or console feet become dirty or dusty, clean them with a dry cloth. If the console is positioned vertically, put it on a surface where it is not likely to fall if it tips over.

Arran and pets are not likely to trip over or accidentally pull on them as they move around or walk through the area. When the console is not in use, you may need to disconnect all cables and cords from the front and rear of the console to keep them out of the reach of children and pets. Do not allow children to play with cables and cords.

ge all cables and cords so that people

Prevent the Console from Overheating

Do not block any ventilation openings on the console or power supply. Do not place the console or power supply on a bed, sofa, or other soft surface that may block ventilation openings. Do not place the console or power

supply in a conned space, such as a

bookc

ase, rack, or stereo cabinet, unless the

space is well ventilated. Do not place the console or power supply

near any heat sources, such as radiators, heat

registers, stoves, or ampliers.

Avoid Smoke and Dust

Do not use the console in smoky or dusty locations. Smoke and dust can damage the console, particularly the DVD drive.

english

CONNECT TO YOUR TV AND AUDIO SYSTEM

english

iMPOrTanT

Stationary images in video games can “burn” into some TV screens, creating a permanent shadow. Consult your TV owner’s manual or manufacturer before playing games.

Connect the Component HD AV Cable

Use your component HD AV cable to connect your console to your TV.

To connect to your standard TV:

1 Connect the HD AV cable connector to the

AV port on the console.

2 Set the switch on the AV port connector to

TV.

3 Connect the yellow color-banded

composite signal video connector on the HD AV cable to the yellow input on your TV. Leave the red, green, and blue colorbanded video connectors unconnected.

4 Connect the solid color left and right (white

and red) audio connectors on the HD AV cable to the audio inputs on your TV or stereo receiver.

For monaural (mono) TVs, which have only

one audio input, connect either the right or left audio connector to the audio input.

5 Select the appropriate video input on your

TV (see No Picture under “ Troubleshooting” for more information).

nOTE

Your Xbox 360 Component HD AV Cable has two distinct sets of connectors on the TV end grouped by audio and video. Do not confuse the red connector from the audio group with the red connector from the video group.

english

To connect to your high denition TV:

1 Connect the HD AV Cable connector to the

AV port on the console.

2 Set the switch on the AV port connector to

TV or HDTV. The HDTV position should be

selected if your TV supports high denition

lutions such as 480p, 720p, 1080i, or

reso 1080p.

3 Connect the red, green, and blue color-

banded video connectors on the HD AV cable to the corresponding color inputs (Y, Cb/Pb, Cr/Pr) on your TV. Leave the yellow color-banded composite video connector unconnected.

4 Connect the solid color left and right (white

and red) audio connectors on the HD AV cable to the audio inputs on your TV or stereo receiver.

5 Select the appropriate video input on your

TV (see “No Picture” under “Troubleshooting” for further information).

After you’ve set up your console, you can

congure additional console audio settings

st your connection from the System

and te area of the Xbox Dashboard. But before doing so, proceed through the steps in the following pages for connecting to power, connecting your controller, and other initial settings.

Other AV Input

You can also connect to additional TV input types by using the Xbox 360 S-Video AV Cable, the Xbox 360 VGA HD AV Cable, or the Xbox 360 HDMI AV Cable (all sold separately). For more information, go to www.xbox.com/setup.

Connect to a Digital Audio System

If your system (typically, a receiver or

amplier) supports digital audio input, you can

conn

ect to digital audio rather than to the standard left and right audio. Digital audio should produce higher-quality sound.

To connect to digital audio:

1 Connect your video input as described in

the preceding sections.

2 Connect your digital audio cable (not

included) to the digital audio output on your AV cable and to the digital audio input on your receiver.

CONNECT TO POWER

Electrical Safety

As with many other electrical devices,

failure to take the following precautions can result in serious injury or death from

electric shock or re or damage to the

60 video game and entertainment

Xbox 3 system.

ect an appropriate power source for

Sel

english

your Xbox 360 console:

• Use only the power supply unit and AC power cord that came with your console or that you received from an authorized repair center. If you are not sure if you have the correct power supply unit, compare the model number on the power supply unit with

the model number specied on your

ole. If you need a replacement

cons power supply unit or AC power cord, contact Xbox Customer Support.

• Conrm that your electrical outlet

provides the type of power indicated on the power supply unit (in terms of

voltage [V] and frequency [Hz]). If you are not sure of the type of power supplied to your home, consult a

qualied electrician.

ot use non-standard power

• Do n sources, such as generators or inverters, even if the voltage and frequency appear acceptable. Only use AC power provided by a standard wall outlet.

• Do n

ot overload your wall outlet,

extension cord, power strip, or other

electrical receptacle. Conrm that they

are rat

ed to handle the total current (in amps [A]) drawn by the Xbox 360 console (indicated on the power supply unit) and any other devices that are on the same circuit.

• Do not connect any other devices between the Xbox 360 power supply unit and the Xbox 360 console or between the power cord and the Xbox 360 power supply unit.

To avoid damaging the power cords and power supply:

• Protect the power cords from being walked on.

• Protect cords from being pinched or sharply bent, particularly where they connect to the power outlet, the power supply unit, and the console.

• Do not jerk, knot, sharply bend, or otherwise abuse the power cords.

• Do not expose the power cords to sources of heat.

• Do not wrap power cords around the power supply unit.

• Keep children and pets away from the power cords. Do not allow them to bite or chew on them.

• When disconnecting the power cords, pull on the plug—do not pull on the cord.

• Do n from e

If a power cord or power supply becomes

damaged in any way, stop using it immediately and contact Xbox Customer Support for a replacement.

Unplug your Xbox 360 console during

lightning storms or when unused for long periods of time.

Always connect th

according to the following instructions:

1 Fully insert the power supply cord

into the Xbox 360 console.

2 Plug the AC power cord into the power

supply until it stops.

3 Plug the other end of the AC power

cord into the wall outlet.

ot let the power supply hang

ither power cord.

english

e power cords

THE XBOX 360 WIRELESS CONTROLLER

Your wireless controller lets you experience the ultimate in wireless freedom with the same precision, speed, and accuracy as a wired controller.

Xbox Guide Button

The Xbox Guide button in the center of your controller puts the Xbox 360 experience at your

ngertips. Press the Xbox Guide button to turn

onsole on. Once on, pressing the Xbox

your c Guide button gives you immediate access to the Xbox Guide. To turn off your console, press and hold the Xbox Guide button for three seconds

and conrm your selection.

Ring of Light

Composed of four quadrants, the Ring of Light that surrounds the Xbox Guide button on the controller and the Power button on the console is the Xbox 360 status indicator. When you connect a controller to your console, it is

SET UP YOUR WIRELESS CONTROLLER

Before you can use your Xbox 360 Wireless Controller with your Xbox 360 console, you need to insert a battery pack.

english

Insert Batteries

The wireless controller uses disposable batteries or the Xbox 360 Rechargeable

assigned a specic quadrant, which glows green

icate the controller’s number and position.

to ind Each subsequent controller connected to the console (up to four) is assigned an additional quadrant.

If sys

tem problems should arise, the Ring of Light

on the console will ash combinations of red. For

more i

nformation, see “Troubleshooting.”

Expansion Port

The expansion port (with 2.5-mm audio connector) on your controller lets you connect expansion devices like the Xbox 360 Headset to your controller. For more information, see the instruction manual for your controller expansion device.

Charge Port

The charge port on the front of your controller works exclusively with the Xbox 360 Play & Charge Kit (sold separately).

Battery Pack (sold separately). If you plan to use disposable batteries, you should familiarize yourself with the “Disposable Battery Safety” section that follows.

Disposable Battery Safety

Improper use of batteries may result in

battery uid leakage, overheating, or explosion. Risk of re if batteries are

repl

aced by an incorrect type. Released

battery uid is corrosive and may be toxic.

ause skin and eye burns, and is

It can c harmful if swallowed. To reduce the risk of injury:

• Keep batteries out of reach of children.

• Do not heat, open, puncture, mutilate,

or dispose of batteries in re.

• Us

e only alkaline batteries, type AA

(LR6).

• Do n

ot mix new and old batteries.

• Remove the batteries if they are worn out or before storing your controller for

an extended period of time. Do not leave batteries in the AA battery pack when it is not installed in the controller.

• If a battery leaks, remove all batteries,

taking care to keep the leaked uid

from t

ouching your skin or clothes. If

uid from the battery comes into contact with skin or clothes, ush skin

ater immediately. Before

with w inserting new batteries, thoroughly clean the battery compartment with a damp paper towel, or follow the battery manufacturer ’s recommendations for cleanup.

• Dispose of batteries in accordance with local and national disposal regulations (if any).

Insert batteries according to the following instructions.

To insert batteries into the wireless controller

AA bat tery pack:

1 Press the tab on the top of the AA battery

pack and pull down to detach it from the controller.

2 Insert two new AA (LR6) batteries with

their positive (+) and negative (–) ends as shown on the underside of the battery pack. For best performance, AA rechargeable batteries are not recommended.

3 Slide the AA battery pack back into place

on the controller and push it in to lock.

Remove Controller Batteries

Aboard Aircraft

Before boarding any aircraft or packing

the wireless controller in luggage that will be checked, remove any batteries from the wireless controller. The wireless controller can transmit radio frequency (RF) energy, much like a cellular telephone, whenever batteries are installed.

Connect Your Wireless Controller to Your Console

Your Xbox 360 Wireless Controller comes already wirelessly connected to your console, right out of the box. Should you need to reconnect your wireless controller to your console or connect to a different console, see “Add Wireless Controllers.”

Turn Your Console and Wireless Controller On

To turn your console and controller on, press and hold the Xbox Guide button on your controller.

n on your console only, press the Power

To tur button on your console. To turn on your controller only, press the Start button on your controller.

nOTE

To avoid pinching your ngers when inserting, push only on the at surface of the battery

pack.

Turn Your Console and Wireless Controller Off

To turn your console and controller off, press and hold the Xbox Guide button on your controller for three seconds. Then select whether you want to turn off just your controller or both your controller and your console. (Selecting the console will turn off both the console and all connected controllers.)

Pressing the power button on your console will turn off both the console and any connected wireless controllers.

Select Language and Other Settings

The rst time you turn on your Xbox 360

console, you’ll be prompted to enter a language. Follow the prompts to select a language for your console.

You can change language and other console settings in the System area of the Xbox Dashboard, including time, audio, display, and automatic turn-off after six hours of non-use.

english

The new Family Settings feature for Xbox 360 gives parents and caregivers the ability to provide ageappropriate entertainment

Console settings can limit the games and movies that can be played on your console. Xbox LIVE settings can customize the Xbox LIVE experience for each child account, even when playing away from home.

through customized settings.

Apply Family Settings

To apply Family Settings for your games and

Xbox LIVE:

1 Select System, Family Settings. 2 Choose the settings you want to apply to

your console and your Xbox LIVE accounts.

In the U.S. and Canada, Xbox 360 Family Settings for games are based on the ESRB (Entertainment Software Rating Board) rating system and movie settings are based on the MPAA (Motion Picture Association of America) rating system. By default, Xbox 360 Family Settings are set to Allow All for games and movies. For more information about game

english

ratings, see www.esrb.org. Not all movies have the rating encoded on the

DVD. These DVD movies will play regardless of your settings.

Xbox LIVE Settings

You can make sure that your family has a positive experience on Xbox LIVE by setting limits for each child’s account. Manage up to eight settings for each account and set different limits for each account. Your child’s Xbox LIVE settings are pre-selected when their Xbox LIVE account is created. You can make changes at any time by selecting System, Family Settings, Live Controls, and choosing the child’s account.

Family Settings for Xbox LIVE includes these features:

• Parental approval for adding individuals to your child’s friends list.

• Limiting voice, video, and text chat to individuals on your child’s friends list.

• Blocking or limiting the display of your

child’s pro le information and online

status.

• Blocking or limiting your child’s ability to view content created by other gamers.

• Blocking access to Xbox LIVE multiplayer games.

• Preventing your child from purchasing items on Xbox LIVE Marketplace.

USING THE DISC DRIVEXBOX 360 FAMILY SETTINGS

To insert a disc:

1 Press the eject button to open the disc tray. 2 Place the Xbox 360 game disc, audio CD, or

DVD movie on the disc tray with the label facing up (to the right if the console is vertical).

To eject a disc:

1 Press the eject button to open the disc tray. 2 Remove the disc. 3 Press the eject button to close the disc

tray.

nOTE

When the console is oriented vertically, make sure the disc is held in place by the tabs on the disc tray so that it doesn’t fall.

iMPOrTanT

To avoid jamming the disc drive and damaging discs or the console:

• Remove discs before moving the console or tilting it between the horizontal and vertical positions.

• Never use cracked discs. They can shatter inside the console and jam or break internal parts.

• When the console is vertical, do not use discs that are smaller than standard DVDs and CDs. If the disc drive jams or is damaged, contact Xbox Customer Support to have your console repaired or exchanged.

english

IMPORTANT HEALTH WARNINGS ABOUT PLAYING VIDEO GAMES

Photosensitive Seizures

A very small percentage of people may

experience a seizure when exposed to

certain visual images, including ashing

ts or patterns that may appear in

ligh video games. Even people who have no history of seizures or epilepsy may have an undiagnosed condition that can cause these “photosensitive epileptic seizures” while watching video games.

These seizures may have a variety of

symptoms, including lightheadedness, altered vision, eye or face twitching, jerking or shaking of arms or legs, disorientation, confusion, or momentary loss of awareness. Seizures may also cause loss of consciousness or convulsions that can lead to injury from falling down or striking nearby objects.

Immediately stop playing and consult a

doctor if you experience any of these symptoms. Parents should watch for or ask their children about the above symptoms—children and teenagers are more likely than adults to experience

english

these seizures. The risk of photosensitive epileptic seizures may be reduced by taking the following precautions:

• Sit farther from the TV screen.

• Use a smaller TV screen.

• Play in a well-lit room.

• Do not play when you are drowsy or fatigued.

u or any of your relatives have a

If yo

history of seizures or epilepsy, consult a doctor before playing.

Musculoskeletal Disorders

Use of game controllers, keyboards,

mice, or other electronic input devices may be linked to serious injuries or disorders.

When playing video games, as with

many activities, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. However, if you experience

symptoms such as persistent or recurring discomfort, pain, throbbing, aching, tingling, numbness, burning sensation, or stiffness, DO NOT IGNORE THESE WARNING SIGNS. PROMPTLY SEE A QUALIFIED HEALTH PROFESSIONAL, even if symptoms occur when you are not playing a video game. Symptoms such as these can be associated with painful and sometimes permanently disabling injuries or disorders of the nerves, muscles, tendons, blood vessels, and other parts of the body. These musculoskeletal disorders (MSDs) include carpal tunnel syndrome, tendonitis, tenosynovitis, vibration syndromes, and other conditions.

While researchers are not yet able to

answer many questions about MSDs, there is general agreement that many factors may be linked to their occurrence, including medical and physical conditions, stress and how one copes with it, overall health, and how a person positions and uses their body during work and other activities (including playing a video game). Some studies suggest that the amount of time a person performs an activity may also be a factor.

Some guidelines that may help you work

and play more comfortably and possibly reduce your risk of experiencing an MSD can be found in the Healthy Gaming Guide at www.xbox.com. These guidelines address topics such as:

• Positioning yourself to use comfortable, not awkward, postures.

• Keeping your hands, ngers, and

other body parts relaxed.

• Taking breaks.

• Developing a healthy lifestyle.

If you have questions about how your

own lifestyle, activities, or medical or physical condition may be related to

MSDs, see a qualied health

professional.

PLAY GAMES

The Xbox 360 console can play only game discs licensed by Microsoft for the Xbox 360 video game and entertainment system. Licensed games bear this logo:

For the latest information about Xbox 360 games, go to www.xbox.com.

CONNECT TO XBOX LIVE

You can instantly become an Xbox LIVE Silver member by simply connecting an Ethernet cable to the Ethernet port on the back of the console. With a Silver membership, you can create a gamertag, access the Xbox LIVE Marketplace, view gamer cards, participate in chats, get voice messages, make friends, and use Xbox LIVE Family Settings. Xbox LIVE Silver members get limited-time gameplay through special events like free Xbox LIVE Gold weekend play, Xbox LIVE Game with Fame, and Xbox LIVE Prime Time.

If you’re ready for the full Xbox LIVE experience, sign up for an Xbox LIVE Gold membership. Xbox LIVE Gold gives you all the features of Xbox LIVE Silver, plus online multiplayer gaming, enhanced matchmaking and feedback tools, privileges and rewards on Xbox LIVE Marketplace, and media features such as music and photo sharing.

To start a game:

1 Press the eject button to open the disc tray. 2 Place the Xbox 360 game disc on the disc

tray with the label facing up (to the right if the console is vertical).

3 Press the eject button to close the disc

tray. The game will start.

Set Up Your Connection

Set up your Xbox LIVE connection using one of the following connection types. You can also set up a wireless home network connection using the Xbox 360 Wireless Networking Adapter (sold separately). For more information about setting up your connection and further home networking options, go to www.xbox.com/setup.

nOTE

You must have a high-speed (cable or DSL) Internet connection to play on Xbox LIVE. You must also have an Xbox 360 Hard Drive included with the standard Xbox 360 system; sold separately for Xbox 360 Arcade or Xbox 360 Memory Unit to store your Xbox LIVE account information.

english

Cable/DSL Modem

Router

Modem Connection

Choose a modem connection if you want the easiest way to set up and play and you don’t want to share your Internet connection with your PC (or other device).

english

To set up a modem connection:

1 Connect one end of an Ethernet cable to

the Ethernet port on your high-speed modem and the other end to the Ethernet port on the back of your Xbox 360 console.

2 Follow the on-screen instructions. You may

need to enter information provided by your ISP in the System area of the Xbox Dashboard.

Cable/DSL Modem

Router

Router Connection

Choose a router connection if you want to share your Internet connection with your PC (or other device), your high-speed modem supports an Ethernet connection, and you want to be able to play on Xbox LIVE whether your PC is on or off.

To set up a router connection:

1 Connect one end of an Ethernet cable to

the Ethernet port on your high-speed modem and the other end to the WAN or Uplink port on your router.

2 Connect one end of an Ethernet cable to an

Ethernet LAN port on your router and the other end to the Ethernet port on your PC (or other device). Follow the instructions

from your ISP to use your PC’s browser or

software to congure the router, then

fy that your PC is connected to the

veri Internet.

3 Connect one end of an Ethernet cable to an

Ethernet LAN port on your router and the other end to the Ethernet port on the back of your Xbox 360 console.

n OTE

Some modems and devices may require a

network hub instead of a router.

4 Follow the on-screen instructions. You may

need to enter information provided by your ISP in the System area of the Xbox Dashboard.

english

Cable/DSL gateway

Gateway Connection

Choose a gateway connection if your ISP has supplied you with an Ethernet gateway device. Like a router connection, you can share your Internet connection with your PC (or other device) and play on Xbox LIVE whether your PC is on or off.

To set up a gateway connection:

1 Connect your high-speed Internet

english

connection to your gateway (using the coaxial cable jack for cable providers or telephone jack for DSL providers).

2 Connect one end of an Ethernet cable to an

Ethernet LAN port on your gateway and the other end to the Ethernet port on your PC (or other device). Follow the instructions from your ISP to use your PC’s browser or

software to congure the gateway, then

veri

fy that your PC is connected to the

Internet.

3 Connect one end of an Ethernet cable to an

Ethernet LAN port on your gateway and the other end to the Ethernet port on the back of your Xbox 360 console.

4 Follow the on-screen instructions. You may

need to enter information provided by your ISP in the System area of the Xbox Dashboard.

Troubleshoot Your Connection

If your Xbox 360 console cannot connect automatically, you may need to manually

congure your network settings in the Xbox

board. Some Internet service providers

Dash

(ISPs) require specic settings, including host

, MAC address, and ISP user name and

name password (for PPPoE authentication). If you are unsure about whether you need this information, check with your ISP. For more information, go to www.xbox.com/setup.

To create your account, select Xbox LIVE from the Xbox Dashboard and follow the instructions on the screen.

Communicate on Xbox LIVE

Use your Xbox 360 Headset to chat and communicate with your friends while on Xbox LIVE.

Connect Your Headset to Your Controller

To connect your headset:

1 Turn down the volume by rotating the

volume control all the way to the left. Insert the 2.5-mm headset connector into the controller expansion port at the back of your game controller.

2 Put on your headset and adjust the

microphone.

n OTE

Correct placement of the headset and

microphone is critical to using your headset successfully. Make sure the headset goes over the top of your head, not around the back of your head. You may rotate the microphone and earpiece to your right or left side. Position the microphone about one inch (2.54 cm) from your mouth and off to one side. This will ensure that it doesn’t transmit your breathing into a chat session. As you adjust the microphone, make sure the microphone opening is pointed toward your mouth and not rotated on its axis.

3 Now the headset is ready for a game or

chat session. Start your game or chat and turn the volume up to a comfortable level.

Use Your Headset

To temporarily turn off voice transmission, slide the mute switch on the headset control. To adjust the listening volume of the headset, rotate the volume control knob. For more information about using your Xbox 360 Headset with a particular game, see your

game manual. To chat and send voice messages, you need

an Xbox LIVE membership.

iMPOrTanT

To prevent damage to your headset, avoid sitting or stepping on the headset, its cable, or the cable connector.

Hearing Loss

Extended exposure to high volumes when

using a headset may result in temporary or per

manent hearing loss. Some unapproved third-party headsets may produce higher sound levels than

oved Xbox 360 Headsets.

appr

english

Ethernet

USB

WATCH MOVIES

Your Xbox 360 console plays DVD movies. To enhance your DVD movie playback experience, consider using the Xbox 360 Universal Media Remote (sold separately).

To play DVD movies:

1 Press the eject button to open the disc tray. 2 Place the DVD movie on the disc tray with

the label facing up (to the right if the console is vertical).

3 Press the eject button to close the disc

tray. The DVD movie will begin playing.

PLAY CDs

The Xbox 360 console can play audio CDs that have this logo:

english

4 Press any controller button other than the

Xbox Guide button to show the DVD on-

screen controls. Use your controller to

control movie playback.

The Xbox 360 console can only play region 1 DVDs that have this logo:

To play audio CDs:

1 Press the eject button to open the disc tray. 2 Place the audio CD on the disc tray with

the label facing up (to the right if the

console is vertical).

3 Press the eject button to close the disc

tray. The CD will begin playing.

Ethernet

USB

SHARE MEDIA FROM AN AUDIO PLAYER OR CAMERA

english

Use your Xbox 360 console to play music,

view pictures, and access media les from

othe

r devices. You can connect USB devices such as music players and digital cameras to the Xbox 360 USB ports. You can also connect your console to a Windows–based PC or a Windows Media Center–based PC.

For a list of third-party devices supported by Xbox 360, go to www.xbox.com/media.

Stream Music to Your Console

To stream music from a personal audio player

to your Xbox 360 console:

1 Connect a USB cable (not provided)

between the device and your console.

2 Congure the device to play through the

USB port.

3 Select Media, Music, Portable Device. 4 Select the music or playlist you want to

listen to.

nOTE

Recordings and programs may be protected by copyright. Microsoft does not authorize, support, or condone the use of its products for unauthorized copying. You may not copy, reproduce, distribute, publicly perform, or modify recordings unless authorized by the copyright owner or allowed by law.

View Your Pictures

You can create slideshows and view pictures stored on your digital camera.

To connect your digital camera:

1 Set up your digital camera for viewing

pictures. See your camera instructions for details about how to view pictures.

2 With your console turned on, use a USB

cable to connect your camera to a USB port on the console.

3 The console will detect your digital camera.

Follow the on-screen instructions to access your pictures.

SHARE MEDIA FROM YOUR PC

To access media les, including video, audio,

and pictures, from a Windows XP–based PC, you need a simple Ethernet connection from the Ethernet port on the back of your Xbox 360 console to your PC. If your PC or home network is also connected to high-speed Internet, you can use this connection to connect to Xbox LIVE. For more information about home networking options, see “Connect to Xbox LIVE” or go to www.xbox.com/setup.

Windows Media Connect lets you connect your Xbox 360 console to a PC running Windows XP Service Pack 2 (SP2) or later. If you have a Windows Media Center–based PC, you can also use it with your connected Xbox 360 console.

Along with normal DVD remote control functions, the Xbox 360 Universal Media Remote (sold separately) features a Windows Media Center button that lets you access a connected Windows Media Center–based PC.

Windows Media Connect

Windows Media Connect lets your Xbox 360 console stream music and pictures stored on your Windows XP–based PC anywhere in your

english

home. View slide shows on your TV, and play all your music through one sound system connected to your console through a digital audio receiver. To learn more about Windows Media Connect, go to www.xbox.com/media.

To set up Windows Media Connect:

1 Go to www.xbox.com/pcsetup and

download the Windows Media Connect software to a PC running Windows XP SP2 or later.

2 Connect your console to your PC using one

of the connection types described in “Connect to Xbox LIVE.”

3 Select Media, and then select pictures or

music from your PC. Follow the on-screen

instructions to nish Windows Media

ect setup.

Conn

Windows Media Center

Your Xbox 360 console can deliver the ultimate integration of gaming and room-toroom entertainment—including watching or recording TV shows, viewing your digital photos, and listening to your digital music library—from a Windows Media Center–based PC to any TV in your home. When you connect your console to the same network as your Windows Media Center–based PC, the experience is delivered to your Xbox 360 video game and entertainment system. (You can

connect up to ve consoles to a Windows

Medi

a Center–based PC.)

To learn more about Windows Media Center for Xbox 360, go to www.microsoft.com/extender.

To set up Windows Media Center:

1 Go to www.xbox.com/pcsetup and

download the latest Windows Media Center software update to your Windows Media Center–based PC.

2 Connect your console to your Windows

Media Center–based PC using one of the connection types described in “Connect to Xbox LIVE.”

3 On your Xbox 360 console, go to Media,

then select Windows Media Center.

Follow the on-screen instructions to nish

ows Media Center setup.

Wind

STORAGE

With the Xbox 360 Hard Drive (included) or an Xbox 360 Memory Unit (sold separately), you can save games and other media and enable Xbox LIVE sign-in.

Remove and Reattach Your Hard Drive

Your Xbox 360 console comes with a hard drive attached, but should you need to remove it, use the following procedures for removal and reattachment.

To remove your hard drive:

1 Turn off your

console.

2 Press the tab

on the front of the hard drive and lift the unit from the console.

iMPOrTanT

Avoid touching hard drive bay contacts and

hard drive connector contacts with ngers or
