Surface Pro X
Fact Sheet
October 2020
Meet the future of always-connected productivity.
What’s new?
Surface Pro X introduces the Microsoft SQ®2, the second generation of our custom chip on our
premium configurations, building on the innovation of the Microsoft SQ® 1, delivering even more multi-tasking power for true connected productivity.
Surface Pro X is now available in a new Platinum finish in addition to Matte Black, and Surface Pro
X Keyboards are now available in three new colors2: Ice Blue, Poppy Red, and Platinum, in addition to Black.
In addition to refreshing our top-end SKUs, additional software improvements will benefit all
customers of Surface Pro X:
o Increased battery life that now delivers up to 15 hours of typical usage.
3
o Increasing number of key app partners are embracing Windows on ARM and taking
advantage of the power and performance benefits of Microsoft SQ® 1 and Microsoft SQ® 2 and bringing new experiences for all Surface Pro X customers – current and new, including new Microsoft 365 applications4 optimized for Windows on ARM such as Microsoft Edge and Microsoft Teams which provides improved performance and reliability.
o For developers, Visual Studio Code
4
has updated and optimized for Windows on ARM. The new VS Code, paired with WSL2 and the Windows Terminal make Surface Pro X the ideal modern dev box.
Top Features and Benefits
All screen. Ultra-thin bezels deliver an almost edge-to-edge 13” brilliant PixelSense™ display that
brings your work to life on our thinnest Surface Pro.
Always Connected. Connect nearly anywhere with friends, family and colleagues over built-in HD
webcams backed by Studio Mics, Dolby® Audio™, and blazing-fast Gigabit LTE.1 Make a more personal connection with Eye Contact. Powered by artificial intelligence and the onboard neural engine, Eye Contact helps to adjust your gaze on video calls, so you appear to be looking directly in the camera.
Ready when creativity strikes. Surface Slim Pen is there to help you capture every idea in the
moment stored securely and charged in the Signature Keyboard so you’ll never lose it.4
Built for how you live and work. If you live and work in the cloud, Surface Pro X was designed
for you, with blazing-fast speed, support, and choice of Microsoft SQ® 1 and Microsoft SQ® 2 processors. The custom processors powered by Qualcomm combine the connectivity you love on your smartphone with the power of Windows, keeping you connected wherever you go so you never miss a beat. Stay up and running with all-day battery life up, now with up to 15 hours across both configurations,3 and the ability to recharge fast – about 80% in just under an hour.3
Technical Specifications
Operating System
Windows 10 Home on ARM5 (Consumer) Microsoft 365 Family 30-day trial
Exterior
11.3 in x 8.2 in x 0.28 in (287 mm x 208 mm x 7.3 mm) Casing: Signature anodized aluminum with carbon composite fan less thermal cooling Colors: Matte Black, Platinum2 Physical buttons: Volume, Power Weight6 (not including keyboard): 1.7 lbs (774 g)
Display
Screen: 13” PixelSense™ Display (sRGB + Enhanced Color Profiles) Resolution: 2880 x 1920 (267 PPI) Aspect ratio: 3:2 Touch: 10-point multitouch
CPU
Microsoft SQ® 1 Microsoft SQ® 2
Graphics
Microsoft SQ® 1 Adreno™ 685 GPU Microsoft SQ® 2 Adreno™ 690 GPU
Memory
8GB or 16GB LPDDR4x RAM
Storage
Removable solid-state drive (SSD)7 options: 128, 256, or 512GB
Security
Firmware TPM chip for enterprise security and BitLocker support Enterprise-grade protection with Windows Hello face sign-in
Network
Wi-Fi 5: 802.11ac compatible Bluetooth Wireless 5.0 technology Qualcomm® Snapdragon™ X24 LTE modem Up to Gigabit LTE Advanced Pro4 with nanoSIM and eSIM support. LTE Bands supported: 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 19, 20, 25, 26, 28, 29, 30, 38, 39, 40, 41, 46, 66 Assisted GPS and GLONASS support
Battery
Up to 15 hours of typical device usage
3
Cameras
Windows Hello face authentication camera (front-facing)
5.0MP front-facing camera with 1080p full HD video
10.0MP rear-facing autofocus camera with 1080p HD and 4k video
Audio
Dual far-field Studio Mics 2W stereo speakers with Dolby® Audio™
Ports
2 x USB-C®3.2 Gen 2 1 x Surface Connect port Surface Keyboard connector port 1 x nano SIM Compatible with Surface Dial off-screen interaction4
Sensors
Accelerometer Gyroscope Magnetometer Ambient light sensor
Power supply
60W power supply with additional 5W USB A charging Port
In the box
Surface Pro X Power supply SIM card access tool Quick Start Guide Safety and warranty documents
Surface Pen4
4,096 levels of pressure Tilt sensing Best-in-class latency
0.1mm precision
Warranty8
1-year limited hardware warranty
Best-in-class support from Microsoft Store
Microsoft Store Promise for Surface: 60-day return policy
90 days of free technical phone support Free virtual workshops and training Surface price promise
Contact Information
For more information, press only:
Rapid Response Team, WE Communications, (425) 638-7777, rrt@we-worldwide.com
For more product information and images:
Visit the Surface Newsroom at https://news.microsoft.com/presskits/surface/.
For more information about Surface:
Visit Surface at http://www.microsoft.com/surface.
1
Service availability and performance subject to service provider’s network. Contact your service provider for details,
compatibility, pricing, SIM card, and activation. See all specs and frequencies at surface.com.
2
Available colors may vary by market.
3
Up to 15 hours of battery life based on typical Surface device usage. Testing conducted by Microsoft in September 2020
(Surface Pro X with Microsoft SQ® 1 and Surface Pro X with Microsoft SQ® 2) using preproduction software and preproduction configurations of Surface Pro X. Testing consisted of full battery discharge with a mixture of active use and modern standby. The active use portion consists of (1) a web browsing test accessing 8 popular websites over multiple open tabs, (2) a productivity test utilizing Microsoft Word, PowerPoint, Excel and Outlook, and (3) a portion of time with the device in use with idle applications. Tested with Windows Version 10.0.19041.1(20H1) and Edge version 85.0.564.51. All settings were default except screen brightness was set to 150nits with Auto-Brightness disabled. Wi-Fi was connected to a network. Battery life varies significantly with settings, usage and other factors.
4
Some software, apps, and accessories sold separately. App availability and compatibility may vary.
5
At this time, Surface Pro X will not install 64-bit applications that have not been ported to ARM64, some games and CAD
software, and some third-party drivers or anti-virus software. New 64-bit apps are coming to ARM 64 all the time, read here for more information on Surface Pro X application compatibility
6
Weight not including Surface Pro X Keyboard or Surface Pro X Signature Keyboard.
7
Hard drive is not user removable. Hard drive is only removable by skilled technician following Microsoft provided instructions.
8
Microsoft’s Limited Warranty is in addition to your consumer law rights.
