Microsoft RX-44 User Manual
Internet Tablet OS 2008 edition
User Guide
Nokia N800 Internet Tablet
Nokia N810 Internet Tablet
Issue 1 EN
© 2007 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Nseries, N800 and N810 are trademarks or
registered trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia
Corporation. Other product and company names mentioned herein may be
trademarks or tradenames of their respective owners.
Reproduction, transfer, distribution, or storage of part or all of the contents in this
document in any form without the prior written permission of Nokia is prohibited.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for
personal and noncommercial use in connection with information which has been
encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged
in a personal and noncommercial activity and (ii) for use in connection with
MPEG-4 video provided by a licensed video provider. No license is granted or shall
be implied for any other use. Additional information, including that related to
promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC.
See http://www.mpegla.com.
Nokia operates a policy of ongoing development. Nokia reserves the right to make
changes and improvements to any of the products described in this document
without prior notice.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO
CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR
ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL
OR INDIRECT DAMAGES HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED
BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN
RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT.
NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY
TIME WITHOUT PRIOR NOTICE.
The availability of particular products and applications and services for these
products may vary by region. Please check with your Nokia dealer for details, and
availability of language options.
Export controls
This device may contain commodities, technology or software subject to export
laws and regulations from the US and other countries. Diversion contrary to law is
prohibited.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a
telephone in close proximity to receiving equipment). The FCC or Industry Canada
can require you to stop using your telephone if such interference cannot be
eliminated. If you require assistance, contact your local service facility. This device
complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause
undesired operation. Any changes or modifications not expressly approved by Nokia
could void the user's authority to operate this equipment.
Issue 1 EN
Contents
For your safety...........................................5
Your device.................................................7
Touch screen...........................................................................7
Task navigator.................................................................8
Application title area....................................................8
Status indicator area....................................................8
Minimize and close buttons .......................................9
Application area...........................................................10
Toolbar ............................................................................10
Home view.............................................................................10
Device control.......................................................................10
Text input methods.............................................................11
Integrated keyboard....................................................11
Full-screen finger keyboard......................................12
On-screen keyboard....................................................12
Handwriting recognition ...........................................13
Text input settings.......................................................13
Volume control.....................................................................13
Device lock ............................................................................14
Change lock code.........................................................14
Lock touch screen and keys......................................14
Memory management........................................................15
Memory cards ...............................................................15
Back up and restore data ..........................................16
Help .........................................................................................17
Search for information......................................................18
Internet connections ...............................19
Connectivity settings .........................................................19
WLAN connection...............................................................19
Mobile phone connection.................................................21
Bluetooth wireless technology................................ 21
Select a phone..............................................................22
Manually create connection ....................................23
Disable wireless connections...........................................24
Browse the Web.......................................25
Open and browse Web pages ..........................................25
Manage bookmarks ............................................................26
Internet communication .........................27
Accounts................................................................................27
Presence.................................................................................28
Contacts.................................................................................29
Instant messaging...............................................................29
Internet call ..........................................................................30
E-mail.....................................................................................31
Create an e-mail account.........................................31
Retrieve and read e-mail messages .......................32
Create and send e-mail messages..........................33
Define basic e-mail settings.....................................33
Updating page ......................................................33
Composing page...................................................33
Clean-up page.......................................................34
Define advanced settings..........................................34
Incoming page ......................................................34
Outgoing page ......................................................35
Security page.........................................................35
Inbox folder...................................................................35
Outbox folder................................................................35
Sent folder.....................................................................36
Drafts folder..................................................................36
Media applications ..................................37
Media player.........................................................................37
Media sources...............................................................37
Internet radio................................................................37
File formats ...................................................................38
UPnP media servers.....................................................39
RSS feed reader....................................................................39
Images ....................................................................................40
Positioning................................................41
GPS receiver..........................................................................41
About satellite signals .......................................................42
Map application...................................................................42
Browse maps.................................................................42
Select and download maps.......................................43
Find locations ...............................................................43
Favorites.........................................................................44
Points of interest .........................................................44
Extra services................................................................44
Settings ....................................................46
Application manager.......................................................... 46
Connection manager..........................................................46
Control panel........................................................................46
Restore original settings ...........................................47
Clear device data.........................................................47
Install connection settings.......................................47
Utilities .....................................................48
Calculator..............................................................................48
Clock .......................................................................................48
File manager.........................................................................48
Notes ...................................................................................... 48
PDF reader.............................................................................48
Sketch.....................................................................................48
PC connectivity........................................49
Software update.................................................................. 49
Battery information ................................50
Charging and discharging.................................................50
Nokia battery authentication guidelines .....................50
Care and maintenance ............................52
Additional safety information................53
Open source software notice .................54
For your safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY Do not switch the device
on when wireless device use is prohibited or
when it may cause interference or danger.
ROAD SAFETY COMES FIRST Obey all local
laws. Always keep your hands free to operate
the vehicle while driving. Your first
consideration while driving should be road
safety.
INTERFERENCE All wireless devices may be
susceptible to interference, which could affect
performance.
SWITCH OFF IN HOSPITALS Follow any
restrictions. Switch the device off near medical
equipment.
SWITCH OFF IN AIRCRAFT Follow any
restrictions. Wireless devices can cause
interference in aircraft.
SWITCH OFF WHEN REFUELING Do not use
the device at a refuelling point. Do not use near
fuel or chemicals.
SWITCH OFF NEAR BLASTING Follow any
restrictions. Do not use the device where
blasting is in progress.
USE SENSIBLY Use only in the normal position
as explained in the product documentation.
QUALIFIED SERVICE Only qualified personnel
may repair this product.
ENHANCEMENTS AND BATTERIES Use only
approved enhancements and batteries. Do not
connect incompatible products.
WATER-RESISTANCE Your device is not
water-resistant. Keep it dry.
BACK-UP COPIES Remember to make
back-up copies or keep a written record of all
important information stored in your device.
5
CONNECTING TO OTHER DEVICES When
connecting to any other device, read its user
guide for detailed safety instructions. Do not
connect incompatible products.
Network services
Contact your service provider for additional instructions
for the use of network services and information on what
charges will apply. Some networks may have limitations
that affect how you can use network services.
Your service provider may have requested that certain
features be disabled or not activated in your device. Your
device may also have a special configuration.
Memory
The following features in this device may share memory:
bookmarks; image, audio, and video files; notes, sketch,
and other files; contacts; e-mail messages; and
applications. Use of one or more of these features may
reduce the memory available for the remaining features
sharing memory. Your device may display a message that
the memory is full when you try to use a shared memory
feature. In this case, delete some of the information or
entries stored in the shared memory features before
continuing.
For more information, see ‘Memory management’, p. 15.
6
Your device
Your Nokia Internet tablet provides easy broadband access
to the Internet through a wireless network connection
(WLAN/Wi-Fi) or Bluetooth connection with compatible
mobile phones. Its wide screen and portable size make it
optimal for enjoying the Web and Internet
communications away from your laptop or desktop.
Your compatible WLAN/Wi-Fi access point must be
compliant with the IEEE 802.11b or 802.11g standard.
Read this user guide carefully before using your device.
Read also the get started guide provided with the device
and the user guide of your compatible phone, which
provides important safety and maintenance information.
The availability of some applications, configurations, and
settings may vary according to the software version or
your country and sales region.
Touch screen
Your device
The touch screen consists of the task navigator (1), the
application title area (2), the status indicator area (3), the
minimize and close buttons (4), the application area (5),
the toolbar (6), and the application switcher (7).
7
Task navigator
The task navigator (1) includes icons that you can tap to
open new applications and switch between running
applications.
Your device
To select an option in a menu, tap it. To close the menu, tap
another area of the screen.
The task navigator contains the following items by default.
To change the items, tap , and select Settings >
Control panel. In Control panel, select Panels. For more
information, see the device help.
First item: Web browser—Tap to access Internet
functions such as new browser windows and bookmarks.
Second item: Contacts—Tap to view your contacts,
access your e-mail, make Internet calls, and send chat
messages.
Third item: Application menu—Tap for access to all
installed applications. To change the structure of the
menu, select Settings > Control panel. In Control panel,
select Panels.
Application switcher—The application switcher (7)
contains the icons of currently open applications. The icons
of the three most recently launched applications are
shown on the application switcher. If several instances of
an application are open (for example, multiple Web
browser windows), the group has one application icon. To
see all running applications, tap .
To change to an application, tap the respective icon in the
application switcher. If you hold the stylus down on an
icon, a tool tip is shown.
When you receive new e-mail or chat messages,
authorization requests and responses, or group chat
invitations, the icons on the application switcher blink to
indicate these events.
Leaving applications running in the background increases
the demand on battery power and reduces the battery life.
Application title area
The application title area (2) displays the name of the
active application and the open file. To open the
application menu, tap , or press the menu key.
Status indicator area
Tap the icons in the status indicator area to get more
information or perform tasks related to a specific function.
To change the icons in the status indicator area, tap ,
and select Settings > Control panel. In Control panel,
select Panels > Status bar.
The status indicator area (3) may contain the following
icons:
8
indicates that you have set an alarm in Clock.
indicates that the Internet tablet is connected to
another device through a USB cable.
The presence icon indicates your presence status and
allows you to adjust the presence settings. The icon is
visible only after you have created an account for Internet
call and instant messaging services. indicates that you
are online; that you are away; that you are
invisible; or that you are offline.
indicates the level of display brightness and allows you
to adjust the display settings.
indicates the volume level and allows you to adjust
the master volume and other sound settings. The more bars
the icon contains, the higher the volume. When the sounds
are muted, the icon is . When there is an active
connection between your device and an external Bluetooth
headset, is displayed and you cannot control the master
volume of your Internet tablet through the status icon.
Disconnect the Bluetooth headset to regain control of the
master volume.
The Internet connection icon indicates the status and type
of the Internet connection and allows you to open and
close an Internet connection, and adjust connectivity
settings. indicates that a WLAN connection is active;
that an ad hoc WLAN connection is active; that a
packet data connection (for example, GPRS) is active;
that a data call connection (for example, GSM data call) is
active; that there is no Internet connection; or
that the device is in the offline mode where no
connections are allowed.
indicates how much charge is left in the battery. The
more bars the icon contains, the more charge is left. To
view the estimated battery time, tap the icon.
indicates that a Bluetooth connection to an external
device is active, and that the Bluetooth feature is
switched on, but there is no active connection at the
moment.
The GPS icon is visible only on Nokia N810 Internet Tablet
products that have an internal GPS receiver. The GPS icon
indicates the use of GPS location data by applications and
allows you to configure GPS location settings.
The GPS icon is visible only when the internal GPS receiver
is switched on. indicates that the GPS receiver has
found satellite signals and your location is known; ,
that the GPS receiver has not found satellite signals and
your location is unknown; or , that the GPS receiver is
trying to find satellite signals and your location is being
searched.
Minimize and close buttons
Every application has the minimize and close buttons (4).
Your device
9
If you tap , the current application is hidden and the
underlying application is shown. To bring the minimized
application back to the top, tap its icon in the application
switcher.
If you tap , the current application or application
Your device
window closes. To close an application, you can also select
Close from the application menu, press the escape key for
a second, or tap the close button in the application
switcher menu.
Application area
When you open an application from the task navigator, the
application is displayed in the application area (5). If there
are currently no open applications, the device home view
is displayed.
Toolbar
The toolbar (6) contains the command buttons of the
active application.
Home view
When you switch on the device, the home view is
displayed. The home view offers you quick and easy access
to such product features as clock, Internet radio, Internet
search, RSS feed reader, speed contacts, Web shortcut,
tutorial and promotion applets.
For more information on the available applets, see the
device help.
To show available applets on the home view, select >
Select applets... and the desired applets from the list.
To rearrange the applets in the home view, drag them with
the stylus to the desired new positions. You can also resize
some applets by dragging from the handle on the applet.
To access context-sensitive menu for an applet, hold the
stylus down on the desired applet. Depending on the
applet, you can define applet settings or close the applet
using the context-sensitive menu commands.
To set the background image for the home view, select
> Set background image....
To modify the look and feel of your device, select >
Set theme....
To calibrate the touch screen, select >
Calibrate screen, and follow the instructions on the
screen.
Device control
You can control the device in several different ways: tap
the screen with the stylus or fingers; or press the scroll key
10
and other hardware keys on the device. For more
information on touch screen and hardware key interaction,
see the device help named after your product, for example,
‘Nokia N800 Internet Tablet’.
Text input methods
You can enter letters, numbers, and special characters in
several different ways. The virtual keyboards allow you to
tap characters with the stylus or your fingers. Handwriting
recognition allows you to write characters directly onto
the screen using the stylus as a pen.
You can also pair an external hardware keyboard with your
Internet tablet using Bluetooth technology; or use the
integrated keyboard on some Nokia Internet tablet
products.
To be able to enter text with an on-screen keyboard,
full-screen finger keyboard, or handwriting recognition
method, you must check that these features have been
activated.
Depending on the product model, the procedure for
defining text input settings can vary:
Nokia N800 Internet Tablet—Tap , and select
Settings > Control panel. In Control panel, select
Text input settings > General.
Nokia N810 Internet Tablet—Tap , and select
Settings > Control panel. In Control panel, select
Text input settings > On-screen.
Once you have activated the text input methods, tap any
text field. The text input area appears on the touch screen
and displays one of the keyboards or the handwriting
recognition area, depending on the previously used text
input method.
Your device can complete words based on the built-in
dictionary for the selected text input language. The device
also learns new words from your input.
Integrated keyboard
Some Nokia Internet tablet products may have an
integrated keyboard. When the integrated keyboard is in
use, the on-screen text input methods are disabled.
To enter text, press the keys on the keyboard. To put the
caps lock on, press the shift key twice.
To enter numbers, additional characters and common
symbols, press [Fn] and the desired character key. To lock
the [Fn] key, press it twice.
To enter accented letters, hold down [Chr], and press a
letter key repeatedly until the desired accented character
appears. To preview all special characters available, press
[Chr] briefly.
Your device
11
The integrated keyboard allows you to use global keyboard
shortcuts, as well as shortcuts for application specific
tasks. For example, to copy selected content, press
[Ctrl]+[C]; and to close the currently open application,
press [Ctrl]+[Q]. For more shortcuts, see the device help
for text input methods and integrated keyboard.
Your device
On-screen keyboard
Full-screen finger keyboard
To begin text input with the finger keyboard, tap the text
input field with your fingers. The finger keyboard opens in
the full screen mode.
When using the finger keyboard, use only clean hands and
regularly clean the touch screen by wiping the screen
gently with a dry, soft cloth.
The finger keyboard displays buttons and functions similar
to the other text input methods; however, not all of the
special characters are available.
To close the finger keyboard, tap in the upper right
corner of the keyboard.
12
1 —Adds a tabulator space or moves the cursor to the
next available text input field.
2 [Caps]—Locks the uppercase characters of the
keyboard. In the handwriting recognition mode,
switches between the normal and special character
recognition modes.
3 —Allows you to enter an uppercase character in the
on-screen keyboard mode when you write in lowercase.
When you tap this key in the handwriting recognition
mode, the last lowercase character switches to
uppercase, and vice versa.
4 —Opens the text input menu, which includes
commands such as Copy, Cut, and Paste. You can also
access the text input settings from the text input menu.
5 On-screen keyboard.
6 Space bar—Inserts a space. This area also shows word
completion.
7 Numeric keyboard—When you press the shift key, the
most common special characters are displayed in this
area.
8 —Deletes the character to the left of the cursor.
9 —Moves the cursor to the next row or text input
field. Additional functions are based on the current
context (for example, in the Web address field of the
Web browser, it acts as a go button).
10 —Opens a view, in which you can select from
commonly used special characters, symbols, and
language character accents.
11 —Closes the on-screen keyboard and handwriting
recognition input area.
You can draw the following handwriting gestures on top of
the on-screen keyboard:
1 for a backspace
2 for a space
3 to switch a letter
between uppercase
and lowercase
4 to add a line break
Handwriting recognition
You can use the stylus as a pen to write text. Write legible,
upright characters on the text input area, and leave a small
horizontal gap between each character. Do not use cursive
writing.
To write common characters and numbers (default mode),
write words as you normally write them. To write special
characters, tap [Abc1] in the left pane of the input area,
and write the characters as you normally write them.
To insert new characters in and after words, draw them in
the intended positions.
To teach the device your handwriting style, tap on the
on-screen keyboard, and select Tools > Teach.
You can draw the following handwriting gestures on the
handwriting recognition area:
1 for a backspace
2 for a space
Text input settings
To define the text input settings, tap , and select
Settings > Control panel. In Control panel, select
Text input settings. For more information, see the device
help.
Volume control
To adjust the master volu me of y our device, tap on th e
status indicator area. To set the master volume, drag the
Your device
13
volume slider with the stylus, or tap [+] or [-]. The master
volume overrides all other volume settings in the device.
Warning: Do not hold the device near your
ear when the loudspeaker is in use, because
Your device
the volume may be extremely loud.
Device lock
To prevent unauthorized use of your device, change the
lock code, and set the device to automatically lock after a
certain time-out period.
To lock the device, briefly press the power key, select
Lock device > OK. If you have not set the lock code, you
are asked to do so. To unlock the device, enter the lock
code, and select OK.
To edit the device lock settings, tap , and select
Settings > Control panel. In Control panel, select
Device lock.
To set the time-out period, select Autolock period and the
desired time.
Change lock code
To change the lock code, do the following:
1. Tap , and select Settings > Control panel.
2. In Control panel, select Device lock >
Change lock code.
3. Enter the current lock code, and select OK. The default
code is 12345.
4. Enter the new code, and select OK.
5. Enter the new code again, and select OK.
If you select Cancel in any of these dialogs, the device
lock code is not changed.
Keep the new code secret and in a safe place separate
from your device.
Note: If you lose the device lock code, you
must take the device to a Nokia authorized
service facility. To unlock the device, the
software must be reloaded, and all data you
have saved in the device may be lost.
Lock touch screen and keys
The touch screen and key lock prevents accidental
operation of the device when it is switched on. When the
touch screen and keys are locked, the device plays no key
tones and accepts no keypresses except for unlocking the
touch screen and keys.
Depending on the product model, the procedure for locking
and unlocking the touch screen and keys can vary:
14
Nokia N800 Internet Tablet—To lock the touch screen
and keys, briefly press , and select
Lock touch screen and keys > OK. To unlock the touch
screen and keys, press and .
Nokia N810 Internet Tablet—To lock the touch screen
and keys, push to the left. To unlock the touch screen
and keys, push to the left again.
Memory management
To view current storage memory consumption, tap ,
and select Settings > Control panel. In Control panel,
select Memory > Storage to display storage memory
information of the device and memory cards. To view more
detailed information about the storage memory
consumption, select Details.
To use a memory card as additional virtual memory for
running applications, do the following:
1. Tap , and select Settings > Control panel.
2. In Control panel, select Memory.
3. In Memory, select Virtual > Extend virtual memory,
and the desired size for the additional memory.
Additional virtual memory is always tied to the internal
memory card of your device.
Heavy usage of the extended virtual memory may affect
the durability of the memory card.
Important: Do not remove the memory card in
the middle of an operation when the card is
being accessed. Removing the card in the middle
of an operation may damage the memory card as
well as the device, and data stored on the card
may be corrupted.
To free memory, delete data in the file manager or other
applications. To find and delete files of a certain size, use
the search application.
Memory cards
Depending on the product model, the amount of available
memory card slots and the type of compatible memory
cards can vary:
Nokia N800 Internet Tablet—Your device has two
memory card slots. There is an internal slot under the back
cover and another slot under the memory card cover on the
front corner of the device.
The supported memory card formats are as follows:
• MultiMediaCard (MMC), (full size)
• Reduced Size MMC (with adapter)
• SD card (full size)
• miniSD card (with adapter)
• microSD card (with adapter)
Your device
15
Nokia N810 Internet Tablet—Your device has an external
memory card slot under the desk stand on the front right
corner of the device. Your device also includes a nonremovable internal memory card. You can view the content
of the internal memory card in Utilities > File manager.
Your device
The supported memory card formats are as follows:
• miniSD card
• microSD card (with adapter)
You can insert and remove a memory card when the
Internet tablet is switched on (hot swap feature), if the
memory card is not being used by an application.
Nokia Internet tablets do not support the write protection
feature of SD cards.
Use only compatible MultiMediaCards (MMC), Reduced
Size MultiMediaCards, SD cards, microSD cards, or miniSD
cards approved by Nokia for use with this device. Nokia
uses approved industry standards for memory cards, but
some brands may not be fully compatible with this device.
Incompatible cards may damage the card and the device
and corrupt data stored on the card.
The size limit is 8 GB. You can only use FAT 16/32
formatted compatible memory cards with Nokia Internet
tablets.
To view and manage the contents of a memory card, tap
, select Utilities > File manager and the desired
memory card from the folder list.
To rename a memory card in file manager, select >
File > Rename....
To format a memory card in file manager, select >
Tools > Format memory card.... All data is permanently
deleted from the memory card.
Back up and restore data
You can back up data to a compatible external or internal
memory card and restore it, if necessary. The backup
appears as a folder on the memory card. You can also
secure the backup with a password.
To back up data, do the following:
1. Tap , and select Settings > Backup/Restore >
New backup.
2. In New backup, change the name of the backup and
define the desired location of the backup.
3. In Select data for backup, select data types you want
to back up.
To protect the backup with a password, select
Password protect > OK, enter twice the password you
want to use, and select OK.
16
Note that the following information, for example, is not
backed up:
• contents of the non-removable internal memory card
on Nokia N810 Internet Tablet
• theme settings, when you restore backups from
previous product versions
• Bluetooth connectivity settings
• browser settings
• installed applications
However, you can make a backup of a list of applications
you have installed on your device. During the restore
process, your device tries to get the actual application files
from the Internet and reinstall them.
To restore data, do the following:
1. Tap , and select Settings > Backup/Restore. Select
the desired backup and Restore.
2. In Select data to restore, select data types you want
to restore.
If you have protected the backup with a password,
Password needed is displayed. Enter the password, and
select OK.
Important: To ensure that the e-mail application
works properly, always back up settings and
e-mail messages. Restore the backup when no
settings or e-mail messages are present in the
application, for example, directly after updating
the software on your device.
Help
The help function provides additional information on key
features, applications, and dialogs of the device. To access
help from the task navigator, tap , and select
My selection > Help. To access help from an application,
tap , and select the help command from the menu
(usually under Tools).
To browse help topics, tap the following:
or to see other help topics if you have recently
viewed several help topics
to see a list of recently viewed help topics
to search for the text that you have entered in the
search field.
To access help related to the contents of a dialog (contextsensitive help), tap the [?] button on the dialog.
Your device
17
Loading...
