Overview

Model number: Nokia Nxxx-1.

Hereinafter referred to as Nokia Nxxx.

Nokia Nxxx provides easy broadband access to the internet through a wireless LAN (WLAN)/Wi-Fi or Bluetooth connection with compatible mobile phones. Its wide screen and portable size make it optimal for enjoying the web and internet communications away from your laptop or desktop.

Your compatible WLAN access point must be compliant with the IEEE 802.11b or 802.11g standard.

Read this user guide carefully before using your device. Read also the quick start guide provided with the device and the user guide of your compatible phone, which provides important safety and maintenance information.

The availability of some applications, configurations, and settings may vary according to the software version or your country and sales region.

Nokia support on the web

Check www.nokia.com/support or your local Nokia web site for the latest version of the guide, additional information, downloads, and services related to your Nokia product.

Check also www.nokia.com/nxxx to explore the device online features.

Touch screen

The touch screen consists of the task navigator (1), the application title area (2), the status indicator area (3), the minimize and close buttons (4), the application area (5), the toolbar (6), and the application switcher (7).

Overview

Task navigator

The task navigator (1) includes icons that you can tap to open new applications and switch between running applications.

To select an option in a menu, tap it. Alternatively, scroll to the desired option in a menu using the and hardware keys and press to open it. To close the menu, press , or tap another area of the screen.

The task navigator contains the following items by default. To change the items, tap and select Tools >

Control panel > Navigation. For more information, see the

device help.

First item: web browser—Tap to access internet functions such as Open new browser window and

Manage bookmarks.

Second item: contacts—Tap to access functions such as View contacts, View inbox, New e-mail message,

New Internet call, New chat, and Set presence. When you

receive new e-mail or chat messages, authorization requests and responses, or group chat invitations, the icon is highlighted and the menu is updated. The information of these events is displayed at the bottom of the menu.

Applications—Tap for access to all installed applications. To change the structure of the menu, select

Tools > Control panel > Navigation.

Application switcher—The application switcher (7) contains icons of currently open applications. The icons of the four most recently launched applications are shown on the application switcher. To see all running applications, tap . If several instances of an application are open (for example, multiple web browser windows), the group has one application icon.

To change to an application, tap the icon of the application in the application switcher. If you hold the stylus down on an icon, a tool tip is shown.

Leaving applications running in the background increases the demand on battery power and reduces the battery life.

Application title area

The application title area (2) displays the name of the active application and the open file. To open the application menu, tap the title, or press .

Status indicator area

Tap the icons in the status indicator area to get more information or perform tasks related to a specific function. The status indicator area (3) may contain the following icons:

Overview

indicates how much charge is left in the battery. The more bars the icon contains, the more charge is left. To view the estimated battery time left, tap the icon.

The internet connection icon indicates the status and type of the internet connection and allows you to open and close an internet connection. indicates that a WLAN connection is active, that a packet data connection (for example, GPRS) is active, that a data call connection (for example, GSM data call) is active, that there is no internet connection, or that the device is in the offline mode where no connections are allowed. indicates that a WLAN connection is active, but the device did not receive an IP address from the network. Your connection to the internet is limited.

indicates the volume level and allows you to adjust the master volume and other sound settings. The more bars the icon contains, the higher the volume. When the sounds are muted, the icon is .

indicates the level of display brightness and allows you

to adjust the display settings.

The presence icon indicates your presence status and allows you to adjust the presence settings. The icon is visible only after you have created an account for internet call and instant messaging service. indicates that you are online, that you are away, that you are invisible, or that you are offline.

indicates that the device is connected to a PC through

a USB cable.

indicates that you have set an alarm in the Clock

application.

The status indicator area makes it possible to display multiple status icons simultaneously. If you have, for example, installed your own status indicators and want to display more than seven items at a time, they will be shown on several lines. When there are additional lines, they can be accessed by tapping the arrow icon.

To change the icons in the status indicator area, tap and select Tools > Control panel > Navigation > Status bar.

If you replace the contact icon in the task navigator with a different task navigator icon, you receive information about new chat messages, authorization requests and responses, or group chat invitations to .

Minimize and close buttons

Every application has the minimize and close buttons (4).

If you tap , the current application is hidden and the underlying application is shown. To bring the minimized application back to the top, tap its icon in the application switcher.

If you tap , the current application or application window closes. To close an application, you can also

Overview

select Close from the application menu, press for a second, or tap the close button in the application switcher menu.

Application area

Wh en you open a n a pplica ti on from th e task na vi gator, th e application is displayed in the application area (5). If there are currently no open applications, the applets you selected in the Home menu are displayed in the application area.

Toolbar

The toolbar (6) contains the command buttons of the active application.

Home view

When you switch on the device, the home view is displayed. The home view contains various applets (small utilities) that you can open, close, and rearrange. You can also install new applets using the Application manager.

The following applets are available in your device:

Clock—Displays the time in digital or analog format. The date format depends on the regional settings. To set the

time and date, tap the clock, and select Clock > Tools >

Date and time settings....

Internet radio—Select an internet radio channel from the list. The content of the list comes from the Media player application, where you can add and remove radio channels.

RSS feed reader—Shows the number of unread news articles and lists the latest headlines when you subscribe to a news service. The subscription is made in the RSS feed reader application. To view an article, tap its headline. To refresh the article list from the web, tap . To stop the refresh, tap .

Speed contacts—Allows you to quickly get in contact with a selected group of people. To select the contacts to be displayed on the applet, select Home > Applet settings >

Speed contacts.

Web shortcut—To set the web page that opens when you tap the shortcut image, select Home > Applet settings >

Web shortcut. The functions of this feature may vary

depending on the product package.

Internet search—Enables you to look for a requested piece of information. Enter the search string in the search field and tap .

Overview

To set the background image for the home view, select

Home > Tools > Set background image.... The background

may display a solid color, an image, or both.

To personalize the look and feel of your device, select

Home > Tools > Themes....

To add or remove applets from the application area, select

Home > Select applets..., and mark or unmark the desired

applet.

To arrange applets in the home view, select Home >

Edit layout. In the layout mode you can rearrange the

applets by dragging them. You can also resize some applets in the layout mode. To accept the layout, tap . To discard the changes you made, tap .

Device control

You can control the device in two ways: tap the screen with the stylus or press the hardware keys on the device.

Stylus

Using the stylus enables different functions depending on the context. The stylus can be used in the following ways:

• Single tap—To activate controls and other interactive

interface components, tap them once with the stylus. A single tap may open a list, activate a button in a dialog

or a link on a web page, select a check box, and activate a text input method from a text field.

• Highlight and activate—To highlight an item, tap it once with the stylus. To activate or open the item, tap it again.

• Multiple selection—To select consecutive items, place the stylus on a non-highlighted item, and drag the stylus over the items. To add more items to the selection, place the stylus on a non-highlighted item and drag the stylus over the items. To remove a selection, tap a single item.

• Drag and drop—To drag an item, hold the stylus down on a highlighted item, drag the item to its new location, and release the stylus. To drag and drop multiple items, perform a multiple selection, and start the drag from the highlighted item.

• Tap and hold—To activate a context-sensitive menu, briefly hold the stylus down on an item.

Calibrate the touch screen

If the touch screen responds inaccurately, you may need to calibrate it. Select Home > Tools > Screen calibration. If the touch screen does not respond at all, you can also access this function by pressing in the home view and using and to navigate in the menu. Follow the instructions on the screen.

Overview

A small number of missing, discolored, or bright dots may appear on the screen. This is a characteristic of this type of display. Some displays may contain pixels or dots that remain on or off. This is normal, not a fault.

Hardware keys

A keypress refers to the press and release of a key. Some actions depend on the length of the keypress.

Power key—A short keypress opens the

Device mode dialog. A long keypress turns the device on or

off.

, Zoom keys—A short keypress changes the zoom level of the current view, and adjusts the volume in audio applications.

Full-screen key—A short keypress switches

between full screen and normal screen modes.

Scroll key—A short keypress moves the focus from one item to another in the respective direction. A long keypress in the web browser scrolls the content of the active page or frame. Press the center of the scroll key to activate the highlighted item, and to accept confirmation notes.

Escape key—A short keypress closes menus and dialogs and rejects confirmation notes. In the web browser this key acts as a back button. A long keypress closes the topmost dialog or application.

Menu key—A short keypress opens and closes the

application menu.

Swap key—A short keypress activates the application switcher menu. A long keypress displays the home view of the device.

Text input methods

You can enter letters, numbers, and special characters in two ways. The keyboards allow you to tap characters with the stylus or your fingers. Handwriting recognition allows you to write characters directly onto the screen using the stylus as a pen.

To begin text input, tap any text field with the stylus or your fingers. The text input area appears on the touch screen and displays one of the keyboards or the handwriting recognition area, depending on the previously used text input method.

To switch between text input methods, tap on the keyboards or handwriting recognition view, and select

Input method and the desired option. Start writing.

Your device can complete words based on the built-in dictionary for the selected text input language. The device also learns new words from your input.

Overview

On-screen keyboard

• Tabulator key (1)—Adds a tabulator space or moves the cursor to the next available text input field.

• [Caps] (2)—Locks the uppercase characters of the keyboard. In the handwriting recognition mode, switches between the normal and special character recognition modes.

• Shift key (3)—Allows you to enter an uppercase character in the on-screen keyboard mode when you write in lowercase. When you tap this key in the handwriting recognition mode, the last lowercase character switches to uppercase, and vice versa.

• Input menu key (4)—Opens the text input menu, which includes commands such as Edit > Copy, Cut, and Paste. You can also access the text input settings from the text input menu.

• On-screen keyboard (5)

• Space bar (6)—Inserts a space. This area also shows word completion.

• Numeric keyboard (7)—When you press the shift key, the most common special characters are displayed in this area.

• Backspace key (8)—Deletes the character to the left of the cursor.

• Enter key (9)—Moves the cursor to the next row or text input field. Additional functions are based on the current context (for example, in the web address field of the web browser, it acts as a go button).

• Special character key (10)—Opens a view, in which you can select from commonly used special characters, symbols, and language character accents.

• Close (11)—Closes the on-screen keyboard and handwriting recognition input area.

To use handwriting gestures on top of the on-screen keyboard, do the following:

Draw gesture 1 for a backspace or gesture 2 for a space. Draw gesture 3 on a letter to switch between uppercase and lowercase letters or gesture 4 to add a line break.

Overview

Full-screen finger keyboard

To begin text input with the finger keyboard, tap the text input field with your fingers. The finger keyboard opens in the full screen mode.

The finger keyboard displays buttons and functions similar to the other text input methods; however, not all of the special characters are available.

To close the finger keyboard, tap in the upper right corner of the keyboard.

To change the finger keyboard settings, tap , and select

Tools >Control panel > Text input settings > Thumb board.

When using the finger keyboard, use only clean hands and regularly clean the touch screen by wiping the screen gently with a dry, soft cloth.

Handwriting recognition

You can use the stylus as a pen to write text. Write legible, upright characters on the text input area, and leave a small horizontal gap between each character. Do not use cursive writing.

To write common characters and numbers (default mode), write words as you normally write them.

To write special characters, tap [Abc1] in the left pane of the input area, and write the characters as you normally write them.

To in sert n ew c haracter s in and af ter words, dr aw them in the intended positions.

To teach the device your handwriting style, tap on the on-screen keyboard, and select Tools > Teach.

To use handwriting gestures on the handwriting recognition area, do the following:

Draw gesture 1 for a backspace or gesture 2 for a space.

Text input settings

To define the text input settings, tap , and select

Tools > Control panel > Text input settings. For more

information, see the device help.

Volume control

To adjust the master volume, tap to access the sound settings. To decrease or increase the volume, drag the

Overview

volume slider to the desired position. The master volume overrides all other volume settings in the device.

Warning: Listen to music at a moderate level. Continuous exposure to high volume may damage your hearing. Do not hold the device near your ear when the loudspeaker is in use, because the volume may be extremely loud.

Device lock

To prevent unauthorized use of your device, change the lock code, and set the device to automatically lock after a certain time-out period.

To lock the device, briefly press , select Lock device, and tap OK. To unlock the device, enter the lock code, and tap

OK.

To edit the device lock settings, tap , and select Tools >

Control panel > Device lock.

To set the time-out period, tap Autolock period, and select the desired time.

2. Enter the current lock code (the default code is

12345), and tap OK.

3. Enter the new code, and tap OK.

4. Enter the new code again, and tap OK.

If you tap Cancel in any of these dialogs, the device lock code is not changed.

Keep the new code secret and in a safe place separate from your device.

Note: If you lose the device lock code, you must take the device to a Nokia authorized service facility. To unlock the device, the software must be reloaded, and all data you have saved in the device may be lost.

Lock touch screen and keys

To lock the touch screen and keys, briefly press , and select Lock touch screen and keys > OK. To unlock the touch screen and keys, press and .

Overview

Change the lock code

To change the lock code, do the following:

1. Tap , and select Tools > Control panel > Device lock >

Change lock code.

Memory management

To view current user memory consumption, tap , and select Tools > Control panel > Memory.

To view the amount of free and used memory, select the

Storage page.

To use part of the memory card as additional virtual memory for running applications, open the Virtual page, and select Extend virtual memory. Additional virtual memory is always tied to the memory card that you are currently using in the internal memory card slot.

Heavy usage of the extended virtual memory may affect the durability of the memory card.

Important: Do not remove the memory card in the middle of an operation when the card is being accessed. Removing the card in the middle of an operation may damage the memory card as well as the device, and data stored on the card may be corrupted.

To free memory, delete data in File manager or other applications. To find and delete files of a certain size, use the Search application.

The applications display error messages when you try to move, copy, or save files, and when there is not enough memory on the device or the memory card.

Memory card

Your device has two memory card slots. There is an internal slot under the back cover and another slot under the

memory card cover on the front corner of the device. Both memory cards can be inserted and removed when the device is powered (hot swap feature).

The supported memory card formats are as follows:

• MultiMediaCard (MMC), (full size)

• Reduced Size MMC (with adapter)

• SD card (full size)

• miniSD card (with adapter)

• microSD card (with adapter)

This device does not support the write protection feature of SD cards.

Use only compatible MultiMediaCards (MMC), Reduced Size MultiMediaCards, SD cards, microSD cards, or miniSD cards approved by Nokia for use with this device. Nokia uses approved industry standards for memory cards, but some brands may not be fully compatible with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.

The size limit is 2 GB. You can only use FAT 16/32 formatted compatible memory cards with this device.

To view and manage the contents of the memory card, tap

, select File manager, and tap the memory card in the

folder list.

Overview

To rename a memory card, select File manager >

Memory card > Rename....

To format a memory card, select File manager >

Memory card > Format.... All data is permanently deleted

from the memory card.

Back up and restore data

You can back up data to a compatible memory card and restore it, if necessary. The backup appears as a folder on the memory card. You can also secure the backups with a password.

To back up data, do the following:

1. Tap , and select Tools > Backup/Restore >

New backup.

2. In the Backup selection dialog, change the name of the

backup; tap the name, and enter a new one. If both memory cards are installed, define the desired location of the backup using a choice list.

3. In the Data selection dialog, select whether you want to

back up all data or only the specified data types.

To protect the backup with a password, tap

Protect with password, enter twice the password you

want to use, and tap OK.

To restore data, do the following:

1. Tap , and select Tools > Backup/Restore.

2. Select the backup on the memory card that you want

to restore. Tap Restore.

If you have protected the backup with a password, the

Password needed dialog is displayed. Enter the

password, and tap OK.

To delete an unnecessary backup, select the backup and tap Delete.

Important: To ens ure th at the E-mail application works properly, always back up settings and email messages. Restore its backup when no settings or e-mail messages are present in the application, for example, directly after updating the software on your device.

The following information, for example, is not backed up:

• theme settings, when you restore backups from previous product versions,

• Bluetooth connectivity settings,

• installed applications, and

•browser settings.

Overview

+ 37 hidden pages
