830Lumia Nokia |
Quick |
|
Guide |
9263474 Issue 1.0 EN-US |
RM-985 |
||
|
|
|
|
|
|
|
|
|
|
|
|
Keys and parts
Important: For important info on the safe use of your device and battery, read “Safety” and “Product and safety info” at www.nokia.com/ support before you take your device into use. The same info is available in the in-device user guide. Select
Lumia Help+Tips.
1Micro-USB connector
2Earpiece
3Audio connector AHJ 3.5 mm
4Proximity/Light sensor
5Front camera
6Volume keys
7Power/Lock key
8Camera key
9Search key
10Start key
11Microphone
12Back key
13Antenna area
14NFC area
15Microphone
16Camera flash
17Camera lens
18Wireless charging area
19Speakerphone
Some of the accessories mentioned in this user guide, such as charger, headset, or data cable, may be sold separately.
Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the communication quality and may reduce battery life due to higher power level during operation.
Get started
Before you start using your phone, remove the back cover to insert the nano-SIM card (also known as the nano-UICC card).
Make sure the phone is switched off.
1. At the bottom of the phone, put the nail of your index finger in the small slot between the metal frame and the back cover.
Do not use any sharp tools, as they may damage the phone.
2. Press the middle of the back cover, bend the cover open, and remove it.
Insert the SIM and memory cards
If the battery is in, lift it out.
1.Slide the nano-SIM card into the SIM slot with the metal contact area down until you hear a click.
2.If you have a memory card, slide the card into the memory card slot until you hear a click.
Tip: For best performance, it is recommended that you use a fast 4–128GB memory card by a well-known manufacturer.
Use of incompatible SIM cards, or use of SIM card adapters, may damage the card or the device, and may corrupt data stored on the card.
Replace the battery and back cover
1.Line up the battery contacts, and put the battery in.
2.Press the top edge of the back cover against the top edge of your phone.
3.Snap the cover into place, locking all the latches around the edges of the cover.
To switch your phone on, press the power key.
Charge the battery
Plug a compatible charger into a wall outlet, and connect the micro-USB end to your phone. You can also charge your phone from a computer with a USB cable.
If the battery is completely discharged, it may take up to 20 minutes before the charging indicator is displayed.
