User’s Guide for the Nokia Wireless GPS Module (LD-1W)

Part number

Issue 1

LD1W_Ilmari_legal.fm Page 2 Thursday, October 7, 2004 9:50 AM

DECLARATION OF CONFORMITY We, NOKIA CORPORATION, declare under our sole responsibility that the

product LD-1W is in conformity with the provisions of the following Council Directive: 1999/5/EC. A copy of the Declaration of Conformity can be found from http://www.nokia.com/phones/declaration_of_conformity/.

contents in this document in any form without the prior written permission of Nokia is prohibited.

Nokia is a registered trademark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

Bluetooth is a registered trademark of Bluetooth SIG, Inc. Nokia operates a policy of continuous development. Nokia reserves the

right to make changes and improvements to any of the products described in this document without prior notice.

LD1W_Ilmari_legal.fm Page 3 Thursday, October 7, 2004 9:50 AM

Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused.

The contents of this document are provided "as is". Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice.

The availability of particular products may vary by region. Please check with the Nokia dealer nearest to you.

Part number/Issue 1

LD1W_Ilmari_legal.fm Page 4 Thursday, October 7, 2004 9:50 AM

Contents

For your safety ............................................................. 6

1.Introduction.............................................................. 8

Global Positioning System................................................................... 8

Bluetooth wireless technology......... ................................................ 11

Bluetooth passcode............................................................................. 11

External antenna.................................................................................. 11

2.Getting started....................................................... 12

Overview................................................................................................. 12

Batteries and chargers........................................................................ 14

Installing the battery.......................................................................... 15

Charging the battery........................................................................... 17

Pairing the GPS module with a compatible phone.................... 18

3.Using the GPS module........................................... 20

Power key functions............................................................................ 20

Carrying the GPS module................................................................... 21

Using the GPS module with several paired phones................... 22

Disconnecting and reconnecting the GPS module..................... 23

LD1W_Ilmari_legal.fm Page 5 Thursday, October 7, 2004 9:50 AM

Contents

Resetting the GPS module................................................................ 24

Troubleshooting................................................................................... 25

4.Battery information................................................ 26

Care and maintenance................................................ 29

LD1W_Ilmari_legal.fm Page 6 Thursday, October 7, 2004 9:50 AM

For your safety

Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this user’s guide.

ROAD SAFETY COMES FIRST

Remember that the safety of operating a motor vehicle in traffic requires the full attention of all motorists. Only use your Nokia Wireless GPS Module (LD-1W) if traffic conditions permit safe use and check if local laws/regulations restrict the use of mobile devices while driving.

When using the GPS module in a mobile environment place it so that it does not disrupt the normal operation of the vehicle. Make sure you fasten the GPS module properly to prevent accidental movement of it.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

LD1W_Ilmari_legal.fm Page 7 Thursday, October 7, 2004 9:50 AM

For your safety

BATTERIES AND CHARGERS

Use only approved batteries and chargers. Do not connect incompatible products.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read the relevant user’s guide for detailed safety instructions. Do not connect incompatible products.

QUALIFIED SERVICE

Only qualified personnel may repair this device.

LD1W_Ilmari_legal.fm Page 8 Thursday, October 7, 2004 9:50 AM

Introduction

1. Introduction

With the help of the Nokia Wireless GPS Module you can determine your current position and direction easily. The GPS module is a battery operated device that uses Bluetooth technology to communicate positioning information to compatible mobile phones, PCs, PDAs and other devices.

Read this user’s guide carefully before using the GPS module. Check also http://www.nokia.com/support or your local Nokia Web site for the latest version of this guide, additional information, downloads, and services related to your Nokia product.

■Global Positioning System

The Global Positioning System (GPS) is a worldwide radio navigation system that includes 24 satellites and their

LD1W_Ilmari_legal.fm Page 9 Thursday, October 7, 2004 9:50 AM

Introduction

ground stations that monitor the operation of the satellites.

A GPS terminal (such as the Nokia Wireless GPS Module) receives low-power radio signals from the satellites and measures the travel time of the signal. From the travel time, the GPS terminal can calculate its location to the accuracy of +/- 25 metres. In optimal conditions, the accuracy may be within a few metres.

The accuracy can be affected by poor satellite geometry. The more satellites the GPS module can "see", the better the accuracy. The internal antenna of the GPS module, which is located on the same side as the Nokia logo, should be facing upwards for proper functioning. Note also that some car windshields and windows may contain metal, for example, for heat reflection or defogging purposes. This may block or attenuate the satellite signal.

The availability and quality of GPS signals may also be affected by buildings and natural obstacles as well as weather conditions. Therefore, the GPS should not be

LD1W_Ilmari_legal.fm Page 10 Thursday, October 7, 2004 9:50 AM

Introduction

used for precise location measurement, and you should never rely solely on location data from the GPS module.

In addition, the GPS determines your direction on the basis of your movement. Therefore, the GPS cannot detect which way you are facing if you are not moving.

Note: The Global Positioning System is operated by the United States government, which is solely responsible for accuracy and maintenance of the system. The accuracy of location data can be affected by adjustments to GPS satellites made by the United States government and is subject to change with the United States Department of Defense civil GPS policy and the Federal Radionavigation Plan.

Warning! This GPS module does not support emergency location service (E911).
