Starsys

STARSYS

™

MOBILE WORKCENTERS

The Starsys™ Mobile WorkCenter group is a polymer­based, highly-adaptive system, that enhances
productivity and space effi ciency by empowering the
end user with the ability to easily reconfi gure and move
units to fi t your changing workfl ow demands.

Mobile WorkCenters create fl exible space. No matter
what you need — open, closed, short, tall, mobile or
stationary, preconfi gured workcenters — Starsys has the
solution for you.

With Starsys, you choose from an array of modular units
to fi t the space and work specifi cations. It’s that easy.
And that fl exible.

Benefi ts:

• Facilitates fast, effi cient product or
furniture installation.

• The ability to easily reconfi gure the WorkCenter room
layout as needs change.

• The ability to easily reconfi gure unit design.

• Durable, easy-to-clean, polymer enclosures
that won’t chip, peel, dent, or rust — ever.

• Rigid anodized aluminum and metal substructure,
combined with advanced polymers, provides a
robust and stable work environment for even the most
sensitive equipment.

• Advanced Security Options available — including
electronic locks, push button locks, as well as
mechanical keylocks.

*MICROBAN® antimicrobial product protection

helps keep surfaces “cleaner between cleanings”
by inhibiting the growth of mold, mildew, fungus,
and bacteria that cause odors and stains on the
shelf surface.

MICROBAN

trademarks of the Microban Products Company, Huntersville, NC.

®

and the MICROBAN® symbol are registered

™

System — Mobile WorkCenters

Single-wide

Mobile WorkCenter

with Overhead

Cat. No. SXSENT1

Double-wide Mobile
WorkCenter with
Laminate Countertop

Triple-wide

Mobile WorkCenter

with Kneewell,

Overhead Storage

and Stainless

Steel Top

Metro incorporates several elements in its product design to support a facility’s cleaning protocols:

• Microban® antimicrobial protection helps prevent the growth of stain and odor causing bacteria

on the product.

• Advanced polymer and other proprietary finishes provide corrosion resistance

• Smooth rounded corners to allow for easier cleaning

Look for the

“red check” symbol for this added protection.

46.02

To confi gure a Starsys unit to your exact specifi cations, please visit www.metroconfi gurator.com

InterMetro Industries Corporation

North Washington Street
Wilkes-Barre, PA 18705
www.metro.com

STARSYS™ SYSTEM — MOBILE WORKCENTERS

Specifi cations

Countertops

Starsys™ epoxy resin worksurfaces are generally 1" (25mm) thick. Unless otherwise specifi ed, worksurfaces are monolithic
and molded from a modifi ed epoxy resin, with a uniform mixture throughout the top forming a thermosetting material. Back or
side splashes are shipped separately and affi xed on site to epoxy top. Worksurfaces have a smooth, non-glare fi nish.

Phenolic countertops are 1" (25mm) thick with back and side splash options. The laboratory-grade tops are made of an epoxy
resin composite (thermoset resins with cellulose fi ber reinforcement), are non-porous, highly resistant to a wide variety of
aggressive chemicals, easy to clean, disinfect and maintain.

Laminate countertops are composed of a 1.125" (29mm) 45 lb. density particle board core with melamine backing and high­pressure laminate surfacing material, .045" nominal thickness.

®

Solid surface countertops are nominally 1" (25.4mm) thick with a .485" Corian
(Hi-Density Polyethylene) core.

Stainless steel countertops are 1.25" (32mm) thick with Type 304 series 18-gauge fabricated stainless steel with homopolymer
polypropylene cores. Available with backsplashes or “island style.”

Refer to Starsys chemical resistance report for a complete description of Starsys material specifi cations. A copy of the report
can be found at www.metro.com or by contacting your local Metro representative.

solid surface (matte fi nish) bonded to a .5" HDPE

Drawers

Standard Drawers

Inside Dimensions Weight
Height/Width/Length Capacity
Model No. Description (in.) (mm) (lbs.) (kg)

SXRS3 3" (76mm) 23/8x163/8x157/8 60x416x403 25 11.4
SXRS4.5 4.5" (114mm) 37/8x163/8x157/8 98x416x403 25 11.4
SXRS6 6" (152mm) 53/8x161/4x153/4 136x413x400 40 18.2
SXRS7.5 7.5" (191mm) 67/8x161/4x153/4 175x413x400 40 18.2
SXRS9 9" (230mm) 83/8x161/4x153/4 213x413x400 40 18.2
SXRS10.5 10.5" (267mm) 97/8x161/4x153/4 251x413x400 40 18.2
SXRS12 12" (305mm) 113/8x161/4x153/4 289x413x400 40 18.2

Heavy-Duty Drawers

Inside Dimensions Weight
Height/Width/Length Capacity
Model No. Description (in.) (mm) (lbs.) (kg)

Single-wide Drawers

SXRS3HD 3" (76mm) 21/4x163/8x193/16 57x416x487 150 68.0
SXRS6HD 6" (152mm) 51/4x163/8x193/16 133x416x487 150 68.0
SXRS9HD 9" (230mm) 81/4x163/8x193/16 209x416x487 150 68.0
SXRS12HD 12" (305mm)* 111/4x163/8x193/16 285x416x487 150 68.0

Double-wide Drawers

SXRD3HD 3" (76mm) 21/8x361/4x193/16 54x920x487 150 68.0
SXRD6HD 6" (152mm) 51/8x361/4x193/16 130x920x487 150 68.0
SXRD9HD 9" (230mm) 81/8x361/4x193/16 206x920x487 150 68.0
SXRD12HD 12" (305mm) 111/8x361/4x193/16 283x920x487 150 68.0

*Note: Single wide 12" (305mm) fi le drawers include hanging fi le accessory.

Drawer/Door Label Holders

Dimensions
Model No. Description Height/Length

SXRLABKIT Label Kits (10 Pieces Per Kit)

3

/4" X 11" (19 x 279mm)

Heavy-Duty Drawer

SXRLABKIT

Drawer Pulls (one required per drawer) To specify color for drawer pull, order following catalog numbers for each drawer:

Dark Taupe

SXRDP-TP

White

SXRDP-WH

Code Blue

SXRDP-CB

Red

SXRDP-RE

Orange

SXRDP-OR

Green

SXRDP-GR

Yellow

SXRDP-YL

Slate Blue

SXRDP-BL

Violet

SXRDP-VL

Pink

SXRDP-PK

Black

SXRDP-BK

Starsys Carts are built to exact customer specifi cations, therefore, they are non-cancelable, non-returnable.

STARSYS™ SYSTEM — MOBILE WORKCENTERS

Mobile WorkCenter Overhead Cabinets*

Cabinets include inner panels and mounting rails.

Height/Depth/Width
Overall Dimensions Inside Dimensions
Model No. Description (in.) (mm) (in.) (mm)

Single-wide Cabinets

SXRSOH24P 24" (610mm) 263/8x131/2x211/2 670x343x546 245/8x12x17 625x341x432
SXRSOH27P 27" (686mm) 293/8x131/2x211/2 746x343x546 275/8x12x17 702x341x432
SXRSOH30P 30" (760mm) 323/8x131/2x211/2 822x343x546 305/8x12x17 778x341x432
SXRSOH33P 33" (838mm) 353/8x131/2x211/2 898x343x546 335/8x12x17 854x341x432
SXRSOH36P 36" (914mm) 383/8x131/2x211/2 973x343x546 365/8x12x17 930x341x432

Double-wide Cabinets

SXRDOH24P 24" (610mm) 26
SXRDOH27P 27" (686mm) 293/8x131/2x413/8 746x343x1051 275/8x10x363/4 702x254x933
SXRDOH30P 30" (760mm) 323/8x131/2x413/8 822x343x1051 305/8x10x363/4 778x254x933
SXRDOH33P 33" (838mm) 353/8x131/2x413/8 898x343x1051 335/8x10x363/4 854x254x933
SXRDOH36P 36" (914mm) 383/8x131/2x413/8 973x343x1051 365/8x10x363/4 930x254x933

Shelves for Single-wide Cabinets†

SXRSOHWE Wire Shelf 1
SXRSOHPS Poly Shelf 11/2x12x18 38x305x457

Shelves for Double-wide Cabinets††

SXRDOHWE Wire Shelf 13/8x11x3611/16 35x279x932
SXRDOHPS Poly Shelf 11/2x12x375/8 38x305x956

† Load rating for Single-wide shelves, both wire and poly, is 60 lbs. (27kg).
†† Load rating for Double-wide shelves, both wire and poly, is 120 lbs. (54kg).

* Triple-wide overhead cabinets are only offered as part of Mobile WorkCenter offering. Contact your Metro representative for more information.

3

/8x131/2x413/8 670x343x1051 245/8x10x363/4 625x254x933

3

/8x11x1715/16 35x279x456

Model # SXRDENT2 with
SXRDOH27P Overhead,
(2) SXRDOHPS Shelves
and Clear Locking Doors

Overhead Accessories

Height/Depth/Width
Model No. Description (in.) (mm)

SXRSOHL Light for Single-wide Overhead Cabinets 1.50x5.82x19.75 38x148x502
SXRDOHL Light for Double-wide Overhead Cabinets 1.50x5.82x39.55 38x148x1005
SXRTOHL Light for Triple-wide Overhead Cabinets 1.50x5.82x59.35 38x148x1507
SXROHLT Overhead Light (No Valance) 1.32x4.63x14.25 34x118x362
SXROHFLR-49 Overhead Back Filler Strip (1 Pair)* 2.875x.125x49.75 73x3x1264

*One kit recommended for a single unit or for each end on a run of multiple units.

Drawer/Door Label Holders

Dimensions
Model No. Description Height/Length

SXRLABKIT Label Kits (10 Pieces Per Kit)

3

/4" X 11" (19 x 279mm)

SXRLABKIT

Tambour Door Overhead
(Also available on Mobile

WorkCenters)

Single-wide Overhead

Cabinet with Solid Door

Double-wide Overhead Cabinet

with Wire Shelves (2) and

Locking, Clear Doors

Double-wide Overhead

Cabinet with Polymer Shelves

and Locking, Clear Doors

Job ________________________________________________Job ________________________________________________

STARSYS™ SYSTEM —

46.02

MOBILE WORKCENTERS

Mobile WorkCenter Overhead Cabinet and Reagent Shelving Support

Model No. Description

Lateral Support for Overhead Cabinets — Select one per WorkCenter

SXRSMWOHB Overhead Structure Single Wide Mobile WorkCenter
SXRDMWOHB Overhead Structure Double Wide Mobile WorkCenter
SXRTMWOHB Overhead Structure Triple Wide Mobile WorkCenter
SXRKMWOHB Overhead Structure Single-Kneewell Mobile WorkCenter

Vertical Supports for Overhead Cabinets — Select one pair per WorkCenter

SXRMWUP24-24 24" (610mm) Base Interior with 24" (610mm) Overhead Interior (1 Pair)

SXRMWUP24-27 24" (610mm) Base Interior with 27" (686mm) Overhead Interior (1 Pair)
SXRMWUP24-30 24" (610mm) Base Interior with 30" (762mm) Overhead Interior (1 Pair
SXRMWUP24-33 24" (610mm) Base Interior with 33" (838mm) Overhead Interior (1 Pair)
SXRMWUP27-24 27" (686mm) Base Interior with 24" (610mm) Overhead Interior (1 Pair)
SXRMWUP27-27 27" (686mm) Base Interior with 27" (686mm) Overhead Interior (1 Pair)
SXRMWUP27-30 27" (686mm) Base Interior with 30" (762mm) Overhead Interior (1 Pair)
SXRMWUP30-24 30" (762mm) Base Interior with 24" (610mm) Overhead Interior (1 Pair)
SXRMWUP30-27 30" (762mm) Base Interior with 27" (686mm) Overhead Interior (1 Pair)
SXRMWUP33-24 33" (838mm) Base Interior with 24" (610mm) Overhead Interior (1 Pair)

Overhead Cabinet and Shelving Combination — Vertical Supports — Select one pair per WorkCenter

SXRMWUP24Q-24 24" (610mm) Base 24" (610mm) Overhead Interior & Slotted Inserts (1 Pair)
SXRMWUP24Q-27 24" (610mm) Base 27" (686mm) Overhead Interior & Slotted Inserts (1 Pair)
SXRMWUP24Q-30 24" (610mm) Base 30" (762mm) Overhead Interior & Slotted Inserts (1 Pair)
SXRMWUP24Q-33 24" (610mm) Base 33" (838mm) Overhead Interior & Slotted Inserts (1 Pair)
SXRMWUP27Q-24 27" (686mm) Base 24" (610mm) Overhead Interior & Slotted Inserts (1 Pair)
SXRMWUP27Q-27 27" (686mm) Base 27" (686mm) Overhead Interior & Slotted Inserts (1 Pair)
SXRMWUP27Q-30 27" (686mm) Base 30" (762mm) Overhead Interior & Slotted Inserts (1 Pair)
SXRMWUP30Q-24 30" (762mm) Base 24" (610mm) Overhead Interior & Slotted Inserts (1 Pair)
SXRMWUP30Q-27 30" (762mm) Base 27" (686mm) Overhead Interior & Slotted Inserts (1 Pair)
SXRMWUP33Q-24 33" (838mm) Base 24" (610mm) Overhead Interior & Slotted Inserts (1 Pair)

Contact the Metro Starsys team for dimension and packaged weight information.

Mobile WorkCenter Reagent Shelving and Support

Depth/Width
Model No. Description (in) (mm)

Reagent Shelving Options

SXRSMWSHF Shelf Assembly — Single width 14 x 21.5 355 x 546
SXRDMWSHF Shelf Assembly — Double width 14 x 41.3 355 x 1049
SXRTMWSHF Shelf Assembly — Triple width 14 x 61.1 355 x 1552
SXRKMWSHF Shelf Assembly — Single — Kneewell — Single 14 x 73 355 x 1854

Lateral Support for Reagent Shelving — Select one pair per WorkCenter

SXRSMWSB Cross Member — Single width
SXRDMWSB Cross Member — Double width (1 Pair)
SXRTMWSB Cross Member —Triple width (1 Pair)
SXRKMWSB Cross Member — Single — Kneewell —Single (1 Pair)

Vertical Supports with Slotted Inserts for Reagent Shelving — Select one per WorkCenter

SXRMWUP24Q 24" (610mm) Base Interior with Slotted Inserts
SXRMWUP27Q 27" (686mm) Base Interior with Slotted Inserts
SXRMWUP30Q 30" (762mm) Base Interior with Slotted Inserts
SXRMWUP33Q 33" (838mm) Base Interior with Slotted Inserts

System — Mobile WorkCenters

™

Starsys

Contact the Metro Starsys team for dimension and packaged weight information.

Other Casters Options

3" (76mm)
Total-Lock Caster:

Utilize 3" total-lock
plate casters for limited
mobile applications or
when additional storage
area is required.

5" (127mm) Swivel/Lock (Directional) Casters (available by request)
Other specialty caster options are available, consult your Metro representative.

All Metro Catalog Sheets are available on our website: www.metro.com

Mobile WorkCenter with
Reagent Shelving

Shelf Weight Capacity:
40 lbs per sq. ft., 200 lb.
maximum per shelf.
Mobile WorkCenter
maximum load not to
exceed 900 lbs.
Shelves are adjustable on
1" centers.
Minimum shelf spacing: 5"
(102mm)

Additional caster options
are available through the
Metro Starsys Confi gurator

(1 Pair)

or by contacting your Metro
representative.

Standard Casters

(1 Pair)
(1 Pair)
(1 Pair)
(1 Pair)

B3P-TL

5" (127mm)
Stainless
Steel Caster:

Recommended
for corrosive
environments.

B5PBGSA

5" (127mm)
Total-Lock, All-Polymer
Caster: Recommended

for corrosive
environments. All­polymer total-lock
plate caster is an

economical alternative to stainless casters.

B5PC-TL

InterMetro Industries Corporation

North Washington Street • Wilkes-Barre, PA 18705 • 570.825.2741
Fax: [phone] (East Coast/Canada) • Fax: [phone] (West Coast)

FOR PRODUCT INFORMATION/CUSTOMER SERVICE:

U.S./Canada/Latin America: 1.800.992.1776 • Europe: +31.76.587.7550
Asia/Pacifi c: +65.6567.8003 • Middle East/Africa: +971.4.811.8286

Information and specifi cations are subject to change without notice. Please confi rm at time of order Copyright © 2012 InterMetro Industries Corp.

Mobile WorkCenters
come standard with (2)
Polymer Toe Brake front
side casters and (2)
Polymer Swivel back
side casters.

Stabilizer/
Leveling Caster:

Recommended for
applications where
benchtop equipment
demands unit stability
and/or a level worksurface. Engage
caster foot for stability, release for
mobility.

B3N-AS

Printed in U.S.A.

L03-284e

09/12
