Mercedes-Benz M-Class 2003, ML 350 2003, ML 500 2003 User Manual
ML 320
ML 350
ML 500
ML 55 AMG
Our company and staff congratulate you
on the purchase of your new
Mercedes-Benz.
Your selection of our product is a demonstration of your trust in our company
name. Further, it exemplifies your desire to
own an automobile that will be as easy as
possible to operate and provide years of
service.
Your Mercedes-Benz represents the efforts of many skilled engineers and craftsmen. To help assure your driving pleasure,
and also the safety of you and your passengers, we ask you to make a small investment of time:
앫 Please read this manual carefully be-
fore putting it aside. Then return it to
your vehicle where it will be handy for
your reference.
앫 Please follow the recommendations
contained in this manual. They are designed to acquaint you with the operation of your Mercedes-Benz.
앫 Please pay attention to the warnings
and cautions contained in this manual.
They are designed to help improve the
safety of the vehicle operator and occupants.
We extend our best wishes for many miles
of safe, pleasurable driving.
Mercedes-Benz USA, LLC
A DaimlerChrysler Company
Introduction.......................................... 9
Product information ................................ 9
Operator’s Manual ............................... 10
Service and warranty information .. 10
Important notice for California
retail buyers and lessees of
Mercedes-Benz automobiles .......... 11
Maintenance .................................. 12
Roadside Assistance ...................... 12
Change of address or ownership.... 12
Operating your vehicle outside
the USA or Canada......................... 13
Where to find it .................................... 15
Symbols............................................... 16
Operating safety .................................. 17
Proper use of the vehicle ............... 17
Problems with your vehicle .................. 18
Reporting safety defects...................... 19
Reporting safety defects ................ 19
At a glance .......................................... 21
Cockpit................................................. 22
Instrument cluster ................................ 24
Center console ..................................... 27
Upper part ...................................... 27
Lower part ...................................... 28
Overhead control panel ........................ 29
Getting started................................... 31
Unlocking ............................................. 32
Remote control with folding key ..... 32
Adjusting .............................................. 34
Seats............................................... 34
Steering wheel ................................ 37
Mirrors ............................................ 38
Driving .................................................. 40
Fastening the seat belts.................. 40
Starting the engine ......................... 44
Switching on headlamps ................. 46
Turn signals..................................... 47
Windshield wipers ........................... 47
Rear window wiper.......................... 48
Problems while driving.................... 49
Contents
Parking and locking .............................. 50
Parking brake ................................. 50
Switching off headlamps................. 51
Turning off engine ........................... 51
Safety and Security ........................... 53
Occupant safety ................................... 54
Airbags ........................................... 55
Seat belts ....................................... 60
Children in the vehicle .................... 63
Blocking of rear door
window operation ........................... 69
Panic alarm .......................................... 70
Activating........................................ 70
Deactivating.................................... 70
Driving and safety systems .................. 71
ABS................................................. 71
BAS................................................. 73
4-ETS .............................................. 73
EBP ................................................. 74
ESP ................................................. 75
Anti-theft systems ................................ 78
Immobilizer ..................................... 78
Anti-theft alarm............................... 78
Contents
Tow-away alarm,
glass breakage sensor.................... 79
Controls in detail ............................... 83
Locking and unlocking ......................... 84
Remote control with folding key ..... 84
Opening the doors
from the inside ............................... 86
Opening the liftgate........................ 87
Closing the liftgate ......................... 88
Automatic central locking .............. 89
Locking and unlocking
from the inside ............................... 90
Seats.................................................... 91
Seat heater*................................... 91
Removing and installing
head restraints ............................... 92
Rear seats ...................................... 93
Third row seats*............................. 96
Memory function*................................ 99
Storing positions in memory ........ 100
Recalling positions from memory . 100
Exterior rear view mirror parking
position (passenger side) ............. 100
Lighting.............................................. 102
Combination switch ..................... 102
Fog lamps .................................... 105
Hazard warning flasher ................ 106
Interior lighting............................. 107
Instrument cluster ............................. 110
Instrument cluster illumination .... 110
Coolant temperature gauge ......... 111
Display in the speedometer ......... 111
Resetting trip odometer ............... 112
Tachometer .................................. 112
Outside temperature indicator ..... 112
Setting the clock .......................... 112
Automatic transmission ..................... 113
One-touch gearshifting ................. 113
Gear ranges.................................. 114
Gear selector lever position ......... 115
Accelerator position ..................... 117
Towing a trailer ............................ 117
Emergency operation (Limp Home
Mode)........................................... 117
Transmission control –
LOW RANGE mode............................. 118
Switching on LOW RANGE mode.. 118
Switching off LOW RANGE mode . 118
Good visibility .................................... 119
Rear view mirror .......................... 119
Headlamp cleaning system* ........ 121
Windshield wipers ........................ 122
Rear window wiper....................... 123
Sun visor ...................................... 123
Automatic climate control ................. 124
Automatic mode .......................... 126
Adjusting air volume and air
distribution manually ................... 127
Defrosting .................................... 128
Air recirculation mode.................. 128
Air conditioning............................ 129
Residual heat and ventilation ....... 130
Rear window defroster ................. 131
Rear passenger compartment
ventilation and rear automatic
climate control ............................. 131
Front and rear air outlets ............. 132
Power windows.................................. 134
Opening and closing the side
windows....................................... 134
Rear quarter windows* ................ 136
Sliding/pop-up roof* ......................... 137
Opening and closing the
sliding/pop-up roof...................... 137
Contents
Loading.............................................. 139
Loading instructions..................... 139
Partition net* ............................... 141
Cargo area cover blind* ............... 143
Cargo floor plates ........................ 144
Roof rack*.................................... 145
Driving systems ................................. 146
Cruise control .............................. 146
Parktronic system*
(Parking assist) ............................ 149
Useful features .................................. 152
Interior storage spaces ................ 152
Cup holders.................................. 154
Armrest in rear seat bench .......... 155
Ashtrays and cigarette lighter ...... 156
Electrical outlet ............................ 158
Telephone* .................................. 158
Tele Aid* ...................................... 159
Garage door opener ..................... 168
Trip computer*............................. 172
Operation ......................................... 177
The first 1000 miles (1500 km) ......... 178
Driving instructions............................ 179
Drive sensibly – save fuel ............. 179
Drinking and driving ...................... 179
Pedals ........................................... 179
Power assistance .......................... 179
Brakes........................................... 180
Driving off ..................................... 181
Parking.......................................... 182
Tires.............................................. 182
Hydroplaning................................. 183
Tire traction .................................. 183
Tire speed rating ........................... 184
Winter driving instructions ............ 184
Standing water.............................. 185
Off-road driving ............................. 186
Trailer towing ................................ 192
Passenger compartment............... 196
Driving abroad .............................. 197
Control and operation of radio
transmitters .................................. 197
Catalytic converter........................ 198
Emission control ........................... 198
Coolant temperature..................... 199
At the gas station ............................... 200
Check regularly and
before a long trip .......................... 201
Engine compartment .......................... 202
Hood............................................. 202
Engine oil ...................................... 203
Transmission fluid level ................ 206
Coolant ......................................... 206
Battery .......................................... 207
Windshield washer system and
headlamp cleaning system ........... 208
Tires and wheels ................................ 209
Important guidelines ..................... 209
Life of tire ..................................... 210
Direction of rotation ..................... 210
Checking tire inflation pressure .... 211
Rotating wheels ............................ 212
Winter driving ..................................... 213
Winter tires ................................... 213
Block heater (Canada only) ........... 214
Snow chains ................................. 214
Maintenance ...................................... 215
Clearing the service indicator ....... 215
Service term exceeded ................. 215
Calling up the service indicator .... 216
Resetting the service indicator ..... 216
Vehicle care ....................................... 217
Cleaning and care
of the vehicle ................................ 217
Contents
Practical hints.................................. 223
What to do if … .................................. 224
Lamps in instrument cluster ......... 224
Additional indicators in the
speedometer display .................... 235
Where will I find ...?............................ 236
First aid kit ................................... 236
Vehicle tool kit ............................. 237
Electric air pump (ML 55 AMG) .... 238
Spare wheel (space-saver tire) ..... 239
Unlocking/locking in an emergency.. 242
Unlocking the vehicle ................... 242
Locking the vehicle ...................... 243
Changing batteries ....................... 243
Fuel filler flap ............................... 244
Manually unlocking the
transmission selector lever .......... 245
Opening/closing in an emergency ..... 246
Sliding/pop-up roof*.................... 246
Replacing bulbs ................................. 247
Bulbs ............................................ 247
Replacing bulbs for front lamps.... 249
Replacing bulbs for rear lamps ..... 251
Adjusting headlamp aim ............... 253
Replacing wiper blades...................... 254
Removal ....................................... 254
Installation ................................... 254
Flat tire .............................................. 255
Mounting the spare wheel............ 255
Battery............................................... 261
Disconnecting the battery ............ 261
Removing the batteries ................ 262
Charging and reinstalling
batteries....................................... 262
Reconnecting the batteries .......... 262
Jump starting ..................................... 264
Towing the vehicle ............................. 267
Front towing eye .......................... 269
Rear towing eye ........................... 269
Stranded vehicle .......................... 270
Fuses ................................................. 271
Fuse box in engine
compartment ............................... 271
Auxiliary fuse box in front
passenger footwell ....................... 272
Technical data ................................. 273
Spare parts service............................ 274
Warranty coverage ............................ 275
Loss of Service and Warranty
Information Booklet ..................... 275
Identification labels ........................... 276
Layout of poly-V-belt drive................. 277
Engine ............................................... 278
Rims and tires ................................... 279
Rims and tires .............................. 279
Rims and winter tires* ................. 280
Spare wheel ................................. 280
Electrical system ............................... 281
Main Dimensions ............................... 282
Weights ............................................. 283
Fuels, coolants, lubricants etc. .......... 284
Capacities .................................... 284
Engine oils ................................... 286
Engine oil additives ...................... 286
Air conditioning refrigerant .......... 286
Brake fluid.................................... 286
Premium unleaded gasoline ......... 286
Fuel requirements ........................ 287
Gasoline additives ........................ 287
Coolants ...................................... 287
Anticorrosion/antifreeze.............. 288
Windshield and headlamp
washer system ............................. 290
Windshield and headlamp
washer fluid mixing ratio .............. 290
Consumer information ....................... 291
Uniform tire quality grading ......... 291
Temperature ................................ 292
Contents
Technical terms................................ 293
Index.................................................. 299
Contents
Product information
Please observe the following in your own
best interest:
We recommend using Mercedes-Benz original parts as well as conversion parts and
accessories explicitly approved by us for
your vehicle model.
We have tested these parts to determine
their reliability, safety and their special
suitability for Mercedes-Benz vehicles.
We are unable to make an assessment for
other products and therefore cannot be
held responsible for them, even if in individual cases an official approval or authorization by governmental or other agencies
should exist. Use of such parts and accessories could adversely affect the safety,
performance or reliability of your vehicle.
Please do not use them.
Introduction
Product information
Mercedes-Benz original parts as well as
conversion parts and accessories approved by us are available at your authorized Mercedes-Benz Light Truck Center
where you will receive comprehensive information, also on permissible technical
modifications, and where proper installation will be performed.
9
Introduction
Operator’s Manual
Operator’s Manual
This Operator’s Manual contains a great
deal of useful information. We urge you to
read it carefully and familiarize yourself
with the vehicle before driving.
For your own safety and longer service life
of the vehicle, we urge you to follow the instructions and warnings contained in this
manual. Ignoring them could result in damage to the vehicle or personal injury to you
or others. Vehicle damage caused by failure to follow instructions is not covered by
the Mercedes-Benz Limited Warranty.
Your vehicle may have some or all of the
equipment described in this manual.
Therefore, you may find explanations for
optional equipment not installed in your
vehicle. If you have any questions about
the operation of any equipment, your authorized Mercedes-Benz Light Truck Center will be glad to demonstrate the proper
procedures.
We continuously strive to improve our
product, and ask for your understanding
that we reserve the right to make changes
in design and equipment. Therefore, information, illustrations and descriptions in
this Operator’s Manual might differ from
your vehicle.
Optional equipment is also described in
this manual, including operating instructions wherever necessary. Since they are
special-order items, the descriptions and
illustrations herein may vary slightly from
the actual equipment of your vehicle.
If there are any equipment details that are
not shown or described in this Operator’s
Manual, your authorized Mercedes-Benz
Light Truck Center will be glad to inform
you of correct care and operating procedures.
The Operator’s Manual and Service Booklet are important documents and should be
kept with the vehicle.
Service and warranty information
The Service and Warranty Information
Booklet contains detailed information
about the warranties covering your
Mercedes-Benz, including:
앫 New Light Truck Limited Warranty,
앫 Emission System Warranty,
앫 Emission Performance Warranty,
앫 California, Maine, Massachusetts, and
Vermont Emission Control System
Warranty
(California, Maine, Massachusetts, and
Vermont only),
앫 State Warranty Enforcement Laws
(Lemon Laws).
10
Introduction
Operator’s Manual
Important notice for California retail
buyers and lessees of Mercedes-Benz
automobiles
Under California law you may be entitled to
a replacement of your vehicle or a refund
of the purchase price or lease price, if
Mercedes-Benz USA, LLC and/or its authorized repair or service facilities fail to fix
one or more substantial defects or malfunctions in the vehicle that are covered by
its express warranty after a reasonable
number of repair attempts. During the period of 18 months from original delivery of
the vehicle or the accumulation of
18 000 miles (approx. 29 000 km) on the
odometer of the vehicle, whichever occurs
first, a reasonable number of repair attempts is presumed for a retail buyer or
lessee if one or more of the following occurs:
(1) the same substantial defect or mal-
function results in a condition that is
likely to cause death or serious bodily
injury if the vehicle is driven, that defect or malfunction has been subject to
repair two or more times, and you have
directly notified Mercedes-Benz USA,
LLC in writing of the need for its repair,
(2) the same substantial defect or mal-
function of a less serious nature than
category (1) has been subject to repair
four or more times and you have directly notified us in writing of the need for
its repair, or
(3) the vehicle is out of service by reason
of repair of the same or different substantial defects or malfunctions for a
cumulative total of more than
30 calender days. Written notification
should be sent to us, not a dealer, at
Mercedes-Benz USA, LLC, Customer
Assistance Center, One Mercedes
Drive, Montvale, NJ 07645-0350.
11
Introduction
Operator’s Manual
Maintenance
The Service Booklet describes all the necessary maintenance work which should be
performed at regular intervals.
Always have the Service Booklet with you
when you take the vehicle to your authorized Mercedes-Benz Light Truck Center
for service. The service advisor will record
each service in the booklet for you.
Roadside Assistance
The Mercedes-Benz Roadside Assistance
Program provides factory-trained technical
help in the event of a breakdown. Calls to
the toll-free Roadside Assistance number
1-800-FOR-MERCedes (in the USA)
1-800-387-0100 (in Canada)
will be answered by Mercedes-Benz Customer Assistance Representatives
24 hours a day, 365 days a year.
Roadside Assistance will be provided in accordance with standard program guidelines which include providing service to the
vehicle up to a reasonable distance from a
paved roadway. We will make every effort
to assist in a breakdown situation, however, the accessibility of your vehicle will be
determined by our authorized Mercedes-Benz Light Truck Center technician
or the tow service provider on a
case-by-case basis and may be a factor in
our ability to respond.
Additional charges may be applicable for a
breakdown location determined not to be a
reasonably accessible roadside location as
determined by our authorized technician
and tow service provider.
For additional information refer to the
Mercedes-Benz Roadside Assistance Program brochure in your glove box.
Change of address or ownership
If you change your address, be sure to
send in the “Change of Address Notice”
found in the Service and Warranty Information Booklet, or simply call the
Mercedes-Benz Customer Assistance
Center (in the USA) at
1-800-FOR-MER-Cedes, or Customer Service (in Canada) at 1-800-387-0100. It is in
your own interest that we can contact you
should the need arise.
If you sell your Mercedes, please leave all
literature with the vehicle to make it available to the next operator.
If you bought this vehicle used, be sure to
send in the “Notice of Purchase of Used
Car” found in the Service and Warranty Information Booklet, or call the
Mercedes-Benz Customer Assistance Center (in the USA) at 1-800-FOR-MERCedes,
or Customer Service (in Canada) at
1-800-387-0100.
12
Operating your vehicle outside the USA
or Canada
If you plan to operate your vehicle in foreign countries, please be aware that:
앫 Service facilities or replacement parts
may not be readily available,
앫 unleaded gasoline for vehicles with cat-
alytic converters may not be available;
the use of leaded fuels will damage the
catalysts,
앫 gasoline may have a considerably low-
er octane rating, and improper fuel can
cause engine damage.
Introduction
Operator’s Manual
13
Introduction
Operator’s Manual
Warning! G
This Sport Utility Vehicle is designed for both on-road and off-road use. It can go places and perform tasks for which conventional 2-wheel drive
passenger cars were not intended. This vehicle will handle and maneuver differently from conventional passenger cars in driving conditions which
may occur on streets, highways and off-road use.
This vehicle has a higher ground clearance and a higher center of gravity than many passenger cars. As with other vehicles of this type, if you
make sharp turns at excessive speeds or abrupt maneuvers, the vehicle may roll over or may go out of control and crash. Utility vehicles have a
significantly higher rollover rate than other types of vehicles. Failure to operate this vehicle safely may result in an accident, rollover of the vehicle,
and severe or fatal injury.
Before you start to drive this vehicle, read the Operator’s Manual. Take time to become familiar with the driving characteristics of this vehicle. Be
sure you are familiar with all vehicle controls. Learn how your vehicle handles on different road surfaces. Do not attempt sharp turns at excessive
speeds or abrupt maneuvers or other unsafe driving actions that can cause loss of vehicle control. When driving off-road or working the vehicle
hard, do not overload it. And, always wear your seat belts at all times. In a rollover crash, an unbelted person is significantly more likely to die than
a person wearing a seat belt.
14
Where to find it
This Operator’s Manual is designed to provide comprehensive support information
for you, the vehicle operator. Each section
has its own reference color so you can find
information quickly.
At a glance
Here you will find an overview of all the
controls that can be operated from the
driver’s seat.
Getting started
Here you will find all the information you
need for your first drive. You should read
this section first if this is your first
Mercedes-Benz vehicle or if you are renting or borrowing this vehicle.
Safety and Security
Here you will find descriptions of the safety
features of your vehicle.
Controls in detail
Here you will find detailed information
about the equipment installed on your vehicle. This section expands on the “Getting
started” section and also describes technical innovations. If you are already familiar
with the basic functions of your vehicle,
this section will be of particular interest to
you.
Operation
Here you will find all the information you
need for the proper operation of your vehicle.
Practical hints
This section provides fast assistance for
dealing with problems you may encounter.
Introduction
Where to find it
Technical data
All important technical data for your vehicle can be found in this section.
Indexes
The glossary provides explanations of the
most important technical terms.
The table of contents and the index are designed to help you find information quickly
and easily.
The following publications are part of your
vehicle documentation:
앫 this Operator’s Manual
앫 the Service Booklet
Separate operating instructions will be
provided as required depending on the
equipment options installed in your vehicle.
15
Introduction
Symbols
Symbols
The following symbols are found in this
Operator’s Manual:
Warning! G
왘 This symbol points to instructions for
you to follow.
* Optional equipment is identified
with an asterisk. Since standard
equipment varies between models,
the descriptions and illustrations in
this manual may differ slightly from
the actual equipment of your vehicle.
Warning notices draw your attention to hazards that may endanger your health or life,
or the health or life of others.
!
Highlights hazards that may result in
damage to your vehicle.
i
Helpful hints or further information you
may find useful.
왘 A number of these symbols appearing
in succession indicates a multiple-step
procedure.
컄 Page This symbol tells you where to
look for further information on a
topic.
컄컄 This continuation symbol marks
an interrupted procedure which
will be continued on the next
page.
-> In the glossary of technical
terms, this symbol is used to
cross-reference term definitions.
Display
Words appearing in the multifunction display are printed in
the type shown here.
16
Operating safety
Warning! G
Work improperly carried out on electronic
components and associated software could
cause them to cease functioning. Because
the vehicle’s electronic components are interconnected, any modification made may
produce an undesired effect on other systems.
Electronic system malfunctions could seriously impair the operating safety of your vehicle.
Ensure that any repairs or modifications to
electronic components are carried out by an
authorized Mercedes-Benz Light Truck Center.
Other improper work or modifications on the
vehicle could also have a negative impact on
the operating safety of the vehicle.
Some safety systems only function while the
engine is running. You should therefore never turn off the engine while driving.
Introduction
Operating safety
Proper use of the vehicle
Proper use of the vehicle requires that you
are familiar with the following information
and rules:
앫 the safety precautions in this manual
앫 the “Technical data” section in this
manual
앫 traffic rules and regulations
앫 motor vehicle laws and safety stan-
dards
17
Introduction
Problems with your vehicle
Problems with your vehicle
If you should experience a problem with your vehicle, particularly one that you believe may affect its safe operation, we urge you to
immediately contact your authorized Mercedes-Benz Light Truck Center to have the problem diagnosed and corrected if required. If
the matter is not handled to your satisfaction, please discuss the problem with the Mercedes-Benz Light Truck Center management,
or if necessary contact us at one of the following addresses:
In the USA:
Customer Assistance Center
Mercedes-Benz USA, LLC
One Mercedes Drive
Montvale, NJ 07645-0350
In Canada:
Customer Relations Department
Mercedes-Benz Canada, Inc.
849 Eglinton Avenue East
Toronto, Ontario, M4G 2L5
18
Introduction
Reporting safety defects
Reporting safety defects
For the USA only:
The following text is published as required of manufacturers under Title 49, Code of U.S. Federal Regulations, Part 575 pursuant to the
“National Traffic and Motor Vehicle Safety Act of 1966”.
Reporting safety defects
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform
the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Mercedes-Benz USA, LLC.
If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it
may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your dealer,
or Mercedes-Benz USA, LLC.
To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-888-327-4236 (or 366-0123 in Washington, D.C. area) or
write to: NHTSA, U.S. Department of Transportation, Washington, D.C. 20590. You can also obtain other information about motor vehicle safety from the Hotline.
19
20
At a glance
Cockpit
Instrument cluster
Center console
Overhead control panel
21
At a glance
Cockpit
Cockpit
22
At a glance
Cockpit
Item Page
1 Hood lock release 202
2 Parking brake pedal 50
3 Parking brake release 50
4 Left cup holder 154
5 Combination switch
앫 Turn signals
앫 High beam
6 Cruise control lever 146
7 Instrument cluster 110
8 Hazard warning flasher
switch
9 Lever for voice control
system*, see separate
operating instructions
46
106
Item Page
10 Windshield wiper/washer
switch
11 Front Parktronic* warning
indicator
12 Glove box 152
13 Right cup holder 154
14 Storage compartment
15 Electrical outlet 158
16 Horn
17 Headlamp washer button* 121
18 Steering lock with ignition 33
19 Steering wheel adjustment
stalk
122
150
37
23
At a glance
Instrument cluster
Instrument cluster
24
At a glance
Instrument cluster
Item Page
1 Gauge for
Coolant temperature
Outside temperature
Fuel with fuel reserve warning lamp
2 Knob for
Activating instrument cluster
Adjusting intensity
of instrument lamps
Main odometer 111
Trip odometer readout/reset
Flexible Service
System (FSS)
111
112
233
110
110
112
215
Item Page
3 Left indicator lamps
with:
¿ Brake Assist Sys-
tem (BAS)/Electronic Stability
Program (ESP) malfunction warning
lamp
{ Electronic Traction
System (4-ETS) malfunction indicator
lamp
- Antilock Brake Sys-
tem (ABS) malfunction indicator lamp
2 Brake pad wear in-
dicator lamp
: Low engine oil level
warning lamp
225
226
225
234
229
Item Page
/ Low engine coolant
level warning lamp
ê Low range indicator
lamp
? Engine malfunction
indicator lamp
4 Speedometer with:
v 4-ETS (Electronic
Traction System)/Electronic
Stability Program
(ESP) warning lamp
Trip/main odometer
Flexible Service
System (FSS)
Engine oil level indicator
230
226
232
224
111
215
204
25
At a glance
Instrument cluster
Item Page
5 Photo sensor
(adjusts the brightness of
the digital displays located
in 1, 4 and 8)
6 Right indicator lamps
with:
W Low wind-
shield/headlamp
washer system fluid
level warning lamp
7 Front passenger air-
bag switched off
‡ Front fog lamp
switched on
234
232
105
Item Page
_ Steering wheel ad-
justment not locked
< Seat belt nonusage
warning lamp
1 Supplemental Re-
straint System
(SRS) indicator
É Brake warning lamp 228
# Charge indicator
lamp
A High beam head-
lamp switched on
229
234
227
229
233
47
Item Page
7 Knob for setting clock 112
8 Tachometer with:
Selector lever
position
Clock 112
9 K Turn signal
indicator lamp right
10 L Turn signal
indicator lamp left
114
26
Center console
Upper part
Item Page
1 Air outlets, automatic
climate control
2 MCS, see separate
operating instructions
3 Automatic climate control 124
Rear window defroster
switch
4 Seat heater switch*,
passenger side
5 Rear quarter window
switch*, right
6 ESP control switch 75
132
131
91
136
At a glance
Center console
Item Page
7 Rear window wiper/wash-
er switch
8 Rear quarter window
switch*, left
9 Seat heater switch*,
driver’s side
10 Front and rear fog lamp
switch
11 Indicator lamp for antitheft
alarm system
12 Transmission control
switch, LOW RANGE mode
123
136
91
105
78
118
27
At a glance
Center console
Lower part
Item Page
1 Ashtray with cigarette
lighter
2 Selector lever for
automatic transmission
3 Power window switch, right
front door
4 Power window switch, right
rear door
5 Parking assist* (Parktron-
ic) deactivation switch
6 Storage compartment with
cup holder
156
44
134
134
149
154
Item Page
7 Exterior rear view mirror
adjustment switch
Exterior rear view mirror
electrically folding*
8 Central locking switch 89
9 Power window switch, left
rear door
10 Switch for rear door win-
dow override
11 Power window switch, left
front door
38
120
134
69
134
28
Overhead control panel
At a glance
Overhead control panel
Item Page
1 Front left interior lighting 107
2 Signal transmitter keys for
garage door opener
3 Front right interior lighting 107
4 Roadside Assistance
button
Information button 165
5 Interior lighting control 107
6 Trip computer* display 172
7 Rear view mirror 119
168
163
Item Page
8 Right reading lamp on/off 108
9 Automatic antiglare func-
tion* on/off
10 Left reading lamp on/off 108
11 Glass breakage sensor 79
12 Trip computer* control 172
Tow-away alarm switch 80
13 Tele Aid (emergency call
system) button
14 Sliding/pop-up roof*
switch
119
163
137
29
30
Loading...
