Medeli MK100 User guide

ELECTRONIC
KEYBOARD

RECORD -

PLAY -

- TOUCH

- SUSTAIN

INFORMATION FOR YOUR SAFETY!

THE FCC REGULATION WARNING (for USA)

This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15 of

the FCC Rules.

These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequen-

cy energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that

interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio

or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and

receiver.

Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician

for help.

PRECAUTIONS

PLEASE READ CAREFULLY BEFORE PROCEEDING

Please keep this manual in a safe place for future reference.

Power Supply

Please connect the designated DC adaptor to an AC outlet
of the correct voltage.

Do not connect it to an AC outlet of voltage other than that
for which your instrument is intended.

Unplug the DC power adaptor when not using the instru­ment, or during electrical storms.

Connections

Before connecting the instrument to other devices, turn off
the power to all units. This will help prevent malfunction and
/ or damage to other devices.

Location

Do not expose the instrument to the following conditions to
avoid deformation, discoloration, or more serious damage:
Direct sunlight
Extreme temperature or humidity
Excessive dusty or dirty location
Strong vibrations or shocks
Close to magnetic fields

Unauthorized changes or modification to this system can

void the user's authority to operate this equipment.

CAUTION

The normal function of the product may be disturbed

by Strong Electro Magnetic Interference. If so, simply

reset the product to resume normal operation by

following the owner's manual. In case the function

could not resume, please use the product in other

location.

Interference with other electrical devices

Radios and televisions placed nearby may experience
reception interference. Operate this unit at a suitable
distance from radios and televisions.

Cleaning

Clean only with a soft, dry cloth.
Do not use paint thinners, solvents, cleaning fluids, or
chemical-impregnated wiping cloths.

Handling

Do not apply excessive force to the switches or controls.

Do not let paper, metallic, or other objects into the instru­ment. If this happens, remove the electric plug from the
outlet. Then have the instrument inspected by qualified
service personnel.

Disconnect all cables before moving the instrument.

02

Contents

Panel & Display Description

Front Panel..................................................................4

Rear Panel...................................................................5

Display.........................................................................5

Setup

Power Supply...............................................................6

Connections

Connecting an MP3/CD Player....................................7

Connecting an Audio Equipment.................................7

Connecting a pair of Headphones...............................7

Connecting a Microphone...........................................7

Connecting a Sustain Pedal........................................7

Connecting a Computer...............................................7

Power Switch and Master Volume...........................8

Playing the Demos....................................................8

Playing the Voices

Playing a Voice............................................................9

Playing Two Voice Simultaneously-DUAL...................9

Playing Different Voices with Both hands-LOWER......9

Touch...........................................................................9

Sustain.......................................................................10

DSP Effect.................................................................10

Transpose..................................................................10

Octave.......................................................................10

Piano Mode...............................................................10

Metronome

Turning on the Metronome........................................14

Selecting the Beat.....................................................14

Function Menu

Octave.......................................................................15

Split Point..................................................................15

Beat Type...................................................................15

Accompaniment Volume............................................16

Touch........................................................................16

Tune..........................................................................16

Reverb Level.............................................................16

Chorus Level.............................................................16

Auto Power Off..........................................................16

Register Memory.....................................................17

Selecting a Registration Bank....................................17

Chord Dictionary.....................................................18

Playing the Songs

Listening to the Songs...............................................19

Lesson Mode.............................................................19

Recording and Playback.........................................20

MIDI Function

What’s MIDI?.............................................................20

MIDI Connection........................................................20

Auto Accompaniment

Selecting a Style........................................................11

Sync Start..................................................................11

Intro/Ending...............................................................11

Playing a Fill..............................................................12

Fade In/Out................................................................12

Tempo.......................................................................12

Auto Bass Chord........................................................12

Chord Basics.............................................................13

One Touch Setting.....................................................14

Trouble Shooting.....................................................21

Specifications..........................................................21

Appendices

Voice List...................................................................22

Style List....................................................................27

Song List....................................................................29

MIDI Implementation Chart........................................31

03

Panel & Display Description

Front Panel

1

5

43

6 7

2

8 9 10

1. [VOLUME] Knob

Adjust the master volume.

2. [ ] Button

Turn the power on or off.

3. [LESSON] Button

Enter the lesson mode.

4. [L/R] Button

Choose to practice the left hand
or right hand part.
[CHORD DICT.] Button
Turn the chord dictionary function
on or off.

5. [FADE] Button

Turn the Fade In/Out function on
or off.

6. [TEMPO +/-] Buttons

Adjust the current tempo value.

7. [CHORD] Button

Enter the Chord Mode.

8. [INTRO/ENDING] Button

Play the Intro or Ending pattern.

9. [FILL A] Button

Play the fill-in pattern A.

10. [FILL B] Button

Play the fill-in pattern B.

RECORD -

PLAY -

RECORD -

PLAY -

- TOUCH

- SUSTAIN

29

14

13 15

11

16 17 18 19

12. [START/STOP] Button

Start or stop playing the style or
song.

13. [BANK] Button

Switch between memory banks.
[STORE] Button
Register the current panel settings.

14. [M1]~[M4] Buttons

Recall the registered panel settings.

15. [O.T.S.] Button

Turn the One Touch Setting
function on or off.

16. [RECORD] Button

Enter the Record Mode.
[PLAY] Button
Play back the recording.

17. [DUAL] Button

Turn the dual function on or off.

18. [LOWER] Button

Turn the lower function on or off.

19. [SUSTAIN] Button

Turn the sustain function on or off.

20. [VOICE] Button

Switch to Voice Mode.
Press [VOICE] and [STYLE] at the
same time to enter Demo Mode.

- TOUCH

- SUSTAIN

2012

21 22 24 272623 25

21. [STYLE] Button

Switch to Style Mode.
Press [VOICE] and [STYLE] at the
same time to enter Demo Mode.

22. [SONG] Button

Switch to Song Mode.

23. [PIANO] Button

Turn the Piano Mode on or off.

24. [METRO] Button

Turn the metronome on or off.

25. [TRANSPOSE] Button

Adjust the Transpose value.

26. [DSP]Button

Turn the DSP effect on or off.

27. [FUNCTION] Button

Enter the function menu.

28. [+]/[-] and Number Buttons

Set parameters value or select
the number.

29. LCD Display

Display all parameters and values
related to the current operation.

28

11. [SYNC START] Button

Turn the Sync Start function on
or off.

04

Rear Panel

Panel & Display Description

Display

30

31 32 33 34 35

30. USB Jack

Connect to a computer.

31. SUSTAIN Jack

Connect a sustain pedal.

32. PHONES/OUTPUT Jack

Connect a pair of headphones or an
audio equipment.

33. AUX IN Jack

Connect an external audio source,
such as MP3 or CD player.

34. MIC Jack

Connect a microphone.

35. DC IN Jack

Connect the DC 12V power adapter.

1

2

3

6

7

8

1. RECORD/PLAY

2. NUMBER

3. VOICE/STYLE/DEMO/SONG

4. CHARACTER

5. TOUCH/SUSTAIN

6. RECORD

7. TREBLE CLEF

8. BASS CLEF

9. MEASURE

4

11

13

17

HARMONY

14

12

9

15

10

16

10. BEAT

11. TEMPO

12. CHORD

13. MEMORY/O.T.S.

14. A.B.C./FULL RANGE/FADE/A/B

15. NOTE INDICATION

16. LESSON

17. DUAL/LOWER/DSP

5

SUSTAIN

05

Setup

This section contains information about setting up your instrument
and preparing to play. Please go through this section carefully
before turning the power on.

Power Supply

You can power the instrument either by batteries or by power adaptor.
Follow the instructions described below.

Using Batteries

The instrument needs 6 pieces of AA (NO.5) or equivalent alkaline
batteries for power supply.

1. Open the battery cabinet cover located on the bottom of the

instrument.

2. Insert the batteries, carefully following the polarity markings on the

cabinet.

3. Replace the cabinet cover. Make sure it locks firmly in place.

Notes:

1. Do not mix using any used and new batteries.

2. Always use the same types of batteries.

3. Remove the batteries when the instrument is not in use for a long

period of time.

Using Power Adaptor

1. Turn down the volume before connecting to power supply.

2. Connect the adaptor to the DC IN jack of the instrument.

3. Plug the adaptor into an AC outlet. This will automatically cut off

the battery power supply.

Notes:

1. In order to save energy, the instrument will automatically shut down
after 30 minutes if it is not used. (Please refer to Auto Power Off).

2. For your safety, please unplug the instrument when it is not in use
or during a thunderstorm.

06

Connecting an MP3/CD Player

The rear-panel AUX IN jack receives audio signals from an external
audio source such as an MP3 or a CD player.
Use an audio cable to connect the AUX IN jack of the instrument to
the OUTPUT jack of the MP3/CD player. The instrument’s speakers
will play the music transmitted from the external player, and you can
play along.

Connecting an Audio Equipment

The rear-panel PHONES/OUTPUT jack delivers the output of the
instrument to an external audio equipment such as a keyboard
amplifier, a stereo sound system, a mixing console, or a recorder.
Use an audio cable to connect the PHONES/OUTPUT jack of the
instrument to the INPUT jack of the external audio equipment.

Notes:

1. Turn off the power to all units before connecting or disconnecting
the external equipment.

2. To avoid damaging the speakers, please set the master volume
to minimum level before turning on the power.

Connections

Connecting a pair of Headphones

A standard pair of stereo headphones can be connected to the
PHONES/OUTPUT jack for private practice or late-night playing.
The internal stereo speaker system is automatically shut off when a
pair of head phones is plugged into this jack.

Note:

Do not listen with the headphones at high volume for long periods
of time. Doing so may cause hearing loss.

Connecting a Microphone

You can plug a microphone to the MIC jack to sing along with your
keyboard performance or song playback.

1. Set the master volume to minimum level before connecting or

disconnecting a microphone.

2. Plug a microphone into the MIC jack.

3. Adjust the master volume to an appropriate level.

Connecting a Sustain Pedal

An optional footswitch can be plugged into the sustain jack and be
used to switch sustain on or off. Simply by pressing the pedal, you
will have a natural sustain as you play.

Connecting a Computer

Use a standard USB cable to connect the USB jack of the instru­ment to the USB port of a computer. You can transmit MIDI
messages between the instrument and the computer.

Notes:

1. Do not set the USB device to be input and output simultaneously
when setting the software on the computer. Otherwise, the sound
will be overlapped when playing the keyboard.

2. We recommend using a USB2.0 interface to connect the
instrument to computer.

07

Power Switch and Master Volume

Power Switch

Before you switch your instrument on, please turn down the volume
of instrument and the connected audio equipment first.

1. Make sure the instrument is properly connected to power supply.

2. Press POWER SWITCH, the LCD screen is lit, and displays

“Loading!”, indicating the instrument is powered on.

Master Volume

Rotate the [VOLUME] knob clockwise to increase the master volume
or counter-clockwise to decrease it. You can use the knob to set the
desired volume level.

Note:

If the speakers do not produce sound, please check if the master
volume is set too low or if headphones are plugged into the
PHONES jack.

Playing the Demos

The instrument features a variety of demo songs.

1. Press the [STYLE] and [VOICE] buttons simultaneously to start

playing all demo songs in a loop. The LCD will display the current
demo number and name.

2. Select a demo song.

Use the number keys, the [+]/[-] buttons to select the desired
demo song.

3. Press the [STYLE] and [VOICE] buttons simultaneously again or

press the [START/STOP] button to stop playing and exit the demo
mode.

Note:

During demo playback, only the following buttons will work:
[START/STOP], [TEMPO -]/[TEMPO +], [+]/[-], the Number buttons,
[VOLUME] and [POWER].

DEMO

1 2 3

4 5 6

7 8 9

0

08

The instrument features a variety of exceptionally realistic voices. Please
refer to Voice List.

Playing the Voices

1 2 3

Playing a Voice

1. Press the [VOICE] button.

Enter the VOICE mode. LCD shows “VOICE R1”, the voice number
and the voice name.

2. Select a voice.

Use the number keys, the [+]/[-] buttons to select the voice you want
to play.

3. Play the voice.

Play the keyboard and enjoy the beautiful voice.

Note:

When the DUAL and LOWER function is on, you can press [VOICE]
button repeatedly to choose the voice source. The corresponding LCD
indicator will highlight between R1, R2, and L.

Playing Two Voice Simultaneously-DUAL

1. Press the [DUAL] button to turn on the dual function. LCD shows

“VOICE R2”, the dual voice number and name.

2. Use the number keys, the [+]/[-] buttons to select a voice for VOICE R2.

3. Play the keyboard, you will hear two different voices layered together,

just like two different instruments being played at the same time.

4 5 6

7 8 9

0

DUAL

4. Press the [DUAL] button again to turn off the dual function.

Playing Different Voices with Both hands­LOWER

The Lower function splits the keyboard into two areas so as to create
different voices for each of your hands. The left hand voice is the lower
voice “L” .

1. In idle mode, press the [LOWER] button to turn the lower function on.

The LCD displays the left hand voice name and number, and the
indicator “VOICE L” and “LOWER”.

2. Use the number keys, the [+]/[-] buttons to select a voice for VOICE L.

3. Play the keyboard with both hands, and you will hear two different

voices.

4. Press the [LOWER] button again to turn off the lower function.

Split Point

The key on the keyboard that separates voice L and voice R1/R2 is called
the “split point”. The default split point is at F#3 (19) , however you can
assign it to any other key. Refer to the Function Menu.

Touch

The keyboard is equipped with a touch response feature that lets you
dynamically and expressively controls the level of the voice with your
playing strength – just as on an acoustic instrument. Please refer to the
function menu to adjust the touch level.

LOWER

09

Playing Voices

Sustain

When the Sustain feature is ON, all notes played on the keyboard will
have a longer sustain. Press the [SUSTAIN] button to turn sustain on or
off.

Note:

When using a sustain pedal, you can produce a much stronger and
more natural sustain effect than by using the [SUSTAIN] button.

DSP Effect

The DSP simulates sounds in real environment. With the DSP effects,
you can add ambiance and depth to your performance in a variety of
ways.

The function is turned on by default. You can press the [DSP] button to
turn DSP effect on or off.

Transpose

Transpose function allows the overall pitch of the instrument to be
transposed up or down by one octave in semitone steps.

1. the [TRANSPOSE] button to enter transpose menu. The LCD shows

the current transpose value.

SUSTAIN

TRANSPOSE

2. Use [+]/ [-] buttons to adjust the transpose value.

3. Press the [+] and [-] buttons simultaneously to reset the transposition

to 0.

Octave

The octave function will shift the pitch of the specified voice layer up or
down in the step of an octave.

You can refer to the function menu to adjust the octave value.

Note:

After adjusting the octave, notes in the highest and lowest keyboard
range may not sound normally.

Piano Mode

This function is to set the voice of the entire keyboard to piano instantly.

1. Press [PIANO] button to enter or exit piano mode.

2. In piano mode, you can play the accompaniment as in the other

modes, but it plays only the rhythm part.

Note:

In piano mode, the A.B.C. is automatically turned off.

PIANO

10

Auto Accompaniment

The auto accompaniment function puts a full backing band at your
fingertips. All you have to do is to play chords with your left hand, and
the accompaniment will automatically play along, instantly following
the chords you play. With auto accompaniment, even a solo performer
can enjoy playing with the backing of an entire band or orchestra.
The instrument features a variety of styles, please refer to the Style
List. Try selecting the different styles and enjoy the auto accompani­ment.

Selecting a Style

1. Press the [STYLE] button.

Enter the STYLE mode. LCD shows “STYLE”, the style number and
the style name.

2. Use the number keys, the [+]/[-] buttons to select the style you want

to play.

3. Press the [START/STOP] button to start the rhythm tracks of the

auto accompaniment.

Sync Start

When style stops, press the [SYNC START] button to turn on the
function. The beats on LCD will flash along with the tempo.

1. In Sycn Start mode, if the A.B.C. function is turned off, you can

press a key on the keyboard to start playing auto accompaniment
of the rhythm track.

1 2 3

4 5 6

7 8 9

0

SYNC
START

2. In Sycn Start mode, if the A.B.C. function is in use, you can press a

key on the chord range of the keyboard to start playing auto
accompaniment of all tracks.

Intro/Ending

The intro is an opening section of a song. When the intro pattern
finished, the system will automatically shift to the main section.

Ending is the ending section of a song. When the ending is finished,
accompaniment automatically stops.The length of the ending differs
depending on the selected style.

1. Press the [STYLE] button.

2. Select a style.

3. Turn the Chord Mode on.

4. Turn SYNC START on.

5. Press the [INTRO/ENDING], the “A” or “B” flashes on LCD, the style

is ready to play.

6. It will start the accompaniment as soon as you start playing in

Chord section. When the playback of the intro is finished, it
automatically switched to main A or B section.

7. Press the [INTRO/ENDING] again to play the ending section.

When the ending is finished, the auto accompaniment automatically
stops.

INTRO/

ENDING

FILL A FILL B

CHORD

SYNC
START

START/

STOP

Note:

If you press [FILL A] or [FILL B] before the ending is finished, it will play
a fill-in then switch to the corresponding main section.

11

Auto Accompaniment

Playing a Fill

Auto fill in function automatically adds a fill to your performance.
When
the fill-in is finished,accompaniment shifts to the Main section (A,B).

Note:

If you keep pressing [FILL A]/[FILL B] buttons during style playback,
the fill-in pattern will repeat playing until the button is released.
Playback will then shift to the related MAIN section.

When style stops, press the [FILL A]/[FILL B] buttons to select a MAIN
section. “A or B” will highlight on LCD.

Fade In/Out

Fade In

Starting the style with fade in produces a smooth beginning, the
volume increases from low to high. Press the [FADE] button when
Style is stopped，LCD will show FADE. Press the [START/STOP]
button to start Style playing. LCD will show◢FADE.

The Accompaniment Volume will change from 0 to the set value in
about 8 seconds. The keyboard volume will change from 0 to default
value at the same time.

Fade Out

Stopping the style with fade out produces a smooth ending, the
volume decreases from high to low. Press the [FADE] button during
Style playing. LCD will show FADE◣.

FILL A FILL B

FADE

The Accompaniment Volume will change from the set value to 0 in
about 8 seconds, and the style stops.

Tempo

Each style of the instrument has been programmed with a default
tempo; however, you can change it as needed.

1. Use the [TEMPO -]/[TEMPO +] buttons to change the tempo. The

value ranges from 5 to 280.

2. Hold down the [TEMPO -]/[TEMPO +] buttons to change the tempo

quickly.

3. Press the [TEMPO+] and [TEMPO-] buttons simultaneously to

restore the default tempo setting.

Auto Bass Chord

1. Press the [CHORD] button, the LCD will display the “A.B.C.”

indicator. The left hand section of the keyboard is the chord section.
You can play different chords in the chord section.

Press [CHORD] button again to enter Full Range mode. The “FULL
RANGE” indicator will be lit. You can play chords over the entire
keyboard in multi-fingering.

TEMPO

CHORD

2. Play chords in the chord section, and the LCD will display the

corresponding chord names.

12

3. Split Point Setting

Please refer to the function menu to set the split point. The split
point and the keys to its left all belong to the chord section.

Chord Basics

A chord, in music, is any harmonic set of three or more notes that is
heard as if sounding simultaneously. The most frequently encountered
chords are triads. A triad is a set of three notes that can be stacked in
thirds. When stacked in thirds, the triad's members, from lowest
pitched tone to highest, are called: the Root, the Third, and the Fifth.

Triad Type

There are following basic triad types:

Auto Accompaniment

Major Triad

Minor Triad

Augmented
Triad
Diminished
Triad

Chord Inversion

We define this chord its root is not in the bass (i.e., is not the lowest
note) as an inversion chord. When the root is in the bass, we call the
chord: root-position chord. If we put the Third and Fifth in the root
position, then it forms “Inversion”, we call this chord “Inversion Chord”.
See the following major triad and its inverted chord.

Chord Name

The chord name contains two parts content: Chord root and Chord
type.

Single Finger

Single finger type not only can detect single finger but also can detect
multi finger. And the single finger makes it easily to play chords through
only one, two or three keys. Including major, minor, seventh, and minor
seventh chord. Refer to relevant picture on the right for details.

A root with a major third added above and a perfect fifth
will consist as a “Major Triad”.
A root with a minor third added above and a perfect fifth
will consist as a “Minor Triad”.
A root with a major third added above and an
augmented fifth will consist as an “Augmented Triad”.
A root with a minor third added above and a diminished
fifth will consist as a “Diminished Triad”.

Multi-finger

Multi-finger allows you to play chords in normal fingering. Try playing
the 32 chord types in C scale as listed on the right.

Note:

In full range mode, the entire keyboard will only recognize chords
played in normal fingering.

13

Auto Accompaniment

One Touch Setting

When One Touch Setting is switched on, you can instantly recall all
auto accompaniment related settings including voices selection and
digital effects simply with a single touch of a button.

1. Press the [O.T.S.] button to turns on the One Touch Setting for

current style. LCD shows “O.T.S.”.

2. Press one of the [M1]-[M4] buttons, various panel settings (such as

voice, effect, etc.) that match the selected style can be instantly
recalled.

3. A.B.C. is automatically turned on during O.T.S. mode.

4. Press the [O.T.S.] button again to quit One Touch Setting mode,

the “O.T.S.” indicator will disappear.

Note:

In O.T.S. mode, the memory is not selectable.

O.T.S.

Metronome

Turning on the Metronome

Press the [METRO] button to turn on the metronome.
Press the [METRO] button again to turn off the metronome.
Press the [TEMPO+] / [TEMPO-] buttons to change the tempo of the
metronome.

Selecting the Beat

You can set the beat type in the function menu, please refer to the
function menu for details.

If you turn on the metronome during style playback, the metronome
sound will start from the next beat and its beat will match the current
style. When style stops, you can change the metronome beat as
desired.
The metronome is not usable in song mode.

METRO

TEMPO

14

Press the [FUNCTION] button to enter the function menu. The LCD
displays the current parameter item.

Press repeatedly the [FUNCTION] button to select an item, then use
the [+]/ [-] buttons to change the value of the selected item.

Parameter items and the value range in the function menu:

Parameter Item

Octave
Split Point
Beat Type
Accompaniment Volume
Touch
Tune
Reverb Level
Chorus Level
Auto Power Off

LCD Display

XXX Octave
XXX Split Pt
XXX Beat
XXX Accomp
XXX Touch
XXX Tune
XXX Rev Lev
XXX Chr Lev
XXX PowerOff

Range

-2 - 2
1 - 61
0， 2 - 9
0 - 32
OFF， 0 - 3

-50 - 50
0 - 127
0 - 127
OFF， 30， 60

Note:

It will exit the function menu if there is no operation in 3 seconds.

Function Menu

FUNCTION

Octave

1. Repeatedly press the [FUNCTION] button to select the octave menu.

The LCD displays “Octave”.
Use the [+] / [-] buttons to change the value over the range of -2 - 2.

2. Pressing [+] and [-] buttons at the same time will reset the octave value

to default “000”.

Split Point

The Point on the keyboard that separates voice L and voice R1/R2 is
called the "split point". Left hand section controls the auto bass chord
accompaniment when the A.B.C. function is on, or it plays the lower
voices when the A.B.C. function is off.

1. Repeatedly press the [FUNCTION] button to select split point menu.

The LCD displays “Split Pt”. Use [+] / [-] buttons to change Split Point.
The range of Split Point is: 1~61.

2. Press [+] / [-] buttons simultaneously will set the split point value to its

default setting: F#3 (19).

Beat Type

1. Repeatedly press the [FUNCTION] button to select the beat menu.

The LCD displays “Beat”.
Use the [+ ]/ [-] buttons to change the beat type.

2. Pressing [+] and [-] buttons at the same time will reset the beat type

to default “004”.

15

Function Menu

Accompaniment Volume

The function adjusts the accompaniment volume.

1. Repeatedly press the [FUNCTION] button to enter the function menu,

and when the LCD displays "Accomp", you can adjust the volume
level over the range of 0-32. LCD will show the current volume level.

2. In the function menu, press both [-] and [+] buttons simultaneously to

mute the accompaniment part. LCD shows “OFF Accomp”. Press
both buttons again to unmute the accompaniment volume.

Touch

1. Repeatedly press the [FUNCTION] button to select the touch menu.

The LCD displays “Touch”.
Use the [+ ]/ [-] buttons to change the touch level.

2. Pressing [+] and [-] buttons at the same time will reset the touch level

to default “002”.

Tune

The function adjusts the pitch of the entire keyboard in a 2-cent increment.

1. Repeatedly press the [FUNCTION] button to select the tune menu.

The LCD displays “Tune”.
Use the [+] / [-] buttons to change the value over the range of -50 - +50.

2. Pressing [+] and [-] buttons at the same time will reset the tune value

to default “000”.
The setting applies to both accompaniment and the voice.

Reverb Level

1. Repeatedly press the [FUNCTION] button to select the reverb level

menu. The LCD displays “Rev Lev”.
Use the [+]/ [-] button to adjust the level over the range of 0-127.

2. Pressing [+] and [-] buttons at the same time will reset the reverb level

to default.

Chorus Level

1. Repeatedly press the [FUNCTION] button to select the chorus level

menu. The LCD displays “Chr Lev”.
Use the [+]/ [-] button to adjust the level over the range of 0-127.

2. Pressing [+] and [-] buttons at the same time will reset the chorus

level to default.

Auto Power Off

1. Repeatedly press the [FUNCTION] button to select the power off

menu. The LCD displays “PowerOff”.
Use the [+]/ [-] button to change the time setting.

2. Pressing [+] and [-] buttons at the same time will reset the setting to

default “030” (30 min).

16

The Registration Memory feature allows you to save virtually all panel
settings to a registration memory, and you can instantly recall them by
pressing a single button.

The instrument has 4 memory banks, and each bank has 4 memories
(M1-M4).

Register Memory

1. Hold down [STORE] button , then press one of the memory buttons

[M1] - [M4] to save the panel settings. The LCD will display “Mem
Stor” and the new settings will replace the previous memory data.

2. Press one of the memory buttons [M1] - [M4] to recall the panel

settings saved to that memory.

3. You can save following parameters to the memory:

Voice Parameter: voice, dual, DSP.
Accompaniment Parameter: style, tempo, and chord no/off,
accompaniment sections.
Function Parameter: touch, some parameters in the function menu.

Note:

Registration memory cannot be recalled when the One Touch Setting
function is in use. The registration memory will reset to default settings
after power off.

Selecting a Registration Bank

1. Press the [BANK] button. The LCD will display the bank number.

2. Repeatedly press the [BANK] button to select a bank over the range

of 1-4.

M2M1 M3 M4BANK

BANK

17

Chord Dictionary

If you know the name of a chord but don't know how to play it, you can
use the Chord Dictionary function.

1. Press and hold the [CHORD DICT.] button for 2 seconds to enter this

mode. The LCD displays the Chord Type and Chord Notes.

2. The keys above C4 (including C4) are used to assign the Chord Type,

and the keys above C6 (including C6) are used to assign the Chord
Root. When the Chord Type and Chord Root are confirmed, the LCD
will display the Chord and the staff notation.

3. When you play the correct chord on the chord range of the keyboard,

an applause sound will be heard.

4. Press and hold the [CHORD DICT.] button for 2 seconds again to exit

this mode.

CHORD DICT.

L / R

18

The instrument has a variety of songs (Please refer to the Song List).
Each song can be practiced in LESSON mode.

Listening to the Songs

1. Press the [SONG] button to enter the song mode. It will play all

songs circularly. Press the [SONG] button again, it will stop the song.

2. In song mode, use the number keys and [+]/[-] buttons to select a

song.

3. During song playback, you can press the [START/STOP] button to

stop the song, press it again to play the current song repeatedly.

4. Use the [TEMPO+]/[TEMPO-] buttons to change the tempo of the

current song.

5. When the song is stopped, press [STYLE], [VOICE], [DUAL],

[M1] - [M4] to exit the song mode.

Playing the Songs

Lesson Mode

The instrument presets 3 different ways to practice a song, as specified
in Lesson 1, Lesson 2 and Lesson3. The instrument will grade your
practice when you finish a lesson, helping you to keep track of your
progress.

1. When song playback is stopped, press the [LESSON] button to enter

the lesson mode or select a lesson to practice.

2. Press the [START/STOP] button to start the lesson. The LCD displays

the note that needs to be played.

3. Press the [START/STOP] button again to stop the lesson.

4. In lesson mode, press repeatedly the [L/R] button to select to

practice the left hand part, the right hand part, or both hands.

5. You can select to practice one of the three lessons. It will grade your

practice when you finish a lesson.

In lesson 1, you will learn to practice at the correct time value. It doesn't
matter even you play the wrong notes.

In lesson 2, you will learn to play the correct notes. The lesson will
continue only when you have played correctly the note displayed on
LCD.

In lesson 3, you will learn to play the correct notes at the correct time
value.

LESSON

CHORD DICT.

L / R

When you finish a lesson, the instrument will grade your practice by
telling you the level you get.
Level 1: OK.
Level 2: Good.
Level 3: Very Good.
Level 4: Excellent.

After grading, the song will play back again, and you can practice again.

19

Recording and Playback

You can record you performance and then play it back.

1. Press the [RECORD] button, the RECORD

indicator will be lit, and the beats will flash.

2. Play the keyboard or press the [START/STOP] button to start

recording. If you want to record the accompaniment, please turn on
the A.B.C. function, then play chords in the chord section of the
keyboard.

3. Press the [RECORD] button again to stop recording. The RECORD

indicator goes out.

4. Press and hold the [PLAY] button for 2 seconds to play back the

recording. The PLAY indicator will be lit.

5. Press and hold the [PLAY] button for 2 seconds again to stop

playback. The PLAY indicator goes out.

Note:

The recording data will be lost after power off.

PLAY

RECORD

PLAY

RECORD

By using the MIDI functions you can expand your musical possibilities.
This section explains what MIDI is, and what it can do, as well as how
you can use MIDI on your instrument.

What's MIDI?

MIDI (short for Musical Instrument Digital Interface) allows a wide variety
of electronic musical instruments, computers and other related devices
to connect and communicate with one another. MIDI carries event
messages that specify notation, pitch and velocity, control signals for
parameters such as volume, vibrato, audio panning, and program
change information to change the voice selections.
The instrument can output the real-time playback information via MIDI
and control external MIDI devices. The instrument can also accept
incoming MIDI messages and generate sound accordingly.

MIDI Connection

The instrument is equipped with a standard USB interface, which allows
the instrument to be connected to a computer. Most computers will
automatically recognize the instrument, and allow MIDI messages to be
transmitted between the instrument and the computer via the USB-MIDI
jack.
Use a standard USB cable to connect the USB jack of the instrument to
the USB port of a computer.

Note:

Activate the computer from a sleep/suspended/standby mode before
connecting the USB cable.
Connect the USB cable to the instrument and a computer before
turning the power of the instrument on.

MIDI Function

20

Trouble Shooting

Problem

The speakers produce a “pop” sound whenever
the power is turned ON or OFF.

No sound results when the keyboard is played.

When using a mobile phone, noise is produced.

The auto accompaniment does not play back even
Sync is in standby condition and a key is pressed.

Keyboard & Display
Keyboard
Touch Response
Display
Voices
Polyphony (max.)
Voices
Layer
Split
Styles
Styles
Style Control

O.T.S.
Chord Types
Effects
Effects
Reverb
Chorus
Song & Recording
Music Library

Sequencer
Demo Song

61 Keys with Touch Response
3 types, Off
Multi-functional LCD

64
480 preset
Left, Right1, Right2
Yes

160 preset
Start / Stop
Sync Start
Intro / Ending
Main A / Fill in A
Main B / Fill in B
Chord mode
Fade in/out
Accomp volume
Yes
32

DSP on / off
128 levels
128 levels

140 preset
Music tutorial system
1 user song
140 preset

Possible Cause and Solution

This is normal and is no cause for alarm.

1. Check if the master volume is set too low.

2. Check if headphones are plugged into the PHONES jack.

Using a mobile phone in close proximity to the instrument may
produce interference. To prevent this, turn off the mobile phone or
use it further away from the instrument.

You may be trying to start accompaniment by playing a key in the
right-hand range of the keyboard. To start the accompaniment with
Sync Start, make sure to play a key in the left-hand range of the
keyboard.

Specifications

Pitch Adjustment
Transpose
Octave
Tuning
Other Functions
Accompaniment Volume
Performance Memory
Metronome
Tempo
Other control
Connections
Interaction & Expansion
Phones
Pedals
USB
Input
Output
Power Supply
Power
Power Off Protection
Amplifiers & Speakers
Amplifiers
Speakers
Dimensions & Weight
Dimensions LWH (mm)
Weight (kg)

* All specifications and appearances are subject to
change without notice.

-12 ~ +12

-2 ~ +2

-50 ~ +50

0~32
4 preset banks x 4
0, 2 ~ 9
5 ~ 280
Piano Mode, Chord Dict

USB MIDI
1 standard stereo
Sustain
USB MIDI
Standard stereo
Yes (Phones jack)

DC 12V / 1 A
Yes

2.5W x 2
3W x 2

946 x 316 x 101
4

21

Voice List

No.

Englich Name

PIANO

1

Acoustic Grand Piano

2

Piano Dark

3

Octave Piano

4

Octave Piano 2

5

Piano & Choir

6

Grand Piano / W

7

Analog E.Piano

8

Analog E.Piano 2

9

Analog E.Piano Wah

10

Bright Piano

11

Stereo Bright Piano

12

Detuned Piano

13

Chorus Piano

14

Bright Piano / W

15

Piano & Vibraphone

16

Electric Grand Piano

17

Electric Grand Piano / W

18

Stereo Synth E.Piano

19

Stereo Synth E.Piano 2

20

Honky-Tonk Piano

21

Honky-Tonk Dark

22

Honky-Tonk / W

23

E.Piano

24

50's E.Piano

25

E.Piano / W

26

E.Piano 2 / W

27

E.Piano 2

28

Detuned E.P.

29

Harpsichord

30

Harpsichord / W

31

Harpsichord Octave

32

Harpsichord Off

33

Digital E.Piano

34

Digital E.Piano 2

35

Clavichord

36

Stereo Clavichord

37

Clavichord / W

38

Clavichord Wah

39

Synth Clav

CHROMATIC PERCUSSION

40

Celesta

41

Dark Celesta

42

Celesta & Sine

43

Reecho Bell

44

Celesta & Music Box

45

Glockenspiel

46

Glockenspiel & Sine

47

Children's Song

48

Analog Bell

49

Stereo Analog Bell

50

Music Box

51

Vibraphone

52

Vibraphone / W

53

Vibraphone & Bell

LCD Name

GrandPno

GrdPnD

OctPno

OctPno2

Pno&Cho

GrandPnW

AnEPno

AnEPno2

AnPnoWah

BritPno

BritePnS

DetunPno

ChoPno

BritPnW

Pno&Vib

EPianoG

E.PianoW

StSyElPn

StSyEPn2

HnkyTonk

HnkTonkD

HnkyTkW

E.Piano

50'sEP

EPianoW

EPianoW2

E.Piano2

DetunEP

Harpsi

HarpsiW

HarpsiO

HarpsiOf

DigiEP

DigiEP2

Clavi

ClaviS

ClaviW

ClaviWa

SynClav

Celesta

CelestD

Cele&Sin

ReBell

Cel&Mbox

Glocken

Glkn&Sin

ChilSong

AnaBell

StAnaBel

MusicBox

Vibra

VibraW

Vibr&Bel

54

Vibraphone & Harpsichord

55

Marimba

56

Marimba / W

57

Sine Marimba

58

Stereo Marimba

59

Marimba & Vibraphone

60

Wood Drum

61

Rotating

62

Dual Attack

63

Stereo TRI

64

Xylophone

65

Tubular Bells

66

Rotate Octave

67

Synth Organ Staccato

68

Synth Organ Staccato 2

69

Dulcimer

ORGAN

70

Drawbar Organ

71

Stereo Drawbar Organ

72

Soft Stereo Drawbar Organ

73

Mellow Drawbar Organ

74

Bright Drawbar Organ

75

Percussive Organ

76

Percussive Organ Detuned

77

Rock Organ

78

Church Organ

79

Detuned Church Organ

80

Octave Church Organ

81

Octave Church Organ 2

82

Finale

83

Digital Organ

84

Analog Organ

85

Analog Organ 2

86

Reed Organ

87

Reed Organ 2

88

Stereo Reed Organ

89

Accordion

90

Accordion 2

91

Stereo Accordion

92

Harmonica

93

Dark Harmonica

94

Tango Accordion

95

Dark Tango Accordion

GUITAR

96

Nylon Guitar

97

Chorus Nylon Guitar

98

Stereo Nylon Guitar

99

Stereo Nylon Guitar 2

100

Steel Guitar

101

12 String Guitar

102

Detuned Steel Guitar

103

Jazz. Guitar

104

Clean Guitar

105

Clean Guitar 2

106

Stereo Clean Guitar

107

Soft Clean Guitar

Vibr&Hrp

Marimba

MarimbaW

Marm&Sin

MarimbaS

Marm&Vib

WoodDrum

Rotating

DualAtta

StTRI

Xylophon

TubuBel

RotateOc

SyOrSta

SyOrSta2

Dulcimer

DrawOrg

DrawOrgS

DrawOgSf

MellDOrg

DrawOrgB

PercOrgn

DePerOrg

RockOrgn

ChurOrgn

DeChuOrg

ChrOrgO

ChrOrgO2

Finale

DigiOrg

AnaOrg

AnaOrg2

ReedOrgn

RedOrgn2

ReedOrgS

Acordin

Acordin2

AcordinS

Harmnica

HarmnicD

TangoAcd

TangAcdD

NylonGtr

NylonGtC

NylonGtS

NylnGtS2

SteelGtr

12StrGtr

DetStlGt

JazzGtr

CleanGtr

CleanGt2

CleanGtS

ClnGtSof

22

108

Chord Clean Guitar

109

Muted Guitar

110

Stereo Muted Guitar

111

Chord Muted Guitar

112

Overdrive Guitar

113

Dance Lead

114

Distortion Guitar

115

Analog Distortion Guitar

116

5Th Distortion

117

5Th Distortion 2

118

Analog Distortion

119

Analog Distortion 2

120

Analog Distortion Wah

121

Analog Distortion Wah 2

122

Guitar Harmonics

BASS

123

Acoustic Bass

124

Acoustic Bass 2

125

Acoustic Bass Detuned

126

Velocity Crossfade Bass

127

Jazz Style

128

A.Bass & Mute G.T.

129

Finger Bass

130

Finger Bass 2

131

Dark Finger Bass

132

Detuned Finger Bass

133

Velocity Bass

134

Bass & Distortion Guitar

135

Pick Bass

136

Pick Bass 2

137

Mute Pick Bass

138

Pick & Finger Bass

139

Pick Bass & Clean Guitar

140

Detuned Pick Bass

141

Fretless Bass

142

Fretless Bass 2

143

Slap Bass

144

Slap Bass 2

145

Slap Bass 3

146

Synth Bass

147

Synth Bass 2

148

Synth Bass 3

STRINGS & ORCHESTRAL

149

Violin

150

Violin 2

151

2 Violin

152

Viola

153

Viola 2

154

2 Viola

155

Cello

156

Cello 2

157

2 Cello

158

Contrabass

159

Contrabass 2

160

Tremolo Strings

ClnGtCho

MutedGtr

MutedGtS

MutGtCho

Ovrdrive

DancLead

DistGtr

AnDistGt

5ThDist

5ThDist2

AnaDist

AnaDist2

AnDisWah

AnDisWa2

GtrHarmo

AcoBass

AcoBass2

DetAcoBs

VelCroBs

JazzSty

ABs&MtGT

FngrBs

FngrBs2

FngrBsD

DetFngBs

VelBass

Bs&DisGt

PickBs

PickBs2

PickBsM

Pk&FgBs

PBs&ClGt

DetPkBs

Fretles

Fretles2

SlapBas

SlapBas2

SlapBas3

SynBass

SynBass2

SynBass3

Violin

Violin2

2Violin

Viola

Viola2

2Viola

Cello

Cello2

2Cello

Contrbs

Contrbs2

TremStr

161

Tremolo Strings 2

162

Pizzicato Strings

163

Pizzicato Strings 2

164

Orchestral Harp

165

Orchestral Harp 2

166

Stereo Harp

167

Timpani

168

Timpani 2

169

Strings Ensemble

170

Strings Ensemble 2

171

Boiling Life

172

Stereo Strings

173

Stereo Strings 2

174

Synth Strings

175

Synth Strings 2

176

Synth Strings 3

177

Stereo Synth Strings

178

Stereo Synth Strings 2

179

Analog Orchestra

180

Analog String

181

Analog String 2

182

Slow Strings

183

Slow Strings 2

184

Choir Aahs

185

Choir Aahs 2

186

Dark Aahs

187

Stereo Aahs

188

Stereo Aahs 2

189

Mellow Choir Aahs

190

Aahs & SynStr

191

Big Aahs

192

Analog Sound

193

Analog Sound 2

194

Voice Ooh

195

Synth Voice

196

Stereo Synth Voice

197

HK 80's

198

Homesick

199

Child Interest

200

Mechanical Voice

201

Power Voice

202

Child Interest Wah

203

Orchestra Hit

204

Orchestra Hit Stereo

205

Orchestra Hit Octave

BRASS

206

Trumpet

207

Trumpet 2

208

Dark Trumpet

209

Dark Trumpet 2

210

Wah Trumpet

211

Trombone

212

Trombone 2

213

Tuba

214

Tuba 2

Voice List

TremStr2

PizzStr

PizzStr2

Harp

Harp2

HarpS

Timpani

Timpani2

Strings

Strings2

Boiling

StringS

StringS2

SynStrs

SynStrs2

SynStrs3

SynStrS

SynStrS2

AnaOrch

AnaStr

AnaStr2

SlowStr

SlowStr2

ChoirAah

ChoirAh2

ChoAhD

ChoAhS

ChoAhS2

ChoAhMel

Ah&SyStr

BigAahs

AnaSound

AnSound2

VoiceOoh

SynVoic

SynVoicS

HK80's

Homesick

Interest

MechanVo

PoweVo

InterWah

OrchHit

OrchHitS

HitOctO

Trumpet

Trumpet2

TrumpetD

TrmpetD2

TrumpetW

Trmbone

Trmbone2

Tuba

Tuba2

23

Voice List

215

Muted Trumpet

216

Muted Trumpet 2

217

Horn

218

Horn 2

219

Stereo Synth Brass

220

5th Horn

221

Brass Ensemble

222

Majestic Unison

223

Synth Brass

224

Synth Brass 2

225

Synth Brass 3

226

Sharp Brass

227

Analog Brass

228

Analog Brass 2

229

Dynamics Analog Brass

230

Octave Synth Brass

REED

231

Soprano Sax

232

Soprano Sax 2

233

Alto Sax

234

Alto Sax 2

235

Tenor Sax

236

Tenor Sax 2

237

Baritone Sax

238

Baritone Sax 2

239

Oboe

240

Oboe 2

241

Sweet Oboe

242

English Horn

243

English Horn 2

244

Bassoon

245

Bassoon 2

246

Clarinet

247

Clarinet 2

PIPE

248

Piccolo

249

Piccolo 2

250

Flute

251

Flute 2

252

Recorder

253

Recorder 2

254

Pan Flute

255

Pan Flute 2

256

Blown Bottle

257

Blown Bottle 2

258

Shakuhachi

259

Shakuhachi 2

260

Whistle

261

Ocarina

SYNTH LEAD

262

Square Lead

263

Square Lead 2

264

Analog Lead

265

Lead Sine

266

Lead Sine 2

267

Analog Electric

MuteTrp

MuteTrp2

Horn

Horn2

StSyBras

5thHorn

Brass

Unison

SynBras

SynBras2

SynBras3

SharpBra

AnaBrass

AnaBras2

DyAnaBra

SynBrasO

SprnSax

SprnSax2

AltoSax

AltoSax2

TenoSax

TenoSax2

BariSax

BariSax2

Oboe

Oboe2

SwetOboe

EngHorn

EngHorn2

Bassoon

Bassoon2

Clarine

Clarine2

Piccolo

Piccolo2

Flute

Flute2

Recordr

Recordr2

PanFlut

PanFlut2

Bottle

Bottle2

Shakchi

Shakchi2

Whistle

Ocarina

SquarLd

SquarLd2

AnaLead

SineLead

SinLead2

AnaElect

268

Slow Square Lead

269

Analog Classic Lead

270

Thick Square

271

Quint

272

Sine Solo

273

Pulse Lead

274

Pulse Lead 2

275

Mellow Wind

276

80's Digital

277

Classic TRI

278

Stereo Analog Wind

279

Stereo Analog Wind 2

280

Sawtooth Lead

281

Sawtooth Lead 2

282

Stereo Sawtooth

283

Stereo Sawtooth 2

284

Electronic Lead

285

Psychedelic

286

80's Synth

287

5Th Analog

288

5Th Analog 2

289

Vitality

290

5th Sawtooth

291

5th Sawtooth 2

292

Comedy

293

Comedy 2

294

Fazli Lead

295

80's Sawtooth

296

Wind Chimes

297

5Th Digital Age

298

5Th Digital Age 2

299

5Th Square

300

5Th Square 2

301

Stereo Pulse

302

Stereo Pulse 2

303

Analog Signal

304

Analog Signal 2

305

Stereo Electronic Lead

306

Stereo Electronic Lead 2

307

Calliope Lead

308

Calliope Lead 2

309

Grand

310

Octave Pad

311

Classic Lead

312

Sawtooth Wah

313

Chiff Lead

314

Chiff Lead 2

315

Charang Lead

316

Fruity Lead

317

Voice Lead

318

Robot

319

Modulation Distortion

320

Control

321

Vague Vocals

322

Singl Synth

323

Analog Filter

SlowLead

AnClasLd

ThickSq

Quint

SineSolo

PulseLd

PulseLd2

Wind

80'sDig

ClassTRI

StAnWind

StAnWid2

SawLead

SawLead2

SawLdS

SawLdS2

ElecLead

Psyched

80'sSyn

5ThAna

5ThAna2

Vitality

5thSaw

5thSaw2

Comedy

Comedy2

FazliLd

80'sSaw

WindChi

5ThDigAg

5ThDgAg2

5ThSqu

5ThSqu2

StPulse

StPulse2

AnSignal

AnSignl2

StElecLd

StEleLd2

CalipLd

CalipLd2

Grand

OctPad

ClassLD

SawWah

ChiffLd

ChiffLd2

CharnLd

FruityLd

VoiceLd

Robot

ModDist

Control

VagueVo

SinglSyn

AnaFilt

24

324

Analog Voice

325

Analog Voice 2

326

Fifths Lead

327

Ninja

328

Ninja 2

329

Bass & Lead

330

Bass & Lead 2

331

Classic Synth

332

Classic Synth 2

333

Electron Impac

334

Elastic Across

335

Analog Wind

336

Electron Saw

337

Boring Sine

338

Steel Wire

339

Analog Pulse

340

Happiness

341

Deformation Pulse

SYNTH PAD

342

New Age Pad

343

New Age Pad 2

344

Rise

345

Praise

346

Intangible

347

Warm Day

348

Dunhuang

349

Free Space

350

Plump Sawtooth

351

Square Wah

352

Double Pulse

353

Comedy Wah

354

Phase Shift

355

Warm Pad

356

Warm Pad 2

357

Overture

358

Verve

359

Fulness Pad

360

Overture Wah

361

Digital Age

362

Analog Pad

363

Analog Pad 2

364

Analog Wah

365

Sharp

366

Warm Pulse

367

Happiness Pad

368

Sawtooth Pad

369

Sawtooth Pad 2

370

Poly Synth Pad

371

Poly Synth Pad 2

372

Modulation Distortion Wah

373

Choir Pad

374

Choir Pad 2

375

Plush Pad

376

Dawn Wah

377

Chorus Pad Wah

AnaVo

AnaVo2

FifthsLd

Ninja

Ninja2

Bs&Lead

Bs&Lead2

ClassSyn

ClassSy2

EleImpac

Across

AnaWind

EleSaw

BorSine

SteelWir

AnaPulse

Happines

DefPulse

NewAgPd

NewAgPd2

Rise

Praise

Intangi

WarmDay

Dunhuang

FreeSpa

PlumpSaw

SquaWah

DoubPul

ComeWah

PhaShift

WarmPad

WarmPad2

Overture

Verve

FulnesPd

OvertWah

DigitAge

AnalPd

AnalPd2

AnaloWah

Sharp

WarmPul

HappiPd

SawPad

SawPad2

PlySyPd

PlySyPd2

ModDiWah

ChoPad

ChoPad2

PlushPad

DawnWah

ChoPdWah

378

Electric Pad

379

5Th PAD

380

Bowed Pad

381

Bowed Pad 2

382

Metallic Pad

383

Dream

384

Dream 2

385

Dpray

386

Digital Pad

387

Organ Pad Wah

388

Pipe Organ Pad

389

Scene Pad

390

Halo Pad

391

Background

392

Background 2

393

Sweep Pad

394

Star Trek

395

Digital Wah

396

Warm Wah

397

Pulse Wah

398

Digital Distortion Wah

399

Pulse

400

Pulse 2

SYNTH SFX

401

Rain

402

Mysterious

403

Clusters of Stars

404

Additive Synthesis

405

Want To Go

406

Additive Synth Wah

407

Soundtrack

408

Lost Garden

409

Far Away

410

Crystal

411

Crystal 2

412

Game

413

Fly Into Space

414

Little Funny

415

Funny Hammer

416

Surface Of The Water

417

Atmosphere

418

Clouds

419

Brightness

420

Brightness 2

421

Life

422

Life 2

423

Fresh

424

Goblins

425

Fantasy

426

Space Trojan

427

Ceremony

428

Phonism

429

Echoes

430

Empty

431

Deformation

432

Sci-Fi

Voice List

ElecPad

5ThPad

BowdPad

BowdPad2

MetalPad

Dream

Dream2

Dpray

DigiPad

OrganWah

PipOrPd

ScenePad

HaloPad

Backgrd

Backgrd2

SweepPad

StarTrek

DigiWah

WarmWah

PulseWah

DiDisWah

Pulse

Pulse2

Rain

Mysterio

Stars

AddSynth

Wanttogo

AddWah

Soundtrk

Garden

FarAway

Crystal

Crystal2

Game

Fly

Funny

FunnyHam

Surface

Atmosphr

Clouds

Bright

Bright2

Life

Life2

Fresh

Goblins

Fantasy

SpaceTro

Ceremony

Phonism

Echoes

Empty

Deformat

Sci-Fi

25

Voice List

433

WindBells

434

Artistic

435

Artistic 2

436

Artistic 3

437

Digital Effect

438

Abyss

439

Abyss 2

440

Spectrum

441

Spectrum 2

ETHNIC MISC.

442

Sitar

443

Sitar 2

444

Banjo

445

Banjo 2

446

Shamisen

447

Shamisen 2

448

Koto

449

Koto 2

450

Kalimba

451

Kalimba 2

452

Bagpipe

453

Bagpipe 2

454

Fiddle

455

Fiddle 2

456

Shania

457

Shania 2

PERCUSSIVE

458

Tinkle Bell

459

Agogo

460

Steel Drums

461

Bass Drum

462

Wood Block

463

Snare

464

Taiko Drum

465

Melodic Tom

466

Synth Drum

467

Dynamics Jump

468

Reverse Cymbal

SFX

469

Guitar Fret Noise

470

Breath Noise

471

Seashore

472

Bird Tweet

473

Telephone Ring

474

Helicopter

475

Applause

476

Gunshot

477

Fall

DRUMS

478

Standard Drum Set

479

Rock Drum Set

480

Electronic Drum Set

WindBell

Artistic

Artisti2

Artisti3

DigitaEf

Abyss

Abyss2

Spectrum

Spectru2

Sitar

Sitar2

Banjo

Banjo2

Shamisn

Shamisn2

Koto

Koto2

Kalimba

Kalimba2

Bagpipe

Bagpipe2

Fiddle

Fiddle2

Shania

Shania2

TnklBell

Agogo

StelDrum

BassDrum

WoodBlok

Snare

TaikoDrm

MelodTom

SynDrum

DynJump

RevCymbl

FretNoiz

BrthNoiz

Seashore

Tweet

Telphone

Helicptr

Applause

Gunshot

Fall

StandSet

RockSet

ElecSet

26

No.

English Name

LATIN 1

1

Cha Cha

2

Pop Cha Cha

3

Rhumba

4

Pop Rhumba

5

Bossa Nova

6

Tango

7

Jazz Samba

8

Reggae

9

Pop Reggae

DANCE 1

10

Disco

11

Disco Funk

12

Dance

13

House

14

Rap

15

Euro Beat

16

Hip Hop

17

Techno

BEAT & POP 1

18

8 Beat 1

19

8 Beat 2

20

60’s 8 Beat

21

8 Beat Ballad

22

8 Beat Rock

23

16 Beat

24

16 Beat Pop

25

16 Beat Shuffle

26

Ballad

27

Slow Ballad

ROCK 1

28

Rock

29

Pop Rock

30

Fast Rock

31

Slow Rock

32

Rock & Roll

33

Blues Boogie

34

Blues

35

Blues Shuffle

36

Rock Shuffle

37

Charleston

SOUL & FUNK 1

38

Funky Pop

39

Jazz Funk

40

Cool Funky

41

Soul

42

Soul Blues

43

R & B

44

6/8 Gospel

45

Pop Groove

JAZZ 1

46

Swing

47

Cool Jazz

48

Pop Swing

49

Swing Fox

LCD Name

ChaCha

P.ChaCha

Rhumba

P.Rhumba

Bossa

Tango

JazSamba

Reggae

P.Reggae

Disco

DiscFunk

Dance

House

Rap

EuroBeat

HipHop

Techno

8Beat1

8Beat2

60's8Bt

8BtBld

8BtRock

16Beat

16BtPop

16BtShfl

Ballad

SlowBld

Rock

PopRock

FastRock

SlwRock

RockRoll

B.Boogie

Blues

B.Shufle

R.Shufle

Charston

FunkyPop

JazzFunk

CoolFunk

Soul

SoulBlue

R&B

6/8Gospl

PopGrove

Swing

CoolJazz

PopSwing

SwingFox

50

Big Band

51

Ragtime

52

Dixieland

53

Quick Step

COUNTRY 1

54

Country

55

Pop Country

56

Country Rock

57

Country Folk

58

3/4 Country

59

Country Waltz

60

Country Shuffle

61

Country Boogie

62

Country Quick Step

63

Bluegrass

TRADITIONAL 1

64

March

65

German March

66

6/8 March

67

Polka

68

Pop Polka

69

Waltz

70

Slow Waltz

71

Vienna Waltz

72

Musette

PIANIST 1

73

Piano 8 Beat

74

Piano Ballad

75

Piano Boogie

76

Piano Jazz

77

Piano Jazz Waltz

78

Piano March

79

Piano 6/8 March

80

Piano Waltz

LATIN 2

81

Cha Cha-2

82

Pop Cha Cha-2

83

Rhumba-2

84

Pop Rhumba-2

85

Bossa Nova-2

86

Tango-2

87

Jazz Samba-2

88

Reggae-2

89

Pop Reggae-2

DANCE 2

90

Disco-2

91

Disco Funk-2

92

Dance-2

93

House-2

94

Rap-2

95

Euro Beat-2

96

Hip Hop-2

97

Techno-2

BEAT & POP 2

98

8 Beat 1-2

99

8 Beat 2-2

100

60’s 8 Beat-2

101

8 Beat Ballad-2

102

8 Beat Rock-2

103

16 Beat-2

Style List

BigBand
Ragtime
Dixeland
QuickStp

Country
PopCntry
CtryRock
CtryFolk
3/4Ctry
C.Waltz
CtryShfl
C.Boogie
CtryStep
Bluegras

March
G.March
6/8March
Polka
PopPolka
Waltz
SloWaltz
VieWaltz
Musette

Pno8Beat
PnoBalad
PnoBogie
PnoJazz
P.JWaltz
PnoMarch
Pno6/8Mr
PnoWaltz

ChaCha2
P.ChaCa2
Rhumba2
P.Rhumb2
Bossa-2
Tango-2
JzSamba2
Reggae2
P.Regga2

Disco-2
DiscoFk2
Dance-2
House-2
Rap-2
EuropBt2
HipHop-2
Techno-2

8Beat1-2
8Beat2-2
60's8Bt2
8BtBld-2
8BtRck-2
16Bt-2

27

Style List

104

16 Beat Pop-2
16 Beat Shuffle-2

105

Ballad-2

106

Slow Ballad-2

107

ROCK 2

Rock-2

108

Pop Rock-2

109

Fast Rock-2

110

Slow Rock-2

111

Rock & Roll-2

112

Blues Boogie-2

113

Blues-2

114

Blues Shuffle-2

115

Rock Shuffle-2

116

Charleston-2

117

SOUL & FUNK 2

Funky Pop-2

118

Jazz Funk-2

119

Cool Funky-2

120

Soul-2

121

Soul Blues-2

122

R & B-2

123

6/8 Gospel-2

124

Pop Groove-2

125

JAZZ 2

Swing-2

126

Cool Jazz-2

127

Pop Swing-2

128

Swing Fox-2

129

Big Band-2

130

Ragtime-2

131

Dixieland-2

132

Quick Step-2

133

COUNTRY 2

Country-2

134

Pop Country-2

135

Country Rock-2

136

Country Folk-2

137

3/4 Country -2

138

Country Waltz-2

139

Country Shuffle-2

140

Country Boogie-2

141

Country Quick Step-2

142

Bluegrass-2

143
TRADITIONAL 2

March-2

144

German March-2

145

6/8 March-2

146

Polka-2

147

Pop Polka-2

148

Waltz-2

149

Slow Waltz-2

150

Vienna Waltz-2

151

Musette-2

152

PIANIST 2

Piano 8 Beat-2

153

Piano Ballad-2

154

Piano Boogie-2

155

Piano Jazz-2

156

16BtPop2
16BtShf2
Ballad-2
SlwBld-2

Rock-2
PopRck-2
FastRk-2
SlwRk-2
RkRoll-2
B.Bogie2
Blues-2
B.Shufl2
R.Shufl2
Charstn2

FunkPop2
JazzFk-2
CoolFk-2
Soul-2
SoulBlu2
R&B-2
6/8Gosp2
PopGrov2

Swing-2
CoolJz-2
PopSwin2
SwinFox2
BigBand2
Ragtime2
Dixland2
QuickSp2

Cntry-2
PopCtry2
CtryRk-2
CtryFok2
3/4Ctry2
C.Waltz2
CtryShf2
C.Bogie2
CtryStp2
Bluegra2

March-2
G.March2
6/8Marc2
Polka-2
PopPoka2
Waltz-2
SlWaltz2
ViWaltz2
Musette2

Pno8Bt-2
PnoBald2
PnoBogi2
PnoJazz2

157

Piano Jazz Waltz-2

158

Piano March-2

159

Piano 6/8 March-2

160

Piano Waltz-2

P.JWalz2
PnoMarc2
Pno6/8M2
P.Waltz2

28

No.

English Name

CLASSIC

1

Chanson Du Toreador

2

Meditation

3

Wiegenlied

4

A Lover's Concerto

5

Whispering Hope

6

From The New World

7

O Sole Mio

8

Auf Flugeln Des Gesanges

9

Santa Lucia

FAVORITE

10

Deck The Halls

11

Old Folks At Home

12

Camptown Races

13

Oh! Susanna

14

Jeanie With The Light Brown Hair

15

Long Long Ago

16

Annie Laurie

17

My Old Kentucky Home

18

Turkey In The Straw

19

Aloha Oe

20

Carry Me Back To Old Virginny

21

The Blue-Bells Of Scotland

22

Joy To The World

23

Jingle Bells

24

Battle Hymne Of The Republic

25

Silent Night

26

Ode To Joy

27

My Bonnie

28

La Cucaracha

29

Yellow Rose Of Texas

30

The Wabash Cannon Ball

31

Red River Valley

32

Dreaming Of Home And Mother

33

Ring Ring De Banjo

34

Der Freischutz

35

Tales Of Hoffman

36

Die Forelle

FOLK

37

Aura Lea

38

When The Saints Go Marching In

39

Twinkle Twinkle Little Star

40

I’ve Been Working On The Railroad

41

With Games

42

Way Home

43

Yankee Doodle

44

Michael Row The Boat Ashore

45

Auld Lang Syne

46

My Darling Clementine

47

Little Brown Jug

48

The House Of The Rising Sun

49

Danny Boy

50

El Condor Pasa

51

Greensleeves

52

Heidenroslein

LCD Name

Toreador

Meditati

WieGenli

Concerto

Whisper

NewWorld

OSoleMio

Gesanges

SantaLuc

DeckHall

OldFolks

C.Races

Susanna

Jeanie

LongAgo

AnnieLa

Kentucky

TukyStaw

AlohaOe

Virginny

BlueBell

JoyWorld

JingBell

BatlHyme

SltNight

OdeToJoy

MyBonnie

Cucarach

YellRose

CannBall

RedRiver

Dreaming

DeBanjo

DerFreis

Hoffman

Forelle

AuraLea

Marching

Twinkle

WorkRail

WithGame

WayHome

YankeeD

RowBoat

LangSyne

Clemtine

BrownJug

RiseSun

DannyBoy

ElCondor

Sleeves

Heidenro

53

Wiegenlied 2

54

Her Bright Smile Haunts Me Still

55

Old Black Joe

56

Old Dog Tray

57

Are You Lonesome Tonight?

58

Arirang

59

The Quilting Party

60

The Colorado Trail

61

I'D Like To Be In Texas

62

Shenandoah

63

Down In The Valley

64

On Top Of Old Smoky

65

Barbara Allen

66

Careless Love

67

Sweet Betsy From Pike

68

Jesse James

69

The Cowboy's Lament

KID’S SONG

70

Skip To My Lou

71

London Bridge Is Falling Down

72

Home On The Range

73

This Old Man

74

Polly Wolly Doodle

75

Sippin' Cider Through A Straw

76

Home Sweet Home

77

Mary Had A Little Lamb

78

Valse Brillante Op 34 #3 In F Major

79

Musette In D Major

80

Blue Bird Waltz
PIANO & KEYBOARD

81

Yankee Doodle (Piano)

82

Kaiser Walzer

83

Etude On Leger Lines 2

84

From A Story Book

85

Hanon Piano Fingering 1

86

Hanon Piano Fingering 2

87

Hanon Piano Fingering 3

88

Hanon Piano Fingering 4

89

Hanon Piano Fingering 5

90

Hanon Piano Fingering 6

91

Hanon Piano Fingering 7

92

Basic Tutorial Beyer Piano 8

93

Basic Tutorial Beyer Piano 12

94

Basic Tutorial Beyer Piano 13

95

Basic Tutorial Beyer Piano 14

96

Basic Tutorial Beyer Piano 15

97

Basic Tutorial Beyer Piano 16

98

Basic Tutorial Beyer Piano 18

99

Basic Tutorial Beyer Piano 19

100

Basic Tutorial Beyer Piano 20

101

Cuckoo

102

Butterfly

103

Christmas Eve

104

Beyer Eight Degrees Jump Etude

105

Old Folks At Home (Piano)

Song List

Wieglid2

HerSmile

BlackJoe

DogTray

Lonesome

Arirang

TheParty

TheTrail

InTexas

Shenando

Valley

TopSmoky

Allen

CaleLove

SwetPike

James

CowboyLa

SkipMyLo

Bridge

HomeRang

OldMan

PlyWlyDo

SipinCid

SwetHome

MaryLamb

ValOpFMr

MusetDMr

BlueBird

YankeeD2

Kaiser

EtudeLL2

StoryBok

Hanon1

Hanon2

Hanon3

Hanon4

Hanon5

Hanon6

Hanon7

Beyer8

Beyer12

Beyer13

Beyer14

Beyer15

Beyer16

Beyer18

Beyer19

Beyer20

Cuckoo

Buterfly

XmasEve

BeyrJump

OldFolk2

29

Song List

106

A Little Polish Dance

107

Larghetto

108

Minuet 2

109

Prelude

110

Duke Aria From “The Rigoletto”

111

Puck

112

The Happy Farmer

113

Etude

114

Dance Of The Four Swans From "Swan Lake"

115

Jesus Saviour Pilot Me

116

Old Macdonald Had A Farm

117

2-Part Invention No.13 In A Minor BWV 784

118

Musette

119

Bourree

120

Carl Czerny 599 NO92

121

Away In A Manger

122

Marriage Of Figaro

123

Angels We Have Heard On High

124

Waltz

125

Did You Ever See A Lassie

126

Old France

127

Santa Claus Is Coming To Town

128

Minuet 3

129

In The Theatre

130

Alfredo And Violetta Column Tower Duet

131

Als Die Alte Mutter Mich Noch lehrte Singen

132

At The Ball

133

Dancing Raindrops

134

Comin'Round The Mountain

135

Song Of The Brook

136

Cotton-pickin' Fingers

137

Menuett G Dur 3

138

Knight

139

Gavotte

140

The Angels Singing

PolishDc

Largheto

Minuet2

Prelude

DukeAria

Puck

HpFarmer

Etude

SwanLake

Jesus

OldAFarm

Invetion

Musette

Bourree

599No92

AwayInAM

Marriage

Angles

Waltz

Lassie

OldFranc

SantComn

Minuet3

Theatre

Alfredo

Mutter

AtBall

Raindrop

Mountain

SofBrook

CtnPFngs

MenuettG

Knight

Gavotte

Singing

30

MIDI Implementation Chart

1

31

MK100_OM03
