Model AGS—140 to 500 tons,

R-134a

Air-Cooled Screw Compressor Chillers—140 to 500 Tons

• Ultra-quiet operation - as low as 65 dBA per ARI Standard 370, with
optional sound attenuation package

• Application flexibility - remote evaporator option allows for split system
applications

• Optional unit-mounted pump packages available on standard efficiency
units

• Reliability - proven single screw compressor design

• Controls flexibility—MicroTech
feature for easy integration with the BAS of your choice

• Efficiency options - ASHRAE Standard 90.1 compliant standard efficiency
units. High and premium efficiency units available up to 10.6 EER at full
load

• R-134a refrigerant - no ozone depletion potential, no phase-out schedule

®

II controls with our Open Choices™

For more detail, refer
to Catalog AGSD and
Catalog AGSDP.
For the most current
information, refer to
www.mcquay.com.

Air-Cooled Chillers

124 2010 McQuay Products Catalog

Air-Cooled Chillers

Available LONMARK certified

Modbus

®

Pathfinder Chiller - 175 to 530 tons,

Model AWS, R-134a

Pathfinder™ Air-Cooled Chillers—175 to 530 Tons

• Three levels of efficiency

- Standard: meets ASHRAE Standard 90.1 for efficiency

- High: enhanced efficiency, up to 10.8 EER at full load

- Premium: highest full load efficiency in its class with part load efficiency
that rivals competitive chillers with VFDs

• Integrated VFD further optimizes part load efficiency to redefine world class
performance

• Quietest air cooled screw chiller available, with sound pressure levels as low
as 65 dBA with no attenuation

- Patented condenser fan moves maximum amounts of air with minimal

sound

- Unique screw compressor with single main rotor and dual gaterotors

operates more quietly than dual rotor screw compressors

• Contributes to Leadership in Energy and Environmental Design (LEED
Green Building Rating System™ points for enhanced refrigerant
management and optimized energy efficiency

• Small unit footprint makes it ideal for retrofit and replacement projects

• All Pathfinder Chillers shipped in North America are D-Net™ remote service
capable, providing a direct electronic connection to a Pathfinder Chiller and
the ability for enhanced level of support to keep the chiller running efficiently
and reliably

• Application flexibility with remote evaporator option available on standard
efficiency units

®

)

For more detail, refer
to Catalog 600.
For the most current
information, refer to
www.mcquay.com.

Air-Cooled Chillers

2010 McQuay Products Catalog 125

Air-Cooled Chillers

Pathfinder Model AWS Air-Cooled Packaged Chiller, Standard Efficiency—Physical Data

AWS 175ADS through AWS 210ADS, Packaged, Standard Efficiency, R-134a

Data

Basic Data

Unit cap. @ AHRI tons (kW) 174.1 (612.2) 194.2 (682.9) 207.8 (730.6)
Unit operating charge lb (kg) 145 (66) 145 (66) 165 (75) 165 (75) 175 (79) 175 (79)
Unit dimensions

L × W × H, in (mm)
Unit operating weight, lb (kg) 12950 (5874) 13673 (6202) 14208 (6445)
Unit shipping weight, lb (kg) 12407 (5628) 13130 (5956) 13665 (6198)
Weight-add for copper fins 1786 (810) 1786 (810) 1786 (810)
Weight-add for louvered panels 676 (307) 788 (357) 788 (357)
Weight-add for sound enclosures 477 (216) 477 (216) 477 (216)

Compressors, Screw, Semi-Hermetic

Nominal capacity, tons (kW) 90 (316) 90 (316) 90 (316) 100 (351) 100 (351) 100 (351)
Minimum capacity (% of full load) 15 15 15
Oil charge per circuit, gallons (liters)

Condensers, High Efficiency Fin and Tube Type

Pumpdown capacity, lb (kg) 208 (94) 208 (94) 250 (113) 250 (113) 250 (113) 250 (113)
Coil inlet face area, ft
Rows deep/fins per inch

Condenser Fans, Direct Drive Propeller Type

No. of fans/circuit–fan dia., in (mm) 5–31.5 (800) 6–31.5 (800) 6–31.5 (800)
Fan motors–hp (kW) / rpm 1.4 (1.05) / 850 1.4 (1.05) / 850 1.4 (1.05) / 850
Airflow, cfm (L/s) 110850 (52315) 133020 (62778) 133020 (62778)

Evaporator, Direct Expansion Shell and Tube

Shell dia. tube length, in (mm) 16 x 406 (406 x 2750) 16 x 108 (406 x 2750) 16 x 108 (406 x 2750)
Water volume, gallons (L) 67 (255) 67 (255) 63 (240)
Victaulic inlet/outlet conn. in. (mm)
Max. water / refrig. pressure, psi (kPa) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241)

2 (m2

) 123.1 (11.4) 123.1 (11.4) 147.7 (13.7) 147.7 (13.7) 147.7 (13.7) 147.7 (13.7)

AWS175ADS Std Eff AWS190ADS Std Eff AWS210ADS Std Eff

Circuit 1 Circuit 2 Circuit 1 Circuit 2 Circuit 1 Circuit 2

245 x 88 x 100

(6220 x 2225 x 2548)

4.5 (17) 4.5 (17) 4.5 (17) 5.5 (21) 5.5 (21) 5.5 (21)

3 / 16 3 / 16 3 / 16 3 / 16 3 / 16 3 / 16

6 (168) 6 (168) 6 (168)

245 x 88 x 100

(6220 x 2225 x 2548)

245 x 88 x 100

(6220 x 2225 x 2548)

AWS 230ADS through AWS 280ADS, Packaged, Standard Efficiency, R-134a

Data

Basic Data

Unit cap. @ AHRI tons (kW) 231.8 (815.0) 248.7 (874.4) 271.9 (955.9)

Air-Cooled Chillers

Unit operating charge lb (kg) 195 (88) 210 (95) 210 (95) 210 (95) 230 (104) 245 (111)
Unit dimensions

L × W × H, in (mm)
Unit operating weight, lb (kg) 15381 (6977) 15669 (7107) 17012 (7717)
Unit shipping weight, lb (kg) 14838 (6730) 15126 (6861) 16145 (7323)
Weight-add for copper fins 2084 (945) 2084 (945) 2372 (1076)
Weight-add for louvered panels 900 (408) 900 (408) 1012 (459)
Weight-add for sound enclosures 477 (216) 477 (216) 477 (216)

Compressors, Screw, Semi-Hermetic

Nominal capacity, tons (kW) 100 (351) 125 (439) 125 (439) 125 (439) 125 (439) 150 (528)
Minimum capacity (% of full load) 15 15 15
Oil charge per circuit, gallons (liters)

Condensers, High Efficiency Fin and Tube Type

Pumpdown capacity, lb (kg) 291 (132) 291 (132) 291 (132) 291 (132) 333 (151) 333 (151)
Coil inlet face area, ft
Rows deep/fins per inch

Condenser Fans, Direct Drive Propeller Type

No. of fans/circuit–fan dia., in (mm) 7–31.5 (800) 7–31.5 (800) 8–31.5 (800)
Fan motors–hp (kW) / rpm 1.4 (1.05) / 850 1.4 (1.05) / 850 1.4 (1.05) / 850
Airflow, cfm (L/s) 155190 (73241) 155190 (73241) 177360 (83704)

Evaporator, Direct Expansion Shell and Tube

Shell dia. tube length, in (mm) 16 x 108 / (406 x 2750) 16 x 108 / (406 x 2750) 20 x 108 / (508 x 2750)
Water volume, gallons (L) 61 (232) 61 (232) 103 (390)
Victaulic inlet/outlet conn. in. (mm)
Max. water / refrig. pressure, psi (kPa) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241)

2 (m2

) 172.3 (16.0) 172.3 (16.0) 172.3 (16.0) 172.3 (16.0) 169.9 (18.3) 169.9 (18.3)

AWS230ADS Std Eff AWS250ADS Std Eff AWS280ADS Std Eff

Circuit 1 Circuit 2 Circuit 1 Circuit 2 Circuit 1 Circuit 2

280 x 88 x 100

(7121 x 2225 x 2548)

5.5 (21) 5.5 (21) 5.5 (21) 5.5 (21) 5.5 (21) 6 (23)

3 / 16 3 / 16 3 / 16 3 / 16 3 / 16 3 / 16

6 (168) 6 (168) 8 (219)

280 x 88 x 100

(7121 x 2225 x 2548)

316 x 88 x 100

(8022 x 2225 x 2548)

126 2010 McQuay Products Catalog

Air-Cooled Chillers

AWS 300ADS through AWS 350ADS, Packaged, Standard Efficiency, R-134a

Data

Basic Data

Unit cap. @ AHRI tons (kW) 290.5 (1022.4) 327.5 (1151.8) 349.5 (1229.0)
Unit operating charge lb (kg) 245 (111) 245 (111) 270 (122) 270 (122) 285 (129) 285 (129)
Unit dimensions

L × W × H, in (mm)
Unit operating weight, lb (kg) 17724 (8040) 19656 (8916) 19656 (8916)
Unit shipping weight, lb (kg) 16857 (7646) 18789 (8523) 18789 (8523)
Weight-add for copper fins 2372 (1076) 2968 (1346) 2968 (1346)
Weight-add for louvered panels 1012 (459) 1236 (561) 1236 (561)
Weight-add for sound enclosures 477 (216) 477 (216) 477 (216)

Compressors, Screw, Semi-Hermetic

Nominal capacity, tons (kW) 150 (528) 150 (528) 150 (128) 175 (615) 175 (615) 175 (615)
Minimum capacity (% of full load) 15 15 15
Oil charge per circuit, gallons (liters)

Condensers, High Efficiency Fin and Tube Type

Pumpdown capacity, lb (kg) 333 (151) 333 (151) 416 (189) 416 (189) 416 (189) 416 (189)
Coil inlet face area, ft
Rows deep/fins per inch

Condenser Fans, Direct Drive Propeller Type

No. of fans/circuit–fan dia., in (mm) 8–31.5 (800) 10–31.5 (800) 10–31.5 (800)
Fan motors–hp (kW) / rpm 1.4 (1.05) / 850 1.4 (1.05) / 850 1.4 (1.05) / 850
Airflow, cfm (L/s) 177360 (83704) 221700 (104630) 221700 (104630)

Evaporator, Direct Expansion Shell and Tube

Shell dia. tube length, in (mm) 20 x 108 / (508 x 2750) 20 x 108 / (508 x 2750) 20 x 108 / (508 x 2750)
Water volume, gallons (L) 103 (390) 99 (374) 99 (374)
Victaulic inlet/outlet conn. in. (mm)
Max. water / refrig. pressure, psi (kPa) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241)

2 (m2

) 169.9 (18.3) 169.9 (18.3) 246.1 (22.8) 246.1 (22.8) 246.1 (22.8) 246.1 (22.8)

AWS300ADS Std Eff AWS320ADS Std Eff AWS350ADS Std Eff

Circuit 1 Circuit 2 Circuit 1 Circuit 2 Circuit 1 Circuit 2

316 x 88 x 100

(8026 x 2225 x 2548)

6 (23) 6 (23) 6 (23) 6 (23) 6 (23) 6 (23)

3 / 16 3 / 16 3 / 16 3 / 16 3 / 16 3 / 16

8 (219) 8 (219) 8 (219)

387 x 88 x 100

(9823 x 2225 x 2548)

387 x 88 x 100

(9823 x 2225 x 2548)

AWS 375ATS through AWS 400ATS, Packaged, Standard Efficiency, R-134a

Data

Basic Data

Unit cap. @ AHRI tons (kW) 376.5 (1323.9) 396.8 (1395.1)
Unit operating charge lb (kg) 210 (95) 210 (95) 245 (111) 210 (95) 210 (95) 245 (111)
Unit dimensions

L × W × H, in (mm)
Unit operating weight, lb (kg) 23885 (10834) 24570 (11145)
Unit shipping weight, lb (kg) 22486 (10200) 23171 (10510)
Weight-add for copper fins 3256 (1477) 3256 (1477)
Weight-add for louvered panels 1348 (611) 1348 (611)
Weight-add for sound enclosures 776 (352) 776 (352)

Compressors, Screw, Semi-Hermetic

Nominal capacity, tons (kW) 125 (439) 125 (439) 125 (439) 125 (439) 125 (439) 150 (528)
Minimum capacity (% of full load) 8 8
Oil charge per circuit, gallons (liters)

Condensers, High Efficiency Fin and Tube Type

Pumpdown capacity, lb (kg) 291 (132) 291 (132) 333 (151) 291 (132) 291 (132) 333 (151)
Coil inlet face area, ft
Rows deep/fins per inch

Condenser Fans, Direct Drive Propeller Type

No. of fans/circuit–fan dia., in (mm) 7–31.5 (800) 7–31.5 (800) 8–31.5 (800) 7–31.5 (800) 7–31.5 (800) 8–31.5 (800)
Fan motors–hp (kW) / rpm 1.4 (1.05) / 850 1.4 (1.05) / 850
Airflow, cfm (L/s) 266040 (125556) 243870 (115094)

Evaporator, Direct Expansion Shell and Tube

Shell dia. tube length, in (mm) 26 x 130 / (660 x 3300) 26 x 130 / (660 x 3300)
Water volume, gallons (L) 230 (871) 225 (850)
Victaulic inlet/outlet conn. in. (mm)
Max. water / refrig. pressure, psi (kPa) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241)

2 (m2

) 172.3 (16.0) 172.3 (16.0) 169.9 (18.3) 172.3 (16.0) 172.3 (16.0) 169.9 (18.3)

Circuit 1 Circuit 2 Circuit 3 Circuit 1 Circuit 2 Circuit 3

5.5 (21) 5.5 (21) 5.5 (21) 5.5 (21) 5.5 (21) 6 (23)

AWS375ATS Std Eff AWS400ATS Std Eff

438 x 88 x 100

(11123 x 2225 x 2548)

3 / 16 3 / 16 3 / 16 3 / 16 3 / 16 3 / 16

10 (273) 10 (273)

438 x 88 x 100

(11123 x 2225 x 2548)

Air-Cooled Chillers

2010 McQuay Products Catalog 127

Air-Cooled Chillers

AWS 425ATS through AWS 445ATS, Packaged, Standard Efficiency, R-134a

Data

Basic Data

Unit cap. @ AHRI tons (kW) 414.1 (1456.1) 448.2 (1576.1)
Unit operating charge lb (kg) 245 (111) 245 (111) 220 (100) 245 (111) 245 (111) 245 (111)
Unit dimensions

L × W × H, in (mm)
Unit operating weight, lb (kg) 26830 (12170) 27506 (12477)
Unit shipping weight, lb (kg) 25431 (11535) 26107 (11842)
Weight-add for copper fins 3553 (1612) 3553 (1612)
Weight-add for louvered panels 1460 (662) 1460 (662)
Weight-add for sound enclosures 776 (352) 776 (352)

Compressors, Screw, Semi-Hermetic

Nominal capacity, tons (kW) 125 (439) 150 (528) 150 (528) 150 (528) 150 (528) 150 (528)
Minimum capacity (% of full load) 8 8
Oil charge per circuit, gallons (liters)

Condensers, High Efficiency Fin and Tube Type

Pumpdown capacity, lb (kg) 333 (151) 333 (151) 333 (151) 333 (151) 333 (151) 333 (151)
Coil inlet face area, ft
Rows deep/fins per inch

Condenser Fans, Direct Drive Propeller Type

No. of fans/circuit–fan dia., in (mm) 8–31.5 (800) 8–31.5 (800)
Fan motors–hp (kW) / rpm 1.4 (1.05) / 850 1.4 (1.05) / 850
Airflow, cfm (L/s) 266040 (125556) 266040 (125556)

Evaporator, Direct Expansion Shell and Tube

Shell dia. tube length, in (mm) 26 x 130 / (660 x 3300) 26 x 130 / (660 x 3300)
Water volume, gallons (L) 220 (831) 220 (831)
Victaulic inlet/outlet conn. in. (mm)
Max. water / refrig. pressure, psi (kPa) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241)

2 (m2

) 169.9 (18.3) 169.9 (18.3) 169.9 (18.3) 169.9 (18.3) 169.9 (18.3) 169.9 (18.3)

Circuit 1 Circuit 2 Circuit 3 Circuit 1 Circuit 2 Circuit 3

5.5 (21) 6 (23) 6 (23) 6 (23) 6 (23) 6 (23)

3 / 16 3 / 16 3 / 16 3 / 16 3 / 16 3 / 16

AWS425ATS Std Eff

473 x 88 x 100

(12024 x 2225 x 2548)

10 (273) 10 (273)

AWS445ATS Std Eff

473 x 88 x 100

(12024 x 2225 x 2548)

AWS 470ATS through AWS 500ATS, Packaged, Standard Efficiency, R-134a

Data

Basic Data

Unit cap. @ AHRI tons (kW) 478.2 (1681.5) 504.4 (1773.5)

Air-Cooled Chillers

Unit operating charge lb (kg) 245 (111) 245 (111) 275 (125) 275 (125) 275 (125) 245 (111)
Unit dimensions

L × W × H, in (mm)
Unit operating weight, lb (kg) 28631 (12987) 29508 (13385)
Unit shipping weight, lb (kg) 27232 (12352) 28109 (12750)
Weight-add for copper fins 3870 (1755) 4168 (1891)
Weight-add for louvered panels 1572 (713) 1684 (764)
Weight-add for sound enclosures 776 (352) 776 (352)

Compressors, Screw, Semi-Hermetic

Nominal capacity, tons (kW) 150 (528) 150 (528) 175 (615) 175 (615) 175 (615) 150 (528)
Minimum capacity (% of full load) 8 8
Oil charge per circuit, gallons (liters)

Condensers, High Efficiency Fin and Tube Type

Pumpdown capacity, lb (kg) 333 (151) 333 (151) 416 (189) 416 (189) 416 (189) 333 (151)
Coil inlet face area, ft
Rows deep/fins per inch

Condenser Fans, Direct Drive Propeller Type

No. of fans/circuit–fan dia., in (mm) 8–31.5 (800) 8–31.5 (800) 10–31.5 (800) 10–31.5 (800) 10–31.5 (800) 8–31.5 (800)
Fan motors–hp (kW) / rpm 1.4 (1.05) / 850 1.4 (1.05) / 850
Airflow, cfm (L/s) 288210 (136019) 310380 (146482)

Evaporator, Direct Expansion Shell and Tube

Shell dia. tube length, in (mm) 26 x 130 / (660 x 3300) 26 x 130 / (660 x 3300)
Water volume, gallons (L) 220 (831) 220 (831)
Victaulic inlet/outlet conn. in. (mm)
Max. water / refrig. pressure, psi (kPa) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241)

2 (m2

) 169.9 (18.3) 169.9 (18.3) 246.1 (22.8) 246.1 (22.8) 246.1 (22.8) 169.9 (18.3)

Circuit 1 Circuit 2 Circuit 3 Circuit 1 Circuit 2 Circuit 3

6 (23) 6 (23) 6 (23) 6 (23) 6 (23) 6 (23)

3 / 16 3 / 16 3 / 16 3 / 16 3 / 16 3 / 16

AWS470ATS Std Eff

509 x 88 x 100

(12921 x 2225 x 2548)

10 (273) 10 (273)

AWS500ATS Std Eff

544 x 88 x 100

(13823 x 2225 x 2548)

128 2010 McQuay Products Catalog

Air-Cooled Chillers

AWS 530ATS, Packaged, Standard Efficiency, R-134a

Data

Basic Data

Unit cap. @ AHRI tons (kW) 533.9 (1877.1)
Unit operating charge lb (kg) 285 (129) 285 (129) 285 (129)
Unit dimensions

L × W × H, in (mm)
Unit operating weight, lb (kg) 30348 (13766)
Unit shipping weight, lb (kg) 28949 (13131)
Weight-add for copper fins 4466 (2026)
Weight-add for louvered panels 1796 (815)
Weight-add for sound enclosures 776 (352)

Compressors, Screw, Semi-Hermetic

Nominal capacity, tons (kW) 175 (615) 175 (615) 175 (615)
Minimum capacity (% of full load) 8
Oil charge per circuit, gallons (liters)

Condensers, High Efficiency Fin and Tube Type

Pumpdown capacity, lb (kg) 416 (189) 416 (189) 416 (189)
Coil inlet face area, ft
Rows deep/fins per inch

Condenser Fans, Direct Drive Propeller Type

No. of fans/circuit–fan dia., in (mm) 10–31.5 (800) 10–31.5 (800) 10–31.5 (800)
Fan motors–hp (kW) / rpm 1.4 (1.05) / 850
Airflow, cfm (L/s) 332550 (156945)

Evaporator, Direct Expansion Shell and Tube

Shell dia. tube length, in (mm) 26 x 130 / (660 x 3300)
Water volume, gallons (L) 220 (831)
Victaulic inlet/outlet conn. in. (mm)
Max. water / refrig. pressure, psi (kPa) 152 (1048) / 325 (2241)

2 (m2

) 246.1 (22.8) 246.1 (22.8) 246.1 (22.8)

Circuit 1 Circuit 2 Circuit 3

AWS530ATS Std Eff

580 x 88 x 100

(14722 x 2225 x 2548)

6 (23) 6 (23) 6 (23)

3 / 16 3 / 16 3 / 16

10 (273)

Pathfinder Model AWS Air-Cooled Packaged Chiller, High Efficiency—Physical Data

AWS 210ADH through AWS 250ADH, Packaged, High Efficiency, R-134a

Data

Basic Data

Unit cap. @ AHRI tons (kW) 207.0 (727.9) 229.1 (805.4) 246.6 (867.0)
Unit operating charge lb (kg) 180 (82) 180 (82) 200 (90) 220 (100) 220 (100) 220 (100)
Unit dimensions

L × W × H, in (mm)
Unit operating weight, lb (kg) 13411 (6083) 15107 (6852) 15669 (7107)
Unit shipping weight, lb (kg) 12868 (5837) 14564 (6606) 15126 (6861)
Weight-add for copper fins 1876 (851) 2084 (945) 2084 (945)
Weight-add for louvered panels 788 (357) 900 (408) 900 (408)
Weight-add for sound enclosures 477 (216) 477 (216) 477 (216)

Compressors, Screw, Semi-Hermetic

Nominal capacity, tons (kW) 100 (351) 100 (351) 100 (351) 125 (439) 125 (439) 125 (439)
Minimum capacity (% of full load) 15 15 15
Oil charge per circuit, gallons (liters)

Condensers, High Efficiency Fin and Tube Type

Pumpdown capacity, lb (kg) 250 (113) 250 (113) 291 (132) 291 (132) 291 (132) 291 (132)
Coil inlet face area, ft
Rows deep/fins per inch

Condenser Fans, Direct Drive Propeller Type

No. of fans/circuit–fan dia., in (mm) 6–31.5 (800) 7–31.5 (800) 7–31.5 (800)
Fan motors–hp (kW) / rpm 1.4 (1.05) / 850 1.4 (1.05) / 850 1.4 (1.05) / 850
Airflow, cfm (L/s) 133020 (62778) 155190 (73241) 155190 (73241)

Evaporator, Direct Expansion Shell and Tube

Shell dia. tube length, in (mm) 16 x 108 / (406 x 2750) 16 x 108 / (406 x 2750) 16 x 108 / (406 x 2750)
Water volume, gallons (L) 63 (240) 61 (232) 61 (252)
Victaulic inlet/outlet conn. in. (mm)
Max. water / refrig. pressure, psi (kPa) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241)

2 (m2

) 147.7 (13.7) 147.7 (13.7) 172.3 (16.0) 172.3 (16.0) 172.3 (16.0) 172.3 (16.0)

AWS210ADH High Eff AWS230ADH High Eff AWS250ADH High Eff

Circuit 1 Circuit 2 Circuit 1 Circuit 2 Circuit 1 Circuit 2

245 x 88 x 100

(6220 x 2225 x 2548)

4.5 (17) 4.5 (17) 4.5 (17) 5.5 (21) 5.5 (21) 5.5 (21)

3 / 16 3 / 16 3 / 16 3 / 16 3 / 16 3 / 16

6 (168) 6 (168) 6 (168)

280 x 88 x 100

(7121 x 2225 x 2548)

280 x 88 x 100

(7121 x 2225 x 2548)

Air-Cooled Chillers

2010 McQuay Products Catalog 129

Air-Cooled Chillers

AWS 280ADH through AWS 320ADH, Packaged, High Efficiency, R-134a

Data

Basic Data

Unit cap. @ AHRI tons (kW) 271.9 (955.9) 292.3 (1027.9) 327.3 (1150.9)
Unit operating charge lb (kg) 230 (104) 250 (113) 250 (113) 250 (113) 260 (118) 285 (129)
Unit dimensions

L × W × H, in (mm)
Unit operating weight, lb (kg) 17008 (7715) 17008 (7715) 19486 (8839)
Unit shipping weight, lb (kg) 16141 (7322) 16141 (7322) 18619 (8446)
Weight-add for copper fins 2372 (1076) 2372 (1076) 2968 (1346)
Weight-add for louvered panels 1012 (459) 1012 (459) 1236 (561)
Weight-add for sound enclosures 477 (216) 477 (216) 477 (216)

Compressors, Screw, Semi-Hermetic

Nominal capacity, tons (kW) 125 (439) 150 (528) 150 (528) 150 (528) 150 (528) 175 (615)
Minimum capacity (% of full load) 15 15 15
Oil charge per circuit, gallons (liters)

Condensers, High Efficiency Fin and Tube Type

Pumpdown capacity, lb (kg) 333 (151) 333 (151) 333 (151) 333 (151) 416 (189) 416 (189)
Coil inlet face area, ft
Rows deep/fins per inch

Condenser Fans, Direct Drive Propeller Type

No. of fans/circuit–fan dia., in (mm) 8–31.5 (800) 8–31.5 (800) 10–31.5 (800)
Fan motors–hp (kW) / rpm 1.4 (1.05) / 850 1.4 (1.05) / 850 1.4 (1.05) / 850
Airflow, cfm (L/s) 177360 (83704) 177360 (83704) 221700 (104630)

Evaporator, Direct Expansion Shell and Tube

Shell dia. tube length, in (mm) 20 x 108 / (508 x 2750) 20 x 108 / (508 x 2750) 20 x 108 / (508 x 2750)
Water volume, gallons (L) 103 (390) 103 (390) 99 (374)
Victaulic inlet/outlet conn. in. (mm)
Max. water / refrig. pressure, psi (kPa) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241)

2 (m2

) 169.9 (18.3) 169.9 (18.3) 169.9 (18.3) 169.9 (18.3) 246.1 (22.8) 246.1 (22.8)

AWS280ADH High Eff AWS300ADH High Eff AWS320ADH High Eff

Circuit 1 Circuit 2 Circuit 1 Circuit 2 Circuit 1 Circuit 2

316 x 88 x 100

(8022 x 2225 x 2548)

5.5 (21) 5.5 (21) 5.5 (21) 5.5 (21) 5.5 (21) 6 (23)

3 / 16 3 / 16 3 / 16 3 / 16 3 / 16 3 / 16

8 (219) 8 (219) 8 (219)

316 x 88 x 100

(8022 x 2225 x 2548)

387 x 88 x 100

(9823 x 2225 x 2548)

AWS 350ADH through AWS 405ADH, Packaged, High Efficiency, R-134a

Data

Basic Data

Unit cap. @ AHRI tons (kW) 336.6 (1183.7) 365.6 (1286.5) 394.8 (1389.3)

Air-Cooled Chillers

Unit operating charge lb (kg) 285 (129) 285 (129) 285 (129) 331 (150) 331 (150) 331 (150)
Unit dimensions

L × W × H, in (mm)
Unit operating weight, lb (kg) 19656 (8916) 21132 (9585) 21915 (9941)
Unit shipping weight, lb (kg) 18789 (8523) 20265 (9192) 21048 (9547)
Weight-add for copper fins 2968 (1346) 3256 (1477) 3553 (1612)
Weight-add for louvered panels 1236 (561) 1348 (611) 1460 (662)
Weight-add for sound enclosures 477 (216) 477 (216) 477 (216)

Compressors, Screw, Semi-Hermetic

Nominal capacity, tons (kW) 175 (615) 175 (615) 175 (615) 200 (703) 200 (703) 200 (703)
Minimum capacity (% of full load) 15 15 15
Oil charge per circuit, gallons (liters)

Condensers, High Efficiency Fin and Tube Type

Pumpdown capacity, lb (kg) 416 (189) 416 (189) 416 (189) 500 (227) 500 (227) 500 (227)
Coil inlet face area, ft
Rows deep/fins per inch

Condenser Fans, Direct Drive Propeller Type

No. of fans/circuit–fan dia., in (mm) 10–31.5 (800) 10–31.5 (800) 10–31.5 (800) 12–31.5 (800) 12–31.5 (800) 12–31.5 (800)
Fan motors–hp (kW) / rpm 1.4 (1.05) / 850 1.4 (1.05) / 850 1.4 (1.05) / 850
Airflow, cfm (L/s) 221700 (104630) 243870 (115094) 266040 (125556)

Evaporator, Direct Expansion Shell and Tube

Shell dia. tube length, in (mm) 20 x 108 / (508 x 2750) 20 x 108 / (508 x 2750) 20 x 108 / (508 x 2750)
Water volume, gallons (L) 99 (374) 99 (374) 99 (374)
Victaulic inlet/outlet conn. in. (mm)
Max. water / refrig. pressure, psi (kPa) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241)

2 (m2

) 246.1 (22.8) 246.1 (22.8) 246.1 (22.8) 295.3 (27.4) 295.3 (27.4) 295.3 (27.4)

AWS350ADH High Eff AWS380ADH High Eff AWS405ADH High Eff

Circuit 1 Circuit 2 Circuit 1 Circuit 2 Circuit 1 Circuit 2

387 x 88 x 100

(9823 x 2225 x 2548)

6 (23) 6 (23) 6 (23) 6 (23) 6 (23) 6 (23)

3 / 16 3 / 16 3 / 16 3 / 16 3 / 16 3 / 16

8 (219) 8 (219) 8 (219)

438 x 88 x 100

(11123 x 2225 x 2548)

473 x 88 x 101

(12024 x 2225 x 2548)

130 2010 McQuay Products Catalog

Air-Cooled Chillers

AWS 445ATH through AWS 470ATH, Packaged, High Efficiency, R-134a

Data

Basic Data

Unit cap. @ AHRI tons (kW) 439.8 (1546.6) 471.8 (1659.0)
Unit operating charge lb (kg) 250 (113) 250 (113) 250 (113) 250 (113) 250 (113) 295 (134)
Unit dimensions

L × W × H, in (mm)
Unit operating weight, lb (kg) 25590 (11608) 27125 (12304)
Unit shipping weight, lb (kg) 24191 (10973) 25726 (11669)
Weight-add for copper fins 3553 (1612) 3870 (1755)
Weight-add for louvered panels 1460 (662) 1572 (713)
Weight-add for sound enclosures 776 (352) 776 (352)

Compressors, Screw, Semi-Hermetic

Nominal capacity, tons (kW) 150 (528) 150 (528) 150 (528) 150 (528) 150 (528) 175 (615)
Minimum capacity (% of full load) 8 8
Oil charge per circuit, gallons (liters)

Condensers, High Efficiency Fin and Tube Type

Pumpdown capacity, lb (kg) 333 (151) 333 (151) 333 (151) 333 (151) 333 (151) 416 (189)
Coil inlet face area, ft
Rows deep/fins per inch

Condenser Fans, Direct Drive Propeller Type

No. of fans/circuit–fan dia., in (mm) 8–31.5 (800) 8–31.5 (800) 8–31.5 (800) 8–31.5 (800) 8–31.5 (800) 10–31.5 (800)
Fan motors–hp (kW) / rpm 1.4 (1.05) / 850 1.4 (1.05) / 850
Airflow, cfm (L/s) 266040 (125556) 288210 (136019)

Evaporator, Direct Expansion Shell and Tube

Shell dia. tube length, in (mm) 26 x 130 / (660 x 3300) 26 x 130 / (660 x 3300)
Water volume, gallons (L) 225 (850) 220 (831)
Victaulic inlet/outlet conn. in. (mm)
Max. water / refrig. pressure, psi (kPa) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241)

2 (m2

) 169.9 (18.3) 169.9 (18.3) 169.9 (18.3) 169.9 (18.3) 169.9 (18.3) 246.1 (22.8)

Circuit 1 Circuit 2 Circuit 3 Circuit 1 Circuit 2 Circuit 3

AWS445ATH High Eff

473 x 88 x 100

(12024 x 2225 x 2548)

5.5 (21) 5.5 (21) 5.5 (21) 5.5 (21) 5.5 (21) 6 (23)

3 / 16 3 / 16 3 / 16 3 / 16 3 / 16 3 / 16

10 (273) 10 (273)

AWS470ATH High Eff

509 x 88 x 100

(12921 x 2225 x 2548)

AWS 500ATH through AWS 530ATH, Packaged, High Efficiency, R-134a

Data

Basic Data

Unit cap. @ AHRI tons (kW) 493.3 (1734.6) 524.8 (1845.4)
Unit operating charge lb (kg) 295 (134) 295 (134) 250 (113) 295 (134) 295 (134) 295 (134)
Unit dimensions

L × W × H, in (mm)
Unit operating weight, lb (kg) 29098 (13199) 30348 (13766)
Unit shipping weight, lb (kg) 27699 (12564) 28949 (13131)
Weight-add for copper fins 4168 (1891) 4466 (2026)
Weight-add for louvered panels 1684 (764) 1796 (815)
Weight-add for sound enclosures 776 (352) 776 (352)

Compressors, Screw, Semi-Hermetic

Nominal capacity, tons (kW) 175 (615) 175 (615) 150 (528) 175 (615) 175 (615) 175 (615)
Minimum capacity (% of full load) 8 8
Oil charge per circuit, gallons (liters)

Condensers, High Efficiency Fin and Tube Type

Pumpdown capacity, lb (kg) 416 (189) 416 (189) 333 (151) 416 (189) 416 (189) 416 (189)
Coil inlet face area, ft
Rows deep/fins per inch

Condenser Fans, Direct Drive Propeller Type

No. of fans/circuit–fan dia., in (mm) 10–31.5 (800) 10–31.5 (800) 8–31.5 (800) 10–31.5 (800) 10–31.5 (800) 10–31.5 (800)
Fan motors–hp (kW) / rpm 1.4 (1.05) / 850 1.4 (1.05) / 850
Airflow, cfm (L/s) 310380 (146482) 332550 (156945)

Evaporator, Direct Expansion Shell and Tube

Shell dia. tube length, in (mm) 26 x 130 / (660 x 3300) 26 x 130 / (660 x 3300)
Water volume, gallons (L) 220 (831) 220 (831)
Victaulic inlet/outlet conn. in. (mm)
Max. water / refrig. pressure, psi (kPa) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241)

2 (m2

) 246.1 (22.8) 246.1 (22.8) 169.9 (18.3) 246.1 (22.8) 246.1 (22.8) 246.1 (22.8)

Circuit 1 Circuit 2 Circuit 3 Circuit 1 Circuit 2 Circuit 3

AWS500ATH High Eff

544 x 88 x 100

(13823 x 2225 x 2548)

6 (23) 6 (23) 5.5 (21) 6 (23) 6 (23) 6 (23)

3 / 16 3 / 16 3 / 16 3 / 16 3 / 16 3 / 16

10 (273) 10 (273)

AWS530ATH High Eff

580 x 88 x 100

(14722 x 2225 x 2548)

Air-Cooled Chillers

2010 McQuay Products Catalog 131

Air-Cooled Chillers

Pathfinder Model AWS Air-Cooled Packaged Chiller, Premium Efficiency—Physical Data

AWS 210ADP through AWS 250ADP, Packaged, Premium Efficiency, R-134a

Data

Basic Data

Unit cap. @ AHRI tons (kW) 214.7 (755.0) 236.1 (830.1) 255.1 (896.9)
Unit operating charge lb (kg) 200 (91) 200 (91) 225 (102) 225 (102) (235) (107) (235) (107)
Unit dimensions

L × W × H, in (mm)
Unit operating weight, lb (kg) 16812 (7626) 18327 (8313) 20200 (9163)
Unit shipping weight, lb (kg) 15560 (7058) 17075 (7745) 18547 (8413)
Weight-add for copper fins 2372 (1076) 2679 (1215) 2679 (1215)
Weight-add for louvered panels 1012 (459) 1124 (510) 1124 (510)
Weight-add for sound enclosures 477 (216) 477 (216) 477 (216)

Compressors, Screw, Semi-Hermetic

Nominal capacity, tons (kW) 100 (351) 100 (351) 100 (351) 125 (439) 125 (439) 125 (439)
Minimum capacity (% of full load) 15 15 15
Oil charge per circuit, gallons (liters)

Condensers, High Efficiency Fin and Tube Type

Pumpdown capacity, lb (kg) 333 (151) 333 (151) 375 (170) 375 (170) 375 (170) 375 (170)
Coil inlet face area, ft
Rows deep/fins per inch

Condenser Fans, Direct Drive Propeller Type

No. of fans/circuit–fan dia., in (mm) 8–31.5 (800) 9–31.5 (800) 9–31.5 (800)
Fan motors–hp (kW) / rpm 1.4 (1.05) / 850 1.4 (1.05) / 850 1.4 (1.05) / 850
Airflow, cfm (L/s) 177360 (83704) 199530 (94167) 199530 (94167)

Evaporator, Direct Expansion Shell and Tube

Shell dia. tube length, in (mm) 20 x 154 / (508 x 3900) 20 x 154 / (508 x 3900) 26 x 154 / (660 x 3900)
Water volume, gallons (L) 154 (582) 154 (582) 267 (1011)
Victaulic inlet/outlet conn. in. (mm)
Max. water / refrig. pressure, psi (kPa) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241)

2 (m2

) 169.9 (18.3) 169.9 (18.3) 221.5 (20.6) 221.5 (20.6) 221.5 (20.6) 221.5 (20.6)

AWS210ADP Prem Eff AWS230ADP Prem Eff AWS250ADP Prem Eff

Circuit 1 Circuit 2 Circuit 1 Circuit 2 Circuit 1 Circuit 2

316 x 88 x 100

(8022 x 2225 x 2548)

4.5 (17) 4.5 (17) 4.5 (17) 5.5 (21) 5.5 (21) 5.5 (21)

3 / 16 3 / 16 3 / 16 3 / 16 3 / 16 3 / 16

8 (2199 8 (219) 10 (273)

351 x 88 x 100

(8923 x 2225 x 2548)

351 x 88 x 100

(8923 x 2225 x 2548)

AWS 280ADP through AWS 320ADP, Packaged, Premium Efficiency, R-134a

Data

Basic Data

Unit cap. @ AHRI tons (kW) 279.5 (982.7) 301.5 (1060.3) 336.8 (1184.3)

Air-Cooled Chillers

Unit operating charge lb (kg) 250 (113) 250 (113) 260 (118) 260 (118) 260 (118) 300 (136)
Unit dimensions

L × W × H, in (mm)
Unit operating weight, lb (kg) 21068 (9556) 21068 (9556) 22839 (10360)
Unit shipping weight, lb (kg) 19415 (8807) 19415 (8807) 21186 (9610)
Weight-add for copper fins 2968 (1346) 2968 (1346) 3256 (1477)
Weight-add for louvered panels 1236 (561) 1236 (561) 1348 (611)
Weight-add for sound enclosures 477 (216) 477 (216) 477 (216)

Compressors, Screw, Semi-Hermetic

Nominal capacity, tons (kW) 125 (439) 150 (528) 150 (528) 150 (528) 150 (528) 175 (615)
Minimum capacity (% of full load) 15 15 15
Oil charge per circuit, gallons (liters)

Condensers, High Efficiency Fin and Tube Type

Pumpdown capacity, lb (kg) 416 (189) 416 (189) 416 (189) 416 (189) 416 (189) 500 (227)
Coil inlet face area, ft
Rows deep/fins per inch

Condenser Fans, Direct Drive Propeller Type

No. of fans/circuit–fan dia., in (mm) 10–31.5 (800) 10–31.5 (800) 10–31.5 (800) 10–31.5 (800) 10–31.5 (800) 12–31.5 (800)
Fan motors–hp (kW) / rpm 1.4 (1.05) / 850 1.4 (1.05) / 850 1.4 (1.05) / 850
Airflow, cfm (L/s) 221700 (104630) 221700 (104630) 243870 (115093)

Evaporator, Direct Expansion Shell and Tube

Shell dia. tube length, in (mm) 26 x 154 / (660 x 3900) 26 x 154 / (660 x 3900) 26 x 154 / (660 x 3900)
Water volume, gallons (L) 267 (1011) 267 (1011) 254 (963)
Victaulic inlet/outlet conn. in. (mm)
Max. water / refrig. pressure, psi (kPa) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241) 152 (1048) / 325 (2241)

2 (m2

) 246.1 (22.8) 246.1 (22.8) 246.1 (22.8) 246.1 (22.8) 246.1 (22.8) 295.3 (27.4)

AWS280ADP Prem Eff AWS300ADP Prem Eff AWS320ADP Prem Eff

Circuit 1 Circuit 2 Circuit 1 Circuit 2 Circuit 1 Circuit 2

387 x 88 x 100

(9823 x 2225 x 2548)

5.5 (21) 5.5 (21) 5.5 (21) 5.5 (21) 5.5 (21) 6 (23)

3 / 16 3 / 16 3 / 16 3 / 16 3 / 16 3 / 16

10 (273) 10 (273) 10 (273)

387 x 88 x 100

(9823 x 2225 x 2548)

438 x 88 x 100

(11122 x 2225 x 2548)

132 2010 McQuay Products Catalog

Air-Cooled Chillers

AWS 350ADP, Packaged, Premium Efficiency, R-134a

Data

Basic Data

Unit cap. @ AHRI tons (kW) 368.4 (1295.3)
Unit operating charge lb (kg) 310 (141) 310 (141)
Unit dimensions

L × W × H, in (mm)
Unit operating weight, lb (kg) 24140 (10950)
Unit shipping weight, lb (kg) 22487 (10200)
Weight-add for copper fins 3553 (1612)
Weight-add for louvered panels 1460 (662)
Weight-add for sound enclosures 477 (216)

Compressors, Screw, Semi-Hermetic

Nominal capacity, tons (kW) 175 (615) 175 (615)
Minimum capacity (% of full load) 15
Oil charge per circuit, gallons (liters)

Condensers, High Efficiency Fin and Tube Type

Pumpdown capacity, lb (kg) 500 (227) 500 (227)
Coil inlet face area, ft
Rows deep/fins per inch

Condenser Fans, Direct Drive Propeller Type

No. of fans/circuit–fan dia., in (mm) 7–31.5 (800)
Fan motors–hp (kW) / rpm 1.4 (1.05) / 850
Fan tip speed, fpm (m/s) 6984 (35)
Airflow, cfm (L/s) 266040 (125556)

Evaporator, Direct Expansion Shell and Tube

Shell dia. tube length, in (mm) 26 x 154 / (660 x 3900)
Water volume, gallons (L) 254 (963)
Victaulic inlet/outlet conn. in. (mm)
Max. water / refrig. pressure, psi (kPa) 152 (1048) / 325 (2241)

2 (m2

) 295.3 (27.4) 295.3 (27.4)

AWS350ADP Prem Eff

Circuit 1 Circuit 2

473 x 88 x 100

(12024 x 2225 x 2548)

6 (23) 6 (23)

3 / 16 3 / 16

10 (273)

AGS Air-Cooled Screw Comp. Chiller (Remote Evap.), Std. Efficiency—Physical Data

AGS 225DM through 250DM, Remote Evaporator, Standard Efficiency, R-134a

AGS model number

Data

Circuit 1 Circuit 2 Circuit 1 Circuit 2

Basic data

Unit cap. @ ARI conditions, tons (kW)
Unit operating charge, lb (kg)
Cabinet dimensions L × W × H, in (mm) 243 × 88 × 97 (6172 × 2225 × 2464) 279 × 88 × 97 (7087 × 2225 × 2464)
Unit operating weight, lb (kg)
Unit shipping weight, lb (kg)

Compressors, screw, semi-hermetic

Nominal capacity, tons (kW) 100 (350) 100 (350) 100 (350) 125 (437)
Minimum capacity (% of full load)

Condensers, high efficiency fin and tube type with integral subcooler

Pumpdown capacity, lbs (kg) 249 (113) 249 (113) 287 (130) 287 (130)
Coil inlet face area, ft

Condenser fans, direct drive propeller type

No. of fans/circuit–fan dia., in (mm) 6–30 (762)
Fan motor hp (kW) 2.5 (1.8) 2.5 (1.8)
Fan and motor rpm, 60Hz 1140 1140
60 Hz fan tip speed, fpm (m/s) 8954 (45) 8954 (45)
60 Hz total unit airflow, cfm (L/s) 137,328 (64,819) 160,216 (75,622)

Evaporator, direct expansion shell and tube

Shell dia. tube length, in (mm) 16 x 108 (406 x 2750) 16 x 108 (406 x 2750)
Water volume, gallons (L) 65.8 (249.4) 65.8 (249.4)
Max. water pressure, psi (kPa) 152 (1048) 152 (1048)
Max. refrigerant press., psi (kPa) 350 (2413) 350 (2413)

2

2

2

(m2) 129.2 (12.0) 129.2 (12.0) 150.8 (14.0) 150.8 (14.0)

1, 4

3

185 (84) 185 (84) 210 (95) 210 (95)

225DM 250DM

211.2 (742.6) 231.6 (814.3)

10,814 (4905) 11,518 (5224)
10,814 (4905) 11,518 (5224)

13 11

6

–30 (762) 7–30 (762)

7

–30 (762)

Air-Cooled Chillers

2010 McQuay Products Catalog 133

Air-Cooled Chillers

AGS 275DM through 300DM, Remote Evaporator, Standard Efficiency, R-134a

AGS model number

Data

Circuit 1 Circuit 2 Circuit 1 Circuit 2

Basic data

Unit cap. @ ARI conditions, tons (kW) 263.1 (925.1) 297.0 (1042.5)

Unit operating charge, lb (kg) 210 (95) 240 (109) 240 (109) 240 (109)

Cabinet dimensions L × W × H, in (mm) 314 × 88 × 97 (7984 × 2225 × 2464) 314 x 88 x 97 (7984 x 2225 x 2464)

Unit operating weight, lb (kg) 12,226 (5546) 12,226 (5546)

Unit shipping weight, lb (kg) 12,226 (5546) 12,226 (5546)

Compressors, screw, semi-hermetic

Nominal capacity, tons (kW) 125 (437) 150 (525) 150 (525) 150 (525)

Minimum capacity (% of full load)

Condensers, high efficiency fin and tube type with integral subcooler

Pumpdown capacity, lbs (kg) 287 (130) 325 (148) 325 (148) 325 (148)

Coil inlet face area, ft

Condenser fans, direct drive propeller type

No. of fans/circuit–fan dia., in (mm) 8–30 (762)

Fan motor - hp (kW) 2.5 (1.8) 2.5 (1.8)

Fan and motor rpm, 60Hz 1140 1140

60 Hz fan tip speed, fpm (m/s) 8954 (45) 8954 (45)

60 Hz total unit airflow, cfm (L/s) 183,104 (86,425) 183,104 (86,425)

Evaporator, direct expansion shell and tube

Shell dia. tube length, in (mm) 20 x 108 (508 x 2750) 20 x 108 (508 x 2750)

Water volume, gallons (L) 108.5 (411.1) 103.2 (391.2)

Max. water pressure, psi (kPa) 152 (1048) 152 (1048)

Max. refrigerant press., psi (kPa) 350 (2413) 350 (2413)

2

(m2) 150.8 (14.0) 172.5 (16.0) 172.5 (16.0) 172.5 (16.0)

275DM 300DM

11

8

–30 (762) 8–30 (762)

13

8

–30 (762)

AGS 330DM through 360DM, Remote Evaporator, Standard Efficiency, R-134a

AGS model number

Data

Circuit 1 Circuit 2 Circuit 3 Circuit 1 Circuit 2 Circuit 3 Circuit 1 Circuit 2 Circuit 3

Basic data

Unit cap. @ ARI conditions, tons (kW)

Air-Cooled Chillers

Unit operating charge, lb (kg)

Cabinet dimensions L × W × H, in (mm)

Unit operating weight, lb (kg)
Unit shipping weight, lb (kg)

Compressors, screw, semi-hermetic

Nominal capacity, tons (kW) 100 (350) 100 (350) 100 (350) 100 (350) 125 (437) 100 (350) 125 (437) 125 (437) 100 (350)
Minimum capacity, (% of full load)

Condensers, high efficiency fin and tube type with integral subcooler

Pumpdown capacity, lbs (kg) 287 (130) 287 (130) 243 (110) 287 (130) 287 (130) 243 (110) 287 (130) 287 (130) 243 (110)
Coil inlet face area, ft

Condenser fans, direct drive propeller type

No. of fans/circuit–30 in (762 mm) fan dia. 7
Fan motor - hp (kW) 2.5 (1.8) 2.5 (1.8) 2.5 (1.8)
Fan and motor rpm, 60Hz 1140 1140 1140
60 Hz fan tip speed, fpm (m/s) 8954 (45) 8954 (45) 8954 (45)
60 Hz total unit airflow, cfm (L/s) 228,880 (108,031) 228,880 (108,031) 228,880 (108,031)

Evaporator, direct expansion shell and tube

Shell dia. tube length, in (mm) 20 x 108 (508 x 2750) 20 x 108 (508 x 2750) 20 x 108 (508 x 2750)
Water volume, gallons (L) 107.0 (405.4) 107.0 (405.4) 103.2 (391.2)
Max. water pressure, psi (kPa) 152 (1048) 152 (1048) 152 (1048)
Max. refrigerant press., psi (kPa) 350 (2413) 350 (2413) 350 (2413)

3

2

2

2

(m2) 150.8 (14) 150.8 (14) 128.5 (12) 150.8 (14) 150.8 (14) 128.5 (12) 150.8 (14) 150.8 (14) 128.5 (12)

1, 4

210 (95) 210 (95) 190 (86) 210 (95) 210 (95) 190 (86) 210 (95) 210 (95) 190 (86)

330DM 350DM 360DM

318.7 (1120.5) 337.2 (1185.6) 351.1 (1234.5)

403 × 88 × 97

(10,239 × 2225 × 2459)

17,798 (8073) 17,798 (8073) 17,798 (8073)
17,798 (8073) 17,798 (8073) 17,798 (8073)

887

76

403 × 88 × 97

(10,239 × 2225 × 2459)

7

76

403 × 88 × 97

(10,239 × 2225 × 2459)

77

6

134 2010 McQuay Products Catalog

Air-Cooled Chillers

AGS 390DM through 450DM, Remote Evaporator, Standard Efficiency, R-134a

AGS model number

Data

Circuit 1 Circuit 2 Circuit 3 Circuit 1 Circuit 2 Circuit 3 Circuit 1 Circuit 2 Circuit 3

Basic data

Unit cap. @ ARI conditions, tons (kW) 373.2 (1311.8) 390.4 (1373.3) 434.8 (1529.1)
Unit operating charge, lb (kg) 210 (95) 210 (95) 230 (104) 215 (97) 215 (97) 235 (106) 140 (109) 140 (109) 140 (109)

Cabinet dimensions L × W × H, in (mm)

Unit operating weight, lb (kg) 18,632 (8451) 18,632 (8451) 18,632 (8451)
Unit shipping weight, lb (kg) 18,632 (8451) 18,632 (8451) 18,632 (8451)

Compressors, screw, semi-hermetic

Nominal capacity, tons (kW) 125 (437) 125 (437) 125 (437) 125 (437) 125 (437) 150 (525) 150 (525) 150 (525) 150 (525)
Minimum capacity, (% of full load)

Condensers, high efficiency fin and tube type with integral subcooler

Pumpdown capacity, lbs (kg) 287 (130) 287 (130) 316 (144) 287 (130) 287 (130) 316 (144) 287 (130) 287 (130) 316 (144)
Coil inlet face area, ft

Condenser fans, direct drive propeller type

No. of fans/circuit–30 in (762 mm) fan dia. 7
Fan motor - hp (kW) 2.5 (1.8) 2.5 (1.8) 2.5 (1.8)
Fan and motor rpm, 60Hz 1140 1140 1140
60 Hz fan tip speed, fpm (m/s) 8954 (45) 8954 (45) 8954 (45)
60 Hz total unit airflow, cfm (L/s) 251,768 (118,835) 251,768 (118,835) 274,656 (129,637)

Evaporator, direct expansion shell and tube

Shell dia. tube length, in (mm) 20 x 108 (508 x 2750) 20 x 149 (508 x 3785) 20 x 149 (508 x 3785)
Water volume, gallons (L) 103.2 (391.2) 97.2 (368.5) 97.2 (368.5)
Max. water pressure, psi (kPa) 152 (1048) 152 (1048) 152 (1048)
Max. refrigerant press., psi (kPa) 350 (2413) 350 (2413) 350 (2413)

2

(m2) 150.8 (14) 150.8 (14) 171.7 (16) 150.8 (14) 150.8 (14) 171.7 (16) 172.5 (16) 172.5 (16) 171.7 (16)

390DM 400DM 450DM

439 x 88 x 97

(11,140 x 2225 x 2459)

888

78

439 x 88 x 97

(11,140 x 2225 x 2459)

7

78

474 x 88 x 97

(12,040 x 2225 x 2459)

88

8

AGS Air-Cooled Screw Comp. Chiller (Remote Evap.), High Efficiency—Physical Data

AGS 225DF through 260DF, Remote Evaporator, High Efficiency, R-134a

AGS model number

Data

Circuit 1 Circuit 2 Circuit 1 Circuit 2 Circuit 1 Circuit 2

Basic data

Unit cap. @ ARI conditions, tons (kW)
Unit operating charge, lb (kg)

Cabinet dimensions L × W × H, in (mm)

Unit operating weight, lb (kg)
Unit shipping weight, lb (kg)

Compressors, screw, semi-hermetic

Nominal capacity, tons (kW) 100 (350) 100 (350) 100 (350) 125 (437) 125 (437) 125 (437)
Minimum capacity (% of full load)

Condensers, high efficiency fin and tube type with integral subcooler

Pump capacity, lbs (kg) 249 (113) 249 (113) 287 (130) 287 (130) 325 (147) 325 (147)
Coil inlet face area, ft

Condenser fans, direct drive propeller type

No. of fans/circuit–30 in (762 mm) fan dia. 7
Fan motor hp (kW) 2.5 (1.8) 2.5 (1.8) 2.5 (1.8)
Fan and motor rpm, 60Hz 1140 1140 1140
60 Hz fan tip speed, fpm (m/s) 8954 (45) 8954 (45) 8954 (45)
60 Hz total unit airflow, cfm (L/s) 160,216 (75,622) 183,104 (86,425) 183,104 (86,425)

Evaporator, direct expansion shell and tube

Shell dia. tube length, in (mm) 16 x 108 (406 x 2750) 16 x 108 (406 x 2750) 20 x 108 (508 x 2750)
Water volume, gallons (L) 63.6 (241) 63.6 (241) 108.5 (411.1)
Max. water pressure, psi (kPa) 152 (1048) 152 (1048) 152 (1048)
Max. refrigerant press., psi (kPa) 350 (2413) 350 (2413) 350 (2413)

2

2

2

(m2) 150.8 (14) 150.8 (14) 150.8 (14) 172.5 (16) 172.5 (16) 172.5 (16)

1, 4

3

210 (95) 210 (95) 210 (95) 210 (95) 240 (109) 240 (109)

225DF 250DF 260DF

214.9 (755.6) 235.5 (828.0) 249.6 (877.6)

279 x 88 × 97

(7087 x 2225 x 2464)

11,518 (5224) 12,226 (5546) 12,226 (5546)
11,518 (5224) 12,226 (5546) 12,226 (5546)

13 11 13

7

314 × 88 × 97

(7984 × 2225 × 2464)

8

8

314 × 88 × 97

(7984 × 2225 × 2464)

8

8

Air-Cooled Chillers

2010 McQuay Products Catalog 135

Air-Cooled Chillers

AGS 275DF through 300DF, Remote Evaporator, High Efficiency, R-134a

AGS model number

Data

Circuit 1 Circuit 2 Circuit 1 Circuit 2

Basic data

Unit cap. @ ARI conditions, tons (kW) 267.6 (940.9) 299.5 (1053)
Unit operating charge, lb (kg) 240 (109) 260 (118) 265 (120) 265 (120)
Cabinet dimensions L × W × H, in (mm) 350 x 88 x 97 (8890 x 2225 x 2464) 350 x 88 x 97 (8890 x 2225 x 2464)
Unit operating weight, lb (kg) 13,027 (5909) 13,027 (5909)
Unit shipping weight, lb (kg) 13,027 (5909) 13,027 (5909)

Compressors, screw, semi-hermetic

Nominal capacity, tons (kW) 125 (437) 150 (525) 150 (525) 150 (525)
Minimum capacity (% of full load) 11 13

Condensers, high efficiency fin and tube type with integral subcooler

Pumpdown capacity, lbs (kg) 325 (147) 361 (164) 361 (164) 361 (164)
Coil inlet face area, ft

Condenser fans, direct drive propeller type

No. of fans/circuit–30 in (762 mm) fan dia. 9
Fan motor - hp (kW) 2.5 (1.8) 2.5 (1.8)
Fan and motor rpm, 60Hz 1140 1140
60 Hz fan tip speed, fpm (m/s) 8954 (45) 8954 (45)
60 Hz total unit airflow, cfm (L/s) 205,992 (97,228) 205,992 (97,228)

Evaporator, direct expansion shell and tube

Shell dia. tube length, in (mm) 20 x 108 (508 x 2750) 20 x 108 (508 x 2750)
Water volume, gallons (L) 108.5 (411.1) 103.2 (391.2)
Max. water pressure, psi (kPa) 152 (1048) 152 (1048)
Max. refrigerant press., psi (kPa) 350 (2413) 350 (2413)

2

(m2) 172.5 (16) 194.2 (18) 194.2 (18) 194.2 (18)

275DF 300DF

9

9

9

AGS 330DF through 350DF, Remote Evaporator, High Efficiency, R-134a

AGS model number

Data

Circuit 1 Circuit 2 Circuit 3 Circuit 1 Circuit 2 Circuit 3

Basic data

Unit cap. @ ARI conditions, tons (kW)
Unit operating charge, lb (kg)

Cabinet dimensions L × W × H, in (mm)

Air-Cooled Chillers

Unit operating weight, lb (kg)
Unit shipping weight, lb (kg)

Compressors, screw, semi-hermetic

Nominal capacity, tons (kW) 100 (350) 100 (350) 100 (350) 100 (350) 125 (437) 100 (350)
Nominal capacity, (% of full load)

Condensers, high efficiency fin and tube type with integral subcooler

Pumpdown capacity, lbs (kg) 287 (130) 287 (130) 316 (144) 325 (147) 325 (147) 316 (144)
Coil inlet face area, ft

Condenser fans, direct drive propeller type

No. of fans/circuit–30 in (762 mm) fan dia. 7
Fan motor - hp (kW) 2.5 (1.8) 2.5 (1.8)
Fan and motor rpm, 60Hz 1140 1140
60 Hz fan tip speed, fpm (m/s) 8954 (45) 8954 (45)
60 Hz total unit airflow, cfm (L/s) 251,768 (118,834) 274,656 (129,638)

Evaporator, direct expansion shell and tube

Shell dia. tube length, in (mm) 20 x 108 (508 x 2750) 20 x 108 (508 x 2750)
Water volume, gallons (L) 103.2 (391.2) 102.1 (387)
Max. water pressure, psi (kPa) 152 (1048) 152 (1048)
Max. refrigerant press., psi (kPa) 350 (2413) 350 (2413)

3

2

2

2

(m2) 150.8 (14) 150.8 (14) 171.7 (16) 150.8 (14) 172.5 (16) 171.7 (16)

1, 4

210 (95) 210 (95) 230 (104) 210 (95) 240 (109) 240 (109)

330DF 350DF

324.1 (1139.6) 342.9 (1205.6)

439 x 88 x 97

11,140 x 2225 x 2459)

18,632 (8451) 19,305 (8757)
18,632 (8451) 19,305 (8757)

88

78

8

474 x 88 x 97

(12,040 x 2225 x 2459)

88

136 2010 McQuay Products Catalog

Air-Cooled Chillers

AGS 400DF through 450DF, Remote Evaporator, High Efficiency, R-134a

AGS model number

Data

Circuit 1 Circuit 2 Circuit 3 Circuit 1 Circuit 2 Circuit 3

Basic data

Unit cap. @ ARI conditions, tons (kW) 397.1 (1396.6) 438.0 (1540.0)
Unit operating charge, lb (kg) 240 (109) 240 (109) 240 (109) 270 (122) 270 (122) 240 (109)

Cabinet dimensions L × W × H, in (mm)

Unit operating weight, lb (kg) 19,305 (8757) 20,294 (9205)
Unit shipping weight, lb (kg) 19,305 (8757) 20,383 (9205)

Compressors, screw, semi-hermetic

Nominal capacity, tons (kW) 125 (437) 125 (437) 150 (525) 150 (525) 150 (525) 150 (525)
Minimum capacity (% of full load)

Condensers, high efficiency fin and tube type with integral subcooler

Pumpdown capacity, lbs (kg) 325 (147) 325 (147) 316 (144) 361 (164) 361 (164) 316 (144)
Coil inlet face area, ft

Condenser fans, direct drive propeller type

No. of fans/circuit–30 in (762 mm) fan dia. 8 8
Fan motor - hp (kW) 2.5 (1.8) 2.5 (1.8)
Fan and motor rpm, 60Hz 1140 1140
60 Hz fan tip speed, fpm (m/s) 8954 (45) 8954 (45)
60 Hz total unit airflow, cfm (L/s) 274,656 (129,638) 297,544 (140,440)

Evaporator, direct expansion shell and tube

Shell dia. tube length, in (mm) 20 x 142 (508 x 3600) 20 x 142 (508 x 142)
Water volume, gallons (L) 90.5 (343) 90.5 (343.0)
Max. water pressure, psi (kPa) 152 (1048) 152 (1048)
Max. refrigerant press., psi (kPa) 350 (2413) 350 (2413)

2

(m2) 172.5 (16) 172.5 (16) 171.7 (16) 172.5 (16.0) 194.2 (18) 171.7 (16)

400DF 450DF

474 x 88 x 97

(12,040 x 2225 x 2459)

8

8

9

509 x 88 x 97

12,939 x 2225 x 2459)

7

98

Air-Cooled Chillers

2010 McQuay Products Catalog 137
