McIntosh XRT30 User Manual

XRT30 Loudspeaker System
Owner’s Manual
XRT30
McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903-2699 Phone: 607-723-3512 FAX: 607-724-0549
WARNING - TO REDUCE RISK OF
FIRE OR ELECTRICAL SHOCK, DO
NOT EXPOSE THIS EQUIPMENT TO
RAIN OR MOISTURE.
IMPORTANT SAFETY
PLEASE READ THEM BEFORE
OPERATING THIS EQUIPMENT.
NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO
QUALIFIED PERSONNEL.
General:
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Warning: To reduce risk of fire or electrical shock, do not expose this equipment to rain or moisture. This unit is capable of producing high sound pres­sure levels. Continued exposure to high sound pres­sure levels can cause permanent hearing impair­ment or loss. User caution is advised and ear pro­tection is recommended when playing at high vol­umes.
6. Only use attachments/accessories specified by the manufacturer.
Installation:
7. Install in accordance with the manufacturer’s instruc­tions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other equipment (including amplifiers) that produce heat.
9. Do not use this equipment near water.
10. Do not expose this equipment to dripping or splashing and ensure that no objects filled with liquids, such as vases, are placed on the equipment.
11. Use only with the cart, stand, tripod, bracket, or table specified by the manufac­turer, or sold with the equipment. When a cart is used, use caution when moving the cart/equipment combination to avoid in­jury from tip-over.
Care of Equipment:
12. Clean only with a dry cloth.
13. Do not permit objects or liquids of any kind to be pushed, spilled and/or fall into the equipment through enclosure openings.
Repair of Equipment:
14. Refer all servicing to qualified service personnel. Ser­vicing is required when the equipment has been dam­aged in any way, liquid has been spilled or objects have fallen into the equipment, the equipment has been ex­posed to rain or moisture, does not operate normally, or has been dropped.
15. Do not attempt to service beyond that described in the operating instructions. All other service should be re­ferred to qualified service personnel.
16. When replacement parts are required, be sure the ser­vice technician has used replacement parts specified by McIntosh or have the same characteristics as the origi­nal part. Unauthorized substitutions may result in fire, electric shock, or other hazards.
17. Upon completion of any service or repairs to this prod­uct, ask the service technician to perform safety checks to determine that the product is in proper operating condition.
2
Thank You
Table of Contents
Your decision to own this McIntosh XRT30 Loudspeaker System ranks you at the very top among discriminating music listeners. You now have “The Best.” The McIntosh dedication to “Quality,” is assurance that you will receive many years of musical enjoyment from this unit.
Please take a short time to read the information in this manual. We want you to be as familiar as possible with all the features and functions of your new McIntosh.
Please Take A Moment
The serial number, purchase date and McIntosh Dealer name are important to you for possible insurance claim or future service. The spaces below have been provided for you to record that information:
Serial Number:
Purchase Date:
Dealer Name:
Technical Assistance
If at any time you have questions about your McIntosh product, contact your McIntosh Dealer who is familiar with your McIntosh equipment and any other brands that may be part of your system. If you or your Dealer wish ad­ditional help concerning a suspected problem, you can re­ceive technical assistance for all McIntosh products at:
McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903 Phone: 607-723-1545 Fax: 607-723-3636
Customer Service
If it is determined that your McIntosh product is in need of repair, you can return it to your Dealer. You can also return it to the McIntosh Laboratory Service Department. For as­sistance on factory repair return procedure, contact the McIntosh Service Department at:
McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903 Phone: 607-723-3515 Fax: 607-723-1917
Copyright 2002 by McIntosh Laboratory, Inc.
Safety Instructions ............................................................. 2
Thank You and Please Take a Moment ............................. 3
Technical Assistance and Customer Service ..................... 3
Table of Contents and Important Information ................... 3
Introduction ....................................................................... 4
Performance Features ........................................................ 5
Dimensions ........................................................................ 6
Installation ....................................................................... 10
How to Connect using a single amplifier ........................ 12
How to Connect using two amplifiers............................. 14
How to Connect using three amplifiers........................... 16
Specifications .................................................................. 18
Packing Instruction .......................................................... 19
Important Information
Caution: The XRT30 Bass Section Cabinet weight is 192
pounds (87.1kg) and the High Frequency Column weight is 82 pounds (37.20kg) net. It requires two or more persons to safely handle each section.
1. It is very important that Loudspeaker Cables of adequate size be used, to ensure that there will be no power loss or heating. Cable size is specified in Gauge numbers or AWG (American Wire Gauge). The smaller the Gauge number, the larger the wire size:
If the Loudspeaker Cables are 25 feet (7.62m) or less, use at least 18 Gauge (AWG) wire size or larger. If the Loudspeaker Cables are 50 feet (38.1m) or less, use at least 14 Gauge (AWG) wire size or larger. If the Loudspeaker Cables are 100 feet (76.2m) or less, use at least 12 Gauge (AWG) wire size or larger. The Loudspeaker Connection Terminals can accept up to 12 Gauge (AWG) wire.
2. For additional connection information, refer to the owner’s manual(s) for any component(s) connected to the XRT30 Loudspeaker.
3. The XRT30 has built-in speaker protection in the form of six automatic resetting solid-state devices as part of the crossover networks. Two protect the tweeters, one for the midranges and three for the woofers. The characteristics of this protection are that a certain amount of overdrive is allowed but extended periods of overdrive will trigger protection. If an obvious lack of high, mid or low frequencies is noticed, the Loudspeaker Protection Device may have activated. The protection devices will automatically reset when the volume control is reduced significantly and kept low until the output of the affected Loudspeaker Element returns to normal.
4. When the XRT30 Loudspeaker System is driven by more than one amplifier, the output levels of the different amplifiers connected to the Loudspeaker System must be adjusted to achieve a proper balance between the low, midrange and high frequencies reproduced. This adjustment is best achieved through the use of audio test equipment operated by a qualified installer.
3
Introduction
McIntosh Acoustic Engineers have refined the line source Column Loudspeaker concept to provide superior quality midrange and high frequency sound reproduction in a full range system.
The High Fre­quency Section utilizes a patented Column Design
1
with multiple four inch Midrange LD/HP2 Magnetic Circuit Design Drivers and one
Figure 1
inch soft dome Tweeters. Refer to figure 1. Since the audio power fed to a column is distributed among all the drivers, each driver does not have to work as hard, resulting in greater power handling capability and a dramatic reduction in distortion. The Sound Waves from the Column produce a Cylindrical Wave Front with a stable symmetrical hori­zontal sound dispersion to minimize undesirable floor and ceiling re­flections that could detract from a stable sound im­age. Refer to figure 2. In the illus-
Figure 2
tration the Loudspeaker on the left side produces a Cylindrical Wave Front and the Loudspeaker on the right side produces a conventional Spherical Wave Front.
The Low Frequency Section of the System consists of two 12 inch Woofers. They have a large magnet assembly and long cone ex­cursions with very low levels of har­monic dis­tortion and frequency response down to 16Hz. Re­fer to fig-
1
COLUMN Pat. No. 4,267,405 2LD/HP Pat. No. 5,151,943
Figure 3
ure 3. The Woofer also incor-
LD/HP
porates McIntosh’s Patented LD/HP
2
Magnetic Circuit De-
Conventional
sign with shielding to greatly reduce any external magnetic field. Extensive investigating and testing resulted in a new design concept which utilizes a pair of aluminum shorting sleeves in the magnetic cir-
Figure 4
cuit. Refer to figure 4. The sleeves virtually eliminate the negative influence of the fluctuating voice coil field on the permanent magnet field. This results in lower distortion due to more linear mag­netic flux in the voice coil gap. Re­fer to figure 5. Ad­ditional benefits are less volume com­pression due to im­proved heat transfer
Figure 5
through the sleeves and a cooler operating voice coil. Both measurements, as well as critical listening, reveal ten times less distortion than previous designs. A good example of this low distortion is incredible smoothness and clarity in the reproduction of the human voice.
The Crossover Networks used in the XRT30 Loud­speaker Sys­tem are de­signed to en­sure an even frequency re­sponse over the entire au­dible range. The Low Fre­quency Cross­over Network is a Third Or­der design uti­lizing Capaci­tors and In­ductors with high current
Figure 6
capacity. Refer to figure 6. There are three different types of low loss (DCR) Inductors in the network, each one cho­sen not to exhibit any core saturation even at high power
4
levels. This prevents the addition of distortion to the music at low frequencies. The High Frequency Crossover Net­work utilizes both Second and Third Order Crossover Designs. Refer to figure 7. It also uses Capacitors and In­ductors with high current capacity. The Capacitors used include low loss (ESR) Polypro­pylene and Mylar types. Both Cross­over Networks also utilize self resetting high current Poly­Switches to provide an extra measure of protection.
The enclosures are an important part of the XRT30 Loudspeaker System. The Bass Section Cabinet is con­structed from 1 inch and 1-1/2 inch thick MDF with laminated hard­woods and veneers. Internally, the cabi­net is reinforced with multiple MDF Cross-Bracing Trusses all de­signed to help in­sure that the cabi­net will not vibrate. Refer to figure 8. The High Fre­quency Column Section utilizes a massive extruded aluminum enclosure that houses the 30 four inch Midrange and 25 one inch Tweeter Drivers. Refer to figure 9. It also has multiple front to back internal braces to form a dampened rigid Column Struc­ture. The Column’s small footprint allows for a variety of different placements in a room.
Figure 7
Figure 8
Figure 9
Introduction and Performance Features
Performance Features
Patented LD/HP Technology
The McIntosh Low Frequency and Midrange Loudspeaker Elements feature the patented LD/HP Magnetic Circuit Design. This design, when compared to conventional Loudspeaker Elements, reduces distortion significantly. It also increases power handling and efficiency.
Neodymium-Iron-Boron Alloy Magnets
The 30 four inch Midranges and 25 one inch Dome Tweet­ers all use this Alloy. The Neodymium-Iron-Boron Alloy has a high flux density per unit of volume and helps to keep the Column weight to a minimum.
Shielded Magnetic Field
The XRT30 may be used in Home Theater Installations near a television receiver or monitor without causing the television image to degrade. McIntosh has designed special shielding around the magnetic structure of the XRT30 Loudspeaker Elements to prevent interference.
High Power Handling
The Loudspeaker Elements and Crossover Components of the XRT30 are all chosen for use with powerful amplifiers up to 1,200 watts.
Superior Imaging
Locating the Column of Tweeters between the two Columns of Midranges helps to generate a symmetrical horizontal polar response for superior imaging.
Versatile Operation and Placement
In additional to the regular connections, the XRT30 Loud­speaker System provides separate connections for Bi-Am­plification and Tri-Amplification hookups. The Crossover Network has provisions to ensure the best performance when the High Frequency Column is mounted in a wall.
Gold Plated Input Connectors
The XRT30 input connectors are gold plated for superior corrosion resistance and high electrical conductivity.
5
XRT30 Bass Section Dimensions
The following dimensions can assist in determining the best location for your XRT30 Loudspeaker System.
Top View of the XRT30 Bass Section
17"
43.18cm
37-
3/4
95.88cm
Side View of the XRT30 Bass Section
17"
43.18cm
"
17"
43.18cm
14"
1"
2.54cm
35.56cm
Front View of the XRT30 Bass Section
14
-7/8
"
37.78cm
14"
35.56cm
31-
15/16
"
81.12cm
1
-3/4
"
4.45cm
1
-5/8
"
4.13cm
18
-5/8
"
47.31cm
6
37-
1/2
"
95.25cm
14
-7/8
37.78cm
20
-1/4
51.44cm
"
"
