McCulloch Li 58GB operation manual

Li 58GB

EN Operator's manual

2-12

BHB58VPR

Contents

INTRODUCTION............................................................	2
SAFETY..........................................................................	3
ASSEMBLY....................................................................	7
OPERATION...................................................................	7

MAINTENANCE..............................................................	9
TROUBLESHOOTING....................................................	9
TECHNICAL DATA.......................................................	10
CONTENTS OF THE EC DECLARATION OF
CONFORMITY..............................................................	11

INTRODUCTION

Operator's manual

The initial language of this operator's manual is English. Operator's manuals in other languages are translations from English.

Overview

1.	Battery pack	18. Operator's manual
2.	Battery pack charger	Symbols on the product
3.	Battery status button	Symbols on the product
3.	Battery status button
4.	Battery state of charge LEDs
5.	Nozzle
6.	Blower tube	Warning

7.Tab

8.Digital cruise control

	9. Trigger
	10. Rear handle	Read this manual.
	11. Digital control center	Read this manual.
	11. Digital control center
	12. Power meter
	13. Power boost button
	14. Power button	Use approved head protection
	15. Battery release button	Use approved head protection
	15. Battery release button
	16. Air vent
	17. Electrical powerhead

2	451 - 002 - 20.11.2017

Use approved hearing protection

Use approved eye protection

Use approved protective boots and gloves

Look out for thrown objects and ricochets.

Keep hair above shoulders

Do not wear jewelry when you operate the product

Safe distance

Electrical shock

Guaranteed sound power level

The product or packaging cannot be handled as domestic waste. The product and packaging must be submitted to an appropriate recycling station for the recovery of electrical and electronic equipment.

Do not leave, store or use in the rain or in wet conditions.

Recycle

Note Other symbols/decals on the product refer to certification requirements for other commercial areas.

Product liability

As referred to in the product liability laws, we are not liable for damages that our product causes if:

•the product is incorrectly repaired.

•the product is repaired with parts that are not from the manufacturer or not approved by the manufacturer.

•the product has an accessory that is not from the manufacturer or not approved by the manufacturer.

•the product is not repaired at an approved service center or by an approved authority.

SAFETY

Safety definitions

The definitions below give the level of severity for each signal word.

WARNING Injury to persons.

CAUTION Damage to the product.

Note This information makes the product easier to use.

General power tool safety warnings

WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

Work area safety

•Keep work area clean and well lit. Cluttered or dark areas invite accidents.

•Do not operate power tools in explosive atmospheres, such as in the presence of flammable

451 - 002 - 20.11.2017

liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.

•Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

Electrical safety

•Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.

•Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.

•Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.

•Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.

•When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.

•If operating a power tool in a damp location is unavoidable, use a ground fault circuit interrupter (GFCI) protected supply. Use of a GFCI reduces the risk of electric shock.

Personal safety

•Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.

•Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.

•Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.

•Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.

•Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.

•Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away

from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.

•If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.

Power tool use and care

•Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.

•Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.

•Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.

•Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.

•Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.

•Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.

•Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.

Battery tool use and care

•Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack.

•Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.

•When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.

•Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes,

4	451 - 002 - 20.11.2017

additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.

Service

•Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.

Blower safety warnings

•To decrease the risk of electrical shock, do not use the product on wet surfaces or in the rain.

•Keep the product indoors during storage.

•Do not let the product be used as a toy. Do not let children near the product.

•Obey the instructions in this manual. Only use approved attachments.

•If the product has been damaged, fallen into water, left outdoors, or does not operate correctly, speak to an approved service center.

•Do not use the product with wet hands.

•Do not put objects into the openings. Do not use with a blocked opening.

•Keep free of dust, lint, hair and anything that may decrease air flow.

•Keep hair, jewelry, loose clothing, fingers, and all body parts away from the openings and moving parts.

•Be careful when you use the product on stairs.

General safety instructions

•Use the product correctly. Injury or death is a possible result of incorrect use. Only use the product for the tasks found in this manual. Do not use the product for other tasks.

•Obey the instructions in this manual. Obey the safety symbols and the safety instructions. If the operator does not obey the instructions and the symbols, injury, damage or death is a possible result.

•Do not discard this manual. Use the instructions to assemble, to operate and to keep your product in good condition. Use the instructions for correct installation of attachments and accessories. Only use approved attachments and accessories.

•Do not use a damaged product. Obey the maintenance schedule. Only do the maintenance work that you find an instruction about in this manual. An approved service center must do all other maintenance work.

•This manual cannot include all situations that can occur when you use the product. Be careful and use your common sense. Do not operate the product or do maintenance to the product if you are not sure about of the situation. Speak to a product expert, your dealer, service agent or approved service center for information.

•Remove the battery pack before you assemble the product, put the product into storage or do maintenance.

•Do not use the product if it is changed from its initial specification. Do not change a part of the product without approval from the manufacturer. Only use parts that are approved by the manufacturer. Injury or death is a possible result of incorrect maintenance.

•Do not start the product indoors or near flammable material.

•The motor makes an electromagnetic field when you use the product. The electromagnetic field can cause damage to medical implants. Speak to your physician and medical implant manufacturer before you operate the product.

•Do not let a child operate the product. Do not let a person, without knowledge of the instructions operate the product.

•Make sure that you always monitor a person, with decreased physical capacity or mental capacity, that uses the product. A responsible adult must always be.

•Lock the product in an area that children and not approved persons cannot access.

•The product can eject objects and cause injuries. Obey the safety instructions to decrease the risk of injury or death.

•Do not go away from the product when the motor is on.

•The operator of the product is responsible if an accident occurs.

•Make sure that parts are not damaged before you use the product.

•Make sure that you are a safe distance away from other persons or animals before you use the product. Make sure that a person in adjacent area knows that you will use the product.

•Refer to national or local laws. They can prevent or decrease the operation of the product in some conditions.

Safety instructions for operation

•Use the product only for the blowing or removal of leaves and other unwanted material on the ground.

•Do not let bystanders or animals be less than 15 m (50 ft) from the operator.

•This product can eject objects at high speed that can ricochet in the direction of the operator. This can cause eye damage.

•Hold the product as shown.
