Maxtor DiamondMax 6800 User Manual

HARD DRIVE P RODUCT MANUAL
DiamondMax™6800
92720U8, 92040U6, 91700U5 91360U4, 91020U3, 90845U3 and 90650U2
92720U8, 92040U6, 91700U5, 91360U4, 91020U3, 90845U3 and 90650U2
Part #1416
All material contained herein Copyright © 1999 Maxtor Corporation. DiamondMax™, DiamondMax™ 4320, DiamondMax™ 6800, DiamondMax™ Plus 5120 and MaxFax™ are trademarks of Maxtor Corporation. No Quibble® Service is a registered trademark of Maxtor Corporation. Other brands or products are trademarks or registered trademarks of their respective holders. Contents and specifications subject to change without notice. All rights reserved.
Corporate Headquarters
510 Cottonwood Drive Milpitas, California 95035
Tel: 408-432-1700 Fax: 408-432-4510
Research and Development Engineering Center
2190 Miller Drive Longmont, Colorado 80501
Tel: 303-651-6000 Fax: 303-678-2165
Before Y ou Begin
Thank you for your interest in the Maxtor DiamondMax™ 6800 AT hard disk drives. This manual provides technical information for OEM engineers and systems integrators regarding the installation and use of DiamondMax hard drives.
the Maxtor Customer Service Center at 800-2MAXTOR or 408-922-2085.
Before unpacking the hard drive, please review Sections 1 through 4.
Drive repair should be performed only at an authorized repair center. For repair information, contact
CAUTION
Maxtor DiamondMax 6800 hard drives are precision products. Failure to
follow these precautions and guidelines outlined here may lead to
product failure, damage and invalidation of all warranties.
1
2 3
4
5
BEFORE unpacking or handling a drive, take all proper electro-static discharge (ESD) precautions, including personnel and equipment grounding. Stand-alone drives are sensitive to ESD damage.
BEFORE removing drives from their packing material, allow them to reach room temperature.
During handling, NEVER drop, jar, or bump a drive.
Once a drive is removed from the Maxtor shipping container, IMMEDIATELY secure the drive through its mounting holes within a chassis. Otherwise, store the drive on a padded, grounded, antistatic surface.
NEVER switch DC power onto the drive by plugging an electrically live DC source cable into the drive's connector. NEVER connect a live bus to the drive's interface connector.
Please do not remove or cover up Maxtor factory-installed drive labels.
They contain information required should the drive ever need repair.
DIAMONDMAX 6800 PRODUCT MANUAL
Contents
Section 1 Introduction
Maxtor Corporation 1 - 1
Products 1 - 1
Support 1 - 1 Manual Organization 1 - 1 Abbreviations 1 - 1 Conventions 1 - 2
Key Words 1 - 2
Numbering 1 - 2
Signal Conventions 1 - 2
Section 2 Product Description
The DiamondMax 6800 Product Features 2 - 2
Functional/Interface 2 - 2
Zone Density Recording 2 - 2 Read/Write Multiple Mode 2 - 2 UltraDMA - Mode 2 2 - 2 Multi-word DMA (EISA Type B) - Mode 2 2 - 2 Sector Address Translation 2 - 2 Logical Block Addressing 2 - 3 Defect Management Zone 2 - 3 On-the-Fly Hardware Error Correction Code (ECC) 2 - 3 Software ECC Correction 2 - 3 Automatic Head Park and Lock Operation 2 - 3
Cache Management 2 - 4
Buffer Segmentation 2 - 4
Read-Ahead Mode 2 - 4
Automatic Write Reallocation (AWR) 2 - 4
Write Cache Stacking 2 - 4 Major HDA Components 2 - 5
Drive Mechanism 2 - 5
Rotary Actuator 2 - 5
Read/Write Electronics 2 - 5
Read/Write Heads and Media 2 - 5
Air Filtration System 2 - 5
Microprocessor 2 - 5 Subsystem Configuration 2 - 6
Dual Drive Support 2 - 6
Cable Select Option 2 - 6 Jumper Location/Configuration 2 - 6
4092 Cylinder Limitation 2 - 6
i
DIAMONDMAX 6800 PRODUCT MANUAL
Section 3 Product Specifications
Models and Capacities 3 - 1 Drive Configuration 3 - 1 Performance Specifications 3 - 1 Physical Dimensions 3 - 2 Power Requirements 3 - 3 Power Mode Definitions 3 - 3
Spin-up 3 - 3 Seek 3 - 3 Read/Write 3 - 3 Idle 3 - 3 Standby 3 - 3
Sleep 3 - 3 EPA Energy Star Compliance 3 - 3 Environmental Limits 3 - 3 Shock and Vibration 3 - 4 Reliability Specifications 3 - 4
Annual Return Rate 3 - 4
Quality Acceptance Rate 3 - 4
Start/Stop Cycles 3 - 4
Data Reliability 3 - 4
Component Design Life 3 - 4 EMC/EMI 3 - 5
EMC Compliance 3 - 5
Canadian Emissions Statement 3 - 5 Safety Regulatory Compliance 3 - 5
Section 4 Handling and Installation
Pre-formatted Drive 4 - 1 Important Notice 4 - 1 Hard Drive Handling Precautions 4 - 1 Electro-Static Discharge (ESD) 4 - 1 Unpacking and Inspection 4 - 2 Repacking 4 - 3 Physical Installation 4 - 3 Before You Begin 4 - 4
Please Read 4 - 4
Handling Precautions 4 - 4
Tools for Installation 4 - 4
Drive Identification Information 4 - 4
Capacity Barriers 4 - 4
Protecting Your Existing Data 4 - 4 General Requirements 4 - 5
System Hardware Requirements 4 - 5
BIOS Requirements 4 - 5
ii
DIAMONDMAX 6800 PRODUCT MANUAL
Ultra Direct Memory Access (UDMA) 4 - 5 OS Requirements for Large Capacity Hard Drives 4 - 5
Hard Drive Identification 4 - 6
Identifying IDE Devices on the Interface 4 - 6 Jumper Settings 4 - 6 Systems Using Cable Select 4 - 6
Relationship to Other IDE Devices 4 - 6 Mounting Drive in System 4 - 7 Attaching Interface and Power Cables 4 - 7 Attaching System Cables 4 - 7 System Setup 4 - 8
Setting the BIOS (CMOS) 4 - 8
BIOS (CMOS) Parameters 4 - 8 Hard Drive Preparation 4 - 10 System Hangs During Boot 4 - 12
Section 5 AT Interface Description
Interface Connector 5 - 1 Pin Description Summary 5 - 1 Pin Description Table 5 - 2 PIO Timing 5 - 3 DMA Timing 5 - 4 Ultra DMA Timing Parameters 5 - 5
Section 6 Host Software Interface
Task File Registers 6 - 1
Data Register 6 - 1
Error Register 6 - 1
Features Register 6 - 1
Sector Count Register 6 - 2
Sector Number Register 6 - 2
Cylinder Number Registers 6 - 2
Device/Head Register 6 - 2
Status Register 6 - 2 Command Register 6 - 3
Read Commands 6 - 3
Write Commands 6 - 3
Mode Set/Check Commands 6 - 3
Power Mode Commands 6 - 3
Initialization Commands 6 - 3
Seek, Format, and Diagnostic Commands 6 - 3
S.M.A.R.T. Commands 6 - 3 Summary 6 - 4 Control Diagnostic Registers 6 - 5
Alternate Status Register 6 - 5
iii
DIAMONDMAX 6800 PRODUCT MANUAL
Device Control Register 6 - 5 Digital Input Register 6 - 5
Reset and Interrupt Handling 6 - 6
Section 7 Interface Commands
Command Summary 7 - 1 Read Commands 7 - 2
Read Sector(s) 7 - 2 Read Verify Sector(s) 7 - 2 Read Sector Buffer 7 - 2 Read DMA 7 - 3 Read Multiple 7 - 3 Set Multiple 7 - 3
Write Commands 7 - 4
Write Sector(s) 7 - 4 Write Verify Sector(s) 7 - 4 Write Sector Buffer 7 - 4 Write DMA 7 - 5 Write Multiple 7 - 5 Ultra DMA 7 - 5
Set Feature Commands 7 - 5
Set Features Mode 7 - 5
Power Mode Commands 7 - 7
Standby Immediate 7 - 7 Idle Immediate 7 - 7 Standby 7 - 7 Idle 7 - 7 Check Power Mode 7 - 7 Set Sleep Mode 7 - 7 Default Power-on Condition 7 - 7
Initialization Commands 7 - 9
Identify Drive 7 - 9
Initialize Drive Parameters 7 - 12 Seek, Format, and Diagnostic Commands 7 - 13 S.M.A.R.T. Command Set 7 - 14
Section 8 Service and Support
Service Policy 8 - 1 No Quibble Service 8 - 1 Support 8 - 1
Glossary
Glossary GL - 1
iv
DIAMONDMAX 6800 PRODUCT MANUAL
Figures
Figure Title Page
2 - 1 PCBA Jumper Location and Configuration 2 - 6 3 - 1 Outline and Mounting Dimensions 3 - 2 4 - 1 Multi-pack Shipping Container 4 - 2 4 - 2 Single-pack Shipping Container (Option A) 4 - 3 4 - 3 Single-pack Shipping Container (Option B) 4 - 3 4 - 4 Master, Slave and Cable Select Settings 4 - 5 4 - 5 5.25-inch Mounting Brackets and Rails 4 - 6 4 - 6 IDE Interface and Power Cabling Detail 4 - 7 4 - 7 Master, Slave and Cable Select Settings 4 - 10 5 - 1 Data Connector 5 - 1 5 - 2 PIO Data Transfer to/from Device 5 - 3 5 - 3 Multi-word DMA Data Transfer 5 - 4 5 - 4 Initiating an Ultra DMA Data In Burst 5 - 5 5 - 5 Sustained Ultra DMA Data In Burst 5 - 6 5 - 6 Host Pausing an Ultra DMA Data In Burst 5 - 6 5 - 7 Device Terminating an Ultra DMA Data In Burst 5 - 7 5 - 8 Host Terminating an Ultra DMA Data In Burst 5 - 7 5 - 9 Initiating an Ultra DMA Data Out Burst 5 - 8 5 - 10 Sustained Ultra DMA Data Out Burst 5 - 8 5 - 11 Device Pausing an Ultra DMA Data Out Burst 5 - 9 5 - 12 Host Terminating an Ultra DMA Data Out Burst 5 - 9 5 - 13 Device Terminating an Ultra DMA Data Out Burst 5 - 10
v
DIAMONDMAX PLUS 5120 – INTRODUCTION
SECTION 1
Introduction
Maxtor Corporation
Maxtor Corporation has been providing high-quality computer storage products since 1982. Along the way, we’ve seen many changes in data storage needs. Not long ago, only a handful of specific users needed more than a couple hundred megabytes of storage. Today, downloading from the Internet and CD-ROMs, multimedia, networking and advanced office applications are driving storage needs even higher. Even home PC applications need capacities measured in gigabytes, not megabytes.
Products
Maxtor’s products meet those demanding storage capacity requirements with room to spare. They feature proven compatibility and reliability. While DiamondMax6800 is the latest addition to our family of high performance 5,400 RPM desktop hard drives, DiamondMax™ 4320 series hard drives deliver industry-leading capacity, performance and value for many PC applications.
Support
No matter which capacity, all Maxtor hard drives are supported by our commitment to total customer satisfaction and our No Quibble (http://www.maxtor.com) – puts you in touch with either technical support or customer service. We’ll provide you the information you need quickly, accurately and in the form you prefer – a fax, a downloaded file or a conversation with a representative.
®
Service guarantee. One call – or a visit to our home page on the Internet
Manual Organization
This hard disk drive reference manual is organized in the following method:
o Section 1 – Introduction o Section 2 – Description o Section 3 – Specifications o Section 4 – Installation o Section 5 – AT Interface o Section 6 – Host Software Interface o Section 7 – Interface Commands o Section 8 – Service and Support o Appendix – Glossary
Abbreviations
VRBBANOITPIRCSEDVRBBANOITPIRCSED
ATAtnemhcattaTABMetybagem
ipbhcnirepstibces/stibMdnocesrepstibagem
SHCrotces-daeh-rednilycces/BMdnocesrepsetybagem
bdslebicedzHMztrehagem
ABddethgiewA,slebicedsmdnocesillim
AMDsseccayromemtceridBSMtibtnacifingistsom
CCEedocnoitcerrocrorreVmstlovillim
icfhcnirepsegnahcxulfsnsdnocesonan
GnoitareleccaOIPtuptuo/tupnidemmargorp
BGetybagigMPRetunimrepsnoitulover
zHztrehipthcnirepskcart
BKetybolikAMDUsseccayromemtceridartlu
ABL)gni(sserddakcolblacigolcesµdnocesorcim
BSLtibtnacifingistsaelVstlov
AmserepmaillimWsttaw
1 – 1
DIAMONDMAX PLUS 5120 – INTRODUCTION
Conventions
If there is a conflict between text and tables, the table shall be accepted as being correct.
Key Words
The names of abbreviations, commands, fields and acronyms used as signal names are in all uppercase type (e.g., IDENTIFY DRIVE). Fields containing only one bit are usually referred to as the “name” bit instead of the “name” field.
Names of drive registers begin with a capital letter (e.g., Cylinder High register).
Numbering
Numbers that are not followed by a lowercase “b” or “h” are decimal values. Numbers that are followed by a lowercase “b” (e.g., 01b) are binary values. Numbers that are followed by a lowercase “h” (e.g., 3Ah) are hexadecimal values.
Signal Conventions
Signal names are shown in all uppercase type. All signals are either high active or low active signals. A dash character (-) at the end of a signal name
indicates that the signal is low active. A low active signal is true when it is below ViL and is false when it is above ViH. A signal without a dash at the end indicates that the signal is high active. A high active signal is true when it is above ViH and is false when it is below ViL.
When a signal is asserted, it means the signal is driven by an active circuit to its true state. When a signal is negated, it means the signal is driven by an active circuit to its false state. When a signal is released, it means the signal is not actively driven to any state. Some signals have bias
circuitry that pull the signal to either a true or false state when no signal driver is actively asserting or negating the signal. These instances are noted under the description of the signal.
1 – 2
PRODUCT DESCRIPTION
SECTION 2
Product Description
Maxtor DiamondMax™ 6800 AT disk drives are 1-inch high, 3.5-inch diameter random access storage devices which incorporate an on-board ATA-4/Ultra DMA 66 controller. High capacity is achieved by a balanced combination of high areal recording density and the latest data encoding and servo techniques.
Maxtor's latest advancements in electronic packaging and integration methods have lowered the drive's power consumption and increased its reliability. Advanced giant magneto-resistive read/write heads, an state-of-the-art head/disk assembly using an integrated motor/spindle design allow up to four disks in a 3.5-inch package.
Exceptionally high data transfer rates, 5,400 RPM spin speed and < 9.0 ms access times make these performance series disk drives especially well-suited to high-end desktop and server applications.
DiamondMax 6800 Key Features
ANSI ATA-4 compliant PIO Mode 4 interface (Enhanced IDE) Supports Ultra DMA Mode 4 for up to 66.7 MB/sec data transfers 2 MB buffer with multi-adaptive cache manager 5,400 RPM spin speed < 9.0 ms seek time Zone density and I.D.-less recording Outstanding shock resistance at 250 Gs High durability with 50K constant start/stop cycles Advanced multi-burst on-the-fly Error Correction Code (ECC) Extended data integrity with ECC protected data and fault tolerant servo synchronization fields Supports EPA Energy Star Standards (Green PC Friendly) with ATA powering savings commands Auto park and lock actuator mechanism Low power consumption S.M.A.R.T. Capability
Note: Maxtor defines one megabyte as 106 or one million bytes and one gigabyte as 109 or one billion bytes.
2 – 1
PRODUCT DESCRIPTION
Product Features
Functional / Interface
Maxtor DiamondMax™ 6800 hard drives contain all necessary mechanical and electronic parts to interpret control signals and commands from an AT-compatible host computer. See Section 3 Product Specifications, for complete drive specifications.
Zone Density Recording
The disk capacity is increased with bit density management – common with Zone Density Recording. Each disk surface is divided into 16 circumferential zones. All tracks within a given zone contain a constant number of data sectors. The number of data sectors per track varies in different zones; the outermost zone contains the largest number of data sectors and the innermost contains the fewest.
Read/Write Multiple Mode
This mode is implemented per ANSI ATA/ATAPI-4 specification. Read/Write Multiple allows the host to transfer a set number of sectors without an interrupt request between them, reducing transfer process overhead and improving host performance.
UltraDMA - Mode 4
Maxtor DiamondMax 6800 hard drives fully comply with the new ANSI Ultra DMA protocol, which greatly improves overall AT interface performance by significantly improving burst and sustained data throughput.
Multi-word DMA (EISA Type B) - Mode 2
Supports multi-word Direct Memory Access (DMA) EISA Type B mode transfers.
Sector Address Translation
All DiamondMax 6800 drives feature a universal translate mode. In an AT/EISA-class system, the drive may be configured to any specified combination of cylinders, heads and sectors (within the range of the drive's formatted capacity). DiamondMax 6800 drives power-up in a translate mode:
LEDOMLYCDHTPSenoZLmocPWABLXAMYTICAPAC
8U02729447,256136)*()*(259,561,35BM622,72 6U04029855,936136)*()*(464,478,93BM914,02 5U00719569,236136)*()*(027,822,33BM020,71 4U06319273,626136)*()*(679,285,62BM316,31 3U02019977,916136)*()*(232,739,91BM902,01 3U54809383,616136)*()*(460,415,61BM554,8 2U05609595,216136)*()*(067,596,21BM005,6
(*) The fields LZone (Landing Zone) and WPcom (Write Pre-comp) are not used by the Maxtor hard drive and the values may be either 0 or the values set by the BIOS. All capacities listed in the above table are based on 106 or one million bytes.
2 – 2
PRODUCT DESCRIPTION
Logical Block Addressing
The Logical Block Address (LBA) mode can only be utilized in systems that support this form of translation. The cylinder, head and sector geometry of the drive, as presented to the host, differs from the actual physical geometry. The host AT computer may access a drive of set parameters: number of cylinders, heads and sectors per track, plus cylinder, head and sector addresses. However, the drive can’t use these host parameters directly because of zoned recording techniques. The drive translates the host parameters to a set of logical internal addresses for data access.
The host drive geometry parameters are mapped into an LBA based on this formula:
LBA = (HSCA - 1) + HHDA x HSPT + HNHD x HSPT x HCYA (1)
where HSCA = Host Sector Address, HHDA = Host Head Address
= (HSCA - 1) + HSPT x (HHDA + HNHD x HCYA) (2)
HCYA = Host Cylinder Address, HNHD = Host Number of Heads HSPT = Host Sectors per Track
The LBA is checked for violating the drive capacity. If it does not, the LBA is converted to physical drive cylinder, head and sector values. The physical address is then used to access or store the data on the disk and for other drive related operations.
Defect Management Zone (DMZ)
Each drive model has a fixed number of spare sectors per drive, all of which are located at the end of the drive. Upon detection of a bad sector that has been reassigned, the next sequential sector is used.
For example, if sector 3 is flagged, data that would have been stored there is “pushed down” and recorded in sector 4. Sector 4 then effectively becomes sector 3, as sequential sectors are “pushed down” across the entire drive. The first spare sector makes up for the loss of sector 3, and so maintains the sequential order of data. This push down method assures maximum performance.
On-the-Fly Hardware Error Correction Code (ECC)
5 symbols, single burst, guaranteed
Software ECC Correction
22 symbols, single burst, guaranteed
Automatic Park and Lock Operation
Immediately following power down, dynamic braking of the spinning disks delays momentarily allowing the read/write heads to move to an inner mechanical stop. A small fixed magnet holds the rotary actuator in place as the disk spins down. The rotary actuator is released only when power is again applied.
2 – 3
PRODUCT DESCRIPTION
Cache Management
Buffer Segmentation
The data buffer is organized into two segments: the data buffer and the micro controller scratch pad. The data buffer is dynamically allocated for read and write data depending on the commands received. A variable number of read and write buffers may exist at the same time.
Read-Ahead Mode
Normally, this mode is active. Following a read request, disk read-ahead begins on the first sector and continues sequentially until the allocated buffer is full. If a read request is received during the read-ahead operation, the buffer is examined to determine if the request is in the cache. If a cache hit occurs, read­ahead mode continues without interruption and the host transfer begins immediately.
Automatic Write Reallocation (AWR)
This feature is part of the write cache and reduces the risk of data loss during deferred write operations. If a disk error occurs during the disk write process, the disk task stops and the suspect sector is reallocated to a pool of alternate sectors located at the end of the drive. Following reallocation, the disk write task continues until it is complete.
Write Cache Stacking
Normally, this mode is active. Write cache mode accepts the host write data into the buffer until the buffer is full or the host transfer is complete. A command complete interrupt is generated at the end of the transfer.
A disk write task begins to store the host data to disk. Host write commands continue to be accepted and data transferred to the buffer until either the write command stack is full or the data buffer is full. The drive may reorder write commands to optimize drive throughput.
2 – 4
PRODUCT DESCRIPTION
Major HDA Components
Drive Mechanism
A brush-less DC direct drive motor rotates the spindle at 5,400 RPM (±0.1%). The dynamically balanced motor/spindle assembly ensures minimal mechanical run-out to the disks. A dynamic brake provides a fast stop to the spindle motor upon power removal. The speed tolerance includes motor performance and motor circuit tolerances.
Rotary Actuator
All DiamondMax™ 6800 drives employ a rotary voice coil actuator which consists of a moving coil, an actuator arm assembly and stationary magnets. The actuator moves on a low-mass, low-friction center shaft. The low friction contributes to fast access times and low power consumption.
Read/Write Electronics
An integrated circuit mounted within the sealed head disk assembly (near the read/write heads) provides up to eight head selection (depending on the model), read pre-amplification and write drive circuitry.
Read/Write Heads and Media
Low mass, low force giant magneto-resistive read/write heads record data on 3.5-inch diameter disks. Maxtor uses a sputtered thin film medium on all disks for DiamondMax 6800 drives.
Air Filtration System
All DiamondMax 6800 drives are assembled in a Class 100 controlled environment. Over the life of the drive, a 0.1 micron filter and breather filter located within the sealed head disk assembly (HDA) maintain a clean environment to the heads and disks. DiamondMax 6800 drives are designed to operate in a typical office environment with minimum environmental control.
Microprocessor
The microprocessor controls the following functions for the drive electronics:
Command execution Cache management Data correction and error recovery Diagnostic execution Data sequencing Head positioning (including error recovery) Host interface Index detection Spin speed control Seeks Servo S.M.A.R.T.
2 – 5
PRODUCT DESCRIPTION
Subsystem Configuration
Dual Drive Support
Two drives may be accessed via a common interface cable, using the same range of I/O addresses. The drives are jumpered as device 0 or 1 (Master/Slave), and are selected by the drive select bit in the Device/Head register of the task file.
All Task File registers are written in parallel to both drives. The interface processor on each drive decides whether a command written to it should be executed; this depends on the type of command and which drive is selected. Only the drive selected executes the command and activates the data bus in response to host I/O reads; the drive not selected remains inactive.
A master/slave relationship exists between the two drives: device 0 is the master and device 1 the slave. When J50 is closed (factory default, figure 2-1), the drive assumes the role of master; when open, the drive acts as a slave. In single drive configurations, J50 must be closed.
Cable Select Option
CSEL (cable select) is an optional feature per ANSI ATA specification. Drives configured in a multiple drive system are identified by CSEL’s value:
– If CSEL is grounded, then the drive address is 0. – If CSEL is open, then the drive address is 1.
Jumper Location/Configuration
Darkened jumper pins indicate factory-installed (default) shunts.
Figure 2-1
PCBA Jumper Location and Configuration
evalS/retsaM
tceleSelbaC
*delbasiD
delbanE
*delbasiD
delbanE
devreseRyrotcaFO
devreseRyrotcaF O
NOITARUGIFNOCREPMUJ05J84J64J44J24J
*metsysevirdelgnisnievirdylnO
metsysevirdlaudnievirdevalS
noitatimiLrednilyC2904
desolC=CtluafeD=*yeK
C
*metsysevirdlaudnievirdretsaM
C O
O C
O C
)dellatsnirepmuj(
nepO=O
)dellatsnirepmujon(
4092 Cylinder Limitation
On some older BIOS', primarily those that auto-configure the disk drive, a hang may occur when the drive cylinder value exceeds 4096. The 4092 Cylinder Limitation jumper reduces the capacity in the Identify Drive to 4092 allowing large capacity drives to work with older BIOS'. A software driver is required to access the full capacity of the drive.
2 – 6
Product Specifications
Models and Capacities
LEDOM
yticapaCdettamroF
)edoMABLBM(
Drive Configuration
LEDOM8U027296U040295U007194U063193U020193U548092U05609
ecafretnI/rellortnoCdetargetnI AMDartlU/4-ATA
dohteMgnidocnE 71/61LLR4RPE
evaelretnI 1:1
metsySovreS deddebmE
epyT/eziSreffuB MARDSBM2
ecafruSrepsenoZataD 61
sdaeH/secafruSataD8654332
sksiDforebmuN 433222 1
ytisneDlaerA079,4ni/bM
ecafruSrepskcarT )srednilyC( 17, 945
ytisneDkcarT 503,71ipt
ytisneDgnidroceR 882-222ipbk
ytisneDxulF icfk603-632
kcolB/rotceSrepsetyB 215
kcarTrepsrotceS -662426
evirDrepsrotceS
8U027296U040295U007194U063193U020193U548092U05609
622,72914,02020,71063,51902,01554,8,6005
6
01saetybagemenosenifedrotxaM
259,561,35464,478,93027,822,33679,285,62232,739,91460,415,61067,596,21
PRODUCT SPECIFICATIONS
SECTION 3
9
01saetybagigenodnasetybnoillimenoro
2
.setybnoillibenoro
Performance Specifications
LEDOM8U027296U040295U007194U063193U020193U548092U05609
semiTkeeS )lacipyt(
kcarT-ot-kcarT sm0.1
egarevA sm0.9<
mumixaM sm02<
ycnetaLegarevA 5sm55.
deepSlanoitatoR )%1.0±( 5MPR004,
daehrevOrellortnoC sm3.0<
etaRrefsnarTataD
ecafretnImorf/oT
)4edoM-AMDartlU(
ecafretnImorf/oT
)2edoM-AMDdrow-itluM/4OIP(
aideMmorf/oT ces/BM8.72otpu
emiTtratS )ydaeRevirDot0( lacipytces3.7
ces/BM7.66otpu
ces/BM7.61otpu
3 – 1
PRODUCT SPECIFICATIONS
Physical Dimensions
RETEMARAPDRADNATSCIRTEM
thgieHsehcni20.1sretemillim9.52 htgneLsehcni87.5sretemillim6.641
htdiWsehcni00.4sretemillim1.201
thgieWsdnuop3.1smargolik95.0
1.028 max [25.9 mm]
6 x 6-32 UNC Tap
4 x 6-32 UNC Tap
4.000 ± .01 [101.6 mm]
5.787 max
[146.6 mm]
1.75 ± .02
1.638 ± .005 [41.61 mm]
1.122 ± .02 [28.4 mm]
1.625 ± .02
.25 ± .01
4.00 ± .01
[102.1 mm]
3.75 ± .01
[95.25 mm]
3 – 2
Figure 3 - 1
Outline and Mounting Dimensions
Power Requirements
EDOM%8±V21%5±V5REWOP
pu-nipS )kaep( Am0022Am093
keeS )gva( Am087Am063W2.11
etirW/daeR )gva( Am013Am024W8.5
eldI )gva( Am503Am023W3.5
ybdnatS )gva( Am02Am561W1.1
peelS )gva( Am02Am55W25.0
Power Mode Definitions
Spin-up
The drive is spinning up following initial application of power and has not yet reached full speed.
Seek
A random access operation by the disk drive.
Read/Write
Data is being read from or written to the drive.
PRODUCT SPECIFICATIONS
Idle
The drive is spinning, the actuator is parked and powered off and all other circuitry is powered on. The drive is capable of responding to read commands within 40 ms.
Standby
The spin motor is not spinning. The drive will leave this mode upon receipt of a command that requires disk access. The time-out value for this mode is programmable. The buffer is active to accept write data.
Sleep
This is the lowest power state – with the interface set to inactive. A software or hardware reset is required to return the drive to the Standby state.
EPA Energy Star Compliance
Maxtor Corporation supports the goals of the U.S. Environmental Protection Agency’s Energy Star program to reduce the electrical power consumption of computer equipment.
Environmental Limits
RETEMARAPGNITAREPOEGAROTS/GNITAREPO-NON
erutarepmeTC°55otC°5)C°04-(erutarepmetwol
.snoitidnocdecudni-toh;yrogetaccitamilc
tneidarGlamrehT (ruohrepC°52 )mumixam
ytidimuHevitaleR %59ot%5 gnisnednoc-non( )
bluBteW 72°C )mumixam(
edutitlAteef000,01ot002-teef000,04ot002-
esioNcitsuocA )edomeldI( rewopdnuosegarevaleb3.3
)enohporcim01,9777OSIrep(
,3.105dohtem,E018-DTS-LIMrep)C°17(erutarepmethgih
3 – 3
PRODUCT SPECIFICATIONS
Shock and Vibration
RETEMARAPGNITAREPOGNITAREPO-NON
kcohSlacinahceMsrorreon,sm0.2,sG03 egamadon,sm0.2,sG052
kcohSlanoitatoR egamadon,sm0.1-5.0,ces/daR000,81
noitarbiVmodnaRG400.0tazH54-01
noitarbiVeniStpewS
zH02-5
zH003-12
Reliability Specifications
Annual Return Rate
< 1.0% Annual Return Rate (ARR) indicates the average against products
Quality Acceptance Rate
< 500 DPPM The quality acceptance rate indicates the percentage of Maxtor
2
zH/
2
G800.0tazH26-84
zH/
2
zH/
G400.0tazH003-56
2
G6000.0tazH005-103
srorreon
zH/
edutilpmaelbuodsehcni940.0
)kaep-0(edutilpmakaepG0.1
egamadon,smrG51.2tazH000,2-01
shipped. ARR includes all reasons for returns (failures, handling damage, NDF), but does not include inventory credit returns.
products successfully installed by our customers, and/or the number of defective parts per million (DPPM) encountered during the entire installation process.
Start/Stop Cycles
50,000 (minimum) This indicates the minimum cycles for reliable start/stop function at a
60% confidence level.
Data Reliability
14
< 1 per 10
bits read Data errors (non-recoverable). Average data error rate allowed with all
error recovery features activated.
Component Design Life
5 years (minimum) Component design life is defined as a.) the time period before
identified wear-out mechanisms impact the failure rate, or b.) the time period up to the wear-out point when useful component life expires.
3 – 4
PRODUCT SPECIFICATIONS
EMC/EMI
Radiated Electromagnetic Field Emissions - EMC Compliance
The hard disk drive mechanism is designed as a subassembly for installation into a suitable enclosure and is therefore not subject to Subpart J of Part 15 of FCC Rules (47CFR15) or the Canadian Department of Communications Radio Interference Regulations. Although not required, the disk mechanism has been tested within a suitable end-use product and found to comply with Class B limits of the FCC Rules and Regulations of the Canadian Department of Communications.
The CE Marking indicates conformity with the European Union Low Voltage Directive (73/23/EEC) when the disk mechanism is installed in a typical personal computer. Maxtor recommends that testing and analysis for EMC compliance be performed with the disk mechanism installed within the user's end-use application.
Canadian Emissions Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the radio interference regulations of the Canadian department of communications.
Le present appareil numerique n'emet pas de bruit radioelectriques depassant les limites applicables aux appareils numeriques de Class B prescrites dans le reglement sur le brouillage radioelectrique edicte par le ministere des communications du Canada.
Safety Regulatory Compliance
All Maxtor hard drives comply with relevant product safety standards such as CE, CUL, TUV and UL rules and regulations. As delivered, Maxtor hard drives are designed for system integration before they are used.
3 – 5
Loading...
+ 49 hidden pages
