Maxtor DB35 7200.2 DATASHEET

DB35 7200.2

3.5-inch disc drives for DVRs

80GB to 500GB* • ATA/100* and SATA

Key Advantages

• Capacities of 80, 120, 160, 200, 250, 300, 400 and 500GB provide the space for the most inveterate viewer to archive entire seasons of television
programming.

• Up to 500 hours of standard TV capacity, up to 93 hours of high-definition capacity

• DynaPlay Technology delivers the storage industry's most comprehensive set of features for the demanding DVR environment, including video streaming
performance, power optimization and content security.

• DriveTrust Technology improves content security as part of a system digital rights management program.

• High reliability for worry-free DVR operation

• Seagate Design Service Centers improve product performance and reliability, while increasing your time to market, by solving CE design issues quickly and
efficiently.

Best-Fit Applications

• DVRs

• Home media servers

• HDD recorders

Maximum Capacity
and Performance
Optimized for Digital
Video Recorders
(DVRs)

* Compatible with UDMA-2, -3 and -4

DB35 7200.2

3.5-inch disc drives for DVRs

1

One gigabyte, or GB, equals one billion bytes when referring to hard drive capacity.

Model Number

Interface Options

Performance

Spindle Speed (RPM)
Recording Capacity (Hours)

SD MPEG-2 (2.22 Mbits/sec)
HD MPEG-2 (18.52 Mbits/sec)
HD MPEG-4 (12.00 Mbits/sec)

Transfer Rate

Maximum Internal (Mbits/sec)

Maximum Sustained (Mbits/sec)
Cache, Multisegmented (Mbytes)
ATA Transfer Modes Supported
SATA Data Transfer Modes Supported (Gb/s)
Simultaneous SDTV Streams Supported

(Assumes 256K host buffer per stream)
Simultaneous HDTV Streams Supported

(Assumes 2MB host buffer per stream)
Power-On to Ready (typical sec)
Standby to Ready (typical sec, max)

Voltage

Voltage Tolerance (including noise)

Configuration/Organization

Bytes per Sector
Guaranteed Sectors

Reliability/Data Integrity

Nonrecoverable Read Errors per Bits Read
Annualized Failure Rate (AFR)

Power Management

Startup Current (12 V typical, amps)
Seek (typical, watts)
Idle Average (watts)
Standby/Sleep Mode (typical, watts)
Consumer Storage Profile (watts)
PVR Profile (watts)

Environmental

Ambient Temperature (°C)

Operating

Nonoperating
Temperature Gradient (°C per hour max)

Operating/Nonoperating
Relative Humidity (non-condensing, %)

Operating/Nonoperating
Wet Bulb Temperature (°C max)

Operating/Nonoperating
Shock, Operating: 2 msec (Gs)
Shock, Nonoperating: 1 msec (Gs)
Acoustics PVR (typical/max bels)
Rotational Vibration (Rad/sec, Gs)

Operating (acceleration)

Nonoperating (5 to 22 Hz/22 to 350 Hz)

Physical

Height (mm/in)
Width (mm/in)
Depth (mm/in)
Weight (g/lb)

500GB

1

ST3500841SCE
ST3500841ACE

Ultra ATA 100
SATA 3Gb/s

7200

500
60
93

815.2
65

8

3

10

10
16
16

512
976,773,168

1 sector per 10

14

0.34%

2.0

12.6
8

0.8

9.2

4.88

0 to 60
–40 to 70

20/30

5 to 90/5 to 95

33/40
63
300

2.71/2.88

0.25

0.25/5.0

26.11/1.028

101.6/4.000

146.99/5.787
710/1.57

400GB

1

ST3400833SCE
ST3400833ACE

Ultra ATA 100
SATA 3Gb/s

7200

400
48
74

815.2
65

8

3

10

10
16
16

512
781,422,768

1 sector per 10

14

0.34%

2.0

12.6
8

0.8

9.2

4.88

0 to 60
–40 to 70

20/30

5 to 90/5 to 95

33/40
63
300

2.71/2.88

0.25

0.25/5.0

26.11/1.028

101.6/4.000

146.99/5.787
710/1.57

300GB

1

ST3300822SCE
ST3300822ACE

Ultra ATA 100
SATA 3Gb/s

7200

300
36
56

867.2
76

8

3

10

10
16
16

512
586,072,368

1 sector per 10

14

0.34%

2.0

12.6
8

0.8

9.2

4.88

0 to 60
–40 to 70

20/30

5 to 90/5 to 95

33/40
63
300

2.71/2.88

0.25

0.25/5.0

26.11/1.028

101.6/4.000

146.99/5.787
655/1.44

250GB

1

ST3250824SCE
ST3250824ACE

Ultra ATA 100
SATA 3Gb/s

7200

250
30
46

867.2
76

8

3

10

10
16
16

512
488,397,168

1 sector per 10

14

0.34%

2.0

12.6
8

0.8

9.2

4.88

0 to 60
–40 to 70

20/30

5 to 90/5 to 95

33/40
63
300

2.71/2.88

0.25

0.25/5.0

26.11/1.028

101.6/4.000

146.99/5.787
580/1.28

200GB

1

ST3200827SCE
ST3200827ACE

Ultra ATA 100
SATA 3Gb/s

7200

200
24
37

867.2
76

8

3

10

10
16
16

512
390,721,968

1 sector per 10

14

0.34%

2.0

12.4
8

0.8
<5.5

4.88

0 to 60
–40 to 70

20/30

5 to 90/5 to 95

33/40
63
300

2.71/2.88

0.25

0.25/5.0

26.11/1.028

101.6/4.000

146.99/5.787
580/1.28

Specifications

PIO modes 0–4, Multiword DMA modes 0–2, Ultra DMA modes 0–6

5V ± 5%, 12V ± 10%

www.seagate.com
1-800-732-4283
(1-800-SEAGATE)

Copyright © 2006 Seagate Technology LLC.All rights reserved. Printed in USA. Seagate, Seagate Technology and the Wave logo are registered trademarks of
Seagate Technology LLC. DB35 Series,DynaPlay and DriveTrust are either trademarks or registered trademarks of Seagate Technology LLC. Other product names
are trademarks or registered trademarks of their owners. One gigabyte, or Gbyte, equals one billion bytes when referring to hard drive capacity.Accessible
capacity may vary depending on operating environment and formatting. Quantitative usage examples for various applications are for illustrative purposes. Actual
quantities will vary based on various factors, including file size, file format, features and application software. Seagate reserves the right to change, without
notice, product offerings or specifications. Publication Number: DS-1596, June 2006
