M-Audio PROKEYS SONO 61 User Manual

Sono 61

User Guide

ProKeys Sono 61 User GuideProKeys Sono 61 User Guide

| 1

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

ProKeys Sono 61 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

What’s in the Box? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Built-in Audio Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Minimum Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Standalone Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Bus-Powered Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Controls and Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Top Panel Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Top Panel Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Rear Panel Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Hardware Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Audio Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Audio Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

MIDI Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Other Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Example Operating Scenarios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

About the audio inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

ProKeys Sono as a Standalone Instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

ProKeys Sono Premium Voice Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

ProKeys Sono GM sound selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

ProKeys Sono as a Standalone Microphone Preamplifier and Mixer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

ProKeys Sono Demos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Basic ProKeys Sono Setup in Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

ProKeys Sono Setup in Mac OS X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Using ProKeys Sono with a Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Audio Tracks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

MIDI Tracks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

ProKeys Sono Audio Setup and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Using the Microphone and Instrument Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Setting Input Gain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Using the Aux Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Using Direct Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

The Mono Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

The ProKeys Sono Audio Control Panel (Windows Only) . . . . . . . . . . . . . . . . . . . 26

Latency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

About . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

ProKeys Sono 61 User Guide

Routing MIDI Data to and from your Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Routing MIDI Signals to your Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Routing MIDI Signals from your Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Advanced ProKeys Sono Functions in Edit Mode . . . . . . . . . . . . . . . . . . . . . . . . . 29

Audio Options in Edit Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Button, Knob, Wheel and Pedal Jack Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

ProKeys MIDI Output Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Sending a Bank Change or Program Change Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

MIDI Messages In-Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Program & Bank Changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

NRPN/RPNs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Appendices - Useful MIDI Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Appendix A - General MIDI Instruments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Appendix B - Channel 10 Drum Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Appendix C - Standard MIDI Controller Numbers (MIDI CCs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Appendix D - Additional RPN Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Technical Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

ProKeys Sono 61 User Guide

| 3

Introduction

Congratulations on your purchase of M-Audio ProKeys Sono 61. ProKeys Sono 61 is a semi-weighted, velocity sensitive 61-key
digital piano, USB-compatible MIDI controller, and an audio interface in one convenient package. Play the on-board premium
keyboard sounds as a standalone instrument or plug a microphone and guitar into ProKeys Sono and record, edit and produce your
performance via your computer utilizing the included recording software. ProKeys Sono provides everything to instantly transform your
computer into a versatile music studio.

ProKeys Sono functions as a class-compliant device when connected to your computer via USB. This means your computer will
recognize the keyboard without the need to install additional drivers1 and will have immediate access to all audio inputs and outputs as
well as to the built-in MIDI interface. However, as you become more familiar with ProKeys Sono, you may wish to take advantage of
this device’s additional professional features by installing the ProKeys Sono drivers.

Installing the ProKeys Sono drivers in Windows improves audio performance by reducing latency. Latency is the time it takes for MIDI
input (when using software synthesizers) or audio input signal to appear as audio at the ProKeys Sono audio outputs for monitoring.
Windows users will gain additional functionality from installing the ProKeys Sono drivers including: using your new keyboard with more
than one application at the same time (multi-client), the ability to send large SysEx messages, as well as using your ProKeys Sono with
a qualified version of the Pro Tools M-Powered recording software. On a Macintosh, installing the M-Audio drivers enables you to use
your ProKeys Sono with a qualified version of the Pro Tools M-Powered recording software.

Information on Windows driver installation can be found in the printed Quick Start Guide included with your new ProKeys Sono.
Macintosh driver installation instructions are in the “ProKeys Sono 61 Setup in OS X” chapter of this User Guide.

Finally, keep in mind that ProKeys Sono can be used with any third-party music program. Be sure to read your specific application’s
documentation to learn more about how it can best be used with this device.

1

When using ProKeys Sono as a class-compliant device in Windows (i.e., without installing drivers), the computer will search
for the M-Audio DFU (device firmware upgrade tool) and display a Found New Hardware Wizard. The M-Audio DFU is a
component of ProKeys Sono 61 that is enabled when the M-Audio drivers are installed, but is not necessary for class-compliant
operation. As a result, the Found New Hardware Wizard and can safely be ignored in this scenario. See page 14 to learn more
about this topic.

ProKeys Sono 61 User Guide

ProKeys Sono 61 Features

| 4

Keyboard:

 61 semi-weighted, velocity sensitive keys

 5 high-quality voices (Grand Piano, Bright Piano, Electric

Piano, Organ, Clavinet)

 General MIDI (GM) sound set with a total of 128 built-in

sounds for playback of MIDI files

 On-board reverb and chorus effects

 Pitch Bend wheel

 Modulation wheel; MIDI re-assignable

 Voice Volume knob; MIDI re-assignable

 Octave up/down buttons; MIDI re-assignable

 Sustain pedal input; MIDI re-assignable

 MIDI output jack

 40-note maximum polyphony

 Edit mode for advanced functions and programming

 Bus-powered through USB or DC power for standalone

functionality (DC power adaptor sold separately)

2

Built-in Audio Interface:

 16-Bit, 44.1 kHz, 2-in, 2-out audio interface

 XLR microphone input, 1/4” instrument input, and stereo

RCA inputs

 Two rear-panel 1/4” main outputs

 Two front-panel 1/4” headphone outputs

 Dedicated Instrument and Microphone gain control knobs

with signal and peak LEDs

 Direct Monitor knob for near-zero latency monitoring

 Class-compliant operation: no driver installation required—

simply connect the keyboard and power on

2

Stereo premium voices operate at a maximum polyphony of 20 notes.

1

What’s in the Box?

 M-Audio ProKeys Sono 61 keyboard

 Printed Quick Start Guide

 M-Audio ProKeys Sono Drivers and Documentation CD-ROM

 Software Bundle CD-ROM

 USB cable

If any of the above listed items are missing, please contact the retailer where you purchased the product.

ProKeys Sono 61 User Guide

Minimum Requirements

Standalone Operation

Standalone operation refers to using ProKeys Sono without a computer. To do this, an optional 9V,
500mA center-positive power supply or USB-type power supply is required. More information on
available power supplies can be found at www.m-audio.com.

Bus-Powered Operation

In bus-powered mode, ProKeys Sono is connected to a PC or Mac with a USB cable and receives
power through the USB connection. When using ProKeys Sono in this mode, your computer system
must meet the following minimum specifications:

M-Audio ProKeys Sono 61

Windows XP (SP2)

• Pentium® III 1GHz or AMD K7

Athlon 1GHz

(CPU may be higher for laptops)

• 512 MB RAM

• One native USB port

3

Home and Professional Edition
only. Windows Media Center Edition
is not currently supported.

3

Windows Vista 32-bit Mac OS X

• Pentium® 4 1.6GHz

or AMD Athlon XP 2800+

(CPU may be higher for laptops)

• 1 GB RAM

• 128 MB Graphics Card

• One native USB port

| 5

optional USB-type

external power supply

4

• Macintosh G4 1GHz†

• OS X 10.4.11 with 512 MB RAM

• OS X 10.5.2 with 512 MB RAM

• One native USB port

4

G4 accelerator cards are not

supported.

M-Audio suggests you also check the minimum system requirements for any software applications you plan on using with

your new M-Audio hardware, as they may be greater than the above.

➜ IMPORTANT: Connect your headphones or powered speakers to ProKeys Sono.

Sounds created by ProKeys Sono and from software used with it will play through the
main outputs on ProKeys Sono–not the outputs of your computer’s built-in soundcard.

A Note About System Updates: Please check the M-Audio driver download page at
http://www.m-audio.com/drivers for the availability of an updated driver before you decide
to install operating system updates. Before new M-Audio device drivers are released, they
are tested for use with the operating system versions that are available at that time. When
updates for an operating system are released by Microsoft or Apple, all M-Audio device
drivers have to be re-tested and possibly updated to ensure proper operation. M-Audio
recommends refraining from installing operating system updates until a driver has been
posted to the M-Audio website for that specific operating system.

ProKeys Sono 61 User Guide

3

4

1

162

6 758 9 10 11 12 13 14 15

Controls and Connectors

Top Panel Diagram

Top Panel Descriptions

| 6

1. Modulation Wheel (Modulation): This wheel is used to add expressivity to your performance by changing the intensity
of certain effects. The Modulation wheel usually controls vibrato (change in intonation) or tremolo (change in volume) of your
selected sound. The MIDI data range of this wheel is 0 to 127, with 0 being the note-unchanged position (i.e., the wheel is
rolled downward toward the user).

Note that the Modulation wheel can be assigned to control MIDI parameters other than modulation (MIDI CC 1). This topic is

covered in the “Advanced ProKeys Sono Functions in Edit Mode” chapter of this User Guide.

2. Headphone Outputs (Phones): These two output jacks accept standard 1/4” headphones. The volume of these outputs is
controlled by the Master Volume fader (6).

3. Pitch Bend Wheel (Pitch Bend): This wheel lets you create expressive changes in your performances by raising and
lowering pitch. Rolling the Pitch Bend wheel upward will raise an instrument’s pitch whereas rolling it downward will lower the
pitch. Note that this wheel is spring-mounted and will return to the center position when released.

4. Octave Shift (Data) < > Buttons: In this User Guide, these buttons will be referred to as the Data buttons. By default,
these buttons shift the “center” of the keyboard in one octave increments. Pressing the Data > button (right) will shift the
notes played on the keyboard up one octave (for example, D2 becomes D3). When shifted upward, the LED above the
right Data button will illuminate. Pressing the Data < button (left) will shift the notes played on the keyboard downward (for
example, G4 becomes G3) and the LED above the left Data button LED will illuminate. Pressing both Data buttons together
will “center” the keyboard and restore the default state (Octave shift = 0) and any illuminated Data button LEDs will turn off.

The Data buttons can also be assigned to send different MIDI messages or control other features on ProKeys Sono. This is

explained in the “Advanced ProKeys Sono Functions in Edit Mode” section of this User Guide.

5. Edit Mode Button (Edit Mode): When this button is pressed, the associated LED illuminates and the keyboard enters “Edit
mode.” While in this mode, the keys on the keyboard no longer transmit MIDI notes, and are instead used to select advanced
functions and enter data. The “Advanced ProKeys Sono Functions in Edit Mode” section of this User Guide contains more
detailed information about Edit mode. Press this button again to exit Edit mode.

6. Master Volume Fader (Master Volume): The Master Volume fader controls the level of the main outputs (17) as well as
the headphone outputs (2).

ProKeys Sono 61 User Guide

| 7

7. Microphone Gain Knob (Mic Gain): This knob controls the gain level of the Microphone input. The signal (green) LED
illuminates when signal is present at the microphone input (i.e., incoming audio signal is greater than -20dB). The peak (red)
LED illuminates when incoming audio signal is clipping (distorting) and indicates that the Microphone Gain knob should be
turned down.

8. Instrument Gain Knob (Inst. Gain): This knob controls the gain level of the Instrument input. The signal (green) LED
illuminates when signal is present at the instrument input (i.e., incoming audio signal is greater than -20dB). The peak (red)
LED illuminates when incoming audio signal is clipping (distorting) and indicates that the Instrument Gain knob should be
turned down.

9. Mono Button (Mono): By default, this button affects how incoming signals from the Microphone, Instrument and Auxiliary
inputs are heard through your speakers or headphones. When active, any input signal will be routed to both the left and the
right side of your stereo speakers or headphones in equal amounts, making them appear centered in the stereo field.

Note that by default, the Mono button only affects what you hear. In other words, when recording while the Mono button

is active, the signals from the Microphone, Instrument, and Auxiliary inputs are still sent to your computer in separate left
and right channels, meaning the Microphone will appear on the left channel and Instrument on the right channel within
your recording software (the left and right channels of your Auxiliary inputs will appear in the left and right channels of your
software, respectively).

Also note that the function of the Mono button can be changed to allow incoming signals to be recorded exactly as they are

heard while monitoring. See the “MONO Input Record Key” portion of the “Advanced ProKeys Sono Functions in Edit Mode”
section of this User Guide for information on how to change the operation of this button.

10. Direct Monitor Knob (Direct Monitor): The Direct Monitor knob controls the amount of audio input signal flowing from the
Microphone, Instrument or Auxiliary inputs directly to the 1/4” main outputs. This allows you to monitor your inputs with
near-zero latency.

11. Piano Reset Button (Piano Reset): This button restores basic piano and keyboard controller functions, including resetting
the Modulation wheel, Voice Volume knob, and Sustain Pedal to their default settings. This is useful in situations in which a
user has changed settings of ProKeys Sono and would like to quickly return to the default state (i.e., the Local Mode setting
is set to “On” and the ProKeys Sono Grand Piano sound is loaded). Pressing the Piano Reset button also sends a “MIDI
Panic” sequence of commands (i.e., “All Notes Off” and “Reset All Controllers” MIDI messages) on MIDI channel 1—a useful
feature if you experience “stuck” MIDI notes. For a complete list of MIDI messages that are sent when this button is pressed,
see Appendix E, “Piano Reset Button.”

12. Voice Volume Knob (Voice Vol): This is an assignable controller that, by default, controls the volume of the sounds built
into ProKeys Sono. Details on how to change the function of this knob can be found in the “Knob Assignment” portion of the
“Advanced ProKeys Sono Functions in Edit Mode” section of this User Guide.

13. Reverb On/Off Button (Reverb On/Off): This button engages the internal reverb effect of ProKeys Sono, adding the
effect to the internal keyboard sounds of ProKeys Sono. The reverb depth can be controlled via MIDI CC commands. See
the “Advanced ProKeys Sono Functions in Edit Mode” chapter of this User Guide for more information on this.

14. Chorus On/Off Button (Chorus On/Off): This button engages the internal chorus effect of ProKeys Sono, adding
the effect to the internal sounds of ProKeys Sono. The chorus depth can be controlled via MIDI CC commands. See the
“Advanced ProKeys Sono Functions in Edit Mode” chapter of this User Guide for more information on this.

15. Voice Select Buttons: These buttons let you select which of the five high-quality sounds is played by the ProKeys Sono

keyboard.

16. Keyboard: ProKeys Sono features 61 full-size, semi-weighted, velocity-sensitive keys.

ProKeys Sono 61 User Guide

£Ç £n £ Óä Ó£ ÓÓ ÓÎ Ó{ Óx ÓÈ

| 8

Rear Panel Descriptions:

1 7. 1/4” Main Outputs (Output R—L/Mono): Connect these unbalanced tip-sleeve (TS) main outputs to your mixer, powered

speakers, or amplifier. These jacks output a mixed signal consisting of the ProKeys Sono internal piano sounds, signal from all
of the keyboard’s inputs (mic, instrument, and auxiliary), and audio signal coming from your computer. If you are connecting to
a mono (single channel) device or amplifier, use the left 1/4” output.

18. Auxiliary RCA Inputs (Aux Input R—L): These line-level RCA-type inputs can
receive signal from a variety of sources such as mixers, CD players, or drum
machines. These inputs are mixed into the outputs of ProKeys Sono and will be
heard on the 1/4” main outputs (17) or headphone outputs (2).

19. 1/4” Instrument Input (Instrument): This unbalanced tip-sleeve (TS)
connector allows you to connect an instrument, such as an electric guitar or
bass. Use the Instrument Gain knob (8) to control the gain level of this input.

20. XLR Microphone Input (Microphone): This input accepts a dynamic
microphone connected via a standard three-pin balanced XLR cable. Use the
Microphone Gain knob (7) to control the gain level of this input.

TIP: The ProKeys Sono Auxiliary
inputs do not have an input gain
knob. Therefore, the volume of these
inputs must be adjusted at the source
to ensure that the incoming signal
does not clip (distort) at the ProKeys
Sono input. For example, if you have
connected a CD player to the RCA
inputs, you may need to adjust the
output volume of the player itself to
ensure distortion free recordings.

21. Sustain Pedal Jack (Sustain): Connect an optional sustain pedal to this jack.
This pedal is normally used for sustaining the sound you are playing without having to keep your hands on the keyboard (just
like the sustain pedal on a piano).

22. MIDI Out Jack (MIDI Out): ProKeys Sono can connect to external MIDI devices such as synthesizers or sound modules
through this jack. By default, MIDI data generated by playing the keys on the keyboard is sent to this MIDI output jack.
However, it is possible to configure ProKeys Sono to act as a USB to MIDI interface, allowing MIDI data from your computer
to be sent out of this jack. See the “MIDI Out Mode Key” section of the “Advanced ProKeys Sono Functions in Edit Mode”
chapter for more information.

23. USB Port (
computer. This USB connection will power ProKeys Sono and allow transfer of audio and MIDI data between your computer
and the device. Alternatively, an optional USB-type power supply can be
connected to this port for standalone operation.

24. DC Power Supply Port (9V DC): Connect an optional 9V DC >500mA
center-positive power supply to this jack when using ProKeys Sono in standalone
mode. This port does not need to be used when ProKeys Sono is connected to
your computer with a USB cable or if a USB-type power supply is being used.

25. On/Off Switch ( I / O ): This On/Off switch turns ProKeys Sono on and off.

26. Kensington® Security Slot ( ): This slot is compatible with Kensington®
security cables to protect your device from theft.

): Use the provided USB cable to connect ProKeys Sono to an available USB port on a PC or Macintosh

Powering ProKeys Sono:

ProKeys Sono can be powered
through either the USB port or the
DC Power Supply port. It is NOT
necessary to power the device
through both ports. For example, if
ProKeys Sono is connected to your
computer using the USB cable, it is
not necessary to use a DC power
supply.

ProKeys Sono 61 User Guide

| 9

Hardware Connections

Audio Inputs

A dynamic microphone can be connected to the XLR input on the rear panel of the keyboard, while an instrument such as a guitar
or bass can be connected to the 1/4” input jack next to the XLR input. Each of these two inputs has an independent preamp with
its own gain control knob, and signal/clip LEDs. Two RCA Auxiliary inputs are also located on the back panel. Signal from these
inputs is mixed with the Microphone and Instrument inputs before being routed through the USB connection to a connected Mac
or PC.

Audio Outputs

Connect the two 1/4” main outputs on the rear panel to powered monitors, an amplifier, or a mixer. You may also monitor through
headphones by connecting one or two sets of headphones to the 1/4” stereo headphone outputs on the front panel.

MIDI Connections

In addition to the USB MIDI connection between ProKeys Sono and your computer, you can connect the MIDI Out jack of
ProKeys Sono to an external device’s MIDI input. This allows you to control an external synthesizer or sound module by either
using ProKeys Sono as a standalone MIDI controller keyboard or by sending your sequencing application’s MIDI data to the
hardware device through the keyboard (i.e., using ProKeys Sono as a USB to MIDI interface).

Note that the ProKeys Sono “MIDI Out Mode” setting must be configured correctly for your sequencing application’s MIDI output
signals to appear at the MIDI output jack on the back of ProKeys Sono. Please see the section entitled “MIDI Out Mode Key” in
the “ProKeys MIDI Output Settings” chapter to find out more about this setting.

Other Connections

A sustain pedal can be connected to the 1/4” Sustain pedal jack on the back of the keyboard.

ProKeys Sono 61 User Guide

/UTPUT

2 ,<-ONO

!UX)NPUT

)NSTRUMENT -ICROPHONE 3USTAIN -)$)/UT

6$#

2 ,

0RO+EYS3ONOBACK

0OWERED

-ONITORS

#$0LAYER

#OMPUTER

'UITAR

-IC

53"

Example Operating Scenarios

The following diagrams illustrate two scenarios in which ProKeys Sono is connected to external hardware.

| 10

Example Setup #1 shows M-Audio ProKeys Sono with a microphone connected to the Microphone input, and an electric
guitar plugged into the Instrument input. A CD player is connected to the auxiliary inputs. The main outputs of ProKeys Sono are
connected to a monitoring system (powered speakers, in this case) while a computer powers the keyboard through the USB
connection. A sequencing application on the computer handles all incoming and outgoing audio and MIDI data. This is covered
in greater detail in the “Using ProKeys Sono with a Computer” section of this guide.

Example Setup #1

ProKeys Sono 61 User Guide

/UTPUT

2 ,<-ONO

!UX)NPUT

)NSTRUMENT -ICROPHONE 3USTAIN -)$)/UT

6$#

2 ,

0RO+EYS3ONOBACK

0OWERED

-ONITORS

#OMPUTER

53"

-)$)/UT

| 11

Example Setup #2

Example Setup #2 shows a drum machine plugged into the Aux inputs, and the ProKeys Sono main outputs plugged into a
pair of powered speakers. The ProKeys Sono MIDI Output jack is connected to the MIDI input of the drum machine, while a
sequencing application on a computer handles audio and MIDI data through the USB connection (see “Using ProKeys Sono with
a Computer” to learn more about how your ProKeys Sono and computer exchange audio and MIDI data).

This setup allows you to:

1. Send MIDI information from either the ProKeys Sono keyboard or your computer’s sequencer to the drum machine.

2. Return the audio output of the drum machine into ProKeys Sono, where it can be mixed with the built-in sounds and/or

audio coming from the computer.

3. The mixed output is then sent to powered speakers (or headphones) for monitoring.

About the audio inputs:

Keep in mind that ProKeys Sono features a 2-input, 2-output audio interface. This means that while ProKeys Sono has a variety
of analog inputs on its rear panel (i.e., an XLR microphone input, a 1/4” instrument input, and a pair of RCA Aux inputs), the XLR/
Left Aux and Instrument/Right Aux inputs are merged (or “summed”) together before being sent to the computer. In other words,
if signal is present at all of the inputs when you begin recording, the XLR and Left Aux will appear mixed together in channel one
of your software while the Instrument and Right Aux inputs will appear mixed together as channel two.

Note that by default, the built-in ProKeys Sono sounds are also summed with the microphone, instrument, and auxiliary inputs
and sent to the computer for recording. If you do not wish to send the ProKeys Sono sounds to your music software, this can be
accomplished by toggling the USB Record switch in Edit mode. Additional information on this can be found in the “USB Record
Key” portion of the “Advanced ProKeys Sono Functions in Edit Mode” chapter of this User Guide.

Similarly, while ProKeys Sono features two sets of headphone outputs and 1/4” main outputs, all of these outputs play the same
stereo signal.

ProKeys Sono 61 User Guide

| 12

ProKeys Sono as a Standalone Instrument

Standalone operation refers to using ProKeys Sono without a computer. To do this, an optional USB-type power supply or 9V, 500mA
center-positive power supply (sold separately) is required.

NOTE: While ProKeys Sono can receive power from two different power sources, the device only
requires one power source to operate. In other words, if one type of power supply is connected
(such as a USB-type power adapter), it is not necessary to connect the second type of power supply
(the 9V, 500mA adapter).

ProKeys Sono can function as a standalone instrument, providing five premium voices, and a complete General MIDI (GM) sound
set. In addition to playing the built-in sounds, you can use the keyboard to trigger sounds on synthesizers or sound modules that are
connected to the MIDI Out jack on ProKeys Sono. By default, ProKeys Sono transmits MIDI data on channel one.

You can also use the Mic Gain, Instrument Gain, Direct Monitor and Voice Volume knobs in standalone mode to create a mix of your
keyboard, guitar and vocal performances.

ProKeys Sono Premium Voice Selection

The five premium voices can be accessed via the Voice Select buttons on the top panel. Pressing one of these buttons activates
the corresponding sound.

ProKeys Sono GM sound selection

The ProKeys Sono keyboard has a full General MIDI (GM) sound set with 128 sounds built-in. The built-in GM sounds can be
accessed in two ways:

Method 1: Recall a specific General MIDI instrument in Edit mode

Appendix A lists the built-in General MIDI instruments by their sound numbers. Access a specific instrument by entering its

number in Edit mode:

1. Press the Edit Mode button.

2. Press the black key above F5 (F#5), representing “Program.”

3. Enter the desired program number, using the white keys between G4 and B5.

4. Press C6 (Enter) to confirm the selection.

Method 2: Browse General MIDI instruments using the Data buttons

Reassigning the Data buttons to send program change messages will allow you to step through and audition the built-in

General MIDI sounds in consecutive order. To configure the Data < > buttons to send program change messages:

1. Press the Edit Mode button.

2. Press the black key above F2 (F#2). (ProKeys Sono will automatically exit Edit mode).

3. Press the Data > and < buttons to step forward and backwards through the built-in GM sounds.

To return the Data keys to control the octave shift value:

1. Press the Edit Mode button.

2. Press the black key above C2 (C#2), representing “Data = Octave.” (ProKeys Sono will automatically exit Edit mode).

For additional information on program changes, see the “Advanced ProKeys Sono Functions in Edit Mode” chapter of this

User Guide.

ProKeys Sono 61 User Guide

/UTPUT

2 ,<-ONO

!UX)NPUT

)NSTRUMENT -ICROPHONE 3USTAIN -)$)/UT

6$#

2 ,

0RO+EYS3ONOBACK

0OWERED

-ONITORS

!#

!DAPTER

'UITAR

-IC

-)$)/UT

ProKeys Sono as a Standalone Microphone Preamplifier and Mixer

| 13

ProKeys Sono can function as the centerpiece of a simple live performance setup.

Connect a Microphone and an Instrument (such as an electric guitar or bass) to
ProKeys Sono and use the Microphone and Instrument gain knobs to set the input
levels. Next, use the Direct Monitor knob to set the overall level of the microphone
and instrument inputs in the mix. Finally, adjust the level of the keyboard’s built-in
sounds by using the Voice Volume knob.

If you connected the line outputs of an external device to the aux inputs of ProKeys
Sono, the volume level of that device may need to be adjusted at the external device
itself.

The mixed signal of Microphone, Instrument, Aux input and built-in sounds will be
available on both headphone outputs and the rear-panel 1/4” outputs.

Use the Master Volume slider to adjust the overall output level.

NOTE: ProKeys Sono is capable of many advanced features which can be accessed via the
ProKeys Sono Edit mode. Many of these features can be useful when ProKeys Sono is operating in
Standalone mode. Additional information concerning these features can be found in the “Advanced
ProKeys Sono Functions in Edit Mode” chapter of this User Guide.

ProKeys Sono Demos

ProKeys Sono has a built-in demo song for each instrument sound. To hear these demos:

Tip: Connect the MIDI Out jack
of ProKeys Sono to an external
MIDI synthesizer or sound module.
Connect the Line outputs of the
external device to the Aux inputs
on ProKeys Sono. If you play the
ProKeys Sono keyboard, you will
trigger MIDI sounds on the external
MIDI synthesizer, and can hear them
back through the ProKeys Sono main
outputs.

1. Press the Edit Mode button.

2. Press one of the Voice Select buttons.

Demo playback can be stopped by pressing the Edit Mode button. While the demo is playing, the LED of the selected voice

will flash. At the completion of the demo, the demo song will repeat.

ProKeys Sono 61 User Guide

| 14

Basic ProKeys Sono Setup in Windows

Information on Windows driver installation can be found in the included printed Quick Start Guide.

Your computer will recognize ProKeys Sono without the need to install the M-Audio driver software. However, M-Audio recommends
installing the device drivers for improved audio performance and to gain access to additional professional features such as:

 Low latency software monitoring:

Low latency software monitoring allows you to play software synthesizers and monitor audio input through your recording

software with minimal delay between an action (e.g. pressing a key, strumming a chord, or singing a note) and hearing the
resulting sound on your speakers or headphones.

 Multi-client MIDI operation:

This feature allows you to use ProKeys Sono as a MIDI input and output device with more than one application at the same

time.

 Support of large System Exclusive (SysEx) transfers:

Transmit large SysEx files (e.g. all parameters of every sound on an external synthesizer, stored within a single file) to

connected Synthesizers or other MIDI devices.

 Pro Tools M-Powered support:

Use ProKeys Sono as an audio interface with a qualified version of the Pro Tools M-Powered production software.

If you do not require any of the above listed features, you can simply connect ProKeys Sono to your Windows computer and

begin using it without the need to install additional driver software.

Windows XP/Vista users: Important information for class-compliant operation

IMPORTANT: When using ProKeys Sono class-compliant (i.e., without installing drivers) in Windows, the
computer will search for the M-Audio DFU (device firmware upgrade tool) and display a Found New Hardware
Wizard. The M-Audio DFU is a component of ProKeys Sono 61 that is enabled when the M-Audio drivers are
installed, but is not necessary for class-compliant operation. You have the following options:

A. Cancel the Found New Hardware Wizard and start using ProKeys Sono immediately.

The Found New Hardware Wizard will appear every time your computer detects that the device is

connected (e.g. upon restarting the computer or disconnecting/reconnecting ProKeys Sono).

B. Follow the Found New Hardware Wizard until it gives the option not to be prompted to install this

hardware again.

Windows Vista Users:

  •Select“Don’tshowthismessageagainforthisdevice”intherstscreenthatappears.

  •Click“Continue”intheconrmationscreenthatfollows.

Windows XP Users:

  •Intherstscreen,select”No,notthistime”andclick“Next”

  •Inthesecondscreen,select“Installthesoftwareautomatically”andclick“Next”

  •Finally,makesurethecheckboxlabeled“Don’tpromptmeagaintoinstallthissoftware”isactive,then

click Finish.

C. Install the M-Audio drivers as described in the “Driver Installation for ProKeys Sono 61” section of the

Quick Start Guide. After these drivers have been installed, the Found New Hardware Wizard for the
M-Audio DFU will no longer be displayed.
