Model VP-15S1 User Guide

DLP

®

Projector

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL

IMPORTANT SAFETY

DECLARATION OF CONFORMITY

U.S. Responsible Party: Marantz America, Inc.

100 Corporate Drive,
Mahwah, NJ, 07430, U.S.A.
TEL: [phone]

Type of Product:
Model:

DLP Projector
VP-15S1

This device complies with Part 15 of the FCC rules.
Operation is subject to the following conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.

INSTRUCTIONS

READ BEFORE OPERATING EQUIPMENT

The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the product.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF

PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE

LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

NOTE:

This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the
equipment and receiver.

This Class B digital apparatus complies with
Canadian ICES-003.

- Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.

- Consult the dealer or an experienced radio/TV
technician for help.

NOTE:

Changes or modifications not expressly approved
by the party responsible for compliance could void
the user’s authority to operate the equipment.

Cet appareil numérique de la Classe B est
conforme à la norme NMB-003 du Canada.

This product was designed and manufactured to
meet strict quality and safety standards. There are,
however, some installation and operation precautions
which you should be particularly aware of.

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install
in accordance with the manufacture's
instructions.

8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.

9. Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your
safety. If the provided plug does not fit into
your outlet, consult an electrician for
replacement of the obsolete outlet.

10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.

11. Only use attachments/accessories specified
by the manufacturer.

12. Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning
storms or when unused for long periods of
time.

14. Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.

Additional Safety Information!

• This product should not be placed in a
built-in installation such as a bookcase or
rack unless proper ventilation is provided
or the manufacturer’s instructions have
been adhered to.

• Apparatus shall not be exposed to
dripping or splashing and that no objects
filled as vases, shall be placed on the
apparatus.

• When the switch is in the OFF position,
the apparatus isn’t completely switched-off
from the MAINS.

ENGLISH

FOREWORD

This section must be read carefully before any
connection is made to the mains supply.

WARRANTY

For warranty information, contact your local
Marantz distributor.

RETAIN YOUR PURCHASE RECEIPT

Your purchase receipt is your permanent record of
a valuable purchase. It should be kept in a safe
place to be referred to as necessary for insurance
purposes or when corresponding with Marantz.

IMPORTANT

When seeking warranty service, it is the
responsibility of the consumer to establish proof
and date of purchase. Your purchase receipt or
invoice is adequate for such proof.

FOR U.K. ONLY

This undertaking is in addition to a consumer’s
statutory rights and does not affect those rights in
any way.

EQUIPMENT MAINS WORKING SETTING

Your Marantz product has been prepared to
comply with the household power and safety
requirements that exist in your area.

COPYRIGHT

Recording and playback of some material may
require permission. For further information refer to
the following:

- Copyright Act 1956

- Dramatic and Musical Performers Act 1958

- Performers Protection Acts 1963 and 1972

- Any subsequent statutory enactments and
orders

WARNINGS

– Do not expose the equipment to rain or

moisture.

– Do not remove the cover from the equipment.
– Do not insert anything into the equipment

through the ventilation holes.

– Do not handle the mains cord with wet

hands.

– Do not cover the ventilation with any items

such as tablecloths, newspapers, curtains,
etc.

– No naked flame sources, such as lighted

candles, should be placed on the equipment.

– When disposing of used batteries, please

comply with governmental regulations or
environmental public instruction’s rules that
apply in your country or area.

– Make a space of about 0.2 meter around the

unit.

– When the projector is mounted on the ceiling,

the Ceiling Mount Kit approved by MARANTZ
must be used for installation.

– Do not look into the lens when the projector

is turned on. It could damage your eyesight.

– Unplug the projector from the wall outlet if it

is not to be used for a few days.

– No objects filled with liquids, such as vases,

shall be placed on the equipment.

– When the switch is in the OFF position, the

equipment is not completely switched off
from MAINS.

– The equipment shall be installed near the

power supply so that the power supply is
easily accessible.

Lamp Handing Precautions

DANGER

This SHP uses a high voltage glass mercury vapor
lamp. The lamp can break or fail to light if handled
wrongly during replacement or because of the
projector’s surrounding temperature.
Lamp life also varies according to the lamp with
some even breaking or failing to light as soon as
they are used the first time. If the lamp breaks,
glass fragments may be scattered inside the lamp
unit and projector, and gas inside the lamp bulb
that contains mercury vapor may be emitted from
the projector’s vent.
Before use, carefully read the projector user guide
and the lamp replacement instructions. Remember
to handle the lamp with care. In the event of
serious trouble, call for Marantz authorized dealer.

• Do not look directly into the lamp with bare
eyes while lit. The bright light can cause sore
eyes and impair vision.

• Do not directly expose skin to the light of the
lamp. Direct exposure can inflame the skin.

• Do not drop, impact, subject to excessive force
or otherwise damage the lamp.

• Replacing the lamp runs the risk of burns and
electric shock, therefore shut OFF power
supply, unplug the AC power cord from AC
power outlet and wait at least 60 minutes for
the lamp to cool down before attempting to
replace it.

• If the lamp breaks, unplug the AC power cord
from AC power outlet and call for Marantz
authorized dealer to replace it. Do not replace
the lamp yourself or clean up broken glass
inside the projector as this can result in cuts
and burns to you or damages inside the
projector.

• If the projector is hung from a ceiling or
installed in a high place, it is extremely
dangerous to replace the lamp. In this case, do
not replace or handle the damaged lamp
yourself.

CAUTION

• The chance of the lamp breaking is high after
extended use. It is recommended to replace
the lamp when near the end of its designed
life. Do not use a lamp beyond the maximum
lighting time.

• Use only Marantz original lamp units. Check
the model code of the lamp unit matches that
in the user guide.

• Before replacing the lamp, read carefully
“Lamp Unit Replacement” in the user guide.

Replace the lamp as explained therein.

• Entrust disposal of a used lamp to a licensed
industrial waste handler or return it to the place
of purchase. Do not break the lamp or discard
with general waste.

• If the lamp breaks, leave the area immediately
and stay away for at least 30 minutes, and
ventilate the room so as not to inhale the
mercury vapor.

• If you inhale the mercury vapor, see a
physician immediately and follow his
instructions.

FRANÇAIS

AVANT-PROPOS

Prière de lire ce chapitre avant de brancher
l’appareil sur le secteur.

GARANTIE

Pour des informations sur la garantie, contacter le
distributeur local Marantz.

CONSERVER L’ATTESTATION D’ACHAT

L’attestation d’achat est la preuve permanente d’un
achat de valeur. La conserver en lieu sur pour s’y
reporter aux fins d’obtention d’une couverture
d’assurance ou dans le cadre de correspondances
avec Marantz.

IMPORTANT

Pour l’obtention d’ un service couvert par la
garantie, il incombe au client d’établir la preuve de
l’achat et d’en corroborer la date. Le reçu ou la
facture constituent des preuves suffisantes.

REGLAGE DE L’ALIMENTATION
SECTEUR DE L’APPAREIL

Cet appareil Marantz a été conçu pour respecter
les exigences de votre région en matiè re
d’alimentation secteur et de sécurité.

DRUITS D' AUTEUR

L’ enregistrement et la lecture de certaines
informations sonores nécessitent une autorisation.
Pour de plus amples renseignements, consultez:

- La loi de 1956 sur les Copyright

- Loi concernant les Acteurs et Musiciens 1958

- Lois de Protection des Artistes 1963 et 1972

-Les décrets et règlements ultérieurs qui s’y
rapportent

AVERTISSEMENTS

– Ne pas exposer l’appareil à la pluie ni à

l’humidité.

– Ne pas essayer de retirer le boîtier de

l’appareil.

– Ne rien insérer dans l’appareil par les orifices

de ventilation.

– Ne pas manipuler le cordon d’alimentation

avec les mains mouillées.

– Ne pas recouvrir les ouïes de ventilation avec

un objet quelconque comme une nappe, un
journal, un rideau, etc.

– Ne placer aucune source de flamme nue,

comme une bougie allumée, sur l'appareil.

– Pour mettre au rebut les piles usées,

respecter les lois gouvernementales ou les
rè glements officiels concernant
l’environnement qui s'appliquent à votre pays
ou région.

– Veiller à ce qu’aucun objet ne soit à moins de

0,2 mètre des côtés de l'appareil.

– Pour monter le projecteur au plafond, vous

devez utiliser un kit de montage au plafond
approuvé par MARANTZ pour l'installation.

– Ne regardez pas dans l'objectif quand le

projecteur est allumé. Cela pourrait
endommager votre vue.

– Débranchez le projecteur de la prise murale

s'il ne doit pas être utilisé pendant plusieurs
jours.

– Aucun objet rempli de liquide, un vase par

exemple, ne doit être placé sur l'appareil.

– Lorsque l'interrupteur est sur la position OFF,

l'appareil n'est pas complètement
déconnecté du SECTEUR (MAINS).

– L'appareil sera installé près de la source

d'alimentation, de sorte que cette dernière
soit facilement accessible.

Précautions à prendre pour la
manipulation de la lampe

DANGER

Ce SHP utilise une lampe à vapeur de mercure en
verre à haute tension. Cette lampe peut se casser
ou ne pas s'allumer si elle est manipulée
incorrectement pendant son remplacement ou du
fait de la température ambiante du projecteur.
La durée de service d'une lampe varie aussi en
fonction de la lampe, certaines se cassant ou ne
s'allumant pas aussitôt qu'elles sont utilisées pour
la première fois. Si la lampe se casse, des
fragments de verre peuvent se répandre à
l'intérieur de l'unité lampe et du projecteur, et le
gaz à l'intérieur de l'ampoule de la lampe qui
contient de la vapeur de mercure peut être émis
par l'orifice du projecteur.
Avant utilisation, lisez attentivement le guide de
l'utilisateur du projecteur et les instructions de
remplacement de la lampe. Pensez à manipuler la
lampe avec précautions. En cas de problème
sérieux, contactez un distributeur agréé Marantz.

• Ne regardez pas directement la lampe sans
protection pour les yeux pendant qu'elle est
allumée. Sa lumière brillante peut faire mal aux
yeux et affaiblir la vue.

• N'exposez pas directement la peau à la
lumière de la lampe. Une exposition directe
peut provoquer une inflammation de la peau.

• Ne laissez pas tomber la lampe, ne la heurtez
pas, ne la soumettez pas à une force excessive
ni ne l'endommager.

• Le remplacement de la lampe fait courir un risque
de brûlure et de choc électrique ; il faut donc
couper l'alimentation électrique, débrancher le
cordon d'alimentation secteur de la prise secteur
et attendre au moins 60 minutes que la lampe
refroidisse avant d'essayer de la remplacer.

• Si la lampe se casse, débranchez le cordon
d'alimentation secteur de la prise secteur et
contactez un distributeur agréé Marantz pour
qu'il la remplace. Ne remplacez pas la lampe
vous-même ni ne nettoyez le verre brisé à
l'intérieur du projecteur car vous pourriez vous
couper et vous brûler ou endommager
l'intérieur du projecteur.

•

Si le projecteur est accroché au plafond ou
installé dans un endroit en hauteur, il est
extrêmement dangereux de remplacer la lampe.
Dans ce cas, ne remplacez ni ne manipulez
vous-même la lampe endommagée.

ATTENTION

• Le risque que la lampe se casse est élevé
après une utilisation prolongé e. Il est
recommandé de remplacer la lampe
lorsqu'elle approche de sa durée de service
spécifiée. N'utilisez pas une lampe au-delà du
temps d'éclairage maximum.

• N'utilisez que des unités lampes d'origine
Marantz. Vérifiez que le code de modèle de
l'unité lampe correspond à celui indiqué dans le
guide de l'utilisateur.

• Avant de remplacer la lampe, lisez
attentivement "Remplacement de l'unité
lampe" dans le guide de l'utilisateur.
Remplacez la lampe conformément aux
explications de cette section.

• Confiez la mise au rebut d'une lampe usée à
un service de déchets industriels licencié ou
retournez-la où vous l'avez achetée. Ne
cassez pas la lampe ni ne la jetez avec les
ordures ménagères.

• Si la lampe se casse, sortez immédiatement
de la zone pendant au moins 30 minutes, et
aérez la pièce afin de ne pas inhaler la vapeur
de mercure.

• Si vous inhalez de la vapeur de mercure,
consultez immédiatement un médecin et
suivez ses instructions.

ESPAÑOL

PROLOGO

Antes de conectar el equipo a la corriente, debe
leer este capítulo.

GARANTIA

Para obtener información acerca de la garantia
póngase en contacto con su distribuidor Marantz.

GUARDE SU RECIBO DE COMPRA

Su recibo de compra es su prueba permanente de
haber adquirido un aparato de valor, Este recibo
deberá guardarlo en un lugar seguro y utilizarlo
como referencia cuando tenga que hacer uso del
seguro o se ponga en contacto con Marantz.

IMPORTANTE

Cuando solicite el servicio otorgado por la garantia
el usuario tiene la responsabilidad de demonstrar
cuando efectuó la compra. En este caso, su recibo
de compra será la prueba apropiada.

SELECCION DEL VOLTAJE DE
ALIMENTACION

Este producto Marantz se ha preparado para estar
conforme con los requisitos de alimentación
eléctrica doméstica y de seguridad que hay en su
zona.

COPYRIGHT

La grabación y reproducción de determinado
material puede necesitar permiso. Para más
información consulte lo siguiente:

- Acta sobre copyright de 1958

- Acta de la Sociedad General de Autores de
1958

- Acta de Protecció n de la Propiedad
Intelectual de Autores de 1963 y 1972

- Cualquier acta, estatuto y ó rdenes
subsiguientes

ADVERTENCIAS

– No exponga el equipo a la lluvia ni a la

humedad.

– No extraiga la tapa del equipo.
– No introduzca nada en el interior del equipo a

través de los orificios de ventilación.

– No maneje el cable de alimentación con las

manos mojadas.

– No cubra la ventilación con objetos como

manteles, periódicos, cortinas, etc.

– No deben colocarse sobre el equipo

elementos con fuego, por ejemplo velas
encendidas.

– Cuando se eliminen baterías usadas, deben

cumplirse las reglamentaciones oficiales o
las normas de protección medioambiental
aplicables en su país o en su zona.

– Deje un espacio de unos 0,2 metro alrededor

de la unidad.

– Cuando el proyector se monte en el techo

deberá utilizarse para la instalación el juego
de montaje en el techo aprobado por
MARANTZ.

– No mira al objetivo cuando el proyector esté

encendido. Podría lesionarse la vista.

– Desenchufe el proyector de la toma de

corriente si no lo va a utilizar durante unos
pocos días.

– No se deben colocar sobre el aparato

recipientes que contengan líquidos, como por
ejemplo jarrones.

– Cuando el interruptor está en la posición

OFF, el equipo no está completamente
desconectado de la alimentación MAINS.

– El equipo se instalará cerca de la fuente de

alimentación de manera que resulte fácil
acceder a ella.

Precauciones para la manipulación de la
lámpara

PELIGRO

Esta lámpara SHP de vidrio y de alto voltaje
contiene vapor de mercurio. La lámpara puede
romperse o no encenderse si es manipulada
incorrectamente durante el recambio o debido a la
temperatura ambiente del proyector.
La vida útil también varía según las lámparas,
algunas de las cuales se rompen o no se
encienden al cabo del primer uso. Si la lámpara se
rompe, los fragmentos de cristal se pueden
desparramar por el interior de la unidad de la
lámpara y del proyector, y el gas con vapor de
mercurio contenido en la bombilla se puede
escapar a través del sistema de ventilación del
proyector.
Antes de usar el aparato, lea con cuidado la guía
de usuario del proyector y las instrucciones de
recambio de la lámpara. No olvide manipular con
cuidado la lámpara. En caso de producirse
problemas serios, avise a un distribuidor
autorizado de Marantz.

• No mire directamente a la lá mpara sin
protección en los ojos cuando é sta esté
encendida. La luz brillante puede irritar los ojos
e impedir la visión.

• No exponga directamente la piel a la luz de la
lámpara. La exposición directa puede inflamar
la piel.

• No deje caer la lámpara, ni la golpee, ni la
someta a presiones excesivas, ya que de lo
contrario la lámpara se daña.

• El recambio de la lámpara entraña el riesgo de
quemaduras y descargas eléctricas, y por lo
tanto, deberá apagar el aparato, desenchufar
el cable de alimentación del tomacorriente de
CA, y esperar al menos 60 minutos a que la
lá mpara se enfríe antes de intentar
recambiarla.

• Si la lámpara se rompe, desenchufe el cable de
alimentación de CA y avise a un distribuidor
autorizado de Marantz para recambiarla. No
recambie la lámpara usted mismo ni limpie los
cristales rotos en el interior del proyector, pues
podría sufrir cortes y quemaduras y ocasionar
daños en el interior del proyector.

• Si el proyector cuelga del techo o está instalado
en un lugar elevado, el recambio de la lámpara
es extremadamente peligroso. En tal caso, no
recambie ni manipule usted mismo la lámpara
dañada.

PRECAUCIÓN

• La probabilidad de que la lámpara se rompa
es alta después de un uso prolongado. Se
recomienda recambiar la lámpara cerca de la
fecha de expiración de su vida útil prevista.
No utilice una lámpara má s tiempo del
máximo de iluminación previsto.

• Utilice sólo lámparas originales de Marantz.
Compruebe que el código del modelo de la
lámpara coincide con el de la guía de usuario.

• Antes de recambiar la lá mpara, lea
atentamente la sección “Recambio de la
lámpara” en la guía de usuario. Recambie la
lámpara tal y como viene allí explicado.

• Confíe el desecho de la lámpara usada a un
manipulador autorizado de desechos
industriales o devuélvala al lugar donde la
compró. No rompa la lámpara ni la deseche
en la basura normal.

• Si la lámpara se rompe, abandone la zona
inmediatamente y permanezca alejado
durante al menos 30 minutos, ventilando la
habitación con objeto de no inhalar el vapor
de mercurio.

• Si inhala vapor de mercurio, consulte
inmediatamente a su médico y siga sus
instrucciones.

PORTUGUÊS

INTRODUÇÃO

Esta secção deverá ser lida antes de efectuar
qualquer ligação àcorrente.

GARANTIA

Para informações sobre a garantia, contactar o
distribuidor Marantz local.

GUARDAR O RECIBO DE COMPRA

O recibo é o registo permanente da compra que
fez. Deve ser guardado num local seguro, para ser
apresentado em questões relacionadas com o
seguro ou para quando tiver de contactar a
Marantz.

IMPORTANTE

Quando procurar assisténcia técnica ao abrigo da
garantia, é da responsabilidade do consumidor
estabelecer a prova e data de compra. O recibe é
prova adequada.

REGULAÇÃO DO EQUIPAMENTO
CONFORME A ALIMENTAÇÃO DA REDE

O seu produto Marantz foi condicionado a
satisfazer os requisitos domésticos de energia e
segurança existentes na sua zona.

DIREITOS DE AUTOR

Poderá ser necessá ria autorização para a
gravação e a leitura de determinado material. Para
mais informações deverá consultar o seguinte:

- Lei do direito de autor de 1956 (Copyright
Act)

- Lei dos artistas relacionados com a música e
com o teatro de 1958 (Dramatic and Musical
Performers Act)

- Leis de protecção dos artistas de 1963 e de
1972 (Performers Protection Acts)

- Quaisquer regulamentos e despachos
estatutários posteriores

ADVERTÊNCIAS

– Não exponha o equipamento à chuva nem à

humidade.

– Não retire a tampa do equipamento.
– Não atire nada para dentro do equipamento

através dos orificíos de ventilação.

– Não manuseie o cabo de alimentação com

as mãos molhadas.

– Não cobrir os orifícios de ventilação com

objectos tais como toalhas de mesa, jornais,
cortinas, etc.

– Não colocar chamas abertas tais como velas

acesas, sobre o aparelho.

– Ao deitar foras as pilhas usadas, favor

observar os regulamentos governamentais
ou as regras com respeito ao meio ambiente
que se aplicam no seu país ou área de
residência.

– Deixar um espaço de cerca de 0,2 metro ao

redor do aparelho.

– Quando o projector for montado no tecto, o

Kit de Montagem no Tecto aprovado pela
MARANTZ deverá ser utilizado para a
instalação.

– Não olhe para dentro da lente quando o

projector é activado. Isto pode danificar a
visão.

– Desligue o projector da tomada de parede se

este não estiver para ser utilizado durante
alguns dias.

– Não colocar recipientes com água, tal como

vasos, sobre o aparelho.

– Quando o interruptor está na posição OFF, o

equipamento não fica totalmente desligado
de MAINS.

– O aparelho deve ser instalado próximo a

uma tomada de energia para fácil acesso.

Precauções para o manuseio da lâmpada

CUIDADO

Esta lâmpada SHP é uma lâmpada feita de vidro
que contém vapor de mercúrio a alta pressão. A
lâmpada pode quebrar ou não acender caso seja
manuseada incorrectamente durante a
substituição ou devido à temperatura ambiente
onde se encontra o projector.
A vida útil da lâmpada também varia conforme a
lâmpada, com casos de quebra ou falha em
acender na primeira vez que a lâmpada é utilizada.
Se a lâmpada quebrar, estilhaços de vidro podem
cair dentro do compartimento da lâmpada e do
projector, e o gás de dentro da lâmpada que
contém vapor de mercúrio poderá ser emitido
através da saída do projector.
Antes de o utilizar, leia cuidadosamente o guia do
utilizador do projector bem como as instruções
para substituição da lâmpada. Lembre-se de
manusear a lâmpada com cuidado. No caso de
problemas, entre em contacto com o representante
autorizado da Marantz.

• Não olhar directamente na lâmpada acesa
sem protecção ocular. A luz forte pode causar
irritação nos olhos ou prejudicar a visão.

• N ão expor a pele directamente à luz da
lâmpada. Exposição directa pode causar
inflamação na pele.

• Não derrubar, bater, nem usar força excessiva,
pois pode danificar a lâmpada.

• Devido ao risco de queimaduras e choque
eléctrico ao substituir a lâmpada, desligue a
alimentação, desligue o cabo de alimentação da
tomada de CA e espere pelo menos 60 minutos
para arrefecer antes de substituir a lâmpada.

• Se a lâmpada quebrar, desligue o cabo de
alimentação de CA da tomada e entre em
contacto com o representante autorizado da
Marantz para que faça a substituição. Não
tente fazer a substituição nem limpar os
estilhaços de vidro de dentro do projector, pois
pode resultar em cortes e queimaduras ou
ainda danos ao projector.

• Se o projector estiver instalado no teto ou
qualquer lugar alto, é extremamente perigoso
substituir a lâmpada. Nesse caso, não tente
fazer a substituição nem manusear o lâmpada
danificada.

AVISO

• A probabilidade da lâmpada quebrar aumenta
depois de um longo período de utilização. É
recomendável substituir a lâmpada quando a
vida útil da mesma estiver próxima do fim.
Não utilizar a lâmpada além do tempo máximo
determinado.

• Utilizar apenas lâmpadas genuínas Marantz.
Confirme que o código do modelo da lâmpada
corresponde com o listado no guia do
utilizador.

• Antes de substituir a lâ mpada, leia
cuidadosamente a secção “Substituição da
lâmpada” no guia do utilizador. Substitua a
lâmpada de acordo com as instruções dadas.

• Para jogar uma lâmpada usada, solicite os
serviços de uma companhia autorizada a
colectar lixo industrial ou devolva a lâmpada na
loja onde a adquiriu. Não quebrar a lâmpada
nem jogá-la com o lixo comum.

• Se a lâ mpada quebrar, saia da sala
imediatamente, ventile o ambiente para evitar
inalar o vapor de mercúrio e não retorne por
pelo menos 30 minutos.

• Se inalar o vapor de mercúrio, consulte um
médico imediatamente e siga as suas
instruções.

DEUTSCH

VORWORT

Dieser Abschnitt muß gelesen werden, bevor das
Gerät an eine Netzsteckdose angeschlossen wird.

GARANTIE

Bei Garantiefragen wenden Sie sich bitte an Ihren
Marantz-Händler.

HEBEN SIE IHRE QUITTING GUT AUF

Die Quittung dient Ihnen als bleibende Unterlage
für Ihren wertvollen Einkauf Das Aufbewahren der
Quittung ist wichtig, da die darin enthaltenen
Angaben für Versicherungswecke oder bei
Korrespondenz mit Marantz angeführt werden
müssen.

WICHTIG!

Bei Garantiefragen muß der Kunde eine
Kaufunterlage mit Kaufdatum vorlegen. Ihren
Quittung oder Rechnung ist als Unterlage
ausreichend.

NETZSPANNUNGS-EINSTELLUNG DES
GERÄTES

Dieses Marantz-Produkt entspricht den
Netzspannungs- und Sicherheitsanforderungen,
die im Vertriebsgebiet gelten.
VP-12S4 kann nur mit einer Spannung von 230 V
AC betrieben werden.

COPYRIGHT

Für die Aufnahme und Wiedergabe von gewissen
Materialien kann eine Genehmigung erforderlich
sein. Die folgenden Vorschriften müssen beachtet
werden:

- Copyright Act 1956

- Dramatic and Musical Performers Act 1958

- Performers Protection Acts 1963 and 1972

- Jegliche nachfolgenden Gesetze und
Vorschriften

WARNHINWEISE

– Das Gerät nicht Regen oder Feuchtigkeit

aussetzen.

– Die Abdeckung nicht vom Gerät abnehmen.
– Keine Gegenstände durch die

Belüftungsschlitze stecken.

– Das Netzkabel nicht mit feuchten oder

nassen Händen anfassen.

– Decken Sie die Lüftungsöffnungen nicht mit

einem Tischtuch, einer Zeitung, einem
Vorhang usw. ab.

– Es dürfen keine Gegenstände mit offener

Flamme, wie etwa brennende Kerzen, auf
dem Gerät aufgestellt werden.

– Beachten Sie bei der Entsorgung der

verbrauchten Batterien alle geltenden lokalen
und überregionalen Regelungen.

– Auf allen Geräteseiten muß ein

Zwischenraum von ungefähr 0,2 meter
vorhanden sein.

– Wenn der Projektor an der Decke montiert

werden soll, muß der von MARANTZ
vorgesehene Einbauteilesatz für die
Deckenmontage verwendet werden.

– Bei eingeschaltetem Projektor nicht in das

Objektiv schauen. Bei Nichtbeachtung
können Augenschäden die Folge sein.

– Wenn der Projektor mehrere Tage nicht

verwendet werden soll, ist der Stecker aus
der Wandsteckdose herauszuziehen.

– Auf das Gerät dürfen keine mit Flüssigkeiten

gefüllte Behälter, wie etwa eine Vase, gestellt
werden.

– Wenn der Schalter ausgeschaltet ist (OFF-

Position), ist das Gerät nicht vollständig vom
Stromnetz (MAINS) abgetrennt.

– Das Gerät sollte in der Nähe einer

Netzsteckdose aufgestellt werden, damit es
leicht an das Stromnetz angeschlossen
werden kann.

Sicherheitsvorkehrungen zum Umgang
mit der Lampe

GEFAHR

Dieser Projektor verwendet SHP-Lampe, eine
Hochspannungsglaslampe mit Quecksilberdampf.
Die Lampe kann zerbrechen oder unter
Umständen nicht leuchten, falls Sie sie beim
Austauschen falsch handhaben oder infolge der
Umgebungstemperatur des Projektors.
Die Lampenlebensdauer variiert je nach Lampe,
wobei einige Lampen möglicherweise gleich bei der
ersten Verwendung zerbrechen oder nicht leuchten.
Falls eine Lampe zerbricht, können die Scherben in
der Lampeneinheit und im Projektor verstreut werden;
außerdem kann das durch das Zerbrechen der Lampe
freigesetzte Gas, das Quecksilberdampf enthält, durch
die Entlüftungsöffnungen des Projektors ausströmen.
Lesen Sie die Bedienungsanleitung des Projektors und
die Anleitungen zum Austauschen der Lampe vor der
ersten Inbetriebnahme aufmerksam durch. Bedenken
Sie bitte, dass sorgfältige Handhabung gefragt ist.
Sollten ernste Probleme auftreten, wenden Sie sich
bitte an einen autorisierten Marantz-Fachhändler.

• Sehen Sie nicht mit den bloßen Augen direkt in
die leuchtende Lampe. Das helle Licht der
Lampe kann zu schmerzenden Augen führen
und die Sehkraft beeinträchtigen.

•

Achten Sie darauf, dass das Licht der Lampe
nicht direkt auf Ihre Haut trifft. Trifft das Licht
direkt auf Ihre Haut, kann sich diese entzünden.

• Lassen Sie die Lampe nicht fallen, stoßen Sie
sie nicht an, setzen Sie sie keine allzu großen
Kraftanwendung aus, und beschädigen Sie sie
auch sonst nicht.

•

Beim Austauschen der Lampe besteht die
Gefahr von Verbrennungen und Stromschlag.
Schalten Sie den Projektor daher aus, ziehen
Sie das Netzkabel aus der Steckdose und
warten Sie mindestens 60 Minuten, damit sich
die Lampe auskühlt, bevor Sie sie austauschen.

• Falls die Lampe zerbricht, ziehen Sie das
Netzkabel aus der Steckdose und wenden Sie
sich an einen autorisierten Marantz­Fachhändler, um die Lampe austauschen zu
lassen. Versuchen Sie nicht selbst, die Lampe
auszutauschen bzw. das zerbrochene Glas
aus dem Projektor zu entfernen, da Sie sich
dabei schneiden oder verbrennen bzw. das
Projektorinnere beschädigen könnten.

• Falls der Projektor an eine Decke gehängt
oder an einem hoch gelegenen Ort installiert
wird, ist das Austauschen der Lampe
besonders gefährlich. Versuchen Sie in diesem
Fall nie, die beschädigte Lampe selbst
auszutauschen oder zu handhaben.

VORSICHT

• Nach langem Gebrauch ist die Gefahr, dass
die Lampe zerbricht, groß. Wir empfehlen, die
Lampe gegen Ende ihrer festgelegten
Lebensdauer auszutauschen. Verwenden Sie
die Lampe nicht nach ihrer maximalen
Beleuchtungslebensdauer.

• Verwenden Sie nur die originellen Marantz­Lampeneinheiten. Überprüfen Sie, ob der
Modellcode der Lampeneinheit mit dem in der
Bedienungsanleitung angeführten Code

übereinstimmt.

• Lesen Sie vor dem Austauschen der Lampe

den Abschnitt “Austauschen der
Lampeneinheit” aufmerksam durch. Tauschen
Sie die Lampe so aus, wie es in diesem
Abschnitt beschrieben ist.

• Entsorgen Sie die Lampe gemäß den
geltenden Umweltschutzregelungen bzw.
bringen Sie in das Geschäft zurück, in dem Sie
sie erworben haben. Zerbrechen Sie die
Lampe nicht, um sie mit dem normalen
Hausmüll zu entsorgen.

• Sollte die Lampe zerbrechen, verlassen Sie
den Arbeitsbereich unverzüglich und bleiben
Sie mindestens 30 Minuten von diesem Ort
fern. Entlüften Sie den Raum gut, um den
Quecksilberdampf nicht einzuatmen.

• Sollten Sie versehentlich Quecksilberdampf
einatmen, suchen Sie unverzüglichen einen
Arzt auf und befolgen Sie seine Anweisungen.

ITALIANO

INTRODUZIONE

Leggete questa sezione prima di effettuare
qualsiasi collegamento con la rete.

GARANZIA

L’apparecchio è coperto da una garanzia di buon
funzionamento della durata di un anno, o del
periodo previsto dalla legge, a partire dalla data di
acquisto comprovata da un documento attestante il
nominativo del Rivenditore e la data di vendita. La
garanzia sarà prestata con la sostituzione o la
riparazione gratuita delle parti difettose.
Non sono coperti da garanzia difetti derivanti da
uso improprio, errata installazione, manutenzione
effettuata da personale non autorizzato o,
comunque, da circostanze che non possano
riferirsi a difetti di funzionamento dell’apparecchio.
Sono inoltre esclusi dalla garanzia gli interventi
inerenti l’installazione e l’ allacciamento agli
impianti di alimentazione.
Gli apparecchi verranno riparati presso i nostri
Centri di Assistenza Autorizzati. Le spese ed i
rischi di trasporto sono a carico del cliente.
La casa costruttrice declina ogni responsabilità per
danni diretti o indiretti provocati dalla inosservanza
delle prescrizioni di installazione, uso e
manutenzione dettagliate nel presente manuale o
per guasti dovuti ad uso continuato a fini
professionali.

REGOLAZIONE DELLA TENSIONE DI
FUNZIONAMENTO DELL’APPARECCHIO

Il vostro apparecchio Marantz è stato predisposto
per l’adattamento alla tensione ed alle norme di
sicurezza esistenti nella vostra zona.
VP-12S4 può essere alimentato soltanto da
corrente alternata a 230 V.

DIRITTI D’AUTORE

La registrazione e la riproduzione di certi materiali
necessita di un permesso.
Per ulteriori informazioni consultate quanto segue:

- Copyright Act 1956

- Dramatic and Musical Performers Act 1972

- Qualsiasi legge o normativa successiva

AVVERTENZE

– Non esporre l’apparecchio alla pioggia o

all’umidità.

– Non rimuovere il coperchio dell’apparecchio.
– Non introdurre oggetti all’interno

dell’apparecchio attraverso i fori di
ventilazione.

– Non toccare il cavo di alimentazione con le

mani bagnate.

– Non coprire le fessure di ventilazione con

tovaglie, giornali, tende od oggetti analoghi.

– Non posare sull'apparecchio sorgenti di

fiamme scoperte quali candele accese.

– Smaltire le pile usate in conformità alle

norme governative o disposizioni ambientali
vigenti nel proprio paese o zona.

– Lasciare 0,2 metro liberi tutto intorno l'unità.
– Se il proiettore viene montato sul soffitto, si

deve usare per l'installazione il Corredo di
installazione sul soffitto della MARANTZ.

– Non guardare nel proiettore quando questo è

acceso. Ciò può danneggiarvi la vista.

– Se si prevede di non doverlo usare per

qualche tempo, scollegare il proiettore dalla
presa di corrente.

– Non mettere sull'apparecchiatura alcun

contenitore di liquido, come ad esempio dei
vasi.

– Quando l'interruttore è nella posizione OFF,

l'apparecchiatura non è completamente
scollegata da MAINS.

– L’apparecchio va installato in prossimità della

fonte di alimentazione, in modo che
quest’ultima sia facilmente accessibile.

Precauzioni d'uso della lampada

PERICOLO

Questa è una lampada SHP di vetro a vapori di
mercurio ad alta tensione. Potrebbe rompersi o
guastarsi se non viene maneggiata correttamente
durante la sostituzione o se il proiettore è soggetto
a una temperatura eccessiva.
La durata delle lampade è variabile ed alcune
potrebbero addirittura rompersi o non accendersi la
prima volta che vengono utilizzate. Se la lampada
si rompe, le schegge di vetro potrebbero venire
sparse all'interno dell'unità lampada e del
proiettore e il gas all'interno della lampada, che
contiene vapori di mercurio, potrebbe essere
espulso dalle aperture di ventilazione del
proiettore.
Prima dell'uso, leggere con attenzione la guida
d'uso del proiettore e le istruzioni di sostituzione
della lampada. Maneggiare sempre la lampada
con attenzione. Nel caso di guasti gravi, rivolgersi
al rivenditore autorizzato Marantz.

• Non guardare direttamente verso la lampada
accesa a occhio nudo. La luce intensa può
abbagliare e danneggiare la vista.

• Non esporre direttamente la pelle alla luce
della lampada. L'esposizioni diretta potrebbe

irritare la pelle.

• Non far cadere, urtare o sottoporre a forza
eccessiva, altrimenti si guasta la lampada.

• La sostituzione della lampada comporta il
rischio di bruciature e scosse elettriche, perciò
prima di sostituirla, spegnere l'alimentazione,
scollegare il cavo di alimentazione c.a. dalla
corrispondente presa e attendere almeno 60
minuti che la lampada si raffreddi.

• Se la lampada si rompe, scollegare il cavo di
alimentazione c.a. dalla corrispondente presa
e chiamare il rivenditore autorizzato Marantz
affinché la sostituisca. Non sostituirla
personalmente, né raccogliere le schegge di
vetro nel proiettore per non subire tagli o
bruciature e non danneggiare l'interno del
proiettore.

• Se il proiettore è appeso al soffitto o installato
in una posizione elevata, è molto pericoloso
sostituire la lampada. In questo caso, non
sostituire o maneggiare la lampada guasta
personalmente.

ATTENZIONE

• La probabilità che la lampada si rompa è
elevata dopo che è stata usata per molto
tempo. Si consiglia di sostituire la lampada
quando si avvicina al termine della vita utile.
Non usare la lampada oltre il limite della vita
utile.

• Usare unicamente lampade Marantz originali.
Verificare che il codice del modello dell'unità
lampada corrisponda a quello indicato nella
guida dell'utente.

• Prima di sostituire la lampada, leggere con
attenzione "Sostituzione dell'unità lampada"
nella guida per l'utente. Sostituire la lampada
come indicato in tali istruzioni.

• Incaricare dello smaltimento della lampada
usata un apposito servizio di smaltimento di
rifiuti industriali oppure restituirla al rivenditore.
Non rompere la lampada o gettarla con i rifiuti
normali.

• Se la lampada si rompe, lasciare il locale
immediatamente e non farvi ritorno per almeno
30 minuti; arieggiare il locale in modo da non
inalare i vapori di mercurio.

• Se vengono inalati i vapori di mercurio,
rivolgersi immediatamente a un medico e
seguirne le istruzioni.

SUOMI

VARO

Laite on liitettava suojamaadoitus-koskettimilla
varustettuun pistorasiaan.

KONGERIKET NORGE

FORSIKTIG

Apparatet ma tilkoples jordet stikkontakt.

SVENSKA

OBSERVERA

Apparaten skall anslutas till jordat uttag.

TABLE OF CONTENTS

IMPORTANT SAFEGUARDS ................................................................................................2

Caution Concerning the Setup of the Projector........................................................................2

Caution Concerning the Lamp Replacement ...........................................................................2

Caution Concerning the Lamp Unit ..........................................................................................2

Notes on Operation ...................................................................................................................2

FEATURES ............................................................................................................................3

ACCESSORIES......................................................................................................................3

PROJECTOR LAYOUT AND FUNCTIONAL OVERVIEW....................................................4

Front and Top View...................................................................................................................4

Rear and Terminals View..........................................................................................................5

Bottom View ..............................................................................................................................5

Remote Controller .....................................................................................................................6

Remote Controller Operational Range......................................................................................8

Preparing the Remote Controller...............................................................................................8

CONNECTION........................................................................................................................9

Connection with AC Power Supply............................................................................................9

Connection with Video Equipments...........................................................................................9

Connection with a HD-Video, DVD Player, Satellite, Cable Tuner or PC................................10

Advanced Connection .............................................................................................................10

INITIAL SETTING.................................................................................................................11

Turning on the Power..............................................................................................................11

Zooming and Focusing............................................................................................................11

Detail Focusing........................................................................................................................11

Adjusting the Image Position...................................................................................................12

Adjusting the Height ................................................................................................................12

Keystone Correction................................................................................................................12

INSTALLATION ...................................................................................................................13

Recommended Setting............................................................................................................13

Screen Size and Projection Distance (inch) VP-15S1............................................................14

Screen Size and Projection Distance (mm) VP-15S1 ............................................................14

Screen Size and Projection Distance (inch) VP-15S1L..........................................................15

Screen Size and Projection Distance (mm) VP-15S1L ..........................................................15

Lens shift position VP-15S1 ...................................................................................................16

Lens shift position VP-15S1L .................................................................................................17

BASIC OPERATIONS..........................................................................................................18

Turning on the Power..............................................................................................................18

Selecting the Input Signal Source ...........................................................................................18

Selecting the Aspect Mode......................................................................................................18

The Screen Images in a 16:9 screen ......................................................................................19

The Screen Images in a 4:3 screen ........................................................................................20

To Turn off the Power..............................................................................................................20

OPERATIONS......................................................................................................................21

Menu Structure........................................................................................................................21

Functions by Signal.................................................................................................................22

Picture Mode ...........................................................................................................................24

How to Operate Menus ...........................................................................................................24

Picture Adjust ..........................................................................................................................25

Fine Menu 1 ............................................................................................................................26

Fine Menu 2 ............................................................................................................................26

Input Signal .............................................................................................................................27

RGB/HD Adjust .......................................................................................................................27

HDMI .......................................................................................................................................28

Display.....................................................................................................................................28

OSD/Blanking..........................................................................................................................29

Configration.............................................................................................................................30

MAINTENANCE ...................................................................................................................31

Lamp Life and Replace Lamp .................................................................................................31

Replacing Lamp Unit...............................................................................................................31

Cleaning the Lens ...................................................................................................................33

Replacement Parts..................................................................................................................33

Optional Accessories...............................................................................................................33

TROUBLESHOOTING .........................................................................................................34

ERROR MODE.....................................................................................................................35

ON SCREEN MESSAGE .....................................................................................................35

GLOSSARY..........................................................................................................................35

SPECIFICATIONS................................................................................................................36

DIMENSIONS.......................................................................................................................37

VP-15S1..................................................................................................................................37

VP-15S1L................................................................................................................................37

– For Europe –

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. This product and
the accessories packed together are the applicable product to the WEEE directive except
batteries.
Please dispose of any materials in accordance with your local recycling regulations.
When discarding the unit, comply with your local rules or regulations.
Batteries should never be thrown away or incinerated but disposed of in accordance with
your local regulations concerning chemical wastes.

ENGLISH

1

ENGLISH

WARNING

THIS COVER IS PROVIDED WITH
INTERLOCK TO REDUCE THE RISK OF
EXCESSIVE ULTRAVIOLET RADIATION.
DO NOT DEFEAT ITS PORPOSE OR
ATTEMPT TO SERVICE WITHOUT
REMOVING COVER COMPLETELY.

MODEL NO. VP-16S1 / U1M

AC 120V 60H

Z

2.0A

SERIAL NO.

CAUTION :

HIGH PRESSURE LAMP
MAY EXPLODED IF IMPROPERLY HANDLED.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

ATTENTION :

LA LAMPE SOUS
HAUTE PRESSION PEUT SI ELLE, N'EST
PAS MANIPULEE CORRECTEMENT,
CONFIER L'OPERATION A UN
PERSONNEL D'ENTRETIEN QUALIFIE.

CAUTION HOT :

UNPLUG
THE POWER CORD AND WAIT
60 MINUTES BEFORE CHARGING
THE LAMP.

ATTENTION CHAUD :

DEBRANCER LE CORD ON
D'ALOMENTION ET ATENDER
60 MINUTES AVANT DE
CHANGER LAMPE.

M

CAUTION

HIGH PRESSURE LAMP MAY EXPLODED IF
IMPROPERLY HANDLED. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.

ATTENTION

LA LAMPE SOUS HAUTE PRESSION PEUT
EXPLOSER SI ELLE, N'EST PAS MANIPULEE
CORRECTEMENT, CONFIER L'OPERATION
A UN PERSONNEL D'ENTRETIEN QUALIFIE.

VORSICHT

:

BEI FALSCHER HANDHABUNG
KANN DIE HOCHDRUCKLAMPE
EXPLODIEREN UBERLASSEN
SIE WARTUNGSARBEITEN
NUR FACHPERSONAL.

MMODEL NO. VP-12S1 / N1S

MADE IN JAPAN

FABRIQUE AU JAPON

AC 120V 60H

Z

2.0W

SERIAL NO.

CAUTION :

HIGH PRESSURE LAMP
MAY EXPLODED IF IMPROPERLY HANDLED.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

ATTENTION :

LA LAMPE SOUS
HAUTE PRESSION PEUT SI ELLE, N'EST
PAS MANIPULEE CORRECTEMENT,
CONFIER L'OPERATION A UN
PERSONNEL D'ENTRETIEN QUALIFIE.

CAUTION HOT :

UNPLUG
THE POWER CORD AND WAIT
60 MINUTES BEFORE CHARGING
THE LAMP.

ATTENTION CHAUD :

DEBRANCER LE CORD ON
D'ALOMENTION ET ATENDER
60 MINUTES AVANT DE
CHANGER LAMPE.

WARNING

THIS COVER IS PROVIDED WITH
INTERLOCK TO REDUCE THE RISK OF
EXCESSIVE ULTRAVIOLET RADIATION.
DO NOT DEFEAT ITS PORPOSE OR
ATTEMPT TO SERVICE WITHOUT
REMOVING COVER COMPLETELY.

CAUTION HOT

UNPLUG THE POWER CORD AND
WAIT 60 MINUTES BEFORE
CHANGING THE LAMP.

ATTENTION CHAUD

DEBRANCER LE CORD ON
D'ALIMENTION ET ATENDER 60
MINUTES AVANT DE CHANGER
LAMPE.

WARNUNG HEISS

ZIEHEN SIE DEN NETZSTECKER
AB UND WARTEN SIE 60 MINUTEN,
BEVOR SIE DIE GLUHLAMPE
WECHSELN.

95˚F
(+35˚C)

41˚F
(+5˚C)

IMPORTANT SAFEGUARDS

Caution Concerning the Lamp Replacement

There is potential glass particle hazard if the lamp ruptures.

Caution Concerning the Lamp Unit

There is a potential hazard of glass particle if the lamp ruptures.
In case of lamp rupture,contact your nearest Marantz Authorized Dealer or Service Center for a
replacement.
See “Replacing Lamp Unit”. (☞P.31)

Caution

Concerning the Setup of the Projector

For minimal servicing and to maintain high image quality, avoid humidity, dust and cigarette smoke.
When the projector is subjected to these environments,the lens and part of ventilation holes must be cleaned
more often than usual. As long as the projector is properly maintained in this manner, use in these
environments will not reduce the overall operation life. Please note that all internal cleaning must be
performed by an Marantz Authorized Dealer, or Service Center.

• Do not expose the projector to extreme heat or cold.
Operating temperature:41 °F to 95 °F (+5 °C to 35 °C)
Storage temperature:–4 °F to 140 °F (–20 °C to +60 °C)

Notes on Operation

For USA

For Europe

2

• The exhaust ventilative hole, the lamp cage cover and adjacent areas may get extremely hot during

For USA

projector operation. To prevent injury,do not touch these areas until they have sufficiently cooled
down.

• Allow at least 1 foot (30 cm)of space between the exhaust ventilative hole and the nearest wall or
obstruction.

• If the cooling fan becomes obstructed, a protection device will automatically turn off the projector lamp.
This does not indicate a malfunction. Remove the projector power cord from the wall outlet and wait at
least 10 minutes.
Then turn on the power by plugging the power cord back in. This will return the projector to the normal

For Europe

operating condition.

FEATURES

INPUT

V-MUTE

ENTER

MENU

ASPECT

FULL

CINEMA

VCR MODE

BLACK LEVEL

PATTERN

BLACK

NOR ZOOM THRU

INFO.

C1 C2 S G1

H1 H2 V G2

A1

A2 RGB G3

STD DYN

I

M

A

G4

THTR

COMP.1 COMP.2 S-VIDEO USER

HDMI 1 HDMI 2 VIDEO

AUX 1

BLANKING

AUX 2

RC-11VPS1

REMOTE CONTROLLER

ON

STANDBY

IRIS LAMP

C.TEMP GAMMA

B1 OFFB3B2

Incorporates the latest DLP®chip -- “1080p DLP®” (1920 x 1080 pixel, 16:9 wide panel). Using an

•

optimized system for movie viewing with specially designed image circuits and optical parts, the VP­15S1 bring high color reproduction with the pitch black of movie films that reproduces images in rich
tones and crisp black.

Images are sharply detailed, smooth and high quality owing to a powerful chip that builds into a

•

dedicated processor an image processing IC featuring Gennum’s proud “VXPTM” high quality
contouring technology, “TruMotionHDTM”, “FineEdgeTM”, “RealityExpansionTM” and “FidelityEngineTM”.

Konica Minolta optical system custom-made for Marantz.

•

A large 98mm 6-segment color wheel.

•

4 Picture Modes (Theater, Standard, Dynamic, User)

•

5 built-in preset gammas

•

Fine-adjustment menus that allow the user to adjust images as they like

•

18 user menus for saving adjusted images

•

Color temperature setting (5250K, 5800K, 6500K, 7500K, 9300K)

•

Black level adjustment

•

Supports input of NTSC, PAL, SECAM and satellite broadcasts (480i/p, 540p, 576i/p, 720p, 1035i,

•

1080i/p).
Rich array of input jacks including HDCP supporting HDMI digital input jack and dual system

•

component jacks

1.45x zoom lens

•

Lens shift feature for vertically positioning the projection point

•

Digital correction of vertical keystone distortion

•

Projection modes for functional, hanging and rear projection

•

Remote controller with all back-lit keys

•

Equipped with RS-232C port and 12V trigger terminal for custom installation

•

Marantz system bus port

•

Low operating noise thanks to a die-cast silent duct, hermetically sealed color wheel motor and fan speed

•

control
Highly rigid die-cast chassis to minimize radiating noise

•

2000 hr long-life 200W SHP lamp with double-shielded safety structure

•

– Digital Light Processing, DLP, DLP logo and DLP Medallion logo are registered trademarks of Texas

Instruments.

– VXP, Visual Excellence Processing and the VXP Logo are trademarks or registered trademarks of

Gennum Corporation.

– All trademarked product names mentioned in this manual are the property of their respective

companies.

– HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered

trademarks of HDMI Licensing LLC.

ACCESSORIES

• Lens Cap x 1

• Remote Controller x 1

• AAA Size Batteries x 2

• AC Power Code

For USA
00MZC01802110

For Europe
00MZC02003190

• User Guide x 1

• Warranty Card

(1 copy each for USA, CANADA)

Comes with USA model only.

ENGLISH

3

ENGLISH

PROJECTOR LAYOUT AND FUNCTIONAL OVERVIEW

Front and Top View

!3

Projection

Lens

!4

IR sensor

q Focus ring (

Adjust the picture focus.

w Zoom ring (

Adjust the size of the projected image.

e Lens Shift knob (

Manually adjust the position of the image vertically.

r / I button (

Press to turn the projector ON or STANDBY mode.

t MENU button (

Display the on-screen menu.

☞

☞

☞

☞

P.11)

P.11)

☞

P.18)

P.21)

P.12)

y ENTER button

Press to enter the selected menu item.

u INPUT SELECT button (

Selects the input signal (COMPONENT 1,
COMPONENT 2, S-VIDEO, VIDEO, RGB, HDMI 1
and HDMI 2).

i PATTERN button (

Projects a focus pattern on the screen.

☞

☞

P.11)

P.18)

o The 3 / 4 / 1 / 2 buttons

Control the MENU cursor.

!0 ON indicator

Lights up blue when power is ON. When power is
shut OFF, the lamp flashes for about 1 minute
before going out.

!1 STANDBY indicator

Lights up green when the projector is on standby.

!2 WARNING/LAMP indicator

Flashes or lights up when something is wrong with
the lamp cover, lamp, fan, or temperature inside
the projector.
For more information on the error mode, see the
“Error Mode List” (☞P.35)

!3 Ventilation holes (intake)
!4 Ventilation holes (exhaust)

Notes:

• Do not place anything near the ventilation
holes to avoid overheat inside the unit.

• Do not place your hand or objects near the
ventilation holes; the air is coming out.

Note: Pixel defects

DLP®chip is one of the most advanced
technologies for consumer products. The
DLP®chip made by high precision technology,
however some pixel defects may be found on
the projected image. We are trying our best to
control the quality in order to reduce the
number of defective pixels. It is almost
impossible to have zero pixel defects, even
using the most advanced technology. This is
not a problem only for Marantz, but all DLP
projector manufactures. Therefore we have to
note that the warranty does not cover the
DLP®chip for pixel defects. We appreciate
your understandings.

Note: Lamp

SHP lamp is one of the most advanced
technologies for consumer products. The
lamp made by high precision technology,
however some lamps might be failing before it
reaches its life. And projector’s brightness is
getting darker along with accumulated lamp
usage hours. We are trying our best to control
the quality in order to reduce lamp failures. It
is almost impossible to have zero failure, even
using the most advanced technology. This is
not a problem only for Marantz, but all
projector manufactures. Therefore we have to
note that the warranty does not cover the SHP
lamp for lamp failures: explosion, and non­lighting except initial use. And also we have to
note that the warranty does not cover the SHP
lamp for lamp failures: flickering, and getting
darker along with accumulated lamp usage
hours. We appreciate your understandings.

®

4

Rear and Terminals View

Bottom View

IR sensor

Ventilation holes

(exhaust)

Lamp cover

Lamp cover

securing screw

z AC IN (

Connect the supplied AC power code.

☞

P. 9)

x RGB IN

Connect the analog RGB output from an IBM VGA
or compatible equipment.

c COMPONENT VIDEO IN 1 and 2

Terminals 1 and 2 have each Y, PB/CB, PR/C
terminals. Connect them to the component video
output of a video device, AV amp/processor, DVD
player, etc.

v S-VIDEO IN

Connect the S-VIDEO output from a video
equipment.

b VIDEO IN

Connect the composite video output from a video
equipment.

Ventilation holes (intake)

n TRIG.1(TRIGGER 1)

When the unit is turned on, 12V is output. When the
unit is turned off, no voltage is output. This allows
such as a powered up/down screen,whenever the
projector is turned on or off.

Note:

• Do not use TRIG.1, as the power source.

• To connect with external devices, use an

R

ordinal 3.5mm mini-plug (mono) cable.

m REMOTE IN/OUT

By connecting this projector to another Marantz
audio component using a supplied System Control
cable, you can remotely operate the components
as a single system.

• When connecting to component with a remote
sensor (such as the SR9500,SR8500), be sure
to connect the "REMOTE CONTROL IN" jack
of this projector to the "REMOTE CONTROL
OUT" jack of the component with the remote
sensor.

Note:

For connections, use the control adaptor cable.
(Mini jack to RCA)

, TRIG.2(TRIGGER 2)

Select ON or OFF at each aspect mode, such as
Full, Normal, Zoom, V-Stretch and Through to
control screen aspect ratio with powered up/down
dual aspect ratio screen.

Notes:

• Do not use TRIG.2, as the power source.

• To connect with external devices, use an

ordinal 3.5mm mini-plug (mono) cable.

. HDMI IN 1 and 2

Connect the digital signal (TMDS compliant, single
link only)

Note:

To use the HDMI terminal, please follow the
cautions on page 10.

⁄0 RS-232C

This is the control port for the custom installer.

Ventilation holes (intake)

x

z

Adjustable
feet

x

z Adjustment lever (

Lift the projector and turn the adjustment lever right
or left. The adjustable feet will extend from the
projector. Then, release the lever, the adjustable
feet is locked.

Adjustable feet

☞

x Screw holes for ceiling mount kit

z

P.12)

ENGLISH

5

ENGLISH

INPUT

V-MUTE

ENTER

MENU

ASPECT

FULL

CINEMA

VCR MODE

BLACK LEVEL

PATTERN

BLACK

NOR ZOOM THRU

INFO.

C1 C2 S G1

H1 H2 V G2

A1

A2 RGB G3

STD DYN

I

M

A

G4

THTR

COMP.1 COMP.2 S-VIDEO USER

HDMI 1 HDMI 2 VIDEO

AUX 1

BLANKING

AUX 2

RC-11VPS1

REMOTE CONTROLLER

ON

STANDBY

IRIS LAMP

C.TEMP GAMMA

B1 OFFB3B2

a

™9

£0
£1
£2

£3
£4

£5
£6

£8
£9

sdfg

hjk
l¡0¡1
¡2¡3¡4
¡5¡6¡7

¡8¡9 ™0 ™1

™2
™3

™4
™5

™6

™7 ™8

¢0

£7

¢1

Remote Controller

6

a STANDBY button (

Turn the projector off.

☞

P.20)

s IRIS button

Switches lens and illumination aperture.

d LAMP button

Switches the lamp between the normal and
energy-saving modes.

f C.TEMP button

Sets color temperature to 1, 2, 3, 4, 5 or HB.

g GAMMA button

Sets the gamma curve to Theater, Standard,
Dynamic, A, B, C, D or E, when the picture mode is
set to User.

h COMP. 1 (Component video in 1)

button (

Selects the device connected to the COMPONENT
VIDEO IN 1 jack as the input source.

☞

P.18)

j COMP. 2 (Component video in 2)

button (

Selects the device connected to the COMPONENT
VIDEO IN 2 jack as the input source.

k S-VIDEO button (

Select the S-VIDEO IN signal.

l HDMI 1 button (

Select the HDMI 1 IN signal.

¡0 HDMI 2 button (

Select the HDMI 2 IN signal.

¡1 VIDEO button (

Select the VIDEO IN signal.

☞

P.18)

☞

☞

☞

☞

P.18)

P.18)

P.18)

P.18)

¡2 A1 button

This button does not work with this projector.

¡3 A2 button

This button does not work with this projector.

¡4 RGB button (

Select the RGB IN signal.

☞

P.18)

¡5

THEATER (THTR) button (

Select the Theater picture mode.
Theater mode is designed for high fidelity black
appearance and is good for movie pictures.
Every time THTR button is pressed, the selection
rotates in the order of Theater 1 ➔Theater 2
Theater 3 ➔Default.

¡6

STANDARD (STD) button (

Select the STANDARD picture mode.
Standard mode is good for normal pictures.
Every time the button is pressed, the selection
rotates in the order of Standard 1 ➔Standard 2
Standard 3 ➔Default.

¡7 DYNAMIC (DYN) button (

Select the Dynamic picture mode.
Dynamic mode is good for visually dynamic
pictures.
Every time the button is pressed, the selection
rotates in the order of Dynamic 1 ➔Dynamic 2
Dynamic 3 ➔Default.

¡8 B1 button (

Selects Blanking Memory 1.

¡9 B2 button (

Selects Blanking Memory 2.

™0 B3 button (

Selects Blanking Memory 3.

™1 OFF button (

Turns the blanking mode off.

☞

☞

☞

☞

P.29)

P.29)

P.29)

P.29)

☞

☞

☞

P.24)

➔

P.24)

➔

P.24)

➔

™2 V-MUTE button

Turn the picture into black. Press again to resume.

™3 3 / 4 / 1 / 2 / ENTER buttons

Press the cursor buttons (3 [UP], 4 [DOWN], 1
[LEFT], 2 [RIGHT]) to select menu items. Press
the ENTER button to enter the selected menu item.

™4 ASPECT (Aspect select) button

(

P.18)

☞

Selects the aspect ratio. Every time the button is
pressed, the selection rotates in the order of Full
Normal ➔Zoom ➔V-Stretch ➔Through.

™5 VCR MODE button (

Turns the VCR mode on and off.

☞

P.26)

➔

™6 CINEMA button (

Turns the 2-3 pull down mode on and off.

™7 FULL button (

Sets aspect ratio to full mode.

☞

™8 NORMAL button (

Sets aspect ratio to normal mode.

™9 ON button (

Turn the projector on.

☞

£0 USER G1 button (

Selects the user mode.
The user mode is for enjoying images at a user­selected gamma curve.
Every time the button is pressed, the selection
rotates in the order of User 1 ➔User 2 ➔User 3.
For more information on how to select gamma
curve. (☞P.25)

£1 USER G2 button (

Selects the user mode.
The user mode is for enjoying images at a user­selected gamma curve.
Every time the button is pressed, the selection
rotates in the order of User 4 ➔User 5 ➔User 6.
For more information on how to select gamma
curve. (☞P.25)

£2 USER G3 button (

Selects the user mode.
The user mode is for enjoying images at a user­selected gamma curve.
Every time the button is pressed, the selection
rotates in the order of User 7 ➔User 8 ➔User 9.
For more information on how to select gamma
curve. (☞P.25)

☞

P.18)

☞

P.18)

☞

☞

☞

P.26)

P.18)

P.24)

P.24)

P.24)

£3 USER G4 button

This button does not work with this projector.

£4 LIGHT button

Lights all buttons for about 10 sec.

£5 MENU button (

Display the on-screen menu.
If pressed again, the on-screen menu disappears.

£6 INFO. button (

Turn the information menu on or off.

☞

☞

P.21)

P.31)

£7 INPUT (Input signal select)

button (

Selects the input signal. Every time the 3/4
buttons are pressed, the input signal rotates in the
order of COMPONENT 1 ↔ COMPONENT 2 ↔ S-
VIDEO ↔ VIDEO ↔ RGB ↔ HDMI 1 ↔ HDMI 2.

£8 BLACK LEVEL button (

Sets the black level.

During analog signal input ......0 IRE/7.5 IRE

During HDMI signal input........Expand/Normal

☞

P.18)

☞

P.26)

ENGLISH

£9 PATTERN button (

Projects a focus pattern on the screen.

¢0 ZOOM button (

Sets aspect ratio to zoom mode.

☞

¢1 THROUGH button (

Sets aspect ratio to through mode.

☞

P.18)

☞

P.11)

P.18)

7

ENGLISH

Remote Controller Operational Range

Operate the remote controller within a distance of approximately 5m from the IR sensor (remote sensor)
on the projector.
Remote control operation may not be possible if the remote control unit’s transmitter is not pointing in the
direction of the remote sensor or if there is an obstruction between the transmitter and the remote sensor.

Remote
Controller

5m

Remote

Controller

Remote

Controller

5m

5m

60

VP-15S1

60

VP-15S1

Remote
Controller

120

60

Remote

Controller

5m

Preparing the Remote Controller

1. Take the cover off the battery case on the

remote control backside.

Battery case cover

2. Insert two AAA size batteries.

Make sure the polarities match the + and –
marks inside the battery compartment.

AAA size batteries

3. Reattach the battery case cover as before.

Battery case cover

Notes :

•

Do not mix alkaline and manganese batteries.

• Do not mix old and new batteries.

CAUTIONS ON BATTERIES

• Use AAA alkaline batteries in this remote
controller.

• If the remote control unit does not operate
from close to the main unit, replace the
batteries with new ones, even if less then a
year has passed.

• The included battery is only for verifying
operation. Replace it with a new battery as
soon as possible.

• When inserting the batteries, be careful to
do so in the proper direction, following the +
and - marks in the remote control unit’s
battery compartment.

• To prevent damage or battery fluid leakage:

- Do not use a new battery with an old one.

- Do not use two different types of batteries.

- Do not short-circuit, disassemble, heat or
dispose of batteries in flames.

• Remove the batteries when not planning to
use the remote control unit for a long period
of time.

• If the batteries should leak, carefully wipe off
the fluid from the inside of the battery
compartment, then insert new batteries.

• When disposing of used batteries, please
comply with governmental regulations or
environmental public instruction’s rules that
apply in your country or area.

5m

60

VP-15S1

8

CONNECTION

FL OFF

STANDBY

FL OFF

STANDBY

S-VIDEO OUT

VIDEO OUT

COMPONENT VIDEO OUT

COMPONENT VIDEO OUT

❖ When making connections be sure to:

• Turn off all equipment before making any connections.

• Use the proper cables for each connection.

• Securely insert the plug into the port to connect cables. Loose cables can lead to trouble and damage.

❖ When pulling out a cable:

• Be sure to grab the plug, not the cable itself.

Connection with AC Power Supply

Connect the supplied AC power cord into the AC IN socket of the projector.
The STANDBY indicator lights up and the projector goes into the standby mode.

Note : Make sure the AC power cord is firmly connected into the AC IN socket.

Connection with Video Equipments

You can connect this projector to a VCR, DVD player and other video equipment.

Connecting a video source using S-VIDEO IN and VIDEO IN terminals.

1. Connect one of the S-video cable to the S-VIDEO IN terminal, or one end of the video cable to the VIDEO

IN terminal on the projector.

2. Connect the other end of the S-video cable or the video cable to the S-video output terminal or video

output terminal of the video source.

Connecting a DVD player to the COMPONENT VIDEO IN 1 or 2 terminal

(Devices can be connected to both terminals at the same time.)

1. Connect the individual terminals of the component video cable into the COMPONENT VIDEO IN 1 or 2

terminal of the projector.

2. Connect the other end of the cable to the corresponding terminals on a DVD player.

Component cable

(commercially available)

DVD Player

Component cable

(commercially available)

ENGLISH

SUOMI

VARO

Laite on liitettava suojamaadoitus-koskettimilla varustettuun pistorasiaan.

KONGERIKET NORGE

FORSIKTIG

Apparatet ma tilkoples jordet stikkontakt.

SVENSKA

OBSERVERA

Apparaten skall anslutas till jordat uttag.

DVD Player

S-video cable (commercially available)

Video cable

(commercially available)

VCR

9

ENGLISH

RGB OUT

or

DVI-D out

RGB OUT

or

DVI-D out

REMOTE CONTROL IN

REMOTE CONTROL OUT

RS-232C

Connection with a HD-Video, DVD Player, Satellite, Cable Tuner or PC

You can connect this projector to HD-Video /PC using RGB IN port, or DVD Plyer /Satellite /Cable Tuner
/PC using HDMI IN port.

1. Connect one end of the RGB cable to the RGB IN port, or one end of the HDMI cable to the HDMI IN

port on the projector.

2. Connect the other end to the corresponding port on a HD-Video, Satellite, Cable Tuner or personal

computer.

3. If using DVI-A or DVI-D output, use respectively a DVI-A-RGB or DVI-D-HDMI conversion cable.

Note : When projecting a video image from a device connected to the HDMI terminal, follow the

procedure below.

1. Turn on power of this unit. (☞P.18)

2. Set the input video source to HDMI input. (☞P.18)

3. Turn on power of the device connected to the HDMI terminal of the unit (i.e. DVD player).
If the procedure above is not followed, projected image may corrupt.
For the details of the HDMI terminal on the device connected with the unit, see the instruction
manual of the device.

RGB (D-Sub monitor) cable

(commercially available)

RGB OUT

or

DVI-A OUT

HD-Video / Satellite /

DVI-D OUT

or

HDMI OUT

Cable Tuner / DVD Player

Advanced Connection

You can control total home theater system using PC or Marantz receiver equipment.
For installing below system, consult with Marantz authorized dealer.

RS-232C cable
(female-female, straight type,
commercially available)

External Controller

3.5mm Mini Plug (Mono)
(commercially available)

Control Adapter cable

(commercially available)

Control Adapter cable

(commercially available)

Receiver equipment

Screen

10

HDMI-HDMI cable or HDMI-DVD-D cable

(commercially available)

Monitor output

RGB out

or

DVI-D out

IBM VGA or

Compatible PC

INITIAL SETTING

Turning on the Power

1. Connect the supplied AC power cord. (

2. Press the ON button on the remote controller or the / I button on the projector.

The ON indicator lights up.

Zooming and Focusing

Project an image on the screen roughly at first.

1. Turn the Zoom ring and adjust to the desired size

within the zoom range.
WIDE: Enlarges (zooms in) the projected image.
TELE: Reduces (zooms out) the projected image.

2. Turn the Focus ring until the image on the screen

becomes clear.

☞

P.9)

WIDE

STANDBY

IRIS LAMP

C.TEMP GAMMA

COMP.1 COMP.2 S-VIDEO USER

C1 C2 S G1

HDMI 1 HDMI 2 VIDEO

H1 H2 V G2

AUX 1 AUX 2

A1

A2 RGB G3

STD DYN G4

THTR

Detail Focusing

You can strictly focus the image with focus pattern.

1. Press the PATTERN button to project the focus pattern on the screen.

V-MUTE

ASPECT

ON

2. Turn the Focus ring to make an adjustment.

Adjust the focus for the sharpest image possible to obtain, using focus pattern.

3. Press the PATTERN button again to hide the focus pattern. This completes fine focusing.

Note :

Focus Pattern Color by Lens Shift Position (☞P.16)

The focus pattern changes color depending on the lens position. There are two colors and they can
be used for checking the quality of the projected image. The white focus pattern uses the highest
optical performance to maximize the sharpness of the projected image. To enjoy the highest

1.

2.

sharpness, it is recommended to position the lens within this range.
When the lens is shifted outside the aforementioned range, the focus pattern turns green. Rough
focusing in this range looses image sharpness.
Adjusting the zoom position from WIDE to TELE enhances sharpness even at the same lens
position.

A

CINEMA

FULL

MENU

M

ENTER

I

INFO.

VCR MODE

BLACK LEVEL

BLACK

NOR ZOOM THRU

ENGLISH

INPUT

PATTERN

TELE

11

ENGLISH

Adjusting the Image Position

You can adjust the image position with the Lens Shift knob.

❖ Turn the Lens Shift knob to clockwise : The image goes up.

Up

Clockwise

Adjusting the Height

You can position the projected image by changing the
height of the projector’s adjusters.

1. Move the adjuster lever to the left or right to

enable adjuster changing. Carefully lift the
projector.

2. Once having positioned the projector, return the

adjuster lever as before to lock in place. Check
the adjusters are securely locked before
releasing your hands from the projector.

3. Turn the adjuster to fine-adjust the height.

❖ Returning the Projector to its Initial Position

Slightly lift the projector, turn the adjuster lever to the left or right, then carefully set the projector down.

❖ Turn the Lens Shift knob to counterclockwise : The image goes down.

Counterclockwise

Down

Keystone Correction

When the projecting image is a trapezoid, correct it in Keystone and in the Display Menu.
See “Display”. (
When using the keystone feature to correct a trapezoidal image, picture contours can look like staircases
because of image correction.

☞

P.28)

❖ Keystone

(Electronic keystone correction)

12

INSTALLATION

Recommended Setting

❖ Installing on a tabletop

Screen

Screen upper end

Screen size (vertical)

Light axis (center)

Installing level

Screen lower end

Range from light axis to upper
end

Height from installing level to light axis

Projection distance

Lens shift range

❖ Mounting on the ceiling

Screen

Screen upper end

Range from light axis to upper end

Light axis (center)

Screen size (vertical)

Screen lower end

Projection distance

Height from installing
level to light axis

ENGLISH

Lens shift range

lens head

lens head

CAUTION

– For ceiling installation, consult with Marantz authorized dealer.
– Do not look into the lens when the projector is turned on. It could damage your eyesight.

13

ENGLISH

Diagonal Width Height Minimum Maximum

inch inch inch inch inch

70
72
80
82
84
90

92
100
106
110
120
123
133
135
150
170
200
250

56

57 10/16

64

65 10/16

67 3/16

72

73 10/16

80

84 13/16

88
96

98 6/16

106 6/16

108
120
136
160
200

42

43 3/16

48
49 3/16
50 6/16

54
55 3/16

60

63 10/16

66

72

73 13/16
79 13/16

81

90

102
120
150

108 8/16

111 10/16

124 5/16
127 7/16

130 10/16

140 1/16
143 4/16

155 14/16

165 6/16

171 11/16

187 8/16
192 4/16

208

211 3/16

234 14/16

266 8/16
313 14/16
392 14/16

158 5/16

162 14/16

181 3/16

185 13/16

190 6/16
204 2/16

208 11/16

227
240 12/16
249 14/16
272 12/16
279 10/16

302 9/16
307 2/16
341 7/16
387 4/16

455 14/16

570 6/16

To calculate the installation measurement (unit : inch)

Minimum = 1 9/16 x Screen Size - 2 2/16
Maximum= 2 5/16 x Screen Size - 1 15/16

Note :

When installing the projector, consider ±5% tolerance for the Projection Distance in the above table.

4:3 Screen Size (1.33:1 Aspect Ratio) Projection Distance

Diagonal Width Height Minimum Maximum

inch mm mm mm mm

70
72
80
82
84
90

92
100
106
110
120
123
133
135
150
170
200
250

To calculate the installation measurement (unit : mm)

Minimum = 32.8 x Screen Size - 53.4
Maximum= 47.5 x Screen Size - 48.8

Note :

When installing the projector, consider ±5% tolerance for the Projection Distance in the above table.

16:9 Screen Size (1.77:1 Aspect Ratio) Projection Distance

1550
1594
1771
1815
1860
1992
2037
2214
2347
2435
2657
2723
2944
2989
3321
3763
4428
5535

872
897

996
1021
1046
1121
1146
1245
1320
1370
1494
1532
1656
1681
1868
2117
2491
3113

2243
2308
2571
2636
2702
2899
2964
3227
3423
3555
3883
3981
4309
4375
4867
5523
6507
8147

3276
3371
3751
3846
3941
4226
4321
4701
4986
5176
5651
5794
6269
6364
7076
8026
9451

11826

Diagonal Width Height Minimum Maximum

inch mm mm mm mm

70
72
80
82
84
90

92
100
106
110
120
123
133
135
150
170
200
250

To calculate the installation measurement (unit : mm)

Minimum = 40.1 x Screen Size - 53.4
Maximum= 58.1 x Screen Size - 48.8

Note :

When installing the projector, consider ±5% tolerance for the Projection Distance in the above table.

4:3 Screen Size (1.33:1 Aspect Ratio) Projection Distance

1422
1463
1626
1666
1707
1829
1869
2032
2154
2235
2438
2499
2703
2743
3048
3454
4064
5080

1067
1097
1219
1250
1280
1372
1402
1524
1615
1676
1829
1875
2027
2057
2286
2591
3048
3810

2754
2834
3155
3235
3315
3556
3636
3957
4197
4358
4759
4879
5280
5360
5962
6764
7967
9972

4018
4134
4599
4715
4832
5180
5296
5761
6110
6342
6923
7098
7679
7795
8666

9828
11571
14476

Screen Size and Projection Distance (inch) VP-15S1

Screen Size and Projection Distance (mm) VP-15S1

❖ 16 : 9 Screen

In case of displaying the 16:9
picture on the whole of the
16:9 screen.

Width

Height

: Image size = Screen size

Screen size

(Diagonal)

Screen

VP-12S1

Projection distance

16:9 Screen Size (1.77:1 Aspect Ratio) Projection Distance

Diagonal Width Height Minimum Maximum

inch inch inch inch inch

70
72
80
82
84
90

92
100
106
110
120
123
133
135
150
170
200
250

To calculate the installation measurement (unit : inch)

Minimum = 1 5/16 x Screen Size - 2 2/16
Maximum= 1 14/16 x Screen Size - 1 15/16

Note :

When installing the projector, consider ±5% tolerance for the Projection Distance in the above table.

61
62 12/16
69 12/16

71 8/16
73 3/16
78 7/16
80 3/16
87 3/16
92 6/16

95 14/16

104 9/16

107 3/16
115 15/16
117 11/16
130 12/16

148 3/16

174 5/16
217 14/16

34 5/16
35 5/16
39 4/16
40 3/16
41 3/16
44 2/16
45 2/16

49
51 15/16
53 15/16
58 13/16

60 5/16
65 3/16
66 3/16
73 9/16
83 6/16
98 1/16

122 9/16

88 6/16

90 15/16
101 5/16
103 14/16
106 7/16
114 3/16
116 13/16
127 2/16
134 14/16
140 1/16

153
156 14/16
169 12/16
172 6/16
191 12/16
217 9/16
256 6/16

321

129 1/16
132 13/16
147 13/16

151 9/16

155 5/16

166 8/16

170 4/16

185 4/16

196 7/16
203 15/16
222 11/16

228 4/16

247
250 12/16
278 13/16

316 4/16
372 6/16

465 15/16

❖ 16 : 9 Screen

In case of displaying the 16:9
picture on the whole of the
16:9 screen.

Width

: Image size = Screen size

Height

Screen size

(Diagonal)

Screen

VP-12S1

Projection distance

❖ 4 : 3 Screen

In case of displaying the 16:9
picture on the whole of the 4:3
screen.

14

Width

: Image size

: Screen size

Height

❖ 4 : 3 Screen

In case of displaying the 16:9
picture on the whole of the 4:3
screen.

Width

Height

: Image size

: Screen size

Screen Size and Projection Distance (inch) VP-15S1L

Diagonal Width Height Minimum Maximum

inch inch inch inch inch

60
70
72
80
82
84
90

92
100
106
110
120
123
133
135
150
170
200
250
300

48
56

57 10/16

64

65 10/16

67 3/16

72

73 10/16

80

84 13/16

88
96

98 6/16

106 6/16

108
120
136
160
200
240

36
42

43 3/16

48
49 3/16
50 6/16

54
55 3/16

60

63 10/16

66

72

73 13/16
79 13/16

81

90

102
120
150
180

-

157 11/16

162 4/16
180 9/16
185 3/16

189 12/16

203 8/16
208 1/16
226 6/16
240 2/16
249 4/16
272 2/16

279

301 14/16

306 8/16
340 13/16
386 10/16

455 4/16
569 12/16

684 3/16

203 13/16

238 4/16
245 2/16

272 10/16

279 8/16
286 6/16

307

313 15/16

341 7/16
362 1/16

375 13/16

410 3/16

420 9/16
454 15/16
461 13/16

513 6/16

582 3/16

685 6/16

857 6/16
1029 6/16

To calculate the installation measurement (unit : inch)

Minimum = 3 7/16 x Screen Size - 2 9/16
Maximum= 2 5/16 x Screen Size - 2 9/16

Note : When installing the projector, consider ±5% tolerance for the Projection Distance in the above table.

4:3 Screen Size (1.33:1 Aspect Ratio) Projection Distance

Diagonal Width Height Minimum Maximum

inch mm mm mm mm

60
70
72
80
82
84
90

92
100
106
110
120
123
133
135
150
170
200
250
300

To calculate the installation measurement (unit : mm)

Minimum = 71.3 x Screen Size - 64.4
Maximum= 47.5 x Screen Size - 64.8

Note : When installing the projector, consider ±5% tolerance for the Projection Distance in the above table.

16:9 Screen Size (1.77:1 Aspect Ratio) Projection Distance

1328
1550
1594
1771
1815
1860
1992
2037
2214
2347
2435
2657
2723
2944
2989
3321
3763
4428
5535
6641

747
872
897

996
1021
1046
1121
1146
1245
1320
1370
1494
1532
1656
1681
1868
2117
2491
3113
3736

-

-

-
3735
3830
3925
4210
4305
4685
4970
5160
5635
5778
6253
6348
7060
8010
9435

11810
14185

-

-

-
5640
5782
5925
6353
6495
7066
7493
7779
8492
8706
9419
9561

10631
12057
14196
17761
21326

Diagonal Width Height Minimum Maximum

inch mm mm mm mm

60
70
72
80
82
84
90

92
100
106
110
120
123
133
135
150
170
200
250
300

To calculate the installation measurement (unit : mm)

Minimum = 87.3 x Screen Size - 64.4
Maximum= 58.1 x Screen Size - 64.8

Note : When installing the projector, consider ±5% tolerance for the Projection Distance in the above table.

4:3 Screen Size (1.33:1 Aspect Ratio) Projection Distance

1219
1422
1463
1626
1666
1707
1829
1869
2032
2154
2235
2438
2499
2703
2743
3048
3454
4064
5080
6096

914
1067
1097
1219
1250
1280
1372
1402
1524
1615
1676
1829
1875
2027
2057
2286
2591
3048
3810
4572

-
4002
4118
4583
4699
4816
5164
5280
5745
6094
6326
6907
7082
7663
7779
8650
9812

11555
14460
17365

5174
6047
6221
6920
7094
7269
7793
7967
8666
9189

9539
10412
10674
11547
11721
13031
14777
17396
21761
26126

Screen Size and Projection Distance (mm) VP-15S1L

❖ 16 : 9 Screen

In case of displaying the 16:9
picture on the whole of the
16:9 screen.

Width

Height

: Image size = Screen size

Screen size

(Diagonal)

Screen

VP-12S1

Projection distance

16:9 Screen Size (1.77:1 Aspect Ratio) Projection Distance

Diagonal Width Height Minimum Maximum

inch inch inch inch inch

60
70
72
80
82
84
90

92
100
106
110
120
123
133
135
150
170
200
250
300

To calculate the installation measurement (unit : inch)

Minimum = 2 13/16 x Screen Size - 2 9/16
Maximum= 1 14/16 x Screen Size - 2 9/16

Note : When installing the projector, consider ±5% tolerance for the Projection Distance in the above table.

52 5/16

61
62 12/16
69 12/16

71 8/16
73 3/16
78 7/16
80 3/16
87 3/16

92 6/16
95 14/16
104 9/16
107 3/16

115 15/16
117 11/16
130 12/16

148 3/16
174 5/16

217 14/16

261 8/16

29 7/16
34 5/16
35 5/16
39 4/16
40 3/16
41 3/16
44 2/16
45 2/16

49
51 15/16
53 15/16
58 13/16

60 5/16
65 3/16
66 3/16
73 9/16
83 6/16

98 1/16
122 9/16
147 1/16

-

-

-

147 3/16
150 15/16
154 10/16
165 14/16
169 10/16
184 10/16
195 13/16

203 5/16

222

227 10/16

246 6/16

250 2/16

278 3/16
315 10/16
371 12/16

465 5/16
558 14/16

-

-

-

222 3/16

227 13/16

233 7/16
250 5/16

255 15/16

278 6/16
295 4/16
306 8/16
334 9/16

343

371 1/16
376 11/16
418 14/16

475

559 5/16
699 12/16

840 4/16

❖ 16 : 9 Screen

In case of displaying the 16:9
picture on the whole of the
16:9 screen.

Width

: Image size = Screen size

Height

Screen size

(Diagonal)

ENGLISH

Screen

VP-12S1

Projection distance

❖ 4 : 3 Screen

In case of displaying the 16:9
picture on the whole of the 4:3
screen.

Width

: Image size

: Screen size

Height

❖ 4 : 3 Screen

In case of displaying the 16:9
picture on the whole of the 4:3
screen.

Width

Height

: Image size

: Screen size

15

ENGLISH

Screen Position

Screen Position

0% (Center)

0% (Center)

(+100%)

-85%

Screen Height = 1H

0.3H Up
More

0.5H
Up

0.4H
Down

+165%

+100%

Focus pattern color: White

Focus pattern color: Green

VP-15S1VP-15S1

❖ Standard condition (From -85% to +100%) ❖ Extended mounting condition (From +100% to +165%)

Lens shift position VP-15S1

CAUTION:

In the expanded mounting condition (green focus pattern), the corners of the picture may appear
dark or distorted.

16

Screen Height = 1H

+165%

-85%

Focus pattern color: White

0.8 H Up

0.4H Down

VP-15S1L

Screen Positon

0% (Center)

Lens shift position VP-15S1L

❖ Standard condition (From -85% to +165%)

ENGLISH

17

ENGLISH

INPUT

V-MUTE

ENTER

MENU

ASPECT INFO.

C1 C2 S G1

H1 H2 V G2

A1

A2 RGB G3

STD DYN

I

M

A

G4

THTR

COMP.1 COMP.2 S-VIDEO USER

HDMI 1 HDMI 2 VIDEO

AUX 1

BLANKING

AUX 2

IRIS LAMP

C.TEMP GAMMA

B1 OFFB3B2

INPUT

V-MUTE

ENTER

MENU

ASPECT

FULL

CINEMA

VCR MODE

BLACK LEVEL

PATTERN

BLACK

NOR ZOOM THRU

INFO.

I

M

A

BLANKING

B1 OFFB3B2

BASIC OPERATIONS

Turning on the Power

Press the ON button on the remote controller or the / I button on the projector.
The ON indicator lights up.

Selecting the Aspect Mode

You can select 5 kinds of ASPECT mode using remote controller.
Pressing the ASPECT button on the remote control rotates the
aspect ratio in the order of FULL ➔NORMAL ➔ZOOM ➔V­STRETCH ➔THROUGH, allowing you to select an aspect ratio.
An aspect ratio can also be directly selected by pressing one of
the FULL, NORMAL, ZOOM or THROUGH buttons on the remote
controller. A selection can also be made from the menu. (
P.26)

☞

STANDBY

IRIS LAMP

COMP.1 COMP.2 S-VIDEO USER

C1 C2 S G1

HDMI 1 HDMI 2 VIDEO

H1 H2 V G2

AUX 1 AUX 2

A1

THTR

ON

C.TEMP GAMMA

A2 RGB G3

STD DYN G4

Selecting the Input Signal Source

Switch to the equipment connected to the projector.
Every time the INPUT button of the projector or the INPUT 3 button of the remote controller is pressed,
the input signal rotates in the order of COMPONENT 1 ➔COMPONENT 2 ➔S-VIDEO ➔VIDEO ➔RGB

HDMI 1 ➔HDMI 2. When the INPUT 4 button of the remote controller is pressed, the input signal

➔

rotates in the opposite order. An input signal can also be directly selected by pressing one of the COMP.1,
COMP.2, S-VIDEO, VIDEO, RGB, HDMI 1 and HDMI 2 buttons on the remote control.

18

The Screen Images in a 16:9 screen

• Press the ZOOM button, the NORMAL button or the FULL button on the remote controller for the 4:3

aspect ratio video source.

• Press the FULL button on the remote controller for 16:9 aspect ratio video source, such as 1080i,

1035i, and 720p video systems.

• Use Zoom mode when projecting a 480i, 480p, 576i, or 576p squeezed image with a 2.35: 1 aspect
ratio.

• Use V-Stretch mode when projecting a 720p, 1080i, or 1080p squeezed image with a 2.35: 1 aspect
ratio.

❖ Original Source Image

❖ V-Stretch mode

The 2.35:1 image is shown across the entire screen. The vertical component of the aspect ratio is
elongated in this case. This function is best used when a 720p, 1080i, or 1080p squeezed image is input.

ENGLISH

❖ Through mode

Images are shown at the same resolution as RGB/video signals.

16 : 9 video source

❖ Full mode

The 16:9 squeezed image is displayed with the
correct aspect.

❖ Normal mode

❖ Zoom mode

A 2.35:1 image is displayed in the entire screen.
This function is best used when a 480i, 480p, 576i,
or 576p squeezed image is input.

4 : 3 video source

The 4:3 image is enlarged horizontally.

The picture in normal ratio 4:3 is displayed.

19

ENGLISH

The Screen Images in a 4:3 screen

• Press the ZOOM button, the NORMAL button or the FULL button on the remote controller for the 4:3

aspect ratio video source.

• Press the FULL button on the remote controller for 16:9 aspect ratio video source, such as 1080i,

1035i, and 720p video systems.

• Use Zoom mode when projecting a 480i, 480p, 576i, or 576p squeezed image with a 2.35: 1 aspect
ratio.

• Use V-Stretch mode when projecting a 720p, 1080i, or 1080p squeezed image with a 2.35: 1 aspect
ratio.

❖ Original Source Image

❖ V-Stretch mode

The 2.35:1 image is shown across the entire screen. This function is best used when a 720p, 1080i, or
1080p squeezed image is input.

❖ Through mode

Images are shown at the same resolution as RGB/video signals.

16 : 9 video source

❖ Full mode

The 16:9 squeezed image is displayed with the
correct aspect.

❖ Normal mode

❖ Zoom mode

A 2.35:1 image is displayed in the entire screen.
This function is best used when a 480i, 480p,
576i, or 576p squeezed image is input.

4 : 3 video source

The 4:3 image is enlarged horizontally.

The picture in normal ratio 4:3 is displayed.

To Turn off the Power

1. Press the STANDBY button on the remote controller or the / I button on the projector.

2. The fan continues running for about 1 minute to internally cool the projector. In the meantime, the ON

indicator on the projector flashes a blue color and buttons on the projector and remote control are
irresponsive to touch. Once the fan stops, the ON indicator goes out and the STANDBY indicator
lights up a green color to indicate the projector is on standby.

STANDBY

IRIS LAMP

COMP.1 COMP.2 S-VIDEO USER

C1 C2 S G1

HDMI 1 HDMI 2 VIDEO

H1 H2 V G2

AUX 1 AUX 2

A1

Notes :

- Do not pull out the AC power cord until the projector turns in standby mode.

- Do not pull out the power cord suddenly in the state of “POWER ON." It can cause a breakdown.

- If the WARNING indicator lights up or blinks a yellow color, check that the fan has stopped then
unplug the AC power cord from its outlet.

- The projector will not be turned on if the ON button on the remote controller or the / I button on
the projector is pressed immediately after turning off. Press the ON button on the remote controller
or / I button on the projector after the projector turns into standby mode.

- When on standby, power to the projector is not OFF completely. If not planning to use the projector
for an extended period of time, unplug the AC power cord from AC power outlet as explained above.

ON

C.TEMP GAMMA

A2 RGB G3

20

OPERATIONS

Main Menu

Item

Main Menu

Item

Main Menu

Item

Component 1

Video

RGB

Auto*

480i/576i

480p
540p
576p

720p
1035i
1080i

1080p

Auto*

480i/576i

480p
540p
576p

720p
1035i
1080i

1080p

Auto*
NTSC

PAL

SECAM

RGB/HD Adjust

Mode

Readjust
Resolution H
Resolution V
Position H
Position V
Phase
Clamp Position

Input Signal

Component 2

Auto*

480i/576i

480p
540p
576p

720p
1035i
1080i

1080p

HDMI 1 Auto*

480i/576i

480p
576p

720p

1035i
1080i

1080p

HDMI 2 Auto*

480i/576i

480p
576p

720p

1035i
1080i

1080p

S-Video Auto*

NTSC

PAL

SECAM

Yes / No*

Clamp Width

250*
250*

0* 50

-

50

0* 10

-

10

Position H
Position V

0* 50

-

50

0* 50

-

50

0* 50

-

50

0* 50

-

50

0* 10

-

10

P.27

Config.
(Configuration)

Auto Power OFF

Remote Control

Trigger 2 Full
Trigger 2 Normal

Trigger 2 Through

Trigger 2 Zoom

Reset Lamp Life

Enable / Disable*

On* / Off
On* / Off

On* / Off

On* / Off

Trigger 2 V-Stretch

On* / Off

Yes / No
Yes / No

Wireless* / Wired

Reset All

P.30

Display

Keystone
Scale
Width

0* 25

-

25

P.28

Menu Position

OSD/Blanking

Status Info. Enable* / Disable
Power-OFF Confirm. Enable / Disable*
Blanking Memory Off* / 1 / 2 / 3
Blanking Top

0* 100
Blanking Bottom
Blanking Left
Blanking Right

0* 100

-

100 0*

-

100 0*

0* 100

0* 100

Language

English*
Deutsch
Français
Español

Top-L*

Top

Top-R

F + Ceiling
R + Ceiling

Installation

Front*

Rear

F + Ceiling

R + Ceiling

Auto*
Memory1
Memory2

Memory3

P.29

P.27

CSC HDMI 1

Deep Color HDMI 2

Auto*

RGB
YPBPR 4:4:4
YPBPR 4:2:2

YCBCR 4:4:4
YCBCR 4:2:2

Auto*

8bit
10bit
12bit

HDMI

CSC HDMI 2

Auto*

RGB

YPBPR 4:4:4
YPBPR 4:2:2

YCBCR 4:4:4
YCBCR 4:2:2

Deep Color HDMI 1 Auto*

8bit
10bit
12bit

P.28

Picture Mode

Theater

Main Menu

Item

Default / 1* / 2 / 3
Default / 1* / 2 / 3
Default / 1* / 2 / 3

1* / 2 / 3 / 4 / 5 / 6 / 7 / 8 / 9

Standard
Dynamic
User

Picture Adjust

1 / 2 / 3* / 4 / 5 / HB

Iris 1 / 2 / 3*

Aspect

Full*

Normal

Zoom

V-Stretch

Through

Gamma

A
B
C
D
E

Theater

Standard

Dynamic

Contrast

P.24

Fine Menu 1

Noise Reduction
R Gain
G Gain

P.26

P.25

0* 50

-

50

0* 50

Sharpness

0* 50

0* 50

-

50

B Gain

0* 50

-

50

R Bias

0* 50

-

50

G Bias

0* 50

-

50

B Bias

0* 50

-

50

0* 50

-

50

Fine Menu 2

Cinema
VCR Mode
Black Level

During HDMI input, “Expand” or “Normal*” is shown.

FRC
CEC

P.26

Auto* / Off

On / Off*

On / Off*

0 IRE* / 7.5 IRE

Auto 1* / Auto 2 / 60Hz / 50Hz / 48Hz

Luminance Gain

0* 50

-

50

Picture Shift V

0* 50

Overscan

Enable* / Disable

-

50

Chroma Delay

0* 5

-

5

Brightness

0* 50

-

50

Color

0* 50

-

50

Tint

0* G10R10

Color Temp.

Normal* / Economy

Lamp Mode

Center-R
Bottom-L

Center-L

Bottom

Center

Bottom-R

Português

Italiano

Menu Structure

ENGLISH

* Default setting

21

ENGLISH

Functions by Signal

NO SIGNAL VALID SIGNAL

VIDEO or S-VIDEO COMPONENT RGB HDMI

ANY INPUT

Picture Mode Theater –

Standard – ●●●● ●● ●● ●
Dynamic – ●●●● ●● ●● ●
User – ●●●● ●● ●● ●

Picture Adjust Gamma – *1 *1 *1 *1 *1 *1 *1 *1 *1

Contrast – *9 *9 *9 *9 *9 *9 *9 *9 *9
Brightness – *9 *9 *9 *9 *9 *9 *9 *9 *9
Color – *9 *9 *9 *9 *9 –––*9
Tint – *9 *9 *9 *9 *9 –––*9
Sharpness – *9 *9 *9 *9 *9 *9 *9 *9 *9
Color Temp. – *9 *9 *9 *9 *9 *9 *9 *9 *9
Lamp Mode – *9 *9 *9 *9 *9 *9 *9 *9 *9
Iris – *9 *9 *9 *9 *9 *9 *9 *9 *9

Fine Menu 1 Noise Reduction – *9 *9 *9 *9 *9 *9 *9 *9 *9

R Gain – *9 *9 *9 *9 *9 *9 *9 *9 *9
G Gain – *9 *9 *9 *9 *9 *9 *9 *9 *9
B Gain – *9 *9 *9 *9 *9 *9 *9 *9 *9
R Bias – *9 *9 *9 *9 *9 *9 *9 *9 *9
G Bias – *9 *9 *9 *9 *9 *9 *9 *9 *9
B Bias – *9 *9 *9 *9 *9 *9 *9 *9 *9
Luminance Gain – *9 *9 *9 ––––––
Chroma Delay – *9 *9 *9 ––––––

Fine Menu 2 Aspect –

Cinema – ●●● – *2 ● – *2 *2
VCR Mode
Black Level
FRC ● ●●●● ●● ●● ●
CEC – ––––*3 ––*3 *3
Picture Shift V – *4 *4 *4 *4 *4 *4 *4 *4 *4
Overscan –

RGB/HD Adjust Mode – ––––

Readjust – ––––*5 ––*5 *5 *11
Resolution H – ––––*6 ––*6 *6 *11
Resolution V – ––––*6 ––*6 *6 *11
Position H – ––––*5 ––*5 *5 *11
Position V – ––––*5 ––*5 *5 *11
Phase – ––––*5 ––*5 –
Clamp Position – ––––*5 ––*5 –
Clamp Width – ––––*5 ––*5 –

● ●●● ––––––

● ●●●● ●● ●*10 ●

NTSC PAL/SECAM 480i/576i 480p/576p 480i/576i 480p/576p Other

●●●● ●● ●● ●

●●●● ●● ●● ●

●●●● – ●●– *7

1080i/720p/
1080p/540p

● ––● *11

22

NO SIGNAL VALID SIGNAL

VIDEO or S-VIDEO COMPONENT

ANY INPUT

HDMI CSC HDMI 1

CSC HDMI 2 ● –––– ––––●
Deep Color HDMI 1 ● –––– ––––●
Deep Color HDMI 2 ● –––– ––––●

Display Keystone ● ●●●● ●● ●● ●

Scale – ●●●● ●● ●● ●
Width – ●●●● ●● ●● ●
Position H – ●●●● ●● ●● ●
Position V – ●●●● ●● ●● ●
Installation ● ●●●● ●● ●● ●

OSD/Blanking Menu Position ● ●●●● ●● ●● ●

Language ● ●●●● ●● ●● ●
Status Info. ● ●●●● ●● ●● ●
Power-OFF Confirm. ● ●●●● ●● ●● ●
Blanking Memory – ●●●● ●● ●● ●
Blanking Top – *8 *8 *8 *8 *8 *8 *8 *8 *8
Blanking Bottom – *8 *8 *8 *8 *8 *8 *8 *8 *8
Blanking Left – *8 *8 *8 *8 *8 *8 *8 *8 *8
Blanking Right – *8 *8 *8 *8 *8 *8 *8 *8 *8

Configuration Auto Power Off

Trigger 2 Full ● ●●●● ●● ●● ●
Trigger 2 Normal ● ●●●● ●● ●● ●
Trigger 2 Zoom ● ●●●● ●● ●● ●
Trigger 2 V-Strech ● ●●●● ●● ●● ●
Trigger 2 Through ● ●●●● ●● ●● ●
Remote Control ● ●●●● ●● ●● ●
Reset Lamp Life ● ●●●● ●● ●● ●
Reset All ● ●●●● ●● ●● ●

● –––– –– ––●

● ●●●● ●● ●● ●

NTSC PAL/SECAM 480i/576i 480p/576p 480i/576i 480p/576p Other

1080i/720p/

1080p/540p

RGB HDMI

ENGLISH

*1 Can be selected only when User is selected for the Picture Mode.
*2 On only when interlaced signals are input. (Off for progressive signals.)
*3 On only when 1035i / 1080i signals are input.
*4 On when Aspect is set to V-Stretch for HD signals. For other signals, On when Aspect is set to Zoom or V-Stretch.
*5 On when the RGB/HD Adjust mode is set to Memory.
*6 On when the RGB/HD Adjust mode is set to Memory. However, as an exception, it is Off when Aspect is set to Through or V-Stretch.
*7 On when 480i/p or 576i/p signals are input.
*8 On when Blanking Memory is selected for OSD/Blanking.

*9 Cannot be selected when the default is selected for Picture Mode.
*10 Can be selected when the input signal is 540p, 720p, 1035i, 1080i, or 1080p.
*11 Off when the input signal is 480i/p or 576i/p.

23

ENGLISH

Contrast 0

BLANKING

Theater
Standard
Dynamic
User

Default
1
Default
1

Standard 1

Picture Adjust
Fine Menu 1
Fine Menu 2
Input Signal

OSD/Blanking
Config.

RGB/HD Adjust

Display

2
3

1

Default

HDMI

Picture Mode

This unit has four picture modes: Theater, Standard, Dynamic and User. The picture quality recommended
by Marantz is already set for each mode. The User mode has eight gamma curves that can be chosen and
saved by users. Also, the Theater, Standard and Dynamic modes three indexes for memorizing picture
quality adjustments. Similarly, the User mode has nine, making a total of 18 indexes available for use.

How to Operate Menus

This projector has menus that make setting and adjustment easy.

1. Press the MENU button. The MENU screen appears on the screen.

User 1

Picture Adjust
Fine Menu 1
Fine Menu 2
Input Signal
RGB/HD Adjust
HDMI
Display
OSD/Blanking
Config.

Main menu Menu item Setting or adjustment level

Gamma
Contrast
Brightness
Color
Tint
Sharpness
Color Temp.
Lamp Mode
Iris

A
0
0
0
0
0

3

Normal

1

A
B
C
D
E

Theater
Standard
Dynamic

– Theater: Reproduces the black suited for movie software.
– Standard: Suited for normal movie software.
– Dynamic: Suited for visually dynamic image software.
– User 1-9: Enable the user to adjust the gamma curve as preferred. (

Picture mode selection

There are two ways to select the Picture mode: selecting a mode from the MENU screen or pressing
the picture mode buttons (THTR, STD, DYN) on the remote controller. To use the remote controller
buttons to select a picture mode, make sure the MENU screen does not appear on the screen and
press the desired picture mode button any number of times. (
To select an picture mode from the menu, do as follows.

Memorizing settings in an index

The settings made in “Picture Adjust” and “Fine Menu 1” of the main menu are automatically
memorized in the currently selected picture mode. Therefore, first select an picture mode and index,
and then make settings.

Note :

24

Picture mode Index
Theater Default, 1, 2, 3

Standard Default, 1, 2, 3
Dynamic Default, 1, 2, 3
User 1, 2, 3, 4, 5, 6, 7, 8, 9

P.25).

☞

P.6)

☞

1. Press the MENU button. The MENU screen appears on the screen.

2. Use the 3/4 buttons to select the Picture Mode displayed at the top of the menu.

3. Press the ENTER button to display the picture mode selection screen. Use the 3, 4, 2 and 1

buttons to select an picture mode.

4. Press the ENTER button to decide the selected picture mode. Once the mode has been

entered, the screen returns to the previous menu.

When default is selected, “Picture Adjust” and “Fine Menu 1” cannot be selected from the menu.

2. Use the 3 and 4 buttons to select a menu (Picture Adjust, Fine Menu 1, Fine Menu 2, Input Signal,

RGB/HD Adjust, Display, OSD/Blanking, Config) and press the 2 button.
For image mode selection, see “Picture Mode”. (

☞

P.24)

3. Use the 3 and 4 buttons to select a menu item and press the 2 button.

4. Use the 3, 4, 1 and 2 buttons to make the setting or adjustment of the selected item.

• The current setting or adjustment level is displayed to the right of each menu item.

5. Press the MENU button again to close the menu.

1, 52, 3, 4

– Adjustment bar

When there is a “” right of a menu item, this 2 acts as a button for engaging an adjustment mode. In
the adjustment mode, the menu disappears and only an adjustment bar, like that shown below,
appears along the bottom of the display. Use the 1 and 2 buttons to adjust the item to the desired
level. Press the 3 button to return to the menu.

B1 OFFB3B2

V-MUTE

A

ASPECT

CINEMA

ENTER

VCR MODE

MENU

M

I

INFO.

BLACK LEVEL

BLACK

INPUT

PATTERN

1, 5
2, 3, 4

ABCDE

Theater Dynamic

User 1

Picture Adjust
Fine Menu 1
Fine Menu 2
Input Signal
RGB/HD Adjust

Display
OSD/Blanking
Config.

HDMI

Gamma
Contrast
Brightness
Color
Tint

0
0
0

3

0

Lamp Mode

Color Temp.

Normal

A

Iris

1

Sharpness

0

Picture Adjust

Picture quality in each of the picture modes can be adjusted to your liking and those adjustments can be
saved in memory.

Item

Gamma

Contrast

Brightness

Color

Tint

Sharpness
Color Temp.
(Color Temperature)
Lamp Mode

Iris

A, B, C, D, E, Theater,
Standard, Dynamic

Normal, Economy

Contrast (High) (Low)
Brightness (Low) (High)

Sets the lens and illumination
aperture.

Adjustments

-50

Ô

0

Ô

50

(Weak) (Default) (Strong)

-50

Ô

0

Ô

50

(Dark) (Default) (Bright)

-50

Ô

0

Ô

50

(Light) (Default) (Deep)

R10

Ô

0

Ô

G10

(Purple) (Default) (Green)

050
12345HB

(Red) (Blue)

12 3

– Gamma setting

To change the type of Gamma curve, set the Picture Mode (

p.24) to User (1 – 9). Select “Gamma”

☞

from the displayed menu followed by the desired gamma curve (A, B, C, D, E, Theater, Standard or
Dynamic).

– Color Temp. (Color Temperature)

1 : Red comes out strong. Color temperature is about 5250 K.
2 : Red is mildly strong. Color temperature is about 5800 K.
3 : Normal. Color temperature is about 6500 K.
4 : Blue is mildly strong. Color temperature is about 7500 K.
5 : Blue comes out strong. Color temperature is about 9300 K.
HB : High Bright : Display brightest image.

NOTES:

- To adjust picture quality, set the index to a mode other than the default. See “Picture Mode”.
P.24)

(

☞

- The Gamma cannot be set unless User (1 - 9) is set for the Picture Mode (

- Tint cannot be adjusted for RGB input. For details, see “Functions by Signal.” (

☞

P.24).

☞

P.22-23)

- The settings made in Picture Adjust are saved in the currently selected Picture Mode index.

ENGLISH

25

ENGLISH

Standard 1

Cinema
VCR Mode
Black Level

Auto
On
0 IRE

FRC Auto 1

0

Picture Shift V

Picture Adjust
Fine Menu 1
Fine Menu 2
Input Signal
RGB/HD Adjust

Display
OSD/Blanking
Config.

CEC Off

HDMI

Overscan

Enable

Aspect

Full

Standard 1

Noise Reduction
R Gain
G Gain
B Gain

0
0

R Bias
G Bias
B Bias

0
0
0

0

0

Picture Adjust
Fine Menu 1
Fine Menu 2
Input Signal
RGB/HD Adjust

Display
OSD/Blanking
Config.

HDMI

0
0

Luminance Gain
Chroma Delay

Fine Menu 1

By adjusting this Fine Menu, you can make fine picture adjustment.

Item
Noise Reduction
R Gain
G Gain
B Gain
R Bias
G Bias
B Bias
Luminance Gain
Chroma Delay

– Noise Reduction

Adjust the noise reduction.

– R Gain

This menu allows the users to set the gain for red.

– G Gain

This menu allows the users to set the gain for green.

– B Gain

This menu allows the users to set the gain for blue.

– R Bias

This menu allows the users to set the bias for red.

– G Bias

This menu allows the users to set the bias for green.

– B Bias

This menu allows the users to set the bias for blue.

– Luminance Gain

This menu allows the users to set the luminance gain.

– Chroma Delay

This menu allows the users to set the chrominance delay.

Note :

• The settings made in Fine Menu 1 are saved in the currently selected Picture Mode index (Default
excluded).

26

Adjustments

050

-50

-50

-50

-50

-50

-50

-50

-5

Ô

Ô

Ô

Ô

Ô

Ô

Ô

Ô

0

Ô

0

Ô

0

Ô

0

Ô

0

Ô

0

Ô

0

Ô

0

Ô

50
50
50
50
50
50
50

5

Fine Menu 2

Item

Aspect

Cinema
VCR Mode
Black level

FRC

CEC
Picture Shift V

– Cinema

Auto : Automatically selects the cinema mode when a video signal is input.

NTSC: 3-2 pull down, PAL: 2-2 pull down

Off : Pull-down processing is not performed.

– VCR Mode

On : A projector is forced into the intra-field only deinterlacing mode.
Off : A projector is used with external field memories and operates in the full set of deinterlacing

modes, i.e., motion adaptive video deinterlacing and full frame film source deinterlacing
using 3:2 pulldown detection (2:2 pulldown for 625/50 sources).

– Black level

Select the black level by a video source.

– FRC (Frame Rate Conversion)

Auto 1 : Frame Rate Conversion function is basically off. However FRC turns on automatically

depending on vertical frequency of input signal. Normally, use this mode.
Auto 2 : Use this mode when the image stops momentarily.
60Hz : Frame Rate Conversion function is “On”. (59.94Hz fixed)
50Hz : Frame Rate Conversion function is “On”. (50.00Hz fixed)
48Hz : Frame Rate Conversion function is “On”. (47.95Hz fixed)

– CEC (Chroma Error Correction)

On : Reduces CUE (Chroma Up-sampling Error) of 1080i signals.
Off : Normally, use this mode.

– Picture Shift V

When Aspect on the Picture Adjust menu is set to “Zoom” or “V-Stretch”, this setting allows the user to
move the projected image vertically in order to see parts on the image not appearing on the screen.

– Overscan

Selects whether to show or hide picture borders with NTSC, PAL, SECAM, 480i, 480p, 576i and 576p
signals.

Enable: Does not display borders of image signals. (Normally, use this mode.)
Disable: Displays the entire image signal.

Overscan

Notes :

• There are some parameters can not adjust according to input signal.

• The settings made in Fine Menu 2 are saved in each currently selected input signal source.

Adjustments
Full, Normal, Zoom,
V-Stretch, Through
Auto, Off
On, Off
0 IRE, 7.5 IRE /Expand,
Normal (For HDMI input)
Auto 1, Auto 2, 60Hz,
50Hz, 48Hz
On, Off

-50

Ô

0

Ô

Enable, Disable

50

Input Signal

Standard 1

Mode
Readjust
Resolution H
Resolution V
Position H
Position V

Memory 1

0
0
0
0

Phase
Clamp Position
Clamp Width

0

0

0

Picture Adjust
Fine Menu 1
Fine Menu 2
Input Signal
RGB/HD Adjust

Display
OSD/Blanking
Config.

123

HDMI

Standard 1

Picture Adjust
Fine Menu 1
Fine Menu 2
Input Signal
RGB/HD Adjust
HDMI
Display
OSD/Blanking
Config.

Component 1
Component 2
S-Video
Video
RGB Auto
HDMI1 Auto
HDMI2

Auto
Auto
Auto
Auto

Auto

RGB/HD Adjust

ENGLISH

Item Adjustments
Component1, Auto, 480i/576i, 480p, 540p, 576p,
Component2 720p, 1035i, 1080i, 1080p
S-Video Auto, NTSC, PAL, SECAM
Video Auto, NTSC, PAL, SECAM
RGB Auto, 480i/576i, 480p, 540p, 576p,

720p, 1035i, 1080i, 1080p

HDMI 1, HDMI 2 Auto, 480i/576i, 480p, 576p, 720p,

1035i, 1080i, 1080p

NTSC(NTSC-3.58)

: Conventional analog broadcasting used

mainly in USA, Canada, Taiwan, Korea, and
Japan.

PAL(PAL-4.43)

: Conventional analog broadcasting used

mainly in United Kingdom and Germany.

SECAM : Conventional analog broadcasting used

mainly in France and Russia.

480p : Standard digital broadcasting
540p : Special digital broadcasting

(for example: RCA DTC100)

576p : Standard digital broadcasting
720p, 1080p : High Definition digital broadcasting
1035i : Japanese "Hi-Vision" broadcasting

Adjustments

0

Ô

25

Mode
Readjust
Resolution H

Item

Auto, Memory 1, Memory 2, Memory 3
Yes, No

(Default) (Large)

0

Ô

Resolution V

25

(Default) (Large)

Position H

Ô

0

Ô

50

-50

(Left) (Default) (Right)

Position V

Ô

0

Ô

10

-10

(Down) (Default) (Up)

Phase

Ô

0

Ô

10

-10

(Backward) (Default) (Forward)

Clamp Position

Ô

0

Ô

50

-50

(Backward) (Default) (Forward)

Clamp Width

Ô

0

Ô

50

-50

(Small) (Default) (Large)

– Mode

Auto: Each item is adjusted automatically.
Memory1-3: If something wrong with Auto Adjust, select Memory, please adjust each item manually.

– Readjust

Select to readjust settings automatically for each item in this menu.

– Resolution H, V

Adjusts the horizontal and vertical resolution of the RGB/HD input signals.

– Position H, V

Adjust the position of the input signal. H adjusts the horizontal position of the input signal. V adjusts the
vertical position of the input signal.

– Phase

Adjust the phase of the DMD dots and the computer signal input from the RGB IN. Adjust the picture
to where it looks clearest.

– Clamp Position, Width

Adjusts the clamp position and width used in RGB/HD input.

27

ENGLISH

Standard 1

Keystone
Scale
Width
Position H
Position V
Installation

0
0
0

0
0

Front

Picture Adjust
Fine Menu 1
Fine Menu 2
Input Signal
RGB/HD Adjust

Display
OSD/Blanking
Config.

HDMI

Keystone
(Electronic vertical
keystone correction)

Scale

Width

Installation

Item Adjustments

-100 0

-25 250

(Min)

(Min)

( )

( )( )

Position H

Position V

-50 500

(Left) (Right)(Default)

-50 500

(Down) (Up)(Default)

(Max)

-100 0

(Max)

Front, Rear, F+Ceiling,
R+Ceiling

Standard 1

CSC HDMI 1
CSC HDMI 2
Deep Color HDMI 1
Deep Color HDMI 2

Auto
Auto
Auto
Auto

Picture Adjust
Fine Menu 1
Fine Menu 2
Input Signal
RGB/HD Adjust

Display
OSD/Blanking
Config.

HDMI

HDMI

Display

– CSC HDMI 1/CSC HDMI 2

Auto: The color space is automatically selected based on the input signal.
RGB: This is effective for DVI and similar signals.
YP

BPR: This is effective for 720p, 1080i, and other high-resolution TV signals.

YC

BCR: This is effective for 480p, 480i, and other standard TV signals.

– Deep Color HDMI 1/Deep Color HDMI 2

Auto: This automatically selects the color depth based on the input signal.

8/10/12bit: Select this option when the video displayed in Auto is not correct.

28

Item
CSC HDMI 1,
CSC HDMI 2

Auto, RGB, YPBPR 4:4:4, YPBPR 4:2:2,
YCBCR 4:4:4, YCBCR 4:2:2

Adjustments

Select the color space conversion for
HDMI input.

Deep Color HDMI 1,
Deep Color HDMI 2

Auto, 8Bit, 10Bit, 12Bit
Select the color depth for HDMI input.

Normally, use at Auto.

The input settings for the color depth are set to 8Bit, 10Bit, and 12Bit.

– Keystone

Adjust trapezoid image to rectangle image.

– Scale

Reduces the image without changing the aspect ratio. The image can be reduced to about 70% the
original size.

– Width

Reduces the image width without changing the image height. The width can be reduced to about 75%
the original size.

– Position H, V

Adjust the position of the input signal. H adjusts the horizontal position of the input signal. V adjusts the
vertical position of the input signal.

– Instllation

Sets the installation mode of the projector.
Front: Select to set the projector on a tabletop and project from in front of the screen.
Rear: Select to set the projector on a tabletop and project from behind the screen.
F + Ceiling: Select to mount the projector on the ceiling and project from in front of the screen.
R + Ceiling: Select to mount the projector on the ceiling and project from behind the screen.

OSD/Blanking

Standard 1

Picture Adjust
Fine Menu 1
Fine Menu 2
Input Signal
RGB/HD Adjust
HDMI
Display
OSD/Blanking
Config.

Menu Position
Language
Status Info.
Power-OFF Confirm.
Blanking Memory
Blanking Top
Blanking Bottom
Blanking Left
Blanking Right

0
0
0
0

Top-L
English
Enable
Disable
Memory 1

– Blanking Top, Bottom, Left and Right

Set the blanking width of the top, bottom, left and right masks, which are then memorized in Memory 1
– 3 of Blanking Memory. Each can be set from 0 (no mask) to a maximum 100.

ENGLISH

Item

Menu Position

Top-L, Top, Top-R, Center-L, Center, Center-R,

Adjustments

Bottom-L, Bottom, Bottom-R

Language

English, Deutsch, Français, Español,

Português, Italiano
Status Info.
Power-OFF Confirm.
Blanking Memory
Blanking Top
Blanking Bottom
Blanking Left
Blanking Right

Enable, Disable

Enable, Disable

Off, Memory 1, Memory 2, Memory 3

0 100
0 100
0 100
0 100

– Menu Position

OSD position is selected from 9 positions.

– Status Info.

Enable: Displays the current status of the projector for a set amount of time in the upper right-hand

corner of the screen at startup and whenever the Input Source, Picture Mode, Aspect ratio or
other setting is changed.

Disable: Does not display Status Info.

– Power-OFF Confirm.

Disable:

Directly puts the projector on standby without displaying the confirmation message when power

/I

is shut off from the button on the remote controller or the

button on the projector.

Enable: Displays a confirmation message asking whether to shut the power off or continue use

when power is shut off from the button on the remote controller or the /I button on the
projector. To shut off the power immediately, select “Yes” and press the ENTER button. To
not shut off the power, select “No” and press the ENTER button.

– Blanking Memory

Sets the blanking mode with which part of the screen can be hidden in black bands. To use this mode
or change the setting, select from Memory 1 to 3.

Off: Turns the blanking mode off. No masking occurs.
Memory 1-3: Memorize the blanking width of the top, bottom, left and right masks set with the

below features. Up to three settings can be memorized.

29

ENGLISH

Yes No

Reset Lamp Life ?

Reset All ?

Yes No

It will be standby mode soon.

Auto Power Off

Configration

– Auto Power Off

Standard 1

Picture Adjust
Fine Menu 1
Fine Menu 2
Input Signal
RGB/HD Adjust
HDMI
Display
OSD/Blanking
Config.

Auto Power Off
Trigger 2 Full
Trigger 2 Normal
Trigger 2 Zoom
Trigger 2 V-stretch On
Trigger 2 Through On
Remote Control
Reset Lamp Life
Reset All

Disable
On
On
On

Item

Auto Power Off

Enable, Disable
Trigger 2 Full On, Off
Trigger 2 Normal On, Off
Trigger 2 Zoom On, Off
Trigger 2 V-stretch On, Off
Trigger 2 Through On, Off
Remote Control

Wireless, Wired
Reset Lamp Life Yes, No
Reset All Yes, No

When the auto power off feature is set to Enable, power
to the projector automatically shuts off if no signals are
received and no operations are performed for about 10
consecutive minutes. If 9 minutes pass without the
projector receiving any signals or being operated in
anyway, the below message appears on the screen.

– Remote Control

Wireless: Set to use the included remote controller.
Wired: Set to control the projector from either Marantz’s AV components connected to the

REMOTE CONTROL IN/OUT terminals or a PC or other device connected to the RS­232C terminal of the projector. The included remote controller cannot be used in this case.

When this item is selected, a confirmation message appears asking whether to change the currently
selected mode to the other mode or not. To change the mode, select “Yes” and press the ENTER
button on the projector. To keep the same mode, select ‘No” and press the ENTER button.

Notes:

- To prevent misoperation, the ENTER button of the remote controller does not respond to touch
when the Wired/Wireless setting is displayed. Press the ENTER button of the projector to enter the
setting.

- To change from Wired to Wireless, set “Wireless” from the menu using the buttons of the projector.

Adjustments

– Reset Lamp Life

If the lamp is replaced before reaching its 2000 hours
lamp life, be sure to reset the lamp’s life counter. To do
this, select “Reset Lamp Life” from the Configuration
menu. When the user selects this item, the following
message appears:
Select “Yes”, and press the ENTER button. Then the
lamp life is initialized.

– Reset All

All settings are reset to the factory default settings except
the lamp life.
When the user selects this item, the following message
appears:
Select “Yes”, and press the ENTER button.

About 1 minute after the message appears on the screen, power to the projector shuts off.

Note:

After the above message appears on the screen, pressing any button on the projector or remote
control other than the / I button on the projector and the ON or STANDBY buttons on the remote
control resets the auto power off feature.

The auto power off feature will activate again if, after that, the projector goes without receiving any
signals or being operated in anyway for 10 consecutive minutes.

– Tigger 2

Select either 12V output or 0V output by choosing On or Off for each aspect mode. Full, Normal,
Zoom, V-stretch and Through.
This allows you to control such as a powered dual aspect screen with the outputs for the aspect
modes.

On: Output DC 12V.
Off: No output.

30

MAINTENANCE

Lamp Life 0 Hours

Warning

Lamp Life and Replace Lamp

❖ Lamp Life

Display the remaining lamp life by pressing the
INFO. button on the remote controller.

Information

Video Input Component 1 - 1080i / 60
Picture Mode User 1
Gamma A
Aspect Normal
Lamp Mode Economy
Iris 1
Lamp Life 921 Hours
Total Time 3653 Hours

– When the lamp life becomes less than 100

hours and the unit is still on, the remaining
lamp life is displayed on the screen
automatically.

Warning

Lamp Life 100 Hours

– When the lamp life becomes less than 5 hours,

the remaining lamp life is displayed on the
screen .

Warning

❖ Initialize the Lamp Life

The lamp has a lamp life of 2000 hours. The
projector is designed to shut OFF power if the lamp
is used beyond this 2000 hours lamp life. In such
case, replace the lamp and reset the lamp life
counter as follows.

1. After the message “Lamp Life 0 Hours”

appears, power to the projector shuts OFF.
Promptly replace the lamp with a new one.
(☞P.31 “Replacing Lamp Unit”)

2. Once the lamp has been replaced, press the

ON button on the remote control or the / I

button on the projector.
The below message appears on the screen

for 120 seconds.

New Lamp ?

Yes No

Replacing Lamp Unit

CAUTION:

• Do not touch the lamp and the lamp unit
carelessly. It is extremely hot. Wait at least
one hour for the lamp to cool down before
handling.

• Do not loosen any screws except for those
mentioned below.

• The lamp may break if handled improperly.

• Do not use other than a Marantz

replacement lamp unit.

❖ How to replace the Lamp Unit

PREPARATION:

When replacing the lamp, turn off the power for
the projector. After the cooling fan stops,
disconnect the power cord and wait for one
hour until the lamp is cooled down completely,
then replace the lamp.

ENGLISH

ASPECT

CINEMA

ENTER

VCR MODE

IA

INFO.

BLACK LEVEL

BLACK

INPUT

PATTERN

Notes:

• The maximum life limit of the lamp is 2000
hours. Although we care very much about
quality, the lamp can rarely breaks down if
running time exceeds 1000 hours. Therefore
we recommend to replace the lamp if Lamp
Life gets under 1000 hours. The lamp
cannot be used exceeding the maximum life
limit.

• This product is checked under strict quality
control when it is shipped out form factory.

“Total Hours” in the menu includes the time
for this check. So “Total Hours” may not be 0
hours when it is used first time.

Lamp Life 5 Hours

A1

A2 RGB G3

STD DYN

G4

THTR

BLANKING

B1 OFFB3B2

V-MUTE

MENU

M

INPUT

ENTER

To clear the warning, press the MENU button.

– Approximately 2 minutes after the lamp

reaches the end of its lamp life, power to the
projector shuts OFF and the WARNING
indicator lights up a yellow color. If the below
message appears on the screen and power
shuts OFF soon thereafter, promptly replace
the lamp with a new one. (See “Replacing
Lamp Unit”

☞

P.31)

3. Select “Yes”, using the 1 / 2 buttons.

4. Press the ENTER button. The lamp life

indicator is now initialized.

3.

4.

2.

C.TEMP GAMMA

AUX 2

A2 RGB G3

STD DYN

BLANKING

MENU

M

ENTER

I

INFO.

VCR MODE

BLACK LEVEL

PATTERN

ON

2.

G4

4.

INPUT

3.

STANDBY

IRIS LAMP

COMP.1 COMP.2 S-VIDEO USER

C1 C2 S G1

HDMI 1 HDMI 2 VIDEO

H1 H2 V G2

AUX 1

A1

THTR

B1 OFFB3B2

V-MUTE

A

ASPECT

CINEMA

1. Press the STANDBY button on the remote

controller or the / I button on the projector
to turn the projector off.

ON

STANDBY

IRIS LAMP

C.TEMP GAMMA

COMP.1 COMP.2 S-VIDEO USER

C1 C2 S G1

HDMI 1 HDMI 2 VIDEO

H1 H2 V G2

AUX 1 AUX 2

A1

A2 RGB G3

2. After the cooling fan stops, Unplug the AC

power cord.

31

3. Wait at the least one hour for the lamp and

WARNING

THIS COVER IS PROVIDED WITH
INTERLOCK TO REDUCE THE RISK OF
EXCESSIVE ULTRAVIOLET RADIATION.
DO NOT DEFEAT ITS PORPOSE OR
ATTEMPT TO SERVICE WITHOUT
REMOVING COVER COMPLETELY.

SERIAL NO.

CAUTION :

HIGH PRESSURE LAMP
MAY EXPLODED IF IMPROPERLY HANDLED.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

ATTENTION :

LA LAMPE SOUS
HAUTE PRESSION PEUT SI ELLE, N'EST
PAS MANIPULEE CORRECTEMENT,
CONFIER L'OPERATION A UN
PERSONNEL D'ENTRETIEN QUALIFIE.

CAUTION HOT :

UNPLUG
THE POWER CORD AND WAIT
60 MINUTES BEFORE CHARGING
THE LAMP.

ATTENTION CHAUD :

DEBRANCER LE CORD ON
D'ALOMENTION ET ATENDER
60 MINUTES AVANT DE
CHANGER LAMPE.

MMODEL NO. VP-12S1 / N1S

MADE IN JAPAN

FABRIQUE AU JAPON

AC 120V 60H

Z

2.0W

SERIAL NO.

CAUTION :

HIGH PRESSURE LAMP
MAY EXPLODED IF IMPROPERLY HANDLED.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

ATTENTION :

LA LAMPE SOUS
HAUTE PRESSION PEUT SI ELLE, N'EST
PAS MANIPULEE CORRECTEMENT,
CONFIER L'OPERATION A UN
PERSONNEL D'ENTRETIEN QUALIFIE.

CAUTION HOT :

UNPLUG
THE POWER CORD AND WAIT
60 MINUTES BEFORE CHARGING
THE LAMP.

ATTENTION CHAUD :

DEBRANCER LE CORD ON
D'ALOMENTION ET ATENDER
60 MINUTES AVANT DE
CHANGER LAMPE.

WARNING

THIS COVER IS PROVIDED WITH
INTERLOCK TO REDUCE THE RISK OF
EXCESSIVE ULTRAVIOLET RADIATION.
DO NOT DEFEAT ITS PORPOSE OR
ATTEMPT TO SERVICE WITHOUT
REMOVING COVER COMPLETELY.

M

CAUTION

HIGH PRESSURE LAMP MAY EXPLODED IF
IMPROPERLY HANDLED. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.

ATTENTION

LA LAMPE SOUS HAUTE PRESSION PEUT
EXPLOSER SI ELLE, N'EST PAS MANIPULEE
CORRECTEMENT, CONFIER L'OPERATION
A UN PERSONNEL D'ENTRETIEN QUALIFIE.

VORSICHT

:

BEI FALSCHER HANDHABUNG
KANN DIE HOCHDRUCKLAMPE
EXPLODIEREN UBERLASSEN
SIE WARTUNGSARBEITEN
NUR FACHPERSONAL.

CAUTION HOT

UNPLUG THE POWER CORD AND
WAIT 60 MINUTES BEFORE
CHANGING THE LAMP.

ATTENTION CHAUD

DEBRANCER LE CORD ON
D'ALIMENTION ET ATENDER 60
MINUTES AVANT DE CHANGER
LAMPE.

WARNUNG HEISS

ZIEHEN SIE DEN NETZSTECKER
AB UND WARTEN SIE 60 MINUTEN,
BEVOR SIE DIE GLUHLAMPE
WECHSELN.

A

A

B

B

ENGLISH

lamp unit to cool down.

4. Read the caution and warning labels on the

unit.

For USA

For Europe

For USA

For Europe

Lamp cover

5. Remove the lamp cover screw.

6. Remove the lamp cover in the direction of the

arrow.

Lamp cover

7. Open the cover sheet and remove the two

screws (slotted head screwdriver required)
that lock down the lamp unit. Do not remove
any other screws.

Cover sheet

8. Holding the handle and pull the lamp unit out

toward your side.

Lamp unit

9. Install a new lamp unit in position securely.

10. Lock the lamp unit in place with the two

screws removed in step 7. Press on the
handle until it folds over and close the cover
sheet.

11. Install the lamp cover back in its original

position and fasten with the fastening screw.

(a)

(b)

12. Plug in the video projector and turn on the

power and project the image.

• If the lamp is replaced before reaching its
2000 hours lamp life, see “Reset Lamp Life”
(

P.30).

☞

• If the lamp is replaced after reaching its
2000 hours lamp life, see “Initialize the Lamp
Life” (☞P.31).

32

Cleaning the Lens

Optional Accessories

If the lens becomes dirty or smudged, clean it with
a soft dry cloth only. Use optical lens cleaners that
are approved for eyeglasses or cameras. Do not
use a dampen cloth, detergent solution, or thinner.
It may damage the lens and remain as stains.

Replacement Parts

When replacement parts are required, be sure to
inform a Marantz authorized service center. Use
only replacement parts specified by Marantz.
Unauthorized substitutions may result in fire,
electric shock, or other hazards. And, the warranty
may not be guaranteed.

Lamp Unit : LU-12VPS3

ENGLISH

Ceiling Mount kit : MOUNT 20

This kit is specially designed to mount the unit
on ceiling.

Extension Pole : EXT-10

This tool is to adjust height with the Ceiling
Mount Kit MOUNT 20.

CAUTION

:

For ceiling installation, consult with the
Marantz Authorized dealer.

33

ENGLISH

TROUBLESHOOTING

Try the following troubleshooting before calling for service.

1. Are the connections made properly ?

2. Are you operating the unit properly, following the instructions ?

If the unit does not operate properly, check the items shown in the following table.
If any trouble cannot be solved by the instructions below, malfunction of the internal circuitry is suspected; immediately unplug the AC power cord and contact
Marantz dealer or service center.

Possible CauseSymptom Remedy

No power

Image is not
displayed.

Poor color.

Picture is too dark.

Picture is not clear.

Picture rolls.

The Remote
Controller does not
work.

AC power cord is not connected correctly.
Lamp cover is not closed correctly.
A signal cable is not connected correctly.
Selected input is incorrect.
The picture mute is active.
Picture is not adjusted properly.
Lamp life is running out.
Contrast or brightness is not adjusted properly.
Picture is out of focus.
Dew is on the lens.
A signal cable is not properly connected.
Batteries are exhausted.
The distance to the unit is too far.

IR sensor on unit is obstructed.
The “Wired” position in the Menu is selected.

Connect the AC power cord properly.
Close the cover properly. (☞P.32)
Connect a signal cable properly.
Select the correct input source. (☞P.18)
Press the V-MUTE button to release the mute.
Adjust the picture in the MENU mode.
Replace the lamp. (☞P.31)
Adjust contrast or brightness properly.
Adjust the focus. (
Run the projector for about two hours.
Connect a signal cable properly.
Replace batteries. (☞P.8)
Make the distance between the unit and the remote control

closer. (☞P.8)
Remove any obstacles.
Select the “Wireless” position. (☞P.30)

☞

P.11)

Notes:

• If the lamp still does not function after the replacement and initialization of the lamp life, contact a Marantz authorized dealer, or service center.

• This projector uses a microcomputer. External noise can cause malfunctions. In such case, shut power OFF and unplug the power cable from AC power

outlet. Then, plug the AC power cable back in, press the / I button on the projector or the ON button on the remote control and check operation.

34

The lamp cover is not
closed properly.

The lamp has failed, or
the lamp is completely
worn out.

Projector internal
temperature is higher
than the allowed level.

Trouble has occurred
with the fan.

Internal program error

Close the cover correctly.

Replace the lamp and
reset lamp life.

Check if anything is
blocking the exhaust vent.

Shut power OFF and
ON again.

Other

Fan

Temperature

Lamp

Lamp cover

Flashing

Flashing

Flashing

ON

ON

OFF

OFF

OFF

OFF

OFF

Flashing

ON

OFF

Flashing

OFF

Indicators

Error mode

WARNING

/LAMP

ON STANDBY

Possible Cause Recommendation

ERROR MODE

GLOSSARY

WARNING/LAMP indicator, ON indicator, and STANDBY indicator diagnose error mode of the projector as follows.

ON SCREEN MESSAGE

Use the list below to check the message displayed on the screen.

Aspect ratio

Width and height ratio of an image. The normal
aspect ratio of a computer and video image is 4 :

3. There are also wide images with an aspect
ratio of 16 : 9 and 21 : 9.

Black Level (Black setup)

The signal level which represents black picture
intensity.
For NTSC system for USA, this level is 7.5IRE.
NORMAL: 16 (Black) – 235 (White)
For NTSC system for Japan and DVD, this level
is 0IRE.
EXPAND: 0 (Black) – 246 (White)

Color Temperature

White color hue.
Low color temperature implies a warmer (more
yellow/red) light.
High color temperature implies a colder (more
blue) light.

Keystone

Distortion of the image caused by projection to a
wrong vertical angle.

ENGLISH

NO SIGNAL
REPLACE LAMP!

OUT OF RANGE

MeaningMessage

No input signal.
The lamp has reached the end of its life.

Improper signal feed to the projector.

Remedy

Properly connect the cables.
Replace the lamp and reset lamp life.

Adjust resolution, V(Hz) : refresh rate of the
equipment, referring to the Timing Chart.

35

ENGLISH

NTSC 3.58
NTSC 4.43
PAL-B/G
PAL M
PAL N
PAL 60
SECAM
480/60i
480/60p
576/50i
576/48p
576/50p
540/60p
720/24p
720/25p
720/30p
720/50p
720/60p
1035/60i
1080/50i
1080/60i
1080/24PsF
1080/25PsF
1080/30PsF
1080/24p
1080/25p
1080/30p
1080/50p
1080/60p
640

x

350@70Hz

640

x

350@85Hz

640

x

400@70Hz

640

x

400@85Hz

640

x

480@60Hz

640

x

480@72Hz

640

x

480@75Hz

640

x

480@85Hz

800

x

600@56Hz

800

x

600@60Hz

800

x

600@72Hz

800

x

600@75Hz

800

x

600@85Hz

1024

x

768@60Hz

1024

x

768@70Hz

1024

x

768@75Hz

1024

x

768@85Hz

1280

x

1024@60Hz

1600

x

1200@60Hz

-

-

-

-

-

-

-

720

x

487

720

x

483

720

x

576

720

x

576

720

x

576

1920

x

540

1280

x

720

1280

x

720

1280

x

720

1280

x

720

1280

x

720

1920

x

1035

1920

x

1080

1920

x

1080

1920

x

1080

1920

x

1080

1920

x

1080

1920

x

1080

1920

x

1080

1920

x

1080

1920

x

1080

1920

x

1080

640

x

350

640

x

350

640

x

400

640

x

400

640

x

480

640

x

480

640

x

480

640

x

480

800

x

600

800

x

600

800

x

600

800

x

600

800

x

600

1024

x

768

1024

x

768

1024

x

768

1024

x

768

1280

x

1024

1600

x

1200

59.94 / 60

59.94 / 60
50

59.94 / 60
50

59.94 / 60
50

59.94 / 60

59.94 / 60
50
48
50

59.94 / 60

23.98 / 24
25

29.97 / 30
50

59.94 / 60

59.94 / 60
50

59.94 / 60

23.98 / 24
25

29.97 / 30

23.98 / 24
25

29.97 / 30
50

59.94 / 60
70
85
70
85
60
72
75
85
56
60
72
75
85
60
70
75
85
60
60

15.734/15.75

15.734/15.75

15.625

15.734/15.75

15.625

15.734/15.75

15.625

15.734/15.75

31.469/31.5

15.625
30

31.25

33.746/33.78

17.985/18

18.75

22.478/22.5

37.5

44.955/45

33.716/33.75

28.125

33.716/33.75

26.978/27

28.125

33.716/33.75

26.978/27

28.125

33.716/33.75

62.5

67.433/67.5

31.469

37.861

31.469

37.861

31.469

37.861

37.5

43.269

35.156

37.879

48.077

46.875

53.673

48.363

56.476

60.023

68.678

63.981
75

Format

Resolution

V(Hz

)

H(KHz)Comp.1/2

CVBS/S-Video

RGB HDMI

❖ Timing chart

SPECIFICATIONS

❖ Optical characteristics

Panel 1080p DLP

Lamp
Lens VP-15S1: f: 30.7 to 44.5mm

Projection size 70 to 250 inches

❖ Input/Output

VIDEO IN RCA x 1

S-VIDEO IN S-Connector x 1

COMPONENT 3RCA x 2

IN Y, CB/PB, CR/PR

RGB/HD IN D-sub M 15 pin x 1

HDMI IN HDMI x 2

REMOTE
CONTROLLER IN

REMOTE
CONTROLLER OUT

AC IN 3 Prong Grounding Type
TRIG.1 OUT, Mini Jack x 2

TRIG.2 OUT Output: DC12V or 0V
RS-232C RS-232C receptacle plug x 1

Specifications may be subjected to change without any prior notice.

36

(1920 x 1080 pixels)

Super High Pressure 200W DC

VP-15S1L: f: 44.5 to 66.75mm

NTSC-3.58/PAL-4.43/SECAM
Composite video 1.0Vp-p/
75 Ohm

NTSC-3.58/PAL-4.43/SECAM
S-Video

Analog RGB
HD:1080i, 720p, 480p

HDMI 1.3 compliant
(single link only)

Mini jack type x 1

Mini jack type x 1

®

❖ General

Power requirement For USA: AC 120V/60Hz

Power consumption
Standby consumption

Chassis isolation Class-1
Safety UL60950-1

EMC FCC Part-15 Class-B

Dimensions VP-15S1:

Net weight 13 kg
OperatingTemperature
Operating humidity 30 to 85%
Storage Temperature
Storage humidity 30 to 85%

❖ Accessories

• Lens cap x 1

• Remote controller x 1

• Batteries x 2

• AC power code x 1

• User Guide x 1

• Warranty Card

(1 copy each for USA, CANADA)
Comes with USA model only.

For Europe: AC 230V/50Hz

< 350 W

For USA: < 0.3 W (AC 120V)
For Europe: < 0.5 W (AC 230V)

CSA C22.2 E60950
EN60950-1

EN55022 Class-B

15/16(W) x 18 5/16(D)

15
x 6 1/8(H) inch

404.5(W) x 489.5(D) x 158(H) mm

VP-15S1L:

15 15/16(W) x 19 19/32(D)

1/8(H) inch

x 6

404.5(W) x 497.5(D) x 158(H) mm

5 to 35 °C

– 20 to 60 °C

9/16 - 2 7/16

(15.0 - 61.8)

6 12/16 (171.0)

5 5/8 (143.0)

3 - 3

9/16 (76.0 - 91.0)

5 3/16 (132.0)

4 11/16 (119.0)

4 1/8

(105.0)

2 5/16

(58.0)

1

10/16

(42.0)

6 1/16

(153.5)

19 9/16 - 19 19/32 (496.5 - 497.5)

7 3/16

(182.5)

3

1/4

( 82.6)

8 12/16

(222.0)

11

11/16

(296.5)

10

5/16

(262.0)

14 6/16 (346.5)

5

9/16

(141.0)

( 64)

2

8/16

5 3/4

(145.75)

4

11/16

(110.0)

3

11/16

(93.5)

7 5/16

(185.25)

12/16

(19.75)

18 1/4 - 18 5/16 (488.5 - 489.5)

8 12/16
(222.0)

7 3/16

(182.5)

3 1/4

( 82.6)

9/16 - 2 7/16

(15.0 - 61.8)

6 12/16 (171.0)

5 5/8 (143.0)

3 - 3 9/16 (76.0 - 91.0)

5 3/16 (132.0)

4 11/16 (119.0)

4 1/8

(105.0)

2 5/16

(58.0)

1 10/16

(42.0)

6 1/16

(153.5)

5 3/4

(145.75)

12/16

(19.75)

11 11/16 (296.5)

10 5/16 (262.0)

14 6/16 (346.5)

5 9/16 - 5 5/8

(142-143)

4 11/16

(110.0)

3 11/16

(93.5)

7 5/16

(185.25)

( 64)

2

8/16

DIMENSIONS

VP-15S1 VP-15S1L

❖ Top

❖ Front

❖ Rear

❖ Top

❖ Front

❖ Bottom❖ Bottom

❖ Rear

ENGLISH

Unit : inch (mm)

37

Note

www.marantz.com

You can find your nearest authorized distributor or dealer on our website.

is a registered trademark.

Printed in Japan 07/2007 00M29AV851250 mzh-g
