Marantz CDR500 F1B, CDR500 U1B, CDR500 N1B Service Manual

CD Recorder/CD Player

CDR500

388K855010 MIT
3120 785 22420
First Issue 2001.02

Service
Manual

CDR500 /F1B, /N1B, /U1B

R

CDR500

Printed in Japan

Please use this service manual with referring to the user guide ( D.F.U. ) without fail.

HEADPHONE

CD RECORDER/CD PLAYER CDR500

PROG

FINAL

TEXT

LEVEL

TIME

CDPLAY MODECDR

INPUT

ERASE

MENU

REC.
MODE

POWER

IR

STANDBY

010

PUSH ENTER

REC LEVEL/SELECT

DELETE

STORE

CANCL

Recordable

ReWritable

TABLE OF CONTENTS

SECTION PAGE

MAIN UNIT

1.1 Servicing the CDR500 .......................................................................................................................... 1-1

1.2 TECHNICAL SPECIFICATIONS .......................................................................................................... 1-3

1.3 WARNINGS .......................................................................................................................................... 1-4

1.4 SERVICE HINTS .................................................................................................................................. 1-5

1.5 TOOLS ................................................................................................................................................. 1-5

1.6 SIAGNOSTIC SOFTWARE .................................................................................................................. 1-6

1.7 FAULTFINDING TREES .................................................................................................................... 1-10

1.8 FAULTFINDING GUIDE ..................................................................................................................... 1-16

1.9 WIRING DIAGRAM ............................................................................................................................ 1-33

1.10 BLOCK DIAGRAM .............................................................................................................................. 1-35

1.11 SCHEMATIC DIAGRAM AND PARTS LOCATION ............................................................................ 1-37

1.12 EXPLODED VIEW AND PARTS LIST ................................................................................................ 1-43

1.13 ELECTRICAL PARTS LIST ................................................................................................................ 1-46

MAR1250 ( CD MODULE )

2.1 WIRING DIAGRAM .............................................................................................................................. 2-1

2.2 SCHEMATIC DIAGRAM ....................................................................................................................... 2-3

2.3 PARTS LOCATION ............................................................................................................................ 2-11

2.4 EXPLODED VIEW AND PARTS LIST ................................................................................................ 2-15

2.5 ELECTRICAL PARTS LIST ................................................................................................................ 2-17

REMARK : This service manual explains them by extracting specifications designed for the
model CDR500 only. The explanation for CD-R module "MAR775" (Loader : CDL4009' +
CD-R Main board) is not mentioned on this service manual.
The CD-R module information is described in the service manual of CD-R modules
<MAR770/MAR775>.

MARANTZ DESIGN AND SERVICE

Using superior design and selected high grade components, MARANTZ company has created the ultimate in stereo sound.
Only original MARANTZ parts can insure that your MARANTZ product will continue to perform to the specifications for which
it is famous.
Parts for your

MARANTZ equipment are generally available to our National Marantz Subsidiary or Agent.

ORDERING PARTS :

Parts can be ordered either by mail or by Fax.. In both cases, the correct part number has to be specified.
The following information must be supplied to eliminate delays in processing your order :

1. Complete address

2. Complete part numbers and quantities required

3. Description of parts

4. Model number for which part is required

5. Way of shipment

6. Signature : any order form or Fax. must be signed, otherwise such part order will be considered as null and void.

SHOCK, FIRE HAZARD SERVICE TEST :

CAUTION : After servicing this appliance and prior to returning to customer, measure the resistance between either primary AC

cord connector pins ( with unit NOT connected to AC mains and its Power switch ON ), and the face or Front Panel of product and
controls and chassis bottom.
Any resistance measurement less than 1 Megohms should cause unit to be repaired or corrected before AC power is applied, and
verified before it is return to the user/customer.
Ref. UL Standard No. 813.

In case of difficulties, do not hesitate to contact the Technical
Department at above mentioned address.

001120MIT

USA

MARANTZ AMERICA, INC

MARANTZ AMERICA, INC.

440 MEDINAH ROAD
ROSELLE, ILLINOIS 60172
USA
PHONE : 630 - 307 - 3100
FAX : 630 - 307 - 2687

BRAZIL

PHILIPS DA AMAZONIA IND. ELET. ITDA

CENTRO DE INFORMACOES AO

CEP 04698-970
SAO PAULO, SP, BRAZIL
PHONE : 0800 - 123123

(Discagem Direta Gratuita)

FAX : [phone]

JAPAN

Technical

MARANTZ JAPAN, INC.
35- 1, 7- CHOME, SAGAMIONO
SAGAMIHARA - SHI, KANAGAWA
JAPAN 228-8505
PHONE : [phone]
FAX : [phone]

EUROPE / TRADING

MARANTZ EUROPE B.V.
P.O.BOX 80002, BUILDING SFF2
5600 JB EINDHOVEN
THE NETHERLANDS
PHONE : +31 - 40 - 2732241
FAX : +31 - 40 - 2735578

TECHNICAL AUDIO GROUP PTY, LTD
558 DARLING STREET,
BALMAIN, NSW 2041,
AUSTRALIA
PHONE : 61 - 2 - 9810 - 5300
FAX : 61 - 2 - 9810 - 5355

CANADA

LENBROOK INDUSTRIES LIMITED
633 GRANITE COURT,
PICKERING, ONTARIO L1W 3K1
CANADA
PHONE : 905 - 831 - 6333
FAX : 905 - 831 - 6936

AUSTRALIA

QualiFi Pty Ltd,
24 LIONEL ROAD,
MT. WAVERLEY VIC 3149
AUSTRALIA
PHONE : +61 - (0)3 - 9543 - 1522
FAX : +61 - (0)3 - 9543 - 3677

NEW ZEALAND

WILDASH AUDIO SYSTEMS NZ
14 MALVERN ROAD MT ALBERT
AUCKLAND NEW ZEALAND
PHONE : +64 - 9 - 8451958
FAX : +64 - 9 - 8463554

THAILAND

MRZ STANDARD CO.,LTD
746 - 754 MAHACHAI ROAD.,
WANGBURAPAPIROM, PHRANAKORN,
BANGKOK, 10200 THAILAND
PHONE : +66 - 2 - 222 9181
FAX : +66 - 2 - 224 6795

TAIWAN

PAI- YUING CO., LTD.
6 TH FL NO, 148 SUNG KIANG ROAD,
TAIPEI, 10429, TAIWAN R.O.C.
PHONE : +886 - 2 - 25221304
FAX : +886 - 2 - 25630415

MALAYSIA

WO KEE HONG ELECTRONICS SDN. BHD.
SUITE 8.1, LEVEL 8, MENARA GENESIS,
NO. 33, JALAN SULTAN ISMAIL,
50250 KUALA LUMPUR, MALAYSIA
PHONE : +60 3 - 2457677
FAX : +60 3 - 2458180

AMERICAS

SUPERSCOPE TECHNOLOGIES, INC.
MARANTZ PROFESSIONAL PRODUCTS
2640 WHITE OAK CIRCLE, SUITE A
AURORA, ILLINOIS 60504 USA
PHONE : 630 - 820 - 4800
FAX : 630 - 820 - 8103

AUSTRALIA

KOREA

MK ENTERPRISES LTD.
ROOM 604/605, ELECTRO-OFFICETEL, 16-58,
3GA, HANGANG-RO, YONGSAN-KU, SEOUL
KOREA
PHONE : +822 - 3232 - 155
FAX : +822 - 3232 - 154

SINGAPORE

WO KEE HONG DISTRIBUTION PTE LTD
130 JOO SENG ROAD
#03-02 OLIVINE BUILDING
SINGAPORE 368357
PHONE : [phone]
FAX : [phone]

1-1

1.1 Servicing the CDR500

1.1.1 INTRODUCTION:

The CDR500 is the professional version of a CD recorder, this means that the SCMS (Serial Copy Management System)
is included. The CDR500 can only record on the Audio and PC CDRs.
The CDR500 is suitable for recording and playback of CD-RW discs (CD-ReWritable disc).

1.1.2 OPENING THE PRODUCT:

The product can be opened by removing the top cover (6 screws). Once the product is opened one can have access to the
several PCB's and the main module.

Below the several PCB's and it function and service policy will be discussed:

Consumer : For Digital Audio
Professional : For General use (Including PC)
P : Playback
R : Recording

Playback & Recording and Disc

Disc

Player/Recorder

CD

CDR

CD-RW

SCMS

Consumer Disc

Consumer Disc

Professional Disc

Professional Disc

Finalized

Finalized

non
Finalized

non
Finalized

non
Finalized

non
Finalized

Finalized Finalized

Audio CD Player

Current products Ex:CD-17

Audio CD Player

CD-RW playback Ex:CD-17MK II

CD-RW Recorder

For Professional Ex:CDR500/631

CD-RW Recorder

For Consumer Ex:DR6050

PP no P no no no no no -
PP no P no P no P no -
P P P/R P P/R P/R P/R P/R P/R no
P P P/R P P P/R P/R P YES

CDR Module

MAR775

Power Supply

PCB

Terminal

PCB

DISPLAY

PCB

CD

Loader

VAL1250

P

PHONE
BOARD

1-2

1.1.2.1 CDR loader (CDR main module CDL4009 or MAR775):

This complete CDR loader is considered as not repairable in the field. therefore this module will be repaired centrally. A

module exchange procedure will be set up for this purpose. The module can be removed from the product by removing 4
screws and the transformer, and loosing the connectors.

This module is the complete CD recorder, it contains the following parts:

CD Mechanism (CDM4009'). Underneath this mechanism a PCB is mounted which is adjusted to the mechanism (laser
current settings are stored in EEPROM).
Loader Assy. This mechanical assy takes care for the tray control.
Main PCB. This PCB takes care that the (analog or digital) signal to be recorded is converted into a suitable signal which
can be recorded on the disc.
Digital signals with an other sampling frequency then 44.1kHz will be converted in the sample rate converter (DASP) to

44.1kHz.
Analog signals will be first converted into a digital converter by the AD converter.
This PCB also takes care that the signal from the CD (playback) is converted into a suitable digital signal (or analog via
the DA converter).
The main microprocessor controls the several functions of this PCB.

1.1.2.2 Power Supply PCB.

This PCB contains the Power Supply, which delivers the sevelal volteges for the each PCB in the CDR500. On this Power
Supply a fuse (Primaly side) are mounted on this PCB. The power SW is jointed the Power bottom on the front panel.
All parts are available as spare parts.

1.1.2.3 Terminal PCB.

This PCB coutaius input and output terminals. All parts are available as spare parts.

1.1.2.4 Display Board.

This PCB contains the Display, which informs the user about the status of the recording/playback process and it also takes
care for scanning the keys on the front panel. The information from the keys is fed via a I C connection to the main
microprocessor on the CDR loader module. Information which needs to be displayed is also fed via this I C line from the
main microprocessor on the CDR loader module to the display controller.
The parts for this PCB are available as service parts so this PCB can be repairable up to component level.

1.1.2.5 Headphone PCB.

This PCB contains the headphone socket and potentiometer which controls the headphone volume. All parts are available
as spare parts.

2

2

IMPORTANT

In case of replace the CD-R module "MAR775", the initialization is necessary.
Please initialize the CD-R module with following orders.

1. Press the POWER button (POWER ON) while depressing FINALIZE button and REC
MODE button together.

2. FL Display shows;
WAIT

PGM PROTOCOL

PGM PORT END

3. Press the POWER button (POWER OFF).

Then the CD-R module set up to CDR500 own status.

1-3

1.2 TECHNICAL SPECIFICATIONS

GENERAL

System .................................................................................................... Compact disc digital audio

Number of channels ................................................................................ 2 (stereo)

Applicable discs ...................................................................................... CD, CD-R (digital audio), CD-RW (digital audio)

Power Requirement

F version ........................................................................................... AC 100 V 50 / 60 Hz

N version ........................................................................................... AC 100 - 240 V 50 / 60 Hz

U version. .......................................................................................... AC 120 V 60 Hz

Power Consumption ................................................................................ 21 W

Operating Temperature . ......................................................................... 5 °

C - 35 °C

Dimension (MAX)

Width ................................................................................................. 483 mm

Height ................................................................................................ 100 mm

Depth ................................................................................................ 340 mm

Weight ................................................................................................ 5.6 kg

AUDIO

Frequency Response .............................................................................. 20 Hz - 20 kHz

Playback S/N .......................................................................................... 100 dB

Playback Dynamic Range ....................................................................... 96 dB

Playback Total Harmonic Distortion ........................................................ 91 dB

Recording S/N ......................................................................................... 88 dB

Recording Dynamic Range ..................................................................... 88 dB

Recording Total Harmonic Distortion ...................................................... 83 dB

Analog Output Voltage ............................................................................ 2 V RMS

Digital Coaxial Output ............................................................................. 0.5 V (p-p) / 75 ohms

Digital Optical Output .............................................................................. - 20 dB

Headphones ............................................................................................ 0 - 5 Vrms / 8 - 2000 ohms

Recording values for line input

Digital Coaxial Input (automatic sample rate conversion) ....................... 11 - 56 kHz

Digital Optical Input (automatic sample rate conversion) ........................ 11 - 56 kHz

Analog Input Sensitivity (Unbalanced) .................................................... 600 mVrms / 50 kohms

Analog Input Sensitivity (Balanced) ........................................................ 0 dBu to +22 dBu / 50 kohms

(default setting : +16 dBu / 50 kohms)

Specifications subject to change without prior notice.

1-4

WARNING

All ICs and many other semiconductors are susceptible to
electrostatic discharges (ESD). Careless handling during
repair can reduce life drastically.
When repairing, make sure that you are connected with the
same potential as the mass of the set via a wristband with
resistance. Keep components and tools at this potential.

ATTENTION

Tous les IC et beaucoup d´autres semi-conducteurs sont
sensibles aux décharges statiques (ESD). Leur longévite
pourrait être considérablement écourtée par le fait qu´aucune
précaution nést prise à leur manipulation.
Lors de réparations, s´assurer de bien être relié au même
potentiel que la masse de l´appareil et enfileer le bracelet
serti d´une résistance de sécurité.
Veiller à ce que les composants ainsi que les outils que l´on
utilise soient également à ce potentiel.

WARNUNG

Alle ICs und viele andere Halbleiter sind empfindlich
gegenüber elektrostatischen Entladungen (ESD).
Unsorgfältige Behandlung im Reparaturfall kann die
Lebensdauer drastisch reduzieren.
Sorgen Sie dafür, daß sie im Reparaturfall über ein Puls­armband mit Widerstand mit dem Massepotential des
Gerätes verbunden sind.
Halten Sie Bauteile und Hilfsmittel ebenfalls auf diesem
Potential.

WAARSCHUWING

Alle IC´s en vele andere halfgeleiders zijn gevoelig voor
electrostatische ontladingen (ESD).
Onzorgvuldig behandelen tijdens reparatie kan de levensduur
drastisch doen vermindern. Zorg ervoor dat u tijdens reparatie
via een polsband met weerstand verbonden bent met hetzelfde
potentiaal als de massa van het apparaat.
Houd componenten en hulpmiddelen ook op ditzelfde potentiaal.

AVVERTIMENTO

Tutti IC e parecchi semi-conduttori sono sensibili alle scariche
statiche (ESD).
La loro longevità potrebbe essere fortemente ridatta in caso di
non osservazione della più grande cauzione alla loro
manipolazione. Durante le riparationi occorre quindi essere
collegato allo stesso potenziale che quello della massa
delápparecchio tramite un braccialetto a resistenza.
Assicurarsi che i componenti e anche gli utensili con quali si
lavora siano anche a questo potenziale.

Safety regulations require that the set be restored to its
original condition and that parts which are identical with
those specified be used.
Safety components are marked by the symbol

Le norme di sicurezza estigono che l´apparecchio venga
rimesso nelle condizioni originali e che siano utilizzati i
pezzi di ricambiago identici a quelli specificati.
Componenty di sicurezza sono marcati con

Veiligheidsbepalingen vereisen, dat het apparaat in zijn
oorspronkeliijke toestand wordt teruggebracht en dat
onderdelen, identiek aan de gespecificeerde, worden toegepast.
De Veiligheidsonderdelen zijn aangeduid met het symbool

Varning !

Osynlig laserstrålning när apparaten är öppnad och
spärren är urkopplad. Betrakta ej strålen.

Advarsel !

Usynlig laserstråling ved åbning når sikkerhedsafbrydere
er ude af funktion. Undgå udsaettelse for stråling.

Varoitus !

Avatussa laitteessa ja suojalukituksen ohitettaessa olet alttiina
näkymättömälle laserisäteilylle. Älä katso säteeseen !

ESD

SAFETY

Bei jeder Reparatur sind die geltenden Sicherheitsvor­schriften zu beachten. Der Originalzustand des Gerätes
darf nicht verändert werden. Für Reparaturen sind Original­ersatzteile zu verwenden.
Sicherheitsbauteile sind durch das Symbol markiert.

Les normes de sécurité exigent que l`appareil soit remis
à l`état d`origine et que soient utilisées les pièces de
rechange identiques à celles spécifiées.
Les composants de sécurité sont marqués

DANGER: Invisible laser radiation when open.

"Pour votre sécurite, ces documents doivent être utilisés par
des spécialistes agréés, seuls habilités à réparer votre
appareil en panne".

After servicing and before returning the set to customer
perform a leakage current measurement test from all
exposed metal parts to earth ground, to assure no
shock hazard exists.
The leakage current must not exceed 0.5mA.

AVOID DIRECT EXPOSURE TO BEAM.

AVAILABLE ESD PROTECTION EQUIPMENT :

anti-static table mat large 1200x650x1.25mm 4822 466 10953

small 600x650x1.25mm 4822 466 10958

anti-static wristband 4822 395 10223
connection box (3 press stud connections, 1M ) 4822 320 11307
extendible cable (2m, 2M , to connect wristband to connection box) 4822 320 11305
connecting cable (3m, 2M , to connect table mat to connection box) 4822 320 11306
earth cable (1M , to connect any product to mat or to connection box) 4822 320 11308
KIT ESD3 (combining all 6 prior products - small table mat) 4822 310 10671
wristband tester 4822 344 13999

LASER PRODUCT

CLASS 3B

U : VERSION N : VERSION

LASER PRODUCT

CLASS III b

1.3 WARNINGS

1-5

1.5 SERVICE TOOLS

“The tools listed below are standard test tools that can be used for repairing and testing Marantz
CD Players & Recorders.”

Audio signals disc 4822 397 30184
Disc without errors (SBC444)+
Disc with DO errors, black spots and fingerprints (SBC444A) 4822 397 30245
Disc (65 min 1kHz) without no pause 4822 397 30155
Max. diameter disc (58.0 mm) 4822 397 60141
Torx screwdrivers

Set (straight) 4822 395 50145

Set (square) 4822 395 50132
13th order filter 4822 395 30204
Hexagon socket screw button (No. 1.5)

1.4 SERVICE HINTS

1-6

1.6 Diangostic Software

6.1 Dealer mode

The purpose of the dealer mode is to prevent people taking out
the CD inside the player at exhibitions, showrooms etc.. This
mode disables the open/close function of the player.
The dealer mode can be switched on and off pressing keys
[OPEN/CLOSE] and [STOP] of the CDR player simultaneously
while switching on the unit. The dealer mode is stored in the
flash memory and can only be changed by executing the above
actions.

6.2 Dealer diagnostics

Figure 6-1

6.2.1 Description

The intention of the dealer diagnostics is to give an indication
of the CDR player status. An inexperienced, even non­technical dealer will/can perform the test. Tests are executed
automatically without need for external tools or disassembly of
the unit. This test checks the CDR main board using the same
tests as the electrical service diagnostics program. Only the
result of the test, "PASSED" or "ERROR", will be shown on the
display. Pressing keys [F FWD] and [REWIND] simultaneously
while switching on the unit, starts the test. Switching off the unit
ends the test.

6.2.2 Requirements to perform the test

• Working keyboard to start up the test.

• Working local display to check the output messages.

DEALER DIAGNOSTICS

(status of player)

Press <REWIND> + <FFWD>

simultaneously and switch

ON unit

If power ON,

switch power OFF

Set OK?

To end test, switch OFF unit

"PASSED"

Set displays

Display blinks

"

BUSY

"

during test

YES

NO

Set displays

"ERROR"

CL96532086-024.eps

090999

1-7

6.3 Electrical service diagnostics

Figure 6-2

CDR MAIN
BOARD TEST

ELECTRICAL SERVICE DIAGNOSTICS

(software versions, test for defective components)

PLAYER
INFORMATION

YES

NO

Tests OK?

If power ON,

switch power OFF

Load CD-DA disc (SBC444A)

Press <PLAY> + <F FWD>

simultaneously and switch ON unit

Display :

"PLAYER ID"
"SW VERSION BACK END"
"SW VERSION CDR LOADER"

(CDR775

"SW VERSION CD LOADER"

)

Display :

"DTST1"

DRAM test (7702)

Display :

"DTST2"

FLASH CHECKSUM test (7702)

Display :

"DTST3"

FLASH ERASE test (7702)

Display :

"DTST4"

CODEC test (7702)

Display :

"DTST5"

CDR LOADER
COMMUNICATION test

Display :

"DTST6"

*

CD LOADER
COMMUNICATION test

PASS OR FAIL

PASS OR FAIL

PASS OR FAIL

PASS OR FAIL

PASS OR FAIL

PASS OR FAIL

Display :

"DERRn"

n = failed test

Display next
failed test

ABORT TEST

Press <F FWD>

ABORT TEST

Press <F FWD>

ABORT TEST

Press <F FWD>

ABORT TEST

Press <F FWD>

ABORT TEST

Press <F FWD>

LOADER TESTS

Display shows current disc time

CDR LOADER TEST
CD-DA disc must be loaded

ABORT TEST

Press <F FWD>

YES

NO

Test OK?

Display :

"BERR1"

or

"NO CDDA"

or

"NO DISC"

Display shows current disc time

CD LOADER TEST *
CD-DA disc must be loaded

YES

NO

Test OK?

Display :

"BERR2"

or

"NO CDDA"

or

"NO DISC"

* FOR CDR500 ONLY

ABORT TEST

Press <F FWD>

Press <F FWD>

Display segments blink at f=1kHz

DISPLAY TEST

Press <F FWD>

DISPLAY TEST

Press <F FWD>

Display shows name of pressed keys

KEYBOARD & RC TEST

KEYBOARD &
RC TEST

To end test, switch OFF unit

* FOR CDR500 ONLY

CL 96532086_025.eps

080999

1-8

6.3.1 Description

The intention of the electrical service diagnostics is to show the
software versions present in the player and to direct the dealer
towards defective internal units. The units are : the CDR main
board, the CDR loader, the CD loader in case of a CDR500 and
the keyboard/display board. A sequence of tests is executed
automatically. Some of the tests can be aborted or skipped
without the result being taken into account. External tools or
disassembly of the unit is not necessary to get the diagnostic
information. Pressing keys [PLAY/PAUSE] and [F FWD]
simultaneously while switching on the unit, starts the test.
Switching off the unit ends the test.

6.3.2 Requirements to perform the test

Working keyboard to start up the test.
Working local display to check the output messages.
A CD-DA disc with a minimum of 3 tracks in all trays to

perform the disc test.

6.3.3 Description of the tests

Player information

In this part of the test the following important information can be
checked without removing the cover :
Recorder ID.
SW-version back end of player.
SW-version CDR loader.
SW-version CD loader (only for CDR500).

CDR main board test

[F FWD] key. The message "DERRn" will be displayed with n
indicating the faulty test number.
If one of the tests is aborted with the [F FWD] key, no error
message will be displayed for this test. The flash data erase
test ("DTST3") can not be aborted !
The CDR main board test consists out of :

DRAM test

Display : "DTST1". The DRAM used for buffer management is
tested by writing, reading and verifying test patterns.

Flash checksum test

Display : "DTST2". This test checks the checksum of the
player's SW stored in the flash.

Flash data erase

Display : "DTST3". During this test, all temporary information
(CDtxt) in the flash is erased.

CODEC (ADC/DAC) test

Display : "DTST4". This test checks the CODEC IC by writing,
reading and verifying test patterns. The test is not applicable for
CDR950.

CDR communication test

Display : "DTST5". The communication between the host
processor (DASP) and the CDR loader via the DSA-R-bus is
tested.

CD communication test

Display : "DTST6"). The communication between the host
processor (DASP) and the CD loader is tested. The test is only
applicable for CDR500.

Loader tests

These tests determine if the CDR loader and the CD loader in
case of a CDR500 work correctly. A CD-DA disc with a
minimum of 3 tracks needs to be inserted in both loaders. A

disc test is executed to check focus control, disc motor control,
radial control and jump grooves control. The disc test is
performed by audio play-back of 5 seconds at the beginning,
middle and end of the disc.

CDR loader test

During the test, the current disc time is shown. In case of an
error the message "BERR1" will be displayed and the [F FWD]
key must be pressed to continue with the following test.
Pressing the [F FWD] key also aborts this test.

CD loader test

For CDR500 only. During the test, the current disc time is
shown. In case of an error the message "BERR2" will be
displayed and the [F FWD] key must be pressed to continue
with the following test. Pressing the [F FWD] key also aborts
this test.

Display test

All segments will blink at a frequency of 1 Hz. Pressing the [F
FWD] key will start the next test because the user has to check
for himself if all segments work properly.

Keyboard and remote control tests

The test will give the user the ability to test every key without
executing the function assigned to it. Therefore, the user needs
to press every key on the keyboard and the remote control. The
display will show the name of the key being pressed. Pressing
more than one key at once will give an unpredictable result
except for the service combinations : [PLAY/PAUSE] + [STOP],
[PLAY/PAUSE] + [F FWD], [F FWD] + [REWIND], [ERASE] +
[RECORD], [PLAY/PAUSE] + [RECORD].

6.4 Mechanical service diagnostics

Figure 6-3

6.4.1 Description

No external tools are required to perform this test. The cover
needs to be removed because the user has to check the
movements of the tray, focus and sledge visually. Pressing
keys [PLAY/PAUSE] and [STOP] simultaneously while
switching on the unit, starts the test. Switching off the unit ends
the test. In case of a CDR500, one can check the CD loader
mechanics in the same way by pressing the above key
combination on the CD player keys.

FOCUS TEST

Display shows

“BUSY”

Visual inspection

TRAY TEST

Visual inspection

Display shows

“OPENED”

even if tray is blocked

<

OPEN

>

<

CLOSE

>

SLEDGE TEST

Visual inspection

<FWD><REWIND>

MECHANICAL SERVICE DIAGNOSTICS

(test for defective components)

Press <PLAY/PAUSE> + <STOP>

simultaneously and switch

ON unit

If power ON,

switch power OFF

To end test, switch OFF unit

Display shows

“BUSY”

CL96532086_026.eps

080999

1-9

6.4.2 Requirements to perform the test

Working keyboard to cycle through the tests and to start up

the test.

Working local display to check the output messages.

6.4.3 Description of the tests

Focus control test

The focussing lens is continuously moving up and down. The
display reads "BUSY".

Sledge control test

After pressing [F FWD] the sledge continuously moves up and
down. Pressing [REWIND] stops the sledge at the position it is
in and the focus control test resumes. The display reads
"BUSY".

Tray control test

This test starts from within the focus control test routine.
Pressing [OPEN/CLOSE] moves the tray in or out. In the tray
open position one can initiate focus and sledge tests by
pressing [F FWD]. One has to stop these tests pressing
[REWIND] before it is possible to close the tray again.
Depending on the action the display reads "OPEN",
"OPENED", "CLOSE" or "BUSY".

6.5 DC- erase service mode

Figure 6-4

6.5.1 Description

This test is initiated by pressing [ERASE] and [RECORD]
simultaneously while switching on the unit. The player will
erase a complete CD-RW disc (including PMA and ATIP lead
out area) at speed N=2. The display shows the countdown of
the remaining time required for the operation to complete. The
format is "ER mm:ss", where "mm" are the remaining minutes
and "ss" the remaining seconds. After completion the message
"PASSED" is shown, and the player has to be switched off and
on again to start up in normal operating mode. Switching off the
unit before completion of the test, leaves the disc in an
unpredictable state. In such case only a complete DC-erase
procedure can recover the CD-RW disc.

6.5.2 Requirements to perform the test

Functional CDR player.
A CD-RW audio disc must be present in the tray.

Load CD-RW disc

Press

<ERASE> + <RECORD>

simultaneously and switch

ON unit

Display shows:

“

PASSED

”

when the erase function is

completed

“

ERROR

”

if DC ERASE fails

Display shows:

“

ER mm:ss

”

mm

:remaining minutes

ss :remaining seconds

TOTAL

and

REM

are also

illuminated

DC ERASE SERVICE MODE

(erasement of complete CD-RW)

To end test, switch OFF unit

CL96532086_027.eps

080999

1-10

1.7 Faultfinding trees

7.1 CDR-Module

Figure 7-1

NO DISC LOADED

SWITCH ON POWER

PRESS

<OPEN/CLOSE>

SEE CD-DA DISC

FAULT FINDING

SEE CD-R DISC
FAULT FINDING

SEE CD-RW DISC

FAULT FINDING

INSERT DISC

PRESS <OPEN/CLOSE>

DISPLAY?

DISPLAY:

"INSERT DISC"

CD-DA DISC

LOADED?

CHECK:

POWER SUPPLY (SEE FAULT FINDING GUIDE PSU)

WIRING
ON/OFF SWITCH
FUSES
VOLTAGES

DISPLAY (SEE FAULT FINDING GUIDE DISPLAY BOARD)

WIRING

CONTROL SIGNALS

CLOCK SIGNAL 8MHz

SUPPLY VOLTAGES

ELECTRICAL SERVICE DIAGNOSTICS:
DISPLAY TEST, KEYBOARD TEST

POWER SUPPLY VOLTAGES
ELECTRICAL SERVICE DIAGNOSTICS:
REPLACE CDR MODULE IF

"DERRn"

OR

"BERRn"

ERROR OCCURS

CHECK:

MECHANICAL SERVICE DIAGNOSTICS:

REPLACE CDR MODULE IF ERROR OCCURS

TRAY?

CD-R DISC

LOADED?

NONO

NO

NO

NO

YES

YESYES

YES

YES

CD-RW DISC

LOADED?

YES

MAINS, MAINS CABLE

CHECK:

STANDBY LED

KEYBOARD

WIRING

DISPLAY BOARD (SEE FAULT FINDING GUIDE DISPLAY BOARD)

WIRING

CONTROL SIGNALS

CLOCK SIGNAL 8MHz

SUPPLY VOLTAGES

ELECTRICAL SERVICE DIAGNOSTICS:
DISPLAY TEST, KEYBOARD TEST

KEYBOARD

CL 96532076_016.eps

290799

1-11

Figure 7-2

PLAY BACK OF CD-DA

DISCS OK

PRESS <PLAY>

CD-DA DISC LOADED

CHECK:

CHECK:

PLAY AUDIO SIGNALS DISC TRACK 15:
SIGNAL OF 5.6 VPP ON PINS 1 AND 3 OF CONN.
J601

MUTE VOLTAGE (pin 7 conn. J601):

-3V DURING PLAY

NO

NO

NO

NO

NO

YES

YES

YES

YES

HEADPHONE?

DIGITAL

YES

DISTORTION?

DISPLAY:

“CD”

&

T.O.C. INFO?

YES

DISC

DETECTION &

READING?

ELECTRICAL SERVICE DIAGNOSTICS:
REPLACE CDR MODULE IF

"DERRn"

OR

"BERRn"

ERROR OCCURS

CHECK:

DISC: DIRT, SCRATCHES, DAMAGED...

NO

POWER SUPPLY VOLTAGES
ELECTRICAL SERVICE DIAGNOSTICS:

REPLACE CDR MODULE IF

"DERRn"

OR

"BERRn"

ERROR OCCURS

CHECK:

WIRING

Terminal BOARD

FLEX CONNECTION
+5V (pin 4 conn. W855)

KILL TRANSISTORS QN51 - QN54

AUDIO

ANALOG

OUT?

ELECTRICAL SERVICE DIAGNOSTICS:
REPLACE CDR MODULE IF

"DERRn"

OR

"BERRn"

ERROR OCCURS

AUDIO CONNECTIONS & CABLES

CHECK:

Terminal BOARD

CONNECTION
+5V (pin 3 conn. W855)

ELECTRICAL SERVICE DIAGNOSTICS:
REPLACE CDR MODULE IF

"DERRn"

OR

"BERRn"

ERROR OCCURS

AUDIO CONNECTIONS & CABLES

CONNECTION OF HEADPHONE BOARD

ELECTRICAL SERVICE DIAGNOSTICS:
REPLACE CDR MODULE IF

"DERRn"

OR

"BERRn"

ERROR OCCURS

CHECK:

AUDIO CONNECTIONS & CABLES
Terminal BOARD

FLEX CONNECTION
+5V (pin 3 conn. J601)

ELECTRICAL SERVICE DIAGNOSTICS:
REPLACE CDR MODULE IF

"DERRn"

OR

"BERRn"

ERROR OCCURS

AUDIO

OUT?

HEADPHONE BOARD

WIRE CONNECTION

+8V (pin 5 conn. W903), -8V (pin 2 conn. W903)

KILL TRANSISTOR, C911, C912
PLAY SBC442 DISC (1kHz, -30dB) AND
CHECK SIGNAL AT Q901

CHECK SIGNAL

-FOR COAXIAL OUT AT Q312, LT13

-FOR OPTICAL OUT AT Q312, JT21

1-12

Figure 7-3

FINALISED CD-R DISC

LOADED

SET OK

CD-R DISC PARTIALLY

RECORDED OR EMPTY

START RECORDING

FROM DIGITAL

SOURCE

START MANUAL

RECORDING FROM

ANALOG SOURCE

CD-R DISC LOADED

LEVEL

ADJUSTABLE?

NO

YES

DIGITAL IN?

OPTICAL IN?

NO

YES

RECORDING

SUCCESSFUL?

NO

YES

NO

YES

DISPLAY:

“CD R”

&

OPC INFO?

YES

DISC

DETECTION &

READING?

ELECTRICAL SERVICE DIAGNOSTICS:
REPLACE CDR MODULE IF

"DERRn"

OR

"BERRn"

ERROR OCCURS

CHECK:

DISC: DIRT, SCRATCHES, DAMAGED...

NO

POWER SUPPLY VOLTAGES
ELECTRICAL SERVICE DIAGNOSTICS:

REPLACE CDR MODULE IF

"DERRn"

OR

"BERRn"

ERROR OCCURS

CHECK:

WIRING

NO

YES

DISPLAY:

“CD”

&

T.O.C. INFO?

SEE CD-DA DISC

FAULT FINDING

CHECK:

ELECTRICAL SERVICE DIAGNOSTICS:
REPLACE CDR MODULE IF

"DERRn"

OR

"BERRn"

ERROR OCCURS

DISPLAY BOARD (SEE FAULT FINDING GUIDE DISPLAY BOARD)

EASY JOG KNOB
I2C COMMUNICATION
ELECTRICAL SERVICE DIAGNOSTICS:
KEYBOARD TEST

AUDIO CONNECTIONS & CABLES

CHECK:

CHECK SIGNAL

-FOR COAXIAL IN AT Q311

-FOR OPTICAL IN AT J301

AUDIO CONNECTIONS & CABLES
I/O BOARD

FLEX CONNECTION
+5V (pin 3 conn. W855)

ELECTRICAL SERVICE DIAGNOSTICS:
REPLACE CDR MODULE IF

"DERRn"

OR

"BERRn"

ERROR OCCURS

CHECK:

ELECTRICAL SERVICE DIAGNOSTICS:
REPLACE CDR MODULE IF

"DERRn"

OR

"BERRn"

ERROR OCCURS

ANALOG IN?

NO

YES

CHECK:

CHECK SINGNAL

-FOR BALANCE IN AT Q761-Q764

-FOR UNBALANCE IN AT Q764

-FOR BALANCE & UNBALANCE IN AT Q702

•

AUDIO CONNECTIONS & CABLES

•

AUDIO BOARD

⇒

⇒

• ELECTRICAL SERVICE DIAGNOSTICS:

REPLACE CDR MODULE IF

"DERRn"

OR

"BERRn"

ERROR OCCURS

+8VA (QM01), -8VA (QM02)

1-13

Figure 7-4

CD-RW DISC LOADED

START ERASING OF LAST RECORDED TRACK

SET OK

ERASING

SUCCESSFUL?

YES

NO

FINALISED CD-RW DISC

LOADED

CD-RW DISC PARTIALLY

RECORDED OR EMPTY

NO

YES

DISPLAY:

“CD RW”

&

OPC INFO?

YES

DISC

DETECTION &

READING?

ELECTRICAL SERVICE DIAGNOSTICS:
REPLACE CDR MODULE IF

"DERRn"

OR

"BERRn"

ERROR OCCURS

CHECK:

DISC: DIRT, SCRATCHES, DAMAGED...

NO

POWER SUPPLY VOLTAGES
ELECTRICAL SERVICE DIAGNOSTICS:

REPLACE CDR MODULE IF

"DERRn"

OR

"BERRn"

ERROR OCCURS

CHECK:

WIRING

NO

YES

DISPLAY:

“CD”

&

T.O.C. INFO?

SEE CD-DA DISC

FAULT FINDING

CHECK:

ELECTRICAL SERVICE DIAGNOSTICS:
REPLACE CDR MODULE IF

"DERRn"

OR

"BERRn"

ERROR OCCURS

IF DISC CORRUPTED TRY DC ERASE

CL 96532076_019.eps

290799

1-14

7.2 C D Module

Figure 7-5

NO DISC

POWER ON

PRESS

<OPEN/CLOSE>

LOAD DISC

(CD-DA OR PARTIALLY

RECORDED CD-R/CD-RW)

PRESS <OPEN/CLOSE>

DISC

DETECTION

STARTS?

DISPLAY?

CHECK FLEX CONNECTION FROM CDR MAIN BOARD
POWER SUPPLY

+5V, +12V AT TESTPOINTS 28 AND 27

+5V AT IC7005 PIN 14
+3V3 AT IC7000 PINS 5,17,21,57, CHECK SAFETY RESISTORS
+5V AT IC7020 PIN 25
+10V AT IC7020 PINS 26, 27, 28
+12V AT IC7021 PIN 5, CHECK SAFETY RESISTOR R3131
+12V AT IC7022 PIN 5, CHECK SAFETY RESISTOR R3154
+5V AT IC7025 PIN 16
+5V AT IC7202 PIN 38, CHECK SAFETY RESISTOR R3308
+3V3 AT IC7309 PINS 4 AND 13, CHECK SAFETY RESISTORS R3215, R3216

CLOCKS

8.4672MHz AT TESTPOINT 7
12MHz AT TESTPOINTS 29 AND 30

11.2896 AT TESTPOINT 10

DISPLAY

SEE FAULTFINDING GUIDE DISPLAY BOARD

MICROPROCESSOR 7202

DIAGNOSTIC SOFTWARE : MECHANICAL SERVICE DIAGNOSTICS CD LOADER : TRAY TEST

CHECK TRAY MOTOR VOLTAGES

TRAY+, TRAY-

MICROPROCESSOR 7202
CHECK TRAY MOTOR DRIVER IC7021
REPLACE OR REPAIR CD LOADER ASSY:

TRAY MOTOR ASSY 02, BELT 11

TRAY?

NO

NO

NO

YES

YES

YES

TOC?

YES

NO

DIAGNOSTIC SOFTWARE : MECHANICAL SERVICE DIAGNOSTICS CD LOADER :

FOCUS TEST & SLEDGE TEST

CHECK WIRING TO CDM
CHECK POWER DRIVERS 7021, 7022, 7020
CHECK VOLTAGES ON POWER DRIVERS (SEE CIRCUIT DIAGRAMS)
TESTPOINTS 4, 5, 6 : PULSE DENSITY MODULATED SIGNALS

HF PATH

TESTPOINTS 1, 2, 3, 9 : EYEPATTERN
CHECK

RW

AT TESTPOINT 8 : HIGH FOR CDDA AND CDR DISC, LOW FOR

CDRW DISC. EYEPATTERN OF CDRW DISC WILL BE AMPLIFIED (

X 2.5).

EYEPATTERN OF CDDA DISC WILL BE ATTENUATED(

X 0.8)

CHECK

S1,S2

AT TESTPOINTS 25 AND 26 (SEE CIRCUIT DIAGRAMS)

TESTPOINTS 20, 21, 22: I

2

S

DATA, WCLK, SCLK

REPLACE OR REPAIR CD LOADER ASSY (CDM MECHANISM)

SEE NEXT PAGE:

PLAYBACK

CD MODULE

+5V AT CONN. 1000 PINS 1 AND 3

+12V AT IC7120 PIN 8, CHECK SAFETY RESISTOR R3263

2.1168MHz AT TESPOINT 20

44.1kHz AT TESTPOINT 21

CL 96532086_030.eps

080999

1-15

Figure 7-6

CD MODULE PLAYBACK

PRESS <PLAY>

AUDIO?

DAC 7309

TESTPOINTS 20, 21, 22 : I2S AT INPUT OF DAC 7309
CHECK POWER SUPPLY PINS 4, 13
CHECK CLK11 AT PIN 6 : 11.2896MHz
PIN 11 : MUTE HIGH?
TESTPOINTS 23, 24 : ANALOG OUTPUT?
REPLACE DAC 7309

OPAMP 7120

TESTPOINTS 23, 24 : ANALOG OUTPUT?
POWER SUPPLY: PIN 8 12V

REPLACE OPAMP 7120

NO

YES

PLAYBACK CD

MODULE OK

DISTORTION?

NO

YES

NO

DAC 7309
OPAMP 7120

AUDIO

CD OUT PCB?

YES

FLEX TO CDR MAINBOARD
FLEX TO CD OUT BOARD

CHECK I/O BOARD, CD OUT BOARD

CL 96532086_031.eps

080999

1-16

1.8 Faultfinding Guide

8.1 D isplay Boar d

8.1.1 Description of display board

General description

The display board has three major parts : the FTD (Fluorescent
Tube Display), the display controller TMP87CH74F and the
keyboard. The display controller is controlled by the DASP
master processor on the CDR main board. The communication
protocol used is I2C. So all the information between DASP and
display controller goes via the SDA or I2C DATA and SCL or
I2C CLK lines. Communication is always initiated by the DASP
on the CDR main board. Unlike the previous generations of
CDR players, the interrupt generated by the display controller
at key-press or reception of remote control is not used. Instead,
the DASP polls the display controller for these events.

Display controller TMP87C874F

TMP87CH74F ( QY01) is a high speed and high performance
8-bit single chip microprocessor, containing 8-bit A/D
conversion inputs and a VFT (Vacuum Fluorescent Tube)
driver. In this application, its functions are :
slave microprocessor.
FTD driver.
generates the square wave for the filament voltage

required for an AC FTD.
generates the grid and segment scanning for the FTD.
generates the scanning grid for the key matrix.
input for remote control.
All the communication runs via the serial bus interface I2C. The
display controller uses an 8MHz resonator as clock driver.

Figure 8-1

651516

26

27

28

29

30

31

32

34

35

36

37

41

141211 17 18 20 21 22

42434445464748495051

10

25

23 244

74

73

72

71

70

69

68

67

66

65

3

64 63 62 61 60 59 58 57 56 55254 53

1

80

79

77

76

75

13

39
38

40

78

79819

33

52

TMP87C874F

SCL

SDA

VSS1

XOUT

XIN

RESETN

P22

P21

TEST1

P20

INT0

INT1

SCK0

PORT3

I C

2

VKK

COUNTER

PROGRAM

I/O PORT1

TIMER/COUNTER

I/O PORT6 (VFT)

VASS

VAREF

VDD

I/O PORT8 (VFT)

CONVERT.

8 BIT A/D

16 BIT

( RAM )

512X8 BIT

DATA MEMORY

TIMER/COUNTER

( ROM )
8kX8 BIT

INTERRUPT

CONTROLLER

I/O PORT7 (VFT)

( I/O PORT2 )

PROGR MEMORY

I/O PORT0

CLOCK/TIMING CONTROLLER

8 BIT

I/O PORTD (VFT) I/O PORT9 (VFT)

I/O PORT5

I/O PORT4

C P U

INT0 external interrupt input 0
INT1 external interrupt input 1
RESETN reset signal input, active low
SCL I2C-bus serial clock input/output
SDA I2C-bus serial data input/output
TEST test pin, tied to low
VAREF analog reference voltage input
VASS analog reference ground
VDD +5V
VKK VFT driver power supply
VSS ground
XIN, XOUT resonator connecting pins for high-frequency clock

BLOCK DIAGRAM

PIN DESCRIPTIONS

CL 96532076_028.eps

290799

1-17

8.1.2 Test instructions

Supply voltages

The display board receives several voltages via connector
JY01.

• VFTD : -35V ±5% measured at pin 2 of conn. JY01.

• VDC1-VDC2 : 4.1V ±10% measured between pin 1 and 3 of
conn. 1119.

• +5 V : +5V ±5% measured at pin 10 of conn. JY01

Voltages VFTD, VDC1 and VDC2 are produced in the power
supply unit and sent to the display board via the CDR main
board. The +5V voltage is produced on the CDR main board as
D5V.

Clock signal

As clock driver for the display controller, a resonator of 8 MHz
(XY01) is used. The signal can be measured at pins 8 and 9 of
the display controller : 8 MHz ±5%.

Control signals

RESET

The reset signal comes via pin 4 of conn. JY01 from the DASP
master processor on the CDR main board (SYS_RESET). The
reset is low active. It should be kept low during power up for at
least 3 machine cycles with supply voltage in operating range
and a stable clock signal (1 machine cycle = 12 x 1/Fc (8 MHz)
sec.). During normal operation, the reset should be high (3V3).
The high signal is 3V3 because the DASP operates on 3V3.

I2C DATA/I2C CLK

These lines connect to the DASP master processor via
respectively pin 5 and pin 7 of conn. JY01

. When there is no
communication, they should have the high level (+5V). The
oscillogram below gives an indication of how these signals
should look like.

Figure 8-2 ‘I2C signals’

FTD drive lines

Filament voltage

Should measure 4.1V ±10% (=VDC1-VDC2) between pins 1-3
and pins 1-52 of the FTD(VX01).

Grid lines

Level and timing of all grid lines, G1-->G15, can be checked
either at the FTD itself or at the display controller. Grid lines
G13, G14 and G15 each have an extra current amplifier in line
: QY04 for G13, QY03 for G14 and QY02 for G15. A typical
grid line signal shows in the oscillogram below.

Figure 8-3 ‘Gridline’

Segment lines

Level and timing of all segment lines, P1-->P21, can be

checked either at the FTD itself or at the

display controller.

The data on these segment lines however,

characters displayed. The oscillogram below

shows a

segment

line with data. A segment line without data

maintains

a -34V level.

Figure 8-4 ‘Segment line’

Key matrix lines

The lines connected to pins 34, 35, 36 and 37 of the display
controller act as matrix scanners. Without a key pressed, they
maintain a low level. As soon as a key is pressed, the scanning
line connected to that key puts out a scanning signal, which
should look like the oscillogram below. This scanning signal
goes via the pressed key to I/O port 4 of the display controller
(pins 28 to 33). The display controller can now determine which
key has been pressed. Without a key pressed, pins 28 to 33 of
the display controller maintain a high level (+5V).

PM3392A

CH1! 2. 00 V =
CH2 2 V= M TB10.0ms ch 1+

+5V

0V

+5V

0V

I2C DATA

I2C CLK

CL 96532076_025.eps

290799

PM3392A

CH1!10.0 V= M TB1. 00ms ch 1+

0V

+4V

-34V

CL 96532076_024.eps

290799

PM3392A

CH1! 10.0 V= M TB1. 00ms ch 1+

0V

+5V

-34V

CL 96532076_027.eps

290799

depends on the

1-18

Figure 8-5 ‘Key matrix scan line’

Easy jog knob

Rotary operation

The easy jog knob (SY26) incorporates a whole heap of user
control possibilities in just one knob. Without the knob being
operated, pin 1 and 3 of the knob (and thus pin 16 and 17 of the
display controller), maintain the +5V level. Turning the knob
clockwise briefly connects pin 1 to GND followed by pin 3.

Figure 8-6 ‘Turn clockwise’

Turning the knob anti-clockwise briefly connects pin 3 to GND
followed by pin 1.

Figure 8-7 ‘Turn anti-clockwise’

The pulses created this way arrive at pin 16 and 17 of the
display controller. The first pulse to arrive tells the controller the
direction of the rotation. Counting the pulses reveals the
amount of rotation. Combining and decoding this information,
the display controller will execute the appropriate task.

Push button operation

This button connects to the key matrix lines and thus the
operation is identical to the ordinary keys. Without being
pressed, pin 4 of the easy jog maintains the low level, pin 5 the
high level. When pressed the scanning signal goes through the
closed contact of pins 4 and 5, and can be checked at both
pins.

IR receiver - remote control

In the CDR500 the IR receiver RPM6934-V4 (ZY01) is
mounted on the IR board. In all versions the IR receiver
connects to the display controller. The signal coming from the
receiver can be checked at pin 22 of the display controller. This
signal is normally high (+5V). When the remote control is being
operated, pulses mixed in with the +5V can be measured. The
oscillogram gives an indication of how the signal looks like with
the RC being operated.

Figure 8-8 ‘IR receiver signal’

PM3392A

CH1!2. 00 V= MT B5.00m s ch1+

0V

+5V

CL 96532076_026.eps

290799

PM3392

Pin3

Pin1

CH1 5.00 V=
CH2 5.00 V= MTB20.0ms- 1.92dv ch2-

CL 96532076_023.eps

290799

PM3392

Pin3

Pin1

CH1 5.00 V=
CH2 5.00 V= MTB20.0ms- 1.92dv ch2-

CL 96532076_022.eps

290799

PM3392A

CH1! 2.00 V= MT B20. 0ms ch 1+

1

+5V

0V

CL 96532076_021.eps

290799

1-19

8.1.3 Display board troubleshooting guide

Figure 8-9 Display board troubl eshooting’

SWITCH POWER ON,

EXIT STAND BY

MODE

DISPLAY BOARD

OK

DISPLAY?

CHECK :

SUPPLY VOLTAGES

-34V

± 5

% at conn. JY01-2

4V1

±

10% between conn. JY01-1 and JY01-3

+5V

±

5 % at conn. JY01-10

CLOCK SIGNAL

8Mhz at pins 8, 9 of QY01

CONTROL SIGNALS

RESETN 3V3 (high) at conn. JY01-4 after start up
I2C DATA at conn. JY01-5
I2C CLK at conn. JY01-7

FTD DRIVE LINES

Filament voltage 4V1

±

10% between pins 1-3 and

pins 1(2)-52(53)

of the FTD (VX01)
Grid lines (see test instructions)
Segment lines (see test instructions)

ELECTRICAL SERVICE DIAGNOSTICS - Local display test

YES

YES

YES

KEY

FUNCTIONS?

REMOTE

CONTROL?

NO

NO

CHECK:

KEY MATRIX LINES (see test instructions)
ELECTRICAL SERVICE DIAGNOSTICS – Keyboard test
EASY JOG KNOB (see test instructions)

NO

CHECK:

IR RECEIVER signal at pin 22 of QY01 ( see test instructions)
ELECTRICAL SERVICE DIAGNOSTICS – Remote control test

1-20

8.2 Power Supply Unit P816

8.2.1 Description of P816

MOSFET Q825 is used as a power switch controlled by the
controller Q810. When the switch is closed, energy is
transferred from mains to the transformer. This energy is
supplied to the load when the switch is opened. Through
control of the switch-on time, the energy transferred in each

cycle is regulated so that the output voltages are independent
of load or input voltage variations. The controlling device
MC44603 is an integrated pulse width modulator. A clock
signal initiates power pulses at a fixed frequency. The
termination of each output pulse occurs when a feedback
signal of the inductor current reaches a threshold set by the
error signal. In this way the error signal actually controls the
peak inductor current on cycle-by-cycle basis.

Figure 8-10 ‘Blockdiagram P816’

Description of controller MC44603

The MC44603 is an enhanced high performance controller that
is specifically designed for off-line and DC-to-DC converter
applications. This device has the unique ability of automatically
changing operating modes if the converter output is
overloaded, unloaded or shorted. The MC44603 has several
distinguishing features when compared to conventional SMPS
controllers. These features consist of a foldback facility for
overload protection, a standby mode when the converter output
is slightly loaded, a demagnetization detection for reduced
switching stresses on transistor and diodes, and a high current
totem pole output ideally suited for driving a power MOSFET. It
can also be used for driving a bipolar transistor in low power
converters. It is optimised to operate in discontinuous mode but
can also operate in continuous mode. Its advanced design
allows use in current mode or voltage mode control
applications.

Pin connections

Figure 8-11

Rref

R Frequency Standby

Voltage feedback Input

Error Amp Output

R Power Standby
Soft-Start/Dmax/

Voltage Mode

Sync Input

Overvoltage Protection (OVP)

Current Sense Input

Demag. Detection

Foldback Input

107

CT

8 9

6

5

11

12

Output

Gnd

VC

VCC

3

4

2

14

13

15

1 16

CL 96532076_030.eps

290799

ERROR
AMP

IREFSYNC

RF
STANDBY

RP
STANDBY

VOLTAGE

VREF

VSB
OUT

2.5V

FEEDBACK
E/A OUT

FOLDBACK

INPUT

FOLDBACK

=1

DMAX&
SOFT-START
CONTROL

SOFTSTART

&DMAXSENSEINPUT

CURRENT

OVER
VOLTAGE
MANAGEMENT

OVER
VOLTAGE
PROTECT

BUFFER

VREF VOCTHERMAL

SHUTDOWN

LATCH

Q

UVL01

IREF

SUUPLY

INITIZLIZATION BLOCK

REFERENCE
BLOCK

VREFIREF

(REDUCED FREQUENCY)

STANDBY

OSCILLATOR

DEMAGNETISATION
MANAGEMENT

DEMAGINETIZATION
DETECT

MC44603P

UVL01

L831

Q810

GND
+5V
+5V
GND
GND
GND
+12V

-8V

GND

GND

GND

+12V

+5V

1

2

3

4

6

11

75

13

14

12

15

10

9

8

16

U810

U811

SELECT
JUMPER

(-8V)

+12V

+12V

-12V

(-8V)

-12V

-12V/-8V

1

4

5

6

7

8

9

10

11

12

13

14

+4.1V

-34V

SWITCHING POWER SUPPLY PCB. (P816)

S1WB

4.7/50V

10k

22

100/25V

2SK2943

1k

1.5

10

µ

H

0.1

100

15

2200pF

180

0.1

2.2/50V

330

1500p

180k1k

15k 15k 4700pF

470p

22k

6.8

µ

H

1

µ

H

10k

2SC

2SA

1k

10k

10k

10k

10

µ

H

PC123F

LM317

1.5

0.1
250V

0.22
250V

18k

1/2W

1.8k

1.8k

330

/16V

100/6.3V

2200
/10V

10/50V

220/50V

1000
/16V

2.2

µ

H

1k

220

/16V 3.3k 100

1.8k

0.022

TL431100

7908

22k

22k

100/25

10k

PC123F

100/25

1k

AG01

RK46

AG01

RU4YX

AG01

10uH

0.1

2SC2878

820pF

82pF

NP0

82k

18k

AG01

AG01

24V

10uH

220

/16V

10k

0.1

10

220

560

0.1

4.7

µ

H

4.7

µ

H

220

/16V

100

/16V

100

/25V

120

/400V

18k

1/2W

0.01

0.1

470pF

/1kV

1

4.7k

330k

(UL/CSA,MITI)

1M(CB)

0.1

0.1

0.1

681
1%

2.21k
1%

10

µ

H

470pF
/400V

470pF
/400V

470pF
/400V

220/16V

100/10V

OPTION

OPTION

J820

J821

J801

L820

D802

C829

R829

R811

C833

D806

D807

Q825

L825

R825

R827

L832

C811

R812

R813

C813

R816

C814

C810

R809

C809

R807R806

R805 R804 C804

C803

R802

L856

L861

R861

Q861

Q862

R862

R863

R864

R865

L862

D868

Q801

L831

Q851

R828

J851

S815

F820

C819

C820

R823

R815

R814

C856

J852

C852

C854

C857

C862

C864

C867

C868

L867

R866

C872

R881 R882

R883

C882

D881R887

Q871

D862

J828

R891

R892

C891

R893

Q892

C892

R894

D803

D804

D851

D856

D861

D866

D871

L866

L871

L873

C877

Q891

C802

C801

R801

R808

D814

D832

D829

L872

C873

R810

C855

R853

R852

R851

C860

L851

L853

C869

C875

C881

C821

R832

G815

J891

C898

C827

R826

R803

R819

C851

C861

C871

C866

R885

R884

R886

L854

L852

C825

C826

C828

C876

C859

R835

D835

1-21

Pin function description

Figure 8-12

Pin Name Description

1 VCC This pin is the positive supply of the IC. The operating voltage range after start-up is 9.0 to 14.5 V.

2 VC The output high state (VOH) is set by the voltage applied to this pin.

3 Output

P

eak currents up to 750 mA can be sourced or sunk, suitable for driving either MOSFET or bipolar transistors.

4 Gnd The groundpin is a single return, typically connected back to the power source.

5 Foldback Input The foldback function provides overload protection.

6 Overvoltage

Protection

When the overvoltage protection pin receives a voltage greater than 2.5V, the device is disabled and requires a
complete restart sequence.

7 Current Sense

Input

A voltage proportional to the current flowing into the power switch is connected to this input.

8 Demagnetisation

Detection

A voltage delivered by an auxiliary transformer winding provides to the demagnetisation pin an indication of the
magnetisation state of the flyback transformer. A zero voltage detection corresponds to complete core
saturation.

9 Synchronisation

Input

The synchronisation input pin can be activated with either a negative pulse going from a level between 0.7V and

3.7V to Gnd or a positive pulse going from a level between 0.7V and 3.7V up to a level higher than 3.7V. The
oscillator runs free when Pin 9 is connected to Gnd.

10 C

T

The normal mode oscillator frequency is programmed by the capacitor CT choice together with the Rref
resistance value. CT, connected between Pin 10 and Gnd, generates the oscillator sawtooth.

11 Soft-

Start/Dmax/Volta
ge-Mode

A capacitor, resistor or a voltage source connected to this pin limits the switching duty-cycle. This pin can be
used as a voltage mode control input. By connecting Pin 11 to Ground, the MC44603 can be shut down.

12 RP Standby A voltage level applied to the RP Standby pin determines the output power level at which the oscillator will turn

into the reduced frequency mode of operation (i.e. standby mode). An internal hysteresis comparator allows to
return in the normal mode at a higher output power level.

13 E/A Out The error amplifier output is made available for loop compensation.

14 Voltage

Feedback

This is the inverting input of the Error Amplifier. It can be connected to the switching power supply output
through an optical (or other) feedback loop.

15 RF Standby The reduced frequency or standby frequency programming is made by the RF Standby resistance choice.

16 Rref

Rref sets the internal reference current. The internal reference current ranges from 100

µ

A to 500µA. This

requires that 5.0kΩ Rref 25kΩ.

CL 96532076_031.eps

290799

<

=

<

=

1-22

Block diagram of MC44603

Figure 8-13

Operating description of MC44603

The input voltage Vcc (pin 1) is monitored by a comparator with
hysteresis, enabling the circuit at 14.5V and disabling the
circuit below 7.5V. The error amplifier compares a voltage Vfb
(pin 14) related to the output voltage of the power supply, with
an internal 2.5V reference. The current sense comparator
compares the output of the error amplifier with the switch
current Isense (pin 7) of the power supply. The output of the
current sense comparator resets a latch, which is set every
cycle by the oscillator. The output stage is a totem pole,
capable of driving a MOSFET directly.

Start up sequence of P816

t1: Charging the capacitors at Vcc
C829 will be charged via R823 and R832, C833 and
C811 v ia R829. The output is switched off during t1.
t2: Charging of output capacitors
When the input voltage of the IC exceeds 14.5V, the circuit is
enabled and starts to produce output pulses. The current
consumption of the circuit increases to about 17mA, depending
on the external loads of the IC. At first, the capacitors at the Vcc
pin will discharge because the primary auxiliary voltage,
coming from winding 7-9 is below the Vcc voltage. At some
moment during t2, the primary auxiliary voltage reaches the
same level as Vcc. This primary auxiliary voltage now
determines the Vcc voltage.
t3: Regulation
The output voltage of the power supply is in regulation.
t4: Overload
When the output is shorted, the supply voltage of the circuit will
decrease and after some time drop below the lower threshold
voltage. At that moment, the output will be disabled and the
process of charging the Vcc capacitors starts again. If the
output is still shorted at the next t2 phase, the complete start­and stop sequence will repeat. The power supply goes in a
hiccup mode.

Figure 8-14 ‘Start-up sequence’

Regulation of P816

Figure 8-14 shows the most relevant signals during the
regulation phase of the power supply.
The oscillator voltage ramps up and down between V1 and V2.
The voltage at the current sense terminal is compared every
cycle with the output of the error amplifier Vcomp. The output

VS8 OUT

CONTROL

Dmax &
SOFT-START

Vref

Voc

GND

OUT

VC

PROTECT

VOLTAGE

OVER

MANAGEMENT

OVER
VOLTAGE

DEMAGNETISATION

MANAGEMENT

OSCILLATOR

STANDBY

(REDUCED FREQUENCY)

ERROR
AMP

CURRENT
SENSE

DEMAGNETISATION
DETECT

SYNC INPUT

CT

RF STANDBY

Iref

REFERENCE

BLOCK

SUPPLY

INITIALISATION BLOCK

Vref Iref

Vref

enable

UVL01

VOSC

VOSC PROT

=1

LATCH

THERMAL
SHUTDOWN

BUFFER

VOLTAGE
FEEDBACK

2.5V

RP STANDBY

Iref

UVL01

Vref

FOLDBACK

FOLDBACK
INPUT

CURRENT SENSE

INPUT

SOFT-START
& DMAX

1

2

3

4

6

57 11

8

9

10

15

12

14

13

E/A OUT

16

C

1Set

1Reset

Vstby

CL 96532076_032.eps

290799

1mA

Vo

0

OUTPUT

t4

short

Icc

0V

17mA

14.5V

7.5V

t1

Vcc

p.a.v.

t2 t3

10V

CL 96532076_035.eps

290799

1-23

is switched off when the current sense level exceeds the level
at the output of the error amplifier.
TimeON phase : A drain current will flow from the positive
supply at pin 2 of the transformer through the transformer's
primary winding, the MOSFET and Rsense to ground. As the
positive voltage at pin 2 of the transformer is constant, the
current will increase linearly and create a ramp dependent on
the mains voltage and the inductance of the primary winding. A
certain amount of energy is stored in the transformer in the form
of a magnetic field. The polarity of the voltages at the
secondary windings is opposite to the primary winding so that
the diodes are non-conducting in this phase.
TimeDIODE phase : When the MOSFET is switched off,
energy is no longer supplied to the transformer. The inductance
of the tranformer now tries to maintain the current which has
been flowing through it at a constant level. The polarity of the
voltage from the transformer therefore reverses. This results in
a current flow through the transformer's secondary winding via
the now conducting diodes, electrolytic capacitors and the load.
This current is also ramp shaped but decreasing.
TimeDEAD phase : when the stored energy has been supplied
to the load, the current in the secondary windings stops flowing.
At this point, the drain voltage of the MOSFET will drop to the
voltage of C821 with a ringing caused by the drain-source
capacitance with the primary inductance.
The oscillator will start a next cycle which consists of the above
described three phases. The time of the different phases
depends on the mains voltage and the load.
TimeDEAD is maximum with an input of 400VDC and a
minimum load. It will be zero with an input of 100VDC and an
overload.

Figure 8-15 ‘Regulation’

Figure 8-16 ‘Oscillograms’

Vosc

Idiodes

Vgate

Vdrain

Idrain

Vsense

Vcomp

0

V2

V1

Ton Tdiode Tdead

CL 96532076_034.eps

290799

PM3394B

ch2

ch3

ch1

CH1 2
CH2
CH3 2 V~ ALT MTB5.00us- 0.90dv ch1-

1

2

3

T

ch1 : Drain voltage
ch2 : Drain current
ch3 : Gate voltage

PM3394B

ch3

ch1

CH1 1
CH3 50mV~ ALT MTB5.00us- 0.90dv ch1-

1

3

T

ch1 : Drain voltage
ch2 : Oscillator voltage

PM3394B

ch3

ch1

CH1 1
CH3 20mV~ ALT MTB5.00us- 0.90dv ch1-

1

3

T

ch1 : Drain voltage
ch3 : Sense voltage

CL 96532076_033.eps

290799

1-24

Circuit description of P816

Input circuit

The input circuit consists of a lightning protection circuit and an
EMI filter.
The lightning protection comprises R819.
The EMI filter is formed by C820, L820, C825 and C826.

It prevents inflow of noise into the mains.

Primary rectifier/smoothing

The AC input is rectified by rectifier bridge D802 and smoothed
into C821. The voltage over C821 is approximately 300V.
It can vary from 100V to 390V.

Start up circuit and Vcc supply

This circuit is formed by R823, R834, C829, D828, R829,
R811, C833 and C811.
When the power plug is connected to the mains voltage, the
stabilised voltage over D829 (24V ) will charge C833 via
R829. When the voltage reaches 14.5V across C811, the
control circuit of Q810 is turned on and the regulation starts.
During regulation, Vcc of IC7110 will be supplied by the
rectified voltage from winding 7-9 via L832, D832 and C833.

Control circuit

The control circuit exists of Q810, C802, C804, C807, C809,
C810, R802, R803, R804, R807, R808, R809 and R810.

C802 and R810 define the frequency of the

oscillator.

Power switch circuit

This circuit comprises MOSFET Q825, Rsense R826, R827 and
R828, R825, C827, L825, R812 and R813. R825 is a

pull-down

resistor to remove static charges from the gate of the

MOSFET.

Regulation circuit

The regulation circuit comprises opto-coupler Q801 which
isolates the error signal from the control IC on the primary side
and a reference component D881. The TL431(D881) can be
represented by two components:
a very stable and accurate reference diode
a high gain amplifier

Figure 8-17 ‘TL 431’

TL431 will conduct from cathode to anode when the reference
is higher than the internal reference voltage of about 2.5V. If the
reference voltage is lower, the cathode current is almost zero.
The cathode current flows through the LED of the opto-coupler.
The collector current of the opto-coupler flows through R806,
producing an error voltage, connected to voltage feedback pin
14 of Q810.

Demagnetisation

The auxiliary winding (7-9) voltage is used to detect magnetic
saturation of the transformer core and connected via R801 to
pin 8 of Q810. During the demagnetisation phase, the output
will be disabled.

Overvoltage protection circuit

This circuit consist of D814, C814, R814, R815 and R816.
When the regulation circuit is interrupted due to an error in the
control loop, the regulated output voltage will increase
(overvoltage). This overvoltage is sensed at the auxiliary
winding 7-9.
When an overvoltage longer than 2.0 (s is detected, the output
is disabled until VCC is removed and then re-applied. The
power supply will come in a hiccup mode as long as the error
in the control loop is present.

Secondary rectifier/smoothing circuit

There are 5 rectifier/smoothing circuits on the secondary side.
Each voltage depends on the number of windings of the
transformer.
The -8V supply is regulated by voltage regulator Q871.

On/off circuit

A

2.5V

R

K

CL 96532076_036.eps

290799

1-25

8.2.2 Troubleshooting P816

Figure 8-18

8.3 CD Main Board

The CD main board is built around the compact disc
mechanism VAM1250 and a loader 1250. The CDM delivers
diode signals and a n unequalised high frequency signal. These
signals are necessary inputs for the decoder CD10. Based on
these signals the decoder will control the disc. The decoder is
able to control the sledge, focus motor, radial motor and turn
table. When everything is "locked", the decoder delivers a
digital output according to IEC958 standard, subcode to the
microprocessor and I2S for reproducing analog audio signals
by means of a D/A converter.

The microprocessor controls the CD10 and is slave of the
master processor on the CDR main board in the CDR500. Both
processors communicate via a DSA connection (data, strobe
and acknowledge).

YES

OK

Connect the mains inlet to a mains

isolated variac

Check the functionality of the following components :

F820, R819, C820, L820, D802, C821

Check Vcc on pin 1 Q810

Vcc = 12V...... 16V

Is power supply ticking?

Check start circuit and Vcc supply:
R823, R834, C829, D829, R829, R811, C811
Replace Q810

Power supply OK

Power supply unit OK

OK

OK

OK

OK

OK

Check the path of the other faulty voltage(s)

Power supply is OK
Check : - CDR main board

- Display assy

- CD main board

Check DC voltages

+5V, +12V, -8V, VFTD (-34V),VDC1-VDC2 (4V1)

Check the +5V and +12V

Disconnect power supply unit from CDR main board

Connect dummy load resistors 10W,

15 ohm at +5V, +12V and ground

Check DC voltages

These voltages might be somewhat higher than specified

+5V, +12V, -8V, VFTD, VDC1-VDC2

OK

+5V : check D856, C857, L856, C859
+12V : check D866, C867, L867, R866, D868, C869

±1.41 x Vin AC

Turn input voltage up and check voltage across C821,
this voltage should be

OK

OK

Check fuse F820 and

replace if necessary

OK

NO

Load on secondary output
Overvoltage protection : L832, D814, C814, R814, R815, R816
Oscillator voltage on pin 10 of Q810 :
check C802, R810 replace Q810
Drive circuit : gate voltage of MOSFET Q825
components R812, R813, C813, R825
Regulation circuit

- Measure voltage on pin 6 of Q810 with oscilloscope

- If > 2.5V check the regulation circuit : Q810, D881
R881- R885, C881, C882, R804 - R806, R809, C804, C809

Check :

OK

1-26

Figure 8-19

8.3.1 Supply Voltages

Description

The CD main board receives +5V and +12V from the CDR main
board via respectively pin 16 and pin 15 of connector 1208. The
+5V is split up into +5VHF and +5V. The +5VHF is used mainly
for the diode currents and the HF-amplifier. The +5V is used for
the digital part of the board. On the board a +3V3 is made from
the +5V for the decoder CD10 and an A3V3 for the DAC
UDA1320. The +12V is split up into A12V for the audio output
stage and +12V for the power drivers of the CDM.

Measurements

Connect following supplies to next pins :

+5V + 5% to pin 16 of connector 1208.
+12V + 5% to pin 15 of connector 1208.
Ground reference to pin 17 of connector 1208.

Keep microprocessor 7202 in reset by forcing pin 7 of
connector 1208 to +5V. Check the following voltages :

Figure 8-20

8.3.2 Clock Signals

Description

The microprocessor has its own Xtal or resonator of 12MHz.
The CD10 needs a clock of 8.4672MHz + 100ppm. This speed
also relates to the disc speed. To avoid locking problems
between the two drives in the CDR500, both drives run on the
same clock. Therefore the CD main board gets the clock for the
decoder from the CDR main board via pin 2 of connector 1208.
The DAC needs a system clock to drive its internal digital filters
and to clock the I2S signals from the decoder. In our case this
is 11.2896MHz (CL11) generated by the CD10.

Measurements

Connect the power supply as described above in "1.1.1.

Supply Voltages".

Connect on pin 2 of position 1208 a clock signal of 8.4672

MHz ( 100ppm minimum rise time of 50ns and at TTL level
(0V and +5V).

Keep microprocessor 7202 in reset by forcing pin 7 at

position 1208 to +5V.

Release the reset. Now, the processor will reset the CD10

for at least 75

The output clock CL11 should be available now at pin 42 of

the CD10.

Check the following frequencies :

Figure 8-21

8.3.3 CD10 Decoder/Servo SAA7324 (7000)

Description

The CD10 is a single chip combining the functions of a CD
decoder, digital servo and bitstream DAC. The decoder/servo
part is based on the CD7. The decoding part supports a full
audio specification and can operate at single speed (n=1) and
double speed (n=2).

Block Diagram

Figure 8-22

Diode sign als

Radial, focus

Motor, sledge

ANA OUT

IIS, DOBM

Trig enta

HF amp.

CD10
SERVO
DECODER

UDA1320
DAC

PROCESSOR

DSA

CDM VA M1250

Loader assy

CL96532086_048.eps

080999

Point Voltage

Position 1000 pins 1,3

+5V

±

5%

Position 7000 pins 5,17,21,57

+3.

3V± 5%

Position 7005 pin 14

+5V

±

5%

Position 7020 pins 25

+5V

±

5%

Position 7020 pins 26,27,28

+10

±

10%

Position 7021 pin 5

+12V

±

10

Position 7022 pin 5

+12V

±

10

Position 7025 pin 16

+5V

±

5%

Position 7202 pin 38

+5V

±

5% ( other appl. 3V3 possible)

Position 7309 pins 4,13

+3V

3 ± 5%

Position 7120 pin 8

+12V

±

10

CL96532086_049.eps

080999

Point Frequency

Position 7000 pin 16

8.4672 MHz

±

100ppm

Position 7202 pins 14,15

12MHz

±

5%

Position 7309 pin 6

11.2896 MHz

±

100ppm

Position 7309 pin 1

2.1168 MHz

±

100ppm

Position 7309 pin2

44.1kHz

±

100ppm

CL96532086_050.eps

080999

23

19

18

21

20

EFM

DEMODULATOR

MICROCONTROLLER

INTERFACE

CONTROL

PART

V

ref

GENERATOR

V

RIN

ADC

PRE-

PROCESSING

CONTROL

FUNCTION

OUTPUT
STAGES

R1

R2

12

D1 D2 D3 D4

SCL

SDA

FRONT

END

HFIN

HFREF

ISLICE

I

ref

13

7

40

39

2

1

3

6

TEST

TEST1

25

TEST2

31

TEST3

44

TIMING

SELPLL

24

CRIN

16

CROUT

15

CL16

26

CL11/4

49

8910

V

SSA1

V

SSA2

V

DDA1

V

DDA2

V

SSD1VSSD3

V

SSD2

V

DDD1(P)VDDD2(C)

4 14 5 17 33 50 58 52 57

RA

FO

SL

54

55

56

LDON

64

DIGITAL

PLL

SRAM

RAM

ADDRESSER

SUBCODE

PROCESSOR

SBSY

48

SFSY

47

SUB

46

RCK

45

STATUS

43

DECODER

MICRO-

CONTROLLER

INTERFACE

RESET

38

VERSATILE PINS

INTERFACE

KILL

BITSTREAM

DAC

RP

RN

22

LP

LN

V

pos

V

neg

36

SDI

35

WCLI

37

SCLI

SERIAL

DATA

(LOOPBACK)

INTERFACE

30

EF

27

DATA

28

WCLK

29

SCLK

SERIAL

DATA

INTERFACE

PEAK

DETECT

EBU

INTERFACE

AUDIO

PROCESSOR

ERROR

CORRECTOR

FLAGS

MOTOR

CONTROL

51

DOBM

53

CFLG

MOTO1

59

MOTO2

60

V1

V2/V3V4 V5 KILL

63 34 61 62 32

SILD

42

RAB

41

11

CL96532086_051.eps

080999

µs.

1-27

Pin Configuration

Figure 8-23

8.3.4 TDA7073A Power Drivers (7021, 7022)

Description

The TDA7073A is a dual power driver circuit for servo systems
with a single supply. In this configuration it is used to drive the
sledge, tray, focus and radial.

Measurements

Keep microprocessor 7202 in reset by forcing pin 7 of
connector 1208 to +5V. Connect the power supply as
described above in "1.1.1. Supply Voltages". Check the
following voltages :

Figure 8-24

Figure 8-25

8.3.5 BA6856FP Turn Table Motor Driver (7020)

Description

This component is a 3 phase, full wave pseudo linear driving
system with inbuilt Hall Bias circuit and 3 phase parallel output.

Measurements

Keep processor 7202 in reset by forcing pin 7 of connector
1208 to +5V. The outputs 9, 10, 11 of connector 1006 are 0V.
Pin 21 of the motor driver 7020 is 2.5V

± 10%.

Pin 22 of the motor driver 7020 is 2.5V

± 10%.

Pin 23 of the motor driver 7020 is 0V.
Pin 19 of the motor driver 7020 is 5V

± 10%.

Put the processor out of reset to continue the measurement.
Check MOT1 at pin 59 of CD10. The duty cycle of the output
should be 50%. Check wave form at pin 11 of 7005-D :
amplitude 5V + 5% duty cycle 50%.
The motor driver 7020 can be measured dynamically by
connecting a hall motor to the application panel. Apply a pulse
of 1V 10Hz and 15% duty cycle to pin 22 (Ec) as input value
with reference to pin 21 (Ecr=2.5V). Measure the output signals
on the driver. This will give as response a square wave on pin
17 and pin 18. When a positive voltage is applied, the square
wave on pin 17 will go ahead of the square wave on pin 18.
All signals will have a value as shown in the truth table. Check
the following output signals :

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

171819202122232425262728293031

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

514950

52

53

54

55

56

57

58

59

60

61

62

63

64

HFREF

HFIN

ISLICE

V

SSA1

V

DDA1

I

ref

V

RIN

D1

D2

D3

D4

R1

R2

V

SSA2

CROUT

CRIN

VDDA2

LN

LP

V

neg

V

pos

RN

RP

SELPLL

TEST1

CL16

RA

FO

SL

DOBM

SAA7324

V

SSD3

MOTO1

SFSY

SBSY

RCK

SUB

V

SSD1

V5

V4

V2/V3

KILL

EF

DATA

WCLK

V

DDD1(P)

SCLK

TEST3

CL11/4

RAB

SCLI

TEST2

SDI

WCLI

V

SSD2

SILD

MOTO2

STATUS

V

DDD2(C)

CFLG

V1

RESET

LDON

SDA

SCL

CL96532086_052.eps

080999

Pin Location Value

5 7021

12V

±

10%

5 7022

12V

±

10%

1 7022

1.65V

±

10%

2 7022

1.65V

±

10%

6 7022

1.65V

±

10%

7 7022

1.65V

±

10%

1 7021

5.0

±

10%

2 7021

5.0

±

10%

6 7021

1.65V

±

10%

7 7021

1.65V

±

10%

CL96532086_053.eps

080999

Pin Location Value DC

9 7022 FOC

5.8V

±

10%
12 7022 FOC 5.8V
13 7022 RAD 5.8V
16 7022 RAD 5.8V

9 7021 SLE 5.8V
12 7021 SLE 5.8V
13 7021 TRAY- 5.8V
16 7021 TRAY+ 5.8V

CL96532086_054.eps

080999

1-28

Motor controller truth table

Figure 8-26

Hall-elements input signal voltage
levels

Figure 8-27

8.3.6 Tray Control

Description

The tray control consists of a TDA7073A power driver (7021)
controlled by the processor 7202 via pin 19 TRAYIN and pin 20
TRAYOUT. If pin 20 is low and pin 19 high, the TRAY+ signal
at pin 16 of 7021 is forced to +8V and the TRAY- signal at pin
13 of 7021 to GND : the tray will open. If pin 20 is high and pin
19 low, TRAY+ becomes GND and TRAY- becomes +8V : the
tray will close. If pin 19 and 20 of the processor have the same
value, TRAY+ and TRAY- will have the same value as well : the
tray stops moving.

Measurements

Keep procesor 7202 in reset by forcing pin 7 of connector 1208
to +5V. Connect a load of 15Ω, 7W between pin 3 and 4 of
connector 1002. Check the voltage over the load with TRAY+
(pin 3) as positive reference. Check also the levels of pins 19
and 20 of the processor.
U TRAY+,TRAY- = <100mV
Pin 20 = +5V
Pin 19 = +5V
Force pin 20 of the processor to ground, and check the
voltages.
U TRAY+,TRAY- = -6.5V

± 10%

Pin 20 = +0V
Pin 19 = +5V
Force pin 19 of the processor to ground as well and check the
levels again.
U TRAY+,TRAY- = <100mV
Pin 20 = +0V
Pin 19 = +0V
Release pin 20 of the processor and check the levels.
U TRAY+,TRAY- = 6.5V

± 10%

Pin 20 = +5V
Pin 19 = +0V
Release pin 19 of the processor and check the levels again:
U TRAY+,TRAY- = <100mV
Pin 20 = +5V
Pin 19 = +5V

Input conditions conn 1006 pin Outputs conn 1006 Test points on driver

684 732 9 10 11 18 17 16

U+ U- V+ V- W+ W- UCOIL VCOIL WCOIL HALL_U HALL_V HALL_W

L M H M M M 6V 0V 0V 0V 5V
H M L M M M 0V 6V 6V 5V 0V
M M L M H M 0V 6V 0V 0V 5V
M M H M L M 6V 0V 6V 5V 0V
H M M M L M 0V 0V 6V 5V 0V
L M M M H M 6V 6V 0V 0V 5V

CL96532086_055.eps

080999

Input voltage Level Tolerance Unit

H2.80.1V

M2.50.1V

L2.20.1V

CL96532086_056.eps

080999

1-29

8.3.7 HF Path

Description

The pre-amplified HF-signal is presented to both n=1 and n=2
amplifier circuits. The mux/demux switches via software and
micro processor controlled S1 and S2 lines between either one
of the amplified n=1 or n=2 signals. The signal will then follow

another amplification and filtering circuit. The filtering again is
controlled by the S1 and S2 lines, dependant on whether the
disc starts up (speed n=1, S1 and S2 Low), disc plays at speed
n=1 (S1 Low, S2 High) or disc plays at speed n=2 (S1 and S2
High).

Figure 8-28

DC Settings

Set the power and reset connections as described above in
"1.1.1. Supply Voltages". Check the following voltages :

Figure 8-29

3

2

1

0

G4

3

0

1

0

4x

END

FRONT

F310

F309

F313

F157

F156

390p

F159

HFGND

2141

2n2

+5VHF

+5VHF

+5VHF

+5VHF

HFGND

2130

100n

HFGND

HFGND

680p

2149

22n

2138

2137

HFGND

22n

3173

430R

HFGND

47u

2161

HFGND

22n

2160

330p

2143

HFGND

22K

3181

HFGND

47n

2150

HFGND

2142

22n

2146

14

15

11

13

1

5

2

4

3

6

8

GND

10

9

VCC

16

VEE

7

1n5

74HCT4052D

7025

12

100p

2162

7009
BFS20

3192

430R

7010

HFGND

HFGND

BC848B

3205

7007

BC858B

2K7

3169

10K

HFGND

2K7

3180

7023
BFS20

1K

3178

3196

3189

390R

2145

1K

VSSA14

47p

5

VDDA1

2 HFIN

1 HFREF

3 ISLICE

SAA7324

7000

2K7

HFGND

3174

430R

3188

180p

2164

HFGND

2K7

3203

HFGND

180p

2140

3191

430R

180R

3193

S1

S2

2

9

3

n=1 AMP

n=2 AMP

HF

HF

DUAL 4 CHANNEL
MUX/DEMUX

HFIN

HF

HF

E AMP

CL96532086_057.eps

080999

Force Pin Location Measure

Emitter 7006 2.4 ± 10%
S1 and S2 “HIGH” Collector 7010 1.9 ± 10%
S1 and S2 “LOW” Collector 7010 1.9 ± 10%
S1 and S2 “HIGH” 13 7025 1.6 ± 10%
S1 and S2 “LOW” 13 7025 1.6 ± 10%
S1 and S2 “HIGH” 3 7025 3.2 ± 10%
S1 and S2 “LOW” 3 7025 3.2 ± 10%

CL96532086_058.eps

080999

n-dependant filtering

1-30

Transfer Characteristics

Set the power and reset connections as described above in
"1.1.1. Supply Voltages". Connect a function generator via a
serial resistor of 1k5 to pin 4 of connector 1000. Use the

function generator as a sine wave generator with output level
of 1Vtt. Check this AC value with an AC mV-meter connected
to the input (pin 2) of the CD10 (7000) :

Figure 8-30

HFDET Setting

Set the power and reset connections as described above in
"1.1.1. Supply Voltages". Connect a function generator via a
serial resistor of 1k5 to pin 4 of connector 1000. Use the

function generator as a sine wave generator with output level
of 500 kHz, 1Vtt. Check this AC value with an AC mV-meter :

Figure 8-31

8.3.8 Audio Part - DAC

Description

The DAC used, is the UDA1320 bit stream, continuous
calibration. I2S signals from various formats can be entered at
pins 1,2 and 3. If these signals are in phase with the delivered
system clock at pin 6, the DAC will reproduce analog output
signals at pins 14 and 16. 0dB level is 0.85Vrms. These analog
signals are at 1.65Vdc level.
The DAC has features which can be checked on the input pins.
Mute will switch off the analog signals. De-emphasis is not
used, since this is done in the decoder. Attenuation of -12dB is
not used because this is also done in the decoder.

I2S

I2S is a kind of digital audio format, consisting out of 3 lines :
CLOCK, WORDSELECT and DATA.

WORD-SELECT

Word select (WS) indicates whether the data-sample is from
the left or the right audio-channel. It has the same frequency as
the sample rate of the digital audio signal. This can be 32, 44.1
or 48kHz. Normal polarity is low for a left sample and high for a
right sample. So within the low state of the WS-line the data bits
for the left channel are transferred, and within the high state the
data bits of the right channel are transferred.

CLOCK

The CLOCK signal (CLK) indicates when DataTips must be
set, and when DataTips must be read. The frequency depends
on the speed of the I2S-bus, but is always a factor of the

frequency of the WS-signal. It can be 48x, 64x, 96, 128x... .In

our case it is 48x the sample rate frequency = 2.1168MHz. The

signal is in phase with the WS-signal. Transition of the WS
always happens on a falling edge of the CLK.

DATA

DATA contains all data-bits. Data bits are set by the
transmitting device, and read by the receiving device. The
position of the DATA-bits within the WS-signal is very
important. There are several formats for this. In our case we
always use Philips I2S format, no Japanese or Sony format.
The number of data-bits per channel depends on the used
devices.

Timing of the I2S-bus, in case of Philips I2S is shown in the
next figure :

Figure 8-32

S1 and S2 “low” S1 and S2 “high”Frequencies

Input V

AC

Pin 2 at 7000 Input V

AC

Pin 2 at 7000

300 Hz 200mV < 100mV ± 20% 200mV < 100mV ± 20%

10 kHz 200mV 295mV ± 20% 200mV 330mV ± 20%
100 kHz 200mV 310 mV ± 20% 200mV 330 mV ± 20%
300 kHz 200mV 385 mV ± 20% 200mV 335 mV ± 20%
800 kHz 200mV 655 mV ± 20% 200mV 485 mV ± 20%

1.5 MHz 200mV 1.1V ± 20% 200mV 760 mV ± 20%

3MHz 200mV 1.1V ± 20% 200mV 1.1V ± 20%

CL96532086_059.eps

080999

Location Voltage DC Voltage AC

No HF HF

F190 4.8V± 20% 4.8V± 20% 175mV± 20%
F192 < 100mV 1.1V± 20% ­F206 4.9V± 20% 150mV± 20% -

CL96532086_060.eps

080999

MSBMSB

LEFT SAMPLE RIGHT SAMPLE

WS

CLK

DATA

CL96532086_061.eps

080999

1-31

Measurements

Figure 8-33

Keep processor 7202 in reset by forcing pin 7 of connector
1208 to +5V. This puts the processor outputs in tristate. Check
the reset at pin 4 of processor 7202 to make sure that the
processor is in reset.
Now, force port 0-4 pin 33 at 7202 to 0V to set the decoder
outputs (SCLK, WCLK, DATA, and CL11).
Check the MUTE pin 11 at 7309 : this pin should be low.
Connect via an I2S generator I2S-signals to the DAC :
Pin 1 at 7309: SLCK.
Pin 2 at 7309: WCLK.
Pin 3 at 7309: DATA.
Connect also the SYSCLK pin 6 at position 7309 to a clock
signal of 11.2896 MHz

±

100ppm.
Generate an I2S signal equivalent with a sine wave of 1kHz at
0dB for both left and right channels.
Check if 0.8 VRMS at pins 14 and 16 at location 7209 with a
DC of 1.65VDC.
Check if 1.7 VRMS

±

2 dB at connector pins 1and 3 at location

1209.
Force MUTE Pin 11 at 7309 high.
Measure again at pins 1 and 3 at location 1209 : both signals
should be at -90 dB.

DAC AMPLIFIER

IIS

CLK11

NMUTE

22

25

1200 - 17

1200 - 19

CL96532086_062.eps

080999

1-32

Note

1-33 1-34

CDR500 connection diagram

2P

LOADER PCB(CDR)

FTD

LOADER PCB(CD)

INT/EXT (RC-5)

RC-5 IN/OUT

OPT IN

COAX OUT CD

ANA INPT SEL

COAX/XLR

COAX IN

ANA OUT CD

COAX OUT CDR/CD

THROUGH OUT

ANA IN

MAINS

H.P. OUT

A : FFC1.0mm
1 GROUND
2 EXT_OPT_IN
3 GROUND
4 EXT_DIG_IN
5 DIG_OUT_C
6 GROUND
7 D5V
8 KILL
9 LEFT_IN
10 GROUND
11 RIGHT_IN
12 RIGHT_OUT
13 GROUND
14 LEFT_OUT

B: EH-EH 2.5mm
1 VDC2
2 VFTD
3 VDC1
4 GROUND
5 +5V
6 +5V
7 GROUND
8 GROUND
9 GROUND
10 +12V
11 -8V

C: PH-PH 2.0mm
1 VDC2
2 VFTD
3 VDC1
4 SYS_RESET
5 IIC_DATA
6 GROUND
7 IIC_CLK
8 DISPL_INT
9 GROUND
10 D5V

D: PH-Bord in 2.0mm
1 LEFT_HP_OUT
2 GROUND
3 RIGHT_HP_OUT

E: FCC 1.25mm
1 LEFT_CD
2 GND
3 RIGHT_CD
4 GND
5 DOBM_CD
6 GROUND
7 KILL

F: FCC 1.0mm
1 GROUND
2 DSA_DATA_CD
3 GROUND
4 DSA_ACK_CD
5 DSA_STR_CD
6 GROUND
7 D5V
8 12V_CD
9 GROUND
10 IIS_WS_CD
11 IIS_BCLK_CD
12 GROUND
13 IIS_DATA_CD
14 GROUND
15 DOBM_CD
16 RESET_CD
17 LEFT_IN_CD
18 GROUND
19 RIGHT_IN_CD
20 KILL
21 SYS_CLK_8W
22 GROUND

A

B

C

D

E

F

POWER

SW

ANA XLR

IN Lch

ANA XLR

IN Rch

2P 1PH2P2P 1P

IR SENSER

I

I: PH-Bord in 2.0mm

1 IR
2 GND
3 +5V

G: PH-PH 2.0mm
1 RC_5_OUT
2 RC_5_IN
3 GND

J

J: PH-Bord in 2.0mm

1 XLR_L_HOT
2 GND
3 XLR_L_COLD
4 XLR_R_HOT
5 GND
6 XLR_R_COLD

2P

ANA OUT CDR/CD

1410 1400 F934 1500 1708

1208 1209

Cooling

FAN

WY04

PY36

JY03

JY01 JY02

PY16

W902 W903

P916

P816

J851

J852

JF52 JC01

J601

W711

J682

J904

G

H: PH-Bord in 2.0mm

1 MUTE
2 -8VA
3 GND
4 GND
5 +8VA

J711

: CONNECTOR

: BORD IN WIRE

JT21

JT22

WT22

W855

: from LOADER ASSY

K

only F

version

OPTICAL

OUT CDR/CD

(only F version)

OPTICAL
OUT CD

(only F version)

1

1

1

1

11 1

1

1

11

1

1

11

11

K: PH-Bord in 2.0mm
1 CD_OPTOUT
2 CD_CDR_OPTOUT
3 GND
4 +5V

PP16

PP26

DISPLAY

HEADPHONE

SWITCHING

POWER
SUPPLY

TERMINAL

1.9 WIRING DIAGRAM

1-35 1-36

OPT DIG. IN

CDU4009 DASP

4M

FlashROM

16M

EDORAM

MACE2

CDR60

CPU

(DISPLAY DRIVER)

Driver

ROM

CINCH DIG. IN

CINCH DIG. OUT(CDR)

CODEC

CINCH ANA. OUT(CDR)

RC5 IN

RC5 OUT

KEY

H.P. OUT

AEGER

2

IIS

DSA

EEPROM

Subcode

L3 BUS

IIS

SWITCHING

POWER SUPPLY

+12.0VA

-12.0V

-8.0VA

+5VD-25.0V
DC1
DC2

MAINS

DISPLAY PCB

SUPPLY

PCB

CD LOADER PCBCDR LOADER PCB

MUTE

DIG.

POT.

IIC

HEAD PHONE PCB

CINCH DIG. OUT(CD)

CPU

CD Driver

CD DECODER

DAC

DSA

IIS

DOBM

CINCH ANA. OUT(CD)

CONNECTOR PCB

IR sensor

INT/EXT (RC5 )

SW

CINCH ANA. IN

XLR ANA. IN

XLR/CINCH

INPUT SENS.VOL.

0dBu ~ +22dBu

OPT DIG. OUT(CD)

OPT DIG. OUT(CDR)

BLOCK DIAGRAM of CDR500

1.10 BLOCK DIAGRAM

1-37 1-38

80

1 24

25

40

4164

65

R651

R652 R654

R655

R656

L651

L652

C652

RN52

RN53

RN54

J311

Q311

J681

L681

L682

JF51

DF51

SY01 SY02 SY03

SY04 SY05

SY06

SY07 SY08 SY09 SY10 SY12

SY13 SY15 SY16 SY17

SY18

SY19 SY20 SY21SY22 SY23

RY04

RY06

DY01

CY03

CY04

CY05

RY10

RY11

CY06

ZY01

CY08

SY26

XY01

QY01

RY13RY12

C651

C681

C682

R683

R684

SF51

J682

J301

C315

LT03

JT51

LT53

LT13

Q312

R315

L701

L702

R701

R702

Q702

S752

L901

L902

R920

R905

R906

R909

R910

L903

J901

C901

C903

C904

C905

C906

R312

R313

R778

R775

R777

R776

R788

R786

R787

R789

R792

R790

R791

R793

R747

R749

R794

R748

R750

R796

R754

R752

R753

R751

R755

R756

R757

R758

R703

R705

R706

R704

R653

RN51

R685

R686

R681

R682

RN81

RN83

RN84

C909 C910

C902

RF51

RF57

R301

C314

C331

R311

CT03

CT02

RT02

RT03

CT05

RT13

CT15

CT14 RT12

CT13

CT12

C763

C761

C771

R763

C773

R761

C769

L769

L770

C774

R762

C770

C762

C764

JT21

JT61

C781

C783

C793

C791

C786

C785

C787

C788

C795

C796

R710

R709

R711

R712

R713

R714

C797

C798

C745

C746

R779

R780

C703 C704

C701

C702

CT31

CT32

CT33

RT31

RT32

RT34

RT35

QF51

QF52

J904

CT53

RT52

CT52

CT60

CT04

CT01

CT11

Q901-1

Q901-2

RT57

C772

C792

C794

J762

J761

JY03

RN82

RY21 RY22 RY23 RY24 RY25

RY26

DY04

RY14

RY01 RY02 RY03

RY31

RY32

RY33

RY34

RY35

RY15

RY16

RY17

W711

J711

JT22

CM01 CM03

CM02

CM04

CC01

CC02

JC01

C908 C907

W902

QN01

QN02

RN01

RN02

W904

J701

J651

R795

C747

C748

CY07

L772

L771

CT21

CT61

C777

C780

R785

C782

C784

J601

C301

RY09

CY10 CY09

RY44

QY42

QY43

QY41

DY41

DY42

R715

R716

JF52

QC01

QM01

QM02

DM01 DM02

JT01

JT01

C749

C750

C741

C707

C708

C779

C778

R764

CT55

CT54

LF51

CF52

CY41

QY44

CY14

LY01

CY13

QY04QY03QY02

QN83

QN51

QN52

QN53

QN54

QN81

QN82

QN84

RT36

RT33

WT22

W855

WY04

JY01

JY02

R781

R783

R782

R784

Q761-1

Q761-2

Q762-1

Q762-2

Q763-1

Q764-1

Q763-2

Q764-2

Q766-1

Q765-1

Q765-2

Q766-2

R907

R911

R912 R908

R903

R904

C671 C672

W903

RY41

WY06

CY11

C691 C692

100

100 100

100k

100k

100p

CH

2.2K

2.2K

2.2K

74HCU04

*

100

470

*

0.022
22P

22P

100

4.7K

0.1

0.1

5V

TMP87CH74F

5V

10K10K

100p

CH

100p

CH

100p

CH

100

100

0.1

74HCU04

100

100k

100k

LC4966

10k

10k

150

150

100/16V

100/16V

100/16V

100/16V

100/16V

6.8k

2.2k

33k

33k

33k

33k

100k

100k

100k

1k

1k

1k

1k

10k

10k

4.7k

10k

10k

4.7k

10k

10k

10k

10k

10k

10k

10k

10k

10k

1k

1k

1k

1k

100

2.2K

100k

100k

100

100

2.2K

2.2K

2.2K

0.1 2200p

100/16V

100

10K

100

47p

SL

0.1

75

47p

0.1

75

22

100p

22

100p

10/63V 75

47p

0.1

47p

47p

47p 100k

100p

100k

47p

100p

100k

47p

47p

47p

10p/50V

10p/50V

47/16V

47/16V

10p/50V

10p/50V

10p/50V

10p/50V

47/16V

47/16V

47k

47k

1k

1k

1k

1k

47/16V

47/16V

47/16V

47/16V

50k

50k

100p 100p

47/16V

47/16V

0.1

0.1

0.1

1K

100K

1K

100K

DTA114ES

/ETC

DTC114ES

/ETC

47p

75

10/63V

100p

10/63V

2200p

2200p

NJM4556

22

47p

47/16V

47/16V

2.2K

6.8K 6.8K 6.8K 6.8K 6.8K

6.8K

VFTDVFTD

VFTD

3.3V

3.3K

VFTDVDC1

VDC2

VFTD

VFTD

VFTD

VFTD

VFTD

VFTD

47K 47K 47K

68K

68K

68K

68K

68K

47K

47K

47K

0.1 0.1

47/16V

+8VA

47/16V

-8VA

0.1
47/16V

100p 100p

2SC2878

A/B

2SC2878

A/B

2.2K

2.2K

10k

47/16V

47/16V

+5V

100/10V

100/10V

100/10V

220/16V

220/16V

100k

10p/50V

10p/50V

100/10V

100

100P 100P

+5VU+5VU

+5VU

+5VU

+5V

10K

DTC144ES

DTC144ES

DTC144ES

+5V

+5V

75

75

PQ09RF1

78L05

79L05

3V3 3V3

2/2

1/2

470p

470p

47/16V

470p

470p

220/16V

220/16V

100k

0.1

2200p

470P

47/25V

DTA144ES

5V

100/10V

22UH

0.1

2SC2458

1740,3119

2SC2458

1740,3119

2SC2458

1740,3119

2SC2878A

2SC2878A

2SC2878A

2SC2878A

2SC2878A

2SC2878A

2SC2878A

2SC2878A

FAN

100

(F)ONLY

100

(F)ONLY

G14

P12

STB_LED

STB_LED

P12

G14

BOARD_IN

BOARD_IN

BOARD_IN

1k

470

1k

470

NJM4558D

NJM4558D

NJM4558D

NJM4558D

NJM4558D

NJM4558D

NJM4558D

NJM4558D

NJM4558D

NJM4558D

NJM4558D

NJM4558D

22k

10k

10k 22k

15k

15k

0.1 2200p

BOARD_IN

100

0.1U

0.1 2200p

5V

5V

5V

5V

5V

-12V 12V5V

5V

5V

5V

5V

5V

5V

5V

5V

VFTD

VDC2

VDC1

VFTD

+12V

-12V

-12V

+12V

+8VA

+12V

FAN

-8VA

+8VA

-8VA

+8VA

-8VA

+8VA

+8VA

-8VA

+8VA

+8VA

-8VA

-8VA

-8VA

+8VA

-8VA

+8VA

+8VA -8VA

+8VA -8VA

G1G2G3G4G5G6G7G8G9

G10

G11

G12

P1

P2

P3

P4

P5

P6

P7

P8

P9

P10

P11

P12

P13

P14

P16

P17

P18

P19

P20

P1P2P3P4P5P8P9

P10

P11

P12

P13

P14

P16

P17

P18

P19

P20

P21

P6

P7

G1G2G3G4G5G6G7G8G9

G10

G11

G12

P22

P21

P22

234

5678

9

10

11 121314

15

16 17 181920 21

22 23

26

27

28

29

30

31

32

33

34

35

36

37

38

39

424344454647

4849505152

53

54

555657

585960

61

62

63

66
67
68
69
70
71
72
73
74
75
76
77
78
79

12345678910

REC

ERASE

MODE

CD

SELECT

CD

CDR

STOPCDCD PLAY

DELETE

MENU

CDR/CD
ANALOG

OUT

CDR/CD

COAX
OUT

OPT

IN

CD

ANALOG

OUT

CD

COAX

RC-5
IN/OUT

RESETN

INTERRUPT

INT/EXT

SW

EXT

RC-5

2

123

STANDBY

RC-5

LCH

LCH

RCH

RCH

1410

F934

1400

CDR CD

LCH
GND
RCH

REC STOP

CDR

SELECT

PLAY

BWD

FWD

LOOP

DOBM

KILL

GND

GND

GND

CD

LCHCD

RCH

POWER

GND

+12V

GND
+5V
GND

-12V

1

2

3

4

5

6

7

J851 J852

1500

1708

GND

COAX
INPUT

ANALOG

INPUT

LCH

RCH

BALANCE

UNBALANCE

HEADPHONE

P916

GND

IN

OPT

GND

IN

COAX

OUT

DIG

GND

5V

MUTE

CD/CDR_RCH

REC_IN_RCH

REC_IN_LCH

GND

GND

CD/CDR_LCH

CD/CDR

OUTPUT

CD

OUTPUT

CD_OPTOUT

CD_OPTOUT

PP16

PY16

12

6

7

89101112131415161718192021

22

2324252627282930313233343536

373839404142

VY01

5

434445464748

49

53

52

G13

G14

G15

CD_CDR_OPTOUT

PY26

1

1

1

6

6

4

1414

IR_SENS

INT

IR_SENS

IIC_DATA

IIC_CLK

13

PP26

1

5

10

14

1

14

INPUT

4

FAN

G13

G14

G15

4

GND

FAN

+9VFAN

FAN

MC01

OPTION

BALANCED

IN

R_CH

L_CH

(F)ONLY

MUTE

1

6

(F)ONLY

1

2

3

12

3

PUSH_ENTER

R_LEVEL/SELECT

1

OPTOUT

CD_CDR

FINAL

OPN/CLS

CANSL

STORE

OPN/CLS

CDRCDR

TEXT

TIME

PLAY

PROG

MODE

LCH_HOT
LCH_CLD

RCH_HOT
RCH_CLD

+8VA

-8VA

GND

OPTION

OPTION

OPTION

PP16

1209

1208

1.11 SCHEMATIC DIAGRAM AND PARTS LOCATION

1-39 1-40

R819

D802

R823

G815

R832

Q851

D856

C857

J881

Q871

D807

D806

Q801

Q892

D866

Q861

D868

Q810

C825

C826

C828

J801

U801

C821

C819

Q825

C827

L825

D803

D804

C803

C802

C810

R803
R805

R806

R804

C804

R802

R810

D829

C829

R829

R811

R801

R809
C809

R815

R814

R807

R813

R812

C813

R808

C814

D814

U803

U804

D832

R828

R826

R825

L832

C882

R883

R884

R885

C881

R887

C866

L861

D861

C861

C856

C862

R861

R862

D862

R865

R864

R863

C864

C852

C851

D851

R853
R852

R851

C854

R894

U814

U813

U817

R866

C877

Q862

C867

C891

R882R892

R893

C892

U808

C875

R891

D871

C871

U810

U811

U812

C898

J891

L854

J820J821

Q891

C833

C855

C860

C873

C869

J828

R881

D881

C872

R827

C820

L820

S815

R816

U806

U809

U815

U816

U818

U819

U820

L852

L862

L866

L867

L871

L873

L853

L851

L856

U807

D835

C811

C868

L872

R886

D836

J852J851

C801

C859

C876

R895

+

-

MC44603

P816

+

L831

020L

F802

S1WB

+

-

-12V

-8V

T2A L 250V

WG388K104-0

Q819

Q825

Q801

Q810

Q829

Q815

Q817 Q862 Q861

P816

ERROR
AMP

IREFSYNC

RF
STANDBY

RP
STANDBY

VOLTAGE

VREF

VSB
OUT

2.5V

FEEDBACK
E/A OUT

FOLDBACK

INPUT

FOLDBACK

=1

DMAX&
SOFT-START
CONTROL

SOFTSTART

&DMAXSENSEINPUT

CURRENT

OVER
VOLTAGE
MANAGEMENT

OVER
VOLTAGE
PROTECT

BUFFER

VREF VOCTHERMAL

SHUTDOWN

LATCH

Q

UVL01

IREF

SUUPLY

INITIZLIZATION BLOCK

REFERENCE
BLOCK

VREFIREF

(REDUCED FREQUENCY)

STANDBY

OSCILLATOR

DEMAGNETISATION
MANAGEMENT

DEMAGINETIZATION
DETECT

MC44603P

UVL01

L831

Q810

GND
+5V
+5V
GND
GND
GND
+12V

-8V

GND

GND

GND

+12V

+5V

1

2

3

4

6

11

75

13

14

12

15

10

9

8

16

U810

U811

SELECT
JUMPER

(-8V)

+12V

+12V

-12V

(-8V)

-12V

-12V/-8V

1

4

5

6

7

8

9

10

11

12

13

14

+4.1V

-34V

SWITCHING POWER SUPPLY PCB. (P816)

S1WB

4.7/50V

10k

22

100/25V

2SK2943

1k

1.5

10

µ

H

0.1

100

15

2200pF

180

0.1

2.2/50V

330

1500p

180k1k

15k 15k 4700pF

470p

22k

6.8

µ

H

1

µ

H

10k

2SC

2SA

1k

10k

10k

10k

10

µ

H

PC123F

LM317

1.5

0.1

250V

0.22
250V

18k

1/2W

1.8k

1.8k

330

/16V

100/6.3V

2200
/10V

10/50V

220/50V

1000
/16V

2.2

µ

H

1k

220

/16V 3.3k 100

1.8k

0.022

TL431100

7908

22k

22k

100/25

10k

PC123F

100/25

1k

AG01

RK46

AG01

RU4YX

AG01

10uH

0.1

2SC2878

820pF

82pF
NP0

82k

18k

AG01

AG01

24V

10uH

220

/16V

10k

0.1

10

220

560

0.1

4.7

µ

H

4.7

µ

H

220

/16V

100

/16V

100

/25V

120

/400V

18k
1/2W

0.01

0.1

470pF
/1kV

1

4.7k

330k

(UL/CSA,MITI)

1M(CB)

0.1

0.1

0.1

681

1%

2.21k
1%

10

µ

H

470pF
/400V

470pF
/400V

470pF
/400V

220/16V

100/10V

OPTION

OPTION

J820

J821

J801

L820

D802

C829

R829

R811

C833

D806

D807

Q825

L825

R825

R827

L832

C811

R812

R813

C813

R816

C814

C810

R809

C809

R807R806

R805 R804 C804

C803

R802

L856

L861

R861

Q861

Q862

R862

R863

R864

R865

L862

D868

Q801

L831

Q851

R828

J851

S815

F820

C819

C820

R823

R815

R814

C856

J852

C852

C854

C857

C862

C864

C867

C868

L867

R866

C872

R881 R882

R883

C882

D881R887

Q871

D862

J828

R891

R892

C891

R893

Q892

C892

R894

D803

D804

D851

D856

D861

D866

D871

L866

L871

L873

C877

Q891

C802

C801

R801

R808

D814

D832

D829

L872

C873

R810

C855

R853

R852

R851

C860

L851

L853

C869

C875

C881

C821

R832

G815

J891

C898

C827

R826

R803

R819

C851

C861

C871

C866

R885

R884

R886

L854

L852

C825

C826

C828

C876

C859

R835

D835

1-41 1-42

JT51

U671

U648

R311

U664
U688

QC01

JF52

JC01

WT22

Q312

W855

Q765

Q761

Q763

W711

J681

R780 R779

LT53

S752

J701

Q764

Q762

Q766

Q702

J651

J311

JT01 JF51

SF51

Q311

LT13 LT03

U682

U666

CT11

CT12

CT01

CT02

C314

R312

R313

C331

C682

C681

R686

R685

QN84

RN84

R684

R683

QN83

RN83

U615

RN81

QN81

R681

R682

QN82

RN82

U613 U610

U608

U604

U603

CM03

QM02

QM01

CM01

U611

U619

U618

U617

C788

R758

U616

R706

C708

R702

RT57

CT60

R704

RT52

CT53

CT55

CT54

U689

R776

R777

R775

U637

U638

U639

U640

U641

U642

C704 C703

C652 C651

R655

RN54

QN54

R654R652

RN52

QN52

R653

QN53

RN53

RN51

QN51

R651

U655

U656
U657

R656

U652

R785R787

R789

R747

U651

R791
R749

U653

R710

C783

R795

R793

C781

R751

C785

R755

R753

U643

R703

R701
C707
R705

R757

C787

U631

U630

U629

U628

R786R788

U627

R748

R790

C782

R794

R792

R750

C784

R796

R754

U622

R756

C786

R752

C746

R716

R714

C750

R712

U625

U624

U623

U632

U634

U635

U636

R709

U633

R715

R713
C749

R711

C747

U658

U659

U662

U672

U647

U646

U645

U679

U680

U675

U681

U673

RT33

RT32

RT31

CT31

CT33

CT32

RT35

RT34

U669
RT36

U670

RT03

CT15

RT13

RT12

CT13

RT02

CT03

U668

U667

R315

C315

R301

U684

RF51

QF51

U687

DF51

CF52

QF52

RF57

U692

U693

U694

U695

U696

U697

U698

U699

U700

J904

U677

U691

U614

U690

U612

C672

C671

R658

U649

C691

C692

R688

J301

C301

C701

C702

C741

C745

C777

C779

C778C780

C791C792

C793

C794

C795

C796

C797

C798

CC01

CC02

CM02CM04

CT04

CT05

CT14

CT52

DM01DM02

L651

L652

L681

L682

L701

L702

LF51

R778

R781R782 R783R784

U650

U654

PP16

WA388K101-0

J682

J601

+9VFAN

GND

+5V

GND

CD_CDR_OPT_OUT

CD_OPT_OUT

FAN

RC-5

GND

IR_SENS

GND

+12V

GND

+5V

GND

-12V

CD_CDR_LCH

GND

CD_CDR_RCH

REC_IN_RCH

GND

REC_IN_LCH

MUTE

+5V

GND

OPT_IN

COAX_IN

GND

DIG_OUT

GND

LCH_HOT

LCH_CLD

GND

GND

RCH_HOT

RCH_CLD

GND

MUTE

KILL

GND

CD_DOBM

GND

CD_LCH

CD_RCH

GND

GND

-8V

+8V

PP16

QN81 - QN84

QM01 - QM02

Q764

Q762
Q766

Q763

Q762

Q765

Q761

QN51 - QN54

Q311
Q312

QF51 QF52

JT61

C764

C762

C774

C769

R761

C761

C763

C773

R763

C771

U302

U303

U304

U306

U307

J761J762

JT31

J711

JT21

JT22

C770

C772

CT21CT61

L755

L769

L754

L770

R762

R772

WA388K102-0

PP26

CD_OPT_OUT

CD_CDR_OPT_OUT

GND

+5V

LCH_HOT

LCH_CLD

GND

GND

RCH_HOT

RCH_CLD

PP26

RY04

ZY01

WY04

CY07

WA388K105-0

PY26

+5V

GND

IR_SENS

PY26

U905

J901

R920

W902

Q901

C906

C901

C902

C903

C904

C909

R905

R903

C905

U903

R904

R906

R907

QN01

R909

RN01 RN02

QN02

R908

R910

U904

U902

C910

C908

C907

U907

U901

W903

R912

R911

L901

L902

L903

RCH

GND

LCH

GND

WA388K103-0

P916

W904

MUTE

GND

+8V

-8V

P916

Q901

QN01
QN01

SY06

SY07

SY08

SY05

SY22

SY23

SY12

SY17

SY13

SY10

SY18

SY21

SY16

SY04

SY09

SY15

XY01

RY35

RY34

RY33

RY32

RY31

RY14

RY17

RY16

RY15

CY08

CY03

CY10

CY09

CY06

RY11

RY26

RY25

RY24

RY23

RY22

RY21

RY13

RY12

DY04

CY04

CY05

RY10

RY09

DY01

WY06

SY26

RY02

QY02

QY03

QY04

RY01

RY03

LY01

CY13

CY14

RY06

QY41

DY42

DY41

QY43

QY42

RY41

CY41

RY44

QY44

WY02

WY01

CY11

WG388K201-0

PY16

QY01

JY03

VY01

ERASE

FINALIZE

MENU

CANCEL/DELETE

BWD

TIME

INPUT

REC TYPE

TEXT

FWD

PROGRAM

CDR OPEN/CLOSE

CD OPEN/CLOSE

CDR SELECT

CD SELECT

DJ MODE

PY16

QY04-QY02

QY01

QY42-QY44

1-43 1-44

023B

x4

125Bx2

127Bx2

5150

2. 6X8( M)

001B

003B

5128
3X8(M)

5128
3X8(M)

5127
3X8(M)

5127
3X8(M)

100B

101B

124Bx2

126Bx2

129Bx2

130Bx2

006B

024B

121Bx2

5128

2. 6X8( M)
x4

015B

030B

016B

018B

060B

110B

111B

120Bx2

005B

105Bx2

5128
3X8(M)

036G

007G

003G

011Gx4

094G

UONLY

5128
3X8(M)

5128
3X18(U)

5128
3X8(M)

001G

030Gx2

037G

5128
3X8(M)

021Gx4

038G

092G

NONLY

090G

NONLY

031Gx5

5405

4( R)

U, N ONL Y

039G

045G

092G

UONLY

I
N
V
I

S
I

B
L

E

L
A

S
E
R

R
A

D
I

A
T

I
O

N
W

H
E
N

O

P
E

N
.

A
V

O
I
D
D

I
R

E
C
T

E
X
P

O
S
U

R
E

T
O

B

E
A
M

.

009B

010B

011B

012B

013B

014B

019B

021B

5128
3X6(M)

070B

020G

MC0 1

5128
3X16(M)

5128
3X8(M)

5128
3X8(M)

5128
3X8(M)

VY01

PP26

P90 6

PY16

PY26

P81 6

5110
3X8(M)

020L

5110
3X6(M)

PP16

L831

5128
3X8(M)

050G

071Bx2

5128
3X10(M)

5127
3X8(M)

5127
3X8(M)

001D

5127
3X8(M)

003D

5128
3X10(M)

005D

T001

001N

5128
3X8(M)

W001

901G

5127
3X8(M)

NONLY

U, F ONLY

W001

5128
3X8(M)

015G

5127
3X8(M)

x12

001M

5110
3X8(M)

908G

015G

UL L ABEL

994G

NONLY

MAR K MA T E R I A L / F I N I S H

STEEL / COPPER
STEEL / BLACK

(M)
(U)

SYMBOL ST YLE

PARTS NAME

+B . H. M. S CREW

+B. H. T AP TI T E SCREW(B TYPE)

5110

5128

5127

+B. H. TAP TI TE SCREW(W/)

5405

TOOTHED LOCK WASHERS

( R) ST EEL/ UNI CHROMATE

+F. H. T AP TI T E SCREW(B T YPE)

5150

1.12 EXPLODED VIEW AND PARTS LIST

1-45

POS.

NO

VERS.

COLOR

PART NO.

(FOR PCS)

DESCRIPTION

PART NO.

(MJI)

POS.

NO

VERS.

COLOR

PART NO.

(FOR PCS)

DESCRIPTION

PART NO.

(MJI)

001B BLACK FRONT PANEL BLACK 388K248010
001B GRAY 9965 000 07543 FRONT PANEL GRY 388K248110
003B BLACK FRONT CHASSIS BLACK 388K105020
003B GRAY 9965 000 07544 FRONT CHASSIS GRY 388K105120
005B 9965 000 07548 WINDOW 388K158010
006B 9965 000 07407 IR LENS 387K355010
009B BLACK POWER BUTTON 371K270150
009B GRAY 9965 000 01609 POWER BUTTON 371K270160
010B 9965 000 07549 RUBBER BUTTON 3KEY 388K270010
011B 9965 000 07550 RUBBER BUTTON 2KEY 388K270110
012B BLACK BUTTON ERASE BL 388K270020
012B GRAY 9965 000 07551 BUTTON ERASE GRY 388K270120
013B BLACK BUTTON TIME BL 388K270220
013B GRAY 9965 000 07552 BUTTON TIME GRY 388K270320
014B BLACK BUTTON FINAL BL 388K270030
014B GRAY 9965 000 07553 BUTTON FINAL GRAY 388K270130
015B 9965 000 07554 BUTTON REC PLAY PAUSE 388K270350
016B 9965 000 07555 BUTTON PLAY PAUSE 388K270360
018B BLACK BUTTON OPEN CLOSE BL 388K270080
018B GRAY 9965 000 07556 BUTTON OPEN CLOSE GRAY 388K270180
019B BLACK BUTTON FF REW BL 388K270050
019B GRAY 9965 000 07557 BUTTON FF REW GRAY 388K270150
021B BRACKET FOR PHONE JACK 457T160010
023B BLACK 4822 411 20336 KNOB FOR PHONE VOLUME 284T154310
023B GRAY 9965 000 01611 KNOB FOR PHONE VOLUME 284T154050
024B BLACK KNOB FOR JOG 388K154010
024B GRAY 9965 000 07558 KNOB FOR JOG 388K154110
030B 9965 000 01393 LENS FOR STANDBY LED 312J355010
060B NUT FOR JOG 302C011030
070B FTD HOLDER 370K271110
071B ADHESIVE FOR FTD 056J122050
100B BLACK ESCUTCHEON CDR BL 388K063010
100B GRAY 9965 000 07417 ESCUTCHEON CDR GRY 388K063110
101B BLACK ESCUTCHEON CD BL 388K063020
101B GRAY 9965 000 07559 ESCUTCHEON CD GRY 388K063120
105B BLACK ARM

FOR ESCUTCHEON BLACK

388K002010

105B GRAY 9965 000 07418 ARM

FOR ESCUTCHEON GRAY

388K002110

110B 9965 000 07419 SPRING FOR ARM L 388K115010
111B 9965 000 07560 SPRING FOR ARM R 388K115020
120B HOLDER

ESCUTCHEON ARM R

387K271010

121B HOLDER

ESCUTCHEON ARM L

387K271020

124B CONTROL BOARD TRAY LID

RELEASE PISTON LEFT

386K127010

125B CONTROL BOARD TRAY LID

RELEASE PISTON RIGHT

386K127020

126B LOCK TRAY LID LEFT 386K102010
127B LOCK TRAY LID RIGHT 386K102020
129B STOPPER TRAY LID LOCK

COVER LEFT

386K114010

130B STOPPER TRAY LID LOCK

COVER RIGHT

386K114020

001D BLACK LID TOP COVER BLACK 292J257050
001D GRAY LID TOP COVER GRY 292J257150
003D BLACK MOUNT BRACKET L 371K160040
003D GRAY 9965 000 07421 MOUNT BRACKET R 371K160060
005D BLACK MOUNT BRACKET R 371K160050
005D GRAY 9965 000 07422 MOUNT BRACKET R 371K160070

011G 4822 462 41771 LEG BLACK 229K057010
036G 9965 000 07424 LINK FOR POWER SWITCH 387K121010
037G 9965 000 07423 LINK FOR POWER BUTTON 387K121020
038G SHAFT FOR POWER BUTTON 387K112010

001M MECHANISM CD-R MODULE

MAR775 SPICE 2.08+

388K304500

001N MECHANISM CD MODULE

MAR1250 (V3.6)

388K304600

J001 F 9965 000 01313 JACK 2P AC INLET M1910-H YJ04002440
J001 N1,U1 9965 000 07428 JACK 3P AC INLET M1910-D YJ04002450

WW01 9965 000 06393 FFC P=1.25 7PIN-100MM YU07100530

WW02 9965 000 06394

FFC P=1.0 14PIN-300MM YU14300520

WW03 9965 000 06395

FFC P=1.0 22PIN-220MM YU22220520

PACKING

001T F USER MANUAL 388K851110
001T N1 9965 000 07561 USER MANUAL 388K851310
001T U1 USER MANUAL 388K851250
004T U1 FLY SHEET 388K851260
005T F FLY SHEET 386K851170
005T N1 FLY SHEET 386K851170

T001 9965 000 05922 REMOTE COTROLLER

RC6049DR

ZK386K0010

W001 F MAINS CORD 2P

FOR 12A 125V AC

ZC01801050

W001 N1 9965 000 07362 MAINS CORD 3P

FOR N 10A 250V AC

ZC02003190

W001 U1 MAINS CORD 3P

FOR U 10A 125V AC

ZC01802110

NOT STANDARD SPARE
PARTS

001S PACKING CASE 388K801010
003S CUSHION 371K809050
W011 U1 4822 321 21438 RCA STEREO CORD

1M WHIT RED

ZD01000330

W012 U1 4822 321 21438 RCA STEREO CORD

1M WHIT RED

ZD01000330

W013 U1 RCA COAX CORD M BLACK ZD01000520

1-46

1.13 ELECTRICAL PARTS LIST

The suppliers and their type numbers of fusible resistors
are as follows;

1. KOA Corporation
Part No. (MJI) Type No. (KOA) Description
NH05 × × × 140 RF25S × × × × ΩJ(±5% 1/4W)
NH05 × × × 120 RF50S × × × × ΩJ(±5% 1/2W)
NH85 × × × 110 RF73B2A × × × × ΩJ(±5% 1/10W)
NH95 × × × 140 RF73B2E × × × × ΩJ(±5% 1/4W)

2. Matsushita Electronic Components Co., Ltd
Part No. (MJI) Type No. (MEC) Description
NF05 × × × 140 ERD-2FCJ × × × (±5% 1/4W)
RF05 × × × 140
NF02 × × × 140

ERD-2FCG

× × × (±2% 1/4W)

RF02 × × × 140

Examples ;

Resistance value

0.1 Ω.... 001 10 Ω .... 100 1 kΩ ....102 100 kΩ .... 104

0.5 Ω.... 005 18 Ω .... 180 2.7 kΩ .... 272 680 kΩ.... 684

1 Ω.... 010 100 Ω .... 101 10 kΩ ....103 1 MΩ.... 105

6.8 Ω.... 068 390 Ω .... 391 22 kΩ .... 223 4.7 MΩ.... 475

ASSIGNMENT OF COMMON PARTS CODES.

RESISTORS

R : 1) GD05 × × × 140, Carbon film fixed resistor, ±5% 1/4W
R : 2) GD05 × × × 160, Carbon film fixed resistor, ±5% 1/6W

Examples ;

Resistance value

0.1 Ω.... 001 10 Ω .... 100 1 kΩ ....102 100 kΩ .... 104

0.5 Ω.... 005 18 Ω .... 180 2.7 kΩ .... 272 680 kΩ.... 684

1 Ω.... 010 100 Ω .... 101 10 kΩ ....103 1 MΩ.... 105

6.8 Ω.... 068 390 Ω .... 391 22 kΩ .... 223 4.7 MΩ.... 475

Note : Please distinguish 1/4W from 1/6W by the shape of parts

used actually.

CAPACITORS

C : CERAMIC CAP.

3) DD1 × × × × 370, Ceramic capacitor

Disc type
Temp.coeff.P350 N1000, 50V

Examples ;

Tolerance (Capacity deviation)

±0.25 pF .... 0

±0.5 pF .... 1

±5% .... 5

Tolerance of COMMON PARTS handled here are as follows :

0.5 pF 5 pF .... ±0.25 pF

6 pF 10 pF .... ±0.5 pF

12 pF 560 pF .... ±5%

Capacity value

0.5 pF ....005 3 pF .... 030 100 pF .... 101

1 pF .... 010 10 pF .... 100 220 pF .... 221

1.5 pF ....015 47 pF .... 470 560 pF .... 561

C : CERAMIC CAP.

4) DK16 × × × 300, High dielectric constant ceramic

capacitor
Disc type
Temp.chara. 2B4, 50V

Examples ;

Capacity value

100 pF .... 101 1000 pF .... 102 10000 pF .... 103

470 pF .... 471 2200 pF .... 222

C : 5) ELECTROLY CAP. ( ), 6) FILM CAP. ( )

5) EA

× × × × ×

×

10, Electrolytic capacitor

One-way lead type, Tolerance ±20%

Examples ;

Capacity value

0.1 µF.... 104 4.7 µF .... 475 100 µF ....107

0.33 µF.... 334 10 µF ....106 330 µF....337

1 µF....105 22 µF ....226 1100 µF ....118

2200 µF ....228

Working voltage

6.3V.... 006 25V .... 025

10V .... 010 35V .... 035

16V .... 016 50V .... 050

6) DF15 × × × 350 Plastic film capacitor
DF15 × × × 310 One-way type, Mylar ±5% 50V
DF16 × × × 310 Plastic film capacitor

One-way type, Mylar ±10% 50V

Examples ;

Capacity value

0.001 µF (1000 pF) ....... 102 0.1 µF .... 104

0.0018 µF ........................ 182 0.56 µF ....564

0.01 µF........................ 103 1 µF ....105

0.015 µF ........................ 153

: 1) The above CODES ( R , R , C , C and
C ) are omitted on the schematic diagram in some

case.

2) On the occasion, be confirmed the common parts on
the parts list.

3) Refer to “Common Parts List” for the other common
parts (RI05, DD4, DK4).

➀

➁

Capacity value
Tolerance

➃

Capacity value

Resistance value

➄

Working voltage
Capacity value

➆

Capacity value

NOTE

NOTE ON SAFETY FOR FUSIBLE RESISTOR :

Resistance value

Resistance value
(0.1 Ω − 10 kΩ)

Resistance value

Resistance value

ANT. : ANTENNA BATT. : BATTERY
CAP. : CAPACITOR CER. : CERAMIC
CONN. : CONNECTING DIG. : DIGITAL
HP : HEADPHONE MIC. : MICROPHONE
µ-PRO : MICROPROCESSOR REC. : RECORDING
RES. : RESISTOR SPK : SPEAKER
SW : SWITCH TRANSF. : TRANSFORMER
TRIM. : TRIMMING TRS. : TRAMSISTOR
VAR. : VARIABLE X’TAL : CRYSTAL

ABBREVIATION AND MARKS

{

{

{

{

{

{

{

{

{

{

➂

➀

➁

➂

➃

➄

➅

➆

➅

NOTE ON SAFETY :

Symbol Fire or electrical shock hazard. Only original
parts should be used to replaced any part marked with
symbol . Any other component substitution (other
than original type), may increase risk of fire or electrical
shock hazard.

1-47

POS.

NO

VERS.

COLOR

PART NO.

(FOR PCS)

DESCRIPTION

PART NO.

(MJI)

POS.

NO

VERS.

COLOR

PART NO.

(FOR PCS)

DESCRIPTION

PART NO.

(MJI)

P816-SUPPLY

CIRCUIT BOARD

P816-CAPACITORS
C801 4822 122 31237 CER. 82pF J CH 50V BLK DD15820300
C810 4822 124 40763 ELECT. 2.2µF M 50V RA-2 OA22505020
C811 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C814 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010

C819 9965 000 04979 FILM 0.1µF 250V AC ECQUL DF17104630
C820 9965 000 06376 FILM 0.22µF 250V AC ECQUL DF17224570
C821 9965 000 04981 ELECT. 120µF 400V EA12740070
C825 9965 000 04980 CER. 470pF AC400V DK17471520
C826 9965 000 04980 CER. 470pF AC400V DK17471520
C827 9965 000 06377 CER. 470pF 1KV DK16471560

C828 9965 000 04980 CER. 470pF AC400V DK17471520
C829 4822 124 80067 ELECT. 4.7µF M 50V RA-2 OA47505020
C833 F ELECT. 120µF 16V RJH EF12701610
C833 N1 ELECT. 120µF 16V RJH EF12701610
C833 U1 4822 124 41535 ELECT. 100µF M 25V RA-2 OA10702520

C851 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C852 9965 000 06378 ELECT. 330µF 16V

LOW IMPEDANCE RJB

EF337016P0

C854 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C855 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C856 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C857 9965 000 06379 ELECT. 2200µF 10V

LOW IMPEDANCE RJB

EF228010P0

C859 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C860 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C861 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C862 9965 000 06380 ELECT. 10µF 50V

LOW IMPEDANCE RJB

EF106050P0

C864 4822 124 90366 ELECT. 220µF M 50V RA-2 OA22705020
C866 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C867 9965 000 06381 ELECT. 1000µF 16V

LOW IMPEDANCE RJB

EF108016P0

C869 4822 124 12404 ELECT. 220µF M 25V RA-2 OA22701620
C871 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C872 9965 000 06382 ELECT. 220µF 16V

LOW IMPEDANCE RJB

EF227016P0

C873 4822 124 12404 ELECT. 220µF M 25V RA-2 OA22701620
C875 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
C876 4822 124 12404 ELECT. 220µF M 16V RA-2 OA22701620
C877 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C881 4822 124 41535 ELECT. 100µF 25V OA10702520
C882 4822 122 30103 CER. 0.022µF 50V DK18223310
C891 4822 124 41535 ELECT. 100µF 25V OA10702520
C892 4822 124 41535 ELECT. 100µF 25V OA10702520
C898 4822 122 40617 CER. 0.1µF 50V DD38104010

P816-CAPACITORS (COMMON)

HIGH DIELECTRIC CONSTANT

CER. CAPACITOR ±10% 50V :
C802-C804 C809 C813

P816-RESISTORS
R809 4822 111 31001 330

Ω

±5% 1/6W GG05331160

R811 4822 052 10229 22

Ω

±5% 1/6W GG05220160

R812 4822 052 10101 100

Ω

±5% 1/6W GG05101160

R813 9965 000 06391 15

Ω

±5% 1/6W GG05150160

R816 9965 000 05893 180

Ω

±5% 1/6W GG05181160
R819 F 4822 116 82449 330Ω K 1/2W ERC12GK334C RC10334120
R819 N1 9965 000 00502 1MΩ ±5% 1W RCR60 L15 RC05105010
R819 U1 2.2MΩ 1/2W ERC12UG RC10225820

R823 4822 053 10183 18k

Ω

±5% 1W GA05183010

R825 4822 052 10102 1k

Ω

±5% 1/6W GG05102160

R826 4822 116 82805 1

Ω

±5% 1/6W GG05010160

R827 9965 000 06392 1.5

Ω

±5% 1/6W GG05015160

R828 9965 000 06392 1.5

Ω

±5% 1/6W GG05015160

R832 4822 053 10183 18k

Ω

±5% 1W GA05183010

R882 4822 052 10101 100

Ω

±5% 1/6W GG05101160

R884 4822 050 22212 2.21k

Ω

±1% 1/6W GM11622110

R885 4822 050 26811 681

Ω

±1% 1/6W GM11668100

R895 JUMPER 75060501P0

P816-SEMICONDUCTORS

D802 4822 130 81248 DIODE S1WB(A)60 30A 600V HD20031290
D803 9965 000 00388 DIODE AG01 400V 0.7A HD20049080
D804 9965 000 00388 DIODE AG01 400V 0.7A HD20049080
D806 9965 000 00388 DIODE AG01 400V 0.7A HD20049080
D807 9965 000 00388 DIODE AG01 400V 0.7A HD20049080
D814 9965 000 00388 DIODE AG01 400V 0.7A HD20049080

D829 4822 130 80116 ZENER DIODE 24V HD32401000

D832 9965 000 00388 DIODE AG01 HD20049080
D851 9965 000 00388 DIODE AG01 HD20049080
D856 4822 130 11074 DIODE RK46 HD20050080
D861 9965 000 00388 DIODE AG01 HD20049080

D862 4822 130 34499 ZENER DIODE 20V HD32001000

D866 9965 000 06383 DIODE RU4AM 600V 2.0A HD20051080

D868 9965 000 00388 DIODE AG01 400V 0.7A HD20049080

D871 9965 000 00388 DIODE AG01 HD20049080

D881 9965 000 06384 IC TL431 SHUNT REGULATOR HC33036590

Q801 4822 130 10431 PHOTO UNIT PC-123F2 HW10032320
Q810 4822 209 90025 IC MC44603P HC10111170
Q825 9965 000 00395 F.E.T. 2SK2943 900V 3A HF22943000
Q851 9965 000 06390 IC LM317 ADJ. REG. HC31937590

Q861 4822 130 41947 TRS. 2SC2458 2SC1740S

2SC3199 ETC.

HT30001000

Q862 4822 130 42715 TRS. 2SA1048 2SA933S

2SA1267 ETC.

HT10001000

Q871 9965 000 01744 IC NJM7908FA HC39908090
Q891 4822 130 43818 TRS. 2SC2878 HT328782A0
Q892 4822 130 10431 PHOTO UNIT PC-123F2 HW10032320

P816-MISCELLANEOUS

F820 F FUSE 2A 125V

UL CSA MITI FBT

FS10200350

F820 N1 4822 070 32001 FUSE 2A 250V BS LISTED FS10200850

F820 U1 FUSE 2A 125V

UL CSA MITI FBT

FS10200350

G815 CER. DE1610F 103M-KH DK17103900

L820 4822 157 70398 CHOKE COIL LINE FILTER

LF-4D-223 22MH

LC22260130

L825 4822 242 80418 FERRITE BEAD

BL02RN2-R62T2

FC90050130

L831 9965 000 06385 MAINS TRANSF. ER2810SG

SWITCHING

TS12900010

L832 9965 000 06386 CHOKE COIL 10µH J%

SUBSTITUDE COIL

LC11033900

L851 9965 000 06387 CHOKE COIL 4.7µH J%

SUBSTITUDE COIL

LC14723900

L852 JUMPER 75060501P0
L853 9965 000 06387 CHOKE COIL 4.7µH J%

SUBSTITUDE COIL

LC14723900

L854 9965 000 06386 CHOKE COIL 10µH J%

SUBSTITUDE COIL

LC11033900

L856 9965 000 06388 CHOKE COIL 6.8µH

PJ8R-6R8M

LC16820110

L861 4822 157 62681 CHOKE COIL 1µH EL0405 LC11023900
L862 9965 000 06386 CHOKE COIL 10µH J%

SUBSTITUDE COIL

LC11033900

L866 JUMPER 75060501P0
L867 9965 000 06389 CHOKE COIL 2.2µH

LHLC06TB2R2M

LC12220190

L871 JUMPER 75060501P0
L872 9965 000 06386 CHOKE COIL 10µH J%

SUBSTITUDE COIL

LC11033900

1-48

POS.

NO

VERS.

COLOR

PART NO.

(FOR PCS)

DESCRIPTION

PART NO.

(MJI)

POS.

NO

VERS.

COLOR

PART NO.

(FOR PCS)

DESCRIPTION

PART NO.

(MJI)

L873 9965 000 06386 CHOKE COIL 10µH J%

SUBSTITUDE COIL

LC11033900

S815 9965 000 05921 PUSH SWITCH

ESB92S94B TV-5 1.5MM

SP01012480

P916-H.P CIRCUIT BOARD

P916-CAPACITORS
C901

4822 124 23052 ELECT. 100µF 16V RC-2 EJ10701610
C906
C907 4822 126 10364 CER. 100pF UP050B101K-A DA16101110
C908 4822 126 10364 CER. 100pF UP050B101K-A DA16101110
C909 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C910 9965 000 07563 CER. 2200pF DA17222110
C911 4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0
C912 4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0

P916-RESISTOR
R920 9965 000 00602 VARIABLE 10 k

Ω

B

RK09L12B0 (D-CUT REVERSE)

RM01031170

P916-SEMICONDUCTOR
Q901 4822 209 82362 IC NJM4556D HC10016090

P916-MISCELLANEOUS
J901 4822 267 31126 JACK H.P. HLJ1520-01-3410 YJ01003020
L901

4822 242 80418 FERRITE BEAD - FC90050130
L903 BL02RN2-R62T2

PP16-MAIN CIRCUIT BOARD

PP16-CAPACITORS
CC01 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CC02 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
CF52 9965 000 07562 CER. 470pF DA16471110
CM01 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CM02 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
CM03 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CM04 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620

CT01 9965 000 07563 CER. 2200pF DA17222110
CT02 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CT03 4822 126 10513 CER. 47pF DA15470110
CT04 4822 124 41134 ELECT. 10µF 63V RA-2 OA10606320
CT05 4822 126 10364 CER. 100pF UP050B101K-A DA16101110
CT11 9965 000 07563 CER. 2200pF DA17222110
CT12 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CT13 4822 126 10513 CER. 47pF DA15470110
CT14 4822 124 41134 ELECT. 10µF 63V RA-2 OA10606320
CT15 4822 126 10364 CER. 100pF UP050B101K-A DA16101110
CT31 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CT32 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CT33 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CT52 4822 124 41134 ELECT. 10µF 63V RA-2 OA10606320
CT53 4822 126 10513 CER. 47pF DA15470110
CT54 9965 000 07563 CER. 2200pF DA17222110
CT55 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CT60 4822 126 10364 CER. 100pF UP050B101K-A DA16101110

C301 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C314 4822 126 10513 CER. 47pF DA15470110
C315 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C331 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C651 4822 126 10364 CER. 100pF UP050B101K-A DA16101110
C652 4822 126 10364 CER. 100pF UP050B101K-A DA16101110
C671 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C672 9965 000 07563 CER. 2200pF DA17222110
C681 4822 126 10364 CER. 100pF UP050B101K-A DA16101110
C682 4822 126 10364 CER. 100pF UP050B101K-A DA16101110

C701 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C702 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C703 4822 126 10364 CER. 100pF UP050B101K-A DA16101110
C704 4822 126 10364 CER. 100pF UP050B101K-A DA16101110
C707 9965 000 07562 CER. 470pF DA16471110
C708 9965 000 07562 CER. 470pF DA16471110
C741 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C745 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C777

4822 124 12404 ELECT. 220µF M 16V RA-2 OA22701620
C780
C781

4822 122 33741 CER. 10pF DA15100120
C788
C791

4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C798

PP16-RESISTORS
RT02 4822 111 41355 75

Ω

±5% 1/6W GD05750160

RT12 4822 111 41355 75

Ω

±5% 1/6W GD05750160

RT52 4822 111 41355 75

Ω

±5% 1/6W GD05750160

R311 4822 111 41355 75

Ω

±5% 1/6W GD05750160

R779 9965 000 07426 VARIABLE 50k

Ω

C RK09K111 RK05030950

R780 9965 000 07426 VARIABLE 50k

Ω

C RK09K111 RK05030950

PV04-RESISTORS (COMMON)

CARBON FILM FIXED RES.

±5% 1/6W : R301 R312 R313
R315 R651-R656 R681-R686
R701-R710 R747-R758 R761
R762 R763 R772 R775-R778
R781-R796 R801-R808 R810
R814 R815 R829 R851-R853
R861-R866 R881 R883 R886
R887 R891-R894 R903-R912
RRF51 RF57 RM01 RN01 RN02
RN51-RN54 RN81-RN85 RT03
RT13 RT31-RT36 RT57 RY01
RY02-RY04 RY06 RY09-RY17
RY21-RY26 RY31-RY35 RY44

PP16-SEMICONDUCTORS
DF51 4822 130 32362 DIODE 1SS176 MA165 1SS254

30V 0.1A

HD20002000

DM01 5322 130 31504 ZENER DIODE MTZ J 3.3A HD30331000
DM02 5322 130 31504 ZENER DIODE MTZ J 3.3A HD30331000

QC01 4822 209 17437 IC PQ09RF1 HC31909320
QF51 4822 130 61227 DIG.TRS.

DTA114ES UN4111 10K 10K

BA10001000

QF52 4822 130 60588 DIG.TRS.

DTC114ES UN4211 10K 10K

BA20001000

QM01 4822 209 71373 IC NJM78L05A HC38105090
QM02 4822 209 83825 IC NJM79L05A HC39105090

QN51

4822 130 43818 TRS. 2SC2878 A RANK HT328781A0
QN54
QN81

4822 130 43818 TRS. 2SC2878 A RANK HT328781A0
QN84
Q311 4822 209 63182 IC LC74HCU04 HC700400U0
Q312 4822 209 63182 IC LC74HCU04 HC700400U0
Q702 4822 209 83804 IC LC4966 HC10150030
Q761

4822 209 83631 IC NJM4558DD HC10008090
Q764

1-49

POS.

NO

VERS.

COLOR

PART NO.

(FOR PCS)

DESCRIPTION

PART NO.

(MJI)

POS.

NO

VERS.

COLOR

PART NO.

(FOR PCS)

DESCRIPTION

PART NO.

(MJI)

PP16-MISCELLANEOUS
JF51 9965 000 07431 TERMINAL 14X14 RCA 2L2P

ORG NI FRONT-GND

YT02021090

JT01 9965 000 07432 TERMINAL 14X14 RCA 2L2P

BLK NI FLM-GND

YT02021220

JT51 4822 267 31729 TERMINAL 14X14 RCA 1L1P

BLK NI FLM-GND

YT02010780

J301 4822 218 11487 OPTICAL RECEIVER GP1F32R YJ15000150
J311 4822 265 10684 TERMINAL 14X14 RCA 1L1P

BLK NI FRONT-GND

YT02011020

J601 9965 000 07564 JACK 1MM PITCH FFC

14FMN-BTRK(ST)

YJ07019380

J651 4822 267 31727 TERMINAL 14X14 RCA 2L2P

W/R NI FRONT-GND

YT02021210

J681 4822 267 31727 TERMINAL 14X14 RCA 2L2P

W/R NI FRONT-GND

YT02021210

J682 9965 000 07565 JACK FFC CONNECTOR 07P

9604S-07C

YJ07011370

J701 4822 267 31727 TERMINAL 14X14 RCA 2L2P

W/R NI FRONT-GND

YT02021210

LF51 4822 242 80418 FERRITE BEAD

BL02RN2-R62T2

FC90050130

LT03 4822 142 60422 PULSE TRNSF.

(TPS247MN-0386AN)

TP41042030

LT13 4822 142 60422 PULSE TRNSF.

(TPS247MN-0386AN)

TP41042030

LT53 4822 142 60422 PULSE TRNSF.

(TPS247MN-0386AN)

TP41042030

L651 4822 242 80418 FERRITE BEAD

BL02RN2-R62T2

FC90050130

L652 4822 242 80418 FERRITE BEAD

BL02RN2-R62T2

FC90050130

L681 4822 242 80418 FERRITE BEAD

BL02RN2-R62T2

FC90050130

L682 4822 242 80418 FERRITE BEAD

BL02RN2-R62T2

FC90050130

L701 4822 242 80418 FERRITE BEAD

BL02RN2-R62T2

FC90050130

L702 4822 242 80418 FERRITE BEAD

BL02RN2-R62T2

FC90050130

MC01 4822 361 11159 D.C MOTOR BRUSHLESS FAN

KD1204pFB2-8

MM01200290

SF51 4822 277 21559 SLIDE SWITCH INT/EXT SS02021150
S752 4822 277 21559 SLIDE SWITCH INT/EXT SS02021150

PP26-XLR CIRCUIT BOARD

PP26-CAPACITORS
CT21 F 4822 124 90353 ELECT. 100µF 10V RA-2 OA10701020
CT61 F 4822 124 90353 ELECT. 100µF 10V RA-2 OA10701020
C761

4822 126 10513 CER. 47pF DA15470110
C764
C769

4822 126 10513 CER. 47pF DA15470110
C772
C773 4822 126 10364 CER. 100pF UP050B101K-A DA16101110
C774 4822 126 10364 CER. 100pF UP050B101K-A DA16101110

PP26-MISCELLANEOUS
JT21 F 4822 267 31369 OPTICAL CONNECTOR

GP1F32F OUTPUT

YJ15000090

JT61 F 4822 267 31369 OPTICAL OCONNECTOR

GP1F32F OUTPUT

YJ15000090

J761 9965 000 02540 JACK NC3FAH2 4P

CANON TYPE HOLZ

YJ01004340

J762 9965 000 02540 JACK NC3FAH2 4P

CANON TYPE HOLZ

YJ01004340

L754 4822 242 80418 FERRITE BEAD

BL02RN2-R62T2

FC90050130

L755 4822 242 80418 FERRITE BEAD

BL02RN2-R62T2

FC90050130

L769 4822 242 80418 FERRITE BEAD

BL02RN2-R62T2

FC90050130

L770 4822 242 80418 FERRITE BEAD

BL02RN2-R62T2

FC90050130

PY16-FTD CIRCUIT BOARD

PY16-CAPACITORS
CY03 4822 122 40588 CER. 0.022uF TP050F223Z DA17223110
CY04 4822 122 33761 CER. 22pF DA15220110
CY05 4822 122 33761 CER. 22pF DA15220110
CY06 4822 126 11558 CER. 0.1µF Z 50V DA17104110
CY08 4822 126 11558 CER. 0.1µF Z 50V DA17104110
CY09 4822 126 10364 CER. 100pF UP050B101K-A DA16101110
CY10 4822 126 10364 CER. 100pF UP050B101K-A DA16101110
CY13 4822 126 11558 CER. 0.1µF Z 50V DA17104110
CY14 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CY41 4822 124 22698 ELECT. 47µF M 25V RA-2 OA47602520

PY16-SEMICONDUCTORS
DY01 4822 130 11569 L.E.D. HLMF-K200 #2UL RED HI10005340
DY04 5322 130 31504 ZENER DIODE MTZ J 3.3A HD30331000
DY41 4822 130 32362 DIODE 1SS176 MA165 1SS254

30V 0.1A

HD20002000

DY42 4822 130 32362 DIODE 1SS176 MA165 1SS254

30V 0.1A

HD20002000

QY01 9965 000 07429 MICROPROCESSOR

TMP87CH74F

HU385KT00F

QY02

4822 130 41947 TRS. 2SC2458 2SC1740S HT30001000
QY04 2SC3199 ETC.
QY42 4822 130 42594 DIG.TRS.

DTC144ES UN4213 47k 47k

BA20002000

QY43 4822 130 42594 DIG.TRS.

DTC144ES UN4213 47k 47k

BA20002000

QY44 4822 130 42682 DIG.TRS.

DTA144ES UN4113 47k47k

BA10002000

PY16-MISCELLANEOUS
LY01 4822 157 62899 CHOKE COIL 220µH

LAL02TA224J

LC12243800

SY04

9965 000 00373 PUSH SWITCH SP01013370
SY10 EVQ11L05R H/5MM,160GF
SY12 9965 000 00373 PUSH SWITCH EVQ11L05R

H/5MM,160GF

SP01013370

SY13 9965 000 00373 PUSH SWITCH EVQ11L05R

H/5MM,160GF

SP01013370

SY15

9965 000 00373 PUSH SWITCH SP01013370
SY18 EVQ11L05R H/5MM,160GF
SY21

9965 000 00373 PUSH SWITCH SP01013370
SY23 EVQ11L05R H/5MM,160GF
SY26 9965 000 05915 ROTARY ENCODER EC11B

WITH PUSH SW

SR03030030

VY01 9965 000 05916 DISPLAY UNIT FTD BJ727GNK

15GRID X 22ANODE

HQ31208410

XY01 4822 242 72066 CERAMIC VIB CST8.0MHz FQ08004010

PY26-IR CIRCUIT BOARD

CY07 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
ZY01 9965 000 06833 PHOTO UNIT IR SENSOR

RPM6936-H4

HW10008210

CD Module

MAR1250

Service
Manual

MAR1250

R

Please use this service manual with referring to the user guide ( D.F.U. ) without fail.

TABLE OF CONTENTS

SECTION PAGE

2. MAR1250 ( CD MODULE )

2.1 WIRING DIAGRAM ............................................................................................................................. 2-1

2.2 SCHEMATIC DIAGRAM ...................................................................................................................... 2-3

2.3 PARTS LOCATION ........................................................................................................................... 2-11

2.4 EXPLODED VIEW AND PARTS LIST ............................................................................................... 2-15

2.5 ELECTRICAL PARTS LIST ............................................................................................................... 2-17

2-1 2-2

Sledge motor

OPU

LOADER VAL1250

CDM VAM1250

Tray motor

MAIN BOARD CD

Turn table

motor

Tray

switch

MAIN BOARD CD

CDM VAM1250

POSITION OF FLEX CONNECTIONS

LOADER VAL1250

Flex from OPU

Flex from
turn table motor

Connector from tray motor
and tray switch

Connector from sledge motor
and sledge switch

Connection tray motor
and tray switch

Connection sledge motor
and sledge switch

Flex from OPU

Flex from
turn table motor

and switch

1002

1208

1210

1209

1001

1006

1000

14

1

22

1

16

1

11

1

16

1

7

14

To main board CDR

To MAIN PCB PP16

CONNECTOR 1006

1 HALL +
2 W­3 W+
4 V+
5 HALL­6 U+
7 V­8 U­9 UCOIL
10 VCOIL
11 WCOIL

CONNECTOR 1002

1 HOMESW
2 SGND
3 TRAY+
4 TRAY-

CONNECTOR 1001

1 HOMESW
2 SGND
3 SL­4 SL+

CONNECTOR 1000

1 VSUB
2 HFGND
3 VDD
4 RF
5 LDON
6 R2
7 R1
8 D4/D3
9 D2
10 D1
11 FTC
12 RW
13 FOC+
14 FOC­15 RAD+
16 RAD-

CONNECTOR 1209

1 AUDIO R (RIGHT_CD)
2 GND
3 AUDIO L (LEFT_CD)
4 GND
5 DOBM5_CD (DOBM_CD)
6 GND
7 KILL

CONNECTOR 1208

1 GND
2 CRIN (SYS_CLK_8W)
3 KILL
4 AUDIO R (RIGHT_IN_CD)
5 GND
6 AUDIO L (LEFT_IN_CD)
7 DSA_RST (SYS_RESET)
8 DOBM (DOBM_CD)
9 GND
10 SCLK (I2S_BCLK_CD)
11 GND
12 WCLK (I2S_WS_CD)
13 DATA (I2S_DATA_CD)
14 GND
15 +12V
16 +5V
17 GND
18 DSA_ACK (DSA_ACK_CD)
19 DSA_STROBE (DSA_STR_CD)
20 GND
21 DSA_DATA (DSA_DATA_CD)
22 GND

2.1 WIRING DIAGRAM
CD LOADER VAL1250

2-3 2-4

CD Diagram 1A

3

2

1

0

G4

3

0

1

0

4x

INTERFACE

VERSATILE

DEMOD

EFM

PLL

DIG.

STAGES

OUTPUT

CONTROL

MOTOR

KILL

INTERF.

LOOPBACK

SER. DATA

INTERF.

VERSAT.

INTERFACE

SER. DATA

BITSTREAM DAC

TIMING

INTERFACE

MICROCONTROLLER

PROCESSOR

AUDIO

PROCESSING

PRE-

FUNCTION

CONTROL

SRAM

ADDR

INTERF.

EBU

DET.

PEAK

CORR.

ERROR

PROCESSOR

SUBCODE

END

FRONT

VREF GEN.

ADC

7008 E2
7009 D5

F321 G12
F322 G12
F324 G10

F168 E14
F170 E1

F147 B1
F149 B13

F174 E7
F175 E7
F177 F1
F178 F9

F166 E7

F167 E143211 F6
3212 F9
3213 F3
3214 F14
3219-A G13

F180 G1
F181 F13
F182 G13

F302 B12
F303 B11
F304 B11

F305 B11
F183 G12
F184 G11

F190 H14

F191 H11

F192 H143273 B11

3274 B12

F306 B12

F308 B11

F318 G12
F319 G97005-B B14

7006 D3
7007 E7

F312 D9
F313 D7
F314 D9
F315 D136003 H14

7000 C93176 C14

3177 C2

3178 C8
3179 C1
3180 C5

7010 E6
7011 E2
7023 B5
7024 F6
7025 B7

7130 H15
7131 H14
7132 H13
7311-A G2
F139 A12
F143 A13
F146 A23193 D7

3194 D8

F151 C13
F154 C1
F155 C2
F156 C8

F171 E7
F172 E14
F173 E1

F162 D7
F163 D14

F164 D7
F165 D133206 E8

3208 F12171 F9
2172 F9
2173 F9
2174 F1
2175 F2

3219-B G13

3219-C G13
3219-D G13
3220 G11
3225 H10
3229 H9
3265 H15
3266 H14
3267 H13
3268 H14

3269 H14
3270 H152233 H13

2236 F6

3275 B12
3276 B11
3279 B2
3280 F13

F309 C9
F310 C9

F311 D133284 D13
3285 H13
3286 H13
3287 H133173 B4

3174 B4
2137 B8
2138 B8

2139 B11
2140 C4

3181 C9
3182 D2
3183 D2
3184 D8
3185 D14
3186 D14

3187 D2
3188 D5
3189 D7
3190 D9
3191 D4
3192 D42154 D9

2155 D9

3195 E8

3196 E6
3197 E8
3198 E2

F157 C3
F159 C9

F160 D13202 E2
3203 E5
3204 E8

3205 E72169 F8

2170 F81000-10 G1
1000-11 G1
1000-12 D1
1000-2 E1
1000-3 B1

2178 G10

2182 F3

2183 F3
2184 G9
2185 G9
2186 G10
2189 G9
2191 H9
2200 H4
2201 H4
2230 H14

2232 H131020 G10

1021 G10

2280 F14
2285 G10
2286 G11
3160 A9

3281 F6

3282 G11

3283 G123168 B12
3169 B5
3171 B13
3172 B11

2134 B1
2135 B1

12345

2141 C6
2142 C9
2143 C4
2145 C9
2146 C6
2147 C1

2148 C1
2149 C6
2150 C9
2151 D3
2152 D3

C

D

2156 D2
2157 D8

2159 D1
2160 D6

3199 E3
3200 E8

3201 E22164 E4
2166 E3
2167 E14
2168 F8

H

1000-1 C1

12345

1000-4 E1
1000-5 A1
1000-6 H1

1000-7 H1
1000-8 H1
1000-9 H1
1003 F7
1004 G9
1009 C15
1010 C15
1011 C15
1012 C15

13 14

1022 G11
1023 G11
1028 B2
1029 B3

3161 B12
3162 B11

3164 B15
2130 B6
2131 B12
2132 B11
2133 B1

RW

VSUB

VDD

LDON

13 14 156789101112

A

B

A

B

C

D

EE

F

G

H

2161 D6
2162 E4
2163 E1

F308

F

G

6 7 8 9 10 11 12 15

FTC

HFGND

RF

1050-1 G1
1050-2 G1
2128 B12

F306

F305

F304

1n5

2286

1n5

2285

F312

F151

F143

F149

F139

F310

F309

F303

F182

F302

F322

F311

F318

F324

F321

F319

F313

F314

100R

3274

3104 123 4236

PB CD MAIN 4236
CDR99

F157

F180

F154

F160

F155

F146

HFGND

F147

F163

F165

F167

3279

1R

F168

F172

F184

F181

F192

F183

F190

F178

F162

F164

F156

3267

1K

F315

3268

100K

3283

1028

1

3282

10K

10K

+5VHF

3270

10K

3269

+5VHF

1n5

2233

100R

3275

100R

390p

3273

100R

+5VHF +5VHF

HFGND

47K

4K7

3285

3286

150K

3287

BC848B

7132
BC848B

7131

BC858B

7130

F166

1029

1

F174

F175

F159

F191

3219-C

47R

F177

3219-B

47R

+5VHF

3168

100R

3213

2183

100n

2182

10u

100R

BAS216

6003

1050-2

2

3266

1K

3220

10K

HFGND

HFGND

102311022

1

102111020

1

VPROC

10K

3280

1004

100n

2280

3276

100R

CX-5F

8M4672

F171

100n

2236

+5VHF

2R2

3281

2232

100n

HFGND

HFGND

2128

2141

2n2

100K

3265

47u

1

+5V

1M

3212

1009

1

+5VHF

1010

+5VHF

+5VHF

+5VHF

HFGND

2130

100n

HFGND

HFGND

2139

100n

1

8

4

680p

2149

1050-1

1

7311-A

TDA1308T

3

2

3214

0R

10K

3171

100R

3172

22n

2138

+5V

2137

0R

3284

+12V

+5V

HFGND

22n

F173

1011

1

5

6

14

7

F170

+3V3

7005-B

74HCT08D

4

2R2

3161

47R

3219-D

+5V

3173

430R

HFGND

47u

2161

HFGND

22n

2160

3186

4K7

3185

4K7

10K

100n

2167

+3V3

3197

3160

+3V3

2R2

3225

2201

+5VHF

10K

HFGND

HFGND

1n5

HFGND

+5VHF

560p

2200

HFGND

47u

2175

HFGND

22n

2174

2230

3208

4R7

4u7

+5VHF

HFGND

4n7

47u

2132

2148

470n

2147

HFGND

1000-12

12

HFGND

1K

3179

1000-5

5

1000-10

10

2159

47n

100n

2131

1000-4

4

330p

2143

2

3162

2R2

+3V3

1000-11

11

HFGND

1000-2

HFGND

100n

2134

+5VHF

1000-3

3

HFGND

HFGND

2135

22u

47u

2186

100n

2178

1012

1

3164

47R

47R

3219-A

100n

2155

100R

3176

22K

3181

HFGND

47n

2150

HFGND

2142

22n

2170

220p

2171

220p

2169

220p

2168

10K

3200

220p

1K5

10K

3206

10K

3204

3199

2157

3195

10K

9

3194

10K

100n

1000-8

8

1000-6

6

1000-9

1000-7

7

+3V3

HFGND

2R2

3229

47u

2191

2184

33p

2185

33p

2173

220p

2172

2146

220p

14

15

11

13

1

5

2

4

3

6

8

GND

10

9

VCC

16

VEE

7

1n5

74HCT4052D

7025

12

100p

2162

7009
BFS20

3192

430R

HFGND

7010

100n

2152

HFGND

HFGND

BC848B

3205

7007

BC858B

2K7

3169

10K

HFGND

2K7

3180

7023

10K

3183

3211

1K

HFGND

BFS20

HFGND

1003

1

2

7024

1K

3178

2163

33n

BF824

3196

3189

390R

2145

HFGND

1K

VDDA2

52

VDDD1P

57

VDDD2C

20

VNEG21VPOS

7

VRIN

VSSA1

4

14

VSSA2

33

VSSD1

50

VSSD2

58

VSSD3

WCLI

35

28

WCLK

47p

SDA

SDI

36

24

SELPLL

47

SFSY

42

SILD

56

SL

43

STATUS

46

SUB

TEST1

25 31

TEST2

44

TEST3

63

V1

34

V2|V3

61V462

V5

5

VDDA1

17LN19

LP

59

MOTO160MOTO2

12

R1

R2

13

54

RA

41

RAB

RCK

45

38

RESETn

22RN23

RP

48

SBSY

40

SCL

37

SCLI

29

SCLK

39

CRIN

15

CROUT

8

D1

9

D2

10

D3

11

D4

DATA

27

51

DOEM

30

EF

FO

55

2

HFIN

1

HFREF

6

IREF

3

ISLICE

32

KILL

64

LDON

18

30K

SAA7324

7000

53

CFLG

49

CL11|4

26

CL16

16

2R2

HFGND

3190

3201

+5VY

+5V

3184

BFS20

7008

1K2

2K7

HFGND

HFGND

3174

430R

3188

180p

2164

HFGND

470n

2K7

3203

+3V3

1000-1

1

2133

HFGND

2154

47u

BFS20

7006

HFGNDHFGND

2166

47n

47R

3198

HFGND HFGND

3202

22K

7011
BFS20

2189

100n

180p

2140

3177

HFGND

47u

2151

+5VHF

1R

390R

3182

390R

47u

2156

HFGND

3187

3191

430R

HFGND

CRIN

MUTE

EF

CFLG

V4

V4

FO

RA

SL

180R

3193

SCLK

CL11

MOT1

HFDET

DOBM5_CD

DOBM5_CD

S1

S2

RW

SILD

SCL

SDA

RESET

SCLK_IN

DATA_IN

WCLK_IN

CL16

DATA

WCLK

CD MAIN BOARD - CIRCUIT DIAGRAM 1A
DECODER & SERVO PROCESSOR PART

>800mVpp

eyepattern

2.5V

0,5us/DIV

3

eyepattern

2.5V

0,5us/DIV

1

2

5

4

6

PULSE DENSITY MODULATION

4

5

6

7

8.4672MHz

CD-DA, CD-R : 5V
CD-RW : 0V

8

1

2

9

9

10

11.2896MHz

CL 96532086_015.eps

080999

CONN. 1000 : TO CDM VAM1250

2.2 SCHEMATIC DIAGRAM

2-5 2-6

CD diagram 1B

-+

REV

PS

-

+

H BIAS

CONTROL

GAIN

DRIVER

+

-

+

-

+

-

+

-

+

-

+

-

+

-

+

-

VDD

+

-

+

-

VDD

F105 A11
F106 F1
F107 A2

F111 B6
F112 B2
F113 G1

F117 B2
F118 G4
F119 H5
F120 H1
F121 I7
F122 I8
F123 H1
F124 H1
F125 H1
F126 I6
F127 I5
F128 C5
F129 I1
F130 I5
F131 I4
F132 I1
F133 D2
F134 D9
F135 D5
F136 D2
F137 D6

3149 D5
3150 D5
3151 D6

F138 D2
F140 E5
F141 D9

3156 E5
3157 E6
3158 E5

F145 E2
F300 H4
F301 H4

6000 G5
6001 G5
6002 G4
7005-D I8
7019 F1
7020 G2
7021 A4
7022 D4
7030 H6
7031 I4
7110-A H10
7110-B H9
7110-C H10
7110-D H11
7301 H8

F100 F3
F101 F1
F102 A11
F103 A2
F104 F4

3101 F2
3102 F1
3103 A6

F108 H8
F109 A2
F110 H9

3107 I4
3110 G8
3113 G8

F114 G1
F115 B2
F116 G1

3117 F1
3129 H11
3130 H8
3131 B10
3132 B7
3134 G4
3135 G4
3136 B5
3137 B6
3138 B6
3139 I7
3140 H6
3141 I9
3142 C4
3143 H5
3144 H5
3145 C5
3146 H4
3147 C5
3148 D3

2100 A5
2102 A6
2103 A5

3152 D3
3154 D8
3155 E3

2107 B7
2108 H9
2109 B5

3159 E3
3277 H9
3278 I8

2113 G1
2114 I8
2115 B5
2116 B5
2117 I7
2118 H4
2119 H4
2120 C5
2121 D5
2122 D5
2123 C6
2124 D7
2125 D7
2126 E5
2127 E6
2220 H8
2221 I11
2281 I6
2282 I4
3100 F1

B

C

D

3104 I6
3105 I6
3106 I5

H

I

1000-13 E1

3114 A5
3115 A5
3116 A6

1001 B1
1002 A1
1005 F5
1006-1 F1
1006-10 G1
1006-11 G1
1006-2 I1
1006-3 I1
1006-4 H1
1006-5 F1
1006-6 G1
1006-7 H1
1006-8 H1
1006-9 G1
1008 F4
1024 D8
1025 D8
1026 B10
1027 B11
1321 F7

789

2104 F3
2105 F3
2106 B7

10 11

1

2110 B7
2111 G1
2112 G1

234567891011

A

B

C

D

E

F

G

H

I

A

E

F

G

1000-14 E1
1000-15 D1
1000-16 D1

RAD+

RAD-

FOC-

FOC+

HOMESW

SGND

SL-

SL+

HOMESW

SGND

TRAY+

TRAY-

123456

PGND

PGND

6000

BYG50D

2

1006-9

9

PGND

7

1006-3

3

1006-2

6

1006-4

4

1006-7

1006-8

8

1006-6

100n

2119

PGND PGND

+5V

100n

2112

100n

2111

+5V

2113

100n

+5V

BC858B

7019

3104

3143

47K

7030

BC847B

180R

2114

100n

PGND

3139

2117

22n

+5V+5V

10K

PGND

PGND

+5V

MT1

29 30

MT2

1

NC1

2

NC2

4

NC3

NC4

6

15

NC5

23

PS

24

REV

RNF

28

25

VCC

19

VH

26

VM1

27

VM2

PGND

A1

7

5

A2

3

A3

20

CNF

22

EC

21

ECR

18

FG1

17

FG2

FG3

16

GND

8

9

H1+

10

H1-

11

H2+

12

H2-

13

H3+

14

H3-

BA6856FB

7020

+5VX +5V

3129

10K

+5V

+5VX

+5VX

100n

2104

2105

47u

3134

1R

6002

BYG50D

1R

3135

BYG50D

6001

PGND

7110-A

74HCT00D

1

2

7

14

3

PH-B

1321

1

2

3

4

F124

0R

3140

1K

F123

+5V

3113

47K

3144

PGND

1

1006-5

5

CDR99

PB CD MAIN 4236

3104 123 4236

1006-11

11

1006-1

F126

1006-10

10

F121

F119

F122

F110

F108

PGND

7005-D
74HCT08D

12

13

11

14

7

1005

PH-B

1

2

3

4

+5V

22K

3101

3100

22K

180R

3106

2281

10n

BC847B

7031

3105

560R

3136

1K2

3117

47R

+12V

2118

100n

3102

47R

PGNDPGND

PGND

2220

100n

1001

1

2

3

4

100n

2108

16

1000-15

15

PH-B

9

12

5

3

4

8

11

15

1000-16

7021

TDA7073A

14

10

2

1

6

7

16

13

3159

0R

150K

3147

0R

3155

7110-C

74HCT00D

9

10

7

14

8

0R

3141

12

13

7

14

11

2121

100n

74HCT00D

7110-D

+3V3

22u

2120

100n

2124

3110

10K

F113

10K

3130

F106

1008

1

PGND

7301

BC848B

F131

F118

F130

SGND

F127

+12V

100n

2106

14

6

74HCT00D

7110-B

4

5

7

10n

2282

560R

1

3115

4K7

3107

47K

3103

1027

2100

100n

3132

22K

2109

22n

2110

100n

SGND

100n

2221

1002

PH-B

1

2

3

4

+3V3

F128

F135

F145

F120

F138

0R

3148

3152

0R

SGND

SGND

3145

270R

1

1025

1

F107

SGND

1024

SGND

SGND

100n

2102

47u

2125

F100

F101

F104

3137

2115

100n

SGND

+3V3

270R

12K

3151

3149

1K

3150

12K

2123

330p

2122

12n

F105

F111

1026

1

F102

100R

3277

8K2

3114

+12V

3278

100R

F301

3146

100K

F116

2107

F114

1000-14

14

47K

3116

47u

1000-13

13

SGND

F134

F137

F141

F140

F136

1R

3154

F133

F103

F112

F115

F117

3157

12K

F109

12K

3156

330p

2127

1K2

3158

8

11

15

10n

2126

14

10

2

1

6

7

16

13

9

12

5

3

4

1n

2103

TDA7073A

7022

SGND

270R

3138

F300

22u

2116

F132

F125

F129

270R

3142

1R

3131

HOMESW

TRAYSW

TRAYIN

TRAYOUT

SL

SL

HALL+

HALL-

STBY

MOT_SW

MOT1

MOT1

MOT_UP

+5VX

FO

FO

RA

RA

+5VY

UCOIL

VCOIL

WCOIL

U+

U-

V+

V-

W+

W-

T1

T2

CD MAIN BOARD - CIRCUIT DIAGRAM 1B

SERVO DRIVERS PART

5V8

5V8
5V8

5V8

5V8

5V8
5V8

5V8

5V

5V

1V6

1V6

1V6

1V6

1V6
1V6

11

12

13

14

15

16

17

18

19

Input voltage Level Tolerance Unit

H2.80.1V
M2.50.1V
L2.20.1V

Input conditions conn 1006 pin Outputs conn 1006 Test points on driver

684 732 9 10 11 18 17 16

U+ U- V+ V- W+ W- UCOIL VCOIL WCOIL HALL_U HALL_V HALL_W

L M H M M M 6V 0V 0V 0V 5V
H M L M M M 0V 6V 6V 5V 0V
M M L M H M 0V 6V 0V 0V 5V
M M H M L M 6V 0V 6V 5V 0V
H M M M L M 0V 0V 6V 5V 0V
L M M M H M 6V 6V 0V 0V 5V

CL 96532086_016.eps

080999

TO TRAY
SWITCH
& MOTOR

TO SLEDGE
SWITCH
& MOTOR

TO CDM
VAM1250

TO TURN TABLE
MOTOR

2-7 2-8

CD diagram 1C

DIGITAL

INTERFACE

CONTROL

INTERFACE

DAC DAC

VOLUME/MUTE/DE-EMPHASIS

INTERPOLATION

NOISE SHAPER

SYS

CLK

1234567

2203 H6

B

C

D

E

F

G

H

CL16

LASEROFF

CRIN

CL11

SCLK

GND

GND

V4

CFLG

GND

DOBM

WCLK

GND

DATA

GND

1208-22 D11
1208-3 G11
1208-4 H11
1208-5 H11
1208-6 I11
1208-8 B11
1208-9 C11
1209-1 H11
1209-2 H11

3260 I8

1209-3 H11
1209-4 I11
1209-5 I11
1209-6 I11
1209-7 G11
1210-10 A11
1210-11 F11

8 9 10 11

1234567891011

A

2180 F5
2181 F6
2187 F5
2188 F6
2190 F8
2197 H9
2199 H9
2202 H8

F323 F10

2204 H6
2208 H9
2211 I9
2214 I8
2216 G8
2217 G9
2218 B8

I

A

B

C

D

E

F

G

H

I

1208-10 C11
1208-11 C11
1208-12 D11
1208-13 D11
1208-14 A11
1208-2 B11

3241 H7
3242 H9
3243 H8
3245 H8
3248 I7
3254 I7
3256 I9
3258 I7

3263 G8
3271 G8
3361 H7
7120-A G8
7120-B I8
7309 F5
7310 F7
F142 A9

1210-12 F11
1210-13 F11
1210-14 F11
1210-15 F11
1210-16 G11
1210-3 A11
1210-4 A11
1210-5 E11
1210-6 E11
1210-7 C11
1210-8 B11
1210-9 D11
2153 C9
2158 D9
2165 D9
2176 E9

F195 H7
F196 H7
F197 G8
F198 I8
F199 H8
F307 B10
F317 E7
F320 F10

F179 F7
F185 F6
F186 F5
F187 G8
F188 G9
F189 H6
F193 H9
F194 H5

2219 B10
2234 G7
2235 I7
2252 I9
3153 A9
3175 B9
3215 F5
3216 F6
3217 E7
3218 E7
3226 F8
3227 F7
3233 G8
3235 G7
3236 G7
3237 G7

F325 G10
F329 G10
F350 G7
F351 G7
F352 G7
F353 H10
F354 I9
F355 I10

F148 B9
F150 B9
F152 C9
F158 C9
F161 D9
F169 D9
F176 E9

F158

1210-12

12

1u

2203

AGND

47p

2199

100R

3153

+3V3

AGND

47p

2158

2211

47p

AGND

2153

47p

F198

100n

2216

F323

2217

47p

F320

AGND

10

1208-9

9

1208-2

2

1208-10

2181

22u

3216

4R7

2188

100n

F353

F317

22K

3258

22K

3254

1208-8

8

F307

1208-14

14

2252

1n

AGND

AGND

AGND

AGND

AGND

AGND

47p

2218

7120-A

3

2

1

8

4

A3V3

TDA1308T

2202

100p

47K

3245

AGND

CDR99

PB CD MAIN 4236

3104 123 4236

3

F199

1210-15

15

1210-16

16

1208-3

1210-14

14

1210-13

13

7120-B
TDA1308T

5

6

7

8

4

AGND

2219

47p

3241

22K

F189

AGND

1208-6

6

100n

2204

F350

3218

1K

1210-5

5

1208-4

4

1208-5

5

100n

2190

10K

3226

13

VDDA4VDDD

14

VOL

16

VOR

VREF-DAC

1215

VSSA5VSSD

2

WS

AGND

UDA1320ATS/N2

7309

APPL0

11

APPL1

10

9

APPL2

APPL3

8

APPSEL

71

BCK

DATAI

3

6

F186

A3V3

1209-7

7

F185

2165

47p

AGND

8

1210-7

7

1208-13

13

1210-8

F325

F194

+3V3

3

F195

1210-10

10

1210-3

1210-4

4

3263

2R2

F150

A3V3

A12V

6

3260

47K

3

1209-4

4

1209-6

F354

1209-3

F355

22

F196

F329

11

1208-12

12

1208-22

F152

1208-11

1209-1

1

+3V3

22u

2180

4R7

3215

22K

3233

100n

2187

7310

BC847B

F351

F352

F188

F193

AGND

AGND

47u

2235

47u

2197

2208

47u

10K

32423256

10K

100R

3175

F179

1210-9

9

1210-6

6

3361

100R

F187

F197

3271

100R

2234

47u

2

10K

3227

1209-2

3237

0R

3217

10K

0R

3236

3235

0R

2214

100p

47p

2176

3248

22K

F176

F161

F148

F169

22K

3243

1210-11

11

F142

1209-5

5

CL16

DATA

DATA

WCLK

SCLK

CL11

LASEROFF

DOBM5_CD

CFLG

CRIN

V4

MUTE

DATA_IN

SCLK_IN

WCLK_IN

DOBM5_CD

CD MAIN BOARD - CIRCUIT DIAGRAM 1C

AUDIO PART

MSBMSB LSB

0.5uS/DIV

32

WCLK

SCL

DATA

RIGHT CHANNEL

44,1KHz

2,1168MHz

LEFT CHANNEL

20

21

22

20 21 22

ANALOG
OUT

23

24

I2S
BUS

0V

TRACK 10 1KHz 0dB

GENERAL PURPOSE TEST

2ms/DIV

5Vpp

23

24

CL 96532086_017.eps

080999

CONN. 1208 : TO CDR MAIN BOARD
CONN. 1209 : TO MAIN BOARD PP16

2-9 2-10

CD diagram 2

3329

5

I

9101112 136

1205 F7
1206 D12
1207 E12
1208-1 E13
1208-15 E13
1208-16 D13
1208-17 E13
1208-18 I13
1208-19 H13
1208-20 I13
1208-21 I13

2300 B6
2301 B6

1210-1 A13

3

1322 G9

2304 E12
2306 E11
2307 E12
2309 G8
2320 H13

3300 A4

1210-2 A13

2303 C12

3305 A5
3306 A5
3307 A5
3308 B7
3309 B3

2321 I13
2322 I13

2305

2308

T1

1 456789101112

3326

13

12

3327

7210

7211

3114

3208

3360 E11

TRAY

3344 E12
3345 E12
3346 B4
3350 F1
3351 C3
3352 C4

A

B

C

D

E

F

1208-7 G13

H

I

A

B

C

D

E

F

G

H

3329

ON_TRACK

3115

MUTE

3330

3311

2327 C11

2326 E13

3303 A5
3304 A4

2302 C10

uP3V3

uP5V

3330

3342 C2

3310 B3
3311 B7
3312 C1
3313 C2
3314 D2
3318 D5

2

3319 D5
3320 D7
3328 F7
3331 G7
3332 G9
3333 G9
3334 G8
3335 H7
3337 I7
3339 I7

3327

3326

3355 E5
3356 E5

34

3359 C10

3353 E4
3354 E5

3357 D9
3358 D9

78

G

6201 H9
7005-A F1
7005-C G1
7202 C6
7203 D1
7204 C12
H401 A12
H402 A13
H403 B12
H404 B13

T2

VPROC

3999 A13

3302 A5

2325 E13

+12V

3334

100R

0R

3345

10K

3305

VPROC

1210-1

1

0R

3360

VPROC

100R

3356

3339

10K

47u

2301

2320

47p

MP

1206

1A

F223

100n

F231

VPROC

2327

F250

100R3320

VPROC

F227

+5V

+3V3

F230

10K

3342

F229

1M

3328

1208-20

20

2322

47p

1208-17

17

VPROC

1208-16

16

VPROC

+5V

4

RST

38

VCC

16

VSS

15

XTAL1

14

XTAL2

1A

1207

MP

19

P2-1

20

P2-2

21

P2-3

22

P2-4

23

P2-5

24

P2-6

25

P2-7

5

P3-0|RxD

7

P3-1|TxD

8

P3-2|INT0n

9

P3-3|INT1n

P3-4|T0

10

11

P3-5|T1

12

P3-6|WRn

13

P3-7|RDn

26

PSENn

36

P0-1|AD1

35

P0-2|AD2

34

P0-3|AD3

33

P0-4|AD4

32

P0-5|AD5

31

P0-6|AD6

30

P0-7|AD7

40

P1-0

41

P1-1

42

P1-2

43

P1-3

44

P1-4

1

P1-5

P1-6|SCL

2

3

P1-7|SDA

18

P2-0

S87C654

7202

27

ALE|PROGn

29

EAn|VPP

28

NC1

6

NC2

NC3

39

17

NC4

37

P0-0|AD0

3359

0R

1K

3312

1210-2

2

100R

3354

6201

BAS216

F202

100R

3331

F200

3999

1K

220u

2304

VPROC

HFGND

10u

2302

VPROC

SGND

F220

3355

100R

F208

3313

10K

VPROC

F240

F241

3311

2R2

100n

2326

10K

3332

2325

100n

F226

F224

LD1117

7204

1

GND

3IN2

OUT

F209

+3V3

HFGND

F212

F216

3346

10K

3352

0R

H402

1

2

A12V

EVQ21

1322

F221

PGND

10K

3300

F207

3357

1K

1208-1

1

3350

1K

100u

2307

100n

2300

1K

3309

1K

3310

F204

F213

+5VY

F203

3303

F225

10K

100R

3333

F218

F211

+5V

3344

0R

F219

F215

10K

3304

10K

3307

1208-21

21

+5VY

+3V3

10K

3306

10K

3314

3353

100R

VPROC

19

VPROC

+5V

VPROC

A3V3

1208-19

+12V

2

VPROC

VPROC

+5V

H401

1

0R

3351

0R

3358

F242

2306

330n

F210

F214

F222

10K

3302

VPROC

3104 123 4236

PB MAIN CD-4236
CDR99

VPROC

F217

1208-18

18

F201

10K

3337

1

2

H403

1

2

47p

2321

H404

7203

BC848B

7005-C
74HCT08D

9

10

8

14

7

F206

4u7

2309

100n

2303

100R

3318

3335

10K

100R 3319

1208-15

15

1205

CST

7

74HCT08D

7005-A

1

2

3

14

7

2R2

3308

1208-7

MUTE

HFDET

F228

S2

S1

STBY

DSA_RST

MOT_SW

TRAYSW

TRAYIN

TRAYOUT

RW

RESET

MOT_UP

SCL

HOMESW

SDA

LASEROFF

SILD

DSA_STROBE

DSA_STROBE

DSA_DATA

DSA_ACK

T2

T1

CD MAIN BOARD - CIRCUIT DIAGRAM 2
MICROPROCESSOR PART

DSA
BUS

25

26

28

27

+5V

+12V

S2 S1

000
1
11

n=1 disc start up
n=1 disc play
n=2 disc play

29 30

12MHz

CL 96532086_018.eps

080999

CONN. 1208 : TO CDR MAIN BOARD

2-11 2-12

CD top

CD MAIN BOARD - TOP VIEW

CL 96532086_019.eps

080999

2.3 PARTS LOCATION

2-13 2-14

CD bottom

CD MAIN BOARD - BOTTOM VIEW

2

3

11

4

5

6

7

8

9

10

1

12

13

14

15

16

17

18

19

21

20

22

23

24

27

28

26

25

30

29

CL 96532086_020.eps

080999

2-15 2-16

2.4 EXPLODED VIEW
CD LOADER VAL1250

CLAMPER ASSY

SUSPENSION

RACK SPRING

RACK

RUBBER

SWITCH

RUBBER

PLUG

TRAY GEARWHEEL

PLUG

TULE

RACK GEARWHEEL

BELT

PULLEY WHEEL

TRAY HORIZONTAL

CDM VAM1250

MOTORSPRING

SUSPENSION

SUB CHASSIS

RUBBER

SUSPENSION

SUSPENSION

RUBBER

CHASSIS ASSY VAL1250

TRAY MOTOR ASSY

MOTORSPRING

SCREW

SCREW

CD Loader VAL1250

0001 3104 147 14100 CHASSIS ASSY LOADER

VAL 1250
0002 4822 361 11131 TRAY MOTOR ASSY
0003 4822 492 11709 MOTOR SPRING
0004 4822 277 11838 SWITCH
0006 4822 532 13097 TULE
0010 4822 528 11295 PULLEY WHEEL
0011 4822 358 10266 BELT, DRIVING
0012 4822 522 10739 RACK GEAR WHEEL
0013 4822 535 10588 PIN, PLASTIC
0014 4822 522 10741 TRAY GEAR WHEEL
0015 4822 535 10588 PIN, PLASTIC
0016 4822 402 11221 RACK
0017 4822 492 11711 RACK SPRING
0020 4822 466 12131 CUSHION RUBBER
0021 4822 466 12131 CUSHION RUBBER
0022 4822 466 12131 CUSHION RUBBER
0023 4822 466 12131 CUSHION RUBBER
0030 9305 022 25001 CDM VAM 1250
0035 3104 144 02030 SUSPENSION
0036 3104 144 02030 SUSPENSION
0037 3104 144 02030 SUSPENSION
0038 3104 144 02030 SUSPENSION
0040 3104 144 05870 SUB-CHASIS
0042 4822 492 11709 MOTOR SPRING
0043 4822 418 10421 TRAY HORIZONTAL
0045 3104 147 13910 CLAMPER ASSY VAL 1250
8001 3104 148 01310 LED ASSY 4P

2-17

2.5 ELECTRICAL PARTS LIST

2-18
