Makita CB100DA User guide

Cordless Heated Blanket
DCB200 / CB100D

Satisfy Professional's Needs

Excellent usability and Warm

Brown Black

Power button

To turn on the blanket, press and hold the
power button for a few seconds. To turn off,
press and hold the power button again.

Temperature adjustment

There are three temperature settings
(high, medium, low)

Low

35h*

Heat Zone

700

mm

Medium

High

*Continuous runtime on a single full battery charge

with BL1860B (18V-6.0Ah Battery)

20h*

10h

*

Battery pocket

The battery holder (with battery cartridge)
can be stored in the battery pocket.

1.5m Extension cord

If you put the battery holder out of the
battery pocket, connect the extension
cord between the jack of the power cord
and the plug of the battery holder.

1400

mm

3-in-1 versatile blanket

By fastening the snap buttons and
strap on the blanket, you can use
the blanket for warming up your
shoulders and waist.

Machine-washable and
machine-dryable

Be sure to remove the battery holder from
the blanket before washing and drying.

Longer continuous run time on a single full battery charge

Li-ion BatteryBattery holderModel No.

18V

DCB200

12Vmax

CB100D

Cordless Heated Blanket DCB200 / CB100D

DCB200

Outer: 100% Polyester / Batting: 100% Polyester / Liner: 100% Polyester
BL1860B:Low / Med / High: 35 / 20 / 10
Upper Center: 1
High / Medium / Low
High: 9.5 W
Med : 4.5 W
Low: 2.3 W
700x1,400 mm (27-1/2"x55")

0.58 kg (1.28 lbs.)

Standard Equipment :

Battery Holder, Storage bag, 1.5m Extension cord

Material
Run Time (hrs)
Heat Zone
Heat Settings
Heat Value

Dimensions (L x W)
Net weight*

*Approximate weight without battery holder, battery cartridge, extension cord, and storage bag.

Continuous run time
Low / Medium / High

BL1860B6.0Ah

BL1850B5.0Ah

BL1840B4.0Ah

BL1830B3.0Ah

BL1820B2.0Ah

BL1815N1.5Ah

BL1041B4.0Ah

BL1021B2.0Ah

BL10161.5Ah

CB100D

BL1041B: Low / Med / High: 14 / 7.5 / 4
Upper Center: 1
High / Medium / Low
High: 9.5 W
Med : 4.5 W
Low: 2.3 W
700x1,400 mm (27-1/2"x55")

0.58 kg (1.28 lbs.)

Items of standard equipment and specifications may vary by country or area.

35 / 20 / 10 h

with BL1860B

14 / 7.5 / 4 h

with BL1041B

Makita Corporation

3-11-8 Sumiyoshi-cho, Anjo, Aichi, 446-8502 Japan

PRINTED IN JAPAN 201908
