BJV140Z
14.4V JIG SAW (LI-ION)
1
2
3
46
47
44
48
45
49
17
50
54
18
57
56
53
55
14
19
21
20
22
23
24
1
51
52
59
26
29
30
31
32
13
43
12
11
10
9
7
8
6
5
27
28
33
34
35
36
37
38
4
39
58
70
69
71
61
62
68
67
60
42
41
63
64
65
66
Page 2
Item No Type Ref Part No Description Qty Unit
1 188206-1 HANDLE SET 1 SET
2 266048-4 TAPPING SCREW 4X40 1 PC.
3 266091-3 TAPPING SCREW 4X50 1 PC.
4 265995-6 TAPPING SCREW 4X18 5 PC.
5 442138-9 PACKING 1 PC.
6 214031-5 PLANE BEARING 4 1 PC.
7 232207-2 LEAF SPRING 1 PC.
8 256117-9 PIN 4 1 PC.
9 911111-5 PAN HEAD SCREW M4X10 2 PC.
10 911111-5 PAN HEAD SCREW M4X10 2 PC.
11 345240-6 LINEAR GUIDE 1 PC.
12 345240-6 LINEAR GUIDE 1 PC.
13 153338-3 GEAR HOUSING COVER COM. 1 PC.
INC.
13
13
13
253313-0 THIN WASHER 14 1 PC.
INC.
257250-0 RING 20 1 PC.
INC.
421815-6 DUST SEAL 8 1 PC.
14 631744-7 LIGHT CIRCUIT 1 PC.
15 689070-8 HEAT SINK 1 PC.
16 911006-2 PAN HEAD SCREW M3X8 1 PC.
17 232152-1 LEAF SPRING 1 PC.
18 419613-0 LOCK OFF BUTTON 1 PC.
19 650584-4 SWITCH C3LA-2A-PLSR 1 PC.
20 233118-4 COMPRESSION SPRING 4 1 PC.
21 419754-2 SWITCH LEVER 1 PC.
22 324233-6 SAFETY WIRE 1 PC.
23 266034-5 TAPPING SCREW CT 4X16 4 PC.
24 643811-6 TERMINAL 1 PC.
26 268090-1 PIN 4 1 PC.
27 961017-7 STOP RING E-3 1 PC.
28 310134-4 SLIDER 1 PC.
29 231659-4 TORSION SPRING 6 1 PC.
30 419820-5 TOOL OPENER 1 PC.
31 265026-1 + PAN HEAD SCREW M4 1 PC.
32 310135-2 PUSH PIN 1 PC.
33 421817-2 DUST COVER 1 PC.
34 962068-3 RETAINING RING R-18 1 PC.
35 165326-8 ROD 1 PC.
36 231660-9 TORSION SPRING 15 1 PC.
37 310136-0 BLADE HOLDER 1 PC.
38 188208-7 MOTOR HOUSING SET 1 SET
39 265995-6 TAPPING SCREW 4X18 4 PC.
41 638504-8 ENDBELL COMPLETE 1 PC.
42 638373-7 YOKE UNIT 1 PC.
43 619204-9 ARMATURE 1 PC.
44 961004-6 RETAINING RING S-8 1 PC.
45 212014-9 NEEDLE BEARING 407 1 PC.
46 265353-6 HEX. SOCKET HEAD BOLT M4X12 2 PC.
47 153336-7 CRANK COMPLETE 1 PC.
48 313108-4 BALANCE PLATE 1 PC.
49 158168-7 GEAR COMPLETE 1 PC.
50 345235-9 PUSH PLATE 1 PC.
51 253877-4 FLAT WASHER 8 1 PC.
52 266050-7 TAPPING SCREW 4X30 4 PC.
53 961018-5 STOP RING E-5 1 PC.
2 MODEL BJV140Z (Updated:4/15/2013)
Page 3
Item No Type Ref Part No Description Qty Unit
54 417839-8 SEAL PLATE 1 PC.
55 286032-3 CAP 5 1 PC.
56 233139-6 COMPRESSION SPRING 3 1 PC.
57 272244-4 LEVER 17 1 PC.
58 268063-4 PIN 4 1 PC.
59 158169-5 GEAR HOUSING COMPLETE 1 PC.
60 252171-1 SQUARE NUT M5-8 1 PC.
61 421816-4 DUST SEAL 1 PC.
62 153334-1 RETAINER COMPLETE 1 PC.
64
64
1
2
191971-3 CARBON BRUSH CB-430, 2PCS/SET, W/O ORIGIN 1 SET
195018-5 CARBON BRUSH CB-430, 2PCS/SET, W/ORIGIN 1 SET
65 643807-7 BRUSH HOLDER CAP 2 PC.
66 232208-0 LEAF SPRING 1 PC.
67 922226-3 HEX. SOCKET HEAD BOLT M5X18 1 PC.
68 345237-5 CRANK PLATE 1 PC.
69 317565-8 BASE 1 PC.
70 912107-9 COUNTERSUNK HEAD SCREW M4X8 4 PC.
71 345238-3 BASE PLATE 1 PC.
100 652038-7 PAN HEAD SCREW M3X8 (F/SWITCH) 2 PC.
101 654037-5 INSULATED TERM. RBV1.25-3.5T (F/SWITCH - TERMINAL) 2 PC.
102 654208-4 RECEPTACLE (F/END BELL) 2 PC.
ACCESSORIES
- See Catalogue or visit www.makita.ca for more accessories information -
A01 415524-7 ANTI-SPLINTERING DEVICE 1 PC.
A02 417852-6 COVER PLATE 1 PC.
A03 792724-9 JIG SAW BLADE, 2PC EACH of B-22, B-10, BR-13 1 SET
A03
A03
A03
3
2
3
792473-8 JIG SAW BLADE B-22, 5PC/SET 1 SET
792529-7 JIG SAW BLADE B-10, 5PC/SET 1 SET
792729-9 JIG SAW BLADE BR-13, 5PC/SET 1 SET
A04 783202-0 HEX. WRENCH 4 1 PC.
A05 193516-3 GUIDE RULE SET 1 PC.
INC.
A05
A05
A05
271601-3 KNOB 20 1 PC.
INC.
323802-0 GUIDE PIN 1 PC.
INC.
922207-7 HEX. SOCKET HEAD BOLT M5X10 1 PC.
A06 P-80020 DUST NOZZLE 1 PC.
A07
A07
A07
A07
A08
A08
1
1 INC.
2
2 INC.
1
2
824775-5 PLASTIC CARRYING CASE 1 PC.
450909-0 LATCH 2 PC.
141486-0 PLASTIC CARRYING CASE COMPLETE 1 PC.
450909-0 LATCH 2 PC.
DC18RA CHARGER DC18RA 1 PC.
DC18RC CHARGER DC18RC 1 PC.
A08 DC18SD CHARGER DC18SD 1 PC.
A08 DC18SE 12V AUTOMOTIVE CHARGER DC18SE 1 PC.
A09 194066-1 14.4V LI-ION BATTERY BL1430(3.0AH) 1 PC.
A10 450128-8 BATTERY COVER F/LI-ION BATTERY 1 PC.
A11 194649-7 BATTERY PROTECTOR (BL1430, BL1830) 1 PC.
A12 193517-1 GUIDE RAIL ADAPTOR 1 PC.
A13 194368-5 GUIDE RAIL 1400MM 1 PC.
A13 194367-7 GUIDE RAIL 3000MM 1 PC.
3 MODEL BJV140Z (Updated:4/15/2013)
