Macromedia Illustrator - CS3 User Guide

SCRIPTING GUIDE

Adobe

Illustrator® CS3 Scripting Guide for Windows® and Mac OS®.

NOTICE: All information contained herein is the property of Adobe Systems Incorporated. No part of this publication (whether in hardcopy or electronic form) may be reproduced or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Adobe Systems Incorporated. The software described in this document is furnished under license and may only be used or copied in accordance with the terms of such license.

This publication and the information herein is furnished AS IS, is subject to change without notice, and should not be construed as a commitment by Adobe Systems Incorporated. Adobe Systems Incorporated assumes no responsibility or liability for any errors or inaccuracies, makes no warranty of any kind (express, implied, or statutory) with respect to this publication, and expressly disclaims any and all warranties of merchantability, fitness for particular purposes, and noninfringement of third party rights.

Any references to company names in sample templates are for demonstration purposes only and are not intended to refer to any actual organization.

Adobe, the Adobe logo, Illustrator, Photoshop, and InDesign are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.

Apple, Mac, Macintosh, and Mac OS are trademarks of Apple Computer, Inc., registered in the United States and other countries. Microsoft, and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and other countries. JavaScript and all Java-related marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and other countries. UNIX is a registered trademark of The Open Group.

All other trademarks are the property of their respective owners.

If this guide is distributed with software that includes an end user agreement, this guide, as well as the software described in it, is furnished under license and may be used or copied only in accordance with the terms of such license. Except as permitted by any such license, no part of this guide may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, recording, or otherwise, without the prior written permission of Adobe Systems Incorporated. Please note that the content in this guide is protected under copyright law even if it is not distributed with software that includes an end user license agreement.

The content of this guide is furnished for informational use only, is subject to change without notice, and should not be construed as a commitment by Adobe Systems Incorporated. Adobe Systems Incorporated assumes no responsibility or liability for any errors or inaccuracies that may appear in the informational content contained in this guide.

Adobe Systems Incorporated, 345 Park Avenue, San Jose, California 95110, USA.

1 Introduction ................................................................................................................................. 6

What is scripting? ........................................................................................................................................................................... 6

Why use scripting?................................................................................................................................................................... 6

What about actions? ............................................................................................................................................................... 7

Script support in Adobe Illustrator CS3.................................................................................................................................. 7

ExtendScript features ............................................................................................................................................................. 7

ExtendScript tools.................................................................................................................................................................... 7

Script file extensions ..................................................................................................................................................................... 8

Viewing sample scripts................................................................................................................................................................. 8

Viewing the object model........................................................................................................................................................... 8

Viewing the JavaScript object model ............................................................................................................................... 8

Viewing the AppleScript object model............................................................................................................................ 9

Viewing the VBScript object model................................................................................................................................... 9

Executing scripts...........................................................................................................................................................................10

Installing scripts in the Scripts menu..............................................................................................................................10

Executing scripts from the Other Scripts menu item................................................................................................10

Startup scripts (.jsx scripts only) .......................................................................................................................................10

Application-specific startup scripts folder..............................................................................................................10

General startup scripts folder......................................................................................................................................11

Changes since earlier versions.................................................................................................................................................11

Known Issues .................................................................................................................................................................................13

2 The Illustrator Scripting Object Model .................................................................................... 15

Object naming conventions.....................................................................................................................................................15

Top-level (containing) objects.................................................................................................................................................16

Application...............................................................................................................................................................................16

Document.................................................................................................................................................................................16

Layer ...........................................................................................................................................................................................17

The artwork tree............................................................................................................................................................................17

Art styles....................................................................................................................................................................................18

Color objects............................................................................................................................................................................18

Text objects ...................................................................................................................................................................................19

Text frames...............................................................................................................................................................................19

Text geometry...................................................................................................................................................................19

Objects that represent text content................................................................................................................................20

Text ranges.........................................................................................................................................................................21

Text styles .................................................................................................................................................................................21

Dynamic objects and symbols ................................................................................................................................................21

Transformations............................................................................................................................................................................22

3 Scripting Illustrator ................................................................................................................... 23

Launching and quitting Illustrator from a script...............................................................................................................23

Launching and activating Illustrator...............................................................................................................................23

Quitting Illustrator .................................................................................................................................................................24

Working with objects .................................................................................................................................................................24

Getting the frontmost document or layer ....................................................................................................................24

Adobe Illustrator CS3

Scripting Guide Contents 4

Creating new objects............................................................................................................................................................25

Collection objects ..................................................................................................................................................................25

Selected objects .....................................................................................................................................................................26

Selecting text ....................................................................................................................................................................26

Selecting art items...........................................................................................................................................................26

Referring to selected art items....................................................................................................................................26

Notes on renaming objects stored in the application’s palettes..........................................................................26

Measurement units......................................................................................................................................................................27

Em space units ........................................................................................................................................................................27

Page item positioning and dimensions ...............................................................................................................................27

Art item bounds......................................................................................................................................................................28

Paths and shapes..........................................................................................................................................................................29

User interaction levels ................................................................................................................................................................29

Printing Illustrator documents ................................................................................................................................................30

4 Scripting with JavaScript .......................................................................................................... 31

Your first Illustrator script..........................................................................................................................................................31

Adding features to "Hello World".....................................................................................................................................32

Working with methods in JavaScript ....................................................................................................................................32

Accessing and referencing objects........................................................................................................................................33

Referencing the application object.................................................................................................................................33

Accessing objects in collections.......................................................................................................................................33

Creating new objects............................................................................................................................................................34

Working with selections ......................................................................................................................................................35

Selecting artwork objects .............................................................................................................................................35

Working with text frames..........................................................................................................................................................35

Threaded frames ....................................................................................................................................................................35

Threaded frames make a single story object.........................................................................................................36

Creating paths and shapes .......................................................................................................................................................36

Paths ...........................................................................................................................................................................................36

Specifying a series of x-y coordinates ......................................................................................................................36

Using pathPoint objects................................................................................................................................................37

Combining path point types .......................................................................................................................................38

Shapes........................................................................................................................................................................................39

Creating a rectangle .......................................................................................................................................................39

Creating a polygon..........................................................................................................................................................39

5 Scripting with AppleScript........................................................................................................ 40

Your first Illustrator script..........................................................................................................................................................40

Adding features to "Hello World".....................................................................................................................................41

Object references .........................................................................................................................................................................41

Obtaining objects from documents and layers ..........................................................................................................42

Creating new objects............................................................................................................................................................42

Working with selections ......................................................................................................................................................42

Selecting artwork objects .............................................................................................................................................43

Working with text frames..........................................................................................................................................................43

Threaded frames ....................................................................................................................................................................43

Threaded frames make a single story object.........................................................................................................44

Creating paths and shapes .......................................................................................................................................................44

Paths ...........................................................................................................................................................................................44

Specifying a series of x-y coordinates ......................................................................................................................44

Using path point objects...............................................................................................................................................44

Adobe Illustrator CS3

Scripting Guide 5

Combining path point types .......................................................................................................................................45

Shapes........................................................................................................................................................................................45

write-once access ............................................................................................................................................................46

Creating a rectangle .......................................................................................................................................................46

Creating a polygon..........................................................................................................................................................46

6 Scripting with VBScript ............................................................................................................. 47

Your first Illustrator script..........................................................................................................................................................47

Adding features to "Hello World".....................................................................................................................................48

Accessing and referencing objects........................................................................................................................................48

Obtaining objects from collections.................................................................................................................................48

Creating new objects............................................................................................................................................................49

Working with selections ......................................................................................................................................................49

Selecting artwork objects .............................................................................................................................................49

Working with text frames..........................................................................................................................................................50

Threaded frames ....................................................................................................................................................................50

Threaded frames make a single story object.........................................................................................................50

Creating paths and shapes .......................................................................................................................................................50

Paths ...........................................................................................................................................................................................50

Specifying a series of x-y coordinates ......................................................................................................................51

Using path point objects...............................................................................................................................................51

Combining path point types .......................................................................................................................................52

Shapes........................................................................................................................................................................................52

Creating a rectangle .......................................................................................................................................................52

Creating a polygon..........................................................................................................................................................52

Working with enumeration values.........................................................................................................................................53

Index ...........................................................................................................................................54

Introduction

This guide describes the scripting interface to Adobe® Illustrator® CS3. It contains the following sections:

● This introduction, which describes scripting support in Adobe Illustrator CS3, and lists changes to the

scripting interface since the previous release.

● “The Illustrator Scripting Object Model” on page 15, which describes the Illustrator document object

model.

● “Scripting Illustrator” on page 23, which provides an overview of how to use scripts to program Adobe

Illustrator CS3.

● “Scripting with JavaScript” on page 31, which provides information about scripting Illustrator using

JavaScript.

● “Scripting with AppleScript” on page 40, which provides information about scripting Illustrator using

AppleScript.

● “Scripting with VBScript” on page 47, which provides information about scripting Illustrator using

VBScript.

If you are new to scripting or would like basic information about scripting and how to use the different scripting languages, see Adobe Introduction to Scripting.

What is scripting?

A script is a series of commands that tells Illustrator to perform one or more tasks. These tasks can be simple, and affect only a single object in the current document; or complex, and affect objects in all of your Illustrator documents. The tasks might even involve other applications, such as word processors, spreadsheets, and database management programs.

The building blocks of scripting correspond for the most part to the Illustrator tools, menus, palettes, and dialog boxes with which you are already an expert. If you know what you’d like Illustrator to do, you can write a script to do it.

Why use scripting?

Graphic design is a field characterized by creativity, but aspects of the actual work are anything but creative. In fact, you’ll probably notice that the time you spend placing and replacing images, correcting errors in text, and preparing files for printing at an image setting service provider often reduce the time you have available for doing creative work.

With a small investment of time and effort—perhaps no more than you’d spend training an assistant—you can learn to write short, simple scripts that perform repetitive tasks for you. As your scripting skills grow, you can move on to more complex scripts that work all night while you’re sleeping.

Scripting can also enhance your creativity by quickly performing tasks you might not have time to try. For example, you could write a script to systematically create a series of objects, modifying the new objects’ position, stroke, and fill properties along the way. You could also write a script that accesses built-in transformation matrix functions to stretch, scale and distort a series of objects. Without scripting, you’ll likely miss out on the creative potential of such labor-intensive techniques.

Adobe Illustrator CS3

Scripting Guide Introduction 7

What about actions?

Actions and scripts are both ways of automating repetitive tasks, but they work very differently.

● Actions use a program’s user interface to do their work. As an action runs, menu choices are executed,

objects are selected, and recorded paths are created. Scripts do not use a program’s user interface to perform tasks, and can execute faster than actions.

● Actions have very limited facilities for getting and responding to information. You cannot add

conditional logic to an action. Therefore, actions cannot make decisions based on the current situation, such as changing the stroke type of rectangles but not ellipses. Scripts are capable of getting information and making decisions and calculations based on the information they receive from Illustrator.

● A script can execute an action, but actions cannot execute scripts.

Script support in Adobe Illustrator CS3

Illustrator scripting supports AppleScript and JavaScript scripts for Mac OS, or VBScript and JavaScript scripts for Windows.

Note: Additionally, Adobe scripting-enabled applications, including Illustrator, support ExtendScript,

Adobe’s extended implementation of ECMA JavaScript. ExtendScript files are distinguished by the

.jsx extension. Giving your JavaScript files a .jsx extension allows you to take advantage of the

ExtendScript features and tools.

ExtendScript features

● ExtendScript offers all standard JavaScript features, plus a development and debugging

environment, the ExtendScript Toolkit (ESTK). The ESTK is installed with all scriptable Adobe applications.

● The ESTK includes an Object Model Viewer that contains complete documentation of the

methods and properties of JavaScript objects.

Note: For information on accessing the ESTK and the Model Viewer, see “Viewing the JavaScript object

model” on page 8.

ExtendScript tools

ExtendScript also provides various tools and utilities such as:

● A localization utility

● Tools that allow you to combine scripts and direct them to particular applications

● Platform-independent file and folder representation

● Tools for building user interfaces to your scripts

● A messaging framework that allows you to send and receive scripts and data among

scripting-enabled Adobe applications

For details of these and additional features, see the JavaScript Tools Guide.

Adobe Illustrator CS3

Scripting Guide Introduction 8

Script file extensions

For a file to be recognized by Adobe Illustrator CS3 as a valid script file, the file must have the correct file name extension:

Script Type File Type Extension Platform

AppleScript compiled script

OSAS file

JavaScript

text

ExtendScript

VBScript text

Viewing sample scripts

Adobe provides sample scripts for many objects, properties, and methods in the Illustrator CS3 DOM. You can view script samples in two locations:

● In the /Scripting/Sample Scripts folder in your Illustrator CS3 installation directory

● In the Adobe Illustrator CS3 scripting reference for your scripting language, which is located in the

/Scripting/Documentation folder in your Illustratator CS3 installation directory.

Viewing the object model

The supported scripting languages each provide a facility for viewing the scripting objects defined by Illustrator, with reference details.

.scpt

.js .jsx

.vbs

(none)

Mac OS

Mac OS & Windows

Windows

Viewing the JavaScript object model

To view the JavaScript object model for Illustrator:

1. Start the ExtendScript Toolkit (ESTK).

Note: In a default Adobe installation, the ESTK is in the following location:

● In Mac OS:

system drive:Applications:Utilities:Adobe Utilities: ExtendScript Toolkit 2

● In Windows:

system drive\Program Files\Adobe\Adobe Utilities\ ExtendScript Toolkit 2

2. In the ESTK, choose Help > Illustrator CS3.

Note: Several extended sample scripts are available in the

your Illustrator CS3 installation directory.

You can also view script samples and information about individual classes, objects, properties, methods and parameters in the Adobe Illustrator CS3 JavaScript Reference, which is found in the

/Scripting/Documentation folder in your Illustrator CS3 installation directory.

/Scripting/Sample Scripts folder in

Adobe Illustrator CS3

Scripting Guide Introduction 9

Viewing the AppleScript object model

Apple provides a Script Editor with all Mac OS systems. You can use Script Editor to view the AppleScript dictionary that describes Illustrator objects and commands.

Note: For details of how to use the Script Editor, see Script Editor Help.

1. Start Script Editor.

Note: In a default Mac OS installation, Script Editor is in Applications:AppleScript:Script Editor. If you

cannot find the Script Editor application, you must reinstall it from your Mac OS system CD.

2. Choose File > Open Dictionary. Script Editor displays an Open File dialog.

3. In the Open File dialog, find and select Illustrator, and then click OK.

Script Editor displays a list of the Illustrator objects and commands, which includes the properties and elements associated with each object and the parameters for each command.

Note: Several extended sample scripts are available in the

your Illustrator CS3 installation directory.

You can also view script samples and information about individual classes, objects, properties, methods and parameters in the Adobe Illustrator CS3 AppleScript Reference, which is found in the

:Scripting:Documentation folder in your Illustrator CS3 installation directory.

Viewing the VBScript object model

VBScript provides a type library that you can use to view Illustrator object properties and methods. This procedure explains how to view the type library through any Microsoft Office program. Your VBScript editor most likely provides access to the library. Consult your editor’s Help for information.

1. In any Microsoft Office application, choose Tools > Macro > Visual Basic Editor.

2. In the Visual Basic Editor, choose Tools > References.

3. In the dialog that appears, select the check box for Adobe Illustrator CS3 Type Library, and then click OK.

4. Turn on the Adobe Illustrator CS3 Type Library option from the list of available references and click OK.

5. Choose View > Object Browser to display the Object Browser window.

6. Choose "Illustrator" from the list of open libraries in the top-left pull-down menu of the Object Browser window.

:Scripting:Sample Scripts folder in

Note: Several extended sample scripts are available in the

your Illustrator CS3 installation directory.

You can also view script samples and information about individual classes, objects, properties, methods and parameters in the Adobe Illustrator CS3 VBScript Reference, which is found in the

/Scripting/Documentation folder in your Illustrator CS3 installation directory.

/Scripting/Sample Scripts folder in

Adobe Illustrator CS3

Scripting Guide Introduction 10

Executing scripts

The Illustrator interface includes a Scripts menu (File > Scripts) that provides quick and easy access to your scripts.

● Scripts can be listed directly as menu items that run when you select them. See “Installing scripts in the

Scripts menu” on page 10.

● You can also navigate from the menu to any script in your file system, and then run the script. See

“Executing scripts from the Other Scripts menu item” on page 10

You can also have JavaScript scripts with a application. For information, see “Startup scripts (.jsx scripts only)” on page 10

.jsx extension start automatically when you launch the

Installing scripts in the Scripts menu

To include a script in the Scripts menu (File > Scripts), save the script in the Scripts folder, which is located in the /Illustrator CS3/ Presets folder in your Illustrator CS3 installation directory. The script’s file name, minus the file extension, appears in the Scripts menu.

Note: Scripts that you add to the Scripts folder while Illustrator is running do not appear in the Scripts

menu until the next time you launch Illustrator.

Any number of scripts can be installed in the Scripts menu. If you have a large collection of scripts, use subfolders in the Scripts folder to help organize the scripts in the Scripts menu. Each subfolder is displayed as a separate submenu containing the scripts in that subfolder.

Executing scripts from the Other Scripts menu item

The Other Scripts item at the end of the Scripts menu (File > Scripts > Other Scripts) allows you to execute scripts that are not installed in the Scripts folder.

Selecting Other Scripts displays a Browse dialog, which you use to navigate to a script file. When you select the file, the script is executed.

Note: Only files that are of one of the supported file types are displayed in the browse dialog. For

information, see “Script support in Adobe Illustrator CS3” on page 7

Startup scripts (.jsx scripts only)

JavaScript scripts with a .jsx file extension can be installed in one of two folders so that the scripts run automatically when you launch Illustrator and each time you run a script. The folders are:

● An application-specific startup scripts folder, which contains scripts for Illustrator CS3

● A general startup scripts folder, which contains scripts that run automatically when you start any

Creative Suite 3 application

Application-specific startup scripts folder

You must place application-specific startup scripts in a folder named Startup Scripts, which you create in the Illustrator installation directory.

Adobe Illustrator CS3

Scripting Guide Introduction 11

For example, when Illustrator CS3 is installed to its default location, you would create the Startup

Scripts

● In Windows:

folder at:

C:\Program Files\Adobe\Adobe Illustrator CS3\Startup Scripts\

● In Mac OS:

/Applications/Adobe Illustrator CS3/Startup Scripts/

Note: JavaScript scripts with a .jsx extension placed in the Startup Scripts folder run automatically

when:

● The application is launched.

● Any JavaScript file is selected from the Scripts menu (File > Scripts).

General startup scripts folder

The general startup scripts folder contains scripts that run automatically when you start any Creative Suite 3 application. You create the folder in the following location:

● In Windows:

Program Files/Common Files/Adobe/Startup Scripts CS3/Illustrator

● In Mac OS:

:Library:Application Support:Adobe:Startup Scripts CS3:Illustrator

Note: If a script in the general startup folder is meant to be executed only by Illustrator, the script must

include the ExtendScript

#target directive (#target illustrator) or code such as the

following:

if( BridgeTalk.appName == "illustrator" ) { //continue executing script }

For additional details, see the JavaScript Tools Guide.

Changes since earlier versions

The following changes have been made to the scripting object model to support features in Adobe Illustrator CS3:

● Create documents using the document preset object, which contains properties for color mode,

height and width, preview mode, title, and other document-defining characteristics:

● JavaScript: app.documents.addDocument(), uses new object documentPreset;

app.startupPresetsList gives available presets; app.getPresetSettings() returns a documentPreset object.

● VBScript: App.Documents.AddDocument, uses new object DocumentPreset;

App.StartupPresetsList gives available presets; App.GetPresetSettings returns a DocumentPreset object.

● AppleScript: add document command, uses new object document preset; the startup

presets property gives available presets, get preset settings command returns a document preset

● Undo and redo operations:

object.

Adobe Illustrator CS3

Scripting Guide Introduction 12

● JavaScript: app.undo(), app.redo()

● VBScript: App.Undo(), App.Redo()

● AppleScript: undo and redo commands

● Clipboard operations, previously available only in AppleScript, are supported in VBScript and

JavaScript. These methods belong to the

● JavaScript: app.cut(), app.copy(), app.paste()

● VBScript: App.Cut, App.Copy, App.Paste

● Additional control of color:

● JavaScript: app.loadColorSettings(), which loads color settings from a specified file;

application object but act upon the current selection:

app.colorSettingsList gives available files.

● VBScript: App.LoadColorSettings; App.ColorSettingsList gives available files.

● AppleScript: load color settings command; the color settings property gives available

files.

● New properties for raster item objects

● JavaScript: rasterItem.overprint, rasterItem.colorizedGrayscale,

rasterItem.transparent, rasterItem.channels, rasterItem.bitsPerChannel, rasterItem.colorants

● VBScript: RasterItem.Overprint, RasterItem.ColorizedGrayscale,

RasterItem.Transparent, RasterItem.Channels, RasterItem.BitsPerChannel, RasterItem.Colorants

● AppleScript: bits per channel, channels, colorants, colorized, overprint,

transparent

● Capturing clipping-area content to a raster file:

● JavaScript: document.imageCapture(); uses new object imageCaptureOptions

● VBScript: Document.ImageCapture; uses new object ImageCaptureOptions

● AppleScript: image capture command, uses new object image capture options

● Merging of graphic styles:

● JavaScript: graphicStyle.mergeTo()

● VBScript: GraphicStyle.MergeTo

● AppleScript: merge command

● Support for indicating the length (in points) of a path:

● JavaScript: pathItem.length

● VBScript: PathItem.Length

● AppleScript: length of path item

● XMP metadata, which names the XMP metadata packet associated with a document:

● JavaScript: document.XMPString

● VBScript: Document.XMPString

● AppleScript: XMP string

● Additional support of Adobe Photoshop

files:

Adobe Illustrator CS3

Scripting Guide Introduction 13

● JavaScript: openOptionsPhotoshop.preserveHiddenLayers,

openOptionsPhotoshop.layerComp

● VBScript: OpenOptionsPhotoshop.PreserveHiddenLayers,

OpenOptionsPhotoshop.LayerComp

● AppleScript: properties of Photoshop options: preserve hidden layers, layer comp

● New method or command for obtaining detailed PPD file information:

● JavaScript: app.getPPDFileInfo() (also, case usage in printerInfo.pPDInfo changed to

printerInfo.PPDInfo)

● VBScript: App.GetPPDFileInfo

● AppleScript: get PPD info command

● Additional support for exporting to Flash SWF format:

● JavaScript: additional properties for exportOptionsFlash

● VBScript: additional properties for ExportOptionsFlash

● AppleScript: additional properties of Flash export options

● AutoCAD support:

● JavaScript: preferences.AutoCADFileOptions, new object AutoCADFileOptions

● VBScript: Preferences.AutoCADFileOptions, new object AutoCADFileOptions

● AppleScript: AutoCAD file options of Illustrator preferences, new object AutoCAD

options

● Expanded support for clipping artwork when exporting to a Flash file allow you to specify whether to

clip the art object, the artboard, or the crop area:

● JavaScript: exportOptionsGIF.artClipping (replaces

exportOptionsGIF.artBoardClipping)

● VBScript: ExportOptionsGIF.ArtClipping (replaces

ExportOptionsGIF.ArtBoardClipping)

● AppleScript: art clipping (replaces artboard clipping)

● New tracing options property allows you to ignore white fill color.

● JavaScript: tracingOptions.ignoreWhite

● VBScript: TracingOptions.IgnoreWhite

● AppleScript: ignore white

Known Issues

● Scripts that create, save and then close a large number of Illustrator files should periodically quit and

relaunch Illustrator. The recommended maximum number of files to process before quitting and relaunching Illustrator is:

● In Windows: 500 files

● In Mac OS: 1000 files

Note: For information on quitting and relaunching Illustrator, see “Launching and activating

Illustrator” on page 23 and “Quitting Illustrator” on page 24.

Adobe Illustrator CS3

Scripting Guide Introduction 14

● The "An Illustrator error occurred: 1346458189 ("PARM")" alert may be popped when badly written

scripts are repeatedly run in Illustrator from the ExtendScript Toolkit.

Scripters need to be very careful about variable initialization and namespace conflict when pushing a batch of Illustrator scripts over and over again for execution in Illustrator via the ExtendScript Toolkit (ESTK) in a single Illustrator session. Each script run is executed within the same persistent ExtendScript engine within Illustrator.

The ESTK debugger uses BridgeTalk to communicate with Illustrator. A single global, persistent ExtendScript engine inside Illustrator handles all BridgeTalk communications. The net effect is that the state of the ExtendScript engine is cumulative to all the scripts that ran previously. Issues with script code that may cause this problem are:

● Reading uninitialized variables.

● Global namespace conflicts, such as when two globals from differents scripts are clobbering each

other.

The Illustrator Scripting Object Model

A good understanding of the Illustrator object model will improve your scripting abilities. The figure below shows the containment hierarchy of the object model, starting with the

layer and group item classes can contain nested objects of the same class which can, in turn,

the contain additional nested objects.

application object. Note that

Illustrator scripting object model

Note: In addition to this application-specific object model, JavaScript provides certain utility objects, such

File and Folder objects, which give you operating-system-independent access to the file

as the system. For details, see the JavaScript Tools Guide.

Object naming conventions

There is a single object model for the Illustrator scripting interface, but the actual object names vary slightly in the different scripting languages:

● AppleScript names are all lower case, and individual words are separated by a space. For example:

graphic style

● VBScript names are capitalized, and additional words in the name are indicated by uppercase initial

letters. For example:

GraphicStyle

Adobe Illustrator CS3

Scripting Guide The Illustrator Scripting Object Model 16

● JavaScript names begin with lowercase letters, and additional words in the name are indicated by

uppercase initial letters. For example:

graphicStyle

This chapter uses generic object and property names, but you can easily apply these conventions to determine the corresponding language-specific names.

Note: In the following sections, properties and methods are displayed in italics. Object names are

displayed in

courier font.

Top-level (containing) objects

Use these objects to access global information about the Illustrator application or an individual document.

Application

The properties of the application object give your script access to global values, such as:

● User preferences, which a user sets interactively in the Illustrator application by using the

Preferences dialog (Edit > Preferences)

● System information such as installed fonts (the text fonts property) and printers (the printer list

property)

Additionally, there are properties that provide application-specific information and higher-level information about any open documents.

● Application information such as the installation path, the version, and whether Illustrator is currently

visible

● The current active document; that is, the art canvas that is currently displayed and accepting user input

● All open documents

application

example:

● Open files

● Undo and redo transactions

● Quit Illustrator

Document

The document object, which your scripts can create or access through the application object, represents an art canvas or loaded Illustrator file. The document’s content. For example:

object methods or commands allow your script to perform application-wide actions. For

document object properties give you access to the

● The current selection, or art objects that the user has selected in the document

● All of the contained art objects, called page items, that make up the artwork tree

● Art objects of particular types, such as symbols and text frames

● All of the layers, and the currently active layer

Adobe Illustrator CS3

Scripting Guide The Illustrator Scripting Object Model 17

Document properties also tell you about the state of the document itself; for example:

● User settings for the document such as ruler units

● Whether the document has been saved since the last alteration of content

● The path of the associated file

document object methods allow your scripts to act on the document. For example:

The

● Save to an Illustrator file or save as the various supported file formats

● Activate or close a document

● Print the document; your scripts can select a printer by referencing a print options object or

reference available printers through the application object’s printer list property

Layer

The layer object provides access to the contents, or artwork tree, of a specific layer. You access the layer object through the about, the layer, such as:

● Whether the layer is visible or locked

document object. The layer object properties provide access to, or information

● The layer opacity (overall transparency) and z order position (position in the stacking order)

● Art creation preferences for the layer, such as artwork knockout and blending mode

The artwork tree

The content of an Illustrator document is called the artwork tree. Artwork is represented by the following objects:

● The compound path item object

● The graph item object

● The legacy text item object

● The mesh item object

● The path item object

● The placed item object

● The plugin item object

● The raster item object

● The symbol item object (See “Dynamic objects and symbols” on page 21.)

● The text frame object

Your scripts can access and manipulate art objects through collections in the objects. There are two types of art object collections:

document and layer

● Collection objects that correspond to each individual artwork object type, such as the graph items

object or the

● The page items object, which includes art objects of all types.

Additionally, you can use the

mesh items object.

group item object to reference a grouped set of art items.

Adobe Illustrator CS3

Scripting Guide The Illustrator Scripting Object Model 18

You can create new art objects using the make command (AppleScript) or add method of an artwork item collection object. For example, to create a new

path item object:

set myPathItem to make new path item in current document

var myPathItem = activeDocument.pathItems.add();

Set myPathItem = appRef.PathItems.Add()

Artwork collections that do not allow the creation of new objects using the make command or add method are:

● The graph items object

● The mesh items object

● The plugin items object

● The legacy text items object

For specific information on creating objects of these types, refer to the Adobe Illustrator CS3 scripting references.

Art styles

Your script can apply a graphic style to artwork using the graphic style object. To apply a graphic style, you use the graphic styles property of the

graphic style object.

Similarly, the through the

Color objects

Your script can apply a color, pattern or gradient to a path item object using the fill color or stroke color properties.

● Scripts can define new color swatches using the make command or add method of the swatches

object. Your script can also create a new spot color using the make command or add property of the

spots object.

● You can define the attributes of an ink object using the ink info object, which is an ink object

property. You access

document object to access the apply to method of the

brush object allows you to specify the brush to apply to artwork. You access any brush

brushes collection object, which is a property of the document object.

ink objects through the ink list property of the document object.

The following objects allow you to create colors within defined color spaces.

● The RGB color object, using the range 0.0 to 255.0 for the each of the three individual color values.

● The CMYK color object, using the percentage values 0.0 through 100.0 for each of the four individual

color values.

Adobe Illustrator CS3

Scripting Guide The Illustrator Scripting Object Model 19

● The grayscale color or LAB color objects, using the same range and number of values that you

use in the Illustrator application.

Text objects

When you type content in an Illustrator document, the type automatically becomes a text frame object and, at the same time, a

Note: To observe this, open a new document in Illustrator and use the horizontal text tool to type some

text, then use the vertical text tool to type some more text, and then create a rectangle and type some text inside it. Now run the following JavaScript script:

var myDoc = app.activeDocument alert("There are " + myDoc.textFrames.length + " text frames.") alert("There are " + myDoc.stories.length + " stories.")

Text frames

A text frame can be one of three kinds:

story object.

●

point

●

area

●

path

To create a specific kind of text frame, you use the kind property of the AppleScript. However, the JavaScript and VBScript

text frames objects contain specific methods for

text frames object in

creating area text frames and path text frames.

As in the Illustrator application, you can thread area or path text frames.

To thread existing text frames, you use the next frame or previous frame property of the object. Threaded frames make a single

story object.

text frame

For information on creating or threading text frames, see the chapter for your scripting language.

Text geometry

While the three kinds of text frame have common characteristics, such as an orientation, each has type-specific qualities, as reflected in the

● An area text frame can have rows and columns, which you access through the row count and column

count properties.

text frame object’s properties. For example:

Adobe Illustrator CS3

Scripting Guide The Illustrator Scripting Object Model 20

● Path text has start T value and end T value properties that indicate where on the path the text begins

and ends.

● Area and path text frames are associated with a text path object, which is specified using the text

frame

object’s text path property. The text path defines the text frame’s position and its orientation (horizontal or vertical) on the artboard (while the text frame object’s orientation property defines the orientation of text within the text frame)

The text path property is not valid for point text, because point text position and orientation are defined completely by the properties of the text frame itself.

Note: A text path is not the same as a path art item. Text paths are associated with path art items that

can be accessed and manipulated to modify the appearance of the associated text frame.

Objects that represent text content

Within a text frame or story, the actual text content can be accessed as any of the following objects:

● characters

● words

● paragraphs

● lines

A line object is all of the characters that fit on a single line in a text frame or story object. All text art items have at least one line of text, defined as a

line object. Text art can have multiple text lines if the text

contains hard line breaks or its characters flow to a new line because they do not fit in the width of the text art. Text objects are accessed and identified by collections within the example,

Both

textFrame("My Text Frame").paragraphs or story("My Story").paragraphs.

text frame and story objects have insertion point and text selection properties. The text frame

text frame and story objects; for

object’s properties also include the defining features of the text frame, such as:

● The frame width, height, and position

● Whether the frame is hidden or locked

● Whether the text is editable

Note: A

word objects.

line object cannot be created in a script. Your script can create character, paragraph, and

Adobe Illustrator CS3

Scripting Guide The Illustrator Scripting Object Model 21

Text ranges

The various text objects within a text frame or story are also represented collectively by the text range object. For example, a character is a text range with a length of 1, and a word is a text range that has a space before it.

You can set the content of a

text range object by passing a string using the contents property.

Text styles

Text style elements, such as font, capitalization, or justification, are represented by paragraph

attribute paragraph style and character style objects. The paragraph style and character style

and character attribute objects. These attribute objects are properties of the

objects have apply to and remove methods that allow your script to assign or remove attributes in a specific paragraph, character, or text range.

You can change the display properties of a text range by applying an appropriate style or providing local overrides of attributes at the text or paragraph levels.

● character style objects apply to sets of one or more characters, and control character features

such as font, alignment, leading, language, and capitalization, which are all properties of the

character attribute object.

● paragraph style objects apply to paragraphs, and control paragraph features such as first line

indent, left indent, or right indent, which are all properties of the

Dynamic objects and symbols

By creating dynamic objects, you can create data-driven graphics. In the Illustrator application, you use the Variables palette to create or edit variables such as graph data, linked file, text string, and visibility variables or variables whose type is not specified. In scripting, you use the this type of variable. The

variable object holds. variable objects are document-level objects; you create them in a document

object.

variable object’s kind property indicates the type of dynamic data that a

paragraph attribute object.

variable object to represent

Note: Do not confuse

variable objects with scripting variables. For information on Illustrator variables,

dynamic objects, and data-driven graphics, refer to Illustrator Help.

Datasets, which collect variables and their associated dynamic data into a single object, are represented in scripting by the

dataset objects in your scripts.

dataset object. The dataset object provides methods with which to update and delete

In Illustrator, symbols are art items that are stored in the Symbols palette. Your scripts can create, delete, and duplicate

symbol objects. When you create symbol objects in your script, Illustrator adds them to

the Symbols palette for the target document.

symbol item is an instance of a symbol object in a document. Each symbol item is linked to its

A symbol definition, so that changing the definition of a symbol updates all instances of the symbol.

Your script can create, delete and duplicate symbol items. Symbol items are Illustrator art items and therefore can be treated in the same way as other art items or page items. You can rotate, resize, select, lock, hide and perform other operations on symbol items.

Adobe Illustrator CS3

Scripting Guide The Illustrator Scripting Object Model 22

Transformations

The matrix object provides access to the power of geometric transformation matrices. Transformation matrices in Illustrator store the settings of an operation that scales, rotates or moves (translates) an object on a page. Some advantages to using matrices are:

● By storing transformation values in a matrix object, you can use the values over and over on different

objects in your script.

● By concatenating rotation, translation and/or scaling matrices and applying the resulting matrix, you

can perform a large series of geometric transformations using only a single script statement.

● You can invert matrix values.

● You can compare the values of two matrices.

The commands or methods to create, get, invert, compare, or concatenate matrices belong to the

application object.

The command or method used to apply a matrix is the transform command, which belongs to any type of object on which transformations can be performed.

Scripting Illustrator

This chapter provides an overview of how to use scripting objects to program Adobe Illustrator CS3. Specific examples for the supported scripting languages are provided in the succeeding chapters.

Launching and quitting Illustrator from a script

Your scripts can control the activation and termination of Illustrator.

Launching and activating Illustrator

Typically, you run JavaScript scripts from the application’s Scripts menu (File>Scripts) or startup folder, so there is no need to launch Illustrator from your script.

Information on launching Illustrator in a JavaScript is beyond the scope of this guide. For information, search for "interapplication messaging" or "JavaScript messaging framework" in the JavaScript Tools Guide.

In AppleScript, you use a tell statement to target Illustrator. The activate command activates Illustrator if it is not already active.

tell application "Adobe Illustrator"

activate

end tell

VBS

In VBScript, there are several ways to create an instance of Illustrator.

● CreateObject launches Illustrator as an invisible application if it is not already running. Note that if

Illustrator is launched as an invisible application you have to manually activate the application to make it visible.

Set appRef = CreateObject("Illustrator.Application")

Note: If you have multiple versions of Illustrator installed on the same machine and use the

CreateObject method to obtain an application reference, using

Illustrator.Application" creates a reference to the latest Illustrator version. To specifically

" target an earlier version, use the numeric version identifier at the end of the string:

● For Illustrator 10, use "Illustrator.Application.1"

● For Illustrator CS, use "Illustrator.Application.2"

● For Illustrator CS2, use "Illustrator.Application.3"

● For Illustrator CS3, use "Illustrator.Application.4"

Adobe Illustrator CS3

Scripting Guide Scripting Illustrator 24

● Use the New operator if you have added a reference to the Illustrator type library to the project. For

example, the following line creates a new reference to the

Set appRef = New Illustrator.Application

Application object:

Quitting Illustrator

In JavaScript use the app.quit() method to close the application.

app.quit()

In AppleScript, you use the quit command.

tell application "Adobe Illustrator"

quit

end tell

VBS

In VBScript, use the Application object’s Quit method to close the application.

Set appRef = CreateObject("Illustrator.Application") appRef.Quit

Working with objects

This section provides general information about working with objects in Illustrator.

Getting the frontmost document or layer

To refer to the selected document, you use the application object’s current document property in AppleScript or the active document property in JavaScript or VBScript. Similarly, you can use the

document object’s current layer or active layer property to refer to the selected layer.

Note: There are other types of "active" or "current" object properties, such as active dataset or active view.

Refer to the scripting reference for your language for details.

Adobe Illustrator CS3

Scripting Guide Scripting Illustrator 25

Creating new objects

There are a number of objects (besides the application object itself) that cannot be obtained from containers or parent objects. Your script must create these objects directly.

The following objects must be created explicitly:

CMYK color document preset EPS save options export options flash export options GIF export options JPEG export options Photoshop export options PNG8 export options PNG24 export options PS5 export options SVG

file folder gradient color gray color Illustrator save options

a. File and Folder objects are Adobe ExtendScript devices designed to provide platform-independent access to the underlying file system. For information on using these objects, see the JavaScript Tools Guide.

See the chapter for your scripting language for information on creating an object explicitly.

Collection objects

Most collection objects must be obtained from a container. For example, a path items collection object can be contained by a collection, you refer to either containing object.

ink ink info matrix no color open options paper info Pattern color PDF open options PDF open options PDF save options PPD file PPD file info print color management options print color separation options print coordinate options printer

printer info print flattener options print font options print job options print options print page marks options print paper options print postscript options screen screen spot function RGB color spot color

document object or a layer object. To obtain an object in a path items

For example:

To refer to a path items object in a document:

path item 1 in document 1

To refer to a path items object in a layer:

path item 1 in layer 1 in document 1

To refer to a path items object in a document:

documents[0].pathItems[1]

To refer to a path items object in a layer:

documents[0].layers[0].pathItems[0]

Adobe Illustrator CS3

Scripting Guide Scripting Illustrator 26

VBS

To refer to a path items object in a document:

Documents(1).PathItems(1)

To refer to a path items object in a layer:

Documents(1).Layers(1).PathItems(1)

For more examples of collection item containers, refer either to document object Elements table in the

Adobe Illustrator CS3 AppleScript Reference, or the Properties table in the Adobe Illustrator CS3 JavaScript Reference or Adobe Illustrator CS3 VBScript Reference. Also, view a diagram of the Illustrator CS3 object

model in “The Illustrator Scripting Object Model” on page 15

Selected objects

There are times when you want to write scripts that act upon the currently selected object or objects. For example, you might want to apply formatting to selected text or change a selected path’s shape.

Selecting text

To select text, you use the select command or method of the text range object.

Selecting art items

You can select an art object (such as graph items, mesh items, raster items, symbol items, and so on) by setting its selected property to

true. (In AppleScript, selected is a property of the page items object.)

Referring to selected art items

To refer to all currently selected objects in a document, you use the document object’s selection property. To work with the objects in the selection array, you must determine their type in order to know which properties and methods or commands you can use with them. Each artwork object type has a read-only typename property in JavaScript or VBScript that you can use to determine the object’s type. In AppleScript, use the class property.

Notes on renaming objects stored in the application’s palettes

Several objects can be renamed; that is, their name property is writeable. The following types of objects can be sorted alphabetically in the corresponding Illustrator palette, so if a script modifies the name of such an object, references to that object by index can become invalid. These object types include the following:

Brush Gradient Graphic Style Pattern Swatch Symbol Variable

Adobe Illustrator CS3

Scripting Guide Scripting Illustrator 27

Measurement units

Illustrator uses points as the unit of measurement for almost all distances, where one inch is equal to 72 points. The one exception is the values for properties such as kerning, tracking, and the aki properties (used for Japanese text composition), which use em units. (See “Em space units” on page 27

Illustrator uses points when communicating with your scripts regardless of the current ruler units. If your script depends on adding, subtracting, multiplying, or dividing specific measurement values for units other than points, it must perform any unit conversions needed to represent your measurements as points.

For example, to use inches for coordinates or measurement units, you must multiply all inch values by 72 when entering the values in your script.

The following table shows the conversion formulae for various units of measurement:

Unit Conversion formula

centimeters 28.346 points = 1 centimeter

inches 72 points = 1 inch

millimeters 2.834645 points = 1 millimeter

picas 12 points = 1 pica

Qs 0.709 point = 1 Q (1 Q equals 0.23 millimeter)

Note: JavaScript provides the

see the JavaScript Tools Guide.

UnitValue object type, which offers unit conversion utilities. For details,

Em space units

Values that use em units instead of points are measured in thousandths of an em unit.

Em units are proportional to the current font size. For example, in a 6-point font, 1 em equals 6 points; in a 10-point font, 1 em equals 10 points. Similarly, a kerning value of 20 em units for a 10-point font would be equivalent to:

(20 units x 10 points) / 1000 units/em = 0.2 points

Page item positioning and dimensions

Illustrator uses simple two-dimensional geometry in the form of points to record the position of page

item

objects in a document. Every page item object in a document has a position property that defines

a fixed point as a pair of page coordinates in the format [x, y]. The fixed point is the top left corner of the object’s bounding box.

Note: See “The artwork tree” on page 17

items

collection.

A point is designated by a pair of coordinates:

● The horizontal position x

● The vertical position y

for information on the types of objects that comprise the page

Adobe Illustrator CS3

Scripting Guide Scripting Illustrator 28

Note: You can see these coordinates in the Info palette when you select or create an object in Illustrator.

The default ruler origin point (0, 0) for coordinate numbering in Illustrator is the lower left corner of the document. (ruler origin is a property of the

● On the horizontal axis, coordinates to the right of the ruler’s zero point are positive numbers.

● On the vertical axis, coordinates above the zero point are positive.

document object.)

The default page origin property of a of the document as a fixed point.

Additionally, each the width or height of a page item is 16348 points.

Art item bounds

Every page item object also has three properties that use fixed rectangles to describe the object’s overall extent.

● The geometric bounds of a page item are the rectangular dimensions of the object’s bounding box

excluding stroke width.

● The visible bounds of a page item are the dimensions of the object including any stroke widths.

● The control bounds define the rectangular dimensions of the object including in- and out- control

points.

The following figure illustrates these properties, using the JavaScript naming convention.

document object defines the lower left corner of the printable region

page item object has a width and height property. The maximum value allowed for

Adobe Illustrator CS3

Scripting Guide Scripting Illustrator 29

Paths and shapes

Paths are represented in the Illustrator DOM by the path item object. Path items include all artwork that contains paths, such as rectangles, ellipses, and polygons, as well as freeform paths.

For information on creating shapes, please see the chapter for your scripting language.

A freeform path consists of a series of path points. A path point can be specified in two ways:

● As an array of x and y page coordinates.

● As a path point object, which defines an anchor point and two direction points or handles that

define the path segment’s curve.

For specific details and samples, see the chapter for your scripting language.

User interaction levels

An application typically presents a dialog when it user feedback is required. This is called user interaction, and is useful and expected when you are directly interacting with the application. However, when a script is interacting with an application, a dialog brings the execution of the script to a halt until the dialog is dismissed. This can be a serious problem in an automation environment where there is no one present to deal with dialogs.

application object contains a user interaction level property that allows you to control the level of

The interaction allowed during script execution. You can suppress interaction in an automation environment, or allow some interaction where scripts are being used in a more interactive fashion.

There are two possible values for the app.userInteractionLevel property in JavaScript:

Property Value Result

DISPLAYALERTS

DONTDISPLAYALERTS

Interaction is allowed

No interaction is allowed

VBS

There are two possible values for the UserInteractionLevel property of the Application object in VBScript:

Adobe Illustrator CS3

Scripting Guide Scripting Illustrator 30

Property Value Result

aiDisplayAlerts

aiDontDisplayAlerts

Interaction is allowed

No interaction is allowed

Using AppleScript, it is possible to send commands from one machine to another, so additional types of interaction are possible. There are four possible values for the user interaction level property in AppleScript:

Property Value Result

never interact

interact with self

interact with local

interact with all

The four values allow you to control interaction based on the source of the script commands. For example, if the application is acting as a server for remote users, it would be difficult for a remote user to dismiss a dialog, but it would be no problem for someone sitting in front of the machine. In this case, an interaction level of interact with local would prevent dialogs from halting remote scripts but would allow dialogs to be presented for local scripts.

No interaction is allowed.

Interact only with scripts executed from the Scripts menu (File > Scripts).

Interact with scripts executed on the local machine (including self).

Interact with all scripts.

Printing Illustrator documents

Using the print options scripting feature, you can capture and automate parts of your print workflow. Scripting exposes the full capabilities of Illustrator printing, some of which may not be accessible through the application’s user interface.

Note: Illustrator supports at most one print session at any give time because of limitations in the current

printing architecture.

document object’s print command or method takes a single optional parameter, which allows you to

The specify a

The options, color management options, and so on. The property, which allows you to specify a preset to define your print job.

When defining the properties of a presets, and other items are available by using the as the printer list property, the PPD file list property, the print presets list property, and so on.

print options object.

print options object allows you to define print settings such as PPD, PostScript options, paper

print options object, you can find out which printers, PPDs, print

print options object also has a print preset

application object’s read-only "list" properties, such

Scripting with JavaScript

This chapter uses script examples and explanations to help you to become familiar with Illustrator scripting using JavaScript.

For more information

Several extended sample scripts are available in the /Scripting/Sample Scripts folder in your Illustrator CS3 installation directory.

For information about individual classes, objects, properties, methods and parameters, as well as script samples that demonstrate how to use many of them, refer to the Adobe Illustrator CS3 JavaScript Reference, which is found in the You can also use the Illustrator dictionary, which you access from the Object Model Viewer in the ExtendScript Toolkit. For information on using the ExtendScript Toolkit and the Object Model Viewer, see

“Viewing the JavaScript object model” on page 8

If you are a beginner and find that you don’t understand the concepts and terms used in this chapter, read the Adobe Introduction to Scripting.

/Scripting/Documentation folder in your Illustrator CS3 installation directory.

Your first Illustrator script

or the JavaScript Tools Guide.

The traditional first project in any programming language is to display the message "Hello World!" In this example, you create a new Illustrator document, then add a text frame containing this message.

1. Using any text editor (including Adobe following text:

Note: For information on locating the ExtendScript Toolkit, see “Viewing the JavaScript object model”

on page 8.

//Hello World! var myDocument = app.documents.add(); //Create a new text frame and assign it to the variable "myTextFrame" var myTextFrame = myDocument.textFrames.add(); // Set the contents and position of the text frame myTextFrame.position = [200,200]; myTextFrame.contents = "Hello World!"

2. To test the script, do either of the following:

● If you are using the ExtendScript Toolkit, select Illustrator CS3 from the dropdown list in the upper

left corner and select Yes to start Illustrator, and then choose Debug> Run in the ExtendScript Toolkit to run the script.

● If you are using a different text editor, save the file as text only in a folder of your choice, using the

file extension then navigate to and run your script file.

.jsx, and then start Illustrator. In Illustrator, choose File>Scripts>Other Scripts, and

InDesign® software or the ExtendScript Tookit), enter the

Adobe Illustrator CS3

Scripting Guide Scripting with JavaScript 32

Tip: To add the script to the Illustrator Scripts menu (File > Scripts), save the script in the Scripts folder. The

script will appear on the menu the next time you start Illustrator. For information, see “Installing

scripts in the Scripts menu” on page 10.

Adding features to "Hello World"

Next, let’s create a new script that makes changes to the Illustrator document you created with your first script.

Our second script will demonstrate how to:

● Get the active document.

● Get the width of the active document.

● Resize the text frame to match the document’s width.

Note: If you’ve already closed the Illustrator document, run your first script again to create a new

document before you proceed with this exercise.

1. Choose File > New in your text editor to create a new script.

2. Enter the following code:

var docRef = app.activeDocument; var docWidth = docRef.width var frameRef = docRef.textFrames[0] frameRef.width = docWidth

3. Run the script.

Working with methods in JavaScript

When you work with methods that have multiple parameters, you may omit optional parameters at the end of the parameter list, but you may not omit parameters in the middle of the list. If you do not wish to specify a particular parameter in the middle of the list, you must insert the value parameter’s default value. For example, the following definition describes the art object.

Note: In the definition, taken from the Adobe Illustrator CS3 JavaScript Reference, optional parameters are

enclosed in square brackets (

rotate

(angle [,changePositions] [,changeFillPatterns] [,changeFillGradients] [,changeStrokePattern] [,rotateAbout])

[]).

undefined to use the

rotate() method for an

To rotate the object 30 degrees and change the fillGradients, you would use the following script statement:

myObject.rotate(30, undefined, undefined, true);

Adobe Illustrator CS3

Scripting Guide Scripting with JavaScript 33

Note that you only need to specify undefined for the changePositions and changeFillPatterns parameters. You do not have to specify anything for optional parameters that follow the

changeFillGradients parameter.

Accessing and referencing objects

When you write a script, you must first decide which file, or document, the script should act on. Through

application object, the script can create a new document, open an existing document, or act on a

the document that is already open.

The script can create new objects in the document, operate on objects that the user has selected, or operate on objects in one of the object collections. The following sections illustrate various techniques for accessing, referencing, and manipulating Illustrator objects.

Referencing the application object

To obtain a reference to a specific object, you need to navigate the containment hierarchy. However, because all JavaScript scripts are executed from within the Illustrator application, a specific reference to

application object is not required. For example, to assign the active document in Illustrator to the

the variable

application object as follows:

frontMostDocument, you could reference the activeDocument property of the

var frontMostDocument = activeDocument;

It is permissible to use the application object in a reference. To reference the application object, you use the global variable

var frontMostDocument = activeDocument;

var frontMostDocument = app.activeDocument;

app. The following two statements appear identical to the JavaScript engine:

Accessing objects in collections

All open documents, as well as the objects in a document, are collected into collection objects for the object type. A collection object contains an array of the objects that you can access by index or by name. The collection object takes the plural form of the object name. For example, the collection object for the

document object is the documents object.

The following script sample gets all all graphic styles available to the active document:

var myStyles = app.activeDocument.graphicstyles;

All numeric collection references in JavaScript are zero-based; that is, the first object in the collection has the index [0].

Note: As a rule, JavaScript index numbers do not shift when you add an object to a collection. However,

there is one exception:

graphic style objects in the graphic styles collection; that is, it gets

documents[0] is always the active or frontmost document.

To access the first style in graphic styles collection, you can use the variable declared in the previous script sample, or you can use the containment hierarchy to refer to the collection:

● Using the myStyles variable:

var firstStyle = myStyles[0];

Adobe Illustrator CS3

Scripting Guide Scripting with JavaScript 34

● Using the containment hierarchy:

var firstStyle = app.activeDocument.graphicStyles[0];

The following statements assign the name "Modern" to the first graphic style in the collection. These statements are identical; you can use them interchangeably.

myStyles[0].name = 'Modern'

firstStyle.name = 'Modern'

app.activeDocument.graphicStyles[0].name = 'Modern'

To get the total number of objects in a collection, use the length property:

alert ( myStyles.length ) ;

The index of the last graphic style in the collection would be myStyles.length-1 (-1 because the collection starts the index count at 0 and the

var lastStyle = myStyles[ myStyles.length - 1 ];

length property counts from 1):

Notice that an expression representing the index value is enclosed in square brackets ([]) as well as quotes.

If you know the name of an object, you can access the object in the collections using the name surrounded by square brackets. For example:

var getStyle = myStyles[’Ice Type’];

Notice that the object name is enclosed in square brackets ([]).

Each element in the collection is an object of the desired type, and you can access its properties through the collection. To get an object’s name, for example, use the

var styleName = app.activeDocument.graphicStyles[0].name;

To apply lastStyle to the first pageItem in the document, use its applyTo() method:

lastStyle.applyTo( app.activeDocument.pageItems[0] );

Creating new objects

You can use a script to create new objects. To create objects that are available from collection objects, or containers, you use the container object’s

var myDoc = app.documents.add() var myLayer = myDoc.layers.add()

Some object types are not available from containers. You create an object of this type by defining a variable, and then using the example, to create a new

name property:

add() method.

new operator with an object constructor to assign an object as the value. For

CMYKColor object using the variable name myColor:

var myColor = new CMYKColor()

Adobe Illustrator CS3

Scripting Guide Scripting with JavaScript 35

Working with selections

When the user makes a selection in a document, the selected objects are stored in the document’s

selection property. To access all selected objects in the active document:

var selectedObjects = app.activeDocument.selection;

The selection property value can be an array of any type of art objects, depending on what types of objects are selected. To get or manipulate the properties of the selected art items, you must retrieve the individual items in the array. To find out an object’s type, use the

The following sample gets the first object in the array, and then displays the object’s type:

var topObject = app.activeDocument.selectedObjects[0]; alert(topObject.typename)

Note: The first object in a selection array is the selected object that was last added to the page, and not

the last object selected.

Selecting artwork objects

To select an art object, use the object’s selected property.

typename property.

Working with text frames

To create a text frame of a specific type in JavaScript, you use the textFrames method whose name corresponds to the text frame type. For example:

var rectRef = docRef.pathItems.rectangle(700, 50, 100, 100);

//use the areaText method to create the text frame var areaTextRef = docRef.textFrames.areaText(rectRef);

Threaded frames

As in the Illustrator application, you can thread area or path text frames.

To thread existing text frames, you use the object.

nextFrame or previousFrame property of the text frame

Adobe Illustrator CS3

Scripting Guide Scripting with JavaScript 36

Note: When copying the following script to the ExtendScript ToolKit, place the value of the contents

property a single line.

var myDoc = documents.add(); var myPathItem1 = myDoc.pathItems.rectangle(244, 64, 82, 76); var myTextFrame1 = myDoc.textFrames.areaText(myPathItem1); var myPathItem2 = myDoc.pathItems.rectangle(144, 144, 42, 116); var myTextFrame2 = myDoc.textFrames.areaText(myPathItem2);

// use the nextFrame property to thread the text frames myTextFrame1.nextFrame = myTextFrame2; var sText = "This is two text frames linked together as one story, with text

flowing from the first to the last. This is two text frames linked together as one story, with text flowing from the first to the last. This

is two text frames linked together as one story. "; myTextFrame1.contents = sText; redraw();

Threaded frames make a single story object

Threaded frames make a single story object.

To observe this, run the following JavaScript after running the script in “Threaded frames” on page 35

var myDoc = app.activeDocument alert("There are " + myDoc.textFrames.length + " text frames.") alert("There are " + myDoc.stories.length + " stories.")

Creating paths and shapes

This section explains how to create items that contain paths.

Paths

To create a freeform path, you specify a series of path points, either as series of x-y coordinates or as

pathPoint objects.

● Using x-y coordinates limits the path to straight segments only.

● To created a curved path, you must create pathPoint objects.

Your path can consist of a combination of page coordinates and

Specifying a series of x-y coordinates

To specify a path using page coordinate pairs, you use the setEntirePath() method of the

pathItems object. The following script specifies three pair of x-y coordinates to create a path that has

three points.

pathPoint objects.

var myDoc = app.activeDocument; var myLine = myDoc.pathItems.add(); //set stroked to true so we can see the path myLine.stroked = true; myLine.setEntirePath([[220, 475], [375, 300], [200, 300]]);

Adobe Illustrator CS3

Scripting Guide Scripting with JavaScript 37

Using pathPoint objects

When you create a pathPoint object, you define three values for the point:

● A fixed anchor point, which is the point on the path

● A pair of direction points: the left direction point and the right direction point, which allow you to

control the path segment’s curve

You define each property as an array of page coordinates in the format [x, y].

● If all three properties of a pathPoint object have the same coordinates, and the properties of the

pathPoint in the line are equal to each other, you create a straight line segment.

● If two or more properties in a pathPoint object hold different values, the segment connected to

the point is curved.

To create a path, or to add points to an existing path, using object and then add the path points as child objects in the

pathPoint objects, you create a pathItem

pathItem.

var myDoc = app.activeDocument; var myLine = myDoc.pathItems.add();

//set stroked to true so we can see the path

myLine.stroked = true;

var newPoint = myLine.pathPoints.add();

newPoint.anchor = [220, 475];

//giving the direction points the same value as the

//anchor point creates a straight line segment

newPoint.leftDirection = newPoint.anchor;

newPoint.rightDirection = newPoint.anchor;

newPoint.pointType = PointType.CORNER;

var newPoint1 = myLine.pathPoints.add();

newPoint1.anchor = [375, 300];

newPoint1.leftDirection = newPoint1.anchor;

newPoint1.rightDirection = newPoint1.anchor;

newPoint1.pointType = PointType.CORNER;

var newPoint2 = myLine.pathPoints.add();

newPoint2.anchor = [220, 300];

//giving the direction points different values

//than the anchor point creates a curve

newPoint2.leftDirection =[180, 260];

newPoint2.rightDirection = [240, 320];

newPoint2.pointType = PointType.CORNER;

Adobe Illustrator CS3

Scripting Guide Scripting with JavaScript 38

Combining path point types

The following script sample creates a path with three points:

var myDoc = app.activeDocument; var myLine = myDoc.pathItems.add();

myLine.stroked = true;

myLine.setEntirePath( [[220, 475], [375, 300]]);

// Append another point to the line var newPoint = myDoc.myLine.pathPoints.add();

newPoint.anchor = [220, 300]; newPoint.leftDirection = newPoint.anchor; newPoint.rightDirection = newPoint.anchor; newPoint.pointType = PointType.CORNER;

Adobe Illustrator CS3

Scripting Guide Scripting with JavaScript 39

Shapes

To create a shape, you use the pathItems method that corresponds to the shape’s name (such as ellipse, rectangle, or polygon), and use the parameters to specify shape’s position, size, and other information such

as the number of sides in a polygon.

Tip: Remember:

● All measurements and page coordinates are processed as points by the scripting engine. For more

information, see “Measurement units” on page 27

● x and y coordinates are measured from the bottom left corner of the document, as indicated in the

Info palette in the Illustrator application. For information, see “Page item positioning and

dimensions” on page 27.

Creating a rectangle

The following sample uses the textFrames object’s rectangle() method to create a rectangle with the following properties:

● The top of the rectangle is 2 inches (144 points) from the bottom edge of the page.

● The left edge is 2 inches (144 points) from the left edge of the page.

● The rectangle is 1 inch wide and 3 inches long.

var myDocument = app.documents.add() var artLayer = myDocument.layers.add() var rect = artLayer.pathItems.rectangle( 144, 144, 72, 216 );

Creating a polygon

The following sample uses the polygon() method to create a polygon with the following properties:

● The center point of the object is inset is 2 inches (144 points) on the horizontal axis and 4 inches (288

points) on the vertical axis.

● The length of the radius from the center point to each corner is 1 inch.

● The polygon has 7 sides.

var myDocument = app.documents.add() var artLayer = myDocument.layers.add() var poly = artLayer.pathItems.polygon( 144, 288, 72.0, 7 );

Scripting with AppleScript

This chapter uses script examples and explanations to help you to become familiar with Illustrator scripting using AppleScript.

For more information

Several extended sample scripts are available in the :Scripting:Sample Scripts folder in your Illustrator CS3 installation directory.

For information about individual classes, objects, properties, commands and parameters, as well as script samples that demonstrate how to use many of them, refer to the Adobe Illustrator CS3 AppleScript Reference, which is found in the directory. You can also use view Illustrator CS3 dictionary from the Script Editor application. See “Viewing

the AppleScript object model” on page 9.

If you are a beginner and find that you don’t understand the concepts and terms used in this chapter, read the Adobe Introduction to Scripting.

Your first Illustrator script

:Scripting:Documentation folder in your Illustrator CS3 installation

1. Open Script Editor.

Note: In a default Mac OS installation, Script Editor is in

Editor

system CD.

2. Enter the following script.

--Send the following commands to Illustrator

tell application "Adobe Illustrator"

--Create a new document

set docRef to make new document

--Create a new text frame with the string "Hello World"

set textRef to make new text frame in docRef ¬

with properties {contents: "Hello World!", position:{200, 200}}

end tell

3. In the Script Editor toolbar, click Run.

Tip: To add the script to the Illustrator Scripts menu (File > Scripts), save the script in the Scripts folder. The

script will appear on the menu the next time you start Illustrator. For information, see “Installing

scripts in the Scripts menu” on page 10.

. If you cannot find the Script Editor application, you must reinstall it from your Mac OS

Applications:AppleScript:Script

Adobe Illustrator CS3

Scripting Guide Scripting with AppleScript 41

Adding features to "Hello World"

Next, let’s create a new script that makes changes to the Illustrator document you created with your first script.

Our second script will demonstrate how to:

● Get the active document.

● Get the width of the active document.

● Resize the text frame to match the document’s width.

Note: If you’ve already closed the Illustrator document, run your first script again to create a new

document.

1. Choose File > New in Script Editor to create a new script.

2. Enter the following code:

tell application "Adobe Illustrator"

-- current document is always the active document

set docRef to the current document

set docWidth to the width of docRef

-- resize the text frame to match the page width

set width of text frame 1 of docRef to docWidth

-- alternatively, one can reference the item directly, as follows:

set width of text frame 1 of current document to docWidth

end tell

3. Run the script.

Object references

In AppleScript, Illustrator returns object references by index position or name. For example, a reference to the first path in layer 2 would be:

path item 1 of layer 2 of document 1

An object’s index position may change when other objects are created or deleted. For example, when a new path item is created on

document 1

Therefore, any references made to object. This method of applying index numbers assures that lowest index number refers to the object that has been worked on most recently. Consider the following sample script.

-- Make 2 new objects and try to select both tell application "Adobe Illustrator"

set newDocument to make new document

set rectPath to make new rectangle in newDocument

set starPath to make new star in newDocument

set selection of newDocument to {rectPath, starPath} end tell

This script does not select both the rectangle and the star, as intended; instead, it selects only the star. Try running the script with the Event Log window open to observe the references returned from Illustrator for each of the consecutive

. This new object displaces our original path item, forcing the original to index position 2.

layer 2, the new path item will become path item 1 of layer 2 of

path item 1 of layer 2 of document 1 will refer to the new

make commands (Choose Event Log at the bottom of the Script Editor window).

Adobe Illustrator CS3

Scripting Guide Scripting with AppleScript 42

Notice that both commands return the same object reference: path item 1 of layer 1 of

document 1

set selection of document 1 to {path item 1 of layer 1 of document 1, ¬

path item 1 of layer 1 of document 1}

. Therefore, the last line resolves to:

A better approach is to reference the objects by name:

tell application "Adobe Illustrator"

set newDocument to make new document

make new rectangle in newDocument with properties {name:"rectangle"}

make new star in newDocument with properties {name:"star"}

set selection of newDocument to ¬

{path item "rectangle" of newDocument, ¬ path item "star" of newDocument}

end tell

This example illustrates the need to uniquely identify objects in AppleScript scripts. It is recommended that you assign names or variables to objects you need to access at a later time, as there is no guarantee you are accessing the objects you expect when accessing them by index.

Obtaining objects from documents and layers

This script references an object as part of a document:

-- Get reference for first page item of document 1 tell application "Adobe Illustrator"

set pageItemRef to page item 1 of document 1 end tell

In the following script, the variable pageItemRef does not necessarily refer to the same object as in the previous script, because this script includes a reference to a layer:

-- Get reference for first page item of layer 1 of document 1 tell application "Adobe Illustrator"

set pageItemRef to page item 1 of layer 1 of document 1 end tell

Creating new objects

To create a new object in AppleScript, you use the make command.

Working with selections

When the user makes a selection in a document, the selected objects are stored in the document’s

selection property. To access all selected objects in the active document:

tell application "Adobe Illustrator"

set myDoc to current document

set selectedObjects to selection of myDoc end tell

Depending on what is selected, the selection property value can be an array of any type of art objects. To get or manipulate the properties of the selected art items, you must retrieve the individual items in the array. To find out an object’s type, use the class property.

Adobe Illustrator CS3

Scripting Guide Scripting with AppleScript 43

The following sample gets the first object in the array, and then displays the object’s type:

tell application "Adobe Illustrator"

set myDoc to current document

set selectedObjects to selection of myDoc

set topObject to item 1 of selectedObjects

display dialog (class of topObject) end tell

Note: The first object in a selection array is the selected object that was last added to the page, and not

the last object selected.

Selecting artwork objects

To select an art object, use the object’s selected property.

Working with text frames

To create a text frame of a specific type in AppleScript, you use the kind property of the text frame object.

set myRect make new rectangle in current document with properties ¬

{position:{100, 700}, height:100, width:100} set myAreaText make new text frame in current document with properties ¬

{kind:area text,contents:"Text Frame 1"}

Threaded frames

As in the Illustrator application, you can thread area or path text frames.

To thread existing text frames, you use the

frame

object.

Note: When copying the following script to your script editor, place the value of the contents property on

a single line. The long line character (

tell application "Adobe Illustrator"

make new document

make new rectangle in current document with properties ¬

{position:{100, 500}, height:100, width:100}

make new text frame in current document with properties ¬

{kind:area text, text path:the result, name:"tf1", ¬ contents:"This is two text frames linked together as one story, with text flowing from the first to the last. First frame content. "}

make new rectangle in current document with properties ¬

{position:{300, 700}, height:100, width:100}

make new text frame in current document with properties ¬

{kind:area text, text path:the result, name:"tf2", ¬ contents:"Second frame content." }

--use the next frame property to thread the frames set next frame of text frame "tf1" of current document to ¬ text frame "tf2" of current document

redraw

end tell

next frame or previous frame property of the text

¬) is not valid within a string value.

Adobe Illustrator CS3

Scripting Guide Scripting with AppleScript 44

Threaded frames make a single story object

Threaded frames make a single story object.

To observe this, run the following JavaScript after running the script in “Threaded frames” on page 43

var myDoc = app.activeDocument alert("There are " + myDoc.textFrames.length + " text frames.") alert("There are " + myDoc.stories.length + " stories.")

Creating paths and shapes

This section explains how to create items that contain paths.

Paths

To create line or a freeform path, you specify a series of path points, either as series of x-y coordinates or as

path point objects.

● Using x-y coordinates limits the path to straight segments only.

● To created a curved path, you must create path point objects.

A path can consist of a combination of page coordinates and

Specifying a series of x-y coordinates

To specify a path using page coordinate pairs, you use the entire path property of the path items object. The following script specifies three pair of x-y coordinates to create a path that has three points.

path point objects.

tell application "Adobe Illustrator" set docRef to make new document

-- set stroked to true so we can see the path set lineRef to make new path item in docRef with properties {stroked:true} set entire path of lineRef to {{220, 475},{200, 300},{375, 300}} end tell

Using path point objects

To create a path point object, you must define three values for the point:

● A fixed anchor point, which is the point on the path

● A pair of direction points: the left direction point and the right direction point, which allow you to

control the path segment’s curve

You define each property as an array of page coordinates in the format [x, y].

● If all three properties of a path point object have the same coordinates, and the properties of the

path point in the line are equal to each other, you create a straight line segment.

● If two or more properties in a path point object hold different values, the segment connected to

the point is curved.

Adobe Illustrator CS3

Scripting Guide Scripting with AppleScript 45

To create a path, or to add points to an existing path, using path point objects, you create a path item object and then add the path points as child objects in the

tell application "Adobe Illustrator" set docRef to make new document

-- set stroked to true so we can see the path set lineRef to make new path item in docRef with properties {stroked:true}

--giving the direction points the same value as the

--anchor point creates a straight line segment

set newPoint to make new path point of lineRef with properties ¬

{anchor:{220, 475},left direction:{220, 475},right direction:{220, 475}¬ point type:corner}

set newPoint2 to make new path point of lineRef with properties ¬

{anchor:{375, 300},left direction:{375, 300},right direction:{375, 300}¬ point type:corner}

--giving the direction points the different values

--creates a curve

set newPoint3 to make new path point of lineRef with properties ¬

{anchor:{220, 300},left direction:{180, 260},right direction:{240, 320}¬ point type:corner}

path item.

end tell

Combining path point types

The following script sample creates a path with three points by combining the entire path property with a

path point object:

tell application "Adobe Illustrator" set docRef to make new document

-- set stroked to true so we can see the path set lineRef to make new path item in docRef with properties {stroked:true} set entire path of lineRef to {{220, 475},{375, 300}} set newPoint to make new path point of lineRef with properties ¬

{anchor:{220, 300},left direction:{180, 260},right direction:{240, 320}¬ point type:corner}

end tell

Shapes

To create a shape, you use the object that corresponds to the shape’s name (such as ellipse, rectangle, or polygon), and use the object’s properties to specify shape’s position, size, and other information such as

the number of sides in a polygon.

Tip: Remember:

● All measurements and page coordinates are processed as points by the scripting engine. For more

information, see “Measurement units” on page 27

● x and y coordinates are measured from the bottom left corner of the document, as indicated in the

Info palette in the Illustrator application. For information, see “Page item positioning and

dimensions” on page 27.

Adobe Illustrator CS3

Scripting Guide Scripting with AppleScript 46

write-once access

Properties for path item shapes use the access status “write-once”, which indicates that the property is writeable only at the time the object is created. For existing path item objects, the properties are read-only properties whose values cannot be changed.

Creating a rectangle

The following sample creates a rectangle with the following properties:

● The top right corner of the of the rectangle is inset 4 inches (288 points) from the bottom of the page

and 5 inches (360 points) from the left edge of the page.

● The lower left corner of the rectangle is inset 1 inch (72 points) from the left edge of the page and 2

inches (144 points) from the bottom of the page.

tell application "Adobe Illustrator" set docRef to make new document set rectRef to make new rectangle in docRef with properties ¬

{bounds:{288, 360, 72, 144}}

end tell

Creating a polygon

The following sample creates a polygon with the following properties:

● The center point of the object is inset is 2 inches (144 points) on the horizontal axis and 4 inches (288

points) on the vertical axis.

● The length of the radius from the center point to each corner is 1 inch.

● The polygon has 7 sides.

tell application "Adobe Illustrator" set docRef to make new document set pathRef to make new polygon in docRef with properties ¬

{center point:{144, 288},sides:7,radius:72.0

end tell

Scripting with VBScript

This chapter uses script examples and explanations to help you to become familiar with Illustrator scripting using VBScript.

For more information

Several extended sample scripts are available in the /Scripting/Sample Scripts folder in your Illustrator CS3 installation directory.

For information about individual classes, objects, properties, methods and parameters, as well as script samples that demonstrate how to use many of them, refer to the Adobe Illustrator CS3 VBScript Reference, which is found in the You can also use view Illustrator CS3 type library from most VBScript editors or any Microsoft Office application. For information, see “Viewing the VBScript object model” on page 9

If you are a beginner and find that you don’t understand the concepts and terms used in this chapter, read the Adobe Introduction to Scripting.

/Scripting/Documentation folder in your Illustrator CS3 installation directory.

Your first Illustrator script

The traditional first project in any programming language is to display the message "Hello World!"

1. Start any text editor (Notepad, for example).

2. Type the following code.

Rem Hello World Set appRef = CreateObject("Illustrator.Application") Rem Create a new document and assign it to a variable Set documentRef = appRef.Documents.Add Rem Create a new text frame item and assign it to a variable Set sampleText = documentRef.TextFrames.Add Rem Set the contents and position of the TextFrame sampleText.Position = Array(200, 200) sampleText.Contents = "Hello World!"

3. Save the file as text only in a folder of your choice. Give the file the file extension .vbs.

4. To test the script, do either of the following:

● Double-click the file.

● Start Illustrator and choose File > Scripts > Other Scripts, and then navigate to and run your script

file.

Tip: To add the script to the Illustrator Scripts menu (File > Scripts), save the script in the Scripts folder. The

script will appear on the menu the next time you start Illustrator. For information, see “Installing

scripts in the Scripts menu” on page 10. Please note in general that, when you launch a VBScript script

from the Scripts menu, any

msgBox dialogs will not display correctly.

Adobe Illustrator CS3

Scripting Guide Scripting with VBScript 48

Adding features to "Hello World"

Next, let’s create a new script that makes changes to the Illustrator document you created with your first script. The second script demonstrates how to:

● Get the active document.

● Get the width of the active document.

● Resize the text frame item to match the document’s width.

Note: If you closed the Illustrator document without saving it, run your first script again to create a new

document.

1. Copy the following script into your text editor, and save the file.

Set appRef = CreateObject("Illustrator.Application") 'Get the active document Set documentRef = appRef.ActiveDocument Set sampleText = documentRef.TextFrames(1) ' Resize the TextFrame item to match the document width sampleText.Width = documentRef.Width sampleText.Left = 0

2. Run the script.

Accessing and referencing objects

When you write a script, you must first decide which file, or Document, the script should act on. Through

Application object, the script can create a new document, open an existing document, or act on a

the document that is already open.

Obtaining objects from collections

In general, to obtain a reference to a specific object, you can navigate the containment hierarchy. For example, to use the variable active document:

Set myPath = appRef.ActiveDocument.Layers(2).PathItems(1)

The following scripts demonstrate how to reference an object as part of a document.

Set documentRef = appRef.ActiveDocument Set pageItemRef = documentRef.PageItems(1)

myPath to store a reference to the first PathItem in the second layer of the

In the script below, the variable pageItemRef will not necessarily refer to the same object as the above script since this script includes a reference to a layer:

Set documentRef = appRef.ActiveDocument Set pageItemRef = documentRef.Layers(1).PageItems(1)

Adobe Illustrator CS3

Scripting Guide Scripting with VBScript 49

Note: VBScript indexes start at 1 for object collections. However, VBScript allows you to specify whether

array indexes start at 1 or 0. For information on specifying the index start number for arrays, refer to any VBScript textbook or tutorial.

Creating new objects

You can use a script to create new objects. To create objects that are available from collection objects, you use the collection object’s

Set myDoc = appRef.Documents.Add() Set myLayer = myDoc.Layers.Add()

Some collection objects do not have an Add method. You create an object of this type by defining a variable and using the the variable name

Set newColor = CreateObject ("Illustrator.CMYKColor")

newColor:

Add method.

CreateObject method. For example, to create a new CMYKColor object using

Working with selections

When the user makes a selection in a document, the selected objects are stored in the document’s selection property. To access all selected objects in the active document:

Set appRef = CreateObject ("Illustrator.Application") Set documentRef = appRef.ActiveDocument selectedObjects = documentRef.Selection

The following sample gets the first object in the array, and then displays the object’s type:

Set appRef = CreateObject ("Illustrator.Application") Set documentRef = appRef.ActiveDocument selectedObjects = documentRef.Selection Set topObject = selectedObjects(1) MsgBox(topObject.Typename)

Note: The MsgBox method does not display a dialog when the script is run from the Illustrator Scripts

menu (File>Scripts).

Note: The first object in a selection array is the selected object that was last added to the page, and not

the last object selected.

Selecting artwork objects

To select an artwork object, use the object’s Selected property.

Adobe Illustrator CS3

Scripting Guide Scripting with VBScript 50

Working with text frames

To create a text frame of a specific type in VBScript, you use the TextFrames method that corresponds to the type of frame you want to create. For example:

Set rectRef = docRef.PathItems.Rectangle(700, 50, 100, 100)

' Use the AreaText method to create the text frame Set areaTextRef = docRef.TextFrames.AreaText(rectRef)

Threaded frames

As in the Illustrator application, you can thread area or path text frames.

To thread existing text frames, you use the object.

Note: When copying the following script to a script or text editor, place the value of the Contents property

a single line. The long line continuation character (

Set appRef = CreateObject("Illustrator.Application") Set myDoc = appRef.Documents.Add Set myPathItem1 = myDoc.PathItems.Rectangle(244, 64, 82, 76) Set myTextFrame1 = myDoc.TextFrames.AreaText(myPathItem1)

myTextFrame1.Contents = "This is two text frames linked together as one story, with text flowing from the first to the last." Set myPathItem2 = myDoc.PathItems.Rectangle(144, 144, 42, 116) Set myTextFrame2 = myDoc.TextFrames.AreaText(myPathItem2)

'Use the NextFrame property to thread the frames myTextFrame1.NextFrame = myTextFrame2

appRef.Redraw()

NextFrame or PreviousFrame property of the TextFrames

_) is not valid when enclosed in a string.

Threaded frames make a single story object

Threaded frames make a single story object.

To observe this, run the following JavaScript after running the script in “Threaded frames” on page 50

var myDoc = app.activeDocument alert("There are " + myDoc.textFrames.length + " text frames.") alert("There are " + myDoc.stories.length + " stories.")

Creating paths and shapes

This section explains how to create items that contain paths.

Paths

To create a freeform path, you specify a series of path points, either as series of x-y coordinates or as

PathPoint objects.

● Using x-y coordinates limits the path to straight segments only.

Adobe Illustrator CS3

Scripting Guide Scripting with VBScript 51

● To created a curved path, you must create PathPoint objects.

Your path can consist of a combination of page coordinates and

PathPoint objects.

Specifying a series of x-y coordinates

To specify a path using page coordinate pairs, you use the SetEntirePath() method of the

PathItems object. The following script specifies three pair of x-y coordinates to create a path that has

three points.

Set appRef = CreateObject ("Illustrator.Application")

Set firstPath = appRef.ActiveDocument.PathItems.Add

firstPath.Stroked = True firstPath.SetEntirePath(Array(Array(220, 475),Array(375, 300),_

Array(200, 300)))

Using path point objects

To create a PathPoint object, you must define three values for the point:

● A fixed anchor point, which is the point on the path

● A pair of direction points: the left direction point and the right direction point, which allow you to

control the path segment’s curve

You define each property as an array of page coordinates in the format

(Array (x,y)).

● If all three properties of a PathPoint object have the same coordinates, and the properties of the

PathPoint in the line are equal to each other, you create a straight line segment.

● If two or more properties in a PathPoint object hold different values, the segment connected to

the point is curved.

To create a path, or to add points to an existing path, using object and then add the path points as child objects in the

PathPoint objects, you create a PathItem

PathItem.

Set appRef = CreateObject ("Illustrator.Application")

Set firstPath = appRef.ActiveDocument.PathItems.Add

firstPath.Stroked = true Set newPoint = firstPath.PathPoints.Add 'Using identical coordinates creates a straight segment newPoint.Anchor = Array(75, 300) newPoint.LeftDirection = Array(75, 300) newPoint.RightDirection = Array(75, 300)

Set newPoint2 = firstPath.PathPoints.Add newPoint2.Anchor = Array(175, 250) newPoint2.LeftDirection = Array(175, 250) newPoint2.RightDirection = Array(175, 250)

Set newPoint3 = firstPath.PathPoints.Add 'Using different coordinates creates a curve newPoint3.Anchor = Array(275, 290) newPoint3.LeftDirection = Array(135, 150) newPoint3.RightDirection = Array(155, 150)

Adobe Illustrator CS3

Scripting Guide Scripting with VBScript 52

Combining path point types

The following script sample creates a path with three points:

Set appRef = CreateObject("Illustrator.Application") Set myDoc = appRef.ActiveDocument Set myLine = myDoc.PathItems.Add

myLine.Stroked = True

myLine.SetEntirePath( Array( Array(320, 475), Array(375, 300)));

// Append another point to the line Set newPoint = myDoc.myLine.PathPoints.Add

'Using identical coordinates creates a straight segment

newPoint.Anchor = Array(220, 300)

newPoint.LeftDirection = Array(220, 300)

newPoint.RightDirection = Array(220, 300)

Shapes

To create a shape, you use the PathItems method that corresponds to the shape’s name (such as ellipse, rectangle, or polygon), and use parameters to specify shape’s position, size, and other characteristics such

as the number of sides in a polygon.

Tip: Remember:

● All measurements and page coordinates are processed as points by the scripting engine. For more

information, see “Measurement units” on page 27

● x and y coordinates are measured from the bottom left corner of the document, as indicated in the

Info palette in the Illustrator application. For information, see “Page item positioning and

dimensions” on page 27.

Creating a rectangle

The following sample creates a rectangle with the following properties:

● The top of the rectangle is 2 inches (144 points) from the bottom edge of the page.

● The left edge is 2 inches (144 points) from the left edge of the page.

● The rectangle is 1 inch wide and 2 inches long.

Set appRef = CreateObject("Illustrator.Application") Set frontDocument = appRef.ActiveDocument ' Create a new rectangle with ' top = 400, left side = 50, width = 150, height = 100 Set newRectangle = frontDocument.PathItems.Rectangle(400,50,150,100)

Creating a polygon

The following sample creates a polygon with the following properties:

● The center point of the object is inset 2 inches (144 points) on the horizontal axis and 4 inches (288

points) on the vertical axis.

● The length of the radius from the center point to each corner is 1 inch.

Adobe Illustrator CS3

Scripting Guide Scripting with VBScript 53

● The polygon has 7 sides.

Set appRef = CreateObject("Illustrator.Application") Set frontDocument = appRef.ActiveDocument ' Create a new rectangle with ' top = 400, left side = 50, width = 150, height = 100 Set newPolygon = frontDocument.PathItems.Polygon(144,288,72,7)

Working with enumeration values

Properties that use enumeration values in VBScript use a numeral rather than a text value. For example,

Orientation property of the TextFrame object specifies whether text content is horizontal or

the vertical in the text frame. The property uses the possible values:

● aiHorizontal

● aiVertical

To find the numeral values of enumerations, use either of the following:

● The object browser in your scripting editor environment. For information, see “Viewing the VBScript

object model” on page 9.

aiTextOrientation enumeration, which has two

● The Adobe Illustrator CS3 VBScript Reference, which lists the numeral values directly after the constant

value in the Enumerations chapter at the end of the book. The following example is taken from that table:

Enumeration Type Values What it means

AiTextOrientation aiHorizontal = 0

aiVertical = 1

The orientation of text in a text frame

The following sample specifies vertical text orientation:

Set appRef = CreateObject ("Illustrator.Application") Set docRef = appRef.Documents.Add Set textRef = docRef.TextFrames.Add textRef.Contents = "This is some text content." textRef.Left = 50 textRef.Top = 700 textRef.Orientation = 1

Note: Generally, it is considered good scripting practice to place the text value in a comment following

the numeral value, as in the following sample statement:

textRef.Orientation = 1 ' aiVertical

Index

actions, about 7 Adobe Illustrator

Plug-in Software Development Kit Function Reference 29 aki properties 27 anchor points 29 AppleScript

dictionary 9
