Lucent Technologies R8r User Manual

DEFINITY
®
Enterprise Communications Server
Release 8.2 Upgrades and Additions for R8r
555-233-115 Comcode 108678335 Issue 1 April 2000
Copyright  2000, Lucent Technologies All Rights Reserved Printed in U.S.A.
Notice
Every effort was made to ensure that the informa tion in thi s book was complete and accura te at th e time o f prin tin g. Howev er , in format ion is subject to change.
Your Responsibility for Your System’s Security
Toll fraud is the unauthorized use of your tel ec ommunications system by an unauthorized party, for example, persons other than your com-
pany’s employees, agents, subcontractors, or persons working on your company’ s beh alf. Not e t hat t her e ma y be a ris k of toll f rau d ass oci at ed with your telecommunications system and, if toll fraud occurs, it can result in substantial additional charges for your telecommunications services.
This equipment returns answer-supe rvi sion signals on all DID calls forwarded back to the publ i c sw itched telephone network. Permissible exceptions are:
• A call is unanswered
• A busy tone is received
• A reorder tone is received
Canadian Department of Communications (DOC) Interference Information
This digital apparatus does no t exceed the Class A limits for radio noise emissions set out in the radi o int er f erence regulations of the Canadian Department of Com m unications.
Le Présent Appareil Nom
dépassant les limites applicables aux appareils numériques de la class A préscrites dans le reglement sur le brouillage radioélectrique édicté par le ministére des Communications du Canada.
érique n’é
met pas de bruits radioélectriques
You and your system manager are responsible for the security of your system, such as programming and confi guring your equipment to pre­vent unauthorized use. The system manager is also responsibl e for reading all installation, instruc tion, and system administration doc u­ments provided with this pro duct in order to fully understand th e fe a­tures that can introduce risk of toll fraud and the steps that can be taken to reduce that risk. Lucent Technologies does not warrant that this product is immune fro m or will prevent unauthorized use of com­mon-carrier telecommun ic ation services or facili ti es accessed through or connected to it. Lucent Technologies will not be responsible for any charges that result from such unauthorized use.
Lucent Technologies Fraud I n tervention
If you suspect that you are being victimized by toll fraud and you need technical support or assistan ce , c al l Technical Service Cen ter Toll Fraud Intervention Hotline at 1 800 643-2353 or contac t your local Lucent repr esentative .
Federal Communica tions Commissi on S ta tement Part 15: Class A Statement. This equipment has been tested and
found to comply with the limits for a Class A digital device, pursua nt to Part 15 of the FCC Rules. These limits are design ed to provide rea­sonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio-frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interfer­ence to radio communications. Operation of this equipment in a resi­dential area is likely to cause harmful interference, in which case the user will be required to correct th e in te rfe re nce at his own expense.
Part 68: Network Registration Number. This equipment is registered with the FCC in accordan ce with Part 68 of the FCC Rules. It is identi­fied by FCC registration number AS593M-13283-MF-E.
Trademarks
See the preface of this docum e nt.
Ordering Information Call: Lucent Technologies BCS Publications Center
Voice 1 800 457-1235 International Voice 317 322-6416 Fax 1 800 457-1764 International Fax 317 322-6699
Write: Lucent Technologies BCS Publications Center
2855 N. Franklin Road Indianapolis, IN 46219
Order: Document No. 555-233-115
Comcode 10867833 5 Issue 1, April 2000
For additional documents, refer to the section in “About This Docu­ment” entitled “Related Resources.”
Y ou can be placed on a standing order list for this and other documents you may need. Standing order will enable you to automatically receive updated versions of individu al documents or document sets, billed to account information that you provide. For more information on stand­ing orders, or to be put on a list to receive future issues of this docu­ment, contact the Lucent Technologies Publications Ce nt er.
European Union Declaration of Conformity
The “CE” mark affixed to the DEFIN ITY® equipment described in this book indicates that the e quipment conforms to the foll ow i ng Euro­pean Union (EU) Directives:
• Electromagne tic Compatibility (89/336/EEC)
• Low Voltage (73/23/EEC)
• Telecommunications Terminal Equi p ment (TTE) i-CTR3 BRI and i-CTR4 PRI
For more information on standards compliance, contact your local dis­tributor.
Part 68: Answer-Supervision Signaling. Allowing this equipment to be operated in a manner that does not provide proper answ e r-supervi ­sion signaling is in violation of Part 68 Rule s. This e qui pm e nt retu rns answer-supervision signals to the public switched netw ork whe n:
• Answered b y the called station
• Answered by the attendant
• Routed to a recorded announcement that can be administered by the CPE user
Comments
To comment on this document, re turn the comment ca rd at the front of the document.
Acknowledgment
This document was prepared by Product Documentation Development, Lucent Technologies, Denver, CO.
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
555-233-115

Contents

Contents
Contents iii
What’s New in Release 8.2r vii About This Book xv
Offer Categories xv
Security Issues xvi
Antistatic Protection xvi
Remove/Install Circuit Packs xvi
Upgrade Paths xvii
Conventions Used in This Book xviii
Related Books xix
How to Order Books xix
How to Comment on This Book xx
Issue 1
April 2000
iii
Where to Call for Technical Support xx
Trademarks xxi
Standards Compliance xxii
LASER Product xxiii
Electromagnetic Compatibility Standards xxiii
Federal Communications Commission Statement xxv
1 Upgrading G3rV2, V3, V4 to R8r and
Adding Memory 1-1
Read This First 1-2
Task Tables 1-4
Upgrade the software and hardware 1-6
2 Upgrading R5r/R6r/R7r to R8r
without Adding Memory 2-1
Read This First 2-2
Task Tables 2-5
Upgrade the software and hardware 2-7
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
555-233-115
Contents
3 Upgrading R5si/R6si to R8r EPN
and Adding Memory 3-1
Read This First 3-2
Task Tables 3-6
Preliminary Procedures 3-8
Release 5/6si to Release 8r 3-10
DEFINITY AUDIX Power Procedures 3-56
4 G3vs with Intel 386 or Risc
Processor to R8r 4-1
Read This First 4-2
Task Tables 4-4
Preliminary Procedures 4-6
Remove the Present System 4-7
Install the Release 8r Cabinets 4-11
Upgrade Completion 4-16
Issue 1
April 2000
iv
DEFINITY AUDIX Power Procedures 4-19
5 Multicarrier G2 Universal Module
to R8r EPN 5-1
Single-Mode Fiber Attenuators 5-1
Read This First 5-2
Task Tables 5-10
Standard Reliability 5-15
High Reliability 5-44
Critical Reliability 5-75
6 Adding or Removing Cabinet Hardware 6-1
Single-Mode Fiber Attenuators 6-1
Add Circuit Packs 6-2
List of Circuit Packs 6-3
Add the Fiber Optic Cable 6-8
Install a New EPN Cabinet in an Existing System 6-22
Remove an EPN Cabinet from an Existing System 6-34
Add External Modem to EPN 6-41
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
555-233-115
Contents
Add DCS Interface 6-42
Add IP Interface Assembly 6-45
Add TTC Japanese 2Mbit Trunks 6-79
Add a Control Carrier (Add Duplication) 6-80
Add a Switch Node Carrier (Standard Reliability) 6-94
Add a Switch Node Carrier (High or Critical Reliability) 6-108
Add Center Stage Switch 6-123
Add MCC Port Carriers 6-128
DEFINITY AUDIX Power Procedures 6-141
Installing an Integrated Channel
Service Unit (ICSU) Module 6-142
Installing a 3150/3170 Channel Service Unit 6-146
A Fiber Link Administration A-1
Administer Fiber Links A-1
Issue 1
April 2000
v
B Troubleshooting an Upgrade B-1
New for Release 8 B-2
Troubleshooting Guidelines B-7
Troubleshooting Release 8 Upgrades B-9
C Access Security Gateway C-1
Using the ASG Mobile C-2
GL Glossary and Abbreviations GL-1 IN Index IN-1
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
Contents
555-233-115
Issue 1
April 2000
vi
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
555-233-115

What’s New in Release 8.2r

What’s New in Release 8.2r
This is a short list of what changed from Release 7r. For more detailed information, refer to categories addressed are as follows:
Features
Hardware
Tools
DEFINITY ECS Release 8 What’s New in Release 8
Issue 1
April 2000
vii
. The
Commands, screens, and fields
Pr ocedures
Upgrade tips
Cautions and warnings
Product names

Features

This list provides categorized features available with Release 8.2. For full descriptions, see
1.0 Change Description.
Phone features Networking — ISDN Public
64 bridged call appearances ATM circuit emulation service (CES) Abort transfer Feature plus — non-DID calling via UDP
Automatic exclusion Restricted Presentation Circular station hunting Multiple pubnet calling/connect
Coverage of calls redirected off-net Pass advice of charge to BRI (basic rate
DEFINITY Enterprise Communications Server Release 8, Issue
numbers/system
interface) endpoints Group call pic k -up BellCore calling name ID Long hold recall - warning
Networking — QSIG
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
What’s New in Release 8.2r
Reset shift call Call-independent signaling connection (CISC)
Station self display VALU distinc tive alerting
Call Center
Advocate related enhancements Transfer to Audix
555-233-115
April 2000
enhancements
VALU call coverage
Issue 1
viii
ASAI/computer telephony integration (CTI) enhancements
Increased Call Center capacities (G3r) CAS Attendant display of COR Site stats for ATM connected remote EPNs CAS Attendant return call CMS measurement of ATM trunks CAS Display enhancements CALLMASTER V (CC 6416D+) native support CAS Priority queue PASTE updat e CAS RLT emulation via PRI CentreVu comp uter Telephony on MAPD
DEFINITY Wireless Business Systems
Coverage interaction support
Green to Standard
13-digit authorization codes (red to std)
(DWBS)
X-station mobility
Hospitality
Auto digit rotation for direct inward dial Interworking with bandwidth constricted ATM
Crisis ale rt to pager ATM - Hybrid reli ability Suite check-in via the hunt-to feature
International
Administrable loss plan Restart notification
Brazil and Hungary — E&M signaling Reliabili ty options
Networking — Other
IP Solutions
networks
System availability/serviceability
Opt ical drive
China — special dial ton e C-LAN serviceability tools China — time supervision & forced release Japan — Support for Japan National Private
Networking Japan — Transfer Call Back 6400 tip/ring module Brazil and Hungary — E&M signaling Fast analog modem support
Terminal support
IDS (6200) family of analog terminals native
support
Security Platform
DADMIN login 24-port analog line (TN793/TN2793B) with
Caller ID
Analog trunk & line board (TN797) without
busy tone detection
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
555-233-115
What’s New in Release 8.2r

Hardware

Minimum required hardware

You need the following minimum required hardware to upgrade to Release 8.2r software.
Code
Equipment
Comcode Notes
Issue 1
April 2000
ix
Basic processor carrier J58890AP-
Duplex processor carrier J58890AP-
Contains the following circuit packs:
TN573B SNI
TN780 tone clock
TN1648B SYSAM
TN1650B memory
TN1655 packet interface
TN1657 disk drive
TN2211 optical drive
UN330B duplicate interface (opt.)
UN331B processor
UN332C MSSNet
Contains the following circuit packs:
TN573B SNI
TN780 tone clock
TN1648B SYSAM
TN1650B memory
TN1655 packet interface
Power unit WP-
TN1657 disk drive
TN2211 optical drive
UN330B duplicate interface
UN331B processor
UN332C MSSNet
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
What’s New in Release 8.2r
555-233-115

R8.2r hardware

The following upgrade equipment is new to Release 8.2r.
Code
Equipment
Comcode Notes
Issue 1
April 2000
x
Optical drive TN2211
107849754
MSSNet UN332C
108566381
Formatted removable media
J58890TO-1 If duplicated system,
with R8.2 software

Additional hardware available

The following equipment is port slot hardware introduced with Release 8.2r.
Code
Equipment
DS1 interface TN2313
Analog line TN793
Analog trunk/line combo TN797
Control-LAN (C-LAN) TN799B
Comcode Notes
108382607
103557468
103557500
108525528
If duplicated system, you need 2
If duplicated system, you need 2
you need 2
Cost reduction, no new features
24-port analog line with CID
Combines an analog trunk and line into one circuit pack.
Updates TN799; enables trace route command
IP interface assembly TN802B
108517996
Updates TN802; expansion of IP trunk; introduces two modes: Media Processor Mode and IP Trunk Mode

Discontinued hardware

The following equipment was discontinued with Release 8.2si.
Equipment Notes
TN1656 tape drive Replaced with the TN2211 optical drive UN332/B MSSNet The TN2211 optical drive requires the UN332C
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
What’s New in Release 8.2r
555-233-115

To ol s

No new tools became available with Release 8.2r.

Commands, screens, and fields

No new commands and screens became available or were affected by Release
8.2r.

Procedures

The following procedures and steps changed or were added because of problems identified in the laboratory or during early introduction.
Many of the upgrade procedures were reordered and the steps within the procedure better defined. Check the task tables at the beginning of each upgrade chapter for the current order.
Issue 1
April 2000
xi
Also, to reduce redundancy in the book, there is no longer a separate upgrade process for high or critical reliability. The procedures and steps that apply to high or critical reliability are noted where they occur in the upgrade process.
Procedure Steps Notes
Check SPE
1. Type
status spe
Enter to check the health of
an d pr e s s
Becomes first step of upgrade procedure
the SPE.
Install the Circuit Packs
1. Insert the TN1650B memory circuit pack in memory slot 3.
Adding memory to the standby SPE causes an error because the memory number between the standby and active carriers does not match.
This requires an additional power down of the carrier.
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
What’s New in Release 8.2r
555-233-115
Procedure Steps Notes
Issue 1
April 2000
xii
Verify Interchange (H/C only)
After the circuit packs have been replaced in the first carrier:
1. Type
status spe
Enter:
The
Standby
Refreshed
an d pr e s s
field shows
no
The
Standby
Shadowing
field shows
off
The
Standby
Handshake
field shows
up
After the circuit packs have bee n replaced in the second carrier:
1. Type
status spe
Enter to make sure the
an d pr e s s
active side is ready for interchange. When it is ready,
Because of the memory mismatch between the standby and active SPEs, typing the
status spe
command yields two different scenarios.
Upgrade other carrier (H/C only)
Upgrade Sof tware
The
Standby
Refreshed
field shows
yes
The
Standby
Shadowing
field shows
on
The
Standby
Handshake
field shows
up
Both SPEs show
functional
To upgrade the other carrier, lock the SPE switches on the DUPINT to the other carrier.
This command copies the software from the removable media to the system disk and takes about 15 minutes to co mplete.
Th e new active carrier reset s (cold 2 restart). Wait until the login prompt appea rs then log in.
All calls are dropped—this is a service interruption
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
What’s New in Release 8.2r
555-233-115

Upgrade tips

The following upgrade tips were generated from problems identified in the laboratory or during early introduction.
Adding a third memory circuit pack and an optical drive requires a second
non-call-preserving service interruption. See Chapter 1, ‘‘Upgrading
G3rV2, V3, V4 to R8r and Adding Memory’’.
When upgrading a DEFINITY ECS R8r to a duplicated system (B carrier)
or adding a switch node carrier (D carrier), you may receive a carrier that looks different than the ones currently installed. The enhanced carriers come with 16 grounding straps that connect to the carrier connector panel. See ‘‘Add a Control Carrier (Add Duplication)’’ on page 6- 80
a Switch Node Carrier (Standard Reliability)’’ on page 6-94, and ‘‘Add a Switch Node Carrier (High or Critical Reliability)’’ on page 6-108.
NOTE:
An enhanced carrier is used only in an R8r PPN cabinet that uses either AC power (U.S.) or Global power.
Issue 1
April 2000
xiii
, ‘‘Add

Cautions and warnings

The following new cautions and warnings were generated from problems affecting possible data loss that were identified in the laboratory or during early introduction.
Procedure Caution or Warning
Unlock the Active SPE (H/C only)
Upgrade Sof tware
!
CAUTION:
Allow 10 minutes after unlocking to make sure the standby SPE has fully returned to service.
!
CAUTION:
All calls are dropped—this is a service interruption
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
What’s New in Release 8.2r
555-233-115

Product names

The following products have been renamed.
Product name Old name Note
Removable media tape Optical drive does not use tapes.
Issue 1
April 2000
xiv
We chose a name that is generic to whatever media is used in the future.
IP interface assembly (TN802B)
IP trunk (TN802) TN802B adds MedPro mode; not
just IP trunk.
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r

About This Book

555-233-115
About This Book
Issue 1
April 2000
xvOffer Categories
This book is intended for use by trained installation technicians and provides procedures for upgrading existing systems to a DEFINITY Communications Server Release 8.2. This book is intended to cover software and hardware upgrades and additions to existing systems only.
Other hardware installation procedures are in
Communications Server Release 8 Installation and Test for Multicarrier Cabinets
To add adjuncts and peripheral devices, refer to
Communications Server Release 7 Installation for Adjuncts and Peripherals.

Offer Categories

Features are limited depending on the category purchased by the customer . Offer Category A allows access to all DEFINITY features. Offer Category B allows access to a subset of DEFINITY features. Contact your Lucent Technologies representative for more information.
®
Enterprise
DEFINITY Enterprise
DEFINITY Enterprise
.
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
About This Book
555-233-115

Security Issues

To ensure the greatest security possible for customers, Lucent Technologies offers services that can reduce toll-fraud liabilities. Contact your Lucent Technologies representative for more security information.
Login security is an attribute of the DEFINITY ECS software. Existing passwords expire 24 hours after installation.

Access Security Gateway Feature

Login security for the System-Parameters Customer-Options forms use the
access security gateway interface for the “init” login. This feature is active for dial-up access only. It is not active when accessing the DEFINITY via the SAT. Access security gateway is automatically imposed during the upgrade.

Antistatic Protection

Issue 1
April 2000
xviSecurity Issues
!
CAUTION:
When handling circuit packs or any components of a DEF INITY System, always wear a wrist ground strap. Connect the strap to an approved ground suc h as the ground jack on the DEFINITY Sys tem.

Remove/Install Circuit Packs

!
CAUTION:
The control circuit packs with white labels cannot be removed or installed when the power is on. The port circuit packs with gray labels (older version circuit packs had purple labels) can be removed or installed w hen the power is on.
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
About This Book
555-233-115

Upgrade Paths

The upgra de paths des cr ibed i n this book as s ume the sys t em being u pgr aded i s at the level of at least a G3V4. To upgrade prior systems to this starting point, refer to
DEFINITY Communications System Generic 3r Upgrades and Additions
Issue 1
April 2000
xviiUpgrade Paths
.
Table 1
correlates each upgrade to an associated chapter number.
Table 1. Software and Hardware Upgrade Chapters
Description Chapter
Upgrading G3rV2, V3, V4 to R8r and Adding Memory Upgrading R5r/R6r/R7r to R8r without Adding Memory Upgrading R5si/R6si to R8r EPN and Adding Memory G3vs with Intel 386 or Risc Processor to R8r Multicarrier G2 Universal Module to R8r EPN
1
2
3 4 5
If upgrading from a pre-Release 5vs to a DEFINITY ECS Release 8si, refer to
DEF INIT Y E nterprise Communications Server Release 8 Upgrades and Additions for R8si
.
The following table indicates the processes and their corresponding time allotment. Not all processes are required for every upgrade; the table shows maximum times and includes high and critical reliability processes.
Process Minutes
Busyout multime dia inter face circuit packs 2 Disable/enable TTI 2 Disable/enable scheduled maintenance 2 Disable/enable alarm origination to INADS 2 Save announcements (TN750/B Only) 40 Save translations 10 Backup disk 25-50 Verify software release 5 Replace disk drives and circuit packs 10 Set tone, lock, power down, power up, and unlock
30
active and standby SPE Restore disk full (both) 30
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
About This Book
555-233-115
Process Minutes
Restore disk install (both) 12 Upgrade software 15 Configure removable media 2 Set vector f 2 Reset standby 4 5 Status spe 10 Shutdown/restart AUDIX and LAN Gateway 20 Miscellaneous 5

Conventions Used in This Book

Issue 1
April 2000
xviiiConventions Used in This Book
Information you type is shown as:
command you typed, press the keyboard, not the
Information displayed on the screen is shown as:
Keyboard keys are shown as: Enter
Circuit pack codes (for example, TN792 or TN754B) are shown with the
minimum acceptable
Enter/Return key in the letters section.
alphabetic suffix (like the “B” in the code “TN754B”).
save announcements
Enter key in the numbers section of the
. To submit the
login:
Generally, an alphabetic suffix higher than the 1 shown is also acceptable. However, not every
vintage
of either the minimum suffix or a higher suffix
code is necessarily acceptable.
NOTE:
Refer to
Vintages and Change Notices
Technical Monthly: Reference Guide for Circuit-Pack
, for current information about the usable vintages of specific circuit pack codes (including the suffix) in a Release 8 system.
The following conventions describe the systems referred to in this book.
The word
system
, is a general term encompassing Release 8 and
includes references to the DEFINITY Enterprise Communications Server.
DEFINITY Systems in this book are called: G3V2, G3v3, G3V4, Release 5,
Release 5si + memory, Release 5r, Release 6, Release 6si, Release 6r, Release 8r, Release 8, and Release 8si.
Information in this book is applicable for Release 5 through Release 8,
unless otherwise specified.
DEFINITY Enterprise Communications Server is abbreviated DEFINITY
ECS.
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
About This Book
555-233-115

Related Books

The following books are useful for system-related information:
DEFINITY Enterprise Communications Server Release 8 S ystem Description Pocket Reference
DEFINITY Enterprise Communications Server Release 8 Maintenance for R8r
DEFINITY Enterprise Communications Server Release 8 Maintenance for R8si
DEFINITY Enterprise Communications Server Release 8 Installation and Test for Single-Carrier Cabinets
DEFINITY Enterprise Communications Server Release 8 Installation and Test for Multicarrier Cabinets
DEFINITY Enterprise Communications Server Release 8 Administrator’s Guide
DEFINITY Enterprise Communications Server Release 8 Upgrades and Additions for R8si
Issue 1
April 2000
xixRelated Books
DEFINITY Enterprise Communications Server Release 8 Installation for Adjuncts and Peripherals
AT&T Network and Data Connectivity Reference
BCS Products Security Handbook
DE FINITY Wireless Business System Users Guide
DEFINITY Wireless Business System Installation and Test Guide
DEFINITY Wireless Business Systems System Interface
Switch Administration for DEFINITY AUDIX
DEFINITY Enterprise Communications Server Release 8 Administration for Network Connectivity

How to Order Books

In addition to this book, other description, installation and test, maintenance, and administration books are available. A complete list of DEFINITY books can be found in the
This book and any other DEFINITY books can be ordered directly from the Luc ent Technologies Bus i nes s Comm uni cation s System Publications Fulfillment Center at 1-317-322-6791 or toll free at 1-800-457-1235.
Business Communications System Publications Catalog
.
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
About This Book
555-233-115

How to Comment on This Book

Lucent Technologies welcomes your feedback. Please fill out the reader comment card found at the front of this manual and return it. Your comments are of great value and help improve our documentation.
If the reader comment card is missing, FA X your comments to 1-303-538-1741 or
to your Lucent Technologies representative, and mention this book’s name and number (in footer),
Upgrades and Additions for R8r
DEFINITY Enterprise Communication Server Release 8
.

Where to Call for Technical Support

Refer to the table below for the telephone numbers for technical support.
Issue 1
April 2000
xxHow to Comment on This Book
Tel ep ho n e N um be r
DEFINITY Helpline (feature administration and system applications)
Luc ent Tec hnologies Toll Fraud Intervention 1-800-643-2353 Lucent Technologies National Customer Care Center 1-800-242-2121 Lucent Technologies Corporate Security 1-800-822-9009 Streamlined Implementation (for missing equipment) 1-800-772-5409 USA/Canada Technical Service Center 1-800-248-1234 ITAC 1-303-804-3777 Luc ent Tec hnol ogies Center s of Excelle nce
Asia/Pacific Regional Support Center 65-872-8686 Western Europe/Middle East/South Africa 44-1252-77-4800 Central/Eastern Europe 361-345-4334 Central/Latin America Caribbean 1-303-804-3778 Australia 61-2-9352-9090 North America (INADS Database Administra tio n) 1-800-248-1111
1-800-225-7585
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
555-233-115
About This Book

Trademarks

This document contains references to the following Lucent Technologies trad em arke d prod ucts:
ACCUNET
AUDIX
Callmaster
CallVisor
CONVERSANT
DEFINITY
FORUM
MEGACOM
SYSTIMAX
TRANSTALK
®
®
®
®
®
®
®
®
Issue 1
April 2000
xxiTrademarks
The following products are trademarked by their appropriate vendor:
Audichron
LINX
Music Mate
PagePac
®
is a registered trademark of Audichron Company
is a trademark of Illinois Tool Works, Inc.
®
is a registered trademark of Harris Corporation
®
is a registered trademark of Harris Corporation, Dracon
Division
Shockwatch
Styrofoam
Tiltwatch
Zone Mate
®
is a registered trademark of Media Recovery, Incorporated
®
is a registered trademark of Styrofoam Corporation
®
is a registered trademark of Media Recovery, Incorporated
®
is a registered trademark of Harris Corporation
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
555-233-115
About This Book

Standards Compliance

The equipment presented in this book complies with the following standards (as appropriate):
ITU-T (Formerly CCITT)
ECMA
ETSI
IPNS
DPNSS
National ISDN-1
National ISDN-2
ISO-9000
ANSI
FCC Part 15 and Part 68
Issue 1
April 2000
xxiiStandards Compliance
EN55022
EN50081
EN50082
CISPR22
Australia AS3548 (AS/NZ3548)
Australia AS3260
IEC 825
IEC 950
UL 1459
UL 1950
CSA C222 Number 225
TS001
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
About This Book
555-233-115

LASER Product

The DEFINITY ECS may contain a Class 1 LASER device if single-mode fiber optic cable is connected to a remote Expansion Port Network (EPN). The LASER device operates within the following parameters:
Maximum Power Output: -5 dBm Wavelength: 1310 nm Mode Field Diameter: 8.8 mm
CLASS 1 LASER PRODUCT IEC 825 1993
!
CAUTION:
Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
Contact your Lucent Technologies representative for more information.
Issue 1
April 2000
xxiiiLASER Product

Electromagnetic Compatibility Standards

This product complies with and conforms to the following EMC standards (as appropriate):
Limits and Methods of Measurements of Radio Interference
Characteristics of Information Technology Equipment, EN55022 (CISPR22), 1993
EN50082-1, E uropean Generic Immunity Standard
FCC Part 15
Australia AS3548
NOTE:
The system conforms to Class A (industrial) equipment. Voice terminals meet Class B requirements.
Electrostatic Discharge (ESD) IEC 1000-4-2
Radiated radio frequency field IEC 1000-4-3
Electrical Fast Transient IEC 1000-4-4
Lightning effects IEC 1000-4-5
Conducted radio frequency IEC 1000-4-6
Mains frequency magnetic field IEC 1000-4-8
Low frequency mains disturbance IEC 1000-4-11
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
555-233-115
About This Book

European Union Standards

Lucent Technologies Business Communications Systems declares that the
DEFINITY equipment specified in this book bearing the “CE” mark conforms to the European Union Electromagnetic Compatibility Directives.
The “CE” (Conformité Europeénne) mark indicates conformance to the European Union Electromagnetic Compatibility Directive (89/336/EEC) Low Voltage Directive (73/23/EEC) and Telecommunication Terminal Equipment (TTE) Directive (91/263/EEC) and with i-CTR3 Basic Rate Interface (BRI) and i-CTR4 Primary Rate Interface (PRI) as applicable.
The “CE” mark is applied to the following Release 8 products:
Global AC powered Multicarrier Cabinet (MCC)
DC powered Multicarrier Cabinet (MCC) with 25 Hz ring generator
AC powered Single-Carrier Cabinet (SCC) with 25 Hz ring generator
AC powered Compact Single-Carrier Cabinet (CSCC) with 25 Hz ring
generator
Issue 1
April 2000
xxivElectromagnetic Compatibility Standards
Enhanced DC Power System
Compact Modular Cabinet (CMC) with 25 Hz ring generator
Compact Modular Cabinet (CMC) with 50 Hz ring generator for France
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
About This Book
555-233-115

Federal Communications Commission Statement

Part 68: Statement

Part 68: Answer-Supervision S ignaling. Allowing this equipment to be operated in a manner that does not provide proper answer-supervision signaling is in violation of Part 68 rules. This equipment returns answer-supervision signals to the public switched network when:
Answered by the called station
Answered by the attendant
Routed to a recorded announcement that can be administered by the CPE
user
This equipment returns answer-supervision signals on all DID calls forwarded back to the public switched telephone network. Permissible exceptions are:
Issue 1
April 2000
xxvFederal Communications Commission Statement
A call is unanswered
A busy tone is received
A reorder tone is received
Lucent Technologies attests that this registered equipment is capable of providing users access to interstate providers of operator services through the use of access codes. Modification of this equipment by call aggregators to block access dialing codes is a violation of the Telephone Operator Consumers Act of
1990. This equipment complies with Part 68 of the FCC Rules. On the rear of this
equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment. If requested, this information must be provided to the telephone company.
The REN is used to determine the quantity of devices which may be connected to the telephone line. Excessive RE Ns on the telephone line may result in devices not ringing in response to an incoming call. In most, but not all areas, the sum of RENs should not exceed 5.0. To be certain of the number of devices that may be connected to a line, as determined by the total RENs, contact the local telephone company.
NOTE:
REN is not required for some types of analog or digital facilities.
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
About This Book
555-233-115
Means of Connection
Connection of this equipment to the telephone network is shown in the following table.
Manufacturer’s Port Identifier FIC Code
Off/On Premises Station OL13C 9.0F RJ2GX, RJ21X,
DID Trunk 02RV2-T 0.0B RJ2GX, RJ21X CO Trunk 02GS2 0.3A RJ21X CO Trunk 02LS2 0.3A RJ21X Tie Trunk TL31M 9.0F RJ2GX
1.544 Digital Interface 04DU9-B,C 6.0P RJ48C, RJ48M
1.544 Digital Interface 04DU9-BN,KN 6.0P RJ48C, RJ48M 120A2 Channel Service Unit 04DU9-DN 6.0P RJ48C
Issue 1
April 2000
xxviFederal Communications Commission Statement
SOC/REN/ A.S. Code Network Jacks
RJ11C
®
If the terminal equipment (DEFINITY
System) causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. But if advance notice is not practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary.
The telephone company may make changes in its facilities, equipment, operations or procedures that could affect the operation of the equipment. If this happens, the telephone company will provide advance notice in order for you to make necessary modifications to maintain uninterrupted service.
If trouble is experienced with this equipment, for repair or warranty information, please contact the Technical Service Center at 1-800-248-1234. If the equipment is causing harm to the telephone network, the telephone company may request that you disconnect the equipment until the problem is resolved.
It is recommended that repairs be performed by Lucent Technologies certified technicians.
The equipment cannot be used on public coin phone service provided by the telephone company. Connection to party line service is subject to state tariffs. Contact the state public utility commission, public service commission or corporation commission for information.
This equipment, if it uses a telephone receiver, is hearing aid compatible.
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r

Upgrading G3rV2, V3, V4 to R8r and Adding Memory

1
555-233-115
Upgrading G3rV2, V3, V4 to R8r and Adding Memory
This chapter provides the information necessary to upgrade the software from a DEFINITY G3rV2, V3, or V4 system to a Release 8r system. The chapter also provides information on replacing the following hardware:
Issue 1
April 2000
1-1
1
The TN1657 disk drive if drive is
The TN 1656 tape drive with the TN2211 optical drive
The UN332/B MSSNET circuit pack with the UN332C circuit pack
(required for the optical drive)
A TN1650B memory circuit pack if the system does not contain 3 of these
circuit packs
NOTE:
Adding memory to the standby SPE causes an error because the memory number between the standby and active carriers does not match.
If the system already contains 3 TN1650B Memory circuit packs and a V4 or later TN1657 disk drive, skip to
Adding Memory’’.
The procedures step you through a software and hardware upgrade that can be done on either a standard reliability system or a high or critical reliability system.
For more help refer to the following books:
— DEFINITY Enterprise Communications Server Release 8 Administrator’s
Guide
— DEFINITY Enterprise Communications Server Release 8 Maintenance for
R8r
Chapter 2, ‘‘Upgrading R5r/R6r/R7r to R8r without
not
Vintage 4 or later.
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
Upgrading G3rV2, V3, V4 to R8r and Adding Memory
1
555-233-115

Read This First

Service Interruption

The upgrade process requires 2 non–call-preserving service interruptions in a standard reliability system and must be closely coordinated with the customer and the local account team.

Call Management System (CMS)

The CMS link is dropped and restarted during the upgrade. This causes CMS data to be lost. This data loss can be minimized if the upgrade is performed just after the last CMS measurement interval.
All measurement data is lost during the upgrade (including BCMS). If needed, the reports may be printed before the upgrade begins.
CMS could abort the processing of a call if a measured trunk that was part of the conference dropped off the call before the end of the call. Customers experiencing this symptom and who are running R3V4 CMS should update to r3v4ao.e or higher.
Issue 1
April 2000
1-2Read This First

Software Compatibility and Translation Errors

Before starting the upgrade, always check the accompanies the system removable media. Translation corruption will occur if incompatible software is loaded.
After loading the new software, check for translation errors. To do this, log off and then log back in. Check for a “Translation Corruption Detected” message before proceeding with the upgrade.
If the message indicates errors, refer to ‘‘No Translations After Upgrade’’
Appendix B, ‘‘Troubleshooting an Upgrade’’
until the errors are corrected.

Usable Circuit Packs

Every circuit pack used in the Re lease 8 system must conform to the minimum usable vintage requirements for that system. At a presale site inspection, the remediation process checks the vintages of existing circuit packs to be reused in the Release 8 system. Replace all unusable vintage circuit packs with current vintages.
Refer to
Notices,
pack vintages. For information about usable vintages of non-U.S. circuit packs, refer to the ITAC Tech Alert from your regional distributor.
Technical Quarterly, Reference Guide for Circuit Pack Vintages, Change
and to the
Software Release Letter
Software Release Letter
. Do not continue with the upgrade
for information about usable circuit
that
in
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
Upgrading G3rV2, V3, V4 to R8r and Adding Memory
1
555-233-115

Software Upgrade

R ele ase 8 so ftwa r e and translat ions ar e save d to removable media. Although the translations automatically update to Release 8, several features require special attention because of screen changes or potential naming conflicts in the process.
Between customer confirmation and the actual update or upgrade, check the screens to ensure the translations meet the customer’s needs. After rebooting the
system, enter the translations either locally or remotely. If done remotely, Contact Field Support Administration Center (FSAC) for the remote entry. For information to make the required changes, refer to:
DEFINITY Enterprise Communications Server Release 8 Administrator’s Guide

Required Hardware

The equipment in Table 1-1 must be o n site be fore the up grade begin s. To pla ce a claim for missing equipment, as part of the Streamlined Implementation process, call 1-800-772-5409 or the number provided by your Lucent Technologies representative.
Issue 1
April 2000
1-3Read This First
Table 1-1. Required Hardware
Quantity
Equipment Description Standard High/Critical
106495120 TN1650B Memory circuit pack 1 105533780 V4 or later TN1657 Disk Drive circuit
1
2 2
pack (if needed)
108566381 UN332C MSSNET circuit pack
12
107849754 TN2211 optical drive 1 2 106590953 Z100A1 Apparatus Blank Faceplate 1 2 J58890TO-1 L1 Formatted removable media
1
2
4
w/Release 8 software
848445086 848445094
1. For a maintenance update, acquired from the Technical Service Center. For an upgrade, shipped from the factory.
Carrier A strip label Carrier B strip label
1 NA
NA 1
DEFINITY Enterprise Communications Server Release 8.2 Upgrades and Additions for R8r
Upgrading G3rV2, V3, V4 to R8r and Adding Memory
1
555-233-115

Task Ta b les

Table 1-2 lists the high-level tasks to perform the upgrades. Refer to the
appropriate page for instructions for each step. The upgrade procedure is similar for both the standard and high or critical
reliability system with a few exceptions. These exceptions are noted as you go through the steps.
Table 1-2. Tasks to upgrade the software and hardware
Task Description Page
Issue 1
April 2000
1-4Task Tables
Check SPE
1-6 Save Translations 1-6 Save Announcements (if necessary) 1-6 Back Up Disk 1-6 Disable Scheduled Maintenance and Alarm Origination to INADS 1-7 Reconfigure the Tape (G3rV2, V3 R31.0 and Earlier) 1-6 Check Link Status 1-8 Disable TTI 1-8 Check Disk Drive 1-8 Install Disk Drive (if not TN1657 V4 or earlier) 1-9 Restore Disk 1-9 Check TTI Status 1-10 Busyout MMI Circuit Packs (H/C only) 1-10 Lock the active SPE (H/C only) 1-10 Check the active tone-clock (H/C only) 1-11 Power Down the Processor Carrier 1-11 Remove the Circuit Packs 1-11 Install the Circuit Packs 1-12 Power Up the Processor Carrier 1-14 Unlock the Active SPE (H/C only) 1-14
Continued on next page
Loading...
+ 472 hidden pages
