Single Channel Portable Dimmer
Operator Manual
LSC Lighting Systems (Aust) Pty Ltd. 18/01/02
monoPAK Single channel portable dimme
r
r
r
r
monoPAK Single channel portable dimmer
monoPAK Single channel portable dimmermonoPAK Single channel portable dimme
Introduction
Introduction
IntroductionIntroduction
The monoPAK has been designed incorporating many of the high quality components used
on LSC’s 12 channel dimmer family such as high rise time toroidal inductors; 40 Amp Triacs;
60mm-travel low profile fader with integral dust cover; safety HRC fuse holder and 10Amp
ceramic fuse; all enclosed in a solid 1.6mm folded metal housing.
The monoPAK comes complete with a 1.6 metre power input cable and a 0.3m long output
cable with socket. For overseas users, the plugs can be cut-off and fitted with the required
plug and socket combination.
Power input cable
1600mm long
Input supply fuse
10A HRC M205
type
Load output cable
300mm long
Keyhole
mounting slot
Power on
indicator
60mm Fader with
dust cover
Keyhole
mounting slot
MonoPAK Dimme
MonoPAK Dimmer
MonoPAK DimmerMonoPAK Dimme
