Louroe Electronics VERIFACT B Specsheet

®

<Convenience Stores
<Fast Food Restaurants
<Booking Rooms
<Interrogation Rooms
<Day Care Centers

<Sleep Disorder Centers
<Therapy Labs
<Cashier Booths
<Gas Stations
<Any where CCTV

Cameras Are Installed

VERIFACT A/B

6955 VALJEAN AVE, VAN NUYS, CA 91406

PH: [phone] / FAX: [phone]

DESCRIPTION

The Verifact Model A is an omni-directional, low impedance,
electret condenser microphone with built-in preamp for
producing line level audio. It is housed in a high impact anti­static ABS dome designed for ceiling or wall mounting. Normal
pick-up pattern is approximately 15' from the microphone
location, all directions, or within 30' diameter circle.

The Verifact Model B Microphone is identical to the Model A,
except that it has an extension cable for positioning the
microphone from 3’ to 10’ from it's dome housing. It is used
with high ceiling installations.

Models A and B are compatible with all Louroe Base Stations.

®

®

APPLICATION

When part of a Louroe Audio System, the Model A
and Model B Microphones can be used in situations
such as:

/ [e-mail]

®

MICROPHONES

TECHNICAL DATA SHEET

MODEL A MICROPHONE

WIRING REQUIREMENTS

2 Conductor shielded cable, 22
gauge with a 24 gauge drain
wire.

NOTE: Unshielded cable is not

satisfactory for audio
systems.

IMPORTANT NOTICE

When this equipment is used as part of an
audio monitoring system, the law requires
that the public be given notice of AUDIO
MONITORING ON THE PREMISES. A
deca l noti ce is included with each
microphone shipped.

Federal Law References:
Federal Regulations, US Code, Title 18.
Crime and Criminal Procedure, Sec 2510.

AUDIO

MONITORING

On

These Premises

®

MODEL B MICROPHONE

FEATURES

<Sturdy ABS housing
<Microphone can pickup normal sounds 15 ft away
<Easily mounted to wall or ceiling surface
<May be located up to 1000 ft from the Louroe Base

Station

<Powered by the Louroe Base Station
<Two position preamp gain setting: Normal and Low

SPECIFICATIONS

Sensitivity

Frequency response
Output
Current drain

R

U

T

E

D

C

A

I

F

U

N

A

M

N

T

H

E

Supply voltage 12 Vdc
Microphone housing High impact anti-static ABS
Dimensions

Weight
Shipping Weight

-45 dBV/Pa
1 Pa = 94 dB SPL

50 Hz to 15 kHz
Line Level (0 dBV, 600W @1kHz)
10 mA

4” " dia x 1 ½ H

Model A 3.5 oz; Model B 4 oz
1 Lb

A-MIC/B-MIC 11/14
