Lorus V142 User Manual

NREV142

INSTRUCTION MANUAL

CAL. V142 (RUN SERIES)

■ CHARACTERISTICS

1. Powered by light energy: The solar
cell installed converts light energy into
electrical energy, and stores it in the
rechargeable battery.

2. No need for battery replacement:

The watch is provided with a rechargeable
solar cell instead of the conventional
silver oxide battery.

3. Large volume rechargeable battery:

When the watch is fully charged, it will
keep operating for approximately 180
days.

4. Energy depletion forewarning function:

When the energy stored in the rechargeable
battery is reduced to an extremely small
amount, the second hand starts moving
at 2-second intervals.

5. Quick-start function: Even when
the watch completely stops operating,
it will start operating immediately once
exposed to light.

■ DISPLAY AND CROWN OPERATION

Hour hand

24

13

23

22

21

Second

hand

20

17

19

18

Crown :

● Setting the date at the first click.

● Setting the time at the second click.

■ HOW TO CHARGE AND START

THE WATCH

Before using the watch, be sure to charge
the rechargeable battery sufficiently by exposing
the watch to light.

24

13

23

22

21

20

19

18

Minute hand

Date

14

Crown

15

8

16

Normal position

14

15

8

16

17

Second
click

First click

04-97

second intervals, the energy stored in
the rechargeable battery is not sufficient.
If the watch is turned away from the
light, the watch will stop operating.

2. Keep the watch exposed to the light
until the second hand moves at 1-second
intervals.

3. Charge the rechargeable battery sufficiently,
and then set the time and put on the
watch.

* See “■ GUIDELINE OF CHARGING TIME”

below.

Caution:

While charging the watch, make sure that the
watch temperature does not exceed 50° C.

• When the watch is fully charged, it

will keep operating for approximately
180 days.

• We recommend that the watch be recharged

daily for about 3 hours.

■ HOW TO SET THE DATE AND TIME

24

13

23

22

21

20

19

14

Crown

15

8

16

17

18

Second
click

First click

1. Pull out the crown to the first click and
turn it to set the previous day’s date.

2. Pull out the crown to the second click
when the second hand is at the 12 o’clock
position. The second hand will stop on
the spot.

3. Turn the crown until the desired date
appears.

4. Turn the crown to set the hour and minute
hands to the desired time.

* When setting the minute hand, first advance

it 4 to 5 minutes ahead of the desired
time and then turn it back to the exact
minute.

5. Push the crown back in to the normal position
in accordance with a time signal.

■ GUIDELINE OF CHARGING TIME

The charging time required varies depending
on the intensity of light.

Illumina-

tion

Light source Environment

(lux)

60-watt incandes-

500

cent light

Fluorescent light

700 11 hours 175 hours

30-watt fluores-

1,000 6 hours

cent light

30-watt fluores-

3,000

cent light

30-watt fluores-

5,000

cent light

30-watt fluores-

10,000 30 minutes 10 hours 3 minutes

cent light

10,000 Sun 30 minutes 10 hours 3 minutes

100,000 Sun 8 minutes 3 hours 1 minute

A : for normal movement of second hand

B : for full charge
C : to maintain 1-day usage

Distance of
60 cm (2 ft.)

Office,
overhead

Distance of
70 cm (2 ft.
4 in.)

Distance of
20 cm (8 in.)

Distance of
12 cm (5 in.)

Distance of
3 cm (1 in.)

Cloudy
weather

Fair
weather

Time required (approx.)

B

A

15 hours 250 hours

2 hours

80 minutes 22 hours 6 minutes

C

60 minutes

50 minutes

120 hours

30 minutes

40 hours 10 minutes

1. Expose the watch to sunlight or strong
artificial light of more than 1,000 lux
(for example, two 15-watt fluorescent
lights with a distance of 70 cm between
the watch and the light source).
It will start operating immediately with
the second hand moving at 2-second intervals.

* While the second hand is moving at 2-

Notes:

1. The above table provides only a general
guideline and the actual charging time
required may differ depending on the model.

2. We recommend that you charge the watch
daily to some degree to make up for any
energy loss, rather than after the watch
is completely stopped.

3. When charging the watch, do not place it
too close to a photoflash light, spotlight,
incadescent light or other light sources
as the watch temperature will become
extremely high, causing damage to the
watch mechanism. (Fluorescent lights
are the proper artificial light source for
charging the watch)

■ ENERGY DEPLETION

FOREWARNING FUNCTION

When the energy stored in the rechargeable
battery is reduced to an extremely small
amount, the second hand starts moving at
2-second intervals instead of the normal 1­second intervals.

• To prevent the energy depletion:

■■ Wear the watch in such a manner that it

is not covered by the cuff of the clothes.

■■ When the watch is not in use, leave it in

a bright place as long as possible.

■■ Before leaving the watch in a dark place

at night, charge it sufficiently.

• When the second hand starts moving

at 2-second intervals:

■■ Recharge the watch as soon as possible

by exposing it to light. (See “■ HOW
TO CHARGE AND START THE WATCH”)

* If the energy depletion forewarning

function is activated, the watch will
stop operating in about 3 days.

■ RECHARGEABLE BATTERY

• Titanium-lithium ion secondary battery

Note:

Unlike conventional quartz watches, the
watch does not use a silver oxide battery,
thus eliminating the need for battery
replacement.

■ LUMIBRITE WATCH (dial, hands, buttons, case, bezel, strap, etc.)

■ CARE OF YOUR LORUS WATCH

• WATER RESISTANT

Condition

Accidental

of use

contact with

No

water, such
as splashes
and rain

*

)

Indica­tion on
the dial/
case back

indication

WATER

RESISTANT

WATER

RESISTANT

(50 M/5 BAR)*

WATER

RESISTANT

100 M/

10 BAR or

(

above

* If your watch is 200 M/20 BAR, 100 M/10

BAR or 50 M/5 BAR water resistant, it is so
indicated on the dial/case back.

• Do not turn the crown when the watch is
wet.

• If the watch is exposed to salt water, rinse
it in fresh water and then wipe it thoroughly
dry.

Swimm-

Skin

diving

Scuba
diving

ing and
taking a
shower

NO NO NO NO

YES NO NO NO

YES YES NO NO

YES YES YES NO

Caution:

Leather straps are not water resistant except
so indicated, even if the watch head is water
resistant.

• ALLERGIC REACTION

Because the case and band touch the skin
directly, it is important to clean them
regularly. If not, shirt sleeves may be
stained and those with delicate skin may
develop a rash. Please wear the watch
with some play to avoid any possible allergic
reaction. If you develop a rash on your
wrist, stop wearing and consult a physician.

• MAGNETISM

Your watch will not be affected by mag­netism generated by household electric
appliances.

• SHOCKS AND VIBRATIONS

Your watch may be worn for normal sports
activities, but be careful not to drop it or
hit it on hard surfaces.

• TEMPERATURE

Your watch is preadjusted so that constant
accuracy may be insured at normal tem­perature.

■ SERVICE

When your LORUS watch requires repair or
servicing, please see the enclosed WARRANTY/
GUARANTEE.

✩ If your watch is a LORUS LUMIBRITE watch,

it has following features.

LORUS LUMIBRITE watches absorb and store
light energy from natural and artificial light
sources and emit light in the dark. They are
made of environmentally friendly material,
and therefore, are harmless to human beings
and the environment.

• With a full charge, LORUS LUMIBRITE
watches glow in the dark hours longer than
conventional luminous watches of this type.
If exposed to a light of more than 500 lux
(i.e., the brightness of a typical office) for
approximately 10 minutes, or direct sunlight
for 2 minutes, they will glow for hours.

• Since LORUS LUMIBRITE watches emit
the light they store, the brightness will
decrease gradually over time. The length
of time they will glow may also differ slightly
depending on such factors as the brightness
of and distance from the light source used
to charge the watch.
