Page 1
tm
Constitution
Clean Face Gas Fireplace
Page 2
tm
Constitution
Clean Face Gas Fireplace
The Constitution Clean Face gas fireplace by Lopi is exceptional
in design and in performance. With advantages not found
anywhere else, it's as close to a traditional masonry style fireplace
as you can get, but has the latest in modern fire technology.
With low Btu's, the Constitution is a perfect choice for those
who enjoy the aesthetics and comfort provided by a large fire
without the excess heat. Others clean face fireplace are merely
decorative with almost all the heat escaping up the chimney.
The Constitution is “Heater Rated” delivering a heating capacity
of up to 1,000 sq. ft.
Advanced Performance
There's nothing traditional about the Constitution's performance.
You have the ultimate in variety and control with variable flame
regulation and heat output. A large, detailed log set cast from
real wood logs and a gorgeous flame simulate a traditional wood
fire. The built-in flame control center is completely hidden so your
only focus is on the fire.
Your Build-Green Fireplace
The Constitution features an Electronic IPI (Intermittent Pilot Ignition)
Gas Valve that allows you to run your fireplace in either “Electronic
Ignition” or “Standing Pilot” modes. The Constitution fireplace
makes the ideal choice for those looking for a Green Alternative
to over other heat and Clean Face fireplaces that dump a majority
of their heat straight up the flue into the environment.
Convenient, Easy Operation
Our Home Comfort™ Control System gives you thermostatic control at your fingertips from anywhere in the room. The hand-held
remote and wireless modulating wall control programs all functions including on/off, room temperature and
flame height adjustment. Both the remote and wall mounted controls come standard with the fireplace.
Wireless
Modulating
Wall Mounted
Control
Controls ON/OFF and
High/Low Settings
Thermostatic
Modulating
Remote
Control
Controls ON/OFF,
High/Low Settings
and Room
Temperature.
Page 3
The Look of a real Fireplace
The Constitution combines a classic fireplace look with no grills or louvers, and the slim outside trim allows a huge view of the
fire (1080 sq. in. ). The Constitution comes with standard black trim that gives your fireplace a finished look and high temperature
tempted glass with a mesh safety screen in front of the glass. This safety screen helps prevent children from trying to touch the
glass. The screen is removable if desired. The Constitution also allows you the ability to personalize the look of you fireplace
with beautiful decorative options.
Standard Black Interior
Weathered Straight Brick
Herringbone Brick
Fireplace Interior Options
Your Constitution CF fireplace comes standard with a black firebox interior. While not required, the Constitution CF allows you
the ability to make your fireplace look like a real masonry fireplace with the reversible fireback brick liner
option. You have the choice of Weathered Brick on one side or Herringbone Brick on the other.
Andirons
Enhance the look of your Constitution CF fireplace even further
with a choice of three optional cast andirons. Andirons feature
finely cast detail and attach to the existing grate. These beautiful
cast iron andirons in a selection of Early American motifs, we give
your fireplace that finely detailed finish look that will set your
fireplace apart from all others.
Extra Room Power Heat Duct Kit
Add heat to an additional room in your home with the optional
Extra Room Power Heat Duct Kit. This venting option uses a
remote fan to pull heat off the fireplace and deliver it to an
Colonial
Andiron
Arabesque
Andiron
Wrought Iron
Andiron
adjoining room. You can direct this heat upstairs, downstairs
or anywhere in your home within 20 feet of the fireplace.
Accent Light
Add a warm glow to your fireplace even when it’s turned off!
The accent light adds a glowing
backlight behind the flames
when the fire is on, and
enhances the pattern of the
fireback when it’s off.
Firescreen
Finish your fireplace with a
decorative firescreen. The
firescreen features detailed
legs and handle for a
traditional fireplace look.
Ideal protection from the
fireplace if you have small
children in your home.
Page 4
Features:
tm
Constitution
Clean Face Gas Fireplace
• No grills for a traditional masonry fireplace look.
• Durable, tempered glass with safety screen.
• Screen is removable.
• Fire viewing area 1080 sq. in.
• Realistic, four-piece detailed log set with embers and twigs.
• Digital Home Comfort Control System can be operated by
• the hand-held remote control and the wireless wall control.
• Operate Y
• be run for greater efficiency in the “Intermittent Pilot Mode”
• with the gas pilot turned off until you need it or “St
• Pilot Mode”,with the gas pilot always on, for reliable cold
• weather operation.
• Natural (NG) or Propane (LP) operation.
• Uses Simpson Duravent 8 5/8” x 6” chimney
• Seven Year “Real World” Warranty.
our Fireplace Green - The Electronic Gas Valve can
anding
.
Framing Dimensions:
See Installation Manual or visit www.lopistoves.com under Constitution
1. Hearth Requirements: Extends 10” from face and 4
2. wide when installed flush. Not required when raised 6”
(See Installation Manual or www.lopistoves.com for details)
2.
2. Non-combustible facing - Two side and two top pieces provided
4. with fireplace.
3. Side Wall Clearance: 11”
9 1/2”
7
Gas Input & Performance:
• Adjustable High Heat System:
• 20,800 – 38,000 Btu's (NG)
• 23,500 – 38,000 Btu's (LP)
• Heater Rated Fireplace: Heats up to 1,000 sq. ft.*
*Heating capacity will vary depending on the temperature zone
you live in.
Maintain
a 14” min. width
between studs
and max. 3 1/2”
depth of studs
for chimney
clearance.
5
4
6
4. Mantle Clearances: 50” from base of fireplace.
4. Maximum allowed mantle depth: 12”
5. Minimum fireplace enclosure height 60”.
6. Measured from base of fireplace.
6. Minimum framing:
6. 50” wide x 56 3/4” tall x 25” deep.
7. Facing Requirements:
6. Provided fiber board or other non-combustible
6. material must extend from the base of the fireplace to
6 .the header and to the framing members on both sides
3
4
1
2
1” to 1-1/2” Thick Cement Board
41 1/ 2 ”
1
Tested and Certified by OMNI-Test Laboratories Inc. to ANSI Z21.88b
“Vented Gas-Fired Direct Fireplace Heater”.
Must be installed in accordance with all local codes, if any:if not, follow ANSI Z223.1
and the requirements listed in the Owner’s Manual.
Note: Improper installation of your gas appliance or failure to operate it in accordance to the guidelines detailed in the Owner’s Manual may
negate your warranty. We recommend all Lopi appliances be installed and maintained on an annual basis by your specialty hearth retailer.
Your Lopi Authorized Dealer is Located At:
10” Min.
25” Min.
Visit us online at: www.lopifire.com
© Copyright T. I. 10/2007 Printed in U.S.A.
We reserve the right to improve or change our products without prior notification. Consult the Owner’s Manual for complete installation requirements. Photos and illustrations are for descriptive purposes only.
#98800000
