Label Description QTY
A Front Panel 1
Assembly Instructions
Caution : You must read this before you proceed
Part List
Page 1 OF 9
TANK HOLDER
Shall be used this TANK HOLDER Instruction with the
Fire Table Instruction
B Back Panel 1
C Side Panel 2
D Top Panel 1
E
Stand (pre-assembled wing
screw)
1
Label Description QTY
①
Screw (M5 *10MM) 17
②
Screw (M6 *30MM) 3
③
Leveller 4
④
Screwdriver 1
Hardware
Page 2 OF 9
OVERVIEW
This Tank Holder has multiple parts and may require up to 30 minutes to assemble.
To give you an overview of the Tank Holder parts, the above picture is to help you put
the various Tank Holder parts into perspective.
Please read through the instructions below to familiarise yourself with the parts and
steps before assembly.
Assembly Preparation
*Before beginning assembly of product, make sure all parts are present.
Compare parts withpackage contents list. If any parts is missing or
damaged,do not attempt to assemble the product.
Assembly Steps
Before
Beginning
Assembly:
Front Panel (A)
Top Panel (D)
Side Panel (C)
Feet (③)
Page 3 OF 9
Step 1
Step 2
Attach the Front Panel (A) and the Back Panel(B) to the Stand (E) using M5 Screw
(①), with Screwdriver(④).
Do not over tighten Screw(①) while assembling the panels in order to adjust the panels
as needed while assembling and make sure you follow the steps fully.
Assemble the 4 Leveller (③) to the bottom of the Front Panel (A) and Back Panel (B).
③
③
①
E
Page 4 OF 9
Step 3
Step 4
Attach the Side Panel (C) to the Front Panel (A) and Back Panel (B) using Screw(①),
with Screwdriver(④).
Repeat the same process to install the other Side Panel.
Attach the Top Panel (D) to the Back Panel (B) using M6 Screws (②) with
Screwdriver(④).
①
②
D
Page 5 OF 9
Step 5
Step 1
Instructions for use
If the Tank Holder wobbles, adjust the Pre-installed Levellers at the bottom of the Panel
(A) & Panel(B) until the Tank Holder is level.
This Tank Holder can only be used on a flat, level surface.
Make sure all parts are connected and securely locked into position.
Your Tank Holder is ready for use.
Place a 20 lb. Propane Gas Tank (not included) on top of Stand (E). Turn the
Preassembled Wing Screw on the Stand (E) clockwise to secure the Gas Propane
Tank.
E
Page 6 OF 9
Step 2
Step 3
Feed the Regulator Hose (from your Gas Appliance) through the bottom of the item.
Step 3.1
Step 3.2
Page 7 OF 9
MAINTENANCE
• Store the item in a cool dry place away from direct sunlight.
• The propane gas tank must be disconnected and removed from the item before this
item may be stored indoors.
• Use manufacturer approved or supplied replacement parts and accessories only.
Otherwise may void the warranty of this product and result in a hazardous condition.
• Keep the item free and clear from combustible materials.
MAXIMUM WEIGHT CAPACITY: This item can withstand an additional weight of 30
lbs.
• This item is intended for outdoor use only.
• Do not use near flammable or combustible objects.
• Storage of this item indoors is permissible only if the tank is disonnected and properly
stored
outdoors.
• Young children should be carefully supervised when in the vicinity of this item.
• Do not sit on this item.
• Always place this item on a hard, level non-combustable surface such as concrete,
rock or stone.
• This item must be used ONLY outdoors in a well ventilated space and shall not be
used
inside a building, garage or any enclosed area.
• This item is designed for use with a 20 lb. liquid propane gas (LP) tank (not included).
• This item is not to be installed or used in or on any recreational vehicle or boat.
• Do not attempt to transport this item with a gas tank installed.
Step 3.1 Connect the Regulator (from your Gas Appliance) to the Gas Propane Tank.
Step 3.2 Then close the Top Panel (D).
CAUTION! Open the cover to connect or disconnect your Regulator and to open or
close the Gas Propane Tank Valve. Make sure that the Hose is not pressed
underneath the item.
Page 8 OF 9
• What does a warning mean?
If a warning is placed on a product label or posted or distributed at a workplace, a business, or in
rental housing, the business issuing the warning is aware or believes that it is exposing individuals to
one or more listed chemicals.
By law, a warning must be given for listed chemicals unless the exposure is low enough to pose no
significant risk of cancer or is significantly below levels observed to cause birth defects or other
reproductive harm.
• Where can I get more information on Proposition 65?
If you have specific questions on the administration or implementation of Proposition 65, you can
contact OEHHA's Proposition 65 program at P65.Questions@oehha.ca.gov, or by phone at (916)
445-6900.
Questions & Answers about Proposition 65
• What is Proposition 65?
Proposition 65 requires businesses to provide warnings to Californians about significant exposures to
chemicals that cause cancer, birth defects or other reproductive harm. These chemicals can be in
the products that Californians purchase, in their homes or workplaces, or that are released into the
environment. By requiring that this information be provided, Proposition 65 enables Californians to
make informed decisions about their exposures to these chemicals.
Proposition 65 also prohibits California businesses from knowingly discharging significant amounts of
listed chemicals into sources of drinking water.
Proposition 65 requires California to publish a list of chemicals known to cause cancer, birth defects
or other reproductive harm. This list, which must be updated at least once a year, has grown to
include approximately 900 chemicals since it was first published in 1987.
• What types of chemicals are on the Proposition 65 list?
The list contains a wide range of naturally occurring and synthetic chemicals that include additives or
ingredients in pesticides, common household products, food, drugs, dyes, or solvents. Listed
chemicals may also be used in manufacturing and construction, or they may be byproducts of
chemical processes, such as motor vehicle exhaust.
Page 9 OF 9
