Longshine LCS-K602-A User Manual
2-port USB Cable KVM
Switch with Audio
User’s Manual
Version 2. 02 2008/12/22
Index
1. INTRODUCTION……………………………………………………………………………………………2
1.1
FEATURES …………………….…..………………………………….………………………… ………2
1.2
PHYSICAL DIAGRAM…….…………………………………...…..………………………………………3
1.3 PACKAGE CONTENTS…………………………………...……………..………………………………...3
2. SPECIFICA TIONS………………………………………………………………………………………….4
2.1
GENERAL……………………………………………………………...…………………………………4
3. INSTALLING THE CABLE KVM SWITCH………………………………………………………………5
3.1
SYSTEM REQUIREMENTS………………………………………….…………………………………….5
3.2
HARDWARE INSTALLATION………...………………………...……………..……………………………5
3.3
NOTICE FOR SUN MICRO SYSTEM USER……………………………………………………….……….6
3.4
HOT SWAPPABLE……………………….……………...……………………..………………………….6
3.5
DRIVER INSTALLATION(WINDOWS 98/SE ONLY)..………………………………………………………6
4. OPERATION……………………………………………………………………….…….………………….9
4.0
PUSH BUTTON……..……………………………………………………………………………………..9
4.1
HOT-KEY OPERATION…………………………………………………………………………………….9
4.2
PC SELECTION………………….…..……………………………………………………………………9
4.3
AUTO-SCAN FUNCTION……….……….………………………………………………………………..10
1
1. Introduction
Thank you for your purchase of the 2-port USB Cable KVM Switch with Audio!
You now have a high quality, durable system that enables you to control two
computers and/or servers from one console (USB Mouse, Keyboard, and
Monitor). In addition, proprietary new technology allows you to independently
control and switch audio between two computers.
1.1 Features
1. Controls 2 computers from a single console (Keyboard/Mouse) over USB
connection.
2. Support Window 98SE/ME/2000/XP/Vista/2003 server, Sun Micro , Mac , Linux
3. Allows sharing of audio devices.
4. Emulates a keyboard on each PC to allow your computers to boot normally
without a keyboard error.
5. Supports hot-swap. All devices connected to the KVM can be added or
removed at any time, without shutting the unit down.
6. Supports USB keyboard Hot-Key Switch and push buttons for easy operation.
7. Supports Auto-Scan function to alternate video between both computers in
preset intervals.
8. Supports LED display for PC and audio status monitoring.
9. Supports VGA resolutions up to 2048x1536 @ 85HZ.
10. Supports Plug and Play.
11. Self powered through USB connection.
12. Provides innovative cable management system to prevent tangles.
2
1.2 Physical Diagram
PC connection 2 LED Indicators (Green)
PC connection 1 LED Indicators (Green)
PC 1 LED Indicators (Red)
PC 2 LED Indicators (Red)
USB Keyboard
VGA Output
USB Mouse
PC Selection Push Button
MIC Jack
z PC LED Indicators:
RED LED indicates that the 2-port USB Cable KVM Switch is switched to the
corresponding PC.
z PC connection LED Indicators:
GREEN LED indicates the status of PC connection.
PC Selection Push Button
Speaker Jack
1.3 Package Contents
The product you purchased should contain the following equipment and
accessories:
1. One 2-port USB Cable KVM Switch with Audio.
2. User Manual.
3
