Logicom Le Starter L Quick Start Guide

QUICK START GUIDE

Logicom Le Starter L Smartphone 4G-LTE/GPS/WIFI/BT

Photo representative only

2

Trademarks

Android, Google, Google Play and other marks are trademarks of Google Inc.
Adobe Flash Player Copyright(C) 1996-2011 Adobe Systems Incorporated. All rights reserved. Adobe and Flash are
either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other
countries.
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON­COMMERCIAL USE OF A CONSUMER TO
(i) ENCODE VIDEO IN COMPLIANCE WITH THE AVC STANDARD (“AVC VIDEO”) AND/OR
(ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL
ACTIVITY AND/OR WAS OBTAINED FROM A
VIDEO PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY
OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE HTTP://MPEGLA.COM
Facebook, the Facebook logo, and the F logo are trademarks or registered trademarks of Facebook, Inc.
Foursquare is the registered trademark of Foursquare Labs, Inc.
This software is partially based on the work of the Independent JPEG Group.
The MPEG Layer-3 audio encoding technology and patents are licensed by Fraunhofer IIS and Thomson.
THIS PRODUCT IS LICENSED UNDER THE MPEG4 PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON­COMMERCIAL USE OF A CONSUMER TO
(i) ENCODE VIDEO IN COMPLIANCE WITH THE MPEG4 STANDARD (“MPEG4 VIDEO”) AND/OR
(ii) DECODE MPEG4 VIDEOS THAT WAS ENCODED BY A CONSUMER ENGAGED
IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED
TO PROVIDE MPEG4 VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE HTTP://MPEGLA.COM
SD, SDHC, microSD and the microSDHC logos are trademarks of SD-3C, LLC.
The Twitter name, logo, Twitter T, Tweet, and Twitter bird are trademarks of Twitter, Inc. in the United States and
other countries.
THIS PRODUCT IS LICENSED UNDER THE VC-1 PATENT PORTFOLIO LICENSE FOR THE
PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER TO
(i) ENCODE VIDEO IN COMPLIANCE WITH THE VC-1 STANDARD (“VC-1 VIDEO”) AND/OR
(ii) DECODE VC-1 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL
ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE VC-1 VIDEO.
NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION MAY BE
OBTAINED FROM MPEG LA, L.L.C.
SEE HTTP://WWW.MPEGLA.COM
Wi-Fi, the Wi-Fi CERTIFIED logo, WPA, WPA2 and Wi-Fi Protected Setup are trademarks or registered trademarks of
Wi-Fi Alliance.
Windows Media is either a registered trademark or trademark of Microsoft Corporation in the United States
and/or other countries.
All other names of systems, products and services are trademarks or registered trademarks of their respective
owners. The symbols ((TM)) or (R) are not used in this guide.

3

Got everything?

 1 x Smartphone
 1 x Charger adaptation sector – USB universal – (Model: YZD-188; 5V 1A) (Shenzhen YiZhongDa Electronic

Technology Co., Ltd.; 6 floor Building A B District, Xixiang Gushu Xiaweiyuan Chaxi Industrial Area Fuyong
Sub-district, Baoan District, Shenzhen City, Guangdong Province, P.R.China.)

 1 x USB cable
 1 x Quick start guide
 1 x Pedestrian kit

NOTE: The packaging materials, such as the adhesive tape, plastic film, string and labels, are not part of this
product.

WARNING: For your safety, please do not remove the screen's protective film, located under the

antistatic film (with tab). It protects your screen against slight scratches and provides optimum
protection if the phone is dropped.

Logicom accepts no responsibility for personal injury sustained following removal of the protective film by the
consumer. Note that this protective film does not increase the robustness of the product. For replacement of
the protective film, please consult a specialist Smartphone dealer.

Installation guide

1. Description of the Smartphone.

1 – Front camera
2 – Rear dual camera & flash
3 – Volume
4 – ON/OFF button
5 – Jack
6 – Micro USB port
7 – Speakers

2. Inserting a SIM card

Your Smartphone is a mobile phone with dual SIM card, which enables you to use two lines on the same Smartphone.
Your smartphone has two SIM slots (SIM 1 and SIM 2).

To insert the SIM card(s):

 Switch off the phone and remove the rear cover and battery.
 Insert the SIM card correctly into the relevant card slots (see

figure below).

CAUTION: The 3G/4G function can only be used on one SIM card.

 Then replace the SIM compartment in place.

4

3. Inserting a MicroSD

It is possible to increase the internal memory of the Smartphone device with a MicroSD card. (Maximum 64GB

MicroSD card).

 Switch off the phone and remove the rear cover and battery.
 Insert the memory card into the relevant slot.
 Then replace the battery and cover.

CAUTION: Inserting or removing a SIM card or a MicroSD card requires the Smartphone to be completely switched
off.

4. Charging the battery

Installing the battery:

 Remove the rear cover of your Smartphone.
 Insert the battery ensuring that the image shown here is facing you.
 Replace the rear cover of the Smartphone.

CAUTION: Risk of explosion if battery is replaced by an incorrect type.

Modèle: SLT396383AR (Li-ion – 3,8V – 2500mAh)
To replace the battery, please enquire with the after-sales service of your
dealer.
Dispose of used batteries according to the instructions.
To replace the battery, please enquire with the after-sales service of your
dealer.
Dispose of used batteries according to the instructions.

Charging the battery:

 To charge the battery, connect the USB cable (supplied) to the USB port of your Smartphone and the

other end to the mains adaptor (supplied). Then connect the mains adaptor to a power outlet.

 The battery charge icon illuminates during charging and indicates the charge status.
 When the battery is fully charged, you can disconnect the USB cable from the device then from the

power outlet.

IMPORTANT:

 The Smartphone is only recharged via its USB port.
 Ensure your Smartphone is fully discharged before charging it for the first time.
 The battery must be charged for at least 5 to 8 hours when first charged.
 After a long period without use, It should be necessary to do many cycles of charging / discharging to

obtain maximum power capacity

Note: You can use the device when it is being charged. In this case, the battery may take longer to charge fully.

Safety information for charging the battery:

 To recharge the battery, only use the mains adaptor supplied with your device. Do not use any other

power supply or electrical device.

 The power outlet to which the device is connected must be near the equipment and must always be

easily accessible.

 Always wait at least 5 seconds after switching off the device before restarting it. Switching the device

off and then back on again immediately may damage the electrical circuits.

 Do not disassemble, open or shred the battery contents. Do not dispose of batteries in fire or water.

Do not charge the battery if the room temperature exceeds 45° C. Keep the battery in a clean and dry
place. Avoid leaving the battery under sunlight.
