Logicom Le Posh 170 User Manual
User Guide
Logicom mobile phone Le Posh 170
representative only
2
Introduction
Thank you for choosing this digital mobile phone with color screen. Read this
manual in order to fully understand and use your GSM mobile phone. You will
appreciate its features and just how easy it is to use.
The mobile phone with color screen is designed for a GSM network environment.
This is a dual-Sim Stand-by phone, but it is impossible to use the second SIM card
when a call is in progress with the first SIM card. In addition to the traditional call
functions, the phone also offers many functions, each as practical as the others:
contacts, messages, audio and video player, camera and camcorder, games,
Bluetooth, an alarm, a calculator, the date and time, etc. This phone is the ideal
accessory for your professional as well as leisure activities. As such, all of its
functions meet your needs.
The color screen phone complies with the mobile telephone requirements and is
certified by the competent authorities.
The company reserves the right to modify the content of this manual without
notice.
3
Please read before using
Safety and care informati on
• Read these instructions carefully.
• Keep these instructions.
• Follow all these instructions.
• Heed the warnings.
• Clean only with a soft cloth (dry or slightly damp).
• Do not attempt to disassemble the device; it would no longer be covered by the warranty.
• Do not bring sharp objects directly into contact with the surface and do not spray any
cleaning product directly onto the screen.
• Do not exert excessive pressure on the screen and do not put objects on it. This could
damage the screen.
• Use the spare parts specified by the manufacturer.
• After any serv ice or re pair carr ied out o n this p roduct, ask the tec hnician to perfor m a safety
check.
• Use only the spare parts/accessories specified by the manufacturer.
• Refer to a qualified person for any repairs. Repair is required if the device is damaged in
some manner or other, if the power cord or plug is damaged, if liquid has been spilled or
objects have fallen on the device, or if the device has been exposed to rain or moisture, or
has been dropped.
• Do not expose the device to direct sunlight or other source of extreme heat or cold.
• Respect the privacy of others when using your Smartphone.
• Keep the device away from all metal objects (coins, keys, etc.).
• Do not leave near a m agnetic field as this c o ul d cause data to be lo st or c ould damage the
device.
• Do not drop the device.
• Do not expose the device to shocks, friction or impact.
• In order to prevent data loss, remember to make a (computer or paper) back-up of
information saved on the device.
• To prevent interference, do not use the device near other electronic devices, a pacemaker
or medical equipment.
• Operating temperature: 0-40°C.
4
NOTE: In order to reduce any risk of fire or electric shock:
• Do not expose this device to rain or moisture.
• Do not expose the product to water droplets or to splashes and do not place
any object filled with liquid, such as a vase, on the device.
• Do not use the product near flammable or explosive materials.
• The power plug is used to disconnect the device and must always be easily
accessible.
• In order to completely disconnect the device from the electricity supply, the
power plug must be disconnected from the power outlet.
• Do not attempt to override the safety features of the polarised plug or the earth
connection. A polarised plug has two pins, one of w hich is wider than the other .
A plug with an earth connection has two flat pins and a third round pin for the
earth connection. The widest pin and the third pin constitute the important
safety features designed to protect you. If you cannot manage to fully insert
the plug into the wall outlet, contact your electrician to replace the obsolete
wall socket.
• Disconnect this device during electrical storms or when not in use for an
extended period.
• Switch off the device in places presenting risk of explosion and when travelling
by plane.
• Do not touch the power cord with wet hands and do not pull on the charger to
disconnect it.
• The power cord must be placed so that it will not be stepped on or crushed
particularly at the outlet, where it is plugged in or where it is connected to the
device.
• Do not overload the power outlet. Use the power supply only as indicated.
• Do not install this device near heat sources such as electric hobs, cookers or
others (including amplifiers).
• Dispose of the battery properly.
5
Package contents
• 1 x Phone
• 1 x Charger with cable - Model: VK-001 / 5V / 0.45A -Produced by Shenzhen
Linksooner Technology Co.,Ltd (Building 1,SZCG Gongming Ind Prak,
Shutianpu Community,Guangming,Guangming New District,Shenzhen,China)
• 1 x Earphone
• 1 x User guide
NOTE: The packaging materials, such as the adhesive tape, plastic film, string
and labels, are not part of this product.
Installing SIM card and memory card
1. SIM card First, insert a valid SIM card into your phone bef ore using it. The SIM card is
supplied by the network operat or.
All of the information pertaining to the network connection is saved in the chip of
the SIM card, such as the contacts, phone numbers and SMS for contacts in the
directory. You can extract the SIM card from your phone and insert it into any other
mobile phone (new mobile phones automatically read SIM cards).
In order to prevent losing or damaging the information saved on the SIM card, do
not touch the metal contacts, and keep the card away from any source of electricity
or magnetic field. If the SIM card is damaged, you cannot use the telephone in a
normal manner.
Recommendation: Make s ure the telephone is turned off before removing the
SIM card from it. A SIM card cannot be inserted or removed w hen t he phone is
connected to an externa l power supply. There is a risk of damage to the SIM
card and the phone.
6
2. Inserting and removing the SIM card
The metal contact surface of the SIM card can be scratched easily. Remove the SIM
card from its support carefully before installing it.
• Turn off the phone; remove the back cover, battery or any other external power
supply.
• Insert the normal side (without angled edge) of the SIM card into the cavity
provided for this purpose, with the metal contacts facing downwards. Insert the
second SIM car in the same way.
• To remove the SIM card, pull it directly outwards and remove it completely.
Recommendation: This manua l does not provide any additional information on
inserting the second SIM card. Re fer to the general instruc tions for insert ing a
SIM card. If you insert only one SIM card, some of the options on the menu will
not be available.
3. Memory card
Insert the card into the memory card reader following the steps below
Remove the back cover from the phone, and then remove the battery.
Push the metal clip in the direction of the arrow shown in photo (1) t o raise it up
Insert the memory card into the slot provided, with the metal contacts facing
downwards, refer to photo (2)
Close the metal clip and drag it in the direction of the arrow shown in photo (3) to
lock the memory card
(1) (2) (3)
7
Tip: If the memory card does not work, check that it is inserted correctly and
also check the metal contact poi nt s. You c a n als o try to format the memory
card. You shouldn’t have t o clos e the me t al cli p w it h a lot of strength.
Installation and charge of battery
Installing the battery
• Remove the back cover from the phone.
• Place the end of the battery that has the metal contacts against the battery
connector.
• Gently push the battery down and press on the other end of it to snap it in.
CAUTION: Risk of explosion if battery is replaced by an incorrect type.
Model: BL-5C / Batterie rechargeable Li-ion (3.7V) / 600mAh
To replace the battery, please enquire with the after-sales service of your dealer.
Dispose of used batteries according to the instructions.
Charging the battery:
• To charge the battery, connect the USB cable (supplied) to the USB port of
your Feature phone and the other end to the mains adaptor (supplied). Then
connect the mains adaptor to a power outlet.
• The battery charge icon illuminates during charging and indicates the charge
status.
• When the battery is fully charged, you can disconnec t the USB cable from th e
device then from the power outlet.
IMPORTANT:
• The Feature phone is only recharged via its USB port.
• Ensure your Feature phone is fully discharged before charging it for the first
time.
• The battery must be charged for at least 5 to 8 hours when first charged.
