233–32478.021

Operating instructions

Spheros R 37

Spheros R 32

Spheros R 26

Contents

Remote control - TV functions 3

Control units Spheros R 26 and R 32 4

Control unit Spheros R 37 5

Connections to rear panel - Spheros R 26 6

Connections to rear panel - Spheros R 32 and R 37 7

Welcome 8

Integrated features 8 Scope of delivery 8 Transporting 8 Installation options 8 Note on the LCD screen 9 Cleaning 9 Disposal 9

For your safety 10

First installation 11

Remote control 11 Connection 11 Handling the fabric hose 12 Using the common interface module 12 Switching on 12 Automatic programming 13 Directing DVB-T antenna 14

Daily operation 14

Switching on/off 14 Changing stations 15 Basics about the menu operation 16 For the info system ... 17 For the index ... 18 Setting the sound 19 Picture settings 19 Direct control on TV set 19

Operating modes – TV 20

How the coloured keys work in TV mode 20 Show status display 20 Calling the index 20 Call additional functions 21 Call timer overview 21 Select picture format 21 Move picture up/down 21 TV menu 21 DVB subtitles 22 Removing the CI module 23 Inserting a new CI module 23 Installing new DVB software 23 Image+ menu 24 Image+ demo mode 24

Operating modes – PIP 25

PIP picture as freeze picture 25 Selecting the station of the PIP picture 25 Select the station of the TV picture (main picture) 25 PIP scan in the PIP picture 25 Interchanging PIP picture/TV picture 25 Functions in the PIP menu 26 Setting the PIP type 26 Position of the PIP picture 26

Operating modes – EPG 27

Using the EPG 27 EPG menu 28 Selecting providers and stations 28 Data capture 28

Operating modes – Teletext 29

Page selection with the coloured keys 29 Displaying teletext pages 29 Programme timer recordings 30 Teletext menu 30 Digital teletext operation (only for UK device version 27) 30

Operating modes – Radio 31

Radio menu 31 EPG - Programme guide 31

Operating additional equipment 32

Login and connect equipment 32 Video playback 33 Timer recording with video or DVD recorder 33 Assignment of digital audio inputs and outputs 34 Connecting Loewe DVD Preceiver Auro 2216 PS and Tremo loudspeaker system 35 Connecting other audio ampliﬁ ers or active speakers 36 HDMI (DVI) connection 37 VGA/XGA connection 37 Component video connection 38 Operating other Loewe devices with the RC3 remote control 39 Setting the remote control to operate devices from other manufacturers 39 Rotating the TV set for Spheros R 32/37 41

What to do, if ... 42

Technical data 44

General data 44 Electrical data 45

Accessories 46

Service Addresses 47

Codelist RC3 / Lista de códigos RC3 48

- 2

Remote control - TV functions

Control LED for programming

the remote LED

Change-over switch for operating of

TV, VCR, DVD recorder/player or Set Top Box

Sound off/on

Call timer list

Menu "Additional functions" on/off

Set picture format

Electronic Programme Guide

(EPG) on/off

Show/hide menu

Analogue Teletext on/off

V–/V+ Volume down/up

for PIP: Position of the PIP picture

/ in the menu: select/set

Red button:

freeze picture on/off

Green button:

Standard settings for picture/sound

Select station down

/ in the Wizard: back

Direct recording

Freeze picture on/off

when equipped with Digital Recorder +, these buttons have different functions, see operating instructions of the Digital Recorder

Radio only for DVB reception

if broadcast by the station

DVD STB

VCR

Switch on/off

- on standby

-Set

-List

Picture menu on/off

Sound menu on/off

REC-MENU

ghi jkl

RADIO

abc def

mno

Radio on/off

Select station directly /in the menu: enter numbers or letters

Call AV selection

pqrs

tuv

wxyz

DVD -AV

EPG

DISC-M

PIP

P+

PIP on/off (picture in picture) Status display on/off

/in the menu: hide menu Open index

/in the menu: info texts on/off

P+/P– Select station up/down

V– V+

Station list on /in the menu: confirm/call

C-SET

P–

Blue button: off/on

TITLE

CARD

Yellow button:

Select station up

Freeze picture off

Freeze picture on

programme info

previous station

with DVB-T stations in UK different function. The coloured keys do not work as described with DVB-T stations in UK, but they operate as described on page 30 (Digital Teletext).

3 -

Control units Spheros R 26 and R 32

SPHEROS

Display:

red = standby

green = operation

orange = operation without screen display

(radio mode, EPG data capture

or timer recording)

Station down,

in the menu: left 

Radio on/off

(back to TV mode),

switching on the radio

from standby,

in the menu: down 

Radio only for DVB reception, provided the station broadcasts this.

Otherwise, switch over to an audio input.

Only for sets with a Digital Recorder

- 4

Call the menu,

in the menu: up 

DR+

Switch TV set on/off to standby

Station up, in the menu: right 

Display DR+ :

white = Digital Recorder integrated, but not active (no recording, no play) green = Digital Recorder active (timeshift or archive playback) red = Digital Recorder active (archive recording)

Control unit Spheros R 37

SPHEROS

Display:

red: standby

green: operation

green and red:

timer recording,

EPG data capture

or radio mode

Common Interface

Headphones connection

S-VHS connection (AVS)

(i.e. for camcorders)

Video input (AVS)

Audio input right

Audio input left

Call the menu,

in the menu: up/down 

Station down,

in the menu: left 

Station up,

in the menu: right 

– +

5 -

Connections to rear panel - Spheros R 26

Common interface

Headphone connection

S-VHS connection (AVS)

(i.e. for camcorders)

Video input (AVS)

Audio input right

Audio input left

Mains switch

Euro-AV-

socket1

Digital satellite tuner can be retroﬁ tted (not in UK version).

- 6

Antenna/cable

analogue/digital

Euro-AV-

socket2

Center audio input (analogue)

Audio input left/right (analogue)

Component video inputs

(Cb/Pb–Cr/Pr–Y)

Audio output left/right (analogue)

Satellite connection socket

VGA/XGA input

HDMI (DVI) input

Digital audio output

Digital audio input

Socket for power cable

Service socket

Connections to rear panel - Spheros R 32 and R 37

Common Interface

Headphones connection

S-VHS connection (AVS)

(i.e. for camcorders)

Video input (AVS)

Audio input right

Audio input left

Call the menu,

in the menu:

up/down 

Station down,

in the menu: left 

Station up,

in the menu: right 

– +

Mains switch

Antenna/cable PIP tuner

or satellite antenna

(Sat tuner 1)

89374.003

5V /80mA

ANT-TV

ANT-SAT

13/18V /350mA

AUDIOOUT

AUDIOIN

SD/HD-COMPONENTIN

AV2

AV1

()

RGB/ YUV

AUDIODIGITAL

INLROUT

rr YC/Pbb

C/P

220-240V~ 50/60Hz

HDTV/PCIN

()

HDMIDVI

SERVICE

VGA/XGA

Center Audio input (analogue)

Satellite antenna

(Sat tuner 2)

Audio input left/right (analogue)

Audio output left/right (analogue)

Rotating stand control

Antenna/cable

analogue/digital

Euro-AV-

socket 1

(tuner 1)

Antenna output PIP tuner

connect to tuner 1

Can be retroﬁ tted. This is already integrated in sets with a digital recorder.

Digital satellite tuner can be retroﬁ tted (not in UK version).

Can be retroﬁ tted for sets with a digital recorder.

Only for Spheros R 37.

Euro-AVsocket 2

Component video inputs

(Cb/Pb–Cr/Pr–Y)

HDMI (DVI) input

Digital audio output

Digital audio input

Socket for

power cable

Service socket

VGA/XGA input

7 -

Welcome

Thank you!

At Loewe, we combine the highest standards of technology, design and user friendliness. This applies equally for TV, video and accessories. Your new TV set is ideally equipped for the TV standard of the future - "HDTV" (High Deﬁ nition Television). With its high-resolution screen and the future-proof digital interfaces HDMI, you have the option to view HD content with excellent picture quality. It therefore carries the European quality mark "HD ready". Digital TV is steadily spreading via terrestrial reception, in the cable network and via satellite. Loewe supplies sets equipped with DVB-T and DVB-C (DVB-C not for UK). A digital satellite tuner (DVB-S) can be retroﬁ tted. The DVB integrated within the TV set is operated via the TV set menus using the remote control. We have designed this TV set so that it is easy to operate by using menus. Information about settings in menus is shown automatically; this enables you to understand the context quickly. You will ﬁ nd the answers to many of your technical queries in the index of your TV. If you want to operate the TV, you can access functions directly from the index. This saves you from having to read through detailed operating instructions and is the reason why this operating manual only explains the most important operating steps.

Integrated features

The maximum equipment is described in these operating instructions (without optional retroﬁ t kits). Functions indicated by Menu contents may differ from the ones shown, depending on how your TV is equipped. You can display how your set is equipped in the "Integrated features" index (press the INFO button in the TV mode if no menu is displayed; the "Integrated features" menu item is also displayed in the index before the initial letter A). There are separate operating instructions for Digital Recorder Plus with the additional DVB satellite tuner.

✳

are not available in all TV sets.

Scope of delivery

•

LCD-TFT TV set

•

RC3 remote control with 2 batteries

•

Table stand

•

Marketing and service card

•

Fabric hose

•

Screen cleaner set (only for Spheros R32/37)

•

These operating instructions

Transporting

Only transport the unit in an upright position. Hold the set by the top and bottom edges of the housing. The LCD screen is made of glass and/or plastic and may break if not handled carefully. Should the LCD screen become damaged or should the liquid crystal begin to leak, then it is imperative you wear rubber gloves when removing the set. Should the liquid come in contact with your skin, thoroughly rinse with water immediately.

Installation options

As a desktop unit

Use the stand included in delivery. There are assembly instructions included with the stand. First read these assembly instructions and then set up your set.

As a rotating desktop unit for Spheros R 32/37

Manual rotating plate for table stand TS51, Loewe order no. 89417001

• Table stand Motor Unit, Loewe order no. 88197B51.

• You also require an adapter kit, Loewe order no. 89117A00.

As a wall-mounted unit

Wall holder WM52 for Spheros R 26, Loewe order no. 64493A00.

• Wall holder WM53 for Spheros R 32/37, Loewe order no. 63493A10.

•

As a free-standing unit mounted on a rack for Spheros R 32/37

Flat TV F-Stand 3, Loewe order no. 64498A00.

• Spheros Rack 1, Loewe order no. 58490A01/M01.

•

As a rotating, freestanding unit mounted on a rack for Spheros R 32/37

Spheros Rack Cube 1, Loewe order no. 61493A00/M00 + A30/M30.

• Spheros Rack Cube 1 TV, Loewe order no. 62497A00/M00 + A30/M30.

• Spheros Rack Cube 2, Loewe order no. 61494A30/M30.

•

You also require an adapter kit for the Cube Racks, Loewe order no. 89117A00.

- 8

Welcome

Note on the LCD screen

The TV set with an LCD screen you have purchased meets the highest quality requirements and has been tested for pixel errors. Despite the utmost caution in production of the displays, it cannot be totally ruled out that some of the pixels might be defective for technological reasons. Please understand that such effects cannot be considered a unit defect as deﬁ ned by the warranty as long as they are within the limits speciﬁ ed by the standard.

Cleaning

Use only a soft, clean, damp cloth to clean the TV set, the screen and remote control (do not use any caustic or abrasive cleaning agents). Use the cleaning cloth and cleaning agent included for this purpose (only for Spheros R32/37).

Note: The front screen is to be removed only by a specialist dealer.

Disposal

Packing and box

You have chosen a long lasting technical product of very high quality. We have paid a fee to authorised recyclers who will collect the packing from your dealer for disposal, pursuant to domestic regulations. Nevertheless, we recommend you to keep the original box and packing material for optimum protection if you have to transport the set.

The set

Attention: The EU directive 2002/96/EC regulates the proper way to recycle, handle and utilise used electronic devices. Hence, all used electronic devices are to be disposed of separately. Please do not dispose of this set in the normal household rubbish.

You may return your used set free of charge at designated recycling centres or at your specialist dealer whenever you purchase a new, comparable set. You can ﬁ nd out more about recycling (also for countries outside the EU) from your local government.

9 -

For your safety

10 cm

For your safety and to avoid unnecessary damage to your TV set, please read and observe the following safety instructions:

• This TV set is designed exclusively for reception and reproduction of video

and audio signals.

• This equipment is designed for domestic and

ofﬁ ce environments and must not be used in rooms with high humidity (e.g. bathroom, sauna) or high concentrations of dust (e.g. workshops). If the equipment is used in the open air, ensure that it is protected against moisture (rain, drips, splashes, sprayed water or dew). Do not place any containers ﬁ lled with liquids or lit candles on top of the TV.

High levels of moisture and

concentrations of dust cause leakage currents in the equipment, which can lead to danger of electric shock or ﬁ re.

The manufacturer‘s warranty is only valid for use in the speciﬁ ed permissible

environment.

• If you have moved the TV set out of the cold into a warm environment, leave

it standing for about an hour since condensation may form.

10 cm

• This equipment must

only be connected to a mains power supply

10 cm

which has the same voltage and frequency as that speciﬁ ed on the rating plate; use the

power cable provided. Incorrect voltages can damage the equipment.

• Like all electronic equipment, your TV needs air for cooling. Obstruction

of the air circulation can cause ﬁ res. Therefore the air vents on the back must always be kept free. Please do not place newspapers or cloths on/over the TV.

10 cm

If the TV is placed in a cabinet or on a shelf, leave at least 10 cm at the sides

and 10 cm at the top to ensure sufﬁ cient air circulation.

Position the set so that it is not exposed to direct sunlight and additional

heating from radiators.

• Prevent any metal parts, needles, paper clips, liquids, wax or the like from getting into the TV set through the air venting slits in the rear panel. This can lead to short-circuits and possibly to ﬁ re. If something should get into the inside of the TV set, pull out the plug immediately and notify customer service.

• Never remove the back of the TV set yourself. Repair and servicing of your TV set should only be carried out by authorised TV technicians.

• Place the TV set on a level, ﬁ rm base. The set should not protrude at the front when installing in cabinets or shelves.

Only use original accessories if possible, e.g. Loewe wall holders and stands. Never let children handle the TV unattended. Do not allow children to play in the immediate vicinity of the TV, they could

knock, shift or pull it over and injure someone.

Never leave the TV on unsupervised.

• Do not install the TV where there may be vibrations. Vibrations can lead to material stress.

• Pull out the power and antenna cables during thunderstorms. Surge voltages caused by lightning strikes can damage the TV through the antenna system and the mains. Also remove the antenna and mains plugs in long periods of absence.

• The mains plug of the TV set must be easily accessible so that the set can be disconnected at any time.

• Lay the mains cable in such a way that it will not be damaged. The power cable may not be kinked or laid over sharp edges, not stood on and not exposed to chemicals, the latter also applies to the device as a whole. A mains cable with damaged insulation can lead to electric shocks and is a ﬁ re risk.

• When removing the mains plug, pull the plug housing and not the cable. The wires in the plug could be damaged and cause a short circuit the next time it is plugged in.

- 10

First installation

Remote control

Batteries

To insert or change the batteries, press on the arrow. Slide the battery compartment cover downwards and remove it. Insert LR 03 alkaline-manganese batteries (AAA) and ensure that the + and - ends are positioned correctly.

Then push the cover back on from the bottom.

Note on disposing batteries

The batteries provided contain no harmful materials such as cadmium, lead or mercury. Regulations concerning used batteries stipulate that batteries may no longer be thrown out with the household rubbish. Deposit any used batteries free of charge into the designated collection containers set up at commercial businesses.

Connection

Power mains

Remove the cover for the connections. Connect the TV set to a 220-240V/50- 60 hertz power outlet. Plug the small plug of the mains cable into the mains socket on the rear of the TV set; plug the large mains plug into a mains socket.

Antennas

Plug the antenna plug of your antenna/cable system or the room antenna for DVB-T into the ANT-TV socket (Tuner 1 for Spheros R 32/37).

220-240V~

ANT-TV ANT-SAT

50/60Hz?

Spheros R 26

Setting up the remote control for operating the TV

DVD STB

VCR

How to operate other equipment is described as of page 39.

Set the rotary switch to "TV"

ANT-TV

ANT-SAT

220-240V~

50/60Hz?

Spheros R 32/37

11 -

First installation

If the reception conditions are good, then a room antenna may be used for DVB-T. Passive and active room antennas are available on the market. The power is supplied for an active antenna via the antenna connection. For automatic programming or in "TV Menu – Connections – Antenna DVB – Antenna DVB-T," the distribution voltage (5 volts) is to be set correspondingly. It may be practical to use a nondirectional antenna. If the location is outside the normal transmitting range, then a unidirectional antenna may also be used to improve the reception quality. You can ﬁ nd out more on the digital stations that can be received in your area at your specialist dealer.

If a Spheros R32/37 was retroﬁ tted with a PIP tuner or if this is already integrated in a set with a digital recorder. The PIP tuner output has to be connected with the ANT-TV socket (Tuner 1). See illustration on page 7.

If a Digital Satellite Tuner 1 has been retroﬁ tted, connect your satellite antenna system to the ANT-SAT socket.

If a Digital Satellite Tuner 2 has been retroﬁ tted (only in conjunction with the Digital Recorder+), then connect one antenna cable each, for example from the antenna switch or from the twin LNC, to both SAT sockets.

When laying the cable, use the cable clips afﬁ xed beneath the TV set. Replace the connection cover on the TV set.

Handling the fabric hose

Use the fabric hose included to lay the mains cables, antenna cables or cables from other electronic components systematically; then lead the hose with the cables to the connection boxes. This provides you with an elegant solution when laying cables.

The diameter of the fabric hose increases when you push it together lengthwise (see illustration). This makes it easier for you to push through cables with plugs.

Using the common interface module

(only for sets with CI slot)

In order to be able to receive encrypted digital stations, the common interface module (CI module) and the smartcard both have to be inserted into the corresponding slot of your TV set. You can purchase the CI module and smartcard at your specialist dealer. You can ﬁ nd the slot on the back of your TV set, see the illustration on pages 6/7.

1. Make sure the TV set is switched off with the mains switch on the set, or pull the mains plugs.

2. First push the smartcard into the CI module as far as it will go. Insert it so that the side with the golden contact chip faces the side of the module printed with the supplier‘s brand logo. Printed arrows indicate how

Contact side

to insert the card. Also follow the installation instructions included with the smartcard.

3. Slide the CI module

carefully into the slot with the contact side facing the front. The logo on the common interface module should be visible.

Eject button

Make sure the module is not twisted in the process.

Do not use force.

When the module locks, the eject button is pressed

outwards.

The CI module and the smartcard are not included in

CI module

the scope of delivery for this set; you can usually obtain them at your specialist dealer.

Switching on

Press the mains switch (for Spheros R 37, the set switches on immediately, the green indicator lamp lights up).

For Spheros R 26/32: The red indicator on the set now lights up (standby mode).

Switch on the set using the switch integrated in the indicator (for further operating options see page 14).

)

CE FA

COMMON INTER

- 12

First installation

Automatic programming

Automatic programming of the TV set is started the ﬁ rst time you switch it on. Follow the menus.

1. First you have to select the menu language.

2. By pressing the OK button, you can call the menu "Connect antenna cable(s)". If you want to receive digital stations via satellite, then choose "DVB-S" - conﬁ rm using the yellow coloured key. If you also want to receive digital terrestrial stations (DVB-T), then select "DVB-T". Also select "Antenna/cable (analogue)"

- this way the standard analogue stations can also be searched for and saved. If you can receive digital stations from the cable network, then select "DVB-C" using the yellow coloured key.

3. For the country-speciﬁ c station sorting, enter the location.

4. If you have selected "DVB-T", you then reach the menu "Antenna DVB-T". If you use an active antenna, then select "yes (5V)".

5. In the "Select satellite installation" menu, make the selection that corresponds to your satellite antenna installation.

Note: If you have any questions on how your satellite antenna installation

is conﬁ gured and on the antenna settings, consult your antenna installer or your specialist dealer.

6. Select the satellite the antenna is directed at, such as ASTRA1. If you only receive one satellite ...

7. In the following menu, specify whether the station search should take place in the high and low band ("Yes") or only in the low band ("No"). Note: For most satellites, a station search is required in both bands.

8. For the low band and high band, the standard frequencies 9750 MHz (9.75 GHz) and 10600 MHz (10.6 GHz) are preset. If your satellite antenna is equipped with an LNC (LNB) with a divergent oscillator frequency, specify the corresponding frequency for low and high band respectively. Note: The correct display of the received frequencies in the "TV menu – Settings – Channels – Manual adjustment" depends upon this setting.

By pressing in one of the arrow directions, you can choose the settings ...

... and conﬁ rm your settings by pressing OK. You then go to the next menu.

Back to the previous menu.

Initial installation Connect antenna cable(s)

Antenna cable(s) for: to antenna socket(s): Antenna/cable (analogue) ANT TV DVB-T ANT TV DVB-C ANT TV DVB-S ANT SAT

Proceed

Connect/disconnect Back

9. You should receive a picture with sound with the settings previously made (only for ASTRA 1 and HOTBIRD). Then press OK.

10. In the "Pre-programming" menu, select the factory-set pre-programming to programme the satellite stations quickly. To ensure all stations that can be currently received are searched for and saved, select "No" at this point. Symbol rates: The standard symbol rates 22000 and 27500 are preset. If you would like to receive stations with different symbol rates, specify the corresponding values here using the numeric buttons on your remote control.

11. Press OK to obtain an overview of the settings with which the automatic programming is to take place.

12. Press the OK button again and the station search will start. The TV set searches for, sorts and saves all the TV stations that can be received, according to your settings and the antennas connected.

13. When the TV stations are saved, you will receive a corresponding message.

14. Press the OK button and the set then searches for the radio stations.

15. The TV set searches for, saves and sorts all radio stations which can be received with your antenna system.

16. Then log on your video equipment, decoder and audio system using the connection wizard and connect these to the TV according to the connection diagram displayed. If you want to connect other equipment later, you can ﬁ nd information as of page 32.

You can repeat the initial installation at any time, e.g. after moving house. Call the index using the INFO button (in the TV mode, if no menu is opened). Select the index item "Repeat initial installation" (you will ﬁ nd this listed separately before the letter A). Press OK to start the initial installation.

Note: For DVB-T stations in UK the stations are tied to "Logical Channel Numbers" -- "LCN" and sorted from 1-799. Digital stations without "LCN" are stored from 800 onwards. Analogue stations are stored from 1001.

Station sorting

Note: not with DVB-T stations in UK. You can change the station sorting that was carried out automatically later at any time, see "TV menu – Settings – Channels – Change stations".

13 -

First installation

Daily operation

Directing DVB-T antenna

Note: not with DVB-T stations in UK. If you use a room antenna to receive one or more DVB-T stations that have picture and sound interference, then you should change the location of where the antenna is set up. To help you direct your antenna or to help you determine the most suitable location to set up the antenna, your TV set has a display for the signal quality C/N and the signal strength Level. Consult your specialist dealer to ﬁ nd out which channels and frequency bands (VHF or UHF) are used to broadcast the digital TV stations in your area. On any one channel, several digital stations are broadcast.

Select a TV channel

1. Call the "TV menu" via the MENU button.

2. Use  to select "Settings", then use  to select the menu line underneath.

3. Select "Channels", then use  to select the menu line underneath.

TV menu

Settings

Channels

Manual adjustment ...

Parental lock

Timer functions

4. Select "Manual adjustment" and call the menu using OK (in UK, the manual adjustment does not work with DVB-T).

Manual adjustment

Signal source Channel Frequency Name Bandwidth

C/N 96

DVB-T E 05

177.50 MHz est

T 7 MHz

Level 99

DVB-C

Antenna/cable (analogue)

END

5. For digital stations, select "Signal source – DVB-T".

6. Use the numerical buttons to specify the corresponding channel number. Depending on the channel selected and country, the system automatically

sets the corresponding bandwidth of 7 or 8 MHz. You should only change the bandwidth under special circumstances - if the channel raster in your area is different from the standard.

When you receive a digital station, the system displays the signal quality C/

N via a bar/numeric value and the signal strength via Level. The antenna‘s direction or position is best when the largest values possible are displayed (long bar) for the signal quality and signal strength.

7. Direct the antenna so that the largest numerical value/bar size is reached.

8. If no signal is found in the channel set, you can start the frequency search run by pressing the blue button within the band selected (VHF or UHF).

9. Check the other channels one after another on which digital stations are broadcast terrestrially in your area.

For the weakest station, direct the antenna so that the maximum numerical

value/bar size is achieved.

10. After you position or direct the antenna, we recommend to search for all the stations using the "Search wizard" (TV menu – Settings – Channels – Search wizard).

- 14

END

INFO

Language

Switching on/off

Your TV is equipped with an eco-standby power supply unit. On standby, the power consumption drops to low power. If you want to save even more electricity, switch the set off with the mains switch. However, please bear in mind that EPG data (electronic programme guide) will be lost and programmed timer recordings will not be performed by the TV.

Switching off

If the TV set is switched on, you can switch it to standby using the blue ON/OFF button on the remote control or by using the indicator ﬁ eld on the set. The red lamp on the TV set lights up. If the orange indicator lights up or if both the green and red

)

indicators light up, then, for Spheros R 37, a timer recording is being made, EPG data is being captured or radio operation without screen display is active.

Switching on the TV set

From standby, it is best to switch the set back on using the blue On/Off button or by using the numeric buttons of the remote control (1 – 99). Or, for Spheros R 26/32, use the switch integrated in the indicator on the set.

)

The green indicator on the TV set lights up.

Or switch on the TV set with OK, you can then see the station list and select a station.

Switch on radio

RADIO

With the RADIO button on the remote control or for Spheros R 26/32: Switch on radio using R on the control ring of the TV set.

)

If you switch off the TV set using the mains switch on the set, the indicator no longer lights up.

For Spheros R 26/32: If the TV set is switched off via the mains switch, you have to switch it into the standby mode ﬁ rst via the mains switch and then switch it on using one of the above mentioned methods.

Daily operation

Changing stations

... with the P+/P- buttons on the remote control

P+

(

V- V+

When changing, the station display is visible for a few seconds.

If additional languages are broadcast with DVB stations, then the set displays the language/sound selection under the station display. Call the language/sound selection by using the green coloured key and select using .

... with the numeric buttons of the remote control

The set has a dynamic memory with 1680 station memory locations. If up to 9 stations are stored, you only need to enter one digit; up to 99 stations, two digits are needed; up to 999 stations, three digits are needed (refer to the station list to see how many stations have been stored).

long

short short long

all short

P–

pqrs

abc

pqrs

abc

pqrs

Stations up/down

41 ZDF Eifellandschaft 21:00 – 21:45

Language/sound selection

1 digit stations

Press buttons 0 -9 for one second, and the station changes instantly. Or press button 0 – 9 brieﬂ y, the station then changes after 2 seconds (the station changes immediately when only 9 stations are saved).

2- and 3-digit stations

After brieﬂ y pressing the ﬁ rst numeric button(s), keep the last numeric button pressed for one second, the station then changes immediately. Or press all numeric buttons brieﬂ y, the station then changes after 2 seconds (the station changes immediately if up to 99 or 999 stations are saved).

4 digit stations

tuv

Press the four numeric buttons brieﬂ y, the channel then changes immediately.

... via the station list

wxyz

For an alphabetical display: Enter letters with the numeric button (like on a mobile phone keypad), select with  and call with OK. For bouquet display (sorting according to broadcasting chains, only for DVB stations, not for DVB-T stations in UK): Enter bouquet number, select with  and call with OK. Digital stations are indicated by

. Child-protected stations are indicated by .

Use OK to call the station list

Station list Numerical

COMP. IN HDMI/DVI VGA

AVS

DVD VCR 0 VIDEO 1 ARD 2 ZDF 3 SAT.1 4 RTL 5 VOX

21:00 - 21:45 Eifellandschaft

Switch to ... Scan stations

0 9

... Select station Change stations

Change sorting

Select the station (if possible, the selected station will be displayed as a small picture) or ...

...

... select with numeric buttons

call selected station

Blue coloured key: sort alphabetically/according to bouquets/ numerically

Station list Alphabetical

COMP. IN HDMI/DVI VGA

AVS

DVD VCR

ARD

BR-ALPHA BR3

21:00 - 21:45 Eifellandschaft

Switch to ... Scan stations

... Select letter Change stations

; encrypted stations are indicated

Change sorting

6 3SAT 7 S–RTL 8 N–TV 9 DSF 10 TM3 11 PRO7 12 RTL 2 13 WDR 3 14 BR 15 HR 16 MDR 3 17 N 3

CNN INT. CAM

DELUXE DSF

EUROSPRT

HOT HR

KIKA

END

Call last viewed station (for DVB-T stations in UK)

You can switch back and forth quickly between two stations using this button.

15 -

Daily operation

Basics about the menu operation

Menus are called via the MENU button or via the button for special menus and can be hidden by using these buttons or by using the END button. The menu is displayed in the bottom section of the screen. At the top, you can see additional information for the menu point selected. In the menus, navigate by using the cursor. You can make settings by using . When you exit the menu, the settings are adopted.

Example of the menu operation

We shall demonstrate how to navigate with the menus using the TV menu as an example. You can see which buttons you can use in the dark blue ﬁ eld on your TV set.

- 16

Open TV menu (in TV mode).

Picture Here you can adjust among other things: Contrast, colour, brightness,

picture adjustment, sharpness, picture format.

TV menu Picture

Picture adjustment ...

Sound

Recording

Connections

Select the function in the TV menu, e.g. "Sound" (for sound settings). Use  to move the menu points displayed on the right into the dark blue ﬁ eld; use  to move the menu points displayed on the left.

TV menu

icture

Sound

Treble ...

Recording

Connections

Select the sound function below with  or OK; you will then see a list of the sound settings.

TV menu

Sound

Treble

Bass

more ...

In the sound settings, also select the function with , e.g. "Bass" (for increasing or reducing the bass tones).

TV menu

Sound

Treble Bass

more ...

To set the bass tones, use  or OK to select the setting bar underneath.

Settings

END

INFO

Settings

END

INFO

END

INFO

END

INFO

TV menu

Sound Bass

Set the bass tones by using .

INFO

If you want to make other sound settings, move up with 

to "Bass" and select with , e.g. "more...". You can also move up further to "Sound" by using  and select other settings in the TV menu (such as, picture settings).

END

TV menu

Bass

Sound

more ...

Use OK to call additional sound settings.

TV menu

Sound

Bass

Loudspeaker sound

Stereo ...

Headphone volume

Headphone sound

Select the sound setting using , e.g. "Auto volume" and ...

TV menu

Sound

sound

Auto volume

off ...

AV audio signal Maximum volume

... use  to select the auto volume option.

TV menu

Sound Auto volume

off

Use  to select "on" and activate the auto volume.

TV menu

Sound Auto volume

off

Press the END button to hide the menu.

INFO

Treble

INFO

Auto vo

INFO

Balance

INFO

Apart from the TV menu shown here, other menus can be opened in TV mode as follows:

Call the Sound menu directly. Call the Picture menu directly. Quick calls for Image+

✳

, teletext subtitles, personal text pages, headphone volume, scan stations and to move the picture up and down.

Green coloured key: Call standard settings for picture and sound.

Using the volume control, you can also open other sound

P+

V– V+

settings, such as Sound via, Sound adjustment, Sound effects and Loudness.

P-

The key  or OK must be pressed for the duration of the volume display for this.

END

Daily operation

For the info system ...

For each menu point, an info text is displayed at the top of the picture to help you with the setting. This saves you from having to refer back to the operating instructions. We shall demonstrate this using the station search option as an example:

In this example, you can see the options available after "Settings".

Call the TV menu.

Select "Settings".

Settings Here, you can search for the stations automatically or manually as well

as set the menu language, timer functions, parental lock, on-screen displays, etc.

TV menu Settings

ctions

Channels ...


Sound

Recording

INFO

Conn

If you want to search for new stations, for example, use  to select "Channels" in the line below.

Channels The menu contains the automatic station search and the manual station

setting. You can re-sort stations, enter and change station names and delete stations.

Use  to select the line below, for example "Search wizard".

Search wizard Use this menu to search for stations automatically once certain settings

have been made. If you want to search for stations with other than the displayed settings, select the "Change settings" menu.

TV menu

Settings

Channels

Search wizard Manual adjustment Change stations

INFO

END

The info text explains how you are to proceed.

Upon delivery, the TV set is conﬁ gured so that the info texts are always displayed (Automatic info "yes"). In this case, you can hide the info texts by using the INFO button.

END

You can also conﬁ gure the TV set so that you call the info texts when needed by using the INFO button (Automatic info "no"). You can ﬁ nd the setting to switch the automatic info option on or off via "TV menu under Settings – Miscellaneous – On-screen displays – Automatic info – yes/no".

TV menu

Settings

Channels

Search wizard ...

Parental lock

Timer functions

The info text indicates which settings you can make in "Channels".

END

INFO

Language Mi

17 -

Daily operation

For the index ...

Using the index, you can access many operational functions directly. You can also ﬁ nd a great deal of information on technical terms about television. Before the alphabetical sorting, you can ﬁ nd the menu language option, the list of features integrated into the TV set and the repeat initial installation option.

INFO

Info on the index item selected is visible at the top of the picture. If the OK symbol is displayed in the line selected, you can use the OK button to access the menu directly and carry out settings or selections.

This is how to select the index item:

wxyz

Call the index in the TV mode (without any other on-screen displays).

You can select your language for operating the TV set.

Index

Language Integrated features Repeat initial installation * Access code Active window (PIP) Automatic channel programming (ACP) AV (Audio/Video)

Activate Previous/next letter

a z

... Select letter Page

abc

Enter the ﬁ rst letter using the numeric buttons on the remote

...



P+

Ç/È

P–

control (like on a mobile phone keypad); or

use  to go to the previous/next letter, or

END

For example, you want to have the TV set switch off automatically:

Select the index item "Switch off" – "Automatic".

You can set your TV set to switch off to stand-by mode once or every day at a given time.

Index

Switch off Automatic Manual Symbol rate* Teletext Activate Character set FLOF

Activate Previous/next letter

a z

... Select letter Page



P+

Ç/È

P–

Use the OK button to call "Switch off" – "Automatic".

Switch off today only If you want your TV set to switch off once automatically (to stand-by

mode) select "yes" and enter the time.

TV menu

Settings

Timer functions

Switch off today only

no ...

Switch off daily

One-time reminder

END

INFO

Wake

The corresponding menu "Timer functions" is displayed (in the TV menu – Settings). You can now choose between "Switch off today only" and "Switch off daily" and enter the time.

- 18

P+

V- V+

P–

use P+/P– to scroll up or down through the pages

and use  to go from line to line.

Daily operation

Setting the sound

Volume and other frequently used sound settings

P+

V– V+

Sound adjustment allows you to adjust the sound characteristics to the station‘s sound. The Sound effects settings allow you to expand a Dolby Pro Logic Signal to a virtual surround signal by using "Dolby Virtual"; by using "Panorama", you can enhance the foundation of the stereo sound virtually for the loudspeakers.

Sound off/on

Other sound settings:

Sound settings: Treble and bass. Different menu items are displayed depending on the connected audio device (AURO, hi-ﬁ ampliﬁ er). Under "more ..." you will ﬁ nd the sound selection for loudspeakers and headphones, auto volume, headphone volume, AV audio signal, maximum volume and balance.

Setting the volume

(

P-

Volume ...

by using  or OK, you can call other sound settings ...

Volume

Sound adjustment

Sound effects

and select using  ...

olume

Sound adjustment

normal

Sound effects

Loudness

use  for the related selection/setting...

normal

Sound adjustment Pop

Classic

Speech

... and use  to make the selection/setting there.

Sound off; Sound on: Press button again or adjust volume.

Sound off

Sound on

Call the Sound menu

Sound

Treble

Bass

more ...

use  to select the sound function to be set and use for the related selection ...

Sound

Bass

and use  to select/set.

Loudness

INFO

END

Picture settings

Open the Picture menu

Picture Picture adjustment

normal ...

use  to select the picture function to be set and use for the related selection ...


Colour

... and use  to set/select.

Picture settings: Picture adjustment, Contrast, Colour, Sharpness. Under "more ...", you can ﬁ nd settings for Brightness, Image+ picture up/down, Auto format and Film quality improvement DMM

Direct control on TV set

On page 4 and 5, you can ﬁ nd illustrations of the control units located on the set.

Switching station on the TV set

Station up: with the button + Station down: with the button –

Switching the radio on/off or switching over to the radio

Press R to switch the radio on or off (not for Spheros R 37).

Additional functions via the menu

In the radio or TV operating modes, you can make settings for Volume, Brightness, Contrast, Picture format and Stations. "Service" is intended for the customer service department.

use M or

Direct control on TV set Operating mode Contrast Picture f

use – or + to select the function to be set

Direct control on TV set Volume

mode ContrastBrightness Picture format Sta

use R or

use – or + to set/select.

Use M or other functions.

for the related setting/selection

Direct control on TV set

Volume



Contrast

Colour



Sharpness

✳

, Picture format, Move

to call the menu

Volume Brightness

to move one level up; you can use – or + to select

more ...

✳

END

INFO

END

INFO

19 -

Operating modes – TV

In initial installation and daily operation, the TV set is in TV mode. This is also the case when none of the other modes of operation, such as EPG, Teletext, PIP or Radio, have been selected. Each of these operating modes has a separate menu with separate functions for the coloured keys. Call the menu via the MENU button.

How the coloured keys work in TV mode

Note: The coloured keys do not work as described below with DVB-T stations in UK, but they operate as described on page 30 (Digital Teletext).

Red: the TV picture freezes. Pressing this button again starts the picture moving again. If your TV set is equipped with a digital recorder, the DR archive is called.

Green: Call personal settings/factory settings for picture and sound, save picture and sound settings as personal settings.

Standard settings Call up personal settings

Activate

Call up factory settings Store as per

Yellow: call last station viewed. You can switch back and forth quickly between two stations using this button.

Blue: call programme info.

1 ARD Eifelland 14:30 - 15:15

END

INFO

Sleep timer) that can be selected in the "TV menu – Settings – Miscellaneous – On-screen displays". For the status display, the DVB station providers may offer additional selection options for each station. Thus, the corresponding colour key or the TEXT button is displayed:

Red: channel selection for multi-channel providers.

Green: language/sound selection.

Yellow: time selection.

Blue: protection of minors.

TEXT

DVB subtitles.

If you press one of the coloured keys during the status display or you press the TEXT button, the related selection menu is displayed. The status display subtitles refer only to the "DVB subtitles" and are not provided by all stations. The options you see depend on the particular station (many stations broadcast subtitles via teletext). The status display is displayed automatically when a new programme begins with options different to the previous one.

Notes:

• In the sound mode, Mono! means that you have switched manually from stereo to mono, for example.

• The selection menus are only available as long as the status display is displayed. You can call them again at any time by pressing the END button on your remote control.

Programme info 14:43 Detailed info

Detailed info (teletext)

Channel preview (tel

Show status display

END

In the line above, you can see the name of the station and the sound mode. Displayed below are additional options (Time, Sound mode, Alarm time and

- 20

Show/hide status

1 ARD Eifellandschaft 14:30 - 15:15 Stereo

14:42 Alarm time 20:00 Sleep timer 23:00

Language/sound selection

Calling the index

INFO

END

You can ﬁ nd more information on the index on page 18.

Calling the index

You can select your language for operating the TV set.

Index

Language Integrated features Repeat initial installation * Access code Active window (PIP) Automatic channel programming (ACP) AV (Audio/Video)

Activate Previous/next letter

a z

... Select letter Page



P+ P–

END

Ç/È

Operating modes – TV

Call additional functions

Select additional functions such as Image+ ✳, Teletext subtitles, Personal teletext pages, Headphone volume and Scan stations.

Additional functions

Image+

off ...

Teletext subtitles Personal teletext pages

INFO

Call timer overview

If timer recordings have been programmed, you will see when which station is recorded here.

Timer list Fri 12.09./14:12

12.09. 18:00-18:30 3SAT Die Köchin, die Putzfrau und d

TEXT

Detail New recording Change

Delete

END

INFO

Select picture format

The TV set sets the best picture format automatically when Auto format is switched on. If you want to set a different format, press this button until the desired format is selected or select the format with .

Picture format

Panorama16:9

4:3

Cinema

Zoom

Move picture up/down

Note: for DVB-T stations in UK you can switch back and forth quickly between two stations using this button.

To make picture subtitles visible, you can useto move the picture up or down with the picture formats "Panorama", "Cinema" and "Zoom".

TV menu

Call up the TV menu

TV menu Picture

Picture adjustment ...

Sound

Recording

Connections

INFO

Settings

For a recorder that is logged in, you can ﬁ nd the following menus in the "Recording wizard":

Recording wizard - to programme new timer recordings

• Via EPG (not for DVB-T in UK) • Via teletext • Manual

END

You will ﬁ nd further information about timer recording on page 33. Timer list

Here you will ﬁ nd a list of programmes programmed for recording. You can change the recording data or delete programmed recordings and programme new recordings.

Pre-record time and Post record time For recordings without VPS/PDC, set a lead and lag time here so that the programme is fully recorded despite any slight differences in the time.

Under "Connections" you will ﬁ nd the following functions:

New devices/modiﬁ cations (connection wizard) The connection wizard helps you connect and log in additional equipment such as video recorders, DVD players/recorders, camcorders/digital cameras, pay TV decoders, equipment with component signals and digital HDMI/DVI signals.

Antenna DVB

• Antenna DVB-T • Antenna DVB-S

You can ﬁ nd more information on pages 13 and 14. Digital Link Plus

Transmission of the station data from the TV set to the video/DVD recorder if a recorder with Digital Link Plus is connected.

Miscellaneous (connections)

• Set AV norm for the connections manually (if it is not recognised automatically).

• "Assign audio digital signals" to one of the AV sockets.

• "Allow switching voltage" to display the signals of the connected device immediately on the screen via Euro AV during playback.

• RGB insertions at AV2 to play back RGB signals at all station storage locations.

• Select decoder stations and set sound encoding.

Under "Settings" you will ﬁ nd the following functions:

Channels Here you can search for and store new stations automatically or manually. With "Change stations", you can rearrange and delete the stations and change

END

station names (not for DVB-T stations in UK).

• Search wizard • Manual adjustment • Change stations

You will ﬁ nd a description of the picture and sound settings on page 19. The TV menu offers other options for recording, connections and settings of the TV set.

only for sets with DVB-S

21 -

Operating modes – TV

Parental lock You can lock the TV "immediatley", "daily" for a certain period of time or "agerelated" for DVB programmes with age restrictions. Here, you determine the PIN to enter if you want to watch locked programmes.

Timer functions You can have your TV switch off at pre-programmed times or wake you/remind you with radio or TV. If you are not present at the time, a safety prompt makes sure the TV switches off again after 5 minutes.

• Switch off today only • Switch off daily • One-time reminder

• Wake up Mon-Fri • Wake up Sat • Wake up Sun • Wake up with

✳

• Wake up signal volume Language

If "your" menu language is not set, you have to select the "Language" menu in a language that you do not understand. Therefore here is a simple way to set the right menu language:

1. Press the INFO button (index), select the ﬁ rst listing (this is above A).

2. Call the language selection by pressing the OK button.

3. Now select the desired language and conﬁ rm it by pressing the OK key.

4. Hide the menu again with the END button. Miscellaneous (settings)

On-screen displays You can set the duration and position of the station and status display, deﬁ ne the content of the status display and switch the automatic info texts on or off:

• On-screen display time • On-screen display position • Programme title

• Sound mode • Time • Alarm time • Sleep timer • Automatic info Time and date

If you receive teletext, the set registers the time and date. These are required for timer recordings, timer functions and EPG. If you do not receive teletext, then you have to enter the date and time; you should not switch off the set using the mains switch since the settings will then be lost.

DVB software Update of DVB software via satellite

DVB subtitles

• Subtitles off • Subtitles for the Hearing Impaired

• Subtitles as translation for foreign language programmes DVB character set

• Western European • Polish • Standard. Rotate TV

For Spheros R 32/37, it is possible to rotate the TV set on a Loewe rotating stand. You can ﬁ nd out more on page 41.

DVB subtitles

If the station provides DVB subtitles, then you can have the TV display them permanently or suppress their display. You can also select between subtitles "for translation" or "for the Hearing Impaired".

1. Call the "TV menu" via the MENU button.

2. Select the "Settings" line and conﬁ rm using OK.

3. Select the "Miscellaneous" line and conﬁ rm using OK.

4. Select the "DVB subtitles" line and conﬁ rm using OK.

DVB subtitles

Subtitles off for impaired hearing for translation

Note: If you have selected "Subtitles off", then the set generates an on-screen display when subtitles are available.

By using the END button, you can open the status display and you can display the subtitles again by using the TEXT button.

• Call the status display by pressing the END button, if it is not yet displayed.

• When the status display is visible, press the TEXT button. Select the desired language and conﬁ rm using OK. The presetting changes for the current programme.

• Which subtitle languages can be selected depends on the provider.

• The automatic shortlist is determined by the menu language and the selection made in the "DVB subtitles" settings menu.

• By pressing the END button, you can hide the menu again.

Note: DVB-T subtitles are not available when Digital Teletext is selected.

END

INFO

only for sets with DVB-S

- 22

Operating modes – TV

Removing the CI module

1. Switch the TV set off by pulling the mains plug from the power outlet.

2. Remove the cover from the back of the set on the upper left.

3. Press the eject button at the module slot; the module is unlocked.

4. Remove the module from the set.

CI module

COMMON INTERFACE

Inserting a new CI module

After you insert a new CI module and switch the TV set on, the following dialogue is displayed:

Autom. station search

Your TV set has detected a new CI module. This requires a station search for all new receivable stations.

After you press the OK button, the system starts the wizard to carry out the automatic station search. Check the proposed search parameters and let the set search for new stations.

Calling the CI module menu

Here you can call up information on the inserted common interface module and the smartcard. To do this, use the MENU button to call the TV menu, select the line "Settings", "Miscellaneous" and then the entry "CI module - xxx" (in place of "xxx" stands the name of the provider which is output by the smartcard. The content of this menu depends on the particular supplier of the CI module.

Note: This menu is only available for digital stations

Installing new DVB software

To ensure your DVB-S receiver is always performing at the state of the art, newly developed software versions are made available from time to time; these are broadcast via satellite and can be automatically installed on your set (only possible via ASTRA1).

Software is recognised automatically

The set can determine whether a new software version is available. This occurs at night when your EPG is automatically updated. For this, your TV set has to remain in the standby mode (do not switch off using the on/off button on the set). If a new software version has been found, the set will indicate this with an onscreen message the next time the set is switched on: You can decide whether or not you want to download the new software. Conﬁ rm using OK, so that the new software can be loaded and installed via satellite. Continue as set out in the "Downloading software" section.

Searching for new software

If you want to carry out a manual search for new software, proceed as follows:

Call the TV menu using the MENU button.

Conﬁ rm the "Settings" using OK.

Conﬁ rm the "Miscellaneous" using OK.

Select "DVB software" and press OK.

Update digital TV software

Current version: V3.x.x

You can search for a new software version with OK.

If you start the search using OK, the set checks if there is a new software version available.

If there is a new version available, the set generates an on-screen message.

Update digital TV software

Current version: V3.x.x

New version: V3.1.0

Downloading software

If you press OK in the dialogue above, you can decide whether you want to download the new software immediately, when you switch off the set or not at all. We recommend you always carry out the update of the digital software. This is the only way to ensure your set is always up to date.

If you do decide to update, the software is initialised on your set and you are informed of the status with a grey bar.

Do not switch your set off during this time. This process may take up to one hour. You will be informed when the process is completed.

After the software is updated, you will be asked to switch your TV set off and back on again using the on/standby switch.

If the update was not carried out, you will be asked several times when you switch on the set whether you want to carry out this update.

23 -

Operating modes – TV

Image+

Image+ is a picture improvement specially developed by LOEWE, which delivers a sharper, lifelike and colour-fast picture richer in detail and contrast. Image+ is only integrated in Spheros R 32 and Spheros R 37.

Image+ menu

Call the menu "Additional functions".

END

more ...

INFO

END

INFO

END

INFO

END

INFO

Additional functions

Image+

off ...

Use  to move to the corresponding selection/setting....

Additional functions

Image+

off

and use  to select/set and use....

Additional functions

Image+

Activate

to activate.

Teletext subtitles Personal teletext pages

Demo

off

IIn the Image+ menu, the functions Image+ "on", "off" and "Demo" can be set. The Image+ settings can also be opened via the "Picture menu".

Open the Picture menu

Picture Picture adjustment

normal ...



Contrast

Colour

Sharpness

Image+ demo mode

In order to show the way Image+ works, a "Demo mode" is integrated. In "Demo mode", the current picture is divided into two parts. The left half of the picture is shown in "normal" mode, the right half in the Image+ optimised mode.

The demo mode can be closed by pressing on any button on the remote control.

Image+ off

Image+ on

use to go to more... and select with OK

Picture Image+

htness

on ...

Picture format

Select/set as described in the Image+ menu.

The standard setting at delivery of the set is Image+ "on".

- 24

Move picture up/down

INFO

END

Auto fo

Operating modes – PIP

Picture in picture (PIP)

Note: The coloured keys do not work as described below with DVB-T stations in UK, but they operate as described on page 30 (Digital Teletext).

Picture in picture displays are possible if the set has an analogue PIP tuner or a digital satellite tuner in addition to the analogue TV cable tuner. You can have a PIP tuner (not for Spheros R 26) or a digital satellite tuner (not for UK sets) retroﬁ tted. If there is no other tuner installed, you can use PIP (AV-PIP) when playing a video recorder or DVD player. For a retroﬁ tted PIP tuner, the following PIP displays are possible: Main picture analogue – PIP picture analogue, Main picture digital – PIP picture analogue. The following is not possible: Main picture digital – PIP picture digital, Main picture analogue – PIP picture digital. For "Split screen," the PIP picture is displayed on the right side of the screen. Both pictures share the screen in two equal halves. For the "Small PIP" setting, a small picture is displayed in the TV picture. The green bar/frame indicates that the control commands have an effect on the PIP picture. The white bar/frame means that the control commands have an effect on the main picture. Use the green coloured key to switch between the PIP picture and the main picture, for example to change stations. The frame or bar between the pictures is green for the time being.

PIP

Show/hide PIP picture

PIP picture as freeze picture

The bar/frame has to be green. If not, press the green coloured key. If you press the red coloured key, the PIP picture freezes. Press again - moving picture.

Selecting the station of the PIP picture

The bar/frame has to be green. If not, press the green coloured key. Then select the station as usual.

Select the station of the TV picture (main picture)

The bar/frame has to be white. If not, press the green coloured key. Then select the station as usual.

Note: For UK sets, you switch from the green bar/frame to the white by using the PIP key. The next time you press the PIP key, PIP is switched off.

41 ZDF Eifellandschaften 21:00 – 21:45

PIP scan in the PIP picture

The bar/frame has to be green. If not, press the green coloured key. Start scanning the stations using the blue coloured key. The bar/frame turns blue.

The stations now change automatically. Stop scanning the stations by using the blue coloured key. The bar/frame turns green again.

Interchanging PIP picture/TV picture

The bar/frame has to be green. If not, press the green coloured key. Interchange the pictures by using the yellow coloured key.

1 ARD Der Wilde Westen 21:15 – 22:15

41 ZDF Eifellandschaften 21:00 – 21:45

25 -

Operating modes – PIP

Functions in the PIP menu

In the PIP menu, you can set the PIP type (small picture or split screen) and the position of the small picture.

Call the PIP menu (PIP must be active, green bar/frame)

TV menu

Settings PIP

all PIP

Type

Split screen



END

INFO

Setting the PIP type

You can have the PIP picture displayed as a small PIP or split screen.

Switch to small PIP:

Select "Type" and then "Small PIP"

Position of the PIP picture

Move the PIP picture with the arrow keys to a corner of the TV picture. In this case, the frame around the PIP picture has to be green, and there should not be any other displays visible on the screen.

Switch to split screen:

You can have the PIP picture displayed on the right hand side of the screen. Both pictures share the screen in two equal halves. You will see a coloured vertical bar between the pictures

Call the PIP menu (PIP must be active, green frame)

Select "Type" and then "Split Screen".

TV menu

Settings PIP

Type

Small PIP

Split screen

For the small PIP, you will see a coloured frame around the PIP picture.

- 26

END

INFO

TV menu

all PIP

Settings PIP

Type

Split screen



END

INFO

Operating modes – EPG

EPG - Programme guide

Note: The EPG does not work with DVB-T stations in UK. The "Now & Next" feature for programme info of the current and next broadcast is displayed instead.

EPG is an electronic programme guide. With this system, you can easily ﬁ nd the programmes that interest you (sorted according to day, time, channel and topic). You can mark programmes and programme recordings. Depending on whether you are receiving analogue stations by cable/antenna or digital stations, you will have different programme guides. A wizard is activated the ﬁ rst time you use EPG (not with DVB) which guides you through the necessary settings. Then run the data capture (see next page).

Using the EPG

EPG

Switch EPG on/off

EPG (Electronic Programme Guide) Fri 10.09./14:14 Fri 10.09.

Date

now soon 14:00 15:00 16:00 17:

Time

Channels

24 Kabel 1

TEXT

Detail View Record

P+

Page

P–

The programme guide menu is divided into two areas: at the top, you can make the settings for the programme list (date, ..., topics); on the bottom, the programme list is displayed. Use the blue coloured key to switch between the two areas to make your selections. All programmes currently running are listed initially in the programme list. With the  buttons, select the programme you want to watch and switch over with the OK button. Brief information is shown below the programme list for some programmes. If more detailed information is available, you can call it using the TEXT button. Use P+/P– to scroll up or down through the pages of the programme guide. In the selection lines for date and time above, you will see the time change when scrolling; when you scroll further, the date also changes. When the "Time" line is selected, you can enter the time as of which the programmes are to be displayed; use the numeric buttons on your remote control to do this. Always enter four digits, such as 0900 for 9 a.m.

all all

Topics

13:20-14:15 Kabel 1 Die Waltons 13:30-14:15 H3 ARD-Buffet 13:55-14:20 Kinderkan Blaubär & Blöd (37) 14:00-14:15 ZDF heute - in Deutschland 14:00-15:00 RTL Das Strafgericht 14:00-15:00 Sat 1 Zwei bei Kallwass 14:00-15:00 Pro7 Das Geständnis - Heute s... 14:00-14:30 N3 DAS! ab 2 14:00-14:20 WDR Die kleinen Strolche (10) Familienserie - Sturzflug

0 9

...

Ç/È select time Select date, ... , topics

END

If programmes are displayed which have not yet started, you can mark these with the OK button. The TV set then switches automatically to this station at the given time. When receiving digital terrestrial and digital satellite stations, you may ﬁ nd that two identical EPG data are displayed in the "EPG (DVB)" menu for one station. If you call the EPG menu in the EPG mode by using the MENU button, then select "Station selection," you can select the duplicate station and deactivate it by using OK). You have direct access to the selection lines above to pre-select the day, the time, the station and the topic.

Blue coloured key: Call Select date/time/channels/topics

EPG (Electronic Programme Guide) Fri 10.09./14:14

Date

Sat 11.09. Sun 12.09. Mon 13.09.

Time

Channels

24 Kabel 1

06:00 all

Topics

all

06:00-06:20 ZDF Die Blobs

06:00-06:30 RTL Wunderbare Jahre 06:00-06:25 Kabel 1 Dennis 06:00-06:25 N3 Extra en español (5) 06:00-06:30 BR Goal. Speak English, Play Football 06:00-06:30 WDR Lokalzeit Südwestfalen 06:00-07:10 SuperRTL Infomercials 06:00-07:10 Kinderkan Reif für die Dodo-Insel (25) 14:00-14:20 9LIVE Reisetraum Comedyserie - Kandidaten mit gewissen Fehlern

Change to programme list

END

Use  to select the menu line for the date, time, channels or topics. Use  to select within the menu line.

If, for example, you are looking for the next news, select today’s date, "Soon" under Time, "All" under Channels and "News" under Topics. Then you get a list of all news programmes in the programme list below.

EPG (Electronic Programme Guide) Fri 10.09./14:14

Date

Fri 10.09.

Time

Channels

24 Kabel 1

soon all

Topics

News Show Hobby Sport Child Kn

15:00-15:15 Das Erste Tagesschau um drei

15:00-15:05 hr-fernse hessen aktuell 15:00-15:15 ZDF heute - Sport 16:00-16:05 SÜDWEST Baden-Württemberg Aktuell 16:00-16:15 Das Erste Tagesschau um vier

Nachrichten - News

Change to programme list

END

If you want to mark one of these news programmes, return to the programme list using the blue coloured key, select the desired news programme by using and mark this by using OK.

27 -

Operating modes – EPG

In front of the programme’s title, the system places an

. This station is

✓

switched later to this programme when the set is switched on. If the TV is off, it switches on again automatically at the beginning of the marked programme if this has been set in the EPG menu. If you are out, a security prompt prevents the TV set staying on unattended. Before leaving the upper selection lines using the blue coloured key, select a speciﬁ c line. If you have switched back to the programme list, you can change this menu line using  without having to leave the programme list.

Programming recording for recorders

The programme marked using the  buttons can be prepared for recording by pressing the red coloured key. In the following menu, conﬁ rm the timer data or change them as required. Then, a red dot is set in front of this programme in the EPG programme list as an identiﬁ cation (if timer data is being transferred to the recorder, no red dot is set). If you select this programme, you can delete it from the timer using the red coloured key (if the timer data has been transferred to a recorder, the timer has to be deleted there).

EPG menu

You will ﬁ nd the following settings in the EPG menu:

• Select provider • Station selection • Timer list • Data capture

• Switch on TV when marked

Call EPG menu

EPG menu Select provider

END

Timer list

INFO

Data captureStation select

Switc

Selecting providers and stations

If you want to change the provider for analogue TV reception (the station which transmits EPG data) to have other stations evaluated, you can do this under "Select provider".

Select "Select provider" and call this menu using OK. If the station you want to switch to is not listed in the "Select provider" list, then use the yellow coloured key to start the automatic search for stations with EPG data. This takes a while.

Or, if you know the station that transmits EPG data, press the blue coloured key to compile manually. Select the provider in the station list and adopt it by using OK and return to the provider selection using .

Select the provider in "Select provider" and adopt it using OK. Then a station list search is performed. The stations offered by the provider are displayed in a list.

If you want certain stations to be omitted from the programme guide, you can select and deactivate these via Station selection. Call the station selection by using the blue coloured key.

Now all stations are displayed (the DVB stations, too). Stations indicated with E are analogue terrestrial/cable stations; stations indicated with D are digital stations ready for the programme guide. Select the stations you want to omit from the programme guide one after another and deactivate each one by using OK.

Data capture

After these settings or after each time the set is switched off using the mains switch, the data must ﬁ rst be collected, before switching on the set. To do this, select the station you have deﬁ ned as a provider and leave the TV set switched on for about one hour or switch the set to the standby mode. After about two minutes, the orange indicator on the set lights up (for Spheros R 37, both indicators light up). The data capture begins and lasts about 1 hour. The data are also automatically captured between 2 a.m. and 5 a.m. when the TV is switched to standby. A prerequisite for data capture is that "Data capture" is "on" (for DVB + analogue) in the EPG menu.

Note: If the TV set is switched off using the mains switch or the mains plug is pulled out, all EPG data are lost. If, for example, you cannot receive any analogue EPG providers or if you only use DVB, you should set the data capture to "on (only for DVB)".

Switch on TV when marked

You can have the TV switched on automatically from standby at the beginning of the marked programme. If you are not present at the time, a safety prompt makes sure the TV switches off again after 5 minutes.

- 28

Operating modes – Teletext

Bulmahn: Bildung statt Eigenheim

120

Analogue Teletext

Teletext transmits information such as news, weather, sports, programme previews and subtitles.

TEXT

Many stations use the TOP operating system, some use FLOF (e.g. CNN). Your TV supports both these systems. The pages are divided into topic groups and topics. After switching on the teletext, up to 3,000 pages are stored for fast access.

Page selection with the coloured keys

The coloured bars (in TOP) or the coloured writing (in FLOF) in the next to the last line show you which coloured keys you can use to scroll to topic groups and topics.

Other page selection options:

Teletext on/off

100 100 ARD-Text 10.09.04 14:14:42

ARD TEXT Teletext im Ersten

Bulmahn: Bildung statt Eigenheim . . . . . . . . 120

Wird auch der Nahverkehr teurer? . . . . . . . . 121

Australien: Keine Zugeständnisse . . . . . . . . 122

Tote bei Zugunglück in Schweden . . . . . . . . 532

Tennis: Haas unterliegt Hewitt . . . . . . . . . . . . 204

Formel 1: Schumacher erneut vorne . . . . . . . 213

Tagesschau . . 110/112 Kultur. . . . . . . . . 500

Wetter. . . . . . . . . . . 170 Gesellschaft . . . 530

Sport. . . . . . . 200/600 Lotto/Toto . . 666

TV Guide . . . 300/400 Wirtschaft. . . . . . 700

Internet: www.ard-text.de

– +

Page selection

Inhalt tagesschau

Index > 101

Red: back to the previously seen page (not in FLOF)

Green: on to the next page (not in FLOF)

Yellow: to the next topic (only in TOP and FLOF)

Blue: to the next topic group (only in TOP and FLOF)

Select one page number speciﬁ ed on the page by using (Page Catching)

ormel 1: Schumacher erneut vorne . . . . . . .21

Tagesschau . . 110/112 Kultur. . . . . . . . . 500

Wetter. . . . . . . . . . . 170 Gesellschaft . . . 530

Sport. . . . . . . 200/600 Lotto/Toto . . 666

TV Guide . . . 300/400 Wirtschaft. . . . . . 700

Internet: www.ard-text.de

– +

Page selection OK View

Inhalt tagesschau

call

In Multiple pages scroll using . You can see which multiples pages can be called in the bottom menu line.

– +

INFO

Call contents page 100

Call the TOP table The TOP table is a general list of teletext. You can only call the table for stations that use the TOP operating system.

Wird auch der Nahverkehr teurer? . . . . . . . . 121

Australien: Keine Zugeständnisse . . . . . . . . 122

TOP table

Tote bei Zugunglück in Schweden . . . . . . . . 532

Übersicht

Tennis: Haas unterliegt Hewitt . . . . . . . . . . . . 204

tagesschau

Formel 1: Schumacher erneut vorne . . . . . . . 213

Wetter Sport 1 TV Guide

Tagesschau . . 110/112 Kultur. . . . . . . . . 500

ARD heute

Wetter. . . . . . . . . . . 170 Gesellschaft . . . 530

ARD morgen

Sport. . . . . . . 200/600 Lotto/Toto . . 666

FS-Sendungen

TV Guide . . . 300/400 Wirtschaft. . . . . . 700

TV Guide 2

Internet: www.ard-text.de

more . . .

– +

View

Use  to select the topic group. Select the topic column using . Select the topic with  and display page with OK.

pqrs

abc

Enter the page number directly

Displaying teletext pages

Stop self-turning pages (HOLD)

wxyz

Zoom page: top part - bottom part - normal size (press button several times)

PIP

TV picture on/off (Split Text)

Seitenauswahl

Zeitplan Fußball

1 2 3 4 5 6 7 8 9 10 11 12

. . . . . . . .

Wetter

Vorhersage

Städte Regional Reisen int. Städte Biowetter

Inhalt tagesschau

100 100 ARD-Text 10.09.04 14:14:42

ARD TEXT Teletext im Ersten

Bulmahn: Bildung statt Eigenheim . . . . . . . . 120

Wird auch der Nahverkehr teurer? . . . . . . . . 121

Australien: Keine Zugeständnisse . . . . . . . . 122

Tote bei Zugunglück in Schweden . . . . . . . . 532

Tennis: Haas unterliegt Hewitt . . . . . . . . . . . . 204

Formel 1: Schumacher erneut vorne . . . . . . . 213

Tagesschau . . 110/112 Kultur. . . . . . . . . 500

Wetter. . . . . . . . . . . 170 Gesellschaft . . . 530

Sport . . . . . . . 200/600 Lotto/Toto . . . . 666

TV Guide . . . . 300/400 Wirtschaft . . . . 700

Internet: www.ard-text.de

– +

Page selection

END

Index > 101

Inhalt tagesschau

29 -

Operating modes – Teletext

Programme timer recordings

A video and/or DVD recorder must be connected and logged in in the connection wizard. Call the programme pages of the current station in teletext mode using the Direct recording button

. Scroll to the teletext page in which the programme to be recorded is listed if necessary. Select the programme you want to record by with  and conﬁ rm with the OK button. For "Timer data," select the VCR or DVD recorder and whether you want to record once or a series of times. Conﬁ rm with OK.

Teletext menu

Here you will ﬁ nd functions such as

• "Newsﬂ ash", this is an on-screen display of the latest messages (e.g.

page 111).

• "Reveal" concealed information, e.g. VPS pages in the station preview

pages.

• Programme wizard for recording via teletext. In the settings, you will ﬁ nd menus to deﬁ ne the station preview pages, subtitle

pages and personal text pages, and menus to set the character set selection as well as HiText graphics.

Display teletext menu

100 100 ARD-Text 10.09.04 14:14:42

Bulmahn: Bildung statt Eigenheim . . . . . . . . 120

Wird auch der Nahverkehr teurer? . . . . . . . . 121

Australien: Keine Zugeständnisse . . . . . . . . 122

Tote bei Zugunglück in Schweden . . . . . . . . 532

Tennis: Haas unterliegt Hewitt . . . . . . . . . . . . 204

Formel 1: Schumacher erneut vorne . . . . . . . 213

Tagesschau . . 110/112 Kultur. . . . . . . . . 500

Wetter. . . . . . . . . . . 170 Gesellschaft . . . 530

Sport. . . . . . . 200/600 Lotto/Toto . . 666

TV Guide . . . 300/400 Wirtschaft. . . . . . 700

ording

Internet: www.ard-text.de

Settings

Personal text pages ...

ARD TEXT Teletext im Ersten

Inhalt tagesschau

Index > 101

Newsflash

ENDINFO

Reveal

Digital teletext operation (only for UK device version 27)

In the UK, the teletext for DVB-T stations is transmitted as per the MHEG5 standard (standard of the Multimedia and Hypermedia Expert Group). It contains text, graphics, functions and links. The operation of these menus depends on the particular provider. Normally after a station is changed, the provider broadcasting the digital teletext makes an introductory offer for this service on the screen via menu selection. Follow these notes.

Depending on the provider’s respective offer, you can use the  buttons and the OK button, the coloured keys, the END/TEXT button and sometimes even the numeric buttons. If you want to close the digital teletext, just select a different station using the P+/P– buttons or follow the menu prompts on the screen.

Note:

Digital teletext is not available when DVB-subtitles are being displayed.

• If a timer recording is programmed at the TV-set, at the start time of the

• recording the digital tletext mode is switched off automatically

- 30

Operating modes – Radio

Radio

You can only receive radio stations via DVB. If you do not have any DVB radio reception, you can play a sound signal from an external device using the TV set via the sound/AV inputs.

RADIO

You can see a station list of the radio stations or with DVB-T in UK the station logo. In this case you can call up the station list by using the OK or INFO key. Station list is sorted by LCN. If data are sent by the station, then the time and title of the programme are displayed in the station list. When the station list is shown you can switch off the screen with the red colour key. The LED indicator on the set changes from green to orange or if both the green and red indicators light up, then, for Spheros R 37. You can switch the screen display back on by using the OK key, red or blue colour keys, by using RADIO or END on the remote control or by using R on the control ring of the TV set. Station switching with dark screen: by using – or + on the control ring of the TV set or by using the remote control P– and P+ or by using the numeric buttons (for DVB-T operation in UK, the buttons may be conﬁ gured differently by the provider).

The sound menu can be called in the radio mode using the

Use the RADIO button on the remote control or the R on the control ring of the TV set to switch the radio on or off.

)

Radio: 8 DLF Numerical

AUDIO IN AVS AV2 AV1 1 B5 AKTL D 2 BAYERN 1 D 3 BR4 KLSK D 4 SUNSHINE D 5 ROCK ANT D 6 ANTENNE D 7 DLR D 8 DLF D

18:00 - 18:10 Nachrichten

Switch to ... Scan stations

0 9

Select station Previous station

...

Screen off/on Change sorting

9 HR-INFO D 10 MDR INFO D 11 MDR FIGA D 12 NDR KULT D 13 SWR1 D 14 SWR2 D 15 WDR3 D 16 WDR5 D 17 OESTER 1 D 18 MDR JUMP D 19 JAZZ RAD D

20 BLUSAT20 D

button.

END

EPG

UK), delete stations from the list, rearrange them or change names and set the switching off and alarm functions.

EPG - Programme guide

Note: not with DVB-T stations in UK.

For the DVB radio stations, you can also use the programme guide if the station currently active supplies data.

EPG

EPG- Call Programme guide

Radio menu

In the radio menu, as in TV mode, you can set the sound, search for radio stations and store them (automatically or manually – not with DVB-T mode in

Call radio menu

Radio menu Sound

Treble ...

Channels

Timer functions

INFO

END

31 -

Operating additional equipment

You have logged in and connected all connected equipment in the initial startup. If you want to connect other equipment or disconnect equipment, call the connection wizard.

State what equipment you want to connect. State whether a piece of audio equipment is to be connected (more details as of page 35). The connection wizard then shows you which sockets you should connect this equipment to. Then connect the equipment to these sockets according to the connection diagram.

Connecting video/DVD recorders

In addition to the connection via the Euro-AV sockets, you also have to connect the antenna (only for terrestrial antenna or cable systems) through the VCR/DVD recorder to the TV set. The antenna signal is then available to the video/DVD recorder and the TV set. Note: Use Euro-AV cables with right-angled plugs as shown.

Call up the TV menu

Select "Connections"

Select the submenu line

Select "New devices/modiﬁ cations" and ...

Call with OK.

Search for and store the station of the video recorder (if no Euro-AV cable is available)

Switch on the test station on the VCR or insert a recorded tape and start playback. In some video recorders the station must be switched on by activating the modulator.

Then call the AV selection on the TV set with 0 AV. Select the menu item "VIDEO" in the AV selection and call using OK. To prevent "normal" TV stations being found in the search, pull out the antenna plug from the antenna input of the VCR temporarily (the cable to the antenna system). If you cannot see the test station or playback from the cassette, the VCR is transmitting on a different channel. You then have to search for the station or set it manually.

1. Call the TV menu with the MENU button.

2. Select the "Settings" menu item with .

3. Select the line below using  and use  to select "Channels".

4. Select the line below using and select "Manual adjustment" using 

and call this menu using OK.

5. Enter channel "E30" under the "Channel" menu item ("Antenna/cable

(analogue)", select in this menu above if necessary).

6. Start search with the blue coloured key.

7. When the station has been found, change the name if needed, conﬁ rm with

OK and save with the red coloured key.

8. A list of the stored stations is displayed.

9. Select 0 (VIDEO) here and overwrite this station storage location using the

red coloured key.

10. Hide the menu again using the END button.

- 32

AV1

ANT-TV

Plug the antenna plug back in.

If you now get interference because a TV station is transmitting on the same channel as the VCR station, you have to change the transmitting station on the VCR and search for the VCR station on the TV again.

ENTREE

SORTIE

AUDIO

ANTENNE

AERIAL

OUT

SORTIE ANTENNE

RF OUT

EURO AV2 DECODER

EURO AV1

AUDIO/ VIDEO

Operating additional equipment

Video playback

There are several ways to see the picture and hear the sound of the VCR, DVD player/recorder or camcorder on your TV:

1. You can usually use the Euro-AV sockets on the TV set and on the VCR. For camcorders or digital cameras, use the AVS sockets on the right of the TV set. DVD players/recorders and SetTopBoxes may have HDMI or component sockets for video and audio transmission. In this case, use the corresponding sockets on the TV set.

When playing back from a video recorder using Euro-AV socket and Digital

Link Plus (or a comparable system from another manufacturer), the picture from the VCR is shown at the current channel location.

When playing back from another VCR, camcorder or digital camera, use

the AV selection device to which the VCR is connected.

Video recorders transmit a switching voltage during playback, which the

TV can evaluate (can be activated in the connection wizard or in the "TV menu – Connections – Miscellaneous – Allow switching voltage" - set to "yes"). Then the picture of the video recorder is shown during playback at the current station location.

2. You can use the antenna connection between the VCR and the TV without a Euro-AV socket. The sound is only transmitted in mono. Select the ﬁ rst menu item, e.g. VIDEO, in the AV selection.

Calling AV inputs in the AV selection:

Now you will see the playback from the connected AV device.

Calling AV input via the station list

Call the station list with the OK button in TV mode. In the numeric and alphabetical sorting, you will always ﬁ nd the AV sockets at the top of the list.

or the station list (OK) to select the AV socket/the

Call AV selection

VIDEO

AV selection VCR

DVD

AVS

HDMI/DVI COMP. IN

VGA

Select AV device/socket (or VIDEO if the video recorder has been connected only via the antenna socket) and use ...

to call.

Timer recording with video or DVD recorder

You can programme timer recordings on the TV set. Programming can be done with the EPG programme guide (not with DVB-T in UK), teletext or manually. Call the "Timer list" menu with the key for the "Recording wizard". Select whether you want to programme the recording via EPG, teletext or manually. You also have the option to programme recordings directly from the EPG programme guide or teletext. Note: Copy-protected programmes are not output to the Euro-AV sockets for legal reasons. When you have connected the Euro-AV socket to a recorder which has Digital Link Plus or a comparable system from a different manufacturer, the timer data of analogue terrestrial stations are transmitted from the TV to the recorder. The recording quality SQ or EQ is transmitted for DVD recorders, in additional to the station, date and time. The recording is then controlled by the recorder and the recorder tuner is used for reception of the station. The recording data are not saved in the timer list of the TV set. You will only ﬁ nd the timer data in the recorder.

If you want to record from digital stations, the TV tuner is used and the recorder is controlled by the TV set. Then the station is locked during the timer recording.

If you have connected a Loewe video recorder with Digital Link to the Euro-AV socket (without Digital Link Plus) and you are using the timer programming of the TV, the TV receiver is always used, for terrestrial stations as well. The TV controls the recording. You have to set the recorder to the AV input (signal source) to which the TV set is connected. Then the station on the TV set is locked during the timer recording. Digital Link must be switched on on the recorder. Read the operating instructions of your Loewe recorder for more information. Use only Euro-AV cables, which are completely wired, otherwise Digital Link/ Digital Link Plus will not work. Another advantage of Digital Link is that you can install the recorder in a concealed place (e.g. in a rack). You can control the recorder with the TV set. If you have a Loewe recorder with both systems, you can use all the advantages. The advantages of Digital Link Plus are used for the timer recording; the advantages of Digital Link for concealed installation of the recorder.

button and press the red coloured

33 -

Operating additional equipment

Assignment of digital audio inputs and outputs

Audio input "AUDIO DIGITAL IN"

The TV set has a coaxial digital audio input "AUDIO DIGITAL IN" and a coaxial digital audio output "AUDIO DIGITAL OUT". If you are using an external digital surround ampliﬁ er for sound reproduction, you have to feed digital audio signals to the TV, e.g. from the DVD player.

AV2

DVD

MAINS

OPT OUT

DIGITAL AUDIO OUT

PCM/MPEG2/AC3/DTS

MULTICHANNEL AUDIO OUT

LEFT CENTER

LEFT

REAR

FRONT

STEREO OUT VIDEO OUT

(CVBS) (Y/C)

RIGHT SUBW.

RIGHT

DIG OUT

REAR

S-VIDEO OUT

VIDEO OUT

FRONT

AUDIO

AUDIO DIGITAL

AUX-I/O

TO TV-I/O

IN OUT

Surround Amplifier

PREOUT

SL SR SUB

AUX1 IN

AUX OUT AUX 2

DIGITAL

OUT

Audio output "AUDIO DIGITAL OUT"

The digital audio signal is applied at the "AUDIO DIGITAL OUT" socket of the TV. For example, you can connect an external digital audio ampliﬁ er or the Loewe Auro system here.

An analogue audio signal from the TV set or another sound source which is received at one of the Euro-AV sockets of the TV set is converted into a digital signal (PCM) and output at the "AUDIO DIGITAL OUT" socket. Conversion from external analogue AV sources to PCM is not possible if the TV’s loudspeakers are used as a centre channel. In this case, connect your audio ampliﬁ er additionally to the TV (AUDIO OUT L/R) with a cinch cable and switch the audio ampliﬁ er to analogue audio input.

The digital TV sound or the digital sound of a connected auxiliary device is only audible via an external digital audio ampliﬁ er (e.g. Loewe Auro system).

Connect the output socket of the DVD player (DIG OUT) to the TV‘s "AUDIO DIGITAL IN" socket with a cinch cable. In the connection wizard, specify that audio transmission is to be digital. Specify that the digital sound is to be assigned for example to the Euro-AV socket 2 to feed the digital sound to the digital audio output of the TV set and via this to the external audio ampliﬁ er. Further information about this can be found on page 36.

- 34

Operating additional equipment

Connecting Loewe DVD Preceiver Auro 2216 PS and Tremo loudspeaker system

You can play audio signals from the TV or DVD player in cinema quality with these components. The Tremo system includes 5 speakers for the front, centre and surround reproduction in addition to the subwoofer illustrated below. The centre signal can be reproduced alternatively by the TV speakers. Connect the cubic socket on the DVD Preceiver to the "Master" cubic socket on the subwoofer. Use the cubic plug cable enclosed with the DVD Preceiver. Plug the white plug (without kink protection) into the cubic socket on the subwoofer. For TV as a centre loudspeaker, connect "AUDIO IN C" on the TV set to "PRE OUT C"on the DVD Preceiver using a cinch cable.

only required for TV as centre loud speaker.

Loewe LCD-TV

Auro

PREOUT

LC R LL

SL LFE SR R R

AUX1 IN

AV2-SCART

AUX OUT AUX 2

DIGITAL

CENTER

DIGITAL OUTCOMPONENT IN

OUT

12V / 15mA

EXT

L-LINK

Connect the digital audio output of the TV set "AUDIO DIGITAL OUT" to the "DIGITAL IN" input of the Preceiver using a cinch cable. Connect the TV socket "SERVICE" to the TV-L-Link socket on the Preceiver using the L-Link cable (provided with the Preceiver). Switch on the TV set and the Preceiver. Via the L-Link, the TV recognises whether the Preceiver is connected. Select the "Tremo" loudspeaker system in the DVD menu of the Preceiver, set the listener/speaker distances and adjust the speaker levels. Please consult the Preceiver manual. If you want to listen to the sound via the TV speakers temporarily, call the Sound menu, select "Sound via" and then "TV". If you want to listen to the sound via the Loewe Auro system, select "AURO" under "Sound via".

Digital audio

Tremo

Power OUT

Surr.

Front

Center to

Sat

System connector

Slave

Master

Bass Intensity

Min. Max.

Line IN

Right

Subw.

Left

Surr.

Front

Right

Center

Left

Component Video

EURO-AV cable

TO TV

COMPONENT

SERVICE

VIDEO OUT

OFF

Phase

0180

230V~50/60Hz

LFE

Six pin Cinch

L-Link cable

Cubic plug cable

FLE

35 -

Operating additional equipment

Connecting other audio ampliﬁ ers or active speakers

In the connection wizard, select "HiFi/AV ampliﬁ er" under "Equipment selection: audio component". The connection wizard allows conﬁ guration of different audio ampliﬁ ers (stereo ampliﬁ ers, surround ampliﬁ ers, analogue or digital) with different sound formats (Dolby Digital, dts, MPEG and Stereo/PCM). Refer to the operating instructions for the audio ampliﬁ er to be connected.

Select "Digital" under "Audio transmission" for digital audio ampliﬁ ers. Connect the digital audio output of the TV AUDIO DIGITAL OUT to the digital audio input of the digital ampliﬁ er.

Assign the digital audio input to the socket through which the corresponding picture is transmitted (e.g. AV2 if a DVD player is connected there). Then the digital sound is passed to the digital audio output of the TV set and fed to the external audio ampliﬁ er via this.

Specify which sound formats can be decoded with your digital ampliﬁ er (Dolby Digital, MPEG, dts).

Specify under "Type of ampliﬁ er" whether the digital ampliﬁ er is a stereo or surround ampliﬁ er.

If it is a surround ampliﬁ er, specify whether or not the TV loudspeakers are to be used as centre loudspeakers. Connect the centre output of the ampliﬁ er to the centre output of the TV using a cinch cable, if necessary. Note: do not use the centre loudspeaker connection on the ampliﬁ er; instead use the pre-ampliﬁ er centre output.

Select "Analogue" for "Sound transmission" for analogue audio ampliﬁ ers. The sound for the analogue ampliﬁ er is transmitted via the AUDIO OUT L/R connections of the TV to the audio ampliﬁ er. Connect the ampliﬁ er with two cinch cables. Specify under "Type of ampliﬁ er" whether the analogue ampliﬁ er is a stereo or surround ampliﬁ er. If it is a surround ampliﬁ er, also specify whether or not the TV speakers are to be used as centre loudspeakers. Connect the centre output of the ampliﬁ er to the centre output of the TV using a cinch cable, if necessary. Note: do not use the centre loudspeaker connection on the ampliﬁ er; instead use the pre-ampliﬁ er centre output.

AUDIO OUT

AUDIO IN

L R

PREOUT

AUX OUT AUX 2

AUX1 IN

DIGITAL

OUT

SL SR SUB

- 36

SL SR SUB

If you want to listen to the sound via the TV loudspeakers temporarily, call the Sound menu using the

button, select "Sound via" and then "TV".

When connecting active speakers, select "Active speakers" in the connection

AUDIO DIGITAL

AUDIO IN

OUT

wizard under "Audio equipment selection". The sound for the active speakers is transmitted via the AUDIO OUT L/R connections to the active speakers. Make connections to the active speakers using the cinch cables. Make the audio settings on the TV set when active speakers are connected. When using an external audio ampliﬁ er, make the audio settings on the audio ampliﬁ er.

PREOUT

AUX OUT AUX 2

AUX1 IN

DIGITAL

OUT

Operating additional equipment

HDMI (DVI) connection

The HDMI connection (High Deﬁ nition Multimedia Interface) allows digital picture and sound transmission via a connecting cable, e.g. from Loewe DVD Recorder Centros 2102/2172 HD.

The digital picture and sound data are transmitted without data compression and therefore lose none of their quality. In the equipment connected, no analogue/digital conversion is necessary, which might also have lead to losses in quality. DVI signals can be also be reproduced by the HDMI connection using a DVI/HDMI adapter cable. This is possible because HDMI is based on DVI and is downwardly compatible. That means that the digital video signals are transmitted via HDMI - no audio signals are transmitted, though. In addition, both use the same copy protection method HDCP.

Connect the set with an HDMI connection using an HDMI cable (type A, 19-pin) to the HDMI socket of the TV set. Log in the HDMI connection in the connection wizard (TV menu - Connections - New devices/modiﬁ cations).

Select the HDMI connection in the AV selection.

Call AV selection

AV selection HDMI/DVI

VGA

Select HDMI/DVI socket and use ...

to call.

Start playback on the device connected with HDMI connection. The set automatically recognises and sets the best possible format for the video. If transmission occurs via a DVI/HDMI adapter cable, then you can feed in the appropriate analogue audio via the audio input sockets AUDIO IN L/R on the TV set. The sound is reproduced via the TV speakers. If you have connected a digital external audio ampliﬁ er, you can select the digital audio signal in the connection wizard (TV menu - Connections - New devices/modiﬁ cations) and assign it to the HDMI/DVI socket. You can make the other settings for the audio ampliﬁ er as described for digital ampliﬁ ers on page 36. The digital audio signal of the DVI audio source is fed in at the AUDIO DIGITAL IN socket on the TV. Feed the digital audio signal from the TV AUDIO DIGITAL OUT to the external ampliﬁ er.

Set geometry: as described for the VGA/XGA connection.

COMP. IN

VIDEO

VCR

DVD

AVS

VGA/XGA connection

You can connect a PC or a Set Top Box (STB) and therefore use the TV screen as an output device. Connect the PC/STB to the VGA/XGA socket on the TV using a

VGA cable. When connecting to a PC, ﬁ rst set one of the following screen resolutions on your PC. 800x600 60Hz (SVGA) 1024x768 60Hz (XGA). When a Set Top Box is connected, set the following screen resolutions according to the options of the Set Top Box: 720x576i (PAL), 720x480i (NTSC), 720x480p (60 Hz) 720x480i, 720x 576i (SDTV – standard modi for STB) 720x576p (50 Hz) 1280x720p, 1920x1080i (HDTV modi)

Select the VGA/XGA connection in the AV selection.

Call AV selection

AV selection

VGA

AVS

Select VGA socket and use ...

to call.

Start the connected device.

Set geometry

Call the TV menu using the MENU button, select "Geometry" using  and set: If the picture is not positioned correctly, you can move the picture horizontally and vertically here so that it ﬁ lls the whole screen. You can also set the phase position so that the picture appears in the best possible quality.

Setting colour standard

Call the Picture menu using the button. Select "Colour standard" using  and make your selection. The colour standard for a connected PC is RGB. In Set Top Boxes, you usually set Ycc as a colour standard. Other formats such as Ypp or RGB can also be output. Please consult the operating instructions of the device connected. If the wrong standard is selected, you will recognise this by the wrong colours in the display.

HDMI/DVI

COMP. IN

VIDEO

VCR

37 -

Operating additional equipment

Sound from PC or Set Top Box

Feed the analogue audio signal from the PC or the STB to the sockets AUDIO IN L/R on the TV via a cinch cable. The sound is reproduced via the TV speakers. If you have connected a digital external audio ampliﬁ er, you can select the digital audio signal in the connection wizard (TV menu - Connections - New devices/modiﬁ cations) and assign it to the VGA/XGA socket. You can make the other settings for the audio ampliﬁ er as described for digital ampliﬁ ers on page

36. The digital audio signal of the Set Top Box is fed in at the AUDIO DIGITAL IN socket on the TV. Feed the digital audio signal from the TV AUDIO DIGITAL OUT to the ampliﬁ er.

Component video connection

If you have a DVD player/recorder with Component OUT

connections, you can connect it to the SD/HD-COMPONENT

IN sockets of the TV instead of to the Euro-AV sockets. The

connecting cable with three cinch plugs each transmits picture information. The playback is of a better quality than via the Euro-AV socket. You need another cinch cable for the analogue sound transmission. Connect the analogue audio outputs of the DVD player to the AUDIO IN L/R sockets on the TV set. The sound is reproduced via the TV speakers. If you want to use the digital sound of the DVD player with a digital audio ampliﬁ er connected to the TV, make a connection between AUDIO DIG OUT of the DVD player and AUDIO DIGITAL IN of the TV set. Log in the component/device in the connection wizard: Assign the AUDIO DIG IN input here to the COMP. IN socket, provided a digital audio ampliﬁ er is also connected. You can make the other settings for the audio ampliﬁ er as described for digital ampliﬁ ers on page 36. Set the signal at the component input in the connection wizard: Set to "Automatic" ﬁ rst. If the signal is not reproduced when playback is started, consult the operating instructions of the DVD device connected to ﬁ nd out what screen resolution is possible (SDTV, HDTV or ProScan).

Select the component connection in the AV selection.

Call AV selection

AV selection

MI/DVI

COMP. IN

Select COMP. IN sockets and use ...

VIDEO

VCR

DVD

AVS

VGA

HDMI/D

- 38

to call.

Start playback on the connected device.

Set geometry and colour standard: as described for the VGA/XGA connection.

Operating additional equipment

Operating other Loewe devices with the RC3 remote control

Using this remote control, you can operate additional devices from Loewe.

DVD STB

VCR

Use the rotary switch to select VCR, TV or a Set Top Box. The following are preset at the factory: Loewe VCRs, Loewe TV sets and for STBs (Set Top Box) in Germany, the common d-box.

Use the driver buttons in the TV and STB position for VCR, DVD or Digital Recorder

You can switch over the six drive buttons (

, , , , , ), both for the TV and for the STB, to control a VCR or DVD player/recorder (the control of the integrated "Digital Recorder Plus" is preset at the factory):

DVD STB

VCR

First set the switch to the main function TV or STB.

Then press the END and EPG buttons simultaneously for at least 5 seconds. The upper left indicator on the remote control

wxyz

tuv

EPG

will blink twice. Enter the the numbers 988 in sequence. The indicator will

again blink two times.

Now set the switch to the desired function for the drive buttons:

END

DVD STB

VCR

to DVD, VCR or to TV, if the digital recorder is to be operated. Press the # PIP button to complete the setting. The indicator

PIP

will blink two times.

Setting the remote control to operate devices from other manufacturers

You can switch over the remote control for other VCRs, DVD players and Set Top Boxes if the infrared code for the device type is listed in the code list or if it is included in the code memory of the RC3.

Even if the manufacturer of the device is listed in the code list, it may not

be possible to operate that device using the Loewe remote control.

Setting the remote control using code entry

Search for the code number for your device in the code list (see as of pages 48-52). The list is arranged according to device type – DVD, VCR, STB – and alphabetically according to manufacturer. Next to the manufacturer’s name, you will ﬁ nd one or more code numbers.

DVD STB

VCR

END

wxyz

Use the rotary switch if you want to switch over a VCR, DVD device or a Set Top Box.

Press the END and EPG buttons simultaneously for at least

EPG

5 seconds. The upper left indicator on the remote control will

blink twice.

jkl

Enter the four numbers in sequence that you found in the code

def

list (e.g. 0539 for Loewe DVD player).

After each number you enter, the indicator will blink once, after the last number it will blink twice. If the number was incorrect, the indicator will remain lit longer. The code number was not accepted. If the code was accepted with two blinks, you can test the functions of the device you just programmed.

If the device cannot be operated or can only be operated poorly, repeat the code entry with the next code from the list. If there are no other codes speciﬁ ed for this manufacturer, try it using the code suggestions from the remote control.

Setting the remote control using the suggestions from the remote control

Switch the device on that you want to switch over to the remote control. Standby mode is not enough.

DVD STB

VCR

END

wxyz

Point the remote control toward the device you want to switch over to the remote control. Observe that device.

Use the rotary switch if you want to switch over a VCR, DVD device or a Set Top Box.

Press the END and EPG buttons simultaneously for at least 5 seconds. The upper left indicator on the remote control will

EPG

blink twice.

Enter the the numbers 991 in sequence. The indicator will blink once after each number entered.

PIP

Press the # PIP button to select the ﬁ rst code.

Now press the button  (Play) or On/Off on the remote control. Wait a moment for the device to react. If the device does not

PIP

react, then that was not the right code. Press the # PIP button again to call the next code.

Press the button  (Play) or On/Off again.

EPG

If the device reacts, press the EPG button to adopt the code.

39 -

Operating additional equipment

Using the RC3 remote control to operate a DVD recorders or DVD player

DVD STB

VCR

In the DVD mode, it is possible to operate the Loewe DVD recorders Centros 1102, 1172, 2102HD, 2172HD, and the DVD players Xemix 6122DO, 8122DA and 6222PS.

Functions for the Loewe DVD recorders (Centros 1102, 1172, 2102, 2172)

VCR, DVD or Set Top Box

timer recording list menu on

User interface of loaded DVD on

/in menu: switch between

Status display (TV, DVD-RW)

cofirm the menu selection

Insert a new chapter marker

Press short during playback:

Press short during pause:

Press long during playback:

Set the rotary switch to "DVD". The infrared code and the functions are preset at the factory

for the Loewe DVD recorder Centros 21x2 HD.

DVD STB

Change-over switch

for operation of TV,

Sound off/on

Set marker / in menu:

highlights title/chapter

Select camera position

Timer recording menu /

Call AV selection

(AV1-AV4,DV,TV)

Main menu on

original and playlist

/in menu:

in menu: select / adjust

ShowView menu on

Start of current chapter

/previous chapter

slow motion back

search back

Record

Playback

Pause /single frame

VCR

-Set

-List

REC-MENU

abc def

ghi jkl

pqrs

tuv

DVD- AV

EPG

DISC-M

P+

V– V+

P–

C-SET

TITLE

RADIO

mno

wxyz

PIP

CARD

Switch DVD player on/off – in standby

Marker search menu on Repeat

Zoom

in menu: enter digits / in stop mode (menu off): select programme (TV)

Picture in picture (PIP) on/off

Close menu

Info / menu bar on/off

Next chapter / in stop mode (menu off): next programme

V–/V+ volume quieter/loude Start of current

chapter / previous chapter /in stop mode (menu off): previous programme

Audio/Foto Card Reader operation on/off

Enter a new title thumbnail / switch between photo and MP3/WMA operation

Press short during playback: next chapter Press short during pause: slow motion forward Press long during playback: search forward

Stop

Using the RC3 remote control to operate a VCR

DVD STB

VCR

In VCR mode, the following VCRs can be operated: ViewVision 8106H, 8136H, 8176H, 6306H, 6336H, 6376H, 6396H, 4306H, 4376H, 2102M, 2302M, 4206, 4236, 4276. For other Loewe equipment than that listed, please use the original remote control.

Functions for Loewe VCR (VV 8106, 8136, 8176)

for operating of TV, VCR,

ShowView timer Menu

at stop: Program up/down

on playback: manual tracking

in the menu: Select position

/frame-by-frame advance

Set the rotary switch to "VCR". The infrared code and the functions for a Loewe VCR are

preset at the factory.

Change-over switch

DVD or Set Top Box

Sound off/on (mute)

Display/close Timer list

Display/close

Switch to Long Play

/Standard Play

Call AV selection (TV)

VCR menu on

/in menu: back

P+/P– Select station

up/down

Reverse play

/in menu: select/set

V–/V+ volume

quieter/louder

Rewind

/search backwards

Start recording

Pause (still frame)

DVD STB

VCR

-List

-Set

REC-MENU

abc def

ghi jkl

pqrs

tuv

DVD-AV

EPG

DISC-M

P+

V- V+

P-

C-SET

TITLE

RADIO

mno

wxyz

PIP

CARD

Switch recorder on/off – in standby

Select picture and sound sou Select video and audio input

Set time display to 0:00:00

Select station directly /in menu: enter digits

Set picture format (TV)

Status display on/off in the menu: Close menu

Status display on/off

on playback: Slow motion forward /in the menu: select/set or to the next menu

Call up station list /in menu: call up/confirm

Fast forward /search forwards

Start playback

Stop tape

- 40

Operating additional equipment

Rotating the TV set for Spheros R 32/37

Spheros R 32/37 have a connection for a rotating stand control. If the TV set is mounted on a motor unit, you can use the remote control to adjust it to your seating location accordingly. You can ﬁ x the position of the TV set when the set is switched off.

Note: Make sure there are no objects in the TV’s area of rotation that might obstruct the rotation or be knocked down due to the rotating motion.

Setting the position of the TV set when switched off

You can set the position the TV set is to assume once it is switched off (switchoff position must be activated for this):

Rotate the TV set when no menu or PIP is being displayed.

Call up the TV menu

TV menu Picture

Picture adjustment ...

Sound

Recording

Connections

INFO

Settings

Select "Settings"

TV menu Settings

ctions

Channels ...


Sound

INFO

Recording

under that, select "Miscellaneous"

TV menu

Settings

Miscellaneous

guage

On-screen displays ...

Channels

Parental lock

INFO

Timer functions La

under that, select "Rotate TV"

TV menu

Settings Miscellaneous

Rotate TV

Activate switch-off position ...

On-screen displays

INFO

Time and date

under that, select "Activate switch-off position"

TV menu

Settings Miscellaneous Rotate TV

Activate switch-off position

no ...

Set switch-off position

INFO

under that, select "yes"

Conn

TV menu

Settings Miscellaneous Rotate TV Activate switch-off position

yes

END

If the TV set is switched off using the blue on/off button on the remote control, the set will rotate to the position deﬁ ned.

go up and select "Set switch-off position"

TV menu

Settings

Miscellaneous

Rotate TV

Set switch-off position

Activate switch-off p

use OK to go down and use the  arrow buttons to set the desired switch-off position. The TV set rotates in the process.

TV menu

Settings

Miscellaneous

Rotate TV Set switch-off position

Adopt

use OK to save the position set.

Close the menu

END

INFO

END

INFO

END

INFO

When it is switched back on, it returns to the position last set manually.

END

41 -

What to do, if ...

Problem Possible cause Remedy

The "Recording" menu point is not displayed in the TV menu.

"Connections" cannot be called in the TV menu (deactivated)

The control of the Loewe video recorder and the timer do not work or do not work properly.

General problems with connecting external equipment via an AV input.

A decoder connection does not function or is faulty. a) The signal is not decoded because the wrong

No video or DVD recorder logged in. Log in the video or DVD recorder in the connection

A time recording is in progress. Wait until the timer recording has ended or delete the

a) The Digital Link function is not activated or not

possible in the recorder. b) Euro-AV cable is not connected. c) Recorder is not logged in.

a) The device is not logged in to the connection

wizard or is connected differently than is shown

in the connection diagram.

b) The AV norm is set incorrectly. c) The AV signal is set incorrectly.

decoder stations are selected in the connection

wizard.

b) The sound is missing in decoder mode because

the wrong decoder sound is assigned in the

connection wizard.

wizard and connect the device.

timer.

a) Activate Digital Link in the recorder (see operating

instructions of the video recorder). b) Connect the Euro-AV cable. c) Log in recorder.

a) In the connection wizard (TV menu –

Connections – New devices/modiﬁ cations),

compare the connection diagram with the actual

installation and connect as shown, if necessary. b) Set the norm correctly. c) Set the AV signal correctly. If "Automatic" is set for AV norm or AV signal, this

can lead to errors for signals which do not conform to the norm. Then the norm and the signal are to be set according to the speciﬁ cations in the operating instructions of the external device.

a) Follow the instructions in the connection wizard

again (TV menu – Connections – New devices/

modiﬁ cations) and select the corresponding

decoder station. b) Follow the instructions in the connection wizard

again and select the right audio source (decoder,

TV or autom.), see instructions of the decoder.

All menus appear in the wrong language. Menu language has been set incorrectly. Set your menu language:

Press the INFO button in TV mode (index). Select the ﬁ rst index item and call it by using OK. Then select the language and conﬁ rm with OK.

- 42

What to do, if ...

Problem Possible cause Remedy

Digital Link Plus does not function. a) Euro-AV cable is not fully wired (pin 10 not

wired).

b) Some recorders can only adopt stations during

the initial installation of the TV set.

c) All or some of the terrestrial and cable stations

are stored on station storage locations ≥ 99.

Various characters are displayed incorrectly in the teletext.

No sound via external digital audio ampliﬁ er. a) The external digital audio ampliﬁ er does not

Device on mounted motor unit does not rotate (only Spheros R 32/37).

The wrong character set is set in the teletext menu. Set the right character set: Teletext menu - Settings -

support the selected sound format (Dolby Digital, dts, MPEG).

b) TV set and external digital audio ampliﬁ er are

not connected.

Motor unit and connection for rotating stand control are not connected to each other.

a) Replace the Euro-AV cable.

b) Restore the recorder to the as-delivered state (see

recorder’s operating instructions). c) Rearrange the terrestrial and cable stations so

that they fall between 1 and 99.

Character set: standard or the appropriate character set.

a) Set PCM stereo on the DVD player in the sound

selection. For DVB stations, switch language/

sound selection (green coloured key) to Stereo on

the TV set in the status display (END). b) Connect Digital-Out from the TV set to a Digital-In

of the external digital audio ampliﬁ er and select

the appropriate input to this.

Use related cable to connect socket of motor unit to interface of rotating stand control (see assembly instructions for motor unit).

43 -

Technical data

General data

Type Spheros R 26 Spheros R 32 Spheros R 37

Versions DVB-T CI Versions DVB-T/C CI Versions DVB-T/C CI Versions DR+ DVB-T/C CI

Set dimensions without stand (ca. cm WxHxD) Dimensions with stand (ca. cm WxHxD)

Set weight without stand (ca. kg) Set weight with stand (ca. kg)

Display Picture diagonal (cm)/picture format Resolution Contrast ratio

Angle of viewing horizontally/vertically 170° 170° 170° Power consumption (IEC 62087)

in operation (watt) in standby (watt)

Ambient temperature (Celsius) 5º – 35º Relative humidity (not condensing) 20 – 80% Barometric pressure 800 – 1114 hPa (0 – 2000 m over NN)

65435x27

65435x87

68,4x50,7x10,8

68,4x56,1x35,0 18,5

20,5 HD-LCD technology

66/16:9 1366x768 800:1

70 < 3

65436x27 65436x84

65436x47

84,5x58,5x9,0 84,5x64,0x40,0

34,5 36,5

HD-LCD technology 80/16:9 1366x768 800:1

85/100 < 3

65437x27 65437x84

65437x47

99,0x67,5x9,0 99,0x71,6x40,0

37,0 39,0

HD-LCD technology 94/16:9 1366x768 800:1

100/115 < 3

The code number 3001 cancels out a

secret code and with it the child lock.

- 44

✄

Please keep in a

safe place.

Technical data

Electrical data

Chassis name L 2650 Power supply 220 V -240V/50- 60 Hz Tuner VHF/UHF/ cable Hyperband 8 MHz 41 MHz to 860 MHz Station storage locations 430 / for DVB 1680 TV standards B/G, I, L, D/K, M, N Colour standard SECAM, PAL, NTSC,

NTSC-V, PAL-V (60Hz)

Sound standard Mono/Stereo/Dual-channel

Nicam B/G, I, L,

Virtual Dolby Rated audio power 2 x 20 watt Analogue Teletext TOP/FLOF Level 2.5 Page Memory 3000 Digital Teletext (in UK only) MHEG-5

Connections

Jack 3.5mm Headphones 32- 2000 ohm Mini-DIN (AVS) Video IN Y/C (S-VHS/Hi 8) Cinch (yellow) Video IN CVBS (VHS/8 mm) Cinch (white/red) Audio IN L/R IEC socket 75 Ohm/5 V/80 mA Antenna/cable/analogue PIP F socket 75 Ohm 13/18 V/350 mA

ANT-SAT

EURO-AV 1 Video IN Y/C (S-VHS/Hi 8)

Video OUT CVBS (VHS/8 mm)

Audio IN L/R Audio OUT L/R EURO-AV 2 Video IN Y/C (S-VHS/Hi 8)

Video OUT CVBS

Y/C, (only with SVHS Link Plus) Audio IN L/R Audio OUT L/R Cinch Audio IN max. 2Vrms Centre 2 x Cinch Audio IN L/R 2 x Cinch Audio OUT (level adjustable in active loud speakers) L/R Cinch COMPONENT IN: Cb/Pb signal Cinch COMPONENT IN: Cr/Pr signal Cinch COMPONENT IN: Y signal Cinch Digital Audio IN (SPDIF) Digital audio Cinch Digital Audio OUT (SPDIF) Digital audio HDMI/DVI Digital Video/Audio IN type A 19pin Digital video and audio VGA/XGA VGA/XGA IN PC/STB video signal Mini-DIN Service/L-Link

/DVB-T/C

CVBS (VHS/8 mm)

Y/C (S-VHS/Hi 8)

CVBS (VHS/8 mm)

RGB, YUV

Dolby and the double ´D´ symbol are trademarks of Dolby Laboratories

Analogue PIP tuner can be retroﬁ tted.

Digital satellite tuner can be retroﬁ tted,

Twin sat tuner can be retroﬁ tted for sets with digital recorder.

Printed in Germany

TB/05/10/2.1

Subject to modiﬁ cations!

45 -

Accessories

Wall holders and stands

Refer to the notes on the installations options on page 8.

PIP tuner

The PIP tuner enables picture in picture displays (PIP) for analogue terrestrial and cable reception. You can retroﬁ t either this PIP tuner or a digital satellite tuner. The PIP function is possible for both retroﬁ t models. Retroﬁ t not possible for Spheros R26 and UK device versions. Loewe order no. 89442.080

Digital Satellite Tuner

You can have your TV set retroﬁ tted with the digital satellite tuner. You receive DVB-S stations with this tuner. The digital satellite tuner is completely integrated in the TV set (physically and logically) and is operated by the remote control/menu control of the TV. When you retroﬁ t your TV set with the digital satellite tuner, your TV set automatically has the PIP function. You can retroﬁ t either this digital satellite tuner or a PIP tuner. Retroﬁ t not possible for UK device versions. Loewe order no. 89361.055

DVB-S Twin sat tuner

(only for sets with a Digital Recorder)

If your TV set is equipped with the Digital Recorder+, you can have it retroﬁ tted with an integrated DVB-S twin sat tuner. The integrated PIP DVB-T/C tuner is exchanged for the DVB-S twin sat tuner (not for Spheros R 26). Loewe order no. 89443.080

Loewe Video Recorders

Loewe video recorders are specially adapted to Loewe TV sets in design, user guidance and technical properties. They greatly simplify daily handling of the equipment.

Loewe DVD players and recorders

The DVD players and recorders from Loewe are characterised by form and colour, which match Loewe TV sets, adapted user guidance and technology. A combination of the two devices forms a system which offers many advantages.

Loewe audio system Auro and the active speaker system Tremo

The interplay of a Loewe TV with a Loewe audio system and a Loewe speaker system creates an excellently coordinated home cinema system. Advantages are high operating comfort, attractive design and adapted technology.

- 46

Subject to delivery options.

Service Addresses

Australia

International Dynamics Australasia Pty Ltd. 129 Palmer Street AUS - Richmond, Victoria 3121 Tel. 00 61 - 3-94 29 08 22 Fax 00 61 - 3- 94 29 08 33 Email ekyriakides@internationaldynamics.com.au

BeNeLux

Loewe Opta Benelux NV/SA Uilenbaan 84 B–2160 Antwerpen Tel. 00 32 - 3- 2 70 99 30 Fax 00 32 - 3- 2 71 01 08 Email ccc@loewe.be

Denmark

Kjaerulff 1 A/S C.F.Tietgens Boulevard 19 DK–5220 Odense SØ Tel. 00 45 - 66 13 54 80 Fax 00 45 - 66 13 54 10 Email mail@kjaerulff1.com

Germany

Loewe Opta GmbH, Customer Care Center Industriestraße 11 D–96317 Kronach Tel. 0049 1801–22256393 Fax 0049 9261–99500 Email ccc@loewe.de

France

Loewe France S.A. 13 rue du Dépôt, Parc del l‘Europe, BP 10010 F - 67014 Strasbourg Cédex Tel. 00 33 - 3- 88 79 72 50 Fax 00 33 - 3- 88 79 72 59 Email loewe.france@wanadoo.fr

Greece

SOUND HELLAS S.A. Kleanthous Str. 10 GR–54642 Thessaloniki Tel. 00 30 - 2310 - 856 100 Fax 00 30 - 2310 - 856 300 Email sound@spark.net.gr

Great Britain

LinnSight Ltd. PO Box 8465 UK – KA 7 2YF Prestwick Tel. 00 44 - 12 92 - 47 15 57 Fax 00 44 - 12 92 - 47 15 54 Email helpline@linnsight.co.uk

CIS

Service Center Loewe Petrovsky per., d. 5, str. 3 of. 17 RUS–107031 Moscow Tel. 0 95 - 928 33 58 Fax 0 95 - 928 58 79 Email loewerus@online.ru Israel PL Trading (pz 2004) Ltd. 27, Aliat Hanoar St.

ISR - Givataiim 53401 Tel. 00 972 - 3 - 57 27 155 Fax 00 972 - 3 - 57 27 150 Email zeev@loewe.co.il

Italy

Loewe Italiana SRL Lago del Perlar, 12 I–37135 Verona Tel. 00 39 - 045 82 51 611 Fax 00 39 - 045 82 51 622 Email Edoardo.Bricchi@loewe.it

Malta

Mirage Holdings Ltd Flamingo Complex, Cannon Road M–Qormi Tel. 0 03 56 22 - 79 40 00 Fax 0 03 56 21 - 44 59 83 Email s.martinelli@ﬂ amingo.com.mt

Morokko

SOMARA S.A. 377, Rue Mustapha El Maani MA–20000 Casablanca Tel. 00 21 22 - 2 22 03 08 Fax 00 21 22 - 2 26 00 06 Email somara@wanadoopro.ma

Norway

CableCom AS Østre Kullerød 5 N–3214 Sandefjord Tel. 00 47 - 33 48 33 48 Fax 00 47 - 33 44 60 44 Email roy@cablecom.no

Austria

Loewe Austria GmbH Parkring 10 A–1010 Wien Tel 00 43 1 / 51 633 - 31 34 Fax 00 43 1 / 51 633 - 30 32

Poland

DSV TRADING SA Plac Kaszubski 8 PL–81-350 Gdynia Tel. 00 48 58 - 6 61 28 00 Fax 00 48 58 - 6 61 44 70 Email market@dsv.com.pl

Portugal

Vídeoacustica Comercio e Representacoes de Equipamentos Electronicos S.A. Estrada Circunvalacao, Quinta do Paizinho, Arm. 5 P–2795-632 Carnaxide Tel. 0 03 51 - 2 14 24 17 70 Fax 0 03 51 - 2 14 18 80 93 Email ofﬁ ce@videoacustica.pt

Sweden

Kjaerulff 1 AB Ridbanegatan 4, Box 9076 S–200 39 Malmö Tel. 00 46 - 4 06 79 74 00

Fax 00 46 - 4 06 79 74 01

Switzerland

Telion AG Rütistrasse 26 CH-8952 Schlieren Tel. 00 41 - 44 732 15 11 Fax 00 41 - 44 730 15 02 Email infoCE@telion.ch

Slowenia

Jadran Trgovsko Podjetje Partizanska cesta 69 SL–6210 Sezana Tel. 0 03 86 - 57 31 04 40 Fax 0 03 86 - 57 31 04 42 Email milos.zvanut@jadran.si

Spain/Canary Islands

Gaplasa S.A. Conde de Torroja, 25 E–28022 Madrid Tel. 0 03 49 - 17 48 29 60 Fax 0 03 49 - 13 29 16 75 Email loewe@maygap.com

South Africa

THE SOUNDLAB PTY LTD P.O. Box 31952, Kylami 1684 Republic of South Africa Tel. 00 27 - 1 14 66 47 00 Fax 00 27 - 1 14 66 42 85 Email loewe@mad.co.za

Czech Republic

K+B EXPERT SPOL. S R.O. U Expertu 91 CZ - 25069 Klicany u Prahy Tel: 0 04 20 - 2 72 12 21 11 (222) Fax: 0 04 20 - 2 72 12 21 99 (239) Email loewe@kbexpert.cz

Turkey

Enkay Elektronik Servis Müdürlügü Alemdag Cad: Site Yolu No.: 10 Ümraniye/ Istanbul Tel. 00 90 - 216 634 44 44 Fax 00 90 - 216 643 39 88 Email mhatipog@enkaygroup.com

Hungary

Basys Magyarorszagi KFT Epitok utja 2–4 H–2040 Budaörs Tel. 00 36 - 23 41 56 37 (121) Fax 00 36 - 23 41 51 82 Email basys@mail.nasys.hu

Cyprus

HADJIKYRIAKOS & SONS LTD. Prodromou 121, P.O Box 21587 CY–1511 Nicosia, Cyprus Tel. 0 03 57 - 22 87 21 11 Fax 0 03 57 - 22 66 33 91 Email savvas@hadjikyriakos.com.cy

47 -

Codelist RC3 / Lista de códigos RC3

Loewe

DVD-Player 0539 DVD-Recorder Centros 11x2 0741 DVD-Recorder Centros 21x2 1463 STB 1127 VCR 0866

DVD

3DLAB 0539 A-Trend 0714 Acoustic Solutions 0730 AEG 0788 0770 Aiwa 0641 0695 Akai 0790 0788 0690 0716 0713 0705 AKI 0718 Akira 0699 Alba 0717 0699 0713 0723 0695 All-Tel 0790 Amitech 0770 Amstrad 0713 Apex Digital 0672 Audiosonic 0690 AWA 0730 Black Diamond 0713 Blaupunkt 0717 Blue Sky 0699 0695 0713 0672 0651 Boman 0783 Brain Wave 0770 Brandt 0651 0551 Bush 0699 0690 0689 0717 0713 0818 0695 0831 0723 C-Tech 0768 Cambridge Audio 0696 Cambridge Soundworks 0696 CAT 0699 Celestial 0672 Centrex 0672 1004 Centrum 0713 cineULTRA 0699 Classic 0730 Clatronic 0788 Clayton 0713 Coby 0730 Conia 0672 Crown 0770 0651 0690 Cybercom 0831 CyberHome 0714 0816 Cytron 0716 0651 0705 Daewoo 0770 0705 0714 Daewoo International 0699 Dansai 0770 0783 Dantax 0723

- 48

DEC 0699 0818 Decca 0770 Denon 0490 0634 Denver 0699 0788 Denzel 0665 Diamond 0651 0768 0723 Digihome 0713 digiRED 0717 Digitrex 0672 DiK 0831 Dinamic 0788 DiViDo 0705 DK digital 0831 DMTECH 0783 0790 Dragon 0831 Dual 0665 0651 0713 0730 0783 0790 0831 E-Boda 0723 Eclipse 0723 Electrohome 0770 Elin 0770 Elta 0690 0770 0788 0790 Emerson 0591 0705 Enzer 0665 Ferguson 0651 Finlux 0741 0770 0783 Firstline 0651 Funai 0695 GE 0717 Global Solutions 0768 Global Sphere 0768 Go Video 0783 GoldStar 0591 0741 Goodmans 0651 1004 0790 0690 0783 0723 0818 Graetz 0665 Grandin 0716 Grundig 0539 0695 0651 0775 0705 0790 0713 0670 0723 Grunkel 0770 H&B 0818 0713 Haaz 0768 Hanseatic 0741 HCM 0788 HDT 0705 HE 0730 Henß 0713 Hitachi 0664 0665 0573 Hiteker 0672 Home Electronics 0730 Hyundai 0783 Ingelen 0788 ISP 0695 Jeken 0699 JMB 0695 JVC 0623 0539 0503 1901 1940 Karcher 0783

Kendo 0699 Kenwood 0534 0490 0737 Kiiro 0718 0770 Kingavon 0818 Kiss 0665 Koda 0818 Koss 0651 Lawson 0705 0716 0768 Lecson 0696 Lenco 0699 0651 0770 0818 Lenoxx 0690 Lexia 0699 LG 0591 0741 1906 Lifetec 0651 Limit 0716 0768 Loewe 0539 1922 LogicLab 0768 Logix 0705 0783 Lumatron 0705 Luxman 0573 Luxor 1004 Magnavox 0503 0818 Magnex 0723 Manhattan 0705 Marantz 0539 Mark 0713 Matsui 0651 0695 MBO 0690 0730 MDS 0699 Medion 0651 0783 0716 0831 Memorex 0831 Metz 0571 0713 MiCO 0723 Microboss 0718 Micromaxx 0695 Micromedia 0503 0539 Micromega 0539 Microsoft 0522 Microstar 0831 Minax 0713 Minoka 0770 Mitsubishi 0713 Mizuda 0818 Monyka 0665 Mustek 0730 Mx Onda 0651 0723 NAD 0741 Naiko 0770 Neufunk 0665 Nordmende 0831 Omni 0690 0699 Onkyo 0627 0503 Optimus 0571 Orava 0818 Orion 0695 Oritron 0651 P&B 0818

Paciﬁ c 0768 0790 0713 0831 Palladium 0695 Palsonic 0689 0672 Panasonic 0490 1908 Panda 0783 Philips 0539 0646 0503 1914 Phonotrend 0699 Pioneer 0571 0631 1900 1902 Pointer 0770 Powerpoint 0718 Proline 0651 0672 0790 1004 Proscan 0522 Prosonic 0699 Provision 0699 Radionette 0741 Raite 0665 Rank Arena 0718 RCA 0522 0651 REC 0689 0490 Red Star 0770 0788 Reoc 0768 Revoy 0699 Roadstar 0699 0690 0689 0713 0818 Rotel 0623 Rowa 1004 Saba 0651 Sabaki 0768 Salora 0741 Samsung 0573 0490 Sansui 0695 0716 0768 0723 0770 Sanyo 0670 0695 0790 Scan 0705 ScanMagic 0730 Schaub Lorenz 0788 0770 Schneider 0651 0783 0705 0790 0788 Scientiﬁ c Labs 0768 Scott 0718 0651 0672 SEG 0665 0713 0768 Shanghai 0672 Sharp 0630 0695 Sherwood 0717 0741 0633 Shinco 0717 Silva 0788 SilvaSchneider 0831 Singer 0690 0716 0723 Skymaster 0730 0768 Slim Art 0770 SM Electronic 0730 0768 0690 Smart 0718 0705 0713 Sonashi 0716 Sony 0533 0573 1903 1904 Soundmaster 0768 Soundmax 0768 Soundwave 0783 Standard 0651 0768 Starmedia 0818 Sunwood 0788

Codelist RC3 / Lista de códigos RC3

Supervision 0730 0768 SVA 0672 Synn 0768 Tandberg 0713 Tatung 0770 Teac 0717 0741 0571 0768 0591 0790 Technics 0490 1908 Technika 0770 Techwood 0713 Tensai 0690 0651 Tevion 0651 0768 Theta Digital 0571 Thomson 0551 0522 Tokai 0665 0788 Tokiwa 0705 0716 Toshiba 0503 Umax 0690 United 0788 0730 0790 Universum 0741 0713 0591 Venturer 0790 Vieta 0705 Voxson 0730 0831 Walkvision 0717 Welkin 0831 Wesder 0699 Wharfedale 0696 0723 Windy Sam 0573 XBox 0522 XLogic 0770 0768 XMS 0788 0689 Yamada 1004 Yamaha 0490 0539 0646 Yamakawa 0665 0710 0765 Yelo 0718 Yukai 0730 Zenith 0503 0591 0741

VCR

Adyson 0072 Aiwa 0307 0000 0209 0348 0352 0037 0041 Akai 0106 0315 0041 0352 0240 Akashi 0072 Akiba 0072 Akura 0072 0041 Alba 0278 0072 0209 0352 0000 0315 0348 0081 Allorgan 0240 Allstar 0081 Amstrad 0000 0278 0072 Anitech 0072 Ansonic 0000 Aristona 0081 ASA 0037 0081 Asuka 0072 0037 0081 0000 0038

Audiosonic 0278 AVP 0352 0000 AWA 0037 0278 0642 0043 Baird 0106 0278 0104 0041 0000 Basic Line 0278 0209 0072 Bestar 0278 Black Diamond 0642 0278 Black Panther 0278 Blaupunkt 1562 0226 0081 Blue Sky 0037 0209 0348 0072 0352 0278 0000 Bondstec 0072 Brandt 0041 0320 Brandt Electronique 0041 Brinkmann 0209 0348 Bush 0072 0278 0315 0209 0352 0000 0348 0081 Carena 0209 0081 Carrefour 0045 Casio 0000 Cathay 0278 CGE 0041 0000 Cimline 0072 0209 Clatronic 0072 0000 Combitech 0352 Condor 0278 Crown 0278 0072 Cyrus 0081 Daewoo 0278 0642 0209 0348 0352 0045 Dansai 0072 0278 Daytron 0278 de Graaf 0042 0081 0104 0048 Decca 0000 0041 0081 0067 0348 0209 Deitron 0278 Denko 0072 Diamant 0037 Domland 0209 Dual 0041 0081 0278 0000 Dumont 0000 0081 0104 Elbe 0278 0038 Elcatech 0072 Elin 0240 Elsay 0072 Elta 0072 0278 Emerson 0072 0045 0000 ESC 0278 0240 Etzuko 0072 Fast 0897 Ferguson 0041 0320 0000 0278 Fidelity 0000 0072 0240 Finlandia 0104 0081 0042 0000 0048 0384 Finlux 0000 0081 0104 0042 Firstline 0072 0209 0348 0043 0037 0045 0042 0278

Fisher 0047 0104 0038 Flint 0209 Frontech 0072 Fujitsu 0000 Funai 0000 Galaxi 0000 Galaxis 0278 GE 0320 GEC 0081 General Technic 0348 Genexxa 0104 Goldhand 0072 GoldStar 0037 0000 Goodmans 0000 0072 0240 0278 0037 0081 0348 0209 0352 0642 Graetz 0041 0104 0240 Granada 0104 0048 0081 0240 0037 0226 0042 0000 Grandin 0072 0037 0000 0278 0209 Grundig 0081 0347 0226 0320 0348 0072 Haaz 0348 0209 Hanimex 0352 Hanseatic 0037 0209 0278 0081 0038 Harwood 0072 HCM 0072 Hinari 0072 0209 0352 0041 0278 0240 Hisawa 0209 0352 Hischito 0045 Hitachi 0042 0041 0000 0240 0081 0104 0384 Hornyphone 0081 Hypson 0072 0209 0278 0352 Imperial 0000 0240 Ingersoll 0209 0240 Inno Hit 0240 0278 0072 Interbuy 0037 0072 Interfunk 0081 0104 Internal 0278 International 0278 0037 Intervision 0000 0278 0037 0209 0348 Irradio 0072 0037 0081 ITT 0106 0041 0384 0104 0240 ITT Nokia 0048 ITV 0278 0037 JMB 0209 0352 Joyce 0000 JVC 0041 0067 0384 Kaisui 0072 Kambrook 0037 Karcher 0278 Kendo 0106 0209 0315 0348 0072 0037 Kenwood 0041 0038 KIC 0000 Kimari 0047

Kneissel 0352 0209 0348 0037 Kolster 0209 0348 Korpel 0072 Kuba 0047 Kuba Electronic 0047 Kuwa 0226 Kyoto 0072 Lenco 0278 Leyco 0072 LG 0037 0000 0278 Lifetec 0209 0348 Loewe 0081 1562 0226 0866 0037 Logik 0240 0072 0106 0209 Lumatron 0278 Luxor 0106 0043 0072 0104 0047 0048 Magnavox 0081 Manesth 0072 0045 0081 0209 Marantz 0081 0038 0209 Mark 0278 Matsui 0209 0348 0037 0240 0352 0000 Mediator 0081 Medion 0209 0348 0352 Melectronic 0000 0037 0038 Memorex 0104 0000 0037 0048 0047 Memphis 0072 Metz 1562 0347 0081 0226 0037 Micormay 0348 Micromaxx 0209 Migros 0000 Mitsubishi 0043 0067 0081 Multitec 0037 Multitech 0000 0072 0104 Murphy 0000 Myryad 0081 NAD 0104 National 1562 0226 NEC 0041 0038 0067 0104 0037 Neckermann 0041 0081 Nesco 0072 0000 0352 Neufunk 0209 Nikkai 0072 0278 Nokia 0104 0106 0315 0041 0278 0240 0048 0042 0081 Nordmende 0041 0384 0320 0067 NU-TEC 0209 0348 Oceanic 0000 0048 0106 0081 0104 0041 Okano 0315 0209 0348 0072 0278 Orbit 0072 Orion 0209 0352 0348 Orson 0000 Osaki 0000 0037 0072 Osume 0072 Otake 0209 Otto Versand 0081

49 -

Codelist RC3 / Lista de códigos RC3

Palladium 0072 0315 0037 0041 0209 0240 0348 0432 Palsonic 0072 0000 Panasonic 1562 0226 Pathe Cinema 0043 Pathe Marconi 0041 Perdio 0000 0209 Philco 0038 0072 Philips 0081 0384 Phoenix 0278 Phonola 0081 Pioneer 0067 0081 0042 Portland 0278 Prinz 0000 Proﬁ tronic 0081 0240 Proline 0000 0320 Prosco 0278 Prosonic 0209 0278 0000 Protech 0081 Provision 0278 Pye 0081 Quasar 0278 Quelle 0081 Radialva 0037 0072 0081 0048 Radiola 0081 Rank 0041 Reoc 0209 0348 0278 Rex 0041 0384 RFT 0072 Roadstar 0240 0072 0037 0278 Royal 0072 Saba 0041 0320 0384 0278 Saisho 0209 0348 Salora 0043 0106 0104 Samsung 0240 0432 Sansui 0041 0067 0106 0072 0348 Sanyo 0104 0047 0048 0067 Saville 0352 0278 0240 SBR 0081 Scan Sonic 0240 Schaub Lorenz 0041 0104 0000 0106 0315 Schneider 0072 0000 0037 0081 0278 0240 0042 0897 Seaway 0278 SEG 0072 0240 0278 0642 0081 SEI 0081 Sei-Sinudyne 0081 Seleco 0041 0384 0037 Sentra 0072 Setron 0072 Sharp 0048 0037 0569 Shintom 0072 0104 Shivaki 0037 Siemens 0037 0104 0081 0320 0347 Siera 0081 Silva 0037

- 50

Silver 0278 Singer 0045 Sinudyne 0081 0209 Smaragd 0348 Sonitron 0047 Sonneclair 0072 Sonoko 0278 Sonolor 0048 Sontec 0037 0278 Sony 0032 0106 Soundwave 0037 0209 0348 Ssangyong 0072 Standard 0278 Starlite 0037 0104 Stern 0278 Sunkai 0209 0348 0278 Sunstar 0000 Suntronic 0000 Sunwood 0072 Supra 0037 0240 Symphonic 0000 0072 T+A 0226 Taisho 0209 Tandberg 0278 Tashiko 0000 0048 0240 0081 0037 Tatung 0000 0041 0081 0048 0043 0209 0348 0352 Teac 0072 0041 0000 0278 0642 0037 0081 0307 TEC 0278 0072 Tech Line 0072 TechniSat 0348 0209 Teleavia 0041 Telefunken 0041 0320 0384 0278 Teletech 0072 0278 0000 Tenosal 0072 Tensai 0000 0037 0072 Tevion 0348 0209 Thomson 0320 0041 0067 0384 0278 Thorn 0041 0104 0037 Thorn-Ferguson 0320 Tokai 0072 0037 0041 0104 Tokiwa 0072 Topline 0348 Toshiba 0045 0041 0384 0043 0081 Towada 0072 Tredex 0278 Uher 0037 0240 Ultravox 0278 Unitech 0240 United Quick Star 0278 Universum 0000 0081 0240 0037 0106 0348 0209 0104 Victor 0067 Watson 0081 0352 0278 0642 Weltblick 0037 Yamaha 0041

Yamishi 0072 0278 Yokan 0072 Yoko 0037 0072 0240 ZX 0209

SAT /STB)

@sat 1300 ABsat 0668 0123 1323 0710 ADB 0642 Adcom 0200 AGS 0668 0710 Akai 0200 Akena 0668 Alba 0455 0713 Allsat 0200 1017 1043 Alltech 0713 Alpha 0668 0200 Altai 0396 Amitronica 0713 Ampere 0396 0132 Amstrad 0847 0713 0742 0396 0132 0882 0885 0863 0501 0795 1113 Anglo 0713 Ankaro 0713 AntSat 1017 1083 Apollo 0455 Arcon 1205 1043 0834 0132 1075 Armstrong 0200 Asat 0200 ASLF 0713 AssCom 0853 Astacom 0668 0710 Aston 1129 Astra 0607 0713 Astro 0133 0173 0501 0658 0607 1113 1099 1100 0200 Athena 0668 Atlanta 0871 Aurora 0879 Austar 0863 0642 0497 0879 1176 Avalon 0396 Axiel 0668 0710 Axis 1111 0834 Beko 0455 Bentley Walker 1017 Blaupunkt 0173 Blue Sky 0713 0885 Boca 0132 0713 Boston 0132 0710 0668 Broco 0713 BskyB 0847 1175 BT 0668 0710 Bubu Sat 0713 Cambridge 0501

Canal Satellite 0853 Canal+ 0853 Cherokee 0123 0710 1323 Chess 0157 0605 0713 1085 CityCom 1176 0115 0607 0299 Clemens Kamphus 0834 0396 Cobra 0396 Colombia 0668 0132 Columbia 0132 Columbus 0668 Comag 0132 Condor 0607 Connexions 0396 Conrad 0607 0573 0115 0501 Conrad Electronic 0607 0713 Cryptovision 0455 0795 Cyrus 0200 D-box 1127 1114 0723 Daeryung 0396 Daewoo 1296 0713 Delfa 0863 Deltasat 1075 DGTEC 1242 Digatron 1294 Digenius 0299 Digiality 0607 Digipro 1105 DigiQuest 0863 Diskoverer 0605 0157 Diskovery 0668 0710 Diseqc 0710 Distratel 0084 0885 1205 Distrisat 0200 DMT 1075 DNT 0200 0396 DREAM multimedia.TV 1237 DStv 0642 0879

Echostar 0610 1169 0871 0167 0853 1086 1200 0454 0396 0713 0668 0511 0453 Einhell 0132 0713 0501 Elap 0713 1129 0668 0710 Elsat 0713 Elta 0200 Emme Esse 0871 Engel 1017 0713 EP Sat 0455 Eurieult 0084 0885 0882 Eurocrypt 0455 Europa 0863 0607 0501 0200 Europhon 0299 0607 Eurosky 0607 0132 0299 0115 0114 0501 Eurostar 0607 0115 Fenner 0668 0157 0605 0713 Ferguson 0455

Codelist RC3 / Lista de códigos RC3

Fidelity 0501 Finlandia 0455 Finlux 0573 0455 Flair Mate 0713 Force 1101 Fortec Star 1017 1083 Foxtel 0879 0720 0455 0497 0795 1176 Fracarro 0871 0668 Freecom 0501 0173 Freesat 0882 FTEmaximal 0713 0863 Fuba 0396 0173 0573 0115 0299 Fugionkyo 1105 Galaxis 1111 1101 0834 0863 1176 0853 0115 0879 Garnet 1075 GF 0834 1043 GF Star 1043 GOD Digital 0200 Goldbox 0853 Goldvision 1017 Gooding 0571 Goodmans 1284 0455 Gradiente 0887 Granada 0455 Grandin 0084 Grundig 0173 0847 1150 1291 1435 0571 0750 0879 0885 0853 0501 1297 1330 Hanseatic 0605 1099 1100 Hänsel & Gretel 0132 0607 Hauppauge 1294 HDT 1011 Heliocom 0607 Helium 0607 Hirschmann 0396 0882 1113 1111 0173 0573 1085 0299 0501 0710 0607 0668 Hitachi 0455 HNE 0742 0132 Houston 0668 0396 Humax 1176 0863 Huth 0132 0607 1017 1075 Hyundai 1011 1159 1075 ID Digital 1176 0863 Imex 0084 Ingelen 0396 0882 International 0132 Interstar 1105 1017 Intervision 0628 0607 Invideo 0871 IRTE 0609 Italtel 0871 ITT Nokia 0573 0455 0723 JOK 0710 JVC 0571

K-SAT 0713 Kamm 0713 Kaon 1300 KaTelco 1111 Kathrein 0658 0249 1057 0173 1221 0200 0713 0668 0742 0123 0115 1323 0710 Kathrein Eurostar 0115 Kiton 0114 Klap 0668 0710 Konig 0607 Koscom 0834 1043 Kreiling 0658 0249 0114 Kreiselmeyer 0173 Kyostar 0132 L&S Electronic 1043 Labgear 1296 LaSAT 0607 0115 0132 0157 0299 Lenco 0713 0115 0607 Lenson 0501 Lexus 0200 LG 1075 Lifesat 0605 0299 1043 0713 Logix 1017 1075 Lorenzen 0299 1294 0607 0742 0132 Luxor 0573 0501 M&B1 0605 Manata 0710 0668 0713 Manhattan 1083 0455 0710 0668 0834 1017 Marantz 0200 Maspro 0750 0713 0173 0571 Matsui 0571 0710 0173 Max 0607 MB 0605 Mediabox 0853 Mediacom 1206 MediaSat 0501 0853 Medion 0713 0299 1043 Medison 0713 Mega 0200 Metronic 0713 1215 0084 0885 1205 Metz 0173 Micro 0607 0501 0713 Micro electronic 0713 Micro Technology 0713 Micromaxx 0299 Microtec 0713 Minerva 0571 Mitsubishi 0455 Morgan’s 0200 0713 0132 Motorola 0856 Multichoice 0642 0879 Multitec 0157 Myryad 0200 Mysat 0713 Netgem 1322

Neuhaus 0501 0713 0834 0607 Neusat 0713 0834 Nikko 0713 0723 0200 Nokia 1023 1114 0751 1127 0723 0853 0573 1223 0455 1723 1310 1312 Nordmende 0455 Nova 0879 OctalTV 1294 Okano 0668 OnDigital 0751 0329 0241 0867 0133 Optex 0834 Optus 0879 0853 Orbitech 1099 1100 0200 0501 0157 Origo 0497 Ouralis 1205 Oxford 0668 Pace 0455 0847 0887 1175 0241 0867 0123 1323 0791 0795 0720 0497 0200 0853 0710 1423 Packsat 0710 Palcom 0299 Palladium 0571 0501 Palsat 0501 Panasat 0879 0615 Panasonic 0847 1104 0455 1320 Panda 0455 0607 0173 0834 Patriot 0668 Philips 0200 1114 0853 0455 0750 0710 0668 0571 0173 0133 1336 Phonotrend 0863 1017 1200 Pioneer 0329 0853 0352 Planet 0871 0396 Polytron 0396 Praxis 0511 Preisner 0132 0396 1101 1113 Premiere 0853 1114 1127 0723 1111 1176 1195 1100 0249 0658 1435 Primacom 1111 Proﬁ le 0668 0710 Promax 0455 Prosat 0628 Prosonic 0742 Pye 0571 Pyxis 0834 Quadral 0628 0668 0710 1323 Quelle 0607 0742 0115 Radiola 0200 Radix 0396 1113 0882 RFT 0200 Roadstar 0713 Rover 0628 0713 Saba 0710 0885 0115 0607 Sabre 0455 Sagem 0820 1114 1253 Samsung 0863 1243 1343 0853 1206 1017 1293 1292

SAT 0501 Sat Control 1300 Sat Partner 0501 Sat Team 0713 Satcom 0605 0607 Satec 0713 0834 Satline 0628 Satstation 1083 Schneider 0710 0668 0157 1206 Schwaiger 0605 0157 0607 0885 1111 0132 1075 SCS 0115 0299 Seemann 0396 SEG 0605 0742 0114 1087 Seleco 0871 Septimo 1205 0885 Siemens 0173 Skantin 0713 Skinsat 0501 SKR 0713 Sky 0847 0856 0887 1014 SKY+ 1175 Skymaster 0713 0605 0157 1200 1085 1075 0628 Skymax 0200 SkySat 0157 0605 0713 SL 0132 0742 SM Electronic 0157 0713 1200 1075 1085 Smart 0132 0299 1101 0882 0396 1113 0115 0713 Sony 0282 0847 0853 0455 SR 0132 Starland 0713 Strong 0879 0853 1105 1159 1300 Sunsat 0713 Sunstar 0132 Tantec 0455 Tatung 0455 Teac 1322 Tecatel 1200 TechniSat 0200 1099 1100 1195 0501 1322 Technosat 1206 Technowelt 0607 0885 Techsan 1017 Techwood 0114 Telasat 0605 0115 0607 Teleciel 1043 Telecom 0713 Telefunken 0710 Teleka 0396 0750 0501 0607 0834 Telesat 0605 0607 Telestar 0501 1099 1100 0114 0200 0157 Teletech 0114 Televes 0455 0501 0132

51 -

Codelist RC3 / Lista de códigos RC3

Thomson 0455 0713 0853 0115 0607 12910820 0668 0710 1046 Thorn 0455 Tokai 0200 Tonna 0455 0668 0501 0713 0834 Top ﬁ eld 1206 Toshiba 0455 TPS 0820 1253 Triasat 0501 Triax 0501 0115 0200 0396 0713 08530114 1296 1291 0132 Turnsat 0713 Twinner 0132 0713 UEC 0879 Uher 0157 Unisat 0200 Universum 0173 0571 0607 0299 0115 0742 1087 Van Hunen 0299 Variosat 0173 Ventana 0200 Vestel 0742 VH-Sat 0299 Viasat 1323 1023 0820 Visionic 1105 Visiosat 0710 0713 Wetekom 0157 0605 0501 Wewa 0455 Wisi 0173 0396 0299 0455 0501 0607 0834 Worldsat 0710 0114 0123 0668 XCOM 0123 0668 XSat 0668 0713 0123 Xtreme 1300 YES 0887 Zehnder 1075 0742 0114 0115 0419 Zenith 0856 Zeta Technology 0200 Zinwell 1176

NTL Cabletell 0276 Ono 1068 Optus 0276 1060 Pace 1068 1060 Philips 0817 0286 PVP Stereo Visual 0003 Sagem 0817 Tele+1 0443 Telepiu 0443 Tudi 0286 United Cable 0003

Visiopass 0817

Cable Box (STB)

Austar 0276 BT 0003 Canal Plus 0443 Comcrypt 0443 Decsat 0423 Filmnet 0443 France Telecom 0817 General Instruments 0276 Jerrold 0003 0276 Kabelvision 0003 Macab 0817 Melita 0003 MNet 0443 Mr Zapp 0817 Noos 0817

- 52

Loewe R 32 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
