Loewe bild, bild 9, bild 7, bild 4, bild 3 User Handbook Manual
...
TV
Loewe bild
bild 9
bild 7
bild 5
bild 4
bild 3
bild 2
bild 1
User handbook
36960023
Loewe bild
User handbook
2
Imprint
Loewe Technologies GmbH
Industriestraße 11
D-96317 Kronach
www.loewe.tv
Editorial date 11/18-4.0 PS, TB, SB
© Loewe Technologies GmbH, Kronach
ID: 5.0.23.0
The screen graphics used are only exemplary. Depending on the device
type, the available hardware/software components may be different.
The information in this document is subject to change without notice
and does not constitute any obligation on the part of Loewe Technolo-
gies GmbH.
All rights including translation, technical modifications and errors
reserved
.
Imprint
hnologies GmbH
traße
11
ronac
h
.tv
itorial date 1118-4 PS, TB,
SB
Loewe Technologies GmbH, Krona
:
.0.23.
0
graphics used are only exemplary. Depending on the device
vailable hardware/software components may be different.
ation in this document is subject to change without notice
ot constitute any obligation on the part of Loewe Technolo
G
ll rights
reserve
d
including translation, technical modifications and errors
Loewe bild
User handbook
3
Table of contents
Imprint ...........................................................................................2
Welcome ........................................................................................5
About this user handbook ........................................................................... 5
Safety/Warning ............................................................................6
Technical information ..................................................................8
Remote control button mapping ..............................................10
Operating controls on the TV set ..............................................11
Function of the connections ..................................................... 12
Preparing the TV set .................................................................. 13
Installing the TV set .....................................................................................13
Set covers .....................................................................................................13
Cable fixing ...................................................................................................13
Connecting the TV set ................................................................................14
Switching the TV set ON/OFF ...................................................................16
General information on menu operation ..................................17
On-screen displays .................................................................... 20
Explanation of keys .....................................................................................20
Explanation of symbols .............................................................................20
Automatic menu info .................................................................................20
Permanent clock display ...........................................................................20
Initial installation ....................................................................... 21
Initial installation wizard ..............................................................................21
TV set as a monitor ....................................................................................33
Home view .................................................................................. 34
Home view - EPG search .......................................................................... 34
Home view - Favourites ............................................................................. 35
TV ................................................................................................ 36
Setting the volume .....................................................................................36
Select channel.............................................................................................36
Status display/Info key ..............................................................................38
Menu options ..............................................................................................39
Electronic Programme Guide – EPG........................................................40
Freeview Play ...............................................................................................44
Teletext .........................................................................................................46
HbbTV / MediaText ....................................................................................48
Picture in Picture (PIP) ...............................................................................49
Rotating the TV set .....................................................................................50
Vogels Motion Mount ..................................................................................51
Recordings ..................................................................................53
Digital Recorder .......................................................................................... 53
TV viewing with time shift .......................................................................53
Archive recording ..................................................................................... 54
Multi recording ......................................................................................... 55
DR+ archive ..............................................................................................56
DR+ Streaming .........................................................................................61
Follow me function ...................................................................................61
Multiroom ....................................................................................................62
Timer ............................................................................................................63
Sources ...................................................................................... 66
Video ............................................................................................................68
Video playback ............................................................................................68
Additional functions for DR+ archive playback .......................................71
Audio ............................................................................................................ 74
Audio playback ........................................................................................... 74
Photo ............................................................................................................ 76
Photo playback ........................................................................................... 76
Apps .............................................................................................78
App Gallery ..................................................................................................78
Browser ........................................................................................................80
DVB radio ......................................................................................................81
Internet radio ............................................................................................... 82
Screen Mirroring ......................................................................................... 83
System settings ........................................................................ 84
Picture ..........................................................................................................85
Sound ...........................................................................................................89
Surround modus .....................................................................................90
Mimi Defined
TM
.........................................................................................91
Channels ......................................................................................................94
Automatic scan TV+Radio .....................................................................95
Manual Scan TV / Radio .........................................................................96
Channel lists TV / Radio .........................................................................98
Compose / edit Personal list ..................................................................99
Update channel list automatically .......................................................100
Transfer all channel lists ........................................................................100
Control ........................................................................................................101
Language ................................................................................................ 102
EPG .......................................................................................................... 102
Parental lock ...........................................................................................103
Energy efficiency .................................................................................... 104
Quick start mode ................................................................................... 104
Software update..................................................................................... 105
On-screen displays .................................................................................110
Time and date .........................................................................................110
DVB settings .............................................................................................111
PIP ..............................................................................................................111
DR+ ..........................................................................................................112
Standard Teletext ....................................................................................113
HbbTV ...................................................................................................... 114
Asterisk key function .............................................................................. 114
Rotate TV ................................................................................................. 115
Display kinematics .................................................................................. 116
Hard disks ................................................................................................ 117
Export log file ........................................................................................... 118
Multimedia/Network ................................................................................119
Network settings .................................................................................... 120
Multimedia settings ............................................................................... 123
Home Automation ................................................................................. 123
Renderer ................................................................................................. 123
Mobile Recording ................................................................................... 124
Bluetooth ................................................................................................ 125
Amazon Alexa login ............................................................................... 127
m
int.............................................
lc
ome
..........................
..
bout this user handboo
k
......
..
afety/Warning..............................
Technical information....................
emote control button mappin
g
erating controls on the TV set.
Function of the connections.........
reparing the TV set ......................
nstalling the TV set
t cove
rs
able fixin
g
Connecting the TV se
t
witching the TV set ON/OFF
General information on menu o
pe
n-screen displays.........................
Explanation of k
s
Explanation of symbols........................
tomati
c menu
nf
ermanent clock displa
y
nitial installati
on
nitial installation wizar
d
set as a monito
r
ome vie
w
Home view - EPG search
ome view - Favourites
.....................................................
etting the volum
e
..................
..
Select channel
Status display/Info ke
y
..............
enu optio
ns
Electronic Programme Guide – EP
G
reeview Pla
y
tex
t
HbbTV / MediaTe x
..............................
Picture in Picture(PI
P)
otating the TV se
t
o
ge
ls M
otion Moun
t
ecording
s
..........................
igital Recorde
r
V viewing with time shift
rchive recordin
g
..................
..
Multi recordin
g
DR+ archiv
e
Streamin
g
owmfution
tir
oom
Loewe bild
User handbook
4
Table of contents
Connections .............................................................................................. 128
Sound components .............................................................................. 129
Antenna DVB .......................................................................................... 134
AV connection settings .........................................................................134
Digital Link ............................................................................................... 135
HDMI ........................................................................................................ 135
Extras .........................................................................................................136
DR+ Streaming ......................................................................................136
Integrated features ................................................................................ 137
Reset to factory settings ....................................................................... 137
Dealer mode ........................................................................................... 138
Legal matters.......................................................................................... 138
Conditional Access module (CA module) .......................................... 139
External devices ....................................................................... 141
Devices to the HDMI connections ........................................................... 141
Digital Link HD ........................................................................................... 142
Devices on AV ............................................................................................ 143
Connecting the speaker system (AUDIO OUT) ................................... 145
Connecting the speaker system (DAL) ................................................. 145
Connecting active loudspeakers ............................................................ 146
Connecting the HiFi/AV amplifier ........................................................... 146
Audio playback from external devices ....................................................147
IR-Link .........................................................................................................147
Serial interface RS-232C (RJ12) ..............................................................147
Setting the remote control ......................................................................148
Teaching the remote control ..................................................149
Loewe app ..................................................................................151
Technical data ..........................................................................155
bild 9 ................................................................................................. 155
Connections rear side of the device (bild 9.65/bild 9.55) .................. 155
Technical data (bild 9.65/bild 9.55) ....................................................... 156
Equipment features (bild 9.65/bild 9.55).............................................. 157
bild 7 .................................................................................................158
Connections rear side of the device (bild 7.77/bild 7.65/bild 7.55) .... 158
Technical data (bild 7.77/bild 7.65/bild 7.55).........................................159
Equipment features (bild 7.77/bild 7.65/bild 7.55) ............................... 160
bild 5 oled ........................................................................................ 161
Connections rear side of the device (bild 5.65 oled/bild 5.55 oled) ..161
Technical data (bild 5.65 oled/bild 5.55 oled) ...................................... 162
Equipment features (bild 5.65 oled/bild 5.55 oled) ............................. 163
bild 5 .................................................................................................164
Connections rear side of the device (bild 5.55/bild 5.48/bild 5.40) . 164
Connections rear side of the device (bild 5.32 dr+/bild 5.32) ........... 165
Technical data (bild 5.55/bild 5.48/bild 5.40/bild 5.32) ..................... 166
Equipment features (bild 5.55/bild 5.48/bild 5.40/bild 5.32) ........... 167
bild 4 .................................................................................................168
Connections rear side of the device (bild 4.55) ................................... 168
Technical data (bild 4.55) ........................................................................169
Equipment features (bild 4.55) ............................................................... 170
System settings (continuation) .............................................128 bild 3 (2017) .....................................................................................171
Connections rear side of the device (bild 3.65 oled/bild 3.55 oled) .. 171
Connections rear side of the device (bild 3.49/bild 3.43) ...................172
Technical data (bild 3.65 oled/bild 3.55 oled/bild 3.49/bild 3.43) .....173
Equipment features (bild 3.65 oled/bild 3.55 oled) .............................174
Equipment features (bild 3.49/bild 3.43) ...............................................175
bild 3 ................................................................................................. 176
Connections rear side of the device (bild 3.55/bild 3.48/bild 3.40) ..176
Technical data (bild 3.55/bild 3.48/bild 3.40/bild 3.40 FHD) .............177
Equipment features (bild 3.55 dal/bild 3.48 dal/bild 3.40 dal) ..........178
Equipment features (bild 3.55/bild 3.48/bild 3.40/bild 3.40 FHD) .. 179
bild 3 .................................................................................................180
Position and function of the connections (bild 2.55 oled) ..................180
Position and function of the connections (
bild 2.49 / bild 2.43
) ...........181
Technical data (bild 2.55 oled/bild 2.49/bild 2.43) ............................. 182
Equipment features (bild 2.55 oled/bild 2.49/bild 2.43) ....................183
bild 1 ..................................................................................................184
Connections rear side of the device (bild 1.65/55) .............................. 184
Connections rear side of the device (bild 1.40/32) .............................. 185
Technical data (bild 1.65/bild 1.55/bild 1.40/bild 1.32) .......................186
Equipment features (bild 1.65/bild 1.55/bild 1.40/bild 1.32).............. 187
bild (across sets) ............................................................................188
Signals via HDMI/AV (PC IN) .................................................................. 188
Signal input groups ...................................................................................191
Accessories ...............................................................................192
Upgrade kits / conversion kits / cables ................................................ 192
Mounting options (bild 9.65/bild 9.55) ................................................. 193
Mounting options (bild 7.77/bild 7.65/bild 7.55) ................................... 194
Mounting options (bild 5.65 oled/bild 5.55 oled) ................................ 195
Mounting options (bild 5.55/bild 5.48/bild 5.40/bild 5.32) ...............196
Mounting options (bild 4.55) .................................................................. 197
Mounting options (bild 3.65 oled/bild 3.55 oled/bild 3.49/bild 3.43) ....
198
Mounting options (bild 3.55/bild 3.48/bild 3.40) ................................ 199
Mounting options (bild 2.55 oled/bild 2.49/bild 2.43)....................... 200
Mounting options (bild 1.65/bild 1.55/bild 1.40/bild 1.32) .................201
VESA standard ......................................................................................... 202
Environmental ......................................................................... 203
Disposal .................................................................................... 203
Licences ................................................................................... 203
Troubleshooting ...................................................................... 205
CA module error codes ........................................................................... 212
Glossary .................................................................................... 213
EC Declaration of Conformity................................................. 217
Index ..........................................................................................218
Service ...................................................................................... 222
Code page ................................................................................ 223
Loewe bild
User handbook
5
Welcome
Thank you,
for choosing a Loewe product and having placed your trust in us.
With Loewe you have not simply decided on a modern and technically
innovative TV set, but for timeless design, sharp picture quality, brilliant
sound for movies and music as well as intuitive operation with the
Loewe remote control unit, smart phone or tablet. In short, Loewe is
perfect for home entertainment.
We look forward to welcome you as our customer and hope that you
enjoy your Premium Home Entertainment made by Loewe.
Many features, one result:
perfect Home Entertainment.
Just more entertainment.
The Loewe os user interface is intuitive and graphically
optimised. This is how you quickly find your desired content
– from TV set to online.
See chapter: Home view.
Perfectly networked.
Thanks to its numerous connections, your Loewe TV
becomes your entertainment centre. Connect it to the
Internet, DVD/Blu-ray player, external speakers, etc.
Hard disk for your TV archive.
Record the TV programme or pause it and continue watching
it at a later date.
Depending on the set type, on an externally connected USB
hard drive or the hard drive installed in the TV set
(1
.
With DR+ (Digital Recording), all this is no problem for your
Loewe TV set.
See chapter: Digital Recorder.
Your contact person.
We are happy to help you with any questions regarding your
TV set and other Loewe products.
In the user handbook refer to Service.
Customer
Care
Center
About this user handbook
For best results regarding safety and the longevity of the set, we
recommend you read the chapter Safety/Warning before switching
the TV set on for the first time.
This user handbook can be used for all current Loewe bild TV sets. The
equipment and function scope varies according to set type.
The Technical data chapter is structured according to set lines and
gives you information about the features of your TV set.
For differences in the functional descriptions, refer to the features in
the Technical data chapter.
The chapter glossary gives explanations of certain terms used in the
TV set and the user handbook.
Paragraphs which begin with the symbol
indicate important
instructions, tips or conditions for the following settings.
Terms which you will find in the menus or printed on the remote control
or TV set are written in bold type.
The necessary control elements are shown in the descriptions to the
left of the text containing the instructions for action.
Depending on the connected accessory equipment the menus in the
TV set can differ from those described here. The screen graphic displayed is only an example. Depending on the device type, the available
hardware/software components may be different.
All the channel names, programme contents, the illustrated photos,
titles, albums and album covers in this user handbook are examples.
In addition to the remote control, a PC keyboard can be connected to
one of the USB ports on your TV and then used to control your TV set.
In the user handbook, this symbol indicates places in
which the use of a keyboard is particularly advantageous.
With the Loewe app, you can also comfortably enter addresses or
search terms. Simply mark the input field for this, the Loewe app
displays automatically a keyboard symbol. Open Loewe app keyboard,
enter and confirm.
The user handbook is updated at irregular intervals. We recommend an
occasional examination on the Support Portal of the Loewe homepage.
General information on the operation of the
TV set
For further information on the user interface and the general operation
of your TV set see chapter General information on the operation.
Important information
Loewe does not accept any liability for the nature and content of
receivable Internet services. This also applies to the Loewe MediaNet
portal. With its devices, Loewe provides the technical platform that
fundamentally enables such material to be received. Loewe cannot
make any guarantees regarding changes in scope and content,
particularly with regard to the future and after going to press. The
receivable online services are not included in the delivery and can vary
depending on the product and country.
(1
Availability varies by device type (see chapter Technical data - equipment features for your TV set).
Loewe bild
User handbook
6
Safety/Warning
Safety/Warning
For your safety, and to avoid unnecessary damage to your unit, please
read and follow the safety instructions below.
Key
This symbol indicates risks caused by high voltages.
This symbol indicates dangers caused by the development
of fire.
This symbol should alert the user to other, more specific risks.
This symbol indicates dangers caused by sharp edges.
Do not remove set rear panel
Warning: When opening or removing the rear panel, there is the dan-
ger of electric shock and the risk of serious injury from high voltages.
Never open the rear panel yourself. Leave repairs and servicing work
on your TV set to qualified, authorised television technicians.
Please contact your dealer or our customer service.
Intended use and environmental conditions
This TV set is intended exclusively for the reception and
playback of picture and sound signals.
The TV set is designed for dry rooms (living rooms and office
spaces). It must not be operated in spaces with high humidity
(for example, near or in a bath or sauna).
We point out that our TV sets can react sensitively to dust and
soot particles in the ambient air.
Excessive amounts of these can lead to damage to the set, up
to loss of function.
Ensure a clean environment, so that your set will not be
damaged.
High humidity and dust concentrations lead to power leaks in
the set. This can lead to danger of injury and damage to the set
by electric tensions or a fire.
If the set is used outdoors, make sure therefore that it is
protected against moisture (rain, dripping or splashing water
or condensation).
If you’ve brought the set from the cold into a warm environment,
leave it off for around an hour due to the formation of
condensation.
Do not place objects filled with liquid on the
set. Protect the set from dripping and
splashing water.
Candles and other open flames must be
kept away from the set at all times, to prevent the spread of fire.
Transport
Improper handling during transportation can lead to damage
to the display and risks of injury.
The screen consists of glass or plastic and can break if handled
improperly.
Only transport the set in a vertical position.
No pressure should be applied to the glass or the plastic during
transport.
For TV sets with OLED screen:
Only handle the TV set at the display corners. The correct
handling is shown in operating instructions 1, which are
enclosed with the TV set.
Do not place it on the lower edge so as to reduce the danger of
damage and contamination.
For TV sets with Loewe Eye:
Make sure that the Loewe Eye is not damaged when
transporting / handling the TV set.
The TV sets with OLED screen of the set product lines bild 3,
bild 4 and bild 5 have a different packaging concept from bild
7 and bild 9.
With these sets you can, as a protective box is located in front
of the display, after unpacking the device, also place this on this
protective box, also on the front side.
The TV sets of the device product lines bild 9 and bild 7 must
not be placed on the front side (display surface).
For TV sets with LCD screen:
Grasp the set by the edges of the housing at the bottom and at
the top.
Do not place it on the lower edge so as to reduce the danger of
damage and contamination.
For TV sets with Loewe Eye:
Make sure that the Loewe Eye is not damaged when
transporting / handling the TV set.
If the set needs to be stored during packing / unpacking, place
the TV set with the entire surface of the front side on a soft
underlay. Use as an underlay, for example a blanket or fleece
from the packaging material.
In the event of damage to the LCD screen and any leaking liquid
crystal, be sure to use rubber gloves to remove the set.
In case of skin contact with the fluid, clean immediately with
plenty of water.
Mains cable/power supply
Incorrect voltages can damage the set.
This set may only be connected to a mains power supply with
the voltage and frequency indicated on the rating plate using
the existing
(1
/ enclosed mains cable.
The mains power plug of the TV set must be easily accessible
so that the set can be disconnected from the mains at any time.
When pulling the mains power plug out, do not pull the cable
but the plug housing. The cables in the mains power plug could
be damaged and cause a short circuit when plugged in again.
A mains power cable with a damaged insulation can lead to
electric shock and presents a fire hazard. Never use a damaged
mains cable.
Lay the mains cables so that they cannot be damaged. Do not
tread on the mains cable.
The mains cable must not be kinked or laid over sharp edges.
(1
Availability varies by device type (see chapter Technical data - equipment features for your TV set).
WARNUNG
STROMSCHLAGGEFAHR –
NICHT ÖFFNEN
Loewe bild
User handbook
7
Safety/Warning
Air circulation and high temperatures
Like any electronic device, your TV set requires air for cooling.
If air circulation is impeded, it may result in a fire.
The ventilation slots on the rear panel of
the set must therefore remain free.
Please do not cover the set.
Wall mounting: Leave at least 10 cm of
space all around the set at the side,
above and below.
Table / stand foot: Leave at least 10 cm
clear space around the set at the side
and at the top.
Foreign bodies
Foreign bodies inside of the set can lead to short circuits and
fires.
Danger of injury and damage exists
Therefore avoid metal parts, needles, paper clips, liquids, wax
or similar passing through the ventilation slits of the rear
panel into the interior of the set.
Should something get into the interior of the appliance, immediately pull out the mains power plug of the set and inform
the customer service department for checking.
Installation
Opting for an incorrect or wrongly mounted installation can
lead to danger of accidents Rolling or falling sets can cause
injuries or damage.
Loewe TV sets are specified for Loewe accessories. We strongly
recommend the use of original Loewe installation options.
Do not use any installation options that are not approved for
your TV set!
Note the instructions regarding the mounting for the different
possible installation options! A corresponding documentation
is included with every Loewe product.
Check before the installation of the set, whether the final location with regard to the surface (pressure sensitivity) and stability (static) is designed for the load from the set! This applies in
particular to high-gloss lacquered surfaces and surfaces made
of real wood, real wood veneer and plastic surfaces.
Only place the TV set on a levelled, stable, horizontal base with
table or stand foot! The set should especially not protrude at
the front when installing in or on furniture.
Not placing the television set on cloth or other materials that
may be located between television set and supporting furniture.
Educating children about dangers of climbing on furniture to
reach the television set or its controls.
The usual usage position of the TV set should be followed. The
TV set can only be operated horizontally upright
A
. The
inclination can amount to a maximum of 10 degrees for wall
mounting
B
. The TV set must never be operated in portrait
orientation,
C
, horizontal D or overhead on the ceiling E .
Position the set so that it is not exposed to direct sunlight and
additional heating from radiators!
Do not place the TV in a location where vibrations can arise!
This can lead to damage.
In the case of installation options for third-party manufacturers
with a motor drive, it is to be ensured that the adjustment of the
TV set does not occur manually. It is generally not advisable to
use the installation options of other manufacturers with locking
devices in certain positions.
When using accessories from third-party manufacturers, it is
to be ensured that the TV set is easily adjusted for the respective installation option.
When adjusting the TV set, ensure that
the pressure applied to the set frame
is not too great. Especially in large
format displays, there is the danger
of damaging the display.
For TV sets with OLED:
OLED technology allows for a design with an extremely thin dis-
play. When you have mounted your TV set on a non-motorized
installation option, avoid over excessive force when rotating
the TV set.
For TV sets with VESA mounting points:
The mounting of a TV set on a On a holder according to the
VESA standard requires mandatory use of the VESA adapter
bolts. Otherwise, damage to the TV may result.
The Vesa adapter bolts must be attached to the TV set with a
torque of circa 4 Nm. You can obtain these from your Loewe
dealer (you can find further information in chapter Miscellane-
ous, section VESA standard).
Make sure that after unpacking and setting up the TV set the
packaging material (TV box, Styrofoam shells and protective
fleece) does not fall carelessly into the hands of children.
Please also note the disposal instructions for packaging and
carton (see chapter Environment / Legal information, section Disposal).
±10°
D
A B
C
E
D
Loewe bild
User handbook
8
Supervision
Do not let unsupervised children handle the TV set nor let them
play immediately around the TV set!
The set could be knocked over, moved or pulled down from the
stand surface and injure people.
Do not leave the TV set when switched on unattended!
Volume
Loud music can lead to hearing damage. Avoid extreme sound
volume, especially over extended periods of time and when
using headphones!
Thunderstorms
During thunderstorms, pull out the mains power plug and all
connected antenna cables from the TV set!
If you have connected a network cable to the LAN port, remove
this as well!
Over-voltages due to lightning strike can damage the set both
via the antenna system and via the mains power supply.
Even in the case of prolonged absence, the mains power plug
and all connected antenna cables should be disconnected from
the TV set.
Cleaning and care/chemicals
Before cleaning, switch the TV set off using the mains power
switch!
Damages caused by chemicals can lead to adverse effects and
development of fire.
Never expose the set or accessories to aggressive (for example,
corrosive) chemicals such as alkalis or acids!
Only clean the TV set, the front screen and the remote control
with a damp, soft, clean and colour neutral cloth, without any
aggressive or scouring cleaning agents!
For TV sets with textile-covered speaker panel:
Hoover the surface regularly with a soft brush attachment!
On stains or dirt, moisten a soft, colour neutral cloth with detergent solution or commercially available stain remove and
rub the stain gently away! You can also treat the stain directly
with a commercial dry stain remover spray (hoover up the
dust).
Do not moisten the covering fabric directly with detergent solution or stain remover (risk of stain circle formation)! Do not use
solvents to clean the fabric!
Note the usage instructions of the manufacturer when using
stain remover!
When cleaning loudspeaker panels which have been exposed
to nicotine, there is an increased risk of stain circle formation.
TV sets with 3D function
(1
Read the following safety instructions before using the 3D
function of your TV set.
Please use the Loewe 3D TV sets only with the Loewe 3D
glasses which can be purchased as an accessory from your
Loewe dealer.
People with a visual disorder may not be able to perceive 3D
effects or may only be able to perceive them to a limited extent.
People who are sensitive to flickering images (e.g. those with
epilepsy) should only use the 3D function after having consulted
their doctor.
It might take some time for you to get used to the 3D glasses
and before you can perceive the 3D effects properly.
Stop using the 3D function immediately if you experience
any feelings of nausea, dizziness or malaise when viewing 3D
content.
Supervise children whilst they are viewing 3D content, as they
can be particularly sensitive to it.
Allow more time for a break after having watched 3D movies,
so that you are able to relax. Failure to do so could result in
headaches, fatigue, dizziness or malaise.
Position yourself comfortably in front of the 3D TV set and ensure that you are seated firmly. By doing this, you will avoid any
injuries that may occur due to reacting to extreme 3D content.
Technical information
Instructions on the built-in / connected hard drive
Switching off the TV set with the mains switch during operation or
an inadvertent disruption to the power supply (e.g., power failure)
can cause damage to the hard disk file system and hence loss of the
recorded broadcasts.
Never ever disconnect the USB storage device from the TV set during
a copy process. Before switching off the set with the mains switch, we
recommend you to switch it to standby mode.
If, contrary to expectation, you are still experiencing problems with the
operation of the hard drive, you can first carry out a test. In addition,
a formatting of the hard disk can be remedy. In the process, however,
all content on the hard disk is deleted. You can find the corresponding
menu items under System settings ט Control ט more...ט Hard
disks.
Loewe are not liable for the loss of data on the integrated hard disk
(1
of your TV set. To avoid data loss, we recommend copying important
recordings to an external storage medium.
Safety/Warning
(1
Availability varies by device type (see chapter Technical data - equipment features for your TV set).
Loewe bild
User handbook
9
Notes on the LCD / OLED screen
The TV set with LCD screen or OLED screen purchased by you meets
the highest quality standards and has been checked for pixel errors.
Despite of thorough care when manufacturing the display, it cannot
be 100% guaranteed that no subpixel defects will occur due to technical reasons.
Please understand that these types of effects, as long as they are
within the limits specified in the standard, cannot be considered as a
device defect in terms of the guarantee.
For TV sets with LCD:
Avoid displaying static images over a longer period. Image persistence
errors may arise.
For TV sets with OLED:
Organic Light Emitting Diodes are an image technology based on
self-luminous pixels that offer clear benefits in terms of image quality
and performance.
Under certain conditions, persistent, one-sided loads on the OLED
material can result in persistence image faults which are irreversible.
Residual image issues can arise by using static image content over a
longer period, such as static images, subtitles or ticker displays, looping dia-shows or video sequences, static displays serving as presentation monitors or with video games, black bars in some screen formats.
These residual image issues are not defects within the meaning of
the warranty.
To minimise such issues, Loewe has developed a special algorithm
for detecting image content.
If static images are displayed for too long, the TV set automatically
switches to a screen-friendly contrast mode. After a new user operation, the device immediately returns to its normal state. In addition,
menu insertions are gradually reduced or displayed transparently
after one minute.
Under normal viewing conditions, such residual image issues do not
arise.
Notes on Kinematics
The Loewe TV sets types bild 9 and bild 7 are equipped with a kinematics that moves the TV set upwards or downwards when switching it on
and off, whereby the speaker cover is visible or is hidden.
Please make sure that there is no externally applied force opposing the
movement. You have the option to fix the position of the kinematics
from the menu, or disable the function.
You can find further information in the chapter System settings,
section Control – Display kinematics.
Software update
It is possible to update the software on your Loewe TV set.
In the software update (package update) all the software releases in
the TV set are scanned and updated as required.
You can find further information in the chapter System settings,
section Control – Software update.
Safety/Warning
Information about OLED calibration
Only for set types with OLED display
(1
.
To maintain the high quality of picture display permanently, your Loewe
TV set calibrates itself automatically at regular intervals. In this way,
excess TFT capacitors are discharged and so-called image sticking
effects / „ghost images“ are eliminated.
When switching off the TV set from the remote control, where necessary, the calibration process is started and lasts for a maximum of
thirty minutes.
During this period, the power supply to the TV set must not be interrupted.
After the calibration is complete, the TV set switches to Standby mode.
Calibration does not take place during normal TV operation and so will
not have any negative impact on usage of the TV set.
If calibration is terminated by switching the set back on prematurely,
the TV-set will attempt to perform a recalibration again the next time
the TV is switched off.
You still have the possibility to start a refresh procedure manually by
means of the user menu of your Loewe TV set.
Call OLED calibration
HOME: Call Home view.
Select System settings,
OK call System settings.
Select Picture,
go to next column.
Select more ...,
call other settings.
Select OLED calibration,
OKCall.
A calibration of the OLEDs is required every 1500 hours. This also starts
automatically when the TV set is switched off using the remote control.
Calibration lasts one hour maximum. If calibration was not finished
properly, an on-screen image will indicate this.
After the calibration is complete, the TV set switches to Standby mode.
(1
Availability varies by device type (see chapter Technical data - equipment features for your TV set).
Loewe bild
User handbook
10
Remote control
(1
The assignment of these keys can be changed. The description refers to the standard setting. The factory setting of the keys can vary depending on the firmware version of the
remote control.
(2
Depending on the settings HbbTV mode on/off, start behaviour of HbbTV channel (System Settings
ט
Control
ט
more ... ט HbbTV)
.
(3
Depending on the set type, on an externally connected USB hard drive or the hard drive installed in the TV set (see chapter Technical data - equipment features for your TV set)
Remote control button mapping
Depending on the selected operating mode (TV/Video/Audio/Photo/Apps) and function (e.g. DR+, EPG, PIP, Teletext, HbbTV, etc.), the key assignment
may differ from the assignment described here (see the corresponding chapter).
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
31
18
19
20
21
22
23
24
25
26
27
28
29
30
32
17
1
Sound mute/on.
2
LED display for currently operated device.
3
Call the TV mode.
4
Reassign remote control to Set-Top-Box
(1
(presetting: Apple TV).
5
Pressing briefly
: Open the DR+ archive.
P
ressing longer
: Call timer.
6
Pressing briefly
: Add current object to Home favourites.
P
ressing longer
: Open App Gallery. (standard assignment)
(1
7
EPG (Electronic Programme Guide) on/off.
8
Teletext/MediaText
(2
on/off.
9
Pressing briefly
: Call menu options for the active operating mode.
P
ressing longer
: Call System settings.
10
V+/V- increase/reduce volume.
11
Pressing briefly: Call channel list.
Pressing longer
: Call
expanded channel list.
In the menu: confirm/call up.
12
Green coloured key: screen on/off in Audio/Radio mode.
13
Red coloured key: call preferred value-added network service, if available
(
2
.
14
Pressing briefly: skip backwards.
Pressing longer: winding backwards.
15
Pressing briefly: direct recording (with determination of recording duration)
(
3
.
Pressing longer: One Touch Recording
(
3
.
16
Pause / Start/pause the timeshift television
(
3
.
17
Stop / End timeshift (return to live image)
(
3
.
18
Pressing briefly: skip forwards.
Pressing longer: winding forwards.
19
Play / Start/continue timeshift television
(
3
.
20
Blue coloured key: call channel menu options
(selection of language/sound, subtitles or channel/video track).
21
Pressing briefly: Yellow coloured key: call history.
Pressing longer: Yellow coloured key: call last channel.
22
Navigation on the user interface, select objects.
In the menu / lists: select/set.
23
P+/P– next/previous channel.
24
Pressing briefly: step / level back.
Pressing long: close all displays.
25
Press briefly during an on-screen display: info display. Info text appropriate to the content
that can assist you further, should you have any questions about your TV set.
Press briefly, without on-screen display: access status display. With status display open
and repeatedly pressing the key call the detailed information on the broadcast.
Press longer: show Explanation of keys.
26
PIP (picture in picture) on/off.
27
Call up the Home view.
28
Select channels with numeric buttons directly.
In the menu: enter numbers or letters
29
Call Sources.
30
Reassign remote control to video device
(1
(presetting: BluTech Vision 3D).
31
Call radio mode (standard assignment) (1.
32
Switches the TV set on (mains switch must be turned on) or switches to standby mode.
Press briefly while TV set is switched on: TV set and all CEC-enabled devices connected to
the HDMI ports will be switched off to standby (System Standby).
Loewe bild
User handbook
11
3
Display:
white: TV set in standby.
Depending on the ambient brightness, the
white LED display is dimmed and lights
up with a different degree of brightness
(OPC)
(1
.
If the TV set is in quick start mode, the
white LED display is not dimmable and
starts with full brightness.
white, intermittent:
TV set starts.
green: TV set switched on.
red: timer recording active.
blue:
TV set in standby and background operation active (EPG
data updating, software update or streaming server
function
(1
, OLED calibration
(1
).
4
IR receiver:
Infrared receiver for receiving the remote control commands.
5
Key M / joystick direction M:
TV set in standby mode: switch on TV set with the last selected
mode (TV/Radio).
TV set switched on: call direct control on TV set.
Direct control on TV set: up .
6
Key R / joystick direction R:
TV set in standby mode: switch on TV set with the last selected
mode (TV/Radio).
TV set switched on: toggle TV mode and radio mode.
Direct control on TV set: down .
7
Key V+ /joystick direction +:
TV set in standby mode: switch on TV set with the last selected
mode (TV/Radio).
TV set switched on: Increase volume.
Direct control on TV set: to the right .
8
Key V– /joystick direction – :
TV set in standby mode: switch on TV set with the last selected
mode (TV/Radio).
TV set switched on: Reduce volume.
Direct control on TV set: to the left .
9
Key P +:
TV set switched on: Programmme + (next channel).
10
Key P –:
TV set switched on: Programme – (previous channel).
11
On/Off button / Press joystick:
Switching on in standby mode
Switching off to the standby mode
Operating controls on the TV set
Operating controls on the TV set
(1
1
Mains switch:
Always return the TV set to Standby mode before switching it off
with the main switch.
The position of the mains supply switch for your TV set can be
found in the chapter Technical data.
2
Infrared transmitter:
When showing 3D content
(1
, the 3D glasses Loewe Active
Glasses 3D are controlled via the infrared sensor.
(1
Availability and position varies according to device type (see chapter Technical data - equipment features for your TV set).
M
R
V+
V-
P+
P-
M
_
R
+
5
6
7
8
9
10
11
5
6
11
7
8
4
1
2
3
3
4
Loewe bild
User handbook
12
Function of the connections
Function of the connections
The position, availability and number of connections on your TV set vary depending on the set type.
Detailed information on the position and function of the connections for your TV set type can be found in the chapter Technical data.
Connection: Labelling: Function:
AC IN
Mains connection
LAN
Network connection
HDMI 1 ARC
HDMI input 1 (with Audio Return Channel)
HDMI 2
HDMI input 2
HDMI 3
HDMI input 3
HDMI 4
HDMI input 4
ANT TV
Antenna/cable analogue / DVB-T/T2 / DVB-C
ANT SAT 1
Satellite antenna (Sat tuner 1) DVB-S/S2
ANT SAT 2
Satellite antenna (Sat tuner 2) DVB-S/S2
SPDIF OUT
Audio output (digital)
USB 3.0
USB connection
USB
USB connection
HEADPHONE
Headphone connection
AUDIO OUT
Audio output (analogue) L/R
RS-232C
Serial interface
AV
Micro AV socket
MOTOR UNIT
Rotating stand control
DIGITAL AUDIO LINK
Surround audio outputs (digital)
COMMON INTERFACE
CI slot
K
Slot for Kensington lock
Loewe bild
User handbook
13
Installing the TV set
Mounting options / Installation notes
Your Loewe dealer can also assist you in finding other mounting
options. Look for the corresponding directions in the installation
instruction.
Choose a place for installing your TV set where no bright light or
sunlight shines directly onto the screen. This could cause reflections
which impair the picture.
3 times the screen diagonal can be taken as a guide value for the
viewing distance (e.g., for a 55-inch set approx. 4.2 m for SD signal).
The viewing distance can be reduced with an HD/UHD signal.
Set covers
Covers for rear and side connections
(1
In order to remove the rear side cable covers pull them simply from
the device.
To fit the cover, insert the lugs at the top edge of the cover into the
corresponding cut-outs in the rear panel and push up the cover until
it snaps in.
The side cover of the TV set can also be completely removed. For this,
open it as far as it will go and gently pull on the open cover.
The cover detaches from the holder and gives free access to the connection area. To insert the cover, simply push it back onto the holders.
A cable bushing connects the lateral and posterior terminal region. In
this way you can pass the cables of the lateral connections through
and lay them out together with the rear connecting cables.
Preparing the TV set
Cable fixing
Using the Velcro cable tie supplied, you can fix the rear cables.
When the TV set is mounted on the Table Stand, the connection cables
are fixed to the Table Stand (see figure).
When using a wall bracket (Wall Mount is available as an accessory
from your specialist dealer), the connection cables are fixed to the
two recesses on the rear of the set (see figure).
If the set type
(1
is equipped A with a removable cable holder, you
can additionally fix the rear connection cables to the rear wall of the
housing.
Table Stand
Wall Mount
A A
(1
Availability different according to set type.
Loewe bild
User handbook
14
Connecting the TV set
Connecting to the mains supply
Remove the cover for the connections.
Connect the TV set to a 220-240V mains socket:
With built in mains cable: Connect the mains supply plug of the mains
supply cable attached to the TV to a power outlet.
With external mains cable: First plug the smaller plug (small set plug)
of the mains supply cable into the mains supply connector (AC IN)
of the TV set and then connect the larger plug (Euro plug) to a mains
supply socket.
Connecting antennas
(1
Cable (analogue)/DVB-C/DVB-T antenna:
Plug the cable of antenna, cable TV system or room antenna into the
ANT TV socket.
If you want to use analogue cables/DVB-C connection and a DVB-T
antenna together, use an external antenna switch (available from
your dealer).
Satellite antenna DVB-S:
Depending on the used satellite system, connect a connecting cable
from the multi-switch or directly from the LNC to the ANT SAT1 and
ANT SAT2 sockets of the TV set respectively.
When connecting the TV set to a single cable community antenna,
connect the ANT SAT1 and ANT SAT2 sockets directly to the
appropriate SAT antenna socket.
AC IN
ANTTVANT
SAT1
ANT
SAT2
R TV
Cable
analogue /
DVB-C
DVB-T DVB-S
When connecting the TV set to a DiSEqC single cable community
antenna (in accordance with EN 50494), connect the ANT SAT1
socket directly to the appropriate SAT antenna socket.
For a DiSEqC single-cable shared system, you only need in principal
only one antenna cable. The further sub-division of the signal to
the two reception pathways is transferred by the satellite tuner of
the TV set.
If you want to use two transmission channels of the DiSEqC single-
cable shared system (for example, for different channels main
picture / PIP picture), both channels are received on a SAT antenna
cable.
In the antenna configuration one antenna cable must be provided.
It is possible to reuse an existing SAT cabling with two connection
cables on a DiSEqC single-cable shared system. However, the
system components used (sockets, distributors, etc.) must be
designed for DiSEqC operation.
If you want to use two channels of the DiSEqC single-cable shared
system (for example, for a different channels main picture / PIP
picture), then one channel will be received per SAT antenna cable.
In the antenna configuration, two antenna cables and the number
of used channels thus also must be set to “two“ .
Ask your dealer in this regard.
Connecting the TV set to the Home network
You may link your TV set to the home network by a wired connection
(Ethernet, Powerline adapters separately available) or by a wireless
radio connection (WLAN). For wireless connections, the TV set has
an internal WLAN antenna.
In order to play back data from your home network your Loewe TV
supports the UPnP AV standard.
You call the network wizard to configure the network adaptor (System
settingsטMultimedia/NetworkטNetwork settingsטNet-
working).
Under no circumstances may the TV set be wired and at the same
time connected by a wireless connection to the same network, e.g.
router. This may cause severe operational faults!
Example for a wired connection
Connect the LAN socket of your TV set to the LAN switch/router of
your home network with a network cable (available from your dealer).
DSL
LAN
LAN switch/router
TV set
PC
Preparing the TV set
(1
Availability varies by device type (see chapter Technical data - equipment features for your TV set).
Loewe bild
User handbook
15
Preparing the TV set
Example for a wireless connection
You can connect the TV set to your home network by a wireless radio
connection via the WLAN antenna inside the set.
Shadow effects of various materials, such as reinforced concrete,
metal surfaces, etc., attenuate the WIFI signal sometimes
significantly or completely.
Help for configuration problems
Loewe cannot provide any support for PC hardware and software or
network components owing to the diverse configuration options with
home networks.
Please contact the administrator of your home network and/or specialist
dealer for support when setting up and for maintenance of network
connections, storage media, media server software and network devices
such as routers.
DSL
WLAN router
TV set
PC
Preparing the remote control unit
Removing the battery protection
The remote control is supplied with batteries. To make them ready for
use, remove the plastic flag out as shown below.
Inserting or replacing batteries
Press on the embossed arrow whilst pushing the battery cover down.
Only use leak-proof micro-cells of the LR 03 (AAA) Alkali-Manganese
type. Do not use different types of batteries and old and new batteries
together.
Make sure that the batteries do not get into the hands of children.
The batteries used must not be exposed to excessive heat such as
sunlight, fire or similar!
The position of the batteries is indicated in the battery compartment
(in opposite directions). Pay attention to the correct polarity of +
and – when inserting the batteries.
Do not be guided by the battery
contacts (springs), but by the illustration at the bottom of the battery
compartment.
If the batteries are too weak after longer use, the TV set prompts you to
change the batteries. Dispose of used batteries in an environmentally
friendly way (see chapter Environment/Legal information).
Push the cover back on from below after having inserted the batteries.
Adjusting the remote control unit for operating the TV set
Press the TV key.
Loewe bild
User handbook
16
Switching the TV set ON/OFF
Switching the TV set ON/OFF
Switching TV set to the standby mode
Put the mains supply switch into Pos I .
The LED display lights up white for a short time. The set now finds
itself in the standby mode.
Meaning of the LED colours:
white: TV set in standby.
Depending on the ambient brightness, the
white LED display is dimmed and lights
up with a different degree of brightness
(OPC)
(1
.
If the TV set is in quick start mode, the
white LED display is not dimmable and
starts with full brightness.
white, intermittent:
TV set starts.
green: TV set switched on.
red: timer recording active.
blue:
TV set in standby and background operation active (EPG data updating, software
update or streaming server function
(1
,
OLED Calibration
(1
).
After switching on the TV set, it takes a few seconds for further oper-
ating commands to be processed (Exception: Quick start mode, see
chapter System settings, section Control – Quick start mode).
Your TV set is ready for operation once the LED display lights green.
Switching the TV set on by means of the remote control
Press the on/off key.
Or:
Press the TV key.
The previously watched channel will be called.
Or:
Press numerical keys 1-9.
The corresponding channel will be called.
After switching on the TV set, it takes a few seconds for further oper-
ating commands to be processed (Exception: Quick start mode, see
chapter System settings, section Control – Quick start mode).
Your TV set is ready for operation once the LED display lights green.
Switching the set off with the remote control (Standby)
Press the on/off key.
Switch TV set and all CEC-capable devices connected
to the HDMI interfaces OFF to Standby mode.
Before switching off the set with the mains switch,
we recommend you to switch it to standby mode.
Quick start mode
If you choose to activate the quick start mode, you will see the TV
screen immediately after each switching on of the TV set and without
any waiting time. You can specify the times at which your device will
be in the Quick Start Mode (see chapter System settings, section
Control – Quick start mode).
In this case, please note the higher power consumption (see chapter
Technical data) and thus a higher annual energy consumption.
Default setting for the Quick Start Mode: off
.
(1
Availability varies by device type (see chapter Technical data - equipment features for your TV set).
Loewe bild
User handbook
17
General information on menu operation
The most important keys for navigation will be explained in general.
The numbers in the text refer to the figure showing the remote control
in chapter Remote control.
The arrow keys
22
help you to navigate in the menus and lists of the
TV set and for selecting menu items. They are arranged in the middle
of the remote control in a circle around the OK key
11
. Later in this
user handbook they will be represented as follows:
Select the desired item.
The OK key
11
is used to confirm a selection, for calling the highlighted
menu item and for opening the channel list. In this user handbook, an
instruction for this key looks like the following:
OKconfirm.
Using the numerical keys of your remote control
29
you enter
programme channels and teletext pages directly. With key
you
open the source menu. In this user handbook, entering numbers with
numerical keys is shown as follows:
Entering programme channel directly.
The numerical keys are also used to enter text (see chapter General
information on menu operation,section Entry of characters by
remote control).
The Home view is the central overview page for all of your TV set‘s
operating modes. You reach Home view with the HOME key
27
.
HOME: Call Home view.
A short key stroke on the BACK
24
key takes you back one level in a
menu. A longer pressing of the BACK key closes all opened windows.
An example for the BACK key in this user manual:
BACK: Stop text entry and exit entry box.
With the keys
18
and
14
, you can jump back and forth in the
various wizards (for example, initial start up, etc.).
Call up next step.
Call up previous step.
Pressing longer on the INFO key
25
displays an explanation of the
most important key functions of the current operating mode (e.g. TV
mode, teletext, PIP, etc.).
Structure of the Menu screen
Basically, the structure of the different menu screens is similar,
depending on the fact if a wizard, rendering media content or a setup
menu are concerned. The structure is explained by means of three
different illustrations.
Screen structure: Wizard
(A) Title bar with name of the wizard and the current operating step.
(B) Selected items, whose number can be different according to the
operating step.
(C) Bottom line showing the available operating controls.
Screen structure: Rendering of media content (example:
Audio player)
(A) Cover display (if available).
(B) Time line.
(C) Album selection or track selection.
A
C
B
C
B
A
General information on menu operation
Loewe bild
User handbook
18
General information on menu operation
Screen structure: Setup (example: picture)
(A) Selected function in the Home overview (here: system settings)
(B) Home Menu System settings, with selected menu item Picture.
(C) Menu items Picture focusing on Contrast.
(D) Help text for the selected menu item Picture > Contrast.
Navigation: Selection of elements (example: On-screen displays)
Highlighting and thus selecting the symbols/elements or menu items
on the screen can be effected by the arrow keys on the remote control.
So you can see all the time where you are. As soon as there is a bar
above a symbol or text, this is a selected element.
(A) Selectable elements / menu items.
(B) The writing of the line in which the relevant selectable menu item
can be found is white.
(C) Move the selection marking by means of the arrow keys
to the menu item to be set.
The position of the marking is to see by a grey rectangle.
The newly selected menu item must be confirmed by selecting
OK. The previously active item’s text colour will change to grey;
the newly selected item will change to white.
A CB
A
B
C
Navigation: Wizards
If the menu item(s) (marked white) is/are already
correctly preset:
Go to next step.
Otherwise:
Mark menu point which should be changed.
OK confirm.
The font colour of the prior active point changes
to grey.
Go to next step.
Navigation: Element selection in lists using initials
Using the numerical keys of the remote control you can jump into list,
e.g., Internet radio channel lists.
If the list is sorted in alphabetical order, you jump to the entered letter.
For example, when pressing the key 7 three times you jump to the first
list element starting with letter R.
In case of numerical sorting, you can directly select the channels
with the numerical keys.
Loewe bild
User handbook
19
General information on menu operation
Entering characters with on-screen keyboard
For certain functions, entering letters or characters is required. An
on-screen keyboard appears for entering text.
Select character/on-screen button,
OK Adopt character.
If a small symbol is displayed next to a letter,
further long letters can be selected by pressing
the OK button (2 seconds).
For the selection of special characters use the .-/
field.
To conclude the entry:
Select Adopt,
OK confirm the selection.
With the Loewe app, you can also comfortably enter
addresses or search terms. Simply mark the input
field for this, the Loewe app displays automatically
a keyboard symbol. Open Loewe app keyboard,
enter and confirm.
Entry of characters by remote control
Alternatively to the on-screen keyboard you can also enter the desired
characters by means of the remote control (as with the keypad of a
mobile phone).
Select text entry field.
Under the 1st letter of the name you will see a line
indicating the current input position.
Input position one character to the right (also for
blanks).
Input position one character to the left.
Input the letters one after another. When using the
remote control, press the numerical keys just as on
a mobile phone keypad (0-9) until the desired symbol
is displayed. The available letters are printed on the
individual numeric buttons.
You find the exact key assignment in the character
table in the right column.
To conclude the entry:
Select Adopt,
OK confirm the selection.
Table of characters for entering text by means of the remote
control
Key Characters (uppercase - lowercase)
1
[space] 1
2
A B C 2 Ä Æ Ã Å Ā À Á Ć Ç Č - a b c 2 ä æ ã å ā â à á ć ç č
3
D E F 3 Ė Ë Ē Ę Ê È É - d e f 3 ė ë ē ę ê è é
4
G H I 4 Ï Ī Į Î Ì Í - g h i 4 ï ī į î î ì í
5
J K L 5 - j k l 5
6
M N O 6 Ö O E Õ Ō Ô Ò Ó Ø - m n o 6 ń ñ ö o e õ ō ô ò ó ø
7
P Q R S 7 ß - p q r s 7 ß
8
T U V 8 Ü Ū Û Ù Ú - t u v 8 ü ū û ù ú
9
W X Y Z 9 - w x y z 9
0
. 0 - / _ : + , ; ? ! = & # % ~ @ $ * ’ ( ) ” § \ { } [ ] < > ´ ` ^ |
Menu options
The menu options, where available will open when clicked on. The list
of the menu options contains Settings and Additional Options.
Depending on when the menu options is selected (e.g. channel is displayed, channel list activated, DVB Radio is used, etc.), the selectable
menu items of the menu options may vary.
The menu items of the menu options are described in the respective
chapters.
An example of a menu options of the used channel list:
OK call channel list,
MENU: call menu options.
Select menu option,
OK confirm the selection.
Loewe bild
User handbook
20
On-screen displays
Explanation of keys
An explanation of the main operating keys that can be used at the
moment, can be displayed.
The availability of the key explanation is dependent on the currently
active operating situation.
INFO press longer: show Explanation of keys.
INFO or BACK: hide Explanation of keys.
Explanation of symbols
A text box will temporarily be displayed for screen pages with remote
control symbols in the footnotes (for instance, teletext) as soon as
the symbol is selected
.
Automatic menu info
The automatic menu info provides an info text for the selected menu
item appropriate to the on-screen display that can assist you further
with the operation of your TV set.
An on-screen display is displayed.
The factory setting is that the info display is shown
automatically for each menu item. In this case you can
temporarily hide the info texts with the INFO key.
Permanent clock display
The clock display can be permanently shown. It is always visible as
long as no other display is made.
You can switch the permanent clock display on or off in Home view
under System SettingsטControlטmore ...ט On-screen displays.
Loewe bild
User handbook
21
Initial installation wizard
Initial installation after switching on for the first time
The Initial installation wizard starts automatically with an initial
installation. It may be called repeatedly again (see chapter System
settings,section Extras – Repeat initial installation).
If a parental lock is activated, the access code must be entered
before repeating initial installation (see chapter System settings,
section Control – Parental lock).
For information on navigation within the wizard refer to chapter
General information on menu operation.
First installation wizard routine
The selected settings affect the routine of the Initial installation wizard.
Select desired Menu language.
OK Confirm selection.
Selecting the language of the user guidance is the
wizard’s first step. Then you simply follow the
instructions on your TV screen.
Proceed to next step.
A licence agreement will be displayed.
Select Confirm.
OK Confirm the licence agreement and proceed to
the next step.
Select Energy efficiency.
OK Confirm selection.
Determine how energy efficient your TV set shall
be. The value for the contrast (and thus the
brightness of the background lighting) is adapted
and the automatic dimmer activated or
deactivated depending on the presetting.
The automatic shutdown is active in the mode
Home Mode and Premium mode.
Menu
language
Energy
efficiency
Home mode:
The emphasis for home use is on low energy
consumption. The automatic dimmer is activated.
Premium mode:
This mode optimises the settings to a brighter
environment at a higher energy consumption. The
automatic dimmer is activated.
The use of this energy efficiency setting must be
confirmed afterwards once again.
Shop mode:
The picture settings are aligned to operation in
the presentation room. The automatic dimmer is
deactivated. If the ambient brightness diminishes, the
energy consumption is not reduced.
The use of this energy efficiency setting must be
confirmed afterwards once again.
Not all image and sound settings will be stored in
the shop mode. These settings will be reset to the
factory default settings after re-starting.
The presetting can be changed later in the System
settings under Control ט Energy efficiency.
Proceed to next step.
Select Location of TV set (national defaults
are adopted).
OK Confirm selection.
For certain locations (e.g., Australia), there is finally
a selection screen where you can indicate in which
state/territory the device is being operated.
Proceed to next step.
Select the Operating mode.
OK Confirm selection.
Use the TV set as a TV set:
Continued with Connect antennas cable(s) (see
next page).
Use the TV set just as a monitor:
see chapter Initial installation, section TV set as a
monitor.
Energy
efficiency
(continued)
Location of
TV set
Operating
mode
Initial installation
Loewe bild
User handbook
22
Initial installation
Select option.
OK Confirm selection.
With the selection, specify whether you want to
configure the available network adaptor now.
Configure now: Make settings for network
adaptor and proxy server (see chapter System
settings,section Multimedia / Network –
Network settings).
Do not configure or configure later: Skip
network adaptor configuration.
Proceed to next step.
Select antenna cable.
OK Connect/disconnect antenna cable.
Select the antenna cables that are connected to
your TV.
Ahead of each selected antenna, the symbol
appears.
Cable analog: analogue channels via cable
Terrestrial (DVB-T/T2): digital channels via antenna
Cable (DVB-C): digital channels via cable
Satellite (DVB-S/cable 1): digital channels via satellite
Satellite (DVB-S/cable 2): digital channels via satellite
IPTV: Streaming via network (In-
ternet)
SAT>IP:
digital channel via local network
With the connection sockets ANT SAT 1 / ANT
SAT2
(1
, when the TV set is switched on, it is automatically detected whether an antenna cable is connected. The symbol appears in the menu dialogue
behind the respective antenna cable
.
IPTV / SAT>IP can only be selected if a network-
connection has been configured in a previous step.
Proceed to next step.
Network
configuration
Connect
antennas
cable(s)
The rest of the initial installation wizard routine
depends on the selected antennas (Cable analogue,
DVB-T/T2, DVB-C, DVB-S/S2, IPTV, SAT>IP (ASTRA))
in step Connect antennas cable(s).
The different antennas/types of reception are
described in the following sections of initial installation.
Setting options for reception via Cable analog:
If you have not selected Cable analog in step Connect antenna
cable(s) in the initial installation, proceed to the next section Setting
options for reception via SAT>IP
.
The selection of a Colour standard is only required
when the Location of TV set Other country was
selected. Otherwise, the country-specific default
settings will be preset when selecting the Location
of TV set. This step will be skipped then
Select appropriate colour standard.
OK Confirm selection.
Proceed to next step.
TV/col.
standard
(1
The ANT SAT 2 connection is only available for set types with dual-channel (see chapter Technical data - equipment features for your TV set).
Loewe bild
User handbook
23
Initial installation
Setting options for reception via SAT>IP:
If you have not selected SAT>IP in step Connect antenna cable(s)
in the initial installation, proceed to the next section Setting options
for IPTV reception
.
Select server,
OK Select / deselect the server.
State from which servers you wish to receive your
channels.
Before each selected server, the symbol
appears.
The server converts the antenna television signals
from the reception system into IP signals and
provides them in an existing local IP network.
Proceed to next step.
Server
selection
Setting options for reception via
IPTV
:
If you have not selected IPTV in step Connect antenna cable(s) in
the initial installation, proceed to the next section Setting options
for DVB-T reception.
If more than one receive network is available via IPTV,
you can select the network from which you want to
receive your channels.
Select network,
OK Confirm selection.
Proceed to next step.
Network
selection
(IPTV)
Loewe bild
User handbook
24
Initial installation
Setting options for DVB-T reception:
If you have not selected Terrestrial (DVB-T) in step Connect
antenna cable(s) in the initial installation, proceed to the next section
Setting options for DVB-C reception.
If several networks are available via DVB-T, you can
decide which network you want to receive your
channels from.
Select network,
OK Confirm selection.
Proceed to next step.
Select and adapt settings for DVB-T reception.
OK Confirm selection.
Scrambled
channels
You can state whether coded channels are to be
searched for in the search/update.
Select yes to save all found scrambled channels.
However, these channels can only be received in
connection with a CA module and the appropriate
Smart Card.
The handling of the CA module is described in the
chapter System settings, section Extras – CA
module.
Accept
Logical
Channel
Number
In various countries, digital channels (DVB-T) are
transmitted with a preset channel number per channel, known as Logical Channel Numbers (LCN).
If you select yes here, these default channel slots
will be used and the channels of the preferred signal
source will be sorted as per LCN. The channels in
the channel list can no longer be shifted.
Network
selection
Settings
Supply
voltage
DVB-T
antenna
Select supply voltage no (0V) / yes (5V).
If you use a DVB-T antenna that requires a supply
voltage (active antenna) and which is not already
supplied via a power adaptor, then select yes (5V)
for the antenna’s power supply.
How to align your DVB-T antenna is described in
chapter System settings, section Connections
– Antenna DVB.
Proceed to next step.
Loewe bild
User handbook
25
Initial installation
Setting options for DVB-C reception:
If you have not selected Cable (DVB-C) in step Connect antenna
cable(s) in the initial installation, proceed to the next section Setting
options for DVB-S reception.
If several networks are available via DVB-C, you can
decide which network you want to receive your
channels from.
The normal DVB-C settings are derived from the
selection of the location or network and do not need
to be changed.
Exactly which of the following settings are present is
dependent on which network is selected.
Select network.
OK Confirm selection.
Proceed to next step.
Select and adapt settings for DVB-C
reception.
OK Confirm selection.
Scrambled
channels
You can state whether coded channels are to be
searched for in the search/update.
Select yes to save all found scrambled channels.
However, these channels can only be received in
connection with a CA module and the appropriate
Smart Card.
The handling of the CA module is described in the
chapter System settings, section Extras – CA
module.
Search
method
If you select Frequency search here, a search is
performed for all receivable channels.
With Network search, only the channels which
the networks supply are searched - either for
all receivable networks or only for the particular
network specified under Network ID.
Start
frequency
The DVB channels are only searched for in the
frequency range above the start frequency.
Network
selection
Settings
Network ID
If you select none here, DVB signals of all current
transmitter networks are searched automatically
(recommended for most cable networks).
If, on the other hand, you specify a certain network ID
(necessary in the cable networks of some countries),
only DVB signals of this broadcasting network are
searched for automatically.
Your cable provider has the information you need.
Accept
Logical
Channel
Number
In various countries, digital channels (DVB-C) are
transmitted with a preset channel number per channel, known as Logical Channel Numbers (LCN).
If you select yes here, these default channel slots
will be used and the channels of the preferred signal
source will be sorted as per LCN. The channels in
the channel list can no longer be shifted.
Proceed to next step.
Loewe bild
User handbook
26
Initial installation
Setting options for DVB-S reception:
If you have not selected Satellite (DVB-S/cable x) in step Connect
antenna cable(s) in the initial installation, proceed to the next section
Setting options for all types of reception.
If several networks are available via DVB-S, you can
decide which network you want to receive your
channels from.
Select network.
OK Confirm selection.
Proceed to next step.
Select Only one antenna cable or Two antenna
cables.
OK Confirm selection.
Select here whether you have one or two satellite
antenna cables available. If two satellite antenna
cables are available, please connect them to the
ANT SAT1 and ANT SAT2 sockets of the TV set.
If only one is available, please connect it to the
ANT SAT1 socket.
Proceed to next step.
Network
selection
Number of
satellite
antenna
cables
Selecting the satellite system.
OK Confirm selection.
Specify how you receive which satellite(s) (single
satellite or type of satellite system). Ask your
dealer in this regard.
The normal DVB-S settings are derived from the
selection of the location and do not need to be
changed in most cases.
Single
satellite
Reception of a single satellite via a connected LNC
(LNB).
2 satellites
on 22 kHz
switchbox
Reception of two different satellites with two LNCs
(LNBs) which are connected to the TV set by a 22
kHz switchbox.
2 satellites
on toneburst
switch
Reception of two different satellites with two LNCs
(LNBs) which are connected to the TV set by a
toneburst switch.
Max. 4
satellites
on DiSEqC
multiswitch
The TV set controls a DiSEqC multiswitch to which
up to four LNCs (LNBs) for different satellites are
connected.
DiSEqC
one cable
communal
system
Select setting if the TV set is connected to a DiSEqC
single-cable system (according to EN 50494). Several
Sat receivers can be connected to one Sat cable.
other
communal
installation
Select setting if the TV set is connected to a
single-cable system (without DiSEqC). Several
Sat receivers can be connected to one Sat cable.
Contrary to a DiSEqC one cable communal system
there are restrictions in the range of certain reception
frequencies in "common" single-cable community
systems.
Proceed to next step.
The rest of the initial installation wizard routine
depends on the selected satellite system in step Select
satellite installation.
The different satellite systems are described in the
following sections of initial installation.
Select
satellite
installation
Loewe bild
User handbook
27
Initial installation
Setting options for the satellite system (single satellite):
Select satellite,
OK Confirm selection.
Proceed to next step.
Select Dual band (low/high) or Single band.
OK Confirm selection.
Here you specify if you use a Dual Band (Universal)
LNB or a Single LNB.
Proceed to next step.
Set LNB frequencies.
OK Adopt settings.
The setting of the LNB frequency is only called
when you have used the setting Single band
in step Dual / single band.
Normally, you do not need to change the values
for high and low band, unless the LNC (LNB) of
your satellite system uses a different oscillator
frequency (important for the frequency display).
Proceed to next step.
Proceed to section Setting options for DVB-S
reception (continued).
Select
single satellite
Dual/single
band
LNC
frequencies
Setting options for the satellite system (2 satellites on 22
kHz switchbox / 2 satellites on toneburst switch):
Mark Satellite 1 / Satellite 2,
select satellite.
OK Adopt settings.
Proceed to next step.
Proceed to section Setting options for DVB-S
reception (continued).
Satellite
selection
Loewe bild
User handbook
28
Initial installation
Setting options for the satellite system
(max. 4 satellites on DiSEqC multiswitch):
Select Automatic or Manual depending on
whether your DiSEqC system should be configured automatically or manually.
OK Accept settings.
Proceed to next step.
For manual configuration, continue in the next column.
Search for available satellites occurs via automatic
configuration.
Proceed to next step.
Or:
Select Satellite selection to select the
satellites used from the list.
Proceed to section Setting options for all types of
reception.
Automatic
DiSEqC
multiswitch
configuration
Automatic
DiSEqC
multiswitch
configuration
Select and adapt settings for the DiSEqC
multiswitch.
OK Adopt settings.
Repeat rate
The refresh rate determines how often a DiSEqC
command is output. A refresh is only necessary with
cascaded systems.
Control
voltage
The control voltage controls the switching of the
polarisation level (horizontal/vertical) in non-DiSEqC
capable components (e.g., control of single LNBs via
DiSEqC multiswitch).
22kHz signal
The 22 kHz signal controls the switching between
high and low band in the Band setting. The Position
setting controls the selection of the satellites in nonDiSEqC capable components.
Toneburst
The Toneburst controls the selection of the satellites
in non-DiSEqC but Toneburst capable components
with the Position and Option settings.
Proceed to next step.
Mark Satellite 1 ... Satellite 4,
Select satellite.
OK Adopt settings.
Proceed to next step.
Set LNB frequencies.
Normally, you do not need to change the values.
OK Adopt settings.
Proceed to next step.
Proceed to section Setting options for DVB-S
reception (continued).
Settings
DiSEqC
multiple
switch
Satellite
selection
Loewe bild
User handbook
29
Initial installation
Setting options for the satellite system
(DiSEqC one cable communal system):
Select One channel or Two channels.
OK Confirm selection.
Here you specify if you use one or two transmission
channels in your one cable communal system.
In case of two channels - as far as they are
available in your system - different channels can
be simultaneously viewed on the main picture and
on PIP.
You get more information on your system from
your dealer.
Proceed to next step.
Select DiSEqC single cable communal
installation.
OK Confirm selection.
Proceed to next step.
Select satellites from list,
OK Confirm selection.
Proceed to next step.
Number of
system
channel used
DiSEqC
one cable
communal
installation
Satellite
selection
.
Set LNB frequencies.
Normally, you do not need to change the
values unless the LNC (LNB) of your satellite
system uses a different oscillator frequency
(important for the frequency display).
OK Adopt settings.
Proceed to next step.
Select and adjust settings for the DiSEqC
single cable communal installation.
OK Adopt settings.
The manual registration must be made for both ANT
SAT jacks when either two DVB-S antenna cables or
two system channels are used.
Transmission
channel
Select the desired transmission channel.
Transmission
frequency
Select the corresponding transmission frequency.
PIN protection
If your system is designed for it, it is possible to
protect your used transmission data from use by
other subscribers with a PIN.
DiSEqC
envelope
mode
Should your DiSEqC system occasionally show
problems during channel switching, you can switch
on the DiSEqC envelope mode to test whether the
switching problems then will no longer occur.
Define/
change PIN
Here you can determine and change the PIN for
PIN protection. Only possible, when yes has been
selected for PIN protection.
Proceed to next step.
Proceed to section Setting options for DVB-S
reception (continued).
LNB
frequencies
Manual
registration
(for socket
ANT SAT)
Loewe bild
User handbook
30
Initial installation
Setting options for the satellite system (other communal
installation):
Select satellite.
OK Confirm selection.
Proceed to next step.
Select and adapt settings.
OK Confirm selection.
LNC
frequency
Normally, you do not need to change the values for
high and low band, unless the LNC (LNB) of your
satellite system uses a different oscillator frequency
(important for the frequency display).
Supply
voltage
If your set is connected to a single-cable system
without external voltage supply, you can connect
the antenna supply (13V or 18V / max. 500mA).
Proceed to next step.
Proceed to section Setting options for all types of
reception.
Select
single satellite
LNB
frequencies,
Supply
voltage
