Listen Technologies LA-209-01 Data Sheet
LA-209
5 VDC Intelligent 12-Unit Charging Tray Replacement Power Supply
Configuration:
LA-209-01 Intelligent 12-Unit Charging Tray
Replacement Power Supply (North America)*
LA-209-02 Intelligent 12-Unit Charging Tray
Replacement Power Supply (Asia, UK)*
LA-209-03 Intelligent 12-Unit Charging Tray
Replacement Power Supply (Euro)*
LA-209-04 Intelligent 12-Unit Charging Tray
Replacement Power Supply (Australia)*
*01, 02, 03, and 04 designation refers to
international plug type (type B, G, E, and I) for
the power supply.
Product Overview:
The LA-209-01 allows you to keep a backup unit handy or replace the power supply for your Listen Technologies 12-unit
charging tray/case (LA-381-01 or oLA-380-01). The steady 5 VDC power safely charges multiple units simultaneously.
Highlights:
Safely powers iDSP multi-unit charging tray or charging/carrying case
Direct replacement for the LA-380-01 or LA-381-01
Reliable 5 VDC power for consistent charging
North American plug standard, other versions available upon request
Includes:
One (1) LA-209-01 Intelligent 12-Unit Charging Tray Power Supply
Product Specification: 5 VDC Intelligent 12-Unit Charging Tray Replacement Power Supply
Power
Power Supply Input 100-240VAC, 50-60 Hz
Power Supply Output 5.0 VDC, 8 A, 40 W
Physical
Color Black
Powered by TCPDF (www.tcpdf.org)
Shipping Weight 2.0 lbs. (0.91 kg)
Cable Length 72 in. (182.9 cm) Input Power Cord, 45 in (114.3 cm) Output Cord
Dimensions (H x W x D) 1.35 in. x 5.6 in. x 2.4 in. (34.3 mm x 142.3 mm x 61 mm)
Unit Weight 1.0 lbs. (454 g)
Compliance
Power Supply Compliance UL, CE, RoHS
Listen Technologies Corporation * 14912 Heritage Crest Way * Bluffdale * Utah 84065-4818 U.S.A.
5 VDC Intelligent 12-Unit Charging Tray Replacement Power Supply Page 1 of 1
+1.801.233.8992 * +1.800.330.0891 North America * +1.801.233.8995 Fax
Listen Technologies Corporation All rights reserved 91407 - Created December 12, 2019
