Installation & Parts Manual
2" & 3" High Capacity Strainers
For Class 1, Petroleum Applications
Installation: M200-20
www.lcmeter.com
Table of Contents
Description Page Number
Introduction ......................................................... 2
What LC Strainers Do............................. 2
How LC Strainers Work .......................... 2
Features ................................................. 2
Installation ...........................................................3
Maintenance........................................................ 4-5
Torque Chart ....................................................... 5
Description Page Number
2" High Capacity Strainer .................................... 6-7
Dimensional View ................................... 6
Exploded View........................................ 7
3" High Capacity Strainer .................................... 8-9
Dimensional View ................................... 8
Exploded View........................................ 9
Troubleshooting................................................... 10-11
Publication Updates and Translations
The most current English versions of all Liquid Controls publications are available on our website, www.lcmeter.com.
It is the responsibility of the Local Distributor to provide the most current version of LC Manuals, Instructions, and
Specification Sheets in the required language of the country, or the language of the end user to which the products are
shipping . If there are questions about the language of any LC Manuals, Instructions, or Specification Sheets, please
contact your Local Distributor.
!!
WARNING WARNING
!
WARNING
!!
WARNING WARNING
• Before using this product, read and understand the instructions.
• Save these instructions for future reference.
• All work must be performed by qualified personnel trained in the proper application, installation, and
maintenance of equipment and/or systems in accordance with all applicable codes and ordinances.
• Failure to follow the instructions set forth in this publication could result in property damage, personal injury,
or death from fire and/or explosion, or other hazards that may be associated with this type of equipment.
What LC Strainers Do
Strainers protect meters from serious damage caused
by burrs dislodged from new piping, pipe scale, or foreign
material.
The strainer’s initial cost is good insurance against the
cost of down time or replacement parts incurred from a
damaged meter.
A meter strainer installed on the inlet side is necessary
even when a coarse strainer on the upstream side of the
pump is included in the system.
Strainers are not meant to be used as a system filter but
as protection for the meter element itself.
How LC Strainers Work
As liquid product enters the strainer housing from the
supply line, it is routed through the strainer basket. The
strainer basket is a two-ply screen. The inner screen is
made of fine mesh of either 20, 40, 80, 100, or 200
squares per inch. The outer screen works as a backing.
It gives reinforcement and support to the fine mesh inner
screen.
Liquid product is filtered and exits the strainer basket
through the screens into the strainer housing. The liquid
then passes through the outlet of the strainer and into
the inlet of the meter. Any debris larger than the mesh in
the basket is trapped.
A properly maintained strainer helps to ensure the system
owner years of trouble free service.
Features
LC markets a wide variety of strainers to fit most meters
in terms of capacity, pipe size, working pressure and
metallurgical compatibility. The design advantages of a
Liquid Controls strainer include:
• Strainer baskets with an unusually high open basket
area to pipe area ratio, resulting in minimum
restriction of flow and low pressure loss.
• A choice of stainless steel strainer basket mesh sizes.
Part Number Description
A3430 ............. 40 Mesh
A3431 ............. 80 Mesh
A3432 ............. 100 Mesh
A3433 ............. 20 Mesh
A3434 ............. 200 Mesh
2
Installation
Flush All New Systems
Flushing the system before the meter has been installed
is the preferred first step.
For new systems that don’t currently have a meter
installed, thoroughly flush the lines until the system is
purged of all foreign materials. See “Maintenance” for
disassembly and reassembly instructions.
For new systems with a meter installed, remove the
meter’s internal element components and strainer basket.
(NOTE: The meter housing cannot be removed in this
instance.) Thoroughly flush the lines until the system is
purged of all foreign materials.
Location for the Strainer
Plan a location for the strainer in the system providing
for the following requirements:
• Make sure there is no pipe strain imposed upon the
strainer or any other component part of the meter
assembly. This means that the meter and its
accessories must not support the weight of the piping.
Installing
Install the strainer on the inlet side of the meter. Bolt the
strainer outlet to the inlet flanged connection of the meter.
Then bolt the inlet piping to the inlet flanged connection
of the strainer.
Piping
New or repaired piping can be the source of welding slag
or other foreign material that will block or rupture the
strainer screen. The strainer should be checked daily
during the first 100 hours of operation or until no more
debris is found in the strainer.
Inspection
Frequent strainer basket inspection and cleaning is
required to insure proper operation.
Follow the steps outlined in “Maintenance” on the
following pages.
• Plan for enough space to allow clearance so that the
strainer basket cover and strainer basket can be
easily removed.
!!
! WARNING
!!
All internal pressures must be relieved before disassembly of the meter, strainer, air eliminator,
any valves in the system, the pulse output device, or the front and rear covers. LINE PRESSURE
MUST BE 0.0 PSI. Refer to your meter manual for instructions on reducing the internal pressure.
Personal injury or death may result from working on a system under pressure.
3
Maintenance
!!
! WARNING
!!
All internal pressures must be relieved before disassembly of the meter, strainer, air eliminator,
any valves in the system, the pulse output device, or the front and rear covers. LINE PRESSURE
MUST BE 0.0 PSI. Refer to your meter manual for instructions on reducing the internal pressure.
Personal injury or death may result from working on a system under pressure.
It is very important to follow the strainer preventive
maintenance procedures to protect the strainer as well
as the metering system. Foreign matter that builds up
inside the strainer, including ice, can cause damage to
the strainer and the metering system. When foreign
matter builds up inside the strainer, it can cause pressure
to build up inside the strainer. This pressure can cause
the strainer screen to rupture. Foreign matter can then
enter the metering chamber. This can cause serious
damage to the meter, and may result in failure of the
meter.
The following strainer preventive maintenance
procedures will keep your strainer functioning properly,
keep strainer repair costs to a minimum, and insure the
protection of your metering system.
Newly installed or repaired systems
• Check the strainer daily during the first 100 hours of
operation or until no more debris is found in the
strainer.
• New or repaired piping can be the source of welding
slag or other foreign particles that can block or rupture
the strainer screen.
• Once a system is cleaned out, the strainer should
be checked several times every season. The
frequency depends on the specific service conditions,
throughput, and product cleanliness.
Disassembling the Strainer
(See Page 7 for Item Numbers)
1. Carefully clean around strainer basket cover plate
(2). Remove all foreign matter.
2. Remove the four bolts (7) and washers (8) from the
end cover plate.
3. Remove the end cover plate (2) and O-Ring (4) from
the strainer housing.
4. Remove the strainer basket. This may dislodge dirt
and particles into the strainer housing.
5. Check inside the strainer housing for any foreign
material. Be sure to wipe the housing clean with a
clean, soft, shop rag.
6. Clean the strainer basket by flushing the basket with
a liquid cleaning agent suited for your application. A
soft brush may be used to dislodge imbedded
particles. If the imbedded particles cannot be
removed, replace the basket. Never tap the basket
ends on a hard surface to dislodge particles. This
may dent the basket and make reassembly difficult
or cause improper sealing.
7. Clean the inner face of cover plate, mating face of
the strainer body, and seal ring with a clean, soft,
shop rag.
8. Make sure the O-Rings are cleaned of all dirt and
grime. Check the O-Rings for damage. If the ORings cannot be cleaned or are damaged or frayed,
replace them. Never reuse Teflon O-Rings. Always
replace them even if they appear to be in good
condition.
4
