A Division of Cisco Systems, Inc.

Wireless-G

Voice

IP Phone

User Guide

Model No.

WIP330

Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2005 Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders.

WARNING: This product contains chemicals, including lead, known to the State of California to cause cancer, and birth defects or other reproductive harm. Wash hands after handling.

How to Use this Guide

The User Guide to the Wireless-G IP Phone has been designed to make understanding networking with the IP Phone easier than ever. Look for the following items when reading this User Guide:

This exclamation point means there is a caution or warning and is something that could damage your property or IP Phone.

This question mark provides you with a reminder about something you might need to do while using the IP Phone.

This checkmark means there is a note of interest and is something you should pay special attention to while using the IP Phone.

In addition to these symbols, there are definitions for technical terms that are presented like this:

Also, each figure (diagram, screenshot, or other image) is provided with a figure number and description, like this:

Figure numbers and descriptions can also be found in the “List of Figures” section.

word: definition.

Figure 0-1: Sample Figure Description

Wireless-G IP Phone

WIP330_V1.1-UG-60120NC JL

Wireless-G IP Phone

Chapter 1: Introduction 1

Welcome 1 What’s in This User Guide? 1

Chapter 2: Getting to Know the Wireless-G IP Phone 3

The Bottom Panel 3 The Front and Side Panels 4 The Back Panel 6

Chapter 3: Installing and Using the Wireless-G IP Phone 7

Overview 7 Inserting the Battery into the Wireless-G IP Phone 7 Powering on the Wireless-G IP Phone 8 Navigating the Wireless-G IP Phone 10 Setting up the Wireless-G IP Phone 12 Using the Wireless-G IP Phone 22

Chapter 4: Configuring the Wireless-G IP Phone 25

Instructions for Configuring the Wireless-G IP Phone 25 Status Information 27 Settings of the Wireless-G IP Phone 28

Appendix A: Troubleshooting 61

Common Problems and Solutions 61 Frequently Asked Questions 66

Appendix B: Glossary 67 Appendix C: Specifications 71 Appendix D: Warranty Information 73 Appendix E: Regulatory Information 75 Appendix F: Contact Information 89

Wireless-G IP Phone

List of Figures

Figure 2-1: Bottom Panel 3 Figure 2-2: Front Panel 4 Figure 2-3: Symbol Selection 5 Figure 2-4: Side Panel 6 Figure 2-5: Back Panel 6 Figure 3-1: Press the Button 7 Figure 3-2: Insert the Battery 7 Figure 3-3: Connect the Power 8 Figure 3-4: Front Panel 10 Figure 3-5: Symbol Selection 11 Figure 3-6: Scan for Wireless Networks 12 Figure 3-7: Select Wireless Network 12 Figure 3-8: Connect to Wireless Network 13 Figure 3-9: Enter WEP Key (Secured Network) 13 Figure 3-10: Enter WPA Key (Secured Network) 13 Figure 3-11: Successful Connection 13 Figure 3-12: Select Menu 14 Figure 3-13: Select SIP Settings 14 Figure 3-14: Edit Proxy IP 15 Figure 3-15: Save Proxy IP 15 Figure 3-16: Save Proxy Port 16 Figure 3-17: Save Register Proxy IP 16 Figure 3-18: Save Register Proxy Port 17 Figure 3-19: Save Outbound Proxy IP 17

Figure 3-20: Edit Outbound Proxy Port 18 Figure 3-21: Save Expire Time 18 Figure 3-22: Save Phone Number 19 Figure 3-23: Save User Name 19 Figure 3-24: Save Password 20 Figure 3-25: Save SIP Settings 20 Figure 3-26: Return to Standby Screen 21 Figure 3-27: Standby Screen 21 Figure 3-28: Call Connected 22 Figure 3-29: Line Options 22 Figure 3-30: Second Call 23 Figure 3-31: Unlock Keys 23 Figure 4-1: Front Panel 25 Figure 4-2: Symbol Selection 26 Figure 4-3: Standby Screen 27 Figure 4-4: Standby Screen 28 Figure 4-5: Main Menu 28 Figure 4-6: Call Log 29 Figure 4-7: Call Log Options 29 Figure 4-8: Type of Phone Number 29 Figure 4-9: Select Phone Book 32 Figure 4-10: Phone Book 32 Figure 4-11: Phone Book Options 32 Figure 4-12: Add Person 33

Figure 4-13: Enter Name 33 Figure 4-14: Select Network Settings 34 Figure 4-15: Network Settings - DHCP 34 Figure 4-16: Network Settings - Fixed IP 35 Figure 4-17: Enter IP Address 35 Figure 4-18: Edit Subnet Mask 35 Figure 4-19: Enter Subnet Mask 35 Figure 4-20: Wireless 36 Figure 4-21: Scanning for Wireless Networks 36 Figure 4-22: List of Wireless Networks 36 Figure 4-23: Connecting to Wireless Network 37 Figure 4-24: Enter WEP Key (for Secured Network) 37 Figure 4-25: Enter WPA Key (for Secured Network) 37 Figure 4-26: Connecting to Wireless Network 37 Figure 4-27: Select Default Hotspot 38 Figure 4-28: Detect Hotspot 39 Figure 4-29: Connecting to Hotspot 39 Figure 4-30: Getting IP Address 39 Figure 4-31: Select IE Browser 39 Figure 4-32: Wi-Fi Profiles 40 Figure 4-33: Edit SSID 40 Figure 4-34: Edit Wireless Mode 40 Figure 4-35: Change Authentication Mode 41 Figure 4-36: Edit WEP Key 41 Figure 4-37: Enter WEP Key 41 Figure 4-38: Change EAP Type (802.1x) 41

Wireless-G IP Phone

Figure 4-39: Edit EAP Type (WPA-PSK) 42 Figure 4-40: Change EAP Type (WPA-PSK) 42 Figure 4-41: Enter SSID 42 Figure 4-42: Change Transmit Key 43 Figure 4-43: Edit WPA Key 43 Figure 4-44: Profile Added 44 Figure 4-45: Select Hotspot 45 Figure 4-46: Edit User Name 45 Figure 4-47: Select Phone Settings 46 Figure 4-48: Phone Settings 46 Figure 4-49: Ring Options 46 Figure 4-50: Ring Types 46 Figure 4-51: Keypad Tone 47 Figure 4-52: Wallpaper 47 Figure 4-53: Change Date 48 Figure 4-54: Change Clock 48 Figure 4-55: Change Time Format 48 Figure 4-56: Change Clock Type 48 Figure 4-57: Select Time Zone 49 Figure 4-58: Change Time Zone 49 Figure 4-59: Select NTP Server 49 Figure 4-60: Enter Name of NTP Server 49 Figure 4-61: Select Language 50 Figure 4-62: Language 50 Figure 4-63: Phone Password 50 Figure 4-64: Select Upgrade 51

Wireless-G IP Phone

Figure 4-65: Edit Download URL 51 Figure 4-66: Upgrade in Progress 51 Figure 4-67: Upgrade Successful 51 Figure 4-68: Edit Proxy IP 52 Figure 4-69: Enter Proxy IP 52 Figure 4-70: Enter Register Proxy IP 52 Figure 4-71: Enter Register Proxy Port 52 Figure 4-72: Change Outbound Proxy IP 53 Figure 4-73: Edit Outbound Proxy Port 53 Figure 4-74: Change Expire Time 53 Figure 4-75: Change Phone Number 53 Figure 4-76: Change User Name 54 Figure 4-77: Change Password 54 Figure 4-78: Edit Payload Type 54 Figure 4-79: Web Site 55 Figure 4-80: Visit Web Site 55 Figure 4-81: Auto-Scroll Option 55 Figure 4-82: Web Site Options 56 Figure 4-83: Edit Web Site 56 Figure 4-84: Add Web Site 57 Figure 4-85: Web Cam 58 Figure 4-86: Web Cam Options 58 Figure 4-87: Edit Web Cam 58 Figure 4-88: Add Web Cam 58 Figure 4-89: Information 60

Chapter 1: Introduction

Welcome

Wireless-G IP Phone

Thank you for choosing the Linksys Wireless-G IP Phone. It will allow you to make phone calls using your broadband connection, whether you are at home, in your office, or at a public hotspot.

How does the IP Phone do this? It connects to your wireless router or gateway, so telephone service is delivered through your cable or DSL Internet connection. You can also surf the Internet with its built-in web browser and backlit, full-color screen.

But what does all of this mean? Networks are useful tools for sharing Internet access and computer resources. Your voice calls can share your high-speed Internet connection. You will be able to make phone calls using the account you set up with your Internet phone service provider, even while you’re surfing the Internet on your computer. So, networks not only are useful in homes and offices, but also can be fun.

Use the instructions in this User Guide to help you connect the IP Phone after you have set up an account with your Internet phone service provider. These instructions should be all you need to get the most out of the Wireless-G IP Phone.

What’s in This User Guide?

This guide covers the steps for installing the Wireless-G IP Phone.

• Chapter 1: Introduction This chapter describes the IP Phone’s applications and this User Guide.

Chapter 1: Introduction Welcome

ip (internet protocol): a protocol used to send data over a network.

network: a series of computers or devices connected for the purpose of data sharing, storage, and/or transmission between users.

NOTE: For information about your Internet phone service, refer to the materials provided by your Internet phone service provider.

Wireless-G IP Phone

• Chapter 2: Getting to Know the Wireless-G IP Phone This chapter describes the physical features of the IP Phone.

• Chapter 3: Installing and Using the Wireless-G IP Phone This chapter explains how to install the IP Phone and use it.

• Chapter 4: Configuring the Wireless-G IP Phone This chapter discusses how to configure the IP Phone’s settings.

• Appendix A: Troubleshooting This appendix describes some potential problems and solutions, as well as frequently asked questions, regarding use of the IP Phone.

• Appendix B: Glossary This appendix gives a brief glossary of terms frequently used in networking.

• Appendix C: Specifications This appendix provides the technical specifications for the IP Phone.

• Appendix D: Warranty Information This appendix supplies the warranty information for the IP Phone.

• Appendix E: Regulatory Information This appendix supplies the regulatory information regarding the IP Phone.

• Appendix F: Contact Information This appendix provides contact information for a variety of Linksys resources, including Technical Support.

Chapter 1: Introduction

What’s in This User Guide?

Chapter 2: Getting to Know the Wireless-G IP Phone

The Bottom Panel

The IP Phone’s headset jack and USB port are located on the bottom panel.

Wireless-G IP Phone

Headset Jack

Figure 2-1: Bottom Panel

Headset Jack This jack allows you to connect a headset.

USB Port The USB port allows you to attach the included power adapter.

Chapter 2: Getting to Know the Wireless-G IP Phone The Bottom Panel

USB Port

Wireless-G IP Phone

The Front and Side Panels

The power LED is located at the top of the IP Phone, while its buttons are located on the front and side panels.

Power LED Blue/Red/Purple. The LED is a solid blue when the IP Phone is powered on and ready

for phone calls. It flashes red when the IP Phone is not ready for phone calls.

The LED alternates between blue and purple when the IP Phone is powered off and charging.

Power LED

The buttons of the IP Phone are described in this table.

Icon Button Name Function

Soft Key Selects the appropriate action

shown on the left- or righthand side of the screen

Navigation Pad and Center Selection Key

Call Uses Internet phone line

Lets you navigate menus and select your choices

Controls cursor for its web browser

Navigation Pad and Center Selection Key

Different Key Choices or + Sign

Soft Key

Call

Figure 2-2: Front Panel

Chapter 2: Getting to Know the Wireless-G IP Phone

The Front and Side Panels

Soft Key

Power or End Call

Enter Symbol or Space

Icon Button Name Function

Power or End Call Press and hold this button for

two seconds to power the IP Phone on or off.

Ends the call or exits the current menu

Different Key Choices or + Sign

Enter Symbol or Space

Chapter 2: Getting to Know the Wireless-G IP Phone The Front and Side Panels

To enter an entry or setting, use the keypad. Keys 1-9 can represent uppercase letters (A, B, C), lowercase letters (a, b, c), or numbers (1, 2, 3). Press the * (star) key to switch between the different choices.

Press the * (star) key twice to enter the + sign.

Press the # (pound) key to open the Symbol Selection menu. Use the navigation pad to move through the menu. When you have the appropriate symbol highlighted, press the center selection key.

Press the # (pound) key twice to enter a space.

Wireless-G IP Phone

Figure 2-3: Symbol

Selection

Wireless-G IP Phone

Icon Button Name Function

Volume Increases or decreases the

volume

The Back Panel

The IP Phone’s battery compartment is located on the back panel of the IP Phone. For directions on how to insert the battery, refer to “Chapter 3: Installing and Using the Wireless-G IP Phone.”

Volume

Figure 2-4: Side Panel

Battery Compartment

Figure 2-5: Back Panel

Chapter 2: Getting to Know the Wireless-G IP Phone

The Back Panel

Wireless-G IP Phone

Chapter 3: Installing and Using the Wireless-G IP Phone

Overview

This chapter provides instructions for first-time installation and use of the IP Phone. You will insert the battery into the IP Phone and then set it up for your wireless network and Internet phone service. Then you will be able to make and receive Internet phone calls.

Inserting the Battery into the Wireless-G IP Phone

To insert the battery, follow these instructions:

1. Remove the cover of the battery compartment. Push down on the button and slide the cover downward.

2. Insert the battery. Make sure the metal contacts of the battery line up with the metal contacts of the battery compartment.

3. Insert the door and slide it upward until it snaps into place.

Proceed to the next section, “Powering on the Wireless-G IP Phone.”

Button

Chapter 3: Installing and Using the Wireless-G IP Phone Overview

Figure 3-1: Press

the Button

Metal Contacts

Figure 3-2: Insert

the Battery

Wireless-G IP Phone

Powering on the Wireless-G IP Phone

Make sure you have the account information, including necessary IP Phone settings, supplied by your Internet phone service provider. If you already have an account set up with your Internet phone service provider, then proceed to step 1. If you do not have an account, then go to the website of your Internet phone service provider and sign up for service. After you have set up an account, proceed to step 1.

1. Make sure you have the account information, including necessary IP Phone settings, supplied by your Internet phone service provider.

2. Plug the USB mini-B connector of the included power adapter into the USB mini-B port of the IP Phone. Then connect the power adapter to a standard electrical outlet.

Figure 3-3: Connect the Power

Chapter 3: Installing and Using the Wireless-G IP Phone

Powering on the Wireless-G IP Phone

3. The power LED will flash, alternating between blue and purple. For the initial charge, allow the battery to charge for at least 10 hours, so the battery will have a full charge, which is indicated by a solidly lit power LED. This maximizes battery performance and life.

NOTE: When the battery is low on power, it will emit one warning sound or vibration, unless the Ring Type is set to Silent. (For more information about Ring Types, refer to Chapter 4: Configuring the Wireless-G IP Phone.”)

When the battery is fully charged, proceed to “Navigating the Wireless-G IP Phone.”

Wireless-G IP Phone

Chapter 3: Installing and Using the Wireless-G IP Phone Powering on the Wireless-G IP Phone

Wireless-G IP Phone

Navigating the Wireless-G IP Phone

Review the descriptions of the buttons you will use to navigate menus and select your choices.

Icon Button Name Function

Soft Key Press the left or right soft key

to select the appropriate action shown on the left- or righthand side of the screen.

Navigation Pad and Center Selection Key

Call Uses Internet phone line

Power or End Call To exit a menu without making

To navigate menus and control the cursor for the web browser, use the navigation pad.

Use the center selection key to make menu choices.

Navigation Pad and Center Selection Key

changes, press this button.

Call

Power LED

Key Choice

Soft KeySoft Key

Power or End Call

Different Key Choices or + Sign

Enter Symbol or Space

Figure 3-4: Front Panel

Chapter 3: Installing and Using the Wireless-G IP Phone

Navigating the Wireless-G IP Phone

Icon Button Name Function

Different Key Choices or + Sign

Enter Symbol or Space

For more details, refer to “Chapter 2: Getting to Know the Wireless-G IP Phone.”

Press the * (star) key twice to enter the + sign.

Press the # (pound) key to open the Symbol Selection menu. Use the navigation pad to move through the menu. When you have the appropriate symbol highlighted, press the center selection key.

Press the # (pound) key twice to enter a space.

Proceed to “Setting up the Wireless-G IP Phone.”

Wireless-G IP Phone

Figure 3-5: Symbol

Selection

Chapter 3: Installing and Using the Wireless-G IP Phone Navigating the Wireless-G IP Phone

Wireless-G IP Phone

Setting up the Wireless-G IP Phone

Before you begin, make sure your network has an active Internet connection.

1. Press and hold the Power button for two seconds.

2. The IP Phone will boot up and automatically scan for wireless networks.

3. A list of wireless networks will be displayed and show their wireless network names (also known as Service Set Identifier or SSID), security status (a lock indicates wireless security), and signal strength, which is indicated by a bar graph.

Scroll through the network choices, and press the center selection key (in the middle of the navigation pad) to select the wireless network you want to use.

If the network you want is not shown, select Rescan for a new scan.

Figure 3-6: Scan for

Wireless Networks

Figure 3-7: Select Wireless Network

Chapter 3: Installing and Using the Wireless-G IP Phone

Setting up the Wireless-G IP Phone

4. The IP Phone will automatically connect to the network you have selected.

If WEP security is enabled on the selected network, a new screen will appear. Using the navigation pad, select the appropriate transmit key number and then move to the WEP Key field. Enter the network’s WEP key. Press the center selection key.

If WPA security is enabled on the selected network, a new screen will appear. Enter the network’s WPA key. Press the center selection key.

Wireless-G IP Phone

5. You will be notified when the IP Phone has connected to the network, and a checkmark will appear next to the name of the network.

Select Exit.

Chapter 3: Installing and Using the Wireless-G IP Phone Setting up the Wireless-G IP Phone

Figure 3-8: Connect to

Wireless Network

Figure 3-10: Enter WPA Key (Secured Network)

Figure 3-9: Enter WEP

Key (Secured Network)

Figure 3-11: Successful

Connection

Wireless-G IP Phone

6. The standby screen will appear. Select Menu.

7. Phone Settings will be highlighted. Navigate the menu choices, and then select SIP Settings. (SIP stands for Session Initiation Protocol.)

Figure 3-12: Select Menu

Figure 3-13: Select SIP

Settings

Chapter 3: Installing and Using the Wireless-G IP Phone

Setting up the Wireless-G IP Phone

8. A list of SIP settings will be displayed. For the Proxy IP setting, select Edit.

NOTE: The Proxy IP address and other information should have been supplied by

your Internet phone service provider. If you do not have this information, contact your Internet phone service provider.

9. Enter the Proxy IP address in the new window, and then press the center selection key.

Wireless-G IP Phone

Figure 3-14: Edit Proxy

Chapter 3: Installing and Using the Wireless-G IP Phone Setting up the Wireless-G IP Phone

Figure 3-15: Save Proxy

Wireless-G IP Phone

10. Scroll down to Proxy Port, and select Edit.

11. Enter the Proxy Port number address in the new window, and then press the center selection key.

12. Scroll down to Register Proxy IP, and select Edit.

13. Enter the Register Proxy IP address in the new window, and then press the center selection key.

Figure 3-16: Save Proxy

Port

Figure 3-17: Save

Chapter 3: Installing and Using the Wireless-G IP Phone

Setting up the Wireless-G IP Phone

14. Scroll down to Register Proxy Port, and select Edit.

15. Enter the Register Proxy Port number in the new window, and then press the center selection key.

16. Scroll down to Outbound Proxy IP, and select Edit.

17. Enter the Outbound Proxy IP address in the new window, and then press the center selection key.

Wireless-G IP Phone

Figure 3-18: Save

Chapter 3: Installing and Using the Wireless-G IP Phone Setting up the Wireless-G IP Phone

Figure 3-19: Save

Outbound Proxy IP

Wireless-G IP Phone

18. Scroll down to Outbound Proxy Port, and select Edit.

19. Enter the Outbound Proxy Port number in the new window, and then press the center selection key.

20. If your Internet phone service provider did not provide an Expire Time setting, then keep the default setting, 3600 seconds, and proceed to step 22.

If your Internet phone service provider provided an Expire Time setting, then scroll down to Expire Time, and select Edit.

21. Enter the Expire Time in the new window, and then press the center selection key.

Figure 3-20: Edit

Outbound Proxy Port

Figure 3-21: Save Expire

Time

Chapter 3: Installing and Using the Wireless-G IP Phone

Setting up the Wireless-G IP Phone

22. Scroll down to Phone Number, and select Edit.

23. Enter the Phone Number you will use for Internet phone calls, and then press the center selection key.

24. Scroll down to User Name, and select Edit.

25. Enter the User Name in the new window, and then press the center selection key.

Wireless-G IP Phone

Figure 3-22: Save Phone

Number

Chapter 3: Installing and Using the Wireless-G IP Phone Setting up the Wireless-G IP Phone

Figure 3-23: Save User

Name

Wireless-G IP Phone

26. Scroll down to Password, and select Edit.

27. Enter the Password, and then press the center selection key.

28. On the SIP Settings screen, select Return.

Figure 3-24: Save

Password

Figure 3-25: Save SIP

Settings

Chapter 3: Installing and Using the Wireless-G IP Phone

Setting up the Wireless-G IP Phone

29. On the main menu, select Return.

30. The standby screen will indicate that the IP Phone is ready for phone calls.

The installation of the Wireless-G IP Phone is complete. Proceed to the next section, “Using the

Wireless-G IP Phone.”

Wireless-G IP Phone

Figure 3-26: Return to

Standby Screen

Chapter 3: Installing and Using the Wireless-G IP Phone Setting up the Wireless-G IP Phone

Figure 3-27: Standby

Screen

Wireless-G IP Phone

Using the Wireless-G IP Phone

To make a call, enter the phone number you want to call. Then press the Call button. When you are on a phone call, select Option to see a list of menu choices. Select HangUp to end the call.

To change the volume, use the + and - buttons on the side panel of the IP Phone. For more information about the buttons on the IP Phone, refer to “Chapter 2: Getting to Know the Wireless-G IP Phone.”

LineOption

When you are on a call, you have several options available. Press the left softkey to make a selection, and press the right softkey to return to the previous menu. Use the navigation pad to scroll through menu choices.

HangUp. To end the call, select HangUp.

Mute. To mute the call, select Mute. Then select UnMute when you are ready to talk.

Hold. To put a call on hold, select Hold. Then select UnHold when you are ready to return to this call.

Line-2. When you want to switch back and forth between two separate conversations, use the Line-2 feature.

When you are on your first call, select Line-2 to switch to a second line. A new window will appear. Enter the phone number of the second call, and then press the Call button. The current call will be put on hold, and you will be switched to the second call. Select Switch to switch back to the first call.

Tra nsfer. There are two types of transfer features available. Use the Transfer feature when you want to introduce the caller you are transferring. Use the Blind TFR (Transfer) feature when you want to transfer the caller without introduction. When you are on your call, select Tra ns fer. A new window will appear. Enter the phone number to which you want to transfer the call, and then press the Call button. When the second call is answered, speak to the answering party and select Tra nsfer. Then hang up.

Figure 3-28: Call

Connected

Figure 3-29: Line Options

Chapter 3: Installing and Using the Wireless-G IP Phone

Using the Wireless-G IP Phone

Blind TFR. For a blind transfer, select Blind TFR. Dial the number to which you want to transfer the call. Select Blind TFR again. Then hang up. When you are on your call, select Blind TFR. A new window will appear. Enter the phone number to which you want to transfer the call, and then press the Call button. Then hang up.

Conference. When you are on your call, select Conference. A new window will appear. Enter the phone number

of the second call, and then press the Call button. When the second call is answered, select Conference.

Second Incoming Call

When you have a second call coming in, you can select Option to see a list of menu choices. Select HangUp to end the call.

Wireless-G IP Phone

Keyguard

To lock the keys, press and hold down the # key. To unlock the keys, select Unlock and then press the * key.

Voicemail

For instructions on how to check your voicemail, contact your Internet phone service provider.

To configure additional settings, proceed to “Chapter 4: Configuring the Wireless-G IP Phone.”

Chapter 3: Installing and Using the Wireless-G IP Phone Using the Wireless-G IP Phone

Figure 3-30: Second Call

Figure 3-31: Unlock Keys

Wireless-G IP Phone

Chapter 3: Installing and Using the Wireless-G IP Phone

Using the Wireless-G IP Phone

Chapter 4: Configuring the Wireless-G IP Phone

Instructions for Configuring the Wireless-G IP Phone

Follow these instructions to configure the IP Phone’s settings. You will use these buttons to navigate menus and select your choices.

Icon Button Name Function

Soft K ey Press the left or right soft key

to select the appropriate action shown on the left- or righthand side of the screen.

Navigation Pad and Center Selection Key

Power or End Call To exit a menu without making

To navigate menus and control the cursor for the web browser, use the navigation pad.

Use the center selection key to make menu choices.

changes, press this button.

Navigation Pad and Center Selection Key

Different Key Choices or + Sign

Soft Key

Call

Power LED

Wireless-G IP Phone

Key Choice

Soft Key

Power or End Call

Enter Symbol or Space

Chapter 4: Configuring the Wireless-G IP Phone Instructions for Configuring the Wireless-G IP Phone

Figure 4-1: Front Panel

Wireless-G IP Phone

Icon Button Name Function

Different Key Choices or + Sign

Enter Symbol or Space

Press the * (star) key twice to enter the + sign.

Press the # (pound) key to open the Symbol Selection menu. Use the navigation pad to move through the menu. When you have the appropriate symbol highlighted, press the center selection key.

Press the # (pound) key twice to enter a space.

Figure 4-2: Symbol

Selection

Chapter 4: Configuring the Wireless-G IP Phone

Instructions for Configuring the Wireless-G IP Phone

Status Information

The standby screen will display a variety of information about the IP Phone.

Wireless Signal Strength

At the top of the screen, the icon on the left indicates wireless signal strength.

Time Display

The current time is shown. To change this time and its format, analog or digital, use the main menu.

Status of the IP Phone

The IP Phone has three status messages. “Ready” indicates that the IP Phone is ready to make and receive calls. “Not Ready” indicates that the IP Phone has no wireless connection. “Not Registered” indicates that the IP Phone does not have a registered phone number.

Date Display

The date display gives you the current date. You can change this date using the main menu.

Battery Strength

The icon on the right of the screen indicates battery strength of the IP Phone.

Wireless-G IP Phone

Battery Strength

Figure 4-3: Standby

Screen

Chapter 4: Configuring the Wireless-G IP Phone Status Information

Wireless-G IP Phone

Wireless Network Name

The screen displays the name of the wireless network used by the IP Phone.

Internet Phone Number

The Internet phone number of the IP Phone is shown.

Press the left soft key button to view the main menu. Its choices will be described in further detail below.

Phonebook

Press the right soft key to access the Phonebook. This can also be accessed through the main menu.

Web Browsing

Press the center selection key to launch the web browser.

Settings of the Wireless-G IP Phone

You will have nine menu choices: Call Log, Phone Book, Network Settings, Wireless, Phone Settings, SIP Settings, Web Site, Web Cam, and Information.

Figure 4-4: Standby

Screen

Figure 4-5: Main Menu

Chapter 4: Configuring the Wireless-G IP Phone

Settings of the Wireless-G IP Phone

Call Log

Scroll through these choices and press the left soft key to make a selection. Select Return to return to the previous menu.

Missed

A list of missed calls will be displayed. Scroll through the calls to select the call you want. Select Option to see menu choices for the selected call. Select Return to return to the previous menu.

Option

Wireless-G IP Phone

You have these choices: Dial (available when you have contacts in the Phone Book), Delete (available when you have contacts in the Phone Book), Delete All, and Add to (or Modify) PhoneBook. Select Return to return to the previous menu.

Dial. Select Dial to dial the phone number of the selected call.

Delete. Select Delete to delete the selected call.

Delete All. Select Delete All to delete all calls.

Add to (or Modify) PhoneBook. If the call information is new, select Add to PhoneBook to add the

phone number to the Phone Book. To select the type of phone number it is, scroll down and select Home, Office, Mobile, Home-2, Office-2, or Mobile-2 (select Return if you want to return to the previous menu). The Add Person screen will appear. Then follow the instructions for the Phone Book settings.

Chapter 4: Configuring the Wireless-G IP Phone Settings of the Wireless-G IP Phone

Figure 4-7: Call Log

Options

Figure 4-6: Call Log

Figure 4-8: Type of

Phone Number

Wireless-G IP Phone

If the phone number is already in the Phone Book, select Modify PhoneBook to modify its entry in the Phone Book. The Phone Book screen will automatically appear. Follow the instructions for the Phone Book settings.

Received

A list of received calls will be displayed. Select Option to see menu choices for the selected call. Select Return to return to the previous menu.

Option

Dial. Select Dial to dial the phone number of the selected call.

Delete. Select Delete to delete the selected call.

Delete All. Select Delete All to delete all calls.

Add to (or Modify) PhoneBook. If the call information is new, select Add to PhoneBook to add the phone number to the Phone Book. To select the type of phone number it is, scroll down and select Home, Office, Mobile, Home-2, Office-2, or Mobile-2 (select Return if you want to return to the previous menu). The Add

Person screen will appear. Then follow the instructions for the Phone Book settings.

Chapter 4: Configuring the Wireless-G IP Phone

Settings of the Wireless-G IP Phone

Dialed

A list of dialed calls will be displayed. Select Option to see menu choices for the selected call. Select Return to return to the previous menu.

Option

Dial. Select Dial to dial the phone number of the selected call.

Delete. Select Delete to delete the selected call.

Delete All. Select Delete All to delete all calls.

Person screen will appear. Then follow the instructions for the Phone Book settings.

Wireless-G IP Phone

Chapter 4: Configuring the Wireless-G IP Phone Settings of the Wireless-G IP Phone

Wireless-G IP Phone

Phone Book

You will see a list of contacts (when you have contacts in the Phone Book). To search for an entry, enter the contact’s name in the field provided. The appropriate entry will be selected.

Select Option to see menu choices. Select Return to return to the previous menu.

Figure 4-9: Select

Phone Book

Option

You have these choices: Edit (available when you have contacts in the Phone Book), Add, Delete (available when you have contacts in the Phone Book), and Mem Usage. Select Return to return to the previous menu.

Edit. Select Edit to edit a contact’s information: Name, Home Number, Office Number, Mobile Number, Home-2 Number, Office-2 Number, Mobile-2 Number, Speed-Dial Number, Ring Tone, and E-Mail. For each setting, select Edit. Enter the appropriate information in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu. After you have finished your edits, select Return to return to the Phone Book screen.

Figure 4-10: Phone

Book

Figure 4-11: Phone

Book Options

Chapter 4: Configuring the Wireless-G IP Phone

Settings of the Wireless-G IP Phone

Add. Select Add to add a new contact. Scroll through the different settings: Name, Home Number, Office

Number, Mobile Number, Home-2 Number, Office-2 Number, Mobile-2 Number, Speed-Dial Number, Ring Tone, and E-Mail. For each setting, select Edit. Enter the appropriate information in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu. After you have entered all of the new contact information, select Return to return to the Phone Book screen.

Delete. To delete a contact, scroll down the entries until the contact is highlighted. Select Option and then select Delete. Then you will be automatically returned to the Phone Book screen.

Mem Usage. Select Mem Usage to find out how much memory has been used. The total number of phone book

entries available and number of entries used will be displayed. Select Exit to return to the Phone Book screen.

Wireless-G IP Phone

Figure 4-12: Add Person

Chapter 4: Configuring the Wireless-G IP Phone Settings of the Wireless-G IP Phone

Figure 4-13: Enter Name

Wireless-G IP Phone

Network Settings

You have two IP Modes available, DHCP and Fixed IP. In most cases, you should keep the default setting, DHCP, if your network router or gateway will assign IP addresses to the IP Phone. If you want to assign a static IP address to the IP Phone, select Fixed IP. To change the IP Mode, select Edit. The on-screen choices will change depending on which IP Mode is selected. Press the center selection key to save the new information, or select Return to return to the previous menu.

DHCP

If DHCP is selected as the IP Mode, there are no other settings to change. Select Return to return to the previous menu.

ip address: the address used to identify a computer or device on a network.

Figure 4-14: Select

Network Settings

Figure 4-15: Network

Settings - DHCP

Chapter 4: Configuring the Wireless-G IP Phone

Settings of the Wireless-G IP Phone

Fixed IP

If Fixed IP is selected as the IP Mode, the screen will show these settings: IP Address, Subnet Mask, Default Gateway, Primary DNS, and Secondary DNS.

IP Address. To add or change the IP Address, select Edit. Enter the new IP Address in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu.

Subnet Mask. To add or change the Subnet Mask, select Edit. Enter the new Subnet Mask in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu.

Default Gateway. To add or change the Default Gateway, select Edit. Enter the new IP address of the Default Gateway in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu.

Primary DNS. To add or change the Primary DNS address, select Edit. Enter the new DNS IP address in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu.

Secondary DNS. To add or change the Secondary DNS address, select Edit. Enter the new DNS IP address in the new window. Press the center selection key to save the new information, or select

Exit to return to the previous menu.

Figure 4-16: Network

Settings - Fixed IP

Wireless-G IP Phone

Figure 4-17: Enter IP

Address

Chapter 4: Configuring the Wireless-G IP Phone Settings of the Wireless-G IP Phone

Figure 4-18: Edit Subnet

Mask

Figure 4-19: Enter

Subnet Mask

Wireless-G IP Phone

Wireless

You have three choices, Set Wi-Fi, Profiles, and Hotspot. If you want to scan for wireless networks in your local area, select Set Wi-Fi. If you want to set configuration profiles for different network setups, select Profiles. The Hotspot screen lists the IP Phone’s default hotspots. If you want to save your user name and password for these default hotspots, select Hotspot. Press the left soft key to make a selection. Select Return to return to the previous menu.

Set Wi-Fi

After you have selected Set Wi-Fi, the IP Phone will scan the local area for wireless access points or routers. A list of wireless networks, including hotspots, will be displayed and show their wireless network names, security status (a lock indicates wireless security), and signal strength, which is indicated by a bar graph.

There are three sets of instructions. If you will connect to a wireless network, proceed to this section, “Connection to a Wireless Network.”

The IP Phone has a list of default hotspots, which are shown on the Hotspot screen. If you will connect to a default hotspot, proceed to this section, “Connection to a Default Hotspot.”

If you will connect to a new hotspot, proceed to this section, “Connection to a New Hotspot.”

Connection to a Wireless Network

1. Scroll through the choices, and press the center selection key (in the middle of the navigation pad) to select the wireless network you want to use.

If the network you want is not shown, select Rescan for a new scan.

Figure 4-20: Wireless

Figure 4-21: Scanning for Wireless Networks

Figure 4-22: List of Wireless Networks

Chapter 4: Configuring the Wireless-G IP Phone

Settings of the Wireless-G IP Phone

2. The IP Phone will automatically connect to the network you have selected.

WEP Security If WEP security is enabled on the selected network, a new screen will appear. Using the navigation pad, select the appropriate transmit key number and then move to the WEP Key field. Enter the network’s WEP key. Press the center selection key.

WPA Security If WPA security is enabled on the selected network, a new screen will appear. Enter the network’s WPA key. Press the center selection key.

Wireless-G IP Phone

3. You will be notified when the IP Phone has connected to the network, and a checkmark will appear next to the name of the network.

Select Exit to return to the Wireless screen.

Chapter 4: Configuring the Wireless-G IP Phone Settings of the Wireless-G IP Phone

Figure 4-23: Connecting

to Wireless Network

Figure 4-25: Enter WPA

Key (for Secured

Network)

Figure 4-24: Enter WEP

Key (for Secured

Network)

Figure 4-26: Connecting

to Wireless Network

Wireless-G IP Phone

Connection to a Default Hotspot

Before you begin, make sure you have saved your User Name and Password for the default hotspot you want to use. These login settings can be configured through the Hotspot screen.

1. Scroll through the choices, and press the center selection key (in the middle of the navigation pad) to select the wireless hotspot you want to use.

If the hotspot you want is not shown, select Rescan for a new scan.

2. You will be notified when the IP Phone has connected to the hotspot, and a checkmark will appear next to the name of the hotspot.

3. A new window will appear. On the Select Hotspot screen, scroll through the choices, and press the center selection key to select the appropriate hotspot.

(If the hotspot you want is not listed on the Select Hotspot screen, proceed to step 3 of the following section, “Connection to a New Hotspot.”)

4. The IP Phone will automatically use your User Name and Password to log in.

After you have logged in, select Exit to return to the Wireless screen.

Figure 4-27: Select

Default Hotspot

Chapter 4: Configuring the Wireless-G IP Phone

Settings of the Wireless-G IP Phone

Connection to a New Hotspot

1. Scroll through the choices, and press the center selection key (in the middle of the navigation pad) to select the wireless hotspot you want to use.

If the hotspot you want is not shown, select Rescan for a new scan.

2. You will be notified when the IP Phone has connected to the hotspot, and a checkmark will appear next to the name of the hotspot.

3. A new window will appear. On the Select Hotspot screen, select IE Browser.

Wireless-G IP Phone

4. The web browser will automatically open. Follow the on-screen instructions to access the hotspot.

5. After you have gained access, you can browse the Internet.

If you want to save the new hotspot’s settings, follow these instructions:

1. When you are connected to the new hotspot, view the main menu.

2. Select Wireless.

3. Select Profiles.

4. Select Option.

5. Select Save <network name>.

Then you will be automatically returned to the Wi-Fi Profiles screen.

Chapter 4: Configuring the Wireless-G IP Phone Settings of the Wireless-G IP Phone

Figure 4-28: Detect

Hotspot

Figure 4-30: Getting IP

Address

Figure 4-29: Connecting

to Hotspot

Figure 4-31: Select IE

Browser

Wireless-G IP Phone

Profiles

You will see a list of profiles (when you have profiles already configured). Select Option to see menu choices. Select Exit to return to the previous menu.

You can designate the order of the profiles saved by the IP Phone. The next time it is powered on, it will use the first profile to automatically connect to the profile’s wireless network. If that network is not available, the IP Phone will try the next profile. This will continue until it has connected to a wireless network.

Option

You have these choices: Edit (available when you have at least one existing profile), Add, Delete (available when you have at least one existing profile), Connect, Go Down/Up (available when you have more than one profile), and Save <network name> (available when the IP Phone is connected to a network lacking a profile). The Edit and Add options configure the same settings. The Edit option is used for changing existing profiles, while the Add option is used for creating new profiles. Select Return to return to the previous menu.

Edit. Select Edit to edit a profile’s information: SSID (wireless network name), Wireless Mode, Authentication Mode, and Encryption. (Additional setting may be available depending on the encryption used.) Scroll through these choices, and select Edit to change a setting.

SSID. To change the SSID, select Edit. Enter the new SSID in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu.

Wireless Mode. You have a choice of Infrastructure and Ad hoc modes. To change the Wireless Mode, select Edit.

Figure 4-32: Wi-Fi

Figure 4-33: Edit SSID

Profiles

ssid (service set identifier): your wireless network’s name.

ad-hoc: a group of wireless devices communicating directly to each other (peer-to-peer) without the use of an access point.

infrastructure: a wireless network that is bridged to

Figure 4-34: Edit

Wireless Mode

Chapter 4: Configuring the Wireless-G IP Phone

a wired network via an access point.

Settings of the Wireless-G IP Phone

Authentication Mode. You have a choice of Auto Switch, Share Key, Open System, and WPA-

PSK. To change the Authentication Mode, select Edit. A new window will open. Scroll through the modes, and select the appropriate mode. Select Save to save the new Authentication Mode, or select Exit to return to the Edit Profile menu without changing the Authentication Mode.

Proceed to the section for the Authentication Mode you have selected.

Auto Switch, Share Key, or Open System

Encryption. You have a choice of Disabled and WEP encryption. To change the Encryption

method, select Edit. If you select Disabled, there are no other settings to change. If you select WEP, there are two more settings available, Key Index and WEP Key.

Key Index. For the index of transmit keys, you have a choice of 1-4. To specify which WEP key the IP Phone will use, select Edit. A new window will open. Scroll through the numbers, and select the appropriate transmit key number. Select Save to save the new transmit key number, or select Exit to return to the Edit Profile menu without changing the number.

WEP Key. To enter the WEP Key, select Edit. Enter the new WEP Key in the new window. Press the center selection key to save the new WEP Key, or select Exit to return to the Edit Profile menu without changing the key.

802.1x. You have a choice of Enable and Disable. The Enable option configures the IP Phone for a network using 802.1x authentication. To change the 802.1x setting, select Edit.

If 802.1x is enabled, configure the EAP Type setting. Select Edit. You have a choice of TLS, MD5, and PEAP. Select Save to save the new EAP Type, or select Exit to return to the Edit Profile menu without changing the EAP Type.

Figure 4-35: Change

Authentication Mode

Figure 4-37: Enter WEP

Key

Wireless-G IP Phone

Figure 4-36: Edit WEP

Key

Figure 4-38: Change

EAP Type (802.1x)

Chapter 4: Configuring the Wireless-G IP Phone Settings of the Wireless-G IP Phone

Wireless-G IP Phone

WPA-PSK

WPA Key. To enter the WPA Key, select Edit. Enter the new WPA Key in the new window. Press the center selection key to save the new WPA Key, or select Exit to return to the previous menu.

EAP Type. To change the EAP Type setting, select Edit. You have a choice of TLS, MD5, and

PEAP. Select Save to save the new EAP Type, or select Exit to return to the Edit Profile menu without changing the EAP Type.

Hotspot. If you have default hotspots configured, then this setting will be available. To change the selected hotspot, select Edit.

Select Return to return to the Wi-Fi Profiles screen.

Add. Select Add to create a profile and enter its information: SSID (wireless network name),

Figure 4-39: Edit EAP

Type (WPA-PSK)

Wireless Mode, Authentication Mode, Key Index, and WEP Key. Scroll through these choices, and select Edit to change a setting.

SSID. To enter the SSID, select Edit. Enter the new SSID in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu.

Wireless Mode. You have a choice of Infrastructure and Ad hoc modes. To change the Wireless Mode, select Edit.

Authentication Mode. You have a choice of Open System, Auto Switch, Share Key, and WPA-PSK. To change

the Authentication Mode, select Edit. A new window will open. Scroll through the modes, and select the appropriate mode. Select Save to save the new Authentication Mode, or select Exit to return to the Add Profile menu without changing the Authentication Mode.

Proceed to the section for the Authentication Mode you have selected.

Figure 4-40: Change

EAP Type (WPA-PSK)

Figure 4-41: Enter SSID

Chapter 4: Configuring the Wireless-G IP Phone

Settings of the Wireless-G IP Phone

Auto Switch, Share Key, or Open System

Encryption. You have a choice of Disabled and WEP encryption. To change the Encryption method, select Edit. If you select Disabled, there are no other settings to change. If you select WEP, there are three more

settings available, Key Index, WEP Key, and 802.1x.

WEP Key. To enter the WEP Key, select Edit. Enter the new WEP Key in the new window. Press the center selection key to save the new WEP Key, or select Exit to return to the Add Profile menu without changing the key.

802.1x. You have a choice of Enable and Disable. The Enable option configures the IP Phone for a network using 802.1x authentication. To change the 802.1x setting, select Edit.

If 802.1x is enabled, configure the EAP Type setting. Select Edit. You have a choice of TLS, MD5, and PEAP. Select Save to save the new EAP Type, or select Exit to return to the Add Profile menu without changing the EAP Type.

WPA-PSK

WPA Key. To enter the WPA Key, select Edit. Enter the new WPA Key in the new window. Press the center

selection key to save the new WPA Key, or select Exit to return to the previous menu.

Wireless-G IP Phone

Figure 4-42: Change

Transmit Key

Chapter 4: Configuring the Wireless-G IP Phone Settings of the Wireless-G IP Phone

Figure 4-43: Edit WPA

Key

Wireless-G IP Phone

EAP Type. To change the EAP Type setting, select Edit. You have a choice of TLS, MD5, and PEAP. Select Save to save the new EAP Type, or select Exit to return to the Add Profile menu without changing the EAP

Typ e.

Hotspot. If you have default hotspots configured, then this setting will be available. To change the selected hotspot, select Edit.

Select Return to return to the Wi-Fi Profiles screen.

Delete. To delete a profile, scroll down the entries until the profile is highlighted. Select Option and then select Delete. Then you will be automatically returned to the Wi-Fi Profiles screen.

Connect. To connect using a profile, scroll down the entries until the profile is highlighted. Select Option and

then select Connect. The IP Phone will automatically connect to the appropriate network. Then you will be automatically returned to the Wi-Fi Profiles screen.

Go Down/Up. You can rearrange the order of the profiles on your list. To move a profile, scroll through the entries until the profile is highlighted. Select Option and then select Go Down or Go Up to move the entry. Then you will be automatically returned to the Wi-Fi Profiles screen.

Save <network name>. When the IP Phone is connected to a network lacking a profile, this option will be available. To save the network’s settings as a new profile, select Option and then select Save <network name>. Then you will be automatically returned to the Wi-Fi Profiles screen.

Figure 4-44: Profile

Added

Chapter 4: Configuring the Wireless-G IP Phone

Settings of the Wireless-G IP Phone

Hotspot

You will see a list of the IP Phone’s default hotspots. Scroll through these choices and press the left soft key to make a selection. Select Return to return to the Wireless screen.

User Name. To change the User Name, select Edit. Enter the new User Name in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu.

Password. To change the Password, select Edit. Enter the new Password in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu.

Wireless-G IP Phone

If you want to save a new hotspot’s settings, do not use this screen. When you are connected to the new hotspot, select Profiles on the Wireless screen. Select Option, and then select Save <network name>. Then you will be automatically returned to the Wi-Fi Profiles screen.

Chapter 4: Configuring the Wireless-G IP Phone Settings of the Wireless-G IP Phone

Figure 4-45: Select

Hotspot

Figure 4-46: Edit User

Name

Wireless-G IP Phone

Phone Settings

You can customize the settings of the IP Phone. You have these choices: Ring Option, Keypad Tone, Wallpaper, Date & Time, Language, Phone Password, and Upgrade. Select Return to return to the previous menu.

Ring Option

Scroll through these choices and press the left soft key to make a selection. Select Return to return to the Phone Settings screen.

Ring Types. There are five different ring types. The selected ring type is indicated by the <*> symbol. Scroll through these choices to hear the actual ring style. Highlight the ring type you want to select, and then press the center selection key to save your change. Select Exit to return to the Ring Option menu without changing the ring type.

Ring Tones. There are seven ring tones. The selected ring tone is indicated by the <*> symbol. Scroll through these choices to hear the actual ring tone. Highlight the ring tone you want to select, and then press the center selection key to save your change. Select Exit to return to the Ring Option menu without changing the ring tone.

Ring Volume. There are five ring volume levels. The selected ring volume level is indicated by the <*> symbol. Scroll through these choices to hear the actual ring volume level. Highlight the ring volume level you want to select, and then press the center selection key to save your change. Select Exit to return to the Ring Option menu without changing the ring volume level.

Figure 4-47: Select

Phone Settings

Figure 4-49: Ring

Options

Chapter 4: Configuring the Wireless-G IP Phone

Settings of the Wireless-G IP Phone

Figure 4-48: Phone

Settings

Figure 4-50: Ring Types

Keypad Tone

To hear the actual keypad tone, scroll through these choices: Off, Soft, and Loud. The selected keypad tone is indicated by the <*> symbol. Highlight the keypad tone you want to select, and then press the center selection key to save your change. Select Exit to return to the Phone Settings menu without changing the keypad tone.

Wallpaper

To see the different wallpaper choices, highlight the wallpaper you want to select, and then select Preview. Click Exit to return to the Wallpaper menu. The selected wallpaper is indicated by the <*> symbol. Highlight the wallpaper you want to select, and then press the center selection key to save your change. Select Exit to return to the Phone Settings menu without changing the wallpaper.

Wireless-G IP Phone

Figure 4-51: Keypad

Ton e

Chapter 4: Configuring the Wireless-G IP Phone Settings of the Wireless-G IP Phone

Figure 4-52: Wallpaper

Wireless-G IP Phone

Date & Time

You have six choices: Date, Clock, Time Format, Clock Type, Time Zone, and NTP Server. Select Exit to return to the previous menu.

Date. Press the left soft key to select the Date setting. A new window will be displayed. Make your changes, and then press the center selection key to save your change. Select Exit to return to the Date & Time screen without changing the date.

Clock. Press the left soft key to select the Clock setting. A new window will be displayed. Make your changes, and then press the center selection key to save your change. Select Exit to return to the Date & Time screen without changing the time.

Time Format. There are two formats available, 12-Hour and 24-Hour. To change the format, highlight Time Format, and press the left soft key.

Clock Type. There are two types available, Analog and Digital. To change the format, highlight Clock Typ e, and press the left soft key.

Figure 4-53: Change

Date

Figure 4-54: Change

Clock

Figure 4-55: Change

Time Format

Chapter 4: Configuring the Wireless-G IP Phone

Settings of the Wireless-G IP Phone

Figure 4-56: Change

Clock Type

Time Zone. Press the left soft key to select the Time Zone setting. A list of multiple time zones will

be displayed. The selected time zone is indicated by the <*> symbol. Scroll through these choices, and highlight the time zone. Then select Settings to save your change. Select Exit to return to the Date & Time menu without changing the time zone.

Wireless-G IP Phone

NTP Server. Press the left soft key to select the NTP Server setting. A new window will be displayed. Enter the URL (web address) of the NTP Server. Press the center selection key to save your change. Select Exit to return to the Date & Time menu without changing the server.

Chapter 4: Configuring the Wireless-G IP Phone Settings of the Wireless-G IP Phone

Figure 4-57: Select Time

Zone

Figure 4-59: Select NTP

Server

Figure 4-58: Change

Time Zone

Figure 4-60: Enter Name

of NTP Server

Wireless-G IP Phone

Language

The selected language is indicated by the <*> symbol. Highlight the language you want to select, and then press the left soft key to save your change. Select Exit to return to the Phone Settings menu without changing the language.

Phone Password

You can set a password so only users who know the password can use the IP Phone. Press the left soft key to select the Phone Password setting. To set a password, select Edit. Enter the password, and then press the center selection key to save it. Select Return to return to the Phone Settings menu without changing the password.

The next time the IP Phone is powered on, it will ask for the Phone Password. Enter it in the field provided, and then select OK.

Figure 4-62: LanguageFigure 4-61: Select

Language

Figure 4-63: Phone

Password

Chapter 4: Configuring the Wireless-G IP Phone

Settings of the Wireless-G IP Phone

Upgrade

Use this screen to upgrade the firmware of the IP Phone.

The IP Phone is pre-configured with the correct Download URL (web address of the download site) and OS Image File (firmware upgrade file) entries.

NOTE: Do not change these settings unless your Internet phone service provider has given you new settings.

Plug the USB mini-B connector of the included power adapter into the USB mini-B port of the IP Phone. Then connect the power adapter to a standard electrical outlet.

NOTE: If the upgrade is interrupted, the IP Phone will revert to its old firmware, and you can attempt the upgrade again.

Select Upgrade to start upgrading the IP Phone’s firmware, or select Return to cancel the upgrade and return to the previous menu.

When the upgrade is complete, the IP Phone will automatically power itself off. Wait five seconds, and then power on the IP Phone.

Figure 4-64: Select

Upgrade

Wireless-G IP Phone

Figure 4-65: Edit

Download URL

Chapter 4: Configuring the Wireless-G IP Phone Settings of the Wireless-G IP Phone

Figure 4-66: Upgrade in

Progress

Figure 4-67: Upgrade

Successful

Wireless-G IP Phone

SIP Settings

SIP settings are used to configure your Internet phone service. The necessary setup information is supplied by your Internet phone service provider. If you do not have this information, contact your Internet phone service provider before you make any changes. Select Return to return to the previous menu.

Proxy IP. To add or change the Proxy IP address, select Edit. Enter the new Proxy IP address in the new window. Press the center selection key to save the new setting, or select Exit to return to the previous screen.

Proxy Port. To add or change the Proxy Port number, select Edit. Enter the new Proxy Port number in the new window. Press the center selection key to save the new setting, or select Exit to return to the previous screen.

Register Proxy IP. To add or change the Register Proxy IP address, select Edit. Enter the new Register Proxy IP address in the new window. Press the center selection key to save the new setting, or select Exit to return to the previous screen.

Figure 4-68: Edit Proxy IP

Figure 4-70: Enter

Chapter 4: Configuring the Wireless-G IP Phone

Settings of the Wireless-G IP Phone

Figure 4-69: Enter Proxy

Figure 4-71: Enter

Register Proxy Port number in the new window. Press the center selection key to save the new setting, or select Exit to return to the previous screen.

Outbound Proxy IP. To add or change the Outbound Proxy IP address, select Edit. Enter the new Outbound Proxy IP address in the new window. Press the center selection key to save the new setting, or select Exit to return to the previous screen.

Outbound Proxy Port. To add or change the Outbound Proxy Port number, select Edit. Enter the new Outbound Proxy Port number in the new window. Press the center selection key to save the new setting, or select Exit to return to the previous screen.

Wireless-G IP Phone

Expire Time. If your Internet phone service provider did not provide an Expire Time setting, then keep the default setting, 3600 seconds. If your Internet phone service provider provided an Expire Time setting, then scroll down to Expire Time, and select Edit. Enter the Expire Time in the new window. Press the center selection key to save the new setting, or select Exit to return to the previous screen.

Phone Number. To add or change the Phone Number you will use for Internet phone calls, select Edit. Enter the new Phone Number in the new window. Press the center selection key to save the new setting, or select Exit to return to the previous screen.

Chapter 4: Configuring the Wireless-G IP Phone Settings of the Wireless-G IP Phone

Figure 4-72: Change

Outbound Proxy IP

Figure 4-74: Change

Expire Time

Figure 4-73: Edit

Outbound Proxy Port

Figure 4-75: Change

Phone Number

Wireless-G IP Phone

User Name. To add or change the User Name, select Edit. Enter the new User Name in the new window. Press the center selection key to save the new setting, or select Exit to return to the previous screen.

Password. To add or change the Password, select Edit. Enter the new Password in the new window. Press the center selection key to save the new setting, or select Exit to return to the previous screen.

Payload Type. G.711a, G.729, and G.711u are the three Payload Types available. They are listed in order of preference. To change the order of preference, select Edit until the appropriate order of preference is displayed on-screen.

Packet Time. You have two Packet Time lengths available, Small and Large. To change the time period, select Edit until the appropriate Packet Time is displayed on-screen.

Figure 4-76: Change

User Name

DTMF Relay. You can enable or disable the DTMF Relay feature. To enable or disable the feature, select Edit.

UDP Port. To add or change the UDP Port number, select Edit. Enter the new UDP Port number in the new window. Press the center selection key to save the new setting, or select Exit to return to the previous screen.

RTP Port. To add or change the RTP Port number, select Edit. Enter the new RTP Port number in the new

window. Press the center selection key to save the new setting, or select Exit to return to the previous screen.

Figure 4-77: Change

Password

Figure 4-78: Edit

Payload Type

Chapter 4: Configuring the Wireless-G IP Phone

Settings of the Wireless-G IP Phone

Web Site

A list of web sites (if saved) will be shown. Scroll through these choices and press the center selection key to visit the web site you want. To save frequently visited web sites, select Option to see menu choices, which will be described in further detail below. Select Return to return to the previous menu.

Visiting a Web Site

When the web site is displayed, use the navigation bar below the Address field to control the web browser, and use the navigation pad to control the cursor. Click the <= and => buttons to move between webpages. Click the red X button to stop loading the current webpage. Click the green refresh button to reload the current webpage. Click the home button to return to your homepage. Click the search button to run a search. Click the smaller capital A to zoom out, or click the larger capital A button to zoom in on the webpage. Click the minimize button to the left of the Address field to minimize the Address bar.

To auto-scroll, press and hold down the center selection key for two seconds until you see an orange navigation cursor. Then use the navigation pad to scroll up and down the webpage. To use the cursor as a page up and down button, press and hold down the center selection key for an additional two seconds until the cursor turns blue with a “P” in the center. Then use the navigation pad to move up and down the webpage.

To visit a different website, select the current web address in the Address field. Begin entering the new web address, and a new window will automatically appear. When you have finished entering the new web address, press the center selection key.

Figure 4-79: Web Site

Wireless-G IP Phone

Figure 4-80: Visit Web

Site

You can also use the Address drop-down menu. Select the website you want. Then press the center selection key, or select Option and then Enter.

Chapter 4: Configuring the Wireless-G IP Phone Settings of the Wireless-G IP Phone

Figure 4-81: Auto-Scroll

Option

Wireless-G IP Phone

To change how the cursor works, select Option. If your cursor uses the Click feature, the Drag & Drop feature will be available. If your cursor uses the Drag & Drop feature, the Click feature will be available. Press the left soft key to select the new cursor feature, or select Return to return to the website.

Select Exit to return to the Web Site screen.

Option

You have these choices: Edit (available when you have at least one web site saved), Add, and Delete (available when you have at least one web site saved). The Edit and Add options configure the same settings. The Edit option is used for changing existing web site entries, while the Add option is used for saving new web site entries. Select Return to return to the previous menu.

Edit. Select Edit to edit a web site’s information: Name, URL (web address), and Port Number. Scroll through these choices, and select Edit to change a setting.

Name. To change the Name, select Edit. Enter the new Name in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu.

URL. To change the URL, select Edit. Enter the new URL in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu.

Port Number. To change the Port Number, select Edit. Enter the new Port Number in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu. (If you are not sure how to change this setting, keep the default, 80.)

Figure 4-82: Web Site

Options

Select Return to return to the Web Site screen.

Figure 4-83: Edit Web

Site

Chapter 4: Configuring the Wireless-G IP Phone

Settings of the Wireless-G IP Phone

Add. Select Add to create a new web site entry with the following information: Name, URL (web address), and Port Number. Scroll through these choices, and select Edit to configure a setting.

Name. To enter the Name, select Edit. Enter the new Name in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu.

URL. To enter the URL, select Edit. Enter the new URL in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu.

Port Number. To enter the Port Number, select Edit. Enter the new Port Number in the new window. Press

the center selection key to save the new information, or select Exit to return to the previous menu. (If you are not sure how to change this setting, keep the default, 80.)

Select Return to return to the Web Site screen.

Delete. To delete a web site, scroll down the entries until the web site is highlighted. Select Option and then select Delete. Then you will be automatically returned to the Web Site screen.

Wireless-G IP Phone

Figure 4-84: Add Web

Site

Chapter 4: Configuring the Wireless-G IP Phone Settings of the Wireless-G IP Phone

Wireless-G IP Phone

Web Cam

Use the IP Phone to view video from any Linksys web camera. On the Web Cam screen, a list of Linksys web cameras (if saved) will be shown. Scroll through these choices and press the center selection key to view video. To save the settings for your Linksys web camera(s), select Option to see menu choices, which will be described in further detail below. Select Return to return to the previous menu.

Viewing a Web Camera

The IP Phone will display video from the Linksys web camera. Press the right soft key to return to the Web Cam screen.

Option

You have these choices: Edit (available when you have at least one Linksys web camera saved), Add, and Delete (available when you have at least one Linksys web camera saved). The Edit and Add options configure the same settings. The Edit option is used for changing existing entries, while the Add option is used for adding new entries. Select Return to return to the previous menu.

Edit. Select Edit to edit a Linksys web camera’s information: Name, URL (web address), and Port Number. Scroll through these choices, and select Edit to change a setting.

Name. To change the Name, select Edit. Enter the new Name in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu.

Figure 4-85: Web Cam

Figure 4-86: Web Cam

Options

URL. To change the URL, select Edit. Enter the new URL in the new window. Press the center

selection key to save the new information, or select Exit to return to the previous menu.

Figure 4-87: Edit Web

Cam

Chapter 4: Configuring the Wireless-G IP Phone

Settings of the Wireless-G IP Phone

Figure 4-88: Add Web

Cam

Port Number. To change the Port Number, select Edit. Enter the new Port Number in the new window. Press

the center selection key to save the new information, or select Exit to return to the previous menu. (If you are not sure how to change this setting, keep the default, 80.)

Select Return to return to the Web Cam screen.

Add. Select Add to create a new entry with the following information: Name, URL (web address), and Port Number. Scroll through these choices, and select Edit to configure a setting.

Name. To enter the Name, select Edit. Enter the new Name in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu.

URL. To enter the URL, select Edit. Enter the new URL in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu.

Port Number. To enter the Port Number, select Edit. Enter the new Port Number in the new window. Press the center selection key to save the new information, or select Exit to return to the previous menu. (If you are not sure how to change this setting, keep the default, 80.)

Select Return to return to the Web Cam screen.

Delete. To delete an entry, scroll down until it is highlighted. Select Option and then select Delete. Then you will be automatically returned to the Web Cam screen.

Wireless-G IP Phone

Chapter 4: Configuring the Wireless-G IP Phone Settings of the Wireless-G IP Phone

Wireless-G IP Phone

Information

The status information of the IP Phone and its software is displayed on this read-only screen. Scroll through the settings to view them. Select Return to return to the previous menu.

Phone Number. Displayed here is the Phone Number of the IP Phone.

IP Address. Displayed here is the IP Address of the IP Phone.

Wireless AP. Displayed here is the name of the wireless network used by the IP Phone. (This is also known as

the SSID.)

MAC Address. Displayed here is the MAC Address of the IP Phone.

eBoot Version. Displayed here is the version number of the eBoot software.

Image Version. Displayed here is the version number of the image software.

SIP Version. Displayed here is the version number of the SIP software.

UI Version. Displayed here is the version number of the UI (User Interface) software.

Figure 4-89: Information

Chapter 4: Configuring the Wireless-G IP Phone

Settings of the Wireless-G IP Phone

Appendix A: Troubleshooting

This appendix provides solutions to problems that may occur during the installation and operation of the Wireless-G IP Phone. Read the description below to solve your problems. If you can't find an answer here, check the website of your Internet phone service provider or the Linksys website at www.linksys.com/international.

Common Problems and Solutions

1. When I make a telephone call, the call doesn’t go through; instead, I hear a fast busy signal.

Go through this checklist until your problem is solved:

• Follow these instructions to reboot your cable or DSL modem, IP Phone, and router:

1. Power off your cable or DSL modem by unplugging its power adapter.

2. Power off the router by unplugging its power adapter.

3. Power off the IP Phone by pressing and holding down the Power button for two seconds.

4. Wait 30 seconds, and then power on your cable or DSL modem by plugging its power adapter into an electrical outlet.

5. Wait 30 seconds. Power on the router by plugging its power adapter into an electrical outlet.

6. Wait 10 seconds. Power on the IP Phone by pressing and holding down the Power button for two seconds.

7. Reboot one of your networked computers, and check for an active Internet connection.

8. Pick up the IP Phone and try your call again.

• Set up port forwarding on your router. You must specify that four port ranges be forwarded to the IP address of the IP Phone. These four port ranges are as follows: 5060-5061 (UDP), 53-53 (UDP), 69-69 (UDP), and 10000-20000 (UDP).

Wireless-G IP Phone

If you have a non-Linksys router, refer to its documentation for instructions.

Appendix A: Troubleshooting Common Problems and Solutions

Wireless-G IP Phone

If you have a Linksys router, then follow these instructions:

1. On one of your networked computers, open your web browser.

2. Access the Router’s Web-based Utility by going to http://192.168.1.1 or the IP address of the Router.

3. A login screen will appear. Leave the User Name field blank. Enter the Router’s password (the default is admin) in the Password field. Then click the OK button.

4. Click the Applications & Gaming tab, and then click the Port Range Forwarding tab.

5. For each port range you must specify, enter a different name in the Application field. Then enter the number or range of external port(s) used by the IP Phone.

6. Select the protocol you will be using, UDP.

7. Enter the IP address of the IP Phone. For example, if the IP Phone’s IP address is 192.168.1.100, you would enter 100 in the field provided.

8. Repeat steps 5-7 until you have entered all four port ranges for the IP Phone.

Application Start and End Protocol IP Address Enable

Internet phone 1 5060 to 5061 UDP (IP address of IP Phone) X

Internet phone 2 53 to 53 UDP (IP address of IP Phone) X

Internet phone 3 69 to 69 UDP (IP address of IP Phone) X

Internet phone 4 10000 to 20000 UDP (IP address of IP Phone) X

9. Check the Enable option for the port services you want to use.

10. When you have completed the configuration, click the Save Settings button.

Appendix A: Troubleshooting

Common Problems and Solutions

2. When I’m on a telephone call, words are dropped intermittently.

Go through this checklist until your problem is solved:

• Are you using a wireless router and cordless phone? If so, the router and cordless phone may be using the same frequency and interfere with each other. Move the cordless phone farther away from the router.

• There may be heavy network activity, particularly if you are running a server or using a file sharing program. Try to limit network or Internet activity during any Internet telephone call. For example, if you are running a file sharing program, files may be uploading in the background even though you are not downloading any files, so make sure you exit the program before you make an Internet phone call.

• There may not be enough bandwidth available for your Internet phone call. You may want to test your bandwidth using one of the bandwidth tests available online. If necessary, access your service account at your Internet phone service provider’s website, and reduce the bandwidth requirements for your service. For more information, refer to your Internet phone service provider’s website.

• There may be too many wireless routers or access points in your location using the same broadcast channel. Try changing the channel that your wireless router or access point uses; refer to the documentation of your router or access point for instructions.

3. The IP Phone does not ring, and my calls automatically go to voicemail.

Go through this checklist until your problem is solved:

• Check the ringer volume on the IP Phone, and make sure it is set to an audible level.

• Follow these instructions to reboot your cable or DSL modem, IP Phone, and router:

1. Power off your cable or DSL modem by unplugging its power adapter.

2. Power off the router by unplugging its power adapter.

3. Power off the IP Phone by pressing and holding down the Power button for two seconds.

4. Wait 30 seconds, and then power on your cable or DSL modem by plugging its power adapter into an electrical outlet.

5. Wait 30 seconds. Power on the router by plugging its power adapter into an electrical outlet.

Wireless-G IP Phone

Appendix A: Troubleshooting Common Problems and Solutions

Wireless-G IP Phone

6. Wait 10 seconds. Power on the IP Phone by pressing and holding down the Power button for two seconds.

7. Reboot one of your networked computers, and check for an active Internet connection.

Note: By default, the IP Phone uses a dynamic IP address assigned by your router. For port forwarding, you may need to assign a static IP address to the IP Phone. Contact your Internet phone service provider for assistance.

If you have a non-Linksys router, refer to its documentation for instructions. If you have a Linksys router, then follow these instructions:

1. On one of your networked computers, open your web browser.

2. Access the Router’s Web-based Utility by going to http://192.168.1.1 or the IP address of the Router.

3. A login screen will appear. Leave the User Name field blank. Enter the Router’s password (the default is admin) in the Password field. Then click the OK button.

4. Click the Applications & Gaming tab, and then click the Port Range Forwarding tab.

5. For each port range you must specify, enter a different name in the Application field. Then enter the number or range of external port(s) used by the IP Phone.

6. Select the protocol you will be using, UDP.

7. Enter the IP address of the IP Phone. For example, if the IP Phone’s IP address is 192.168.1.100, you would enter 100 in the field provided.

Appendix A: Troubleshooting

Common Problems and Solutions

8. Repeat steps 5-7 until you have entered all four port ranges for the IP Phone.

Application Start and End Protocol IP Address Enable

Internet phone 1 5060 to 5061 UDP (IP address of IP Phone) X

Internet phone 2 53 to 53 UDP (IP address of IP Phone) X

Internet phone 3 69 to 69 UDP (IP address of IP Phone) X

Internet phone 4 10000 to 20000 UDP (IP address of IP Phone) X

9. Check the Enable option for the port services you want to use.

10. When you have completed the configuration, click the Save Settings button.

4. The power LED does not light up.

Go through this checklist until your problem is solved:

• Remove the IP Phone’s battery from its compartment. Wait five seconds while the IP Phone resets itself. Insert the battery and power on the IP Phone.

• You may be using the wrong power adapter. Make sure the power adapter you are using is the one included with the IP Phone.

Wireless-G IP Phone

Appendix A: Troubleshooting Common Problems and Solutions

Wireless-G IP Phone

Frequently Asked Questions

Can I make calls if my Internet connection is down?

No. Your high-speed Internet connection must be active when you make Internet phone calls.

Can I use the IP Phone to make a call and browse the Internet at the same time?

No. The IP Phone supports either calling or web browsing, not both at the same time. However, you can receive a call while web browsing with the IP Phone. Also, you can make calls with the IP Phone while browsing the Internet on your computer. Please note that your web browsing may affect the quality of your telephone call, depending on the amount of upstream data traffic passing through your Internet connection.

Can I receive calls while my network is down?

You cannot directly receive calls while your network is down. However, your Internet phone service account may allow you to forward calls to a different telephone number, such as a cellular phone number. For more information, visit the website of your Internet phone service provider.

Appendix A: Troubleshooting

Frequently Asked Questions

Appendix B: Glossary

This glossary contains some basic networking terms you may come across when using this product. For more advanced terms, see the complete Linksys glossary at http://www.linksys.com/glossary.

Access Point - A device that allows wireless-equipped computers and other devices to communicate with a wired network. Also used to expand the range of a wireless network.

Ad-hoc - A group of wireless devices communicating directly with each other (peer-to-peer) without the use of an access point.

Bandwidth - The transmission capacity of a given device or network.

Bit - A binary digit.

Boot - To start a device and cause it to start executing instructions.

Broadband - An always-on, fast Internet connection.

Browser - An application program that provides a way to look at and interact with all the information on the World Wide Web.

Byte - A unit of data that is usually eight bits long

Cable Modem - A device that connects a computer to the cable television network, which in turn connects to the Internet.

Default Gateway - A device that forwards Internet traffic from your local area network.

DHCP (Dynamic Host Configuration Protocol) - A networking protocol that allows administrators to assign temporary IP

addresses to network computers by “leasing” an IP address to a user for a limited amount of time, instead of assigning permanent IP addresses.

Wireless-G IP Phone

Appendix B: Glossary

Wireless-G IP Phone

DMZ (Demilitarized Zone) - Removes the Router's firewall protection from one PC, allowing it to be “seen” from the Internet.

DNS (Domain Name Server) - The IP address of your ISP's server, which translates the names of websites into IP addresses.

Domain - A specific name for a network of computers.

Download - To receive a file transmitted over a network.

DSL (Digital Subscriber Line) - An always-on broadband connection over traditional phone lines.

Dynamic IP Address - A temporary IP address assigned by a DHCP server.

Encryption - Encoding data transmitted in a network.

Ethernet - IEEE standard network protocol that specifies how data is placed on and retrieved from a common transmission

medium.

Firmware - The programming code that runs a networking device.

FTP (File Transfer Protocol) - A protocol used to transfer files over a TCP/IP network.

Full Duplex - The ability of a networking device to receive and transmit data simultaneously.

Gateway - A device that interconnects networks with different, incompatible communications protocols.

Half Duplex - Data transmission that can occur in two directions over a single line, but only one direction at a time.

HTTP (HyperText Transport Protocol) - The communications protocol used to connect to servers on the World Wide Web.

Infrastructure - A wireless network that is bridged to a wired network via an access point.

IP (Internet Protocol) - A protocol used to send data over a network.

IP Address - The address used to identify a computer or device on a network.

Appendix B: Glossary

ISP (Internet Service Provider) - A company that provides access to the Internet.

LAN - The computers and networking products that make up your local network.

MAC (Media Access Control) Address - The unique address that a manufacturer assigns to each networking device.

Mbps (MegaBits Per Second) - One million bits per second; a unit of measurement for data transmission.

Network - A series of computers or devices connected for the purpose of data sharing, storage, and/or transmission between

users.

Packet - A unit of data sent over a network.

Passphrase - Used much like a password, a passphrase simplifies the WEP encryption process by automatically generating

the WEP encryption keys for Linksys products.

Port - The connection point on a computer or networking device used for plugging in cables or adapters.

RJ-45 (Registered Jack-45) - An Ethernet connector that holds up to eight wires.

Roaming - The ability to take a wireless device from one access point's range to another without losing the connection.

Router - A networking device that connects multiple networks together.

Server - Any computer whose function in a network is to provide user access to files, printing, communications, and other

services.

SSID (Service Set IDentifier) - Your wireless network's name.

Static IP Address - A fixed address assigned to a computer or device that is connected to a network.

Wireless-G IP Phone

Static Routing - Forwarding data in a network via a fixed path.

Subnet Mask - An address code that determines the size of the network.

Appendix B: Glossary

Wireless-G IP Phone

Switch - 1. A data switch that connects computing devices to host computers, allowing a large number of devices to share a limited number of ports. 2. A device for making, breaking, or changing the connections in an electrical circuit.

TCP (Transmission Control Protocol) - A network protocol for transmitting data that requires acknowledgement from the recipient of data sent.

TCP/IP (Transmission Control Protocol/Internet Protocol) - A set of instructions PCs use to communicate over a network.

Tel ne t - A user command and TCP/IP protocol used for accessing remote PCs.

TFTP (Trivial File Transfer Protocol) - A version of the TCP/IP FTP protocol that has no directory or password capability.

Throughput - The amount of data moved successfully from one node to another in a given time period.

Topology - The physical layout of a network.

TX Rate - Transmission Rate.

Upgrade - To replace existing software or firmware with a newer version.

Upload - To transmit a file over a network.

URL (Uniform Resource Locator) - The address of a file located on the Internet.

WAN (Wide Area Network)- The Internet.

WEP (Wired Equivalent Privacy) - A method of encrypting network data transmitted on a wireless network for greater security.

WLAN (Wireless Local Area Network) - A group of computers and associated devices that communicate with each other

wirelessly.

Appendix B: Glossary

Appendix C: Specifications

Model WIP330

Standards 802.11b, 802.11g

Channels 11 Channels (US, Canada), 13 Channels (Europe)

Transmit Power 12 dBm for 802.11b and 802.11g @ Normal Temp Range

External Interface One Mini USB 1.1 Port, One Stereo Ear Phone Jack

Display QVGA with 65k colors, 2.2 inch (55.9 mm) (240 x 320 pixels)

Network Protocols TCP/IP

Security WEP (64/128), WPA-PSK Encryption

QoS ToS

Voice Protocols SIP v2 Session Initiation Protocol (RFC3261), SDP (RFC2327)

Wireless-G IP Phone

Voice Codecs G.711 u/A-law, G.729a/b

Appendix C: Specifications

Wireless-G IP Phone

DTMF Transmission In-band, Out-band (RFC2833)

Voice Quality Acoustic Echo Cancellation

Jitter Buffer Control Comfortable Noise Generation Packet Loss Concealment

Dimensions 1.84" x 5.32" x 0.74" (W x H x D) (46.7 mm x 135.2 mm x 18.8 mm)

Unit Weight 4.20 oz. (0.12 kg)

Power 3.7V, 1250mAh Lithium Battery, 5V, 1A AC Adapter

Certifications FCC, cUL, CE

Operating Temp. 32ºF to 113ºF (0ºC to 45ºC)

Storage Temp. -4ºF to 131ºF (-20ºC to 55ºC)

Operating Humidity 10% to 85% Relative Humidity, Non-Condensing

Storage Humidity 10% to 95% Non-Condensing

Appendix C: Specifications

Wireless-G IP Phone

Appendix D: Warranty Information

LIMITED WARRANTY

Your Internet phone service provider warrants to You that, for a period of one year (the “Warranty Period”), your Linksys Product will be substantially free of defects in materials and workmanship under normal use. Your exclusive remedy and Your Internet phone service provider’s entire liability under this warranty will be for Your Internet phone service provider at its option to repair or replace the Product or refund Your purchase price less any rebates. This limited warranty extends only to the original purchaser.

If the Product proves defective during the Warranty Period call Your Internet phone service provider Technical Support in order to obtain a Return Authorization Number, if applicable. If You are requested to return the Product, mark the Return Authorization Number clearly on the outside of the package. You are responsible for shipping defective Products to Your Internet phone service provider.

ALL IMPLIED WARRANTIES AND CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED TO THE DURATION OF THE WARRANTY PERIOD. ALL OTHER EXPRESS OR IMPLIED CONDITIONS, REPRESENTATIONS AND WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF NONINFRINGEMENT, ARE DISCLAIMED. Some jurisdictions do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to You. This warranty gives You specific legal rights, and You may also have other rights which vary by jurisdiction.

This warranty does not apply if the Product (a) has been altered, except by Your Internet phone service provider, (b) has not been installed, operated, repaired, or maintained in accordance with instructions supplied by Your Internet phone service provider, or (c) has been subjected to abnormal physical or electrical stress, misuse, negligence, or accident. In addition, due to the continual development of new techniques for intruding upon and attacking networks, Your Internet phone service provider does not warrant that the Product will be free of vulnerability to intrusion or attack.

TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT WILL YOUR INTERNET PHONE SERVICE PROVIDER BE LIABLE FOR ANY LOST DATA, REVENUE OR PROFIT, OR FOR SPECIAL, INDIRECT, CONSEQUENTIAL, INCIDENTAL OR PUNITIVE DAMAGES, REGARDLESS OF THE THEORY OF LIABILITY (INCLUDING NEGLIGENCE), ARISING OUT OF OR RELATED TO THE USE OF OR INABILITY TO USE THE PRODUCT (INCLUDING ANY SOFTWARE), EVEN IF Your Internet phone service provider HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT WILL Your Internet phone service provider’ LIABILITY EXCEED THE AMOUNT PAID BY YOU FOR THE PRODUCT. The foregoing limitations will apply even if any warranty or remedy provided under this Agreement fails of its essential purpose. Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to You.

Please contact your Internet phone service provider regarding the warranty for the Product.

Appendix D: Warranty Information

Wireless-G IP Phone

Appendix D: Warranty Information

Wireless-G IP Phone

Appendix E: Regulatory Information

FCC Statement

This product has been tested and complies with the specifications for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used according to the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which is found by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.

IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment has been SAR-evaluated. The Maximum average SAR(1g) test value is 0.303 W/kg. Linksys declares that WIP 330 (FCC ID: Q87-WIP330) is limited in CH1~CH11 for 2.4 GHz by specified firmware controlled in U.S.A.

Appendix E: Regulatory Information

Wireless-G IP Phone

Safety Notices

Caution: To reduce the risk of fire, use only No. 26 AWG or larger telecommunication line cord. Do not use this product near water, for example, in a wet basement or near a swimming pool. Avoid using this product during an electrical storm. There may be a remote risk of electric shock from lightning.

Industry Canada

This device complies with Industry Canada ICES-003 and RSS210 rules.

Cet appareil est conforme aux normes NMB003 et RSS210 d'Industrie Canada.

IC Statement

Operation is subject to the following two conditions:

1. This device may not cause interference and

2. This device must accept any interference, including interference that may cause undesired operation of the device.

Règlement d’Industry Canada

Les conditions de fonctionnement sont sujettes à deux conditions:

1. Ce périphérique ne doit pas causer d’interférence et

2. Ce périphérique doit accepter toute interférence, y compris les interférences pouvant perturber le bon fonctionnement de ce périphérique

IMPORTANT NOTE: IC Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. To maintain compliance with IC RF exposure compliance requirements, please avoid direct contact to the transmitting antenna during transmitting. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

Appendix E: Regulatory Information

User Information for Consumer Products Covered by EU Directive 2002/96/EC on Waste Electric and Electronic Equipment (WEEE)

This document contains important information for users with regards to the proper disposal and recycling of Linksys products. Consumers are required to comply with this notice for all electronic products bearing the following symbol:

Wireless-G IP Phone

Appendix E: Regulatory Information

Wireless-G IP Phone

Appendix E: Regulatory Information

Wireless-G IP Phone

Appendix E: Regulatory Information

Wireless-G IP Phone

Appendix E: Regulatory Information

Wireless-G IP Phone

Appendix E: Regulatory Information

Wireless-G IP Phone

Appendix E: Regulatory Information

Wireless-G IP Phone

Appendix E: Regulatory Information

Wireless-G IP Phone

Appendix E: Regulatory Information

Wireless-G IP Phone

Appendix E: Regulatory Information

Wireless-G IP Phone

Appendix E: Regulatory Information

Wireless-G IP Phone

Appendix E: Regulatory Information

Wireless-G IP Phone

For more information, visit www.linksys.com.

Appendix E: Regulatory Information

Appendix F: Contact Information

Need to contact Linksys? Visit us online for information on the latest products and updates to your existing products at: http://www.linksys.com or

ftp.linksys.com Can't find information about a product you want to buy on the web? Do you want to know more about networking with Linksys products? Give our advice line a call at: 800-546-5797 (LINKSYS) Or fax your request in to: 949-823-3002

If you experience problems with any Linksys product, you can call us at: 800-326-7114 Don't wish to call? You can e-mail us at: support@linksys.com

Wireless-G IP Phone

Appendix F: Contact Information

Wireless-G IP Phone

Appendix F: Contact Information

www.linksys.com

Linksys WIP330 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

List of Figures

Chapter 1: Introduction

Chapter 2: Getting to Know the Wireless-G IP Phone

Chapter 3: Installing and Using the Wireless-G IP Phone

Chapter 4: Configuring the Wireless-G IP Phone

Appendix A: Troubleshooting

Appendix B: Glossary

Appendix C: Specifications

Appendix D: Warranty Information

Appendix E: Regulatory Information

Appendix F: Contact Information
