LINCOLN NAVIGATOR User Manual

Introduction 4

Instrument Cluster 12

Warning and control lights 12 Gauges 15

Entertainment Systems 18

AM/FM stereo cassette with CD 18 AM/FM stereo with in-dash six CD 23 Rear seat controls 28 Rear seat entertainment system 33 Navigation system 46

Climate Controls 109

Automatic temperature control 111 Auxiliary passenger climate control 115 Rear window defroster 116

Lights 117

Headlamps 117 Turn signal control 120 Bulb replacement 122

Driver Controls 130

Windshield wiper/washer control 130 Power windows 137 Mirrors 140 Speed control 144 Message center 154

Locks and Security 170

Keys 170 Locks 170

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Table of Contents

Seating and Safety Restraints 185

Seating 185 Safety restraints 201 Airbags 213 Child restraints 221

Tires, Wheels and Loading 235

Tire Information 237 Tire Inflation 239 Tire Pressure Monitoring System (TPMS) 251 Vehicle loading 256 Trailer towing 263 Recreational towing 269

Driving 271

Starting 271 Brakes 275 Air suspension 282 Transmission operation 284

Roadside Emergencies 302

Getting roadside assistance 302 Hazard flasher switch 303 Fuel pump shut-off switch 304 Fuses and relays 305 Changing tires 315 Lug Nut Torque 322 Jump starting 323 Wrecker towing 329

Customer Assistance 331

Reporting safety defects (U.S. only) 339

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Table of Contents

Cleaning 340

Maintenance and Specifications 346

Engine compartment 348 Engine oil 351 Battery 354 Engine Coolant 356 Fuel information 362 Air filter(s) 374 Part numbers 376 Refill capacities 377 Lubricant specifications 379

Accessories 385

Index 387

All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Ford may change the contents without notice and without incurring obligation.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Introduction

CALIFORNIA Proposition 65 Warning

WARNING: Engine exhaust, some of its constituents, and

certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

CONGRATULATIONS

Congratulations on acquiring your new Lincoln. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.

For more information on Ford Motor Company and its products visit the following website:

• In the United States: www.ford.com

• In Canada: www.ford.ca

• In Mexico: www.ford.com.mx

• In Australia: www.ford.com.au

Additional owner information is given in separate publications.

This Owner’s Guide describes every option and model variant available and therefore some of the items covered may not apply to your particular vehicle. Furthermore, due to printing cycles it may describe options before they are generally available.

Remember to pass on the Owner’s Guide when reselling the vehicle. It is an integral part of the vehicle.

Fuel pump shut-off switch: In the event of an accident the

safety switch will automatically cut off the fuel supply to the engine. The switch can also be activated through sudden vibration (e.g. collision when parking). To reset the switch, refer to the Fuel pump shut-off switch in the Roadside Emergencies chapter.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Introduction

SAFETY AND ENVIRONMENT PROTECTION

Warning symbols in this guide

How can you reduce the risk of personal injury to yourself or others? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.

Warning symbols on your vehicle

When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind.

Protecting the environment

We must all play our part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps towards this aim. Information in this respect is highlighted in this guide with the tree symbol.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Introduction

BREAKING-IN YOUR VEHICLE

Your vehicle does not need an extensive break-in. Try not to drive continuously at the same speed for the first 1,000 miles (1,600 km) of new vehicle operation. Vary your speed frequently in order to give the moving parts a chance to break in.

Drive your new vehicle at least 500 miles (800 km) before towing a trailer. Additionally, during the first 500 miles (800 km) that you tow a trailer, do not drive over 70 mph (112 km/h) and do not make starts at full throttle. This style of driving will help the engine and other parts of your vehicle break in at the heavier loads. For more detailed information about towing a trailer, refer to Trailer towing in the Tires, Wheels and Loading chapter.

Do not add friction modifier compounds or special break-in oils during the first few thousand miles (kilometers) of operation, since these additives may prevent piston ring seating. See Engine oil in the Maintenance and Specifications chapter for more information on oil usage.

SPECIAL NOTICES

New Vehicle Limited Warranty

For a detailed description of what is covered and what is not covered by your vehicle’s New Vehicle Limited Warranty, refer to the Warranty Guide that is provided to you along with your Owner’s Guide.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Introduction

Service Data Recording

Service data recorders in your vehicle are capable of collecting and storing diagnostic information about your vehicle. This potentially includes information about the performance or status of various systems and modules in the vehicle, such as engine, throttle, steering or brake systems. In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle.

Event Data Recording

Other modules in your vehicle — event data recorders — are capable of collecting and storing data during a crash or near crash event. The recorded information may assist in the investigation of such an event. The modules may record information about both the vehicle and the occupants, potentially including information such as:

• how various systems in your vehicle were operating;

• whether or not the driver and passenger seatbelts were buckled;

• how far (if at all) the driver was depressing the accelerator and/or the

brake pedal;

• how fast the vehicle was traveling; and

• where the driver was positioning the steering wheel.

To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent, unless pursuant to court order or where required by law enforcement, other government authorities or other third parties acting with lawful authority. Other parties may seek to access the information independently of Ford Motor Company and Ford of Canada.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Introduction

Special instructions

For your added safety, your vehicle is fitted with sophisticated electronic controls.

Please read the section Supplemental restraint system (SRS)

in the Seating and Safety Restraints chapter. Failure to follow the specific warnings and instructions could result in personal injury.

Front seat mounted rear-facing child or infant seats should

NEVER be placed in front of an active passenger air bag.

Using your vehicle with a snowplow

Do not use this vehicle for snowplowing.

Your vehicle is not equipped with a snowplowing package.

Notice to owners of pickup trucks and utility type vehicles

Utility vehicles have a significantly higher rollover rate than

other types of vehicles.

Before you drive your vehicle, please read this Owner’s Guide carefully. Your vehicle is not a passenger car. As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of vehicle control, vehicle rollover, personal injury or death.

Be sure to read Driving off road in the Driving chapter.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Introduction

Cell phone use

The use of Mobile Communications Equipment has become increasingly important in the conduct of business and personal affairs. However, drivers must not compromise their own or others’ safety when using such equipment. Mobile Communications can enhance personal safety and security when appropriately used, particularly in emergency situations. Safety must be paramount when using mobile communications equipment to avoid negating these benefits.

Mobile Communication Equipment includes, but is not limited to cellular phones, pagers, portable email devices, in-vehicle communications systems, telematics devices and portable two-way radios.

A driver’s first responsibility is the safe operation of the vehicle.

The most important thing you can do to prevent a crash is to avoid distractions and pay attention to the road. Wait until it is safe to operate Mobile Communications Equipment.

Middle East/North Africa vehicle specific information

For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner’s Guide; therefore, a supplement has been supplied that complements this book. By referring to the pages in the provided supplement, you can properly identify those features, recommendations and specifications that are unique to your vehicle. Refer to this

Owner’s Guide for all other required information and warnings.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Introduction

These are some of the symbols you may see on your vehicle.

Vehicle Symbol Glossary

Safety Alert

Fasten Safety Belt Air Bag-Front

Air Bag-Side Child Seat

Child Seat Installation Warning

Child Seat Tether Anchor

Anti-Lock Brake System

Powertrain Malfunction Speed Control

Master Lighting Switch Hazard Warning Flasher

Fog Lamps-Front Fuse Compartment

See Owner’s Guide

Child Seat Lower Anchor

Brake System

Brake Fluid Non-Petroleum Based

Fuel Pump Reset Windshield Wash/Wipe

Windshield Defrost/Demist

Rear Window Defrost/Demist

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Vehicle Symbol Glossary

Introduction

Power Windows Front/Rear

Child Safety Door Lock/Unlock

Power Window Lockout

Interior Luggage Compartment Release Symbol

Panic Alarm Engine Oil

Engine Coolant

Engine Coolant Temperature

Do Not Open When Hot Battery

Avoid Smoking, Flames, or Sparks

Battery Acid

Explosive Gas Fan Warning

Power Steering Fluid

Maintain Correct Fluid Level

Emission System Engine Air Filter

MAX

MIN

Passenger Compartment Air Filter

Check fuel cap

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Jack

Low tire pressure warning

Instrument Cluster

WARNING LIGHTS AND CHIMES

Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works. If any light remains on after starting the vehicle, refer to the respective system warning light for additional information.

Service engine soon: The indicator light illuminates when the ignition is first turned to the ON position to check the bulb. Solid illumination after the engine is started indicates the On Board Diagnostics System (OBD-II) has detected a malfunction. Refer to On board diagnostics (OBD-II) in the Maintenance and Specifications chapter. If the light is blinking, engine misfire is occurring which could damage your catalytic converter. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced immediately by your authorized dealer.

Under engine misfire conditions, excessive exhaust temperatures

could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire.

Brake system warning light: To confirm the brake system warning light is functional, it will momentarily illuminate when the ignition is turned to the ON position when the engine is not running, or in a position between ON and START,

BRAKE

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Instrument Cluster

or by applying the parking brake when the ignition is turned to the ON position. If the brake system warning light does not illuminate at this time, seek service immediately from your authorized dealer. Illumination after releasing the parking brake indicates low brake fluid level and the brake system should be inspected immediately by your authorized dealer.

Driving a vehicle with the brake system warning light on is

dangerous. A significant decrease in braking performance may occur. It will take you longer to stop the vehicle. Have the vehicle checked by your authorized dealer.

Anti-lock brake system: If the ABS light stays illuminated or continues to flash, a malfunction has been detected, have the system serviced immediately by your authorized dealer. Normal braking is still functional unless the brake warning light also is illuminated.

Air bag readiness: If this light fails to illuminate when ignition is turned to ON, continues to flash or remains on, have the system serviced immediately by your authorized dealer. A chime will also sound when a malfunction in the supplemental restraint system has been detected.

Safety belt: Reminds you to fasten your safety belt. A chime will also sound to remind you to fasten your safety belt.

ABS

Charging system: Illuminates when the battery is not charging properly.

Engine oil pressure: Illuminates when the oil pressure falls below the normal range. Refer to Engine oil in the Maintenance and Specifications chapter.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Instrument Cluster

Engine coolant temperature:

Illuminates when the engine coolant temperature is high. Stop the vehicle as soon as safely possible, switch off the engine and let it cool. Refer to Engine coolant in the Maintenance and Specifications chapter.

Never remove the coolant reservoir cap while the engine is

running or hot.

Low tire pressure warning (if equipped with the Tire Pressure Monitoring System): Illuminates

when your tire pressure is low. If the light remains on at start up or while driving, the tire pressure should be checked. Refer to Inspecting and Inflating Your Tires in the Tires, Wheels and Loading chapter. When the ignition is first turned to ON, the light will illuminate for 3 seconds to ensure the bulb is working. If the light does not turn ON, have the system inspected by your authorized dealer. For more information on this system, refer to Understanding Your Tire Pressure Monitoring System in the Tires, Wheels and Loading chapter.

AdvanceTrac威 (if equipped):

Illuminates when the AdvanceTrac威 with RSC system is active. If the light remains on, have the system serviced immediately by your authorized dealer.

Speed control: Illuminates when the speed control is activated. Turns off when the speed control system is deactivated.

Four wheel drive low (if equipped): Illuminates when

four-wheel drive low is engaged. If the light fails to illuminate when the ignition is turned ON, continues to flash or remains on, have the system serviced immediately by your authorized dealer.

4x4

LOW

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Instrument Cluster

Four wheel drive high (if equipped): Illuminates when

four-wheel drive high is engaged. If the light fails to illuminate when the ignition is turned ON, continues to flash or remains on, have the system serviced immediately by your authorized dealer.

Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators stay on or flash faster, check for a burned out bulb.

High beams: Illuminates when the high beam headlamps are turned on.

Key-in-ignition warning chime: Sounds when the key is left in the ignition in the OFF/LOCK or ACCESSORY position and the driver’s door is opened.

Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened.

Door ajar warning chime: Sounds when any door, liftgate or the liftgate glass is opened (or not fully closed).

GAUGES

4x4

HIGH

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Instrument Cluster

Speedometer: Indicates the current vehicle speed.

Engine coolant temperature gauge: Indicates engine coolant

temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool. Refer to Engine coolant in the Maintenance and Specifications chapter.

Never remove the coolant reservoir cap while the engine is

running or hot.

Odometer: Registers the total miles (kilometers) of the vehicle.

Refer to Message Center in the Drivers Controls chapter on how to switch the display from Metric to English.

Trip odometer: Registers the miles (kilometers) of individual journeys. Press and release the message center INFO button until “TRIP” appears in the display (this represents the trip mode). Press the control again to select Trip 1 and Trip 2 features. Press and hold the RESET button for two seconds to reset.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Instrument Cluster

Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine.

Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion or on a grade. The ignition should be in the OFF position while the vehicle is being refueled. When the gauge first indicates empty, there is a small amount of reserve fuel in the tank. When refueling the vehicle from empty indication, the amount of fuel that can be added will be less than the advertised capacity due to the reserve fuel.

The FUEL icon and arrow indicates which side of the vehicle the fuel filler door is located.

Refer to Filling the tank in the Maintenance and Specifications chapter for more information.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

AUDIO SYSTEMS

Premium Satellite Compatible AM/FM Stereo/Cassette/Single CD/MP3 radio ( if equipped)

1. EJ (Eject): Press to stop and eject a tape.

2. EJ (Eject): Press to stop and eject a CD.

3. BASS: Allows you to increase or decrease the audio system’s bass output. Press BASS then press TEXT/SEL to decrease

increase the bass levels.

TREB (Treble): Allows you to increase or decrease the audio system’s treble output. Press TREB then press TEXT/SEL to

decrease

or increase the treble levels.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

4. BAL (Balance): Allows you to shift speaker sound between the right and left speakers. Press BAL then press TEXT/SEL to shift sound

to the left

FADE: Allows you to shift speaker sound between the front and rear speakers. Press FADE then press TEXT/SEL to shift the sound to the

rear

5. SHUF (Shuffle): Press to play the CD/MP3 track on the current disc in random order. Press again to deactivate random play.

REPT (Repeat): Press to repeat the current CD/MP3 track.

6. Memory preset stations: To set a memory preset station, tune the radio to the desired station, then press and hold the memory preset control until the sound returns.

7. TEXT/SEL: Select — Use to adjust bass, treble, balance and fade levels.

TEXT: TEXT is available when equipped with Satellite radio. Your radio comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your authorized dealer. Detailed Satellite instructions are included with the dealer installed kit. TEXT is also available with ID3 tags on MP3 files. Dealer installed satellite kit only

available in the continental United States.

8. Folder: Press to reverse ( advance (

or right .

or the front .

)or

) MP3 folders.

9. REW (Rewind): Worksintape and CD modes.

In tape mode, radio play continues until rewind is stopped (by pressing REW again) or the beginning of the tape is reached.

In CD mode, REW control reverses the CD within the current track.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

FF (Fast Forward): Works in tape and CD modes.

In the tape mode, tape direction automatically reverses when the end of the tape is reached.

In CD mode, FF advances the CD within the current track. Fast forward is stopped by pressing FF again.

10. AUX: Press to toggle between the current playing media and DVD (if equipped).

SCAN: Press for a brief sampling of radio stations, tape selections or CD tracks. Press again to deactivate scan mode.

11. Phone/Mute: Press to mute the playing media. Press again to return to the playing media.

12. MENU: Press to access the following options:

• Compression: In CD/MP3 modes, select to bring loud and soft

passages together for a more consistent listening level.

• Folder/Track mode: In MP3 mode, press MENU until MODE appears

in the display. Use SEL to toggle between FOLDER (only tracks within selected folder are accessible) or TRACK (all tracks on disc are accessible).

• Setting the clock: Your vehicle is equipped with a separate analog

clock. Refer to Setting the clock in the Driver Controls Chapter.

• AUTOSET: Press to set first six strong stations into AM, FM1 or FM2

memory buttons; press again to return to the original preset stations. If there are less than six strong stations available on the frequency band, the remaining memory preset controls will all store the last strong station available.

• Speed sensitive volume (if equipped): Automatically changes the

volume with vehicle speed to compensate for road and wind noise. The recommended level is 1–3. Level 0 turns the speed sensitive volume off and level 7 is the maximum setting. To engage the speed sensitive volume feature, press MENU until SPEED VOL X appears in the display. Press TEXT/SEL to

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

increase /decrease volume compensation levels. The selected level will appear in the display.

13. TUNE/CAT: In radio mode, press to manually advance up/down the frequency band. In satellite radio mode, press CAT for a listing of available music categories.

CAT: CAT is only available when equipped with Satellite Radio. Your Audiophile radio comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your authorized dealer. Detailed Satellite instructions are included with the dealer installed kit.

Dealer installed satellite kit only available in the continental United States.

For information regarding SIRIUS Satellite Radio, please call toll-free 888-539-SIRIUS (888-539-7474) or visit the SIRIUS website at www.siriusradio.com

14. SEEK: Works in radio, tape and CD modes. Press to access the

previous radio station, tape selection or CD track.

15. BAND: Press to toggle between AM/FM1/FM2 frequency bands. Press while in tape or CD mode to return to radio mode.

CD: Press CD to enter CD mode and to play a CD already in the system. Press the CD control to toggle between CD and DVD (if equipped).

16. Power/volume: Press to turn the system on/off. Turn to raise/lower the volume.

If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. Audio power can also be turned on by pressing the AM/FM select control or the TAPE or CD select control.

or next listenable

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

17. TAPE: Press to begin tape play. Press during fast forward or rewind to stop fast forward or rewind function.

18. CD slot: Insert the disc with the playing side down and printed side up.

CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ballpoint pens may damage CDs. Please contact your authorized dealer for further information.

19. Tape door: Insert the tape facing the right.

The Dolby威 noise reduction system is manufactured under license from Dolby Laboratories Licensing Corporation. Dolby威 and the double-D symbol are registered trademarks of Dolby威 Laboratories Licensing Corporation.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Audiophile Satellite Compatible AM/FM Stereo In-Dash Six CD/MP3 Radio (if equipped)

1. SEEK: Press and release SEEK strong station or track.

2. TEXT: The filename (Fi), song title (So), artist text (Ar) or album text (AL) may be viewed while playing an MP3 selection. When MP3 selection text is shown on the message display its corresponding text indicator (Fi, So, Ar, or AL) is shown in the elapsed time display. Press TEXT to scroll through the text fields. The display will scroll all of the text in the current field before changing to the next field. (TEXT must be pressed within 3 seconds of the previous button press to proceed to the next/last text display.)

TEXT is also available when equipped with Satellite radio. Your Audiophile radio comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your authorized dealer. Detailed Satellite instructions are included with the dealer installed kit.

Dealer installed satellite kit only available in the continental United States.

/ for previous/next

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

3. AUX: Press to toggle between the current playing media and DVD (if equipped).

4. MUTE: Press to MUTE playing media; press again to return to playing media

5. EJ: Press to eject a CD. Press EJ and a memory preset to eject a specific disc. Press and hold to eject all loaded discs.

6. Bass: Press BASS; then press SEL the bass output.

Treble: Press TREB; then press SEL the treble output.

7. Select: Use with Bass, Treble, Balance, Fade and other menu functions.

8. Balance: Press BAL; then press SEL left/right speakers.

Fade: Press FADE; then press SEL rear/front speakers.

9. Menu: Press and hold MENU to access RDS on/off, Traffic announcement mode, Program type mode and use SEL to toggle functions ON/OFF.

The Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC) recommend that FM radio broadcasters use RDS technology to transmit information. FM radio stations are independently operated and individually elect to use RDS technology to transmit station ID and program type as desired.

/ to decrease/increase

/ to shift sound to the

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Traffic (if equipped): Allows you to hear traffic broadcasts. With the feature ON, press SEEK or SCAN to find a station broadcasting a traffic report (if it is broadcasting RDS data).Traffic information is not

available in most U.S. markets.

FIND Program type (if equipped): Allows you to search RDS-equipped stations for a certain category of music format: Classic, Country, Info, Jazz, Oldies, R&B, Religious, Rock, Soft, Top 40. Press MENU until FIND appears in the display. Use SEL to scroll through music types. Press SEEK or SCAN to search for a station playing the requested music category.

Show TYPE (if equipped): Displays the station’s call letters or music format. Press MENU until SHOW appears in the display. Use SEL to select NONE, NAME or TYPE.

Compression: Brings soft and loud CD passages together for a more consistent listening level when in CD mode. Press MENU until compression status is displayed. Press the SEL control to enable the compression feature when COMPRESS OFF is displayed. Press the SEL control again to disable the feature when COMPRESS ON is displayed.

Occupancy mode (if equipped): Press MENU until occupancy mode appears in the display. Press SEL to select ALL, DRIVER or REAR SEAT occupancy mode.

Autoset: Allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2 . Press MENU until AUTOSET appears in the display. Press SEL to toggle ON/OFF. When the six strongest stations are filled, the station stored in preset 1 will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets.

Speed sensitive volume: Radio volume changes automatically and slightly with vehicle speed to compensate for road and wind noise. Recommended level is 1–3. Level 0 turns the feature off and level 7 is the maximum setting. Press MENU until SPEED VOL X appears in the display. Then press SEL

to increase ( appear in the display.

Setting the clock: Your vehicle is equipped with a separate analog clock. Refer to Setting the Clock in the Driver Controls Chapter.

Folder/Track Mode: In MP3 mode, press MENU until MODE appears in the display. Use SEL to toggle between FOLDER (only tracks within selected folder are accessible) or TRACK (all tracks on disc are accessible) MODE.

) or decrease ( ) the volume setting. The level will

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

10. REPEAT: Press to repeat the current CD/MP3 track. Press again to disable.

11. SHUFFLE: Press to play the CD/MP3 tracks on the current disc in random order. Press again to disable.

12. FOLDER the next MP3 directory.

: Press to access

13. FOLDER the previous MP3 directory

14. FF(Fast forward): In CD mode, press until desired selection is reached.

15. REW(Rewind): In CD mode, press until desired selection is reached.

16. SAT (if equipped): Your radio comes equipped with Satellite Ready capability. The kit to enable the Satellite reception is available through your authorized dealer. Detailed satellite instructions are included with the dealer installed kit. Dealer

installed satellite kit only available in the continental United States.

17. BAND: Press to toggle between AM/FM1/FM2 frequency band.

18. Memory presets: To set a station: Select frequency, tune to a station, press and hold a preset button until sound returns.

19. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels.

: Press to access

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

20. Load: Press to load a CD. Press LOAD and a memory preset to load to a specific disc slot. Press and hold to load up to six discs.

21. CD: Press to enter CD mode.

22. Scan: Press SCAN to hear a brief sampling of radio stations or CD/MP3 tracks. Press again to stop.

23. Disc/Tune: Press manually tune down/up the radio

frequency band, or to listen to the previous/next CD.

CAT: CAT is only available when equipped with Satellite Radio. Your Audiophile radio comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your dealer. Detailed Satellite instructions are included with the dealer installed kit. Dealer

installed satellite kit only available in the continental United States.

For information regarding SIRIUS Satellite Radio, please call toll-free 888-539-SIRIUS (888-539-7474) or visit the SIRIUS website at www.siriusradio.com

24. CD slot: Insert a CD, label side up.

or to

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Rear seat radio controls (if equipped)

If your vehicle is equipped with a front row console, then it is also equipped with rear seat radio controls. This feature allows front and middle seat passengers to listen to different media sources (radio, cassette, CD or DVD) simultaneously. (However, the front and middle-seat passengers cannot listen to two different radio stations at the same time.)

When the rear seat controls are activated, rear seat passengers can use the controls to change the playing media for all passengers (Single Play mode). In this mode, all speakers will play audio from the same media source for all passengers to hear. To activate the rear seat radio controls:

• Press the memory preset controls 3 and 5 at the same time. A headphone icon

will illuminate

in the radio display, indicating the rear seat radio controls are active.

• Press memory preset controls 3 and 5 a second time to deactivate the rear seat controls. The headphone icon display.

If there is a discrepancy between the rear seat controls and the front audio controls (such as both trying to listen to the same playing media), the front audio system will receive the desired selection.

To activate Dual Play mode (rear seat passengers listen to a different playing media than the front seat passengers):

• Press the speaker/headphone control.

• Press the MODE control to change audio sources (for headphone mode only)

• Use the SEEK, VOLUME and MEMORY controls to make adjustments to the playing media.

VOLUME +MODE

SEEK MEMORY

will turn off in the radio

VOLUME +MODE

SEEK MEMORY

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

• Dual Play mode may also be activated by pressing memory

1 2 3 4 5 6

presets 2 and 4 simultaneously on the front audio controls.

The rear speakers mute and rear seat passengers have audio (for their selected media) available through their headphones.

To adjust the volume

The volume control allows the rear seat passengers to adjust the volume level of the audio system.

Press the + control to increase

volume.

VOLUME +MODE

Press the - control to decrease volume.

SEEK MEMORY

From the rear seat controls, volume control can be set no higher than the current radio setting unless the speakers are turned off.

Turning the rear speakers on and off

Press the headphone/speaker

control to turn the rear speakers on

VOLUME +MODE

(Single Play mode) or off (Dual Play mode).

SEEK MEMORY

Using headphones/Dual Play mode

Plug a 3.5 mm headphone (not included) into the

jack. Press the speaker on/off control to operate the headphones. DUAL PLAY illuminates in the radio display and the fade control is disabled, signaling that Dual Play has been activated.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

The rear speakers will cut out once the speaker on/off control is pressed. The front speaker will remain playing for the front passengers. Press the control again to deactivate the headphones. SINGLE PLAY illuminates in the radio display and the fade control is enabled, signaling that Dual Play mode has been deactivated.

To enable Dual Play, the rear seat controls must be active and

Mode select

Push the MODE control to toggle between AM, FM1, FM2, tape (if equipped), CD, CD changer (if equipped) or DVD (if equipped). If in Dual Play mode, SHARED illuminates in the radio display when the front and rear modes are set to the same media.

Memory preset control

Push the MEMORY control successively to allow rear seat passengers to scroll through the 6 memory presets in AM, FM1 or FM2.

Push the MEMORY control in CD mode (if equipped) to advance to the next disc.

illuminated in the radio display.

VOLUME +MODE

SEEK MEMORY

VOLUME +MODE

SEEK MEMORY

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Seek function

• In radio mode, press

the next listenable station down the frequency band.

• In radio mode, press

the next listenable station up the frequency band.

• In tape mode (if equipped), use

the SEEK function to access the next selection.

• In CD mode (if equipped), use the SEEK function to access the

Parental control

Press the memory preset controls 3 and 5 simultaneously on the front audio controls to disable the rear seat controls. They will remain disabled until the front seat passengers “enable” them again by simultaneously pressing the 3 and 5 preset controls. The settings of the front seat controls will always override those of the rear seat controls.

GENERAL AUDIO INFORMATION

Radio frequencies: AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC). Those frequencies are:

AM - 530, 540–1700, 1710 kHz

FM- 87.7, 87.9–107.7, 107.9 MHz

Radio reception factors: There are three factors that can affect radio reception:

• Distance/strength: The further you travel from a station, the weaker

the signal and the weaker the reception.

• Terrain: Hills, mountains, tall buildings, power lines, electric fences,

traffic lights and thunderstorms can interfere with your reception.

• Station overload: When you pass a broadcast tower, a stronger signal

may overtake a weaker one and play while the weak station frequency is displayed.

or previous

or previous selection.

to find

VOLUME +MODE

SEEK MEMORY

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Cassette/player care:

Do:

• Use only cassettes that are 90 minutes long or less.

• Tighten very loose tapes by inserting a finger or pencil into the hole

and turning the hub.

• Remove loose labels before inserting tapes.

• Allow tapes which have been subjected to extreme heat, humidity or

cold to reach a moderate temperature before playing.

• Clean the cassette player head with a cassette cleaning cartridge after

10–12 hours of play to maintain good sound/operation.

Don’t:

• Expose tapes to direct sunlight, extreme humidity, heat or cold.

• Leave tapes in the cassette player for a long time when not being

played.

CD/CD player care:

Do:

• Handle discs by their edges only. Never touch the playing surface.

• Inspect discs before playing. Clean only with an approved CD cleaner

and wipe from the center out.

Don’t:

• Expose discs to direct sunlight or heat sources for extended periods

of time.

• Insert more than one disc into each slot of the CD changer magazine.

• Clean using a circular motion.

Audio system warranty and service: Refer to the Warranty Guide

for audio system warranty information. If service is necessary, see your dealer or qualified technician.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Whenever a warning is received, the radio volume will be lowered to a volume that will allow the tones to be heard. The radio volume will return to the previous level after the warning goes away.

REAR SEAT ENTERTAINMENT DVD SYSTEM (IF EQUIPPED)

Your vehicle may be equipped with a Rear Seat Entertainment DVD System which allows you to watch DVDs, DVDR/RW, play music CDs, CDR/RW, MP3s and to plug in and play video game systems. Please review this material to become familiar with the system features and safety information.

DVD player controls

1. MAIN control

• NEXT — Press to access the next track on the CD, the next chapter

on the DVD, or to go up in cursor mode.

• PREV — Press to access the previous track on the CD, the previous

chapter on the DVD, or to go down in cursor mode.

• REV — Press to reverse in CD and DVD play modes or to move the

cursor left in the menu active mode.

• FWD —Press to advance in CD and DVD play modes or to move the

cursor right in the menu active mode.

2. PLAY/PAUSE control

Press to playback or pause the DVD.

3. DIM control

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Adjust to increase (+) or decrease (-) the amount of brightness on the screen.

4. ENTER control

Press to select the function pointed to within the active menu. May also be used by some user interactive discs during movie play.

5. MENU control

Press to bring up the disc menu.

6. AUX control

Press to switch DVD player from play mode to auxiliary mode.

7. Auxiliary jacks

Insert lines for standard video game players.

8. STOP/EJECT control

Press once to stop DVD play. Press again to eject the DVD.

9. DISPLAY (DISP) control

Press to enable on screen display of player menu and user display adjustments.

DVD control features

Menu control

Press the MENU control to enter into MENU mode. This allows you to move and choose within the DVD generated menu structure. Once in MENU mode:

• Press the NEXT control to move

the cursor one position upward

REV

FWD

• Press the PREV control to move

the cursor one position downward

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

REV

FWD

Entertainment Systems

• Press the REV control to move

the cursor left one position

REV

• Press the FWD control to move

the cursor right one position

REV

Next/Previous control

The NEXT (up) and PREV (down) controls allow you to access the next or previous track on a CD or

REV

chapter on a DVD. When pressed, the playing audio will mute momentarily while the next chapter is accessed. Press and hold to advance or reverse multiple tracks or chapters.

REV/FWD control

Press the REV/FWD control during playback mode to reverse or advance at a normal speed. Press

REV

the REV/FWD control again to disengage the reverse/advance action and return to normal playback mode

FWD

Enter control

The ENTER control allows you to select items when in MENU mode.

Press the ENTER control to select the desired highlighted item.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

ENTER

Entertainment Systems

CD play mode

Press NEXT during CD play to advance to the next track. If you press NEXT during the last track, the system will wrap around to the first track and begin play.

Slow play mode

To enter slow play mode, press the PLAY/PAUSE control. Once the system is in pause mode, press the FWD or REV control for slow motion playback. Three different speeds are available depending on how long the control is held. Press the control once for slow motion playback. Press the control again to disengage slow motion playback. Press the PLAY/PAUSE control to return to normal playback mode.

User menu mode

To adjust the display setting, press DISP once and the current display setting will appear on the screen along with the current media status. Pressing DISP again will toggle the display setting through the next available display settings. (Available screen selections are 4x3, ZOOM, and 16x9.) The setting will disappear after approximately three seconds, but the title bar and audio setting will remain on the screen until DISP is pressed again.

The DVD player will read the disc type and configure the display accordingly. Some movies have a wide screen movie format to fit a normal 4x3 screen. In this case, the movie will have black bars on the top and bottom or left and right of the image on the screen. When shown on the screen, it may appear as a small screen within the wide screen. It may be desirable to view this type of movie in ZOOM mode. To enter ZOOM mode, press DISP once for the current display setting and press DISP again within three seconds to change the display setting to the desired display setting.

REV

DISP

FWD

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Remote control

Entertainment Systems

REV

MNU

MODE

DISP

MEMORY

FWD

SEEKVOL

ENT

1. REWIND control Press to reverse the direction of the DVD movie.

2. FAST FORWARD control

Press to advance the direction of the DVD movie.

3. PLAY/STOP control

Press to play or stop the DVD movie.

4. SEEK control

Press to reverse or advance the chapter of the DVD or the track of the CD.

5. DISPLAY (DISP) control

Press to enable on screen display of player menu and user display adjustments. Once the display is on, use SEEK to choose the desired screen setting.

6. ENTER (ENT) MEMORY control

In DVD playback mode, press the control to select a designated item in menu mode.

In stop mode, press the control to select the next radio memory preset.

7. MNU/MODE control

In DVD playback mode, press to access the disc menu.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

In stop mode, press to change to a different playing media (e.g. AM, FM, CD...)

8. VOLUME control

Press to increase (+) or decrease (-) volume level.

Battery replacement

Batteries are supplied with the remote control unit. Since all batteries have a limited shelf life, replace them when the unit fails to control the DVD player. There is a LED indicator light on the remote control that will illuminate when any control is pressed.

Slide the battery cover off as shown on the remote control to access the batteries.

The remote control unit uses two AAA batteries.

Parental control

To enable or disable your Rear Seat Entertainment DVD System, simultaneously press the memory preset controls 3 and 5 on the radio face.

For further information about the Rear Seat Controls, refer to Rear Seat Controls section in this chapter.

Wireless headphones

Your system is equipped with 2 sets of wireless headphones. (Two AAA batteries are needed to operate the headphones.) Batteries are included.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

To install the batteries, lightly press down on the top of the left earpiece and slide the cover off.

When replacing the batteries, use two new batteries (alkaline recommended) and install them with the correct (+) and (-) orientation.

Note: Additional 1.9-2.3mhz infrared wireless headphones may be purchased by contacting your local dealer or retailer.

Wireless headphone operation

To operate the headphones:

• Press the ON/OFF button on the

left-hand earpiece. The LED light on the right-hand earpiece will illuminate. Press again to turn off.

• Adjust the headphones to

comfortably fit your head.

• Adjust the volume control to a

comfortable listening level.

Note: The volume level of the wireless headphones can only be controlled by the thumbwheel. Neither the remote control nor the rear seat controls will affect the volume output of the wireless headphones.

When not using the headphones, shut them off to preserve battery power. The headphones will automatically turn off after five minutes if they have not received an infrared audio signal from the overhead pod.

Ensure that the line of sight between the headphone and infrared transmitter (mounted on the DVD housing) is not obstructed.

F F

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Liquid Crystal Display (LCD) flip-down screen

The screen rotates down to view and into the housing to store when not in use. Be sure the screen is latched into the housing when being stored.

1. 7.0” (diagonal) active matrix liquid crystal display (LCD) screen.

2. Screen housing.

3. Dimmer switch. Press +/- to increase/decrease the brightness of the screen.

Playback and format

• The DVD player of your Rear Seat Entertainment DVD System can

only be used in the “playback” mode. (The DVD player does not offer a record feature.)

• The system plays standard CDs or DVDs.

• The DVD player is capable of playback of DVDs, DVDR/RW, CDs,

CDR/RW and MP3s.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Rear Seat Entertainment DVD System protection circuits

High temperature sensor circuit

• Excessively high temperatures may cause damage to the DVD player.

• When the temperature of the DVD player becomes too hot, the high

temperature sensor circuit stops machine operation. DVD/CD HOT will illuminate in the radio display.

• The DVD player will remain inactive until it cools to a normal

operating temperature. Length of time to cool will vary depending on conditions.

General operating tips

• When the engine is not running, use the system sparingly. Otherwise,

it will run the battery down.

• When the ignition is turned to OFF, the Rear Seat Entertainment DVD

System is also turned OFF. When the ignition is turned ON, the system will begin playback from the last selected media source when the play control is pressed.

• To disable the DVD player, simultaneously press the 3 and 5 memory

presets on the radio face. To enable the DVD player again, press the 3 and 5 presets simultaneously.

• The DVD player is only capable of reading the bottom side of a disc.

When inserting a single sided disc, the label should be up. For a multi-sided disc, the desired play side should be down when the disc is inserted into the player.

• The DVD player is capable of playback of DVDs, DVDR/RW, CDs,

CDR/RW and MP3s.

• DVDs are formatted by regions. This DVD system can only play region

1 DVDs (DVDs manufactured for U.S. and Canada).

This unit is designed to play commercially pressed 4.75 in (12 cm) audio compact discs and DVDs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford DVD/CD players. Irregular shaped discs, discs with a scratch protection film attached, and discs with homemade paper (adhesive) labels should not be inserted into the player. The label may peel and cause the disc to become jammed. It is recommended that homemade discs be identified with permanent felt tip marker rather than adhesive labels. Ballpoint pens may damage discs. Please contact your dealer for further information.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Inserting a CD/DVD

Partially insert the CD/DVD into the slot and the system will fully pull in the disc. Inserting the disc too far could cause the disc to jam in the system.

Inserting a CD/DVD into the DVD player automatically turns the power ON and playback should begin.

The counter is automatically reset to 0:00:00.

Removing a CD/DVD

1. Press the STOP/EJECT control to stop playback.

2. Press the STOP/EJECT control again to eject the CD/DVD.

If the CD/DVD is not removed within the allotted time, the system will pull the CD/DVD back into the system for safety purposes. If the CD/DVD will not eject from the system, press and hold the EJECT control for approximately 2 seconds. The disc should eject whether the vehicle ignition is ON or OFF.

Playing a video game/auxiliary device

1. Connect the video line from your video game device to the YELLOW auxiliary input jack.

2. Connect the left and right audio lines to the WHITE and RED auxiliary input jacks respectively.

3. Press the MODE control until DVD/CD AUX (no disc in player) or DVD/CD play (disc in player) illuminates in the radio display. If a disc is in the system, playback should begin. To enable the aux inputs, press the STOP control or press the AUX control on the DVD player.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

On-screen indicators

Each time a control is pressed, the operational status of the DVD player is shown on the screen. The following are some possible indicators:

1. DVD/ CD STATUS (PLAY/FWD/REV/PAUSE)

2. CD track number / DVD title

3. DVD chapter number

4. MEDIA COUNTER — displays current viewing time of desired media. (HOURS:MINUTES:SECONDS)

5. Viewing angle (of picture) - Adjustable with cursor controls and ENTER control.

6. Subtitles (specific language type - English, Spanish or French, dependent on disc capability and ON/OFF selection.)

7. AUDIO OUTPUT (not changeable)

8. AUDIO VERSION — (01 ENG., etc.)

9. DISPLAY SETTING (4x3, Zoom, 16x9)

10. STATUS ICON (FWD, x4, x8, x32, REV, x4, x8, x32, etc.)

Safety information

Read all of the safety and operating instructions before operating the system and retain for future reference.

Do not attempt to service, repair or modify the Rear Seat Entertainment DVD System. See your Ford or Lincoln Mercury dealer.

Do not insert foreign objects into the DVD compartment.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

The front glass on the liquid crystal display (LCD) flip-down

screen may break when hit with a hard surface. If the glass breaks, do not touch the liquid crystalline material. In case of contact with skin, wash immediately with soap and water.

Do not expose the liquid crystal display (LCD) flip-down screen to direct sunlight or intensive ultraviolet rays for extensive periods of time. Ultraviolet rays deteriorate the liquid crystal.

Be sure to review user manuals for video games and video game equipment when used as auxiliary inputs for your Rear Seat Entertainment DVD System.

Do not operate video games or video equipment if the power cords and/or cables are broken, split or damaged. Carefully place cords and/or cables where they will not be stepped on or interfere with the operation of seats and/or compartments.

Disconnect video games and video equipment power cords and/or cables when not in use.

Avoid touching auxiliary input jacks with your fingers. Do not blow on them or allow them to get wet or dirty.

Do not clean any part of the DVD player with benzene, paint thinner or any other solvent.

Whenever a warning is received, the radio volume will be lowered to a volume that will allow the tones to be heard. The radio volume will return to the previous level after the warning goes away.

Federal Communication Commission (FCC) Compliance

Changes or modifications not approved by Ford Lincoln Mercury could void user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference with radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to consult the dealer or an experienced radio/TV technician for help.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Care and service of the DVD player

Environmental extremes

DVD players that are subjected to harsh environmental conditions may be damaged or perform at less than maximum capability. To avoid these outcomes, whenever possible avoid exposing your DVD player to:

• extremely hot or cold temperatures.

• direct sunlight.

• high humidity.

• a dusty environment.

• locations where strong magnetic fields are generated.

Temperature extremes

When the vehicle is parked under direct sunlight or in an extremely cold place for a long period of time, wait until the cabin temperature of the vehicle is at normal temperature before operating the system.

Humidity and moisture condensation

Moisture in the air will condense in the DVD player under extremely humid conditions or when moving from a cold place to a warm one. If moisture condensation occurs, do not insert a CD or DVD into the player. If one is already in the player, remove it. Turn the DVD player ON to dry the moisture before inserting a DVD. This could take an hour or more.

Cleaning the liquid crystal display (LCD) flip-down screen

Clean the display screen by applying a small amount of water or any ammonia-based household glass cleaner directly to a soft cloth. Rub the screen gently until the dust, dirt or fingerprints are removed. Do not spray the screen directly with water or glass cleaning solvents. Overspray from these fluids could drip down into the internal electronics of the screen and cause damage. Do not apply excessive pressure while cleaning the screen.

Foreign substances

Exercise care to prevent dirt and foreign objects from entering the DVD player compartment. If liquid is accidentally spilled onto the system, immediately turn the system OFF and consult a qualified service technician.

Cleaning CDs and DVDs

Inspect all discs for contamination before playing. If necessary, clean discs only with an approved CD cleaner and wipe from the center out to the edge. Do not use circular motion.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Cleaning the DVD player exterior

Clean the exterior of the DVD player with a damp cloth. Do not use CD cleaning kits or CDs intended to clean the interior of your DVD player. Use of these products may damage your system.

LINCOLN NAVIGATION SYSTEM (IF EQUIPPED)

Your vehicle may be equipped with a Lincoln Navigation System which allows you to listen to the radio, play CDs and also navigate the vehicle using a navigation DVD.

THX audio system (if equipped)

Your vehicle may be equipped with the THX威 certified premium audio system. This system creates optimal acoustic quality for all seating positions and road conditions.

The system offers an advanced speaker system, amplifier, subwoofer and equalizer.

Your Lincoln Navigation System has a large range of features, yet is easy to use. Guidance is shown on the display screen and is supplemented with voice prompts. The display screen provides full information for operating the system through use of menus, text screens and map displays. Screen selections are made by touching the desired selection on the screen.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

1. VOL-PUSH: Press to turn the system ON/OFF. Turn to adjust the audio volume level.

2. AUDIO: Press to enter audio mode and access radio, CD, CDDJ, DVD (if equipped) settings.

3. MAP: Press to enter map mode and view your current vehicle position on the map. Press and hold to obtain additional position information. This will not function without a map DVD loaded.

4. DEST: Press to enter Destination Entry mode. This allows you to enter a destination and route to it. With an active route, pressing DEST allows the user to request a Detour, display entire route, select route preferences, or change or cancel the destination. This will not function without a map DVD loaded.

5. MENU: Press to access system settings such as display, brightness, clock mode (if equipped), etc.

6. CD OPEN CLOSE: Press to open/close the display screen and access the CD player.

Cold temperature advisory

When operating the system below 32° Fahrenheit (0° Celsius), the display screen requires 20–30 minutes warm-up to achieve maximum brightness. Ensure that the system display setting is set to DAY mode until maximum brightness is achieved (refer to Menu mode section). Once maximum brightness is achieved, revert to AUTO mode display setting.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Initial map display

After pressing AGREE to the initial WARNING screen, you will move into the initial map screen which shows the current vehicle location. Pressing the globe icon will take you to the user settings — audible feedback, navigation units, language and clock (if equipped).

Quick Start — How to get going

To play a radio station:

1. Ensure that the vehicle ignition is on.

2. Press AUDIO.

3. Select AM, FM1 or FM2.

4. Press TUNE to adjust manually up ( band.

5. Press SEEK to find the next strong station up (

Note: If PTY (program type) is selected, the station selection will be limited. Refer to Program Type (PTY) for further information.

) or down ( ) the frequency

) or down ( ).

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

To play a previously loaded CD:

1. Ensure that the vehicle ignition is on.

2. Press AUDIO.

3. Press CD to select a CD which is already loaded. (NO CD will appear in the display if there are no CDs loaded into the system). Use the controls (1–6) to select the desired CD.

4. CD will begin to play.

To load CDs:

1. Press CD OPEN CLOSE at the bottom of the screen to load a CD. (The screen will open).

2. Press LOAD and select the desired slot. Or, press and hold LOAD to auto load all available slots. The slot indicator lights blink rate will increase when the system is ready to accept a disc. Push CD OPEN CLOSE to close the screen. Once closed, the CD will begin to play.

3. Use the touch controls to advance tracks, scan, pause, etc.

To use the Navigation system:

1. Ensure that the vehicle ignition is on, and the navigation DVD is loaded into the navigation DVD player. Refer to Loading the map DVD or Navigation system — DVD location in the Index for your vehicle’s navigation DVD location.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

2. Press DEST. The warning screen will appear. After reading, press AGREE. The screen will show a map with your current location. Press DEST again.

3. Select the desired type of destination entry. You may select “Address”, “Point of Interest”, “Emergency” or “Previous Dest” from the first screen.

Or, press “ selections of “Memory Point”, “Select from map”, “Freeway Ent/Exit” and “Special Memory Points.” After making your selection, enter any required information.

Next Page” to access

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

4. Press DEST at the bottom of the map screen.

5. Choose the desired route by pressing the NEXT button (if it appears). There can be up to three alternative routes.

6. Press START to begin the navigation guidance.

To adjust the voice guidance volume:

1. Press the MAP hard key.

2. Press “Nav Menu” at the bottom left hand corner of the screen.

3. Press On/Off to turn the voice guidance option on/off. Use the numeric keys (1–7) to determine the volume level of the guidance voice prompts.

Voice activated commands (if equipped)

Your Lincoln Navigation System (LNS) may be equipped with a voice activated feature which allows you to “speak” certain commands to the system. Speaking clearly will help to ensure that the system correctly responds to your commands. Ensure that the commands are spoken in English (not any other language) and that they are spoken exactly as they are written, or they may not function.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Press VOICE briefly (on your steering wheel controls) and the voice icon arrow on your steering wheel controls to hear the previous command repeated from the navigation system.

The voice activated command feature will not operate if a map DVD is not inserted into the navigation DVD unit.

At any time, you may say these commands to change modes:

• Radio • Audio on

• AM • Audio off

• FM1 • Power off

• FM2 • CD Changer (if equipped)

• CD • DVD (if equipped)

• Power on

During normal radio operation, you may say:

• Seek up • Seek down

Disc operation commands you may say when using a rear seat DVD (if equipped):

• Track up • Track down

• Previous track • Disc up

• Disc down • Next disc

• Previous disc

During CDDJ or in-dash CD play, you may say:

• Track up • Track down

• Previous track • Disc up

• Next disc • Disc down

• Previous disc

To change the screen display, you may say the following commands:

• Screen off • Screen day mode

• Day mode on • Screen night mode

• Night mode on • Screen auto mode

• Auto mode on

Note: If you say “Screen off”, you must touch the screen in order to activate the screen again. The screen will not turn on again with a voice command.

appears on the Navigation display. Press the REPEAT button or

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Commands that jump over screens:

• Current position • Current location

• Map

While in navigation map mode, the following commands are available:

• Zoom in • Zoom out

• Minimum scale • Maximum scale

• North up • Change to North up

• Heading up • Change to heading up

• Map direction • Change map direction

• Mark this point • Mark

While in navigation POI mode, the following commands are available by voice activation:

• Automobile club • AAA (Triple A)

• Auto service & maintenance • Auto service

• Gas station • Gas

• Parking garage • Parking lot

• AT M • Bank

• City hall • Civic center

• Community center • Convention center

• Exhibition center • Court house

• Higher education • University

• College • Hospital

• Library • Police station

• School • Amusement park

• Casino • Golf course

• Marina • Museum

• Park & recreation • Parks & recreation

• Performing arts • Ski resort

• Skiing •

• Stadium • Tourist attraction

• Winery • Restaurant

• I’m hungry • American restaurant

• American food • Chinese restaurant

Sports complex

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

• Chinese food • Continental restaurant

• Continental food • French restaurant

• French food • Italian restaurant

• Italian food • Japanese restaurant

• Japanese food • Mexican restaurant

• Mexican food • Seafood restaurant

• Seafood • Other restaurant

• Other food • Shopping

• Shopping mall • Grocery store

• Airport • Bus station

• Ferry terminal • Historical monument

• Hotel • Park and ride

• Rental car agency • Rest area

• Rest stop • Tourist information

• Train station • Business facility

• City center • POI off

• Commuter rail station

While in navigation destination (DEST) mode, the following commands are available:

• Home • Go home

• Previous starting point • Go starting point

• Next way point map • First way point map

• Second way point map • Third way point map

• Fourth way point map • Fifth way point map

• Destination map • Delete destination

• Cancel destination

While in navigation guidance mode, the following commands are available by voice activation:

• Repeat guidance • Repeat voice Louder • Softer

•

• Voice guidance off • Voice guidance on

• Open guidance screen • Close guidance screen

• Arrow guidance • Arrow guide

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

• Change to arrow guidance • Change to arrow guide

• Turn list guidance • Turn list guide

• Change to turn list guidance • Change to turn list guide

• Entire route map • Entire route

• Route overview • Reroute

• Detour • Detour entire route

Navigation help commands you may speak at any time:

• Help • Map

• Destination • Guidance

• Radio • Disc

• Map help • Destination help

• Guidance help • Radio help

• Disc help

Audio mode

Your Lincoln Navigation Audio System has many features including a full range of audio functions. To access these functions, press AUDIO on the main bezel. This will take you into audio mode.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Volume/power control

Press knob to turn the audio system on/off. Turn to raise or lower volume. The levels will be displayed on the screen.

To activate the navigation mode, press MAP or DEST.

To adjust the navigation voice output level, select the NAV MENU button via the map screen.

Speed compensated volume (SCV)

With this feature, radio volume changes automatically with vehicle speed to compensate for road and wind noise. To engage the SCV feature:

1. Press AUDIO.

2. Press SOUND.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

SCAN

RDS

87.9

SEEK

PRESET SCAN

TRAFFIC

98.1

89.9

INFO PTY

106.3 107.9

98.5

TUNE

AUTO SET

SET PTY

SOUND

FM1

FM2

Entertainment Systems

3. SCV is located in the middle of the screen. Press to turn on.

4. Select setting 1 to 7 or turn off.

The recommended level for the speed compensated volume is from level 1 through level 3. When activated, level 1 is the minimum setting and level 7 is the maximum setting.

AM/FM select

The AM/FM control works in radio, CD and navigation modes.

AM/FM select in radio mode

Press AM/FM1/FM2 to switch between AM/FM1/FM2 memory preset stations.

AM/FM select in CD mode

Press to stop CD play and begin radio play.

AM/FM select in navigation mode

The radio will continue to play in the background of the navigation screens. To access, press AUDIO then AM/FM1/FM2.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Sound functions

To access settings for Bass, Treble, Balance, Fade, DSP (Digital Signal Programing), SCV (Speed Compensated Volume), and Occupancy modes:

1. Press AUDIO.

2. Press SOUND.

3. Select from Bass/Treb; Bal/Fade; DSP/SCV.

4. Press +/— to increase/decrease the levels.

Bass: Allows you to increase or decrease the audio system’s bass output.

Treble: Allows you to raise or lower the audio system’s treble output.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Fade: Allows you to adjust sound between the front and rear speakers.

Balance: Allows you to adjust the sound distribution between the right and left speakers.

SCV (Speed Compensated Volume): Automatically compensates for road wind and noise. Refer to Speed compensated volume earlier in this chapter.

DSP Occupancy mode:Use to optimize the sound based upon the occupants in the vehicle. Select from ALL SEATS, REAR SEATS or DRIVER SEAT.

If your vehicle is equipped with rear seat controls, DISABLE HEADPHONES and DISABLE REAR CONTROLS will appear as options at the bottom of the screen. These controls allow you to turn off the headphones and the rear controls for the rear seat passengers. Press the appropriate button to turn the headphones or rear controls off. The button will highlight when the function is disabled. When the button is not highlighted, the function is on (headphones and rear seat controls are operating and able to be controlled by the rear seat passengers.)

Setting memory preset stations

The radio is equipped with six station memory preset controls. These controls can be used to select up to six preset AM stations and twelve FM stations (six in FM1 and six in FM2).

1. Select the frequency band with the AM/FM1/FM2 touch controls.

2. Select a station.

3. Press and hold a memory preset until the sound returns. The frequency will appear in the preset.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Seek

• Press listenable station up/down the

frequency band.

• Press next/previous track on a CD.

Tune adjust

Press TUNE to manually move down/up ( band.

In CD mode, press TRACK to select the previous/next (

Autoset memory preset

Autoset allows you to set strong radio stations without losing your original manually set preset stations. This feature is helpful on trips when you travel between cities with different radio stations.

Starting autoset memory preset

1. Select a frequency band using

AM/FM1/FM2.

/ to find the next

/ to advance to the

/ ) the frequency

/ ).

SCAN

RDS

87.9

SEEK

PRESET SCAN

TRAFFIC

98.1

89.9

INFO PTY

106.3 107.9

98.5

TUNE

AUTO SET

SET PTY

SOUND

FM1

FM2

2. Press AUTO SET.

3. When the first six strong stations

are filled, the station stored in memory preset control 1 will start playing.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

If there are less than six strong stations available on the frequency band, the remaining memory preset controls will all store the last strong station available.

To deactivate autoset and return to your audio system’s manually set memory stations, press the AUTO SET again.

Scan

Press SCAN for a brief sampling of all listenable stations and CD tracks. Press again to disable and remain on the current selection.

Preset scan

Press PRESET SCAN to scan the stations stored in the memory presets.

SCAN

RDS

87.9

SCAN

RDS

87.9

SEEK

PRESET SCAN

TRAFFIC

98.1

89.9

SEEK

PRESET SCAN

TRAFFIC

98.1

89.9

INFO PTY

106.3 107.9

98.5

INFO PTY

106.3 107.9

98.5

TUNE

AUTO SET

TUNE

AUTO SET

SET PTY

SOUND

FM1

FM2

SOUND

FM1

FM2

Radio data system (RDS) feature

This feature allows your audio system to receive text information from RDS-equipped FM radio stations such as station call letters, program type, etc. When in FM mode, press RDS to activate/deactivate.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Traffic function

Select TRAFFIC for traffic information broadcast from certain stations which will automatically

SCAN

SEEK

PRESET SCAN

TUNE

AUTO SET

interrupt radio or CD playback at a

RDS

TRAFFIC

89.9

INFO PTY

98.1

98.5

106.3 107.9

preset volume level.

87.9

Traffic information not available in most U.S. markets.

Information feature

Press INFO to view the frequency, call letters and PTY category of the selected FM station.

SCAN

RDS

87.9

SEEK

PRESET SCAN

TRAFFIC

98.1

89.9

INFO PTY

98.5

TUNE

AUTO SET

106.3 107.9

Note: Not all stations support INFO function.

Program type (PTY)

This feature allows you to search for Radio Data System (RDS) stations selectively by their program type.

Ensure that the RDS function is turned on. Press PTY to turn the feature on/off.

SET PTY

SOUND

FM1

FM2

SOUND

FM1

FM2

To set/change PTY:

Ensure that the RDS function is turned on. Press SET PTY to select from the following program types:

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

SCAN

RDS

87.9

SEEK

PRESET SCAN

TRAFFIC

98.1

89.9

INFO PTY

106.3 107.9

98.5

TUNE

AUTO SET

SET PTY

SOUND

FM1

FM2

Entertainment Systems

• All

• Classical

• Country

• Information

• Jazz

• Religious

• Rock

• Soft

• To p 40

Once PTY has been programmed, press SEEK ( initiate a search up or down the frequency.

Preset scan and Autoset also initiate PTY searches. The search will stop when the desired program type has been reached. If no program type is found, a message will display.

Note: Not all stations support PTY information.

Satellite ready capability (if equipped)

Your Lincoln navigation system may be equipped with Satellite ready capability. The kit to enable Satellite reception is available through your Lincoln dealer. Detailed Satellite instructions are included with the dealer installed kit.

/ ) or SCAN to

CD mode

CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ball point pens may damage CDs. Please contact your dealer for further information.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Playing a previously loaded CD:

To begin CD play (if a CD is already loaded), press AUDIO hard button and then CD.

Press CD. CD play will begin where it stopped last.

Loading a CD:

SCAN

RDS

87.9

SEEK

PRESET SCAN

TRAFFIC

98.1

89.9

INFO PTY

106.3 107.9

98.5

TUNE

AUTO SET

SET PTY

SOUND

FM1

FM2

1. Press CD OPEN CLOSE on the bezel.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

2. The navigation screen will fold down, allowing you access to the

in-dash six CD system.

3. Press LOAD and the desired CD slot number. The indicator light will

blink slowly at first, then quickly, signaling the system is ready.

4. Insert a disc.

5. To load more than one disc, press and hold LOAD. This will initiate

autoload and will allow you to load all open CD slots. After an allotted time, the screen will close automatically or you may press CD OPEN CLOSE on the bezel again.

6. Once the screen closes, the system will start playing the last CD

loaded.

Track

Press next/previous track.

/ to advance to the

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Rewind/fast forward in CD mode

Press to reverse or advance

/ ) in the current CD track.

(

Scan feature in CD mode

Press SCAN to hear a brief sampling of all tracks on the current CD. Press again to disengage and remain with the current track.

Shuffle feature in CD mode

When in CD (or CDDJ mode), press SHUFFLE to engage the shuffle feature. Press to select from shuffling between tracks (SHUFFLE TRACK) on the current CD or between all tracks on all CDs (SHUFFLE DISC). All tracks will be played in random order. Press again to disengage (SHUFFLE OFF).

Compression feature

The compression feature works in CD mode and boosts more quiet music and lowers louder music to minimize the need for volume adjustments.

When in CD or CDDJ mode, press COMPRESS to engage or disengage the compression feature.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Pause

In CD mode, press PAUSE to pause the current track. Press again to continue playing.

Map mode

Map display information

Entertainment Systems

To access the map display, press MAP on the bezel.

Once pressed, the current map display will appear on the screen showing the current vehicle location.

Zoom control

When ’Zoom’ is pressed, the scale indicator is shown on the screen. The scale markings are: 1/32, 1/16,1/4, 1/8, 1/2, 1, 2, 4, 8, 16, 32, 64, 128 miles. The control can be used in a number of ways:

• Touch and hold one of the arrow buttons for the map to be displayed again at each zoom level.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

• Touch one of the arrow buttons repeatedly for the map to be displayed again at the final zoom level.

• Touch one of the segments of the scale indicator for the map to be displayed at the selected zoom level.

Additional map function buttons

To initiate the display of additional map function buttons, tap the map anywhere on the screen or press the MAP hard key. These additional features will disappear from the screen within five seconds unless pressed.

• STORE - stores current vehicle location as a memory point. Refer to Memory Points for further information.

• POI (Point of Interest)- brings up the Quick POI menu which allows the user to perform two functions: Display POI icons on the map for one category. Select local map area POIs as destinations or waypoints. The list of local area POIs can be sorted by distance, name, or icon. Refer to Points of Interest for further information.

If home has been previously programmed in the “Nav Menu”, the home icon (house) will appear on the screen and is able to be selected as a destination.

To delete POI icons from the map, touch the map again and press the POI off button.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Route preferences

After entering a destination, the Route preferences will appear on the screen showing what is currently selected. You may choose to activate/deactivate selections which the system will factor in when calculating your route. Those options are:

• Minimize Time/Distance

• Use Major Roads

• Use Toll Roads

• Use Ferries

Information function

INFO will appear on the screen when you have calculated a destination. Press INFO for more information about the current destination, if available.

Entertainment Systems

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Youwillbeabletoviewthe information (if available) as well as choose to store the destination as a memory point by pressing OK.

Screen symbols

Navigation symbol — Indicates the current vehicle position and points to the direction in which the vehicle is currently traveling.

Destination symbol — Indicates the current route destination.

Next turn symbol — Shows the next maneuver that will need to be taken on the current route.

North up button — Indicates that the map is displayed with north to the top of the screen. Press to toggle between “North up” and “Heading up” map display states.

Heading up button — Indicates that the map is displayed with the vehicle heading to the top of the screen. The position of the pointer indicates the direction of north on the map. Press to toggle between “North up” and “Heading up” map display states.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Avoid areas or points — The “X” symbol indicates a point. to be avoided in route calculations.

If the avoid point is enlarged to an avoid area, it will appear on the screen as a shaded box.

Way point symbol — Indicates the location of a way point (locations you wish to visit in route to your ultimate destination) on the map.

Home position symbol — Indicates the location on the map, currently stored as the home position.

Stored location symbol — Indicates the location of a memory point. This is the default symbol used when the point is stored. (If desired, an icon of your own choice can be selected from the 15 icons available.) Refer to Choosing from the icon list.

GPS symbol— Indicates that insufficient GPS satellite signals are being received for accurate map positioning. The symbol is not displayed under normal operation.

Speaker icon symbol— Press to turn voice guidance on/off.

Route options (destination entered)

Once in navigation mode and a route is currently active, press “Chng. route” to access the ROUTE OPTIONS screen. Choose from the following selections:

• Detour: Press to select a detour around the current route. Refer to Detour options later in this chapter for further information.

• Route Preferences: When creating a destination, select from: Minimize Time/Distance, Use Major Roads, Use Toll Roads, Use Ferries.

• Display Whole Route: Will enter MAP mode and display your entire chosen route.

Note: Route preference appears on the Nav menu when no destination is entered.

While driving under route guidance, only follow an instruction

when it is safe to do so as the system cannot be aware of changing conditions. Use voice guidance as much as possible, and only view the display when driving conditions permit.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Ensure that you follow highway code restrictions and do not

take any risks. For example, if you are unable to make a U-turn, continue on your journey. The navigation system will recalculate your route to get you back to an appropriate road to your destination.

Navigation set up

The Navigation Set up screen will allow you to make adjustments to the navigation displays.

Average speed settings

Allows you to set approximate speeds you drive. These speeds enable the navigation system to aid in calculating timing for routes.

Quick POI (Point of Interest)

Allows you to change the Quick POI menu settings. Select the desired Quick POI (Gas, ATM, etc.) and then press ’List Categories’ for further categories, or ’Map Area POIs’ to show the desired POIs on your current map.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Restore system defaults

Resets all system user-selectable options to the default (automatic) values (i.e. guidance, voice, search area and route preferences).

Calibration

This feature is helpful if the car has been towed, or if you notice it is not registering at the correct vehicle location on the map. Press “Position” to reposition the vehicle location. Press the screen to scroll the map to the desired location and press OK to confirm. Press “Distance” to calibrate by distance and improve the navigation accuracy. It is recommended to activate this function after every tire replacement. When the button is highlighted, calibration is in process and will turn off automatically when complete.

DVD map version

Displays the version of the inserted navigation DVD. Refer to Ordering additional map DVDs for further information.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Display Options

The Display Options screen will allow you make adjustments to the navigation display screen. You can choose from:

• Map Mode (Dual or Full)

• Guidance Mode (Arrows or Turn

list)

• Guidance Display (On or Off)

• Time to destination (Show or

Hide)

Stored locations

The Stored locations screen will allow you to choose from destinations that have been saved into the navigation system.

Entertainment Systems

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

In this screen, you can select from Memory Points, Special Memory Points, Home, Avoid Area, Destination and Way Point, or Previous Destination. Please refer to the Destination menu section for a complete description of the functions.

On route scroll

The system automatically scrolls through the entire planned navigation route either forwards or backwards. To activate, press the arrow buttons at the bottom left of the map screen.

Voice guidance/volume

Allows you to turn the voice guidance option on/off and to determine the volume level of the guidance voice prompts. To adjust:

1. Press the MAP hard key.

2. Press “Nav Menu” at the bottom left hand corner of the screen.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

3. Press the speaker icon to turn the voice guidance option on/off. Press the desired number to select the volume level for the voice prompts.

Home

To set home for the first time:

1. Press MAP.

2. Press “Nav. Menu”.

3. Press “Stored Locations”.

Entertainment Systems

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

4. Press “Home”.

5. Press “Add”.

6. Select the desired menu item you wish to set as Home (Address, Memory Point, Point of Interest, Previous Destination).

7. Enter the required details.

8. Press OK to set the home position.

To view home, press the home icon (house) on the Destination Entry screen.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

To view the set home position

1. Press MAP.

2. Press “Nav. Menu”.

3. Press “Stored Locations”.

Entertainment Systems

4. Press “Home”.

5. Press “List”.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Deleting a home location

1. Press MAP.

2. Press “Nav. Menu”.

3. Press “Stored Locations”.

4. Press “Home”.

5. Press “Delete”.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

6. Press YES to confirm.

Special memory points

There are five possible special memory points that you can set.

To set a memory point:

Entertainment Systems

1. Press the MAP hard key.

2. Press “Nav. Menu”.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

3. Press “Stored Locations”.

4. Press “Special Memory”.

5. Press “Add” and select a position.

6. Select point 1–5.

7. Input a destination.

8. Press OK.

Once all five special memory points are entered, the “Add” control will read as “Full”. You must delete points before more can be added.

To delete a memory point:

1. Press the MAP hard key.

2. Press “Nav. Menu”.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

3. Press “Stored Locations”.

4. Press “Special Memory”.

5. Press “Delete”. The list will display.

6. Select the special memory point to delete.

7. Press “Del. all” to delete all entered special memory points.

8. Press “Yes” to confirm.

Detour options

You may engage the detour option once a route has already been calculated by the system. To access the detour option:

1. Press the MAP hard key

2. Press “Chg. Route”.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Press DETOUR to activate. Use the soft controls to select and enter the number of miles you want to deviate off of the current road.

Press DETOUR to confirm the selection and to activate the detour around the specified areas.

Press NEW ROUTE if you would like the system to plan a different route. The system may calculate an entirely new route, depending on what is available.

Route interruptions

In the course of your destination, you may decide to temporarily leave your planned route for gas, food, etc. If you turn off the ignition, the option to continue the route guidance will be displayed when the ignition is turned on again. The route can be accessed once again after you press “Agree” on the warning screen.

Route alterations or cancellations

To cancel or change your current route from the map, press DEST. You may then select from Detour, Display whole route, Route preferences, Destination Entry, Calculate or Cancel Guidance.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Avoiding an area while under guidance

For one reason or another, you may choose to avoid a certain area while in route to your destination. To select the area to avoid:

• From the MAP screen, press Nav Menu.

• Select Route Options, then Display Whole Route

• Press Turn List

• Press Avoid next to the street to be avoided

• Choose OK to confirm

• Press Reroute to activate

The new area is added to the list of stored avoid areas.

Note: In some circumstances, it may not be possible to avoid all selected areas.

Listing areas to avoid

You can list all areas noted as “avoid”.

• Press “Nav Menu”.

• Press “Stored locations”.

• Press “Avoid area”.

• Press LIST to view all previously

stored selections.

• Select the desired one. The map screen will be displayed, showing the location and address of the selected area.

Press Enlarge or Reduce to adjust the size of the visible area. Scroll the map as required.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Deleting areas to avoid

To delete a selection from the “Avoid area” list:

• From the stored locations menu, select “Avoid area”.

• Press DELETE

• Select the desired area to be

deleted.

• Press DEL. ALL to delete all stored areas.

• Press YES to confirm.

Destination menu

Press DEST on the main bezel to access the navigation mode.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Initial map display

Note: There may be a slight time delay between the soft key and the hard key functions.

Route options

Once in navigation mode and a route is currently active, press the DEST hard key. The ROUTE OPTIONS screen will appear and allow you to choose from the following selections:

Entertainment Systems

• Detour — Press to select a detour around the current route.

• Route Preferences — When creating a destination, select from:

Minimize Time/Distance, Use Major Roads, Use Toll Roads, Use Ferries.

• Display Whole Route: Will enter MAP mode and display your entire chosen route.

• Destination Entry: Allows you to enter a new destination or select from entries in: Address book, Points of Interest or Previous Destinations.

While driving under route guidance, only follow an instruction

when it is safe to do so as the system cannot be aware of changing conditions. Use voice guidance as much as possible, and only view the display when driving conditions permit.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Ensure that you follow highway code restrictions and do not

Destination entry Search area

The mapped areas covered by your map DVD are reflected in the Search Area map that is displayed on the Destination Entry screen. Your navigation system uses a regional search area. This area is the area from which navigational directions will be used.

To check your area or reset, press CHANGE under the search area listing. The map will open and allow you to select another regional area. Ensure that your search area is correct prior to setting your destination.

IL , IN , KY , MI , OH , WI

Cancel

Selecting a destination

Press DEST to set a destination. From this menu, you may select from the following options:

• Address— Use to select a

destination based on a known street address.

• Point of Interest— Use to

select a destination that is a point of interest location (i.e., airport, restaurant, hospital).

• Previous Destination — Use to select a destination from among the

last 20 entered destinations

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

• Emergency — Use to select the Emergency screen which will give

you the location of the closest Hospital, Police Station and Dealer.

Press more selections:

• Memory point — Use to select

from a memory point.

• Freeway exit/entrance — Use

to select a certain freeway exit or entrance.

• Select from map —Use to select

a place on the map.

• Special Memory Points — Use to select a destination from

previously stored entries.

Address

1. From the destination entry screen, select “Address”.

’Next Page’ to access

2. Input the house/building number and press OK.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

3. Use the keyboard to type in the street name. When you are typing the street name, the system may bring up possible roads that you can select from. Use the arrows to scroll up or down to select the desired street.

4. Once the address is entered, the system will pull up some possible city and state matches. If one of those is correct, select it. If not, you may press either “5 near cities” for another listing of five possible cities and states (if available). Or, press “Input City Name”.

5. You may use the keyboard to input the desired city.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Points of interest (POI)

Select “Point of Interest” from the Destination Entry Menu. In this next menu, you will have the following options:

• By Name— Enter POI name on

the keyboard. Touch “List” to display the list of matching points of interest. If there are too many matches being listed, try entering the town name first.

• By Category — Press “Category”. Scroll down the list to select the

category, then sub-category desired. Once you have selected a category, your entry of the POI will be restricted to that category.

Previous destination

Press “Previous Destination” on the Destination Entry Menu.

1. Select (touch) the desired item from the list of destinations previously reached. The item details will be listed.

2. Confirm destination details.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Deleting stored locations

Your navigation system allows you to delete any stored locations (previous destinations, memory points, special memory points, home, avoid areas, destination and way points, etc.) To delete any of these stored locations:

1. Press the MAP hard key.

2. Press “Nav Menu” in the bottom left hand corner of the screen.

3. Press “Stored locations”.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

4. Select the desired item you wish to delete (previous destination, memory point, etc.).

5. Press “Delete” at the bottom of the screen.

6. The list of stored locations will be displayed.

7. Select (touch) the entry to be deleted. The item details will be listed.

8. Press YES to confirm the deletion.

9. Press DELETE ALL to delete all stored locations.

Emergency

Your navigation system is equipped with a separate Emergency screen. To access the Emergency screen, press “Emergency”.

Entertainment Systems

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

This screen will list the closest police station, hospital and dealer to your current location.

Memory point

Your navigation system allows you to go to special destinations you may wish to again visit. To view any of these “memory points” without a route calculated:

1. Press the DEST hard control.

2. Press “ Destination Entry screen.

3. Select “Memory Point”.

4. Select the desired item.

5. Confirm the details.

6. Press “Destination” to calculate a route to that memory point.

Note: The list can be sorted by date, name or icon by pressing the appropriate button.

Next page” on the

Adding a memory point

You may add more memory points to be stored in the system.

1. With the map displayed, touch your finger to the screen to scroll to the desired location. When you reach the desired location, remove your finger from the screen and the map will stop scrolling. STORE will appear on the screen.

2. Press STORE to add the location to the memory point list.

You may also add a memory point via the Navigation menu.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

1. Press the MAP hard key.

2. Press “Nav Menu” in the bottom left hand corner of the screen.

3. Press “Stored locations”.

Entertainment Systems

4. Select “Memory Point”.

5. Press “Add” at the bottom of the screen.

6. Select the desired menu item.

7. Enter/select any required details. The new point will be added to the stored list of memory points.

8. Press OK. The new point will be added to the list of stored memory points.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

To give the new memory point a name:

1. Select it from the list.

2. Press NAME.

3. Enter the desired name.

Accessing memory point lists

1. Press the MAP hard key.

2. Press “Nav Menu” in the bottom left hand corner of the screen.

3. Press “Stored locations”.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

4. Press “Memory Point”.

5. Press LIST

6. Select the desired entry to view its location details.

Sorting memory point lists

1. Access the desired list.

2. Press the button to sort the list as desired (i.e. date, name, or icon).

When sorted by distance, the points are ordered by distance from the current vehicle location. When sorting by icon, the icons are listed in the order they appear on the icon selection screen.

Entertainment Systems

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Choosing from the icon list

After selecting a location, press ICON to edit. There will be 15 normal and three sound icons displayed. Press the icon you wish to use.

The normal icons will be displayed on the map to indicate the map location identified with that icon. The audible icon will sound a distinctive chime when the vehicle is approaching the memory point associated with that icon.

Deleting a memory point

• In the Memory Point Menu, press DELETE.

• Select the entry to be deleted.

• The system will ask you to

confirm deletion. Press YES to confirm.

The screen will briefly show “Memory Point Deleted”.

Deleting all memory points

• In the Memory Point Menu, press DELETE ALL.

• The system will ask you to confirm deletion. Press YES to confirm.

The screen will briefly show “All Memory Points Deleted”.

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Freeway Entrance/Exit

To set a freeway entrance or exit as a destination:

1. Press the DEST hard key.

2. Press “

the second page of the Destination Entry menu.

3. Select “Freeway Entrance/Exit”.

1. Enter freeway name— Enter

the freeway name using the keyboard. Press “List” to select a freeway from those displayed.

To enter numbers in the freeway name, press “Sym”.

2. Select entrance/exit— Press

“Entrance” if you wish to join the freeway at this junction. Press “Exit” if you wish to leave the freeway at this junction.

3. Select Junction— The screen

will display a list of junctions on the freeway. They can be listed either by distance, (from the current vehicle location), by pressing the “Dist” button or alphabetically by pressing the “A-Z” button. Select the desired entrance or exit.

The destination details are displayed for confirmation.

Next page” to access

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Destination and way points

The Store Dest. & Way Point menu is used after a destination or way point has been entered for the first time using the Destination Entry menu. You can store and delete destinations and way points (locations you wish to visit in route to your ultimate destination). You can also select the order in which you visit them.

Adding (storing) a destination or way point

• Once a destination is entered, press ADD to store the location. The Store Dest. & Way Point menu is displayed.

• Select whether you want to store an Address, Point of Interest or Previous Destination.

• Enter the necessary details for the selection.

• If a destination was entered, it will be stored as the current location. If a way point was entered, it will be added to the list of way points.

Listing destinations and way points

Press LIST to display the stored way points and destination (if entered).

The first way point to be visited is at the bottom of the list and the destination is at the top.

You may view the map location of any entry. On the map, location details for the entry are displayed at the top of the screen.

To adjust the position of the way point (or destination), scroll the map as required.

Press OK.

100

2006 Navigator (nav) Owners Guide (post-2002-fmt) USA (fus)

LINCOLN NAVIGATOR User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

Introduction

CONGRATULATIONS

SAFETY AND ENVIRONMENT PROTECTION

Warning symbols in this guide

Warning symbols on your vehicle

Protecting the environment

BREAKING-IN YOUR VEHICLE

SPECIAL NOTICES

Service Data Recording

Event Data Recording

Special instructions

Using your vehicle with a snowplow

Notice to owners of pickup trucks and utility type vehicles

Cell phone use

Middle East/North Africa vehicle specific information

Instrument Cluster

WARNING LIGHTS AND CHIMES

GAUGES

Entertainment Systems

AUDIO SYSTEMS

Premium Satellite Compatible AM/FM Stereo/Cassette/Single CD/MP3 radio ( if equipped)

Audiophile Satellite Compatible AM/FM Stereo In-Dash Six CD/MP3 Radio (if equipped)

Rear seat radio controls (if equipped)

GENERAL AUDIO INFORMATION

REAR SEAT ENTERTAINMENT DVD SYSTEM (IF EQUIPPED)

DVD player controls

DVD control features

Menu control

Next/Previous control

REV/FWD control

Enter control

CD play mode

Slow play mode

User menu mode

Remote control

Battery replacement

Parental control

Wireless headphones

Wireless headphone operation

Liquid Crystal Display (LCD) flip-down screen

Playback and format

Rear Seat Entertainment DVD System protection circuits

High temperature sensor circuit

General operating tips

Inserting a CD/DVD

Removing a CD/DVD

Playing a video game/auxiliary device

On-screen indicators

Safety information

Federal Communication Commission (FCC) Compliance

Care and service of the DVD player

Environmental extremes

Temperature extremes

Humidity and moisture condensation

Cleaning the liquid crystal display (LCD) flip-down screen

Foreign substances

Cleaning CDs and DVDs

Cleaning the DVD player exterior

LINCOLN NAVIGATION SYSTEM (IF EQUIPPED)

THX audio system (if equipped)

Cold temperature advisory

Initial map display

Quick Start — How to get going

Voice activated commands (if equipped)

Audio mode

Volume/power control

Speed compensated volume (SCV)

AM/FM select

AM/FM select in radio mode

AM/FM select in CD mode

AM/FM select in navigation mode

Sound functions

Setting memory preset stations

Seek

Tune adjust
