Liebherr CUPSL 305, CUPSL 2221, CUPSL 325, CUP 325, CUP 305 User Manual

Operating instructions

Combined fridge-freezer

061212

CUP(sl) 2221/2721/3021 ... 1

7082814 - 00

Appliance at a glance

Contents

1 Appliance at a glance............................................ 2

1.1 Description of appliance and equipment.................. 2

1.2 Range of appliance use............................................ 2

1.3 Conformity................................................................ 3

1.4 Installation dimensions............................................. 3

1.6 Saving energy.......................................................... 3

2 General safety information................................... 3

3 Controls and displays........................................... 4

3.1 Operating controls.................................................... 4

4 Putting into operation............................................ 4

4.1 Transporting the appliance....................................... 4

4.2 Installing the appliance............................................. 4

4.3 Changing the door stop............................................ 5

4.4 Insertion into a row of kitchen units........................... 6

4.5 Disposing of packaging............................................ 6

4.6 Connecting the appliance......................................... 6

4.7 Switching on the appliance....................................... 7

5 Control.................................................................... 7

5.1 Refrigerator compartment........................................ 7

5.2 Freezer compartment............................................... 8

6 Maintenance........................................................... 8

6.1 Manual defrosting..................................................... 8

6.2 Cleaning the appliance............................................. 9

6.3 Changing the interior light......................................... 9

6.4 Customer service..................................................... 10

7 Malfunction............................................................. 10

8 Decommissioning.................................................. 11

8.1 Switching off the appliance....................................... 11

8.2 Taking the appliance out of service.......................... 11

9 Disposing of the appliance................................... 11

The manufacturer works constantly on the further development of all the types and models. Therefore please understand that we have to reserve the right to make design, equipment and technical modifications.

To get to know all the benefits of your new appliance, please read the information contained in these instructions carefully.

The instructions apply to several models. Differences may occur. Text relating only to specific appliances is marked with an asterisk (*).

Instructions for action are marked with a , the results of action are marked with a .

1 Appliance at a glance

1.1 Description of appliance and equipment

Note

Place food inside the appliance as shown in the diagram.

This allows the appliance to save energy during operation. Shelves, drawers and baskets are arranged for optimum

energy efficiency on delivery.

Fig. 1

(1) Adjustable shelves (9) Adjustable bottle and jar

shelf

(2) Egg tray (10) Vegetable, salad and fruit

bins

(3) Butter shelf (11) Type plate (4) Adjustable door shelf (12) Information system (5) On/Off and temperature

controller and interior lighting

(6) Defrost water drain (14) Adjustable feet at the

(7) Bottle rack (15) Ice cube tray (8) Coldest area in the

refrigerator compartment, for sensitive and perishable foodstuffs

(13) Deep freezer drawers

front, castors for transport at the rear

1.2 Range of appliance use

The appliance is suitable solely for cooling food in a domestic environment or similar. This includes use in, for example

in staff kitchenettes, bed and breakfast establishments,

by guests in country homes, hotels, motels and other forms of accommodation,

in catering and similar services in the wholesale trade

Use the appliance solely as is customary within a domestic environment. All other types of use are inadmissible. The appliance is not suitable for storing and cooling medicines, blood plasma, laboratory preparations or similar substances and products covered by the 2007/47/EC Medical Devices Directive. Misuse of the appliance can result in the stored products suffering harm or perishing. Furthermore,

General safety information

the appliance is not suitable for operation in potentially explosive atmospheres.

The appliance is set to operate within specific ambient temperature limits according to its climate rating. The correct climate rating for your appliance is indicated on the type plate.

Note

Compliance with the ambient temperatures

indicated is required, otherwise the cooling performance is reduced.

Climate rating

SN 10 °C to 32 °C

N 16 °C to 32 °C

ST 16 °C to 38 °C

T 16 °C to 43 °C

for ambient temperatures of

1.3 Conformity

The refrigerant circuit is tested for leakage. The appliance complies with the relevant safety regulations and EC Directives 2006/95/EC, 2004/108/EC, 2009/125/EC and 2010/30/EU.

Note for test institutions:

Tests are to be carried out according to the applicable standards and guidelines. Preparation and testing of the appliances must be carried out taking the manufacturer's loading plans and the

notes in the operating manual into account.

1.4 Installation dimensions

Fig. 2

Model h

CUP(sl) 2221 1360

CUP(sl) 2721 1600

CUP(sl) 3021 1800

1.6 Saving energy

Always ensure good ventilation. Do not cover ventilation

openings or grille. Do not place appliance in areas of direct sunlight or next to a

stove, heater or similar object. The energy consumption depends on the installation condi-

tions, e.g. the ambient temperature (see 1.2) . Keep the time the appliance is open to a minimum.

The lower the temperature setting, the higher the power

consumption. Store food logically. (see Appliance at a glance).

Ensure that all food is well packed and covered for storage.

This will prevent frost from forming. Remove food as needed in order that it does not warm too

much. First cool warm food to room temperature before storing it .

Defrost frozen food in the refrigerator.

If there is a thick layer of frost in the appliance: defrost the

appliance. Accumulated dust increases the energy consumption:

Once a year, dust the refrigerating unit

together with the metal grille of the heat

exchanger at the back of the appliance.

2 General safety information

Danger for the user:

This appliance can be used by children of 8

years old and over, and also by persons with

restricted physical, sensory or mental

capacity or lack of experience and knowl-

edge, if they are supervised or have been

instructed on safe use of the appliance and

understand the resulting risks. Children must

not be allowed to play with the appliance.

Cleaning and user maintenance must not be

carried out by children without supervision.

When disconnecting the appliance from the

supply, always take hold of the plug. Do not

pull the cable.

In the event of a fault pull out the mains plug

or deactivate the fuse.

Do not damage the mains power cable. Do

not operate the appliance with a defective

mains power cable.

Have any repairs to or intervention in the

appliance, and any change of the mains

power cable, carried out by the customer

service only or by other specialised personnel

trained for the purpose.

Only assemble, connect and dispose of the

appliance according to the instructions.

Please keep these instructions in a safe place

and pass them on to any subsequent owners.

Special-purpose lamps (incandescent lamps,

LEDs, fluorescent tubes) in the appliance

serve to illuminate the appliance interior and

are not suited for room illumination.

Controls and displays

Fire hazard:

The refrigerant R 600a is environmentally friendly but flammable. Escaping refrigerant may ignite.

•

Do not damage the refrigerant circuit pipes.

•

Do not allow naked flames or ignition sources to enter the appliance.

•

Do not use any electrical appliances in the interior (e.g. steam cleaners, heaters, ice cream maker etc.).

•

If refrigerant escapes: remove any naked flames or sources of ignition from the leakage area. Ventilate the room well. Notify the after-sales service.

Do not store explosives or sprays using combustible propellants such as butane, propane, pentane, etc. in the appliance. To identify these spray cans, look for the list of contents printed on the can, or a flame symbol. Gases possibly escaping may ignite due to electrical components.

Keep burning candles, lamps and other items with naked flames away from the appliance so that they do not set the appliance on fire.

Please be sure to store alcoholic drinks or other packaging containing alcohol in tightly closed containers. Any alcohol that leaks out may be ignited by electrical components.

Danger of tipping and falling:

Do not misuse the plinth, drawers, doors etc. as a step or for support. This applies particularly to children.

Danger of food poisoning:

Do not consume food which has been stored too long.

Danger of frostbite, numbness and pain:

Avoid lasting skin contact with cold surfaces or refrigerated/frozen food or take protective steps, e.g. wear gloves. Do not consume ice cream, water ice or ice cubes immediately and do not consume them too cold.

Danger of injury and damage:

Hot steam can lead to injury. Do not use electrical heating or steam cleaning equipment, open flames or defrosting sprays to defrost.

Do not use sharp implements to remove the ice.

Please observe the specific information in the other sections:

DANGER identifies a situation involving direct

danger which, if not obviated, may result in death or severe bodily injury.

WARNING identifies a dangerous situation

which, if not obviated, may result in death or severe bodily injury.

CAUTION identifies a dangerous situation

which, if not obviated, may result in minor or medium bodily injury.

NOTICE identifies a dangerous situation

which, if not obviated, may result in damage to property.

Note identifies useful information and tips.

3 Controls and displays

3.1 Operating controls

Fig. 3

(1) Temperature controller (2) Cool-Plus switch

4 Putting into operation

4.1 Transporting the appliance

CAUTION

Risk of injury and danger of damage as a result of incorrect transport!

Transport the appliance in a packed condition.

Transport the appliance upright.

Do not transport the appliance without assistance.

4.2 Installing the appliance

WARNING

Fire hazard due to dampness! If live parts or the mains lead become damp this may cause short circuits.

The appliance is designed for use in enclosed areas. Do not

operate the appliance outdoors or in areas where it is exposed to splash water or damp conditions.

Risk of fire due to short circuit! If the mains cable/connector of the appliance or of another appliance touch the rear of the appliance, the mains cable/ connector may be damaged by the appliance vibrations, leading to a short circuit.

WARNING

Stand the appliance so that it is not touched by connectors or main cables. Do not plug the appliance or any others into sockets located near the rear of the appliance.
