14~15Add Timing Table (VESA & CEA 1280x720 timing)
18
30Update a mechanic drawing
5Update Power Consumption
9Update LED Bar Electrical Characteristics
22Update Color Coordinates
30Update a mechanic drawing
Update Power Sequence (T8 Min. : 500ms Æ 200ms)
Update Suffix (SDE1 Æ SDE5)
0.6Jun. 23. 201112Update LED Connector Pin Configuration
0.7Jan. 20. 20125Luminance Spec change
22Luminance Spec change
23Update Lot Minimum Luminance Spec
Ver. 1.0JAN. 20. 2012
4/ 39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Liquid Crystal Display
Product Specification
1. General Description
LM270WQHD is a Color Active Matrix Liquid Crystal Display with Light Emitting Diode ( White LED) backlight
system without LED driver. The matrix employs a-Si Thin Film Transistor as the active element.
It is a transmissive type display operating in the normally black mode. It has a 27inch diagonally measured
active display area with QHD resolution (2560 vertical by 1440 horizontal pixel array)
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical stripes.
Gray scale or the brightness of the sub-pixel color is determined with a 10-bit gray scale signal for each dot,
thus, presenting a palette of more than 1.07B colors with FRC (Frame Rate Control).
It has been designed to apply the 10-bit 4Lane Display port interface.
It is intended to support displays where high brightness, super wide viewing angle,
high color saturation, and high color are important.
LM270WQ1
Mini-LVDS (RGB)
G1
Gate Driver Circuit
G1440
Source Driver Circuit
S1S2560
TFT - LCD Panel
(2560 Ý RGB Ý 1440 pixels)
B/L System (White LED)
Main Link
4 Lane
AUX CH
HPD
DP function
LCD Power
12 V
CN1
(30pin)
CN7
(6pin)
Flash
memory
SPI
Logic Power
3.3V / 1.2V
EEPROM
(EDID)
I2C
Timing
Controller
Power
Enable
(Video On)
Power Circuit
Block
Vled
General Features
Active Screen Size27.0 inches(68.47cm) diagonal
Outline Dimension630.0(H) x 376.13(V) x 19.8(D) mm(Typ.)
Pixel Pitch0.2331 mm x 0.2331 mm
Pixel Format2560 horiz. By 1440 vert. Pixels RGB stripes arrangement
1. The specified current and power consumption are under the V
whereas mosaic pattern(8 x 6) is displayed and f
2. The current is specified at the maximum current pattern.
3. The duration of rush current is about 2ms and rising time of power Input is 1ms(min.).
White : 255Gray
Black : 0Gray
-(550)(720)mA1
-(700)(910)mA2
-(6.60)(8.64)Watt1
(8.40)(10.92)Watt2
=12.0V, 25 2¶C,fV=60Hz condition
is the frame frequency.
V
LCD
Maximum current pattern
Mosaic Pattern(8 x 6)
Ver. 1.0JAN. 20. 2012
White Pattern
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
7/ 39
www.panelook.com
Global LCD Panel Exchange Center
3-1-2. DisplayPort Main Link Receiver Characteristics
DP628 which supports Apple BER Spec with below test condition is used for DP Rx.
Table 2-1-2. DISPLAYPORT MAIN LINK RECEIVER CHARACTERISTICS
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
Parameter
Symbol Error Rate,
normal link data transmission,
HBR, 4 lane operation
Note :
1. Jitter Tolerance Testing follows VESA DisplayPort™ PHY Compliance Testing Standard, Version 1.1a.
Jitter composition is specified in the Standard.
2. TJ at Receiver Connector (TP3) ≦0.491UI @ Bit Error Rate (BER) = 10
3. Eye Height at TP3 ≧ 150mVpp
4. Max lane to lane mismatch of insertion loss at TP3 : 20*log |max(eye height)/min(eye height)| ≦ 2.3dB
5. Max source pre-emphasis level at level 0 (0dB) ≦ 0.25dB
MinTypMax
Values
-13
101~5
-13
Notes
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
8/ 39
www.panelook.com
Global LCD Panel Exchange Center
Product Specification
Table 2-2. LED Bar ELECTRICAL CHARACTERISTICS
www.panelook.com
LM270WQ1
Liquid Crystal Display
ItemsSymbol
LED String VoltageV
LED String PowerP
BL Power P
LED Life TimeLED_LT30K-Hrs
LED Junction TemperatureTj150-7,8
S
S
BL
MinTypMax
(52.6)(56.1)(59.6)Vrms
(18.4)(19.6)(20.9)W
-(58.9)(62.6)W
Spec
UnitRemarkNotes
Ta=25, at Duty 100%
of DC 350mA
Ta=25, at Duty 100%
of DC 350mA
Ta=25, at Duty 100%
of DC 350mA
Tj≤90, at Duty 100%
of DC 350mA
1,2,3,
7
1,2,3,
4,6,7
1,2,4,
6,7
5,7,8
LED driver design guide
: The design of the LED driver must have specifications for the LED in LCD Assembly.
The performance of the LED in LCM, for example life time or brightness, is extremely influenced by
the characteristics of the LED driver.
So all the parameters of an LED driver should be carefully designed and output current should be
Constant current control.
Please control feedback current of each string individually to compensate the current variation
among the strings of LEDs.
When you design or order the LED driver, please make sure unwanted lighting caused by
the mismatch of the LED and the LED driver (no lighting, flicker, etc) never occurs.
When you confirm it, the LCD module should be operated in the same condition as installed in
your instrument.
1. Specified values are for a single LED bar.
2. The specified current is input LED chip 100% duty current.
3. The specified voltage is input LED string and Bar voltage at typical 350 mA 100% duty current.
4. The specified power consumption is input LED bar power consumption at typical 350 mA 100% duty current.
5. The LED life time is determined as the time at which brightness of the LED is 70% compared to that of initial
value at the typical LED current on condition of continuous operating at below junction temperature 90¶C.
6. The LED power consumption shown above does not include loss of external driver.
The used LED BL current is the LED typical current.
P
String Power Consumption is calculated with
BL Power Consumption is calculated with
S
P
= V
BL
= VSx 350mA
x 350mA x 3 (String no.)
Bar
7. LED operating DC Forward Current and Junction Temperature must not exceed LED Max Ratings.
8. The LED life time and the maximum rating of LED junction temperature are evaluated at LED package level,
not at liquid crystal module level.
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
9/ 39
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
3-2. Interface Connections
3-2-1. LCD Module
- LCD Connector(CN1) : 20525-030E-01 (manufactured by I-PEX)
The pin configuration for the 30 pin connector is shown in the table below.
1GNDGround16Lane0NComponents Signal for Main Link 0
LM270WQ1
Liquid Crystal Display
2DDC_SDADDC Data17GNDHigh Speed Ground for Main Link 1
3DDC_SCLDDC Clock18Lane1PTrue Signal for Main Link 1
4GNDGround19Lane1NComponents Signal for Main Link 1
5I2C_SDAI2C Data20GNDHigh Speed Ground for Main Link 2
6I2C_SCLI2C Clock21Lane2PTrue Signal for Main Link 2
7GNDGround22Lane2NComponents Signal for Main Link 2
8SPDIFAudio output from DP Rx23GNDHigh Speed Ground for Main Link 3
9OPTION_1TBD24Lane3PTrue Signal for Main Link 3
10HPDHot Plug Detect Signal25Lane3NComponents Signal for Main Link 3
11GNDHigh Speed Ground for Auxiliary Channel26GNDHigh Speed Ground
12AUX_CHNComponent Signal for Auxiliary27VIDEO_ONVideo status from DP Rx
13AUX_CHPTrue Signal for Auxiliary Channel28OPTION_2TBD
14GNDHigh Speed Ground for Main Link 029VSYNCVertical sync output from DP Rx
15Lane0PTrue Signal for Main Link 030GNDGround
Notes : 1. Connector
2.1 Connector(Receptacle) : 20525-030E-01(I-PEX)
2.2 Mating Connector(Plug) : 20523-030T-01(I-PEX)
1
30
#1
#30
Rear view of LCM
20525-030E-01 (I-PEX)
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
10 / 39
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Product Specification
3-2. Interface Connections
3-2-1. LCD Module
- Power Connector(CN7) : 53780-8608 (manufactured by MOLEX)
The pin configuration for the 6 pin connector is shown in the table below.
Table 3-2. POWER CONNECTOR(CN7) PIN CONFIGURATION
PinSymbolDescriptionNOTES
1GNDGround
LM270WQ1
Liquid Crystal Display
2GNDGround
3GNDGround
4VIN12V for LCM main power
5VIN12V for LCM main power
6VIN12V for LCM main power
#1#6
\Z^_WT_]W]
3-2-2. Sync Connector
This connector is used for synchronized LED Driver.
The connector is 53780-8604. (Manufactured by MOLEX)
Table 4. LED SYNCHRONIZED CONNECTOR(CN4) PIN CONFIGURATION
#1#6
Rear view of LCM
PinSymbolDescriptionNOTES
1DXPPositive connection to remote temp. sensor
2DXNNegative connection to remote temp. sensor
3GNDGround
4VSYNCMVSYNCM for synchronized LED Driver
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
11 / 39
www.panelook.com
Global LCD Panel Exchange Center
3-2-3. Backlight Interface
- LED Connector : H401K-D12N-12B (Manufactured by E&T)
- Mating Connector : 4530K-F12N-01R (Manufactured by E&T)
Table 5. LED CONNECTOR PIN CONFIGULATION
Pin No.SymbolDescriptionNote
1NCNC
2LED1-LED channel 1 Cathode
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
3LED2+LED channel 2 Anode
4NCNC
5NCNC
6LED3-LED channel 3 Cathode
7LED1+LED channel 1 Anode
8NCNC
9NCNC
10LED2-LED channel 2 Cathode
11LED3+LED channel 3 Anode
12NCNC
1 Bar
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
12 / 39
www.panelook.com
Global LCD Panel Exchange Center
3-3. Signal Timing Specifications
All of the interface signal timing should be satisfied with the following specifications for it’s proper operation.
Table 6_1. TIMING TABLE (VESA COORDINATED VIDEO TIMING)
ITEMSYMBOLMinTypMaxUnitNote
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
DCLK
Hsync
Vsync
Data
Enable
Periodt
FrequencyfCLK241.5241.5241.5MHz-
PeriodtHP272027202720
Width-ActivetWH323232
Periodt
FrequencyfV59.9559.9559.95Hz
Width-Activet
Horizontal Validt
Horizontal Back PorchtHBP808080
Horizontal Front PorchtHFP484848
Horizontal Blank-160160160t
Vertical ValidtVV144014401440
CLK4.144.144.14ns
tCLK
VP148114811481tHP
WV555tHP
HV256025602560
t
CLK
WH+ tHBP+ tHFP
Vertical Back PorchtVBP333333
t
HP
Vertical Front PorchtVFP333
Vertical Blank-414141t
Note: Hsync period and Hsync width-active should be even number times of tCLK. If the value is odd number
times of tCLK, display control signal can be asynchronous. In order to operate this LCM a Hsync,
Vsync, and DE(data enable) signals should be used.
1. The performance of the electro-optical characteristics may be influenced by variance of the vertical
refresh rates.
2. Vsync and Hsync should be keep the above specification.
3. Hsync Period, Hsync Width, and Horizontal Back Porch should be any times of of character
number(8).
4. The polarity of Hsync, Vsync is not restricted.
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
WV+ tVBP+ tVFP
13 / 39
www.panelook.com
Global LCD Panel Exchange Center
Table 6_2. 1280x720 TIMING TABLE (VESA COORDINATED VIDEO TIMING)
ITEMSYMBOLMinTypMaxUnitNote
PeriodtCLK13.4313.4313.43ns
DCLK
Frequencyf
PeriodtHP166416641664
Hsync
Width-ActivetWH128128128
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
CLK74.574.574.5MHz-
tCLK
Periodt
Vsync
Data
Enable
FrequencyfV59.8559.8559.85Hz
Width-Activet
Horizontal Validt
Horizontal Back PorchtHBP192192192
Horizontal Front PorchtHFP646464
Horizontal Blank-384384384t
Vertical ValidtVV720720720
Vertical Back PorchtVBP202020
Vertical Front PorchtVFP333
Vertical Blank-282828t
Note: Hsync period and Hsync width-active should be even number times of t
times of t
CLK, display control signal can be asynchronous. In order to operate this LCM a Hsync,
VP748748748tHP
WV555tHP
HV128012801280
t
CLK
t
HP
CLK. If the value is odd number
WH+ tHBP+ tHFP
WV+ tVBP+ tVFP
Vsync, and DE(data enable) signals should be used.
1. The performance of the electro-optical characteristics may be influenced by variance of the vertical
refresh rates.
2. Vsync and Hsync should be keep the above specification.
3. Hsync Period, Hsync Width, and Horizontal Back Porch should be any times of of character
number(8).
4. The polarity of Hsync, Vsync is not restricted.
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
14 / 39
www.panelook.com
Global LCD Panel Exchange Center
Table 6_3. 1280x720 TIMING TABLE (CEA COORDINATED VIDEO TIMING)
ITEMSYMBOLMinTypMaxUnitNote
PeriodtCLK13.4713.4713.47ns
DCLK
Frequencyf
PeriodtHP165016501650
Hsync
Width-ActivetWH404040
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
CLK74.2574.2574.25MHz-
tCLK
Periodt
Vsync
Data
Enable
FrequencyfV60.0060.0060.00Hz
Width-Activet
Horizontal Validt
Horizontal Back PorchtHBP220220220
Horizontal Front PorchtHFP110110110
Horizontal Blank-370370370t
Vertical ValidtVV720720720
Vertical Back PorchtVBP202020
Vertical Front PorchtVFP555
Vertical Blank-303030t
Note: Hsync period and Hsync width-active should be even number times of t
times of t
CLK, display control signal can be asynchronous. In order to operate this LCM a Hsync,
VP750750750tHP
WV555tHP
HV128012801280
t
CLK
t
HP
CLK. If the value is odd number
WH+ tHBP+ tHFP
WV+ tVBP+ tVFP
Vsync, and DE(data enable) signals should be used.
1. The performance of the electro-optical characteristics may be influenced by variance of the vertical
refresh rates.
2. Vsync and Hsync should be keep the above specification.
3. Hsync Period, Hsync Width, and Horizontal Back Porch should be any times of of character
number(8).
4. The polarity of Hsync, Vsync is not restricted.
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
15 / 39
www.panelook.com
Global LCD Panel Exchange Center
3-4. Signal Timing Waveforms
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
Hsync, Vsync, DE, DATA
t
CLK
Dclk
INVALID
DATA
DE(Data Enable)
Hsync
t
WH
0.5VDD
0.7VDD
0.3VDD
VALID
Data are latched at the falling edge of DCLK
t
HP
INVALID
t
HBP
t
HV
DE(Data Enable)
t
VP
t
WV
Vsync
t
VBP
t
VV
DE(Data Enable)
Ver. 1.0JAN. 20. 2012
t
t
HFP
VFP
16 / 39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
3-5. Color Data Reference
The Brightness of each primary color(red,green,blue) is based on the 8-bit gray scale data input for the color;
the higher the binary input, the brighter the color. The table below provides a reference for color versus data
input.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
17 / 39
www.panelook.com
Global LCD Panel Exchange Center
3-6. Power Sequence
3-6-1. Power Sequence
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
0.4
200
Notes : [1] HPD is asserted high by Sink at power-up
[2] SYMBOL_LOCK indicated by contents of Sink DPCD registers 00202h to 00205h
[3] VIDEO_ON asserted high by Sink when video to panel is valid
[6] BL_EN is an active-high MLB enable signal for panel BLU
Notes : 1. Please avoid floating state of interface signal at invalid period.
2. When the interface signal is invalid, be sure to pull down the power supply for LCD V
3. LED power must be turn on after power supply for LCD and interface signal are valid.
Ver. 1.0JAN. 20. 2012
to 0V.
LCD
18 / 39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
3-6. Power Sequence
3-6-1. Power Sequence
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
Notes : [2] SYMBOL_LOCK indicated by contents of Sink DPCD registers 00202h to 00205h
[4] Power-state set by Source in Sink DPCD register 00600h
[5] VIDEO_ON asserted low by Sink because of :
1) loss of SYMBOL_LOCK or
2) DP Sink is powered down
[7] BL_EN must be asserted low by system as rapidly as possible when video is invalid
to avoid visible artifacts
[8] T14 defines minimum off-time for 12V power
[9] min. times of 0 indicate precedence ordering of events, e.g. where actual timing is TBD
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
19 / 39
www.panelook.com
Global LCD Panel Exchange Center
3-6-2. Power Sequence, EDID Read / Write
*** This timing is for fabrication purpose only, not for normal operation. ***
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
DP Logic Power(3.3V)
HPD
EDID Read*
ADDR : A1
Write protection
EDID Write*
ADDR : A0
VDP
0V
10
%
TE1
90
%
TE2
TE3
TE4
TE6
TE5
TE7
90
%
10
%
TE8
* EDID Read time and EDID write time will be exclusive.
Notes.
In case of without DP signal after DP logic power on, check HPD after TE1 time
and if HPD is low status then any time can read EDID
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Units
20 / 39
www.panelook.com
Global LCD Panel Exchange Center
3-6-3. State Machine
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
OFF MODE
NEGATIVE
DC STATE
(OR CABLE
UNPLUG)
SOURCE
WRITES
02
DP AUX
CHANNEL
NEGATIVE
LINE
SLEEP MODE
DPCD
0x600
VALUE
POSITIVE
DC STATE
SOURCE
WRITES
01
ON MODE
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
21 / 39
www.panelook.com
Global LCD Panel Exchange Center
4. Optical Specifications
Optical characteristics are determined after the unit has been ‘ON’ for approximately 70 minutes
in a dark environment at 25·2¶C. The values specified are at an approximate distance 50cm from the LCD
surface at a viewing angle of and equal to 0 ¶ and aperture 1 degree.
FIG. 1 presents additional information concerning the measurement equipment and method.
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
Pritchard 880 or
equivalent
Optical Stage(x,y)
LCD Module
50cm
FIG. 1 Optical Characteristic Measurement Equipment and Method
Table 9. OPTICAL CHARACTERISTICS
ParameterSymbol
Contrast RatioCR7001000-1
Surface Luminance, whiteL
Luminance Variation
Response Time
Color Coordinates
[CIE1931]
Color Shift
Viewing Angle (CR>10)
General
Effective
Gray Scale2.28
Horizontal
Vertical
Horizontal
Vertical
Rise TimeTr
Decay TimeTr
REDRx
GREENGx0.298
BLUE Bx0.150
WHITEWx0.313
Horizontal
Vertical
WH
WHITE
R
D
Ry0.334
Gy0.619
-0.03
By0.047
Wy0.329
CST_H
CST_V
H
V
GMA_H
GMA_V
(Ta=25 ¶C, V
Values
MinTypMax
380460-cd/m22,9
-6.514ms4.1
-7.514ms4.1
0.652
Typ
-178-
-178-
170178-
170178-
178-
178-
=12.0V, fV=60Hz Dclk=242.28MHz)
LCD
UnitsNotes
30%3
Typ
+0.03
Degree5
Degree6
Degree7
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
22 / 39
www.panelook.com
Global LCD Panel Exchange Center
Notes 1. Contrast Ratio(CR) is defined mathematically as :
It is measured at center point(Location P1)
RatioContrast
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
pixels white all with Luminance Surface
pixels black all with Luminance Surface
2. Surface luminance(L
the surface with all pixels displaying white. For more information see FIG 2.
= = Average[ Lon1,Lon2,Lon3,Lon4,Lon5]
L
WH
3. The variation in surface luminance , WHITE is defined as :
4. Response time is the time required for the display to transition from black to white (Rise Time,
Tr
5. Color shift is the angle at which the color difference is lower than 0.04.
WHI TE
Where L1 to L13 are the luminance with all pixels displaying white at 13 locations.
For more information see FIG 2.
) and from white to black (Decay Time, TrD). For additional information see FIG 3
R
For more information see FIG 4.
- Color difference (Δu’v’)
'
u
WH)is luminance value at 5 points average across the LCD surface 50cm from
)L .... ,L ,(L Average
on5on2on1
4
x
'
3122
yx
21
v
2
9
y
3122
yx
2
)''()''(''vvuuvu
21
u’1, v’1 : u’v’ value at viewing angle direction
u’2, v’2 : u’v’ value at front (θ=0)
)L .. ,L,Minimum(L- )L .. ,L,Maximum(L
on13on2on1on13on2on1
(%)100
- Pattern size : 25% Box size
- Viewing angle direction of color shift : Horizontal, Vertical
6. Viewing angle is the angle at which the contrast ratio is greater than 10. The angles are
determined for the horizontal or x axis and the vertical or y axis with respect to the z axis which
is normal to the LCD surface. For more information see FIG 5.
7. Effective viewing angle is the angle at which the gamma shift of gray scale is lower than 0.3.
For more information see FIG 6 and FIG 7.
8. Gray scale specification
Gamma Value is approximately 2.2. For more information see Table 10.
2
9. 5-lot moving average luminance is minimum 450 cd/m
5-lot moving average means the average of lot (n-4), (n-3), (n-2), (n-1) and (n).
Lot 1, 2, 3 and 4 individually will meet average 450 cd/m
Ver. 1.0JAN. 20. 2012
at center point. (Location P1)
2
at center point. (Location P1)
23 / 39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
Measuring point for surface luminance & measuring point for luminance variation.
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
H
A
H/16
67
B
V
V/10
A : H/4 mm
B : V/4 mm
@ H,V : Active Area
The response time is defined as the following figure and shall be measured by switching the input signal for
“black” and “white”.
100
90
9
1112
FIG. 2 Measure Point for Luminance
2
1
4
TrR
3
5
Active Area
8
10
13
TrD
Optical
Response
10
0
black
FIG. 3. Response Time
Ver. 1.0JAN. 20. 2012
white
black
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
24 / 39
www.panelook.com
Global LCD Panel Exchange Center
Color shift is defined as the following test pattern and color.
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
25% Box size
FIG. 4 Test Pattern
Average RGB values in Bruce RGB for Macbeth Chart
Dark skinLight skinBlue skyFoliageBlue flowerBluish green
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
25 / 39
www.panelook.com
Global LCD Panel Exchange Center
Dimension of viewing angle range.
= 180, Left
www.panelook.com
Product Specification
Normal
E
Y
= 90, Up
LM270WQ1
Liquid Crystal Display
= 270, Down
FIG. 5 Viewing angle
FIG. 6 Sample Luminance vs. gray scale
(using a 256 bit gray scale)
= 0, Right
FIG. 7 Sample Log-log plot of luminance
vs. gray scale
r
LaVL
b
b
Here the Parameter α and γ relate the signal level V to the luminance L.
The GAMMA we calculate from the log-log representation (FIG. 7)
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
)log()log()log(aVrLL
26 / 39
www.panelook.com
Global LCD Panel Exchange Center
Table 10. Gray Scale Specification
Gray LevelRelative Luminance [%] (Typ.)
00.10
311.08
634.71
9511.5
12721.7
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
15935.5
19153.1
22374.5
255100
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
27 / 39
www.panelook.com
Global LCD Panel Exchange Center
5. Mechanical Characteristics
The contents provide general mechanical characteristics. In addition the figures in the next page are detailed
mechanical drawing of the LCD.
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
Horizontal630.0mm
Outline Dimension
Bezel Area
Active Display Area
Weight4050 g (Typ.)
Surface Treatment
Notes : Please refer to a mechanic drawing in terms of tolerance at the next page.
Vertical376.13mm
Depth19.8mm
Horizontal601.7mm
Vertical340.7mm
Horizontal596.74mm
Vertical335.66mm
Hard coating(2H)
Glare, Low Reflection treatment of the front polarizer
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
28 / 39
www.panelook.com
Global LCD Panel Exchange Center
VIEW>
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
<FRONT VIEW>
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
29 / 39
www.panelook.com
Global LCD Panel Exchange Center
<REAR VIEW>
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
30 / 39
www.panelook.com
Global LCD Panel Exchange Center
6. Reliability
Environment test condition
NoTest ItemCondition
1High temperature storage testTa= 60¶C 240h
2Low temperature storage testTa= -20¶C 240h
3High temperature operation testTa= 50¶C 50%RH 240h
4Low temperature operation testTa= 0¶C 240h
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
Vibration test
5
(non-operating)
Shock test
6
(non-operating)
Altitude
7
Operating
Storage / Shipment
Wave form : random
Vibration level : 1.0G RMS
Bandwidth : 10-300Hz
Duration : X,Y,Z, 10 min
One time each direction
Shock level : 100Grms
Waveform : half sine wave, 2ms
Direction : ᇹX, ᇹY, ᇹZ
One time each direction
0 - 10,000 feet(3,048m)
0 - 40,000 feet(12,192m)
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
31 / 39
www.panelook.com
Global LCD Panel Exchange Center
7. International Standards
7-1. Safety
a) UL 60950-1, Second Edition, Underwriters Laboratories Inc.
Information Technology Equipment - Safety - Part 1 : General Requirements.
b) CAN/CSA C22.2 No.60950-1-07, Second Edition, Canadian Standards Association.
Information Technology Equipment - Safety - Part 1 : General Requirements.
c) EN 60950-1:2006 + A11:2009, European Committee for Electrotechnical Standardization(CENELEC).
Information Technology Equipment - Safety - Part 1 : General Requirements.
d) IEC 60950-1:2005, Second Edition, The International Electrotechnical Commission (IEC).
Information Technology Equipment - Safety - Part 1 : General Requirements.
(Including report of IEC60825-1:2001 clause 8 and clause 9)
Notes
1. Laser (LED Backlight) Information
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
Class 1M LED Product
IEC60825-1 : 2001
Embedded LED Power (Class 1M)
2. Caution
: LED inside.
Class 1M laser (LEDs) radiation when open.
Do not open while operating.
7-2. EMC
a) ANSI C63.4 “American National Standard for Methods of Measurement of Radio-Noise
Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz.”
American National Standards Institute (ANSI), 2003.
b) CISPR 22 “Information technology equipment – Radio disturbance characteristics – Limit and
methods of measurement." International Special Committee on Radio Interference
(CISPR), 2005.
c) CISPR 13 “Sound and television broadcast receivers and associated equipment – Radio disturbance
characteristics – Limits and method of measurement." International Special Committee on Radio
Interference (CISPR), 2006.
7-3. Environment
a) RoHS, Directive 2002/95/EC of the European Parliament and of the council of 27 January 2003
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
32 / 39
www.panelook.com
Global LCD Panel Exchange Center
8. Packing
8-1. Designation of Lot Mark
a) Lot Mark
ABCDEFGHI JKLM
A,B,C : SIZE(INCH) D : YEAR
E : MONTH F ~ M : SERIAL NO.
Note
1. YEAR
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
Year
Mark
2. MONTH
Month
Mark
b) Location of Lot Mark
Serial No. is printed on the label. The label is attached to the backside of the LCD module.
This is subject to change without prior notice.
8-2. Packing Form
a) Package quantity in one box : 7ea
b) Box Size : 700mm X 355mm X 430mm
2016G2017H2018J2019
F
Jun7Jul8Aug9Sep
6
CBA
2014E2015
D
Apr5May
4
201320122011
2020
K
Oct
A
Nov
B
DecMarFebJan
C321
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
33 / 39
www.panelook.com
Global LCD Panel Exchange Center
9. PRECAUTIONS
Please pay attention to the followings when you use this TFT LCD module.
9-1. MOUNTING PRECAUTIONS
(1) You must mount a module using holes arranged in four corners or four sides.
(2) You should consider the mounting structure so that uneven force (ex. Twisted stress) is not applied to the
module. And the case on which a module is mounted should have sufficient strength so that external
force is not transmitted directly to the module.
(3) Please attach the surface transparent protective plate to the surface in order to protect the polarizer.
Transparent protective plate should have sufficient strength in order to the resist external force.
(4) You should adopt radiation structure to satisfy the temperature specification.
(5) Acetic acid type and chlorine type materials for the cover case are not desirable because the former
generates corrosive gas of attacking the polarizer at high temperature and the latter causes circuit break
by electro-chemical reaction.
(6) Do not touch, push or rub the exposed polarizers with glass, tweezers or anything harder than HB
pencil lead. And please do not rub with dust clothes with chemical treatment.
Do not touch the surface of polarizer for bare hand or greasy cloth.(Some cosmetics are detrimental
to the polarizer.)
(7) When the surface becomes dusty, please wipe gently with absorbent cotton or other soft materials like
chamois soaks with petroleum benzene. Normal-hexane is recommended for cleaning the adhesives
used to attach front / rear polarizers. Do not use acetone, toluene and alcohol because they cause
chemical damage to the polarizer.
(8) Wipe off saliva or water drops as soon as possible. Their long time contact with polarizer causes
deformations and color fading.
(9) Do not open the case because inside circuits do not have sufficient strength.
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
9-2. OPERATING PRECAUTIONS
(1) The spike noise causes the miss-operation of circuits. It should be lower than following voltage :
V=·200mV(Over and under shoot voltage)
(2) Response time depends on the temperature.(In lower temperature, it becomes longer.)
(3) Brightness depends on the temperature. (In higher temperature, it becomes lower.)
And in lower temperature, response time(required time that brightness is stable after turned on) becomes
longer.
(4) Be careful for condensation at sudden temperature change. Condensation makes damage to polarizer or
electrical contacted parts. And after fading condensation, smear or spot will occur.
(5) When fixed patterns are displayed for a long time, remnant image is likely to occur.
(6) Module has high frequency circuits. Sufficient suppression to the electromagnetic interference shall be
done by system manufacturers. Grounding and shielding methods may be important to minimized the
interference.
(7) Please do not give any mechanical and/or acoustical impact to LCM. Otherwise, LCM can’t be operated
its full characteristics perfectly.
(8) A screw which is fastened up the steels should be a machine screw.
(if not, it causes metallic foreign material and deal LCM a fatal blow)
(9) Please do not set LCD on its edge.
(10) Partial darkness may happen during 3~5 minutes when LCM is operated initially in condition that
luminance is under 40% at low temperature (under 5). This phenomenon which disappears naturally
after 3~5 minutes is not a problem about reliability but LCD characteristic
Ver. 1.0JAN. 20. 2012
34 / 39
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
9-3. ELECTROSTATIC DISCHARGE CONTROL
Since a module is composed of electronic circuits, it is not strong to electrostatic discharge. Make certain that
treatment persons are connected to ground through wrist band etc. And don’t touch interface pin directly.
9-4. PRECAUTIONS FOR STRONG LIGHT EXPOSURE
Strong light exposure causes degradation of polarizer and color filter.
9-5. STORAGE
When storing modules as spares for a long time, the following precautions are necessary.
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
(1) Store them in a dark place. Do not expose the module to sunlight or fluorescent light. Keep the temperature
between 5¶C and 35¶C at normal humidity.
(2) The polarizer surface should not come in contact with any other object.
It is recommended that they be stored in the container in which they were shipped.
9-6. HANDLING PRECAUTIONS FOR PROTECTION FILM
(1) The protection film is attached to the bezel with a small masking tape.
When the protection film is peeled off, static electricity is generated between the film and polarizer.
This should be peeled off slowly and carefully by people who are electrically grounded and with well ionblown equipment or in such a condition, etc.
(2) When the module with protection film attached is stored for a long time, sometimes there remains a very
small amount of glue still on the bezel after the protection film is peeled off.
(3) You can remove the glue easily. When the glue remains on the bezel surface or its vestige is recognized,
please wipe them off with absorbent cotton waste or other soft material like chamois soaked with normalhexane.
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
35 / 39
www.panelook.com
Global LCD Panel Exchange Center
10. EDID DATA
10-1. EDID Data
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
36 / 39
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
37 / 39
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
LM270WQ1
Liquid Crystal Display
Product Specification
Ver. 1.0JAN. 20. 2012
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
