LG Display LC550EQD-FGF2 Specification

( ● ) Preliminary Specification
( ) Final Specification

Title 55.0” WUXGA TFT LCD

LC550EQD

Product Specification

SPECIFICATION

FOR

APPROVAL

BUYER General
LCD MODEL LC550EQD-FGF2
SET MODEL

APPROVED BY

/

/

/

SIGNATURE

DATE

SUPPLIER LG Display Co., Ltd.

*MODEL LC55EQD

SUFFIX FGF2 (RoHS Verified)

APPROVED BY

B. Y. Kim /Team Leader

REVIEWED BY

S. B. Lee / Project Leader

PREPARED BY

K.H. Kim / Engineer

SIGNATURE

DATE

Please return 1 copy for your confirmation with

your signature and comments.

Ver. 0.0

TV Product Development Dept.

LG Display Co., Ltd.

1 /38

Product Specification

CONTENTS

LC550EQD

Number

COVER
CONTENTS

RECORD OF REVISIONS 3
1
2
3

3-1
3-2
3-3

3-4 V by Oone SIGNAL SPECIFICATIONS 13
3-5

3-6
4
5
6

GENERAL DESCRIPTION
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL SPECIFICATIONS
ELECTRICAL CHARACTERISTICS
INTERFACE CONNECTIONS
SIGNAL TIMING SPECIFICATIONS

COLOR DATA REFERENCE
POWER SEQUENCE
OPTICAL SPECIFICATIONS
MECHANICAL CHARACTERISTICS
RELIABILITY

ITEM

Page

1
2

4
5
6
6
8

12

15
16
18
24
27

7

7-1

7-2

7-3
8 PACKING 29

8-1 PACKING FORM 29
9
9-1
9-2

9-3 ELECTROSTATIC DISCHARGE CONTROL 31
9-4 PRECAUTIONS FOR STRONG LIGHT EXPOSURE 31
9-5 STORAGE 31
9-6 Operating condition guide 31

Ver. 0.0

INTERNATIONAL STANDARDS
Safety
EMC
ENVIRONMENT

PRECAUTIONS
MOUNTING PRECAUTIONS
OPERATING PRECAUTIONS

28
28
28
28

30
30
30

2 /38

Product Specification

RECORD OF REVISIONS

Revision No. Revision Date Page Description

0.0 Jun,22, 2013 - Preliminary Specification(First Draft)

LC550EQD

Ver. 0.0

3 /38

LC550EQD

Product Specification

1. General Description

The LC550EQD is a Color Active Matrix Liquid Crystal Display with an integral Source PCB and the Gate PCB
at each side. The matrix employs a-Si Thin Film Transistor as the active element.
It is a transmissive display type which is operating in the normally black mode. It has a 54.64 inch diagonally
measured active display area with QWUXGA resolution progressive mode (2160 vertical by 3840 horizontal
pixel array).
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arrayed in vertical stripes.
Gray scale or the luminance of the sub-pixel color is determined with a 10-bit gray scale signal for each dot.
Therefore, it can present a palette of more than 1.06Bilion colors.
It has been designed to apply the 10-bit 16 Lane V by One interface.
It is intended to support LCD TV, PCTV where high brightness, super wide viewing angle, high color gamut,
high color depth and fast response time are important.

CN1

+12V

(5pin)

Vby1
8lane

Data
format

CN2

(51pin)

Bit

select
HTPDN
LOCKN

Vby1

CN3

8lane

(41pin)

SIN, SCLK, V_Sync

+24.0V, GND, On/Off

ExtVBR-B

Vby1
1~8lane

Option
signal

I2C

Vby1
9~16lane

EEPROM

SCL

SDA

Timing Controller

Vby1 Rx +L/D

+DGA + ODC

Power Circuit

Block

LED Driver

Power Signals

EPI(RGB)

Gate Driver Circuit

Control
Signals

General Features

Active Screen Size 54.64 inches(1387.8mm) diagonal
Outline Dimension 1223.4 (H) x 697.2 (V) x11.7 (B) (Typ.)

Source Driver Circuit

S1 S3840

G1

TFT - LCD Panel

(3840 × RGB × 2160 pixels)

G2160

Local Dimming :12 Block

G1

G2160

Gate Driver Circuit

Pixel Pitch 0.315 mm x 0.315 mm
Pixel Format 3840 horiz. by 2160 vert. Pixels, RGB stripe arrangement
Color Depth 10bit(D), 1.06Billon colors
Luminance, White 450cd/m2 (Center 1point ,Typ.)
Viewing Angle (CR>10) Viewing angle free ( R/L 178 (Min.), U/D 178 (Min.))
Power Consumption Total 100.8W (Typ.) [Logic= 11.5W, LED Driver=89.3W (ExtVbr_B=100% )] (TBD)
Weight 16.5kg(Typ.) (TBD)
Display Mode Transmissive mode, Normally black
Surface Treatment Hard coating(2H), Anti-glare treatment of the front polarizer 1%(Typ)

Ver. 0.0

4 /38

LC550EQD

Product Specification

2. Absolute Maximum Ratings

The following items are maximum values which, if exceeded, may cause faulty operation or permanent damage
to the LCD module.

Table 1. ABSOLUTE MAXIMUM RATINGS

Parameter Symbol

Unit Notes

Min Max

LCD Circuit VLCD -0.3 +14.0 VDC

Power Input Voltage

Driver VBL -0.3 + 27.0 VDC
ON/OFF VOFF / VON -0.3 +3.9 VDC

1

Value

Driver Control Voltage

Brightness EXTVBR-B -0.3 +3.9 VDC

Status Status -0.3 +3.9
T-Con Option Selection Voltage VLOGIC
Operating Temperature TOP 0 +50

-0.3 +4.0 VDC
°C

2,3

Storage Temperature TST -20 +60

Panel Front Temperature TSUR

- +68

°C

°C

4

Operating Ambient Humidity HOP 10 90 %RH

2,3

Storage Humidity HST 10 90 %RH

Notes

1. Ambient temperature condition (Ta = 25  2 °C )

2. Temperature and relative humidity range are shown in the figure below.
Wet bulb temperature should be Max 39°C, and no condensation of water.

3. Gravity mura can be guaranteed below 40°C condition.

4. The maximum operating temperatures is based on the test condition that the surface temperature
of display area is less than or equal to 68°C with LCD module alone in a temperature controlled chamber.
Thermal management should be considered in final product design to prevent the surface temperature of
display area from being over 68℃. The range of operating temperature may be degraded in case of
improper thermal management in final product design.

90%

Ver. 0.0

Wet Bulb
Temperature [°C]

20

10

0

10 20 30 40 50 60 70 80 0 -20
Dry Bulb Temperature [°C]

30

40

50

60

60%

40%

10%

Storage

Operation

Humidity [(%)RH]

5 /38

LC550EQD

Product Specification

3. Electrical Specifications
3-1. Electrical Characteristics

It requires two power inputs. One is employed to power for the LCD circuit. The other Is used for the LED
backlight and LED Driver circuit.

Table 2. ELECTRICAL CHARACTERISTICS

Parameter Symbol

Min Typ Max

Circuit :
Power Input Voltage VLCD 10.8 12.0 13.2 VDC

Power Input Current ILCD

T-CON Option
Selection Voltage

Power Consumption PLCD - 11.5 15 Watt 1
Rush current IRUSH - - 12 A 3

Input High Voltage V
Input Low Voltage VIL 0 - 0.7

IH

- 953 1240 mA 1

- 984 1280 mA 2

2.7 - 3.6

Value

Unit Note

VDC
VDC

notes

1. The specified current and power consumption are under the V

=12.0V, Ta=25  2°C, fV=120Hz

LCD

condition, and mosaic pattern(8 x 6) is displayed and fV is the frame frequency.

2. The current is specified at the maximum current pattern.

3. The duration of rush current is about 2ms and rising time of power input is 0.5ms (min.).

4. Ripple voltage level is recommended under ±5% of typical voltage

White : 1023 Gray
Black : 0 Gray

Ver. 0.0

Mosaic Pattern(8 x 6)

6 /38

Product Specification

Table 3. ELECTRICAL CHARACTERISTICS (Continue)

LC550EQD

-

-

Values

3.7(TBD)

89.3

(TBD)

4.0(TBD)

7.5

(TBD)

96.5

(TBD)

Unit Notes

A 1

VBL = 21.6V

A

Ext VBR-B = 100%

W 1

On Duty

Vdc
Vdc

HIGH : on duty

LOW : off duty

Parameter Symbol

LED Driver :
Power Supply Input Voltage VBL

Power Supply Input Current IBL

Power Supply Input Current (In-Rush) In-rush - -

Power Consumption PBL

On/Off

Input Voltage for

Control System

Signals

LED :
Life Time 30,000 50,000 Hrs 2

Brightness Adjust ExtVBR-B 1 - 100 %

PWM Frequency for
NTSC & PAL

Pulse Duty Level
(PWM)

On V on 2.5 - 3.6 Vdc
Off V off -0.3 0.0 0.7 Vdc

PAL 100 Hz 3

NTSC 120 Hz 3

High Level 2.5 - 3.6

Low Level 0.0 - 0.7

Min Typ Max

21.6 24.0 25.2 Vdc 1

4

6

Notes :

1. Electrical characteristics are determined after the unit has been ‘ON’ and stable for approximately 60
minutes at 25±2°C. The specified current and power consumption are under the typical supply Input voltage
24Vand VBR (ExtVBR-B : 100%), it is total power consumption.

2. The life time (MTTF) is determined as the time which luminance of the LED is 50% compared to that of initial
value at the typical LED current (ExtVBR-B :100%) on condition of continuous operating in LCM state at
25±2°C.

3. LGD recommend that the PWM freq. is synchronized with One time harmonic of V_sync signal of system.
Though PWM frequency is over 120Hz (max 252Hz), function of LED Driver is not affected.

4. The duration of rush current is about 200ms. This duration is applied to LED on time.

5. Even though inrush current is over the specified value, there is no problem if I2T spec of fuse is satisfied.

6. Ext_PWM Signal have to input available duty range.
Between 99% and 100% ExtVBR-B duty have to be avoided. ( 99% < ExtVBR-B < 100%)
But ExtVBR-B 0% and 100% are available.

High

Available duty range

Low

0%

1%

Ver. 0.0

99% 100% Ext_PWM Input Duty

7 /38

LC550EQD

Product Specification

3-2. Interface Connections

This LCD module employs three kinds of interface connection, 5-pin connector, 51pin connector and 41-pin
Connector are used for the module electronics

3-2-1. LCD Module

- LCD Connector(CN1): SM05B-PASS-TB (manufactured by JST)

- Mating Connector : PAP-05V-S(JST) or compatible

Table 3-1. MODULE CONNECTOR(CN1) PIN CONFIGURATION

Pin No Symbol Description Note

1
2
3

GND Ground
GND Ground

VLCD Power Supply +12.0V

4
5

VLCD Power Supply +12.0V
VLCD Power Supply +12.0V

Ver. 0.0

8 /38

Product Specification

- LCD Connector(CN1): FI-RE51S-HF(manufactured by JAE)

- Mating Connector : FI-R51HL(JAE) or compatible

Table 3-2. MODULE CONNECTOR(CN2) PIN CONFIGURATION

No Symbol Description No Symbol Description

1

NC (Reserved)

2

NC (Reserved) Power Supply +12.0V (reserved)

3

NC (Reserved) Power Supply +12.0V (reserved)

4

NC (Reserved) Power Supply +12.0V (reserved)

5

NC (Reserved) Power Supply +12.0V (reserved)

6

NC (Reserved) Power Supply +12.0V (reserved)

7

NC (Reserved) Power Supply +12.0V (reserved)

8

NC (Reserved) Power Supply +12.0V (reserved)

9 NC NO CONNECTION 35 Rx2p V-by-One HS Data Lane 2

10 GND
11

12
13
14

15
16

17
18

19
20
21

22

23
24

25
26

GND
GND
GND
GND

Data format 0
Data format 1

PCID_EN

SDA SDA (For I2C)
SCL SCL (For I2C)

NC NO CONNECTION

Bit SEL

L-DIM Enable

AGP or NSB

GND
HTPDN Hot plug detect
LOCKN Lock detect

Power Supply +12.0V (reserved)

Ground
Ground
Ground
Ground
Ground

Input Data Format [1:0] :

‘00’=Mode1, ’01’=Mode2,
’10’=Mode3, ’11’=Mode4

‘H’ : PCID Enable
‘L’ or ‘NC’ : PCID Disable

‘H’ or NC= 10bit(D) , ‘L’ = 8bit

‘H’=Enable, ‘L’ or NC=Disable

‘H’ or NC : AGP
‘L’ : NSB (No signal Black)

Ground

27
28 Rx0n V-by-One HS Data Lane 0

29 Rx0p V-by-One HS Data Lane 0
30 GND

31 Rx1n V-by-One HS Data Lane 1
32 Rx1p V-by-One HS Data Lane 1

33 GND
34 Rx2n V-by-One HS Data Lane 2

36 GND
37 Rx3n V-by-One HS Data Lane 3
38 Rx3p V-by-One HS Data Lane 3
39 GND

40
41

42
43

44
45
46

47
48

49
50

51

- - -

GND

Ground

Ground

Ground

Ground

Ground

Rx4n V-by-One HS Data Lane 4
Rx4p V-by-One HS Data Lane 4

GND

Ground

Rx5n V-by-One HS Data Lane 5
Rx5p V-by-One HS Data Lane 5

GND

Ground
Rx6n V-by-One HS Data Lane 6
Rx6p V-by-One HS Data Lane 6

GND

Ground
Rx7n V-by-One HS Data Lane 7

Rx7p V-by-One HS Data Lane 7

GND

Ground

LC550EQD

Note

Ver. 0.0

1. All GND (ground) pins should be connected together to the LCD module’s metal frame.

2. #1~#8NC(No connection) : These pin are used for back up power source, Vlcd(power input)
These pin are should be connected together.

3. All Input levels of V-by-One signals are based on the V-by-One-HS Standard Version 1.3

4. #9 & #20 NC(No Connection) : These pins are used only for LGD (Do not connect)

5. About specific pin(#15, #16), Please see the Appendix

7. Specific pin No. #23 is used for “No signal detection” of system signal interface.
It should be GND for NSB (No Signal Black) while the system interface signal is not.
If this pin is “H”, LCD Module displays AGP (Auto Generation Pattern).

9 /38

Product Specification

-LCD Connector (CN2) : FI-RE41S-HF(manufactured by JAE)

- Mating Connector : FI-RE41HL

Table 3-3. MODULE CONNECTOR(CN2) PIN CONFIGURATION

No Symbol Description No Symbol Description

LC550EQD

1 GND
2 Rx8n V-by-One HS Data Lane 8 23 Rx15n V-by-One HS Data Lane 15
3 Rx8p V-by-One HS Data Lane 8 24 Rx15p V-by-One HS Data Lane 15

4 GND
5 Rx9n V-by-One HS Data Lane 9 26 NC NO CONNECTION
6 Rx9p V-by-One HS Data Lane 9 27 NC NO CONNECTION
7 GND
8 Rx10n V-by-One HS Data Lane 10 29 NC NO CONNECTION

9 Rx10p V-by-One HS Data Lane 10 30 NC NO CONNECTION
10 GND
11 Rx11n V-by-One HS Data Lane 11 32 NC NO CONNECTION
12 Rx11p V-by-One HS Data Lane 11 33 NC NO CONNECTION
13 GND
14 Rx12n V-by-One HS Data Lane 12 35 NC NO CONNECTION
15 Rx12p V-by-One HS Data Lane 12 36 NC NO CONNECTION
16 GND
17 Rx13n V-by-One HS Data Lane 13 38 NC NO CONNECTION
18 Rx13p V-by-One HS Data Lane 13 39 NC NO CONNECTION
19 GND
20 Rx14n V-by-One HS Data Lane 14 41 NC NO CONNECTION

Ground

Ground

Ground

Ground

Ground

Ground

Ground

22 GND

25 GND

28 NC NO CONNECTION

31 NC NO CONNECTION

34 NC NO CONNECTION

37 NC NO CONNECTION

40 NC NO CONNECTION

Ground

Ground

21 Rx14p V-by-One HS Data Lane 14 -

notes : 1. All GND (ground) pins should be connected together to the LCD module’s metal frame.

2. #26~#41 NC (No Connection) : These pins are used only for LGD (Do not connect)

CN1

#1

CN1

#1 #5

CN2 CN3

#1 #51 #1 #41

#5

CN2 CN3

#1 #51

#1 #41

Rear view of LCM

Ver. 0.0

10 /38

Product Specification

3-2-2. Backlight Module

Master

-LED Driver Connector
: 20022WR - H14B2(Yeonho) or Compatible

- Mating Connector
: 20022HS - 14B2 or Compatible

Table 5-1. LED DRIVER CONNECTOR PIN CONFIGURATION

Pin No Symbol Description Note

LC550EQD

1
2
3
4
5
6
7
8

9
10
11
12

13
14

VBL Power Supply +24.0V
VBL Power Supply +24.0V
VBL Power Supply +24.0V
VBL Power Supply +24.0V

VBL Power Supply +24.0V
GND
GND
GND
GND
GND

Status

ON/OFF

V

NC Don’t care

EXTVBR-B External PWM 3

Backlight Ground
Backlight Ground
Backlight Ground
Backlight Ground
Backlight Ground
Back Light Status 2
Backlight ON/OFF control 3

1

Notes :1. GND should be connected to the LCD module’s metal frame.

2. Normal : Low (under 0.7V) / Abnormal : Open

3. High : on duty / Low : off duty, Pin#14 can be opened. ( if Pin #14 is open , EXTVBR-B is 100% )

4. Each impedance of pin #12 and 14 is over 50 [KΩ] .

◆ Rear view of LCM

1

Ver. 0.0

◆ Status

PCB

14

1

…

14

…

<Master>

11 /38

LC550EQD

Product Specification

3-3. Signal Timing Specifications

Table 4 shows the signal timing required at the input of the Vx1 transmitter. All of the interface signal timings
should be satisfied with the following specification for normal operation.

Table 4. TIMING TABLE (DE Only Mode)

ITEM Symbol Min Typ Max Unit Note

Horizontal

Vertical

Frequency

Display

Period

Blank

Total

Display

Period

Blank

Total

ITEM Symbol Min Typ Max Unit Note

DCLK

Horizontal

Vertical

tHV
tHB

tHP
tVV

tVB
tVP

fCLK

fH
fV

240 240 240

25 35 60

265 275 300

2160 2160 2160

40

(456)
2200

(2616)

67 74.25 78.00

244 270 280

108

(95)

90

(540)
2250

(2700)

120

(100)

172

(600)

2332

(2760)

122

(104)

tCLK
tCLK

tCLK

Lines

Lines

Lines

MHz

KHz

Hz

3840/16

1

1

1188/16

1
2

NTSC

(PAL)

notes: 1. The input of HSYNC & VSYNC signal does not have an effect on normal operation (DE Only Mode).
If you use spread spectrum of EMI, add some additional clock to minimum value for clock margin.

2. The performance of the electro-optical characteristics may be influenced by variance of the vertical
refresh rate and the horizontal frequency

※ Timing should be set based on clock frequency.

Ver. 0.0

12 /38

Product Specification

3-4. V by One input signal Specifications

3-4-1. V by One input Signal Timing Diagram

LC550EQD

Ver. 0.0

13 /38

Product Specification

3-4-2. V by One Input Signal Characteristics

1) DC Specification

LC550EQD

Ver. 0.0

14 /38

LC550EQD

Product Specification

3-5. Color Data Reference

The brightness of each primary color (red, green, blue) is based on the 10bit or 8bit gray scale data input for the color.
The higher binary input, the brighter the color. Table 5 provides a reference for color versus data input.

Table 5. COLOR DATA REFERENCE

Byte0

Byte1

Byte2

Byte4

Packer input &

Unpacker output

D[0] R[2] R[0]
D[1] R[3] R[1]
D[2] R[4] R[2]
D[3] R[5] R[3]
D[4] R[6] R[4]
D[5] R[7] R[5]
D[6] R[8] R[6]
D[7] R[9] R[7]
D[8] G[2] G[0]

D[9] G[3] G[1]
D[10] G[4] G[2]
D[11] G[5] G[3]
D[12] G[6] G[4]
D[13] G[7] G[5]
D[14] G[8] G[6]
D[15] G[9] G[7]
D[16] B[2] B[0]
D[17] B[3] B[1]
D[18] B[4] B[2]
D[19] B[5] B[3]
D[20] B[6] B[4]
D[21] B[7] B[5]
D[22] B[8] B[6]
D[23] B[9] B[7]
D[24] Don’t care
D[25] Don’t care
D[26] B[0]
D[27] B[1]
D[28] G[0]
D[29] G[1]
D[30] R[0]
D[31] R[1]

30bpp RGB (10bit) 24bpp RGB (8bit)

Ver. 0.0

15 /38

3-6. Power Sequence

3-6-1. LCD Driving circuit

LC550EQD

Product Specification

Power Supply For LCD
V

LCD

0V

0V

Interface Signal (Tx_clock)

User Control Signal

(DATA FORMAT,BIT_SEL,PCID_EN)

Power for LED

Table 6. POWER SEQUENCE

Parameter

Min Typ Max

90%

10%

T1

T6

T2

100%

Value

Vx1 Data

T3 T4

LED ON

90%

10%

T7

Unit Notes

10%

T5

Note :

Ver. 0.0

T1 0.5 - 20 ms 1
T2 0 - - ms 2
T3 400 - - ms 3
T4 200 - - ms 3
T5 1.0 - - s 4
T6 0 - T2 ms 5
T7 0 - - ms 6

1. Even though T1 is over the specified value, there is no problem if I2T spec of fuse is satisfied.

2. If T2 is satisfied with specification after removing LVDS Cable, there is no problem.

3. The T3 / T4 is recommended value, the case when failed to meet a minimum specification,
abnormal display would be shown. There is no reliability problem.

4. T5 should be measured after the Module has been fully discharged between power off and on period.

5. If the on time of signals (Interface signal and user control signals) precedes the on time of Power (V
it will be happened abnormal display. When T6 is NC status, T6 doesn’t need to be measured.

6. It is recommendation specification that T7 has to be 0ms as a minimum value.

※ Please avoid floating state of interface signal at invalid period.
※ When the power supply for LCD (VLCD) is off, be sure to pull down the valid and invalid data to 0V.

LCD

),

16 /38

3-6-2. Sequence for LED Driver

Power Supply For LED Driver

VBL

0V

10%

Product Specification

24V (typ.)

90%

LC550EQD

90%

VON/OFF

Ext-VBR-B

3-6-3. Dip condition for LED Driver

VBL(Typ.) x 0.8

T1 T2

T4

LED ON

T5

T3

V

BL

0 V

: 24V

Table 9. Power Sequence for LED Driver

Parameter

T1 20 - - ms 1
T2 500 - - ms
T3 10 - - ms
T4 0 - - ms
T5 - - 10 ms VBL(Typ) x 0.8

Min Typ Max

Values

Units Remarks

notes : 1. T1 describes rising time of 0V to 24V and this parameter does not applied at restarting time.
Even though T1 is over the specified value, there is no problem if I2T spec of fuse is satisfied.

Ver. 0.0

17 /38

LC550EQD

Product Specification

4. Optical Specification

Optical characteristics are determined after the unit has been ‘ON’ and stable in a dark environment at 25±2°C.
The values are specified at distance 50cm from the LCD surface at a viewing angle of  and  equal to 0 °.
FIG. 1 shows additional information concerning the measurement equipment and method.

Optical Stage(x,y)

LCD Module

Pritchard 880 or
equivalent

50cm

FIG. 1 Optical Characteristic Measurement Equipment and Method

Ta= 25±2°C, V

Table 7. OPTICAL CHARACTERISTICS

Parameter Symbol

Contrast Ratio CR 1000 1400 - 1
Surface Luminance, white L
Luminance Variation 

Gray-to-Gray G to G 5 8

Response Time

MPRT MPRT - 8 12 5

Uniformity 

WH

WHITE

Uniformity 

RED

2D

3D

GREEN

BLUE

WHITE

right(=0°)
left (=180°)
up (=90°)
down (=270°)

up + down

r (x axis) 89 - -

l (x axis) 89 - -
u (y axis) 89 - -
d (y axis) 89 - -
u (y axis)

+d (y axis)

Color Coordinates
[CIE1931]

Color Temperature 10,000 K
Color Gamut 72 %

Viewing
Angle

Gray Scale - - - 7

(CR>10)

(CT≤10%)

2D 360 450
3D 110 170 7

9P 70 3

MPRT

G TO G

Rx
Ry 0.332(TBD)
Gx 0.313(TBD)
Gy 0.594(TBD)

Bx 0.150(TBD)
By 0.054(TBD)
Wx 0.281

Wy 0.288

Min Typ Max

- - 1 5

- - 1 5

Typ

-0.03

14 - - degree 8

Value

0.653(TBD)

=12.0V, fV=120Hz, Dclk=74.25MHz

LCD

EXTVbr-B=100%

Unit notes

2

cd/m

ms

Typ

+0.03

degree 6

2

4

Ver. 0.0

18 /38

LC550EQD

Product Specification

Note : 1. Contrast Ratio(CR) is defined mathematically as :
Surface Luminance with all white pixels

Contrast Ratio =
Surface Luminance with all black pixels

It is measured at center 1-point.

2. Surface luminance is determined after the unit has been ‘ON’ and 1 Hour after lighting the

backlight in a dark environment at 25±2°C. Surface luminance is the luminance value at center
1-point across the LCD surface 50cm from the surface with all pixels displaying white.
For more information see the FIG. 2.

3. Response time is the time required for the display to transit from G(N) to G(M) (Rise Time, TrR)
and from G(M) to G(N) (Decay Time, TrD). For additional information see the FIG. 3. (N<M)
※ G to G Spec stands for average value of all measured points.
Photo Detector : RD-80S / Field : 2˚

4. Viewing angle is the angle at which the contrast ratio is greater than 10. The angles are determined
for the horizontal or x axis and the vertical or y axis with respect to the z axis which is normal to the
LCD module surface. For more information, see the FIG. 4.

5. Gray scale specification
Gamma Value is approximately 2.2. For more information, see the Table 8.

6. 3D performance specification is expressed by 3D luminance, 3D Crosstalk and 3D viewing angle.
3D luminance and 3D crosstalk is measured at center 1-point.
For more information, see the FIG13~16.

Table 8. GRAY SCALE SPECIFICATION

Gray Level Luminance [%] (Typ)

L0 0.07
L15 0.27
L31 1.04
L47 2.49
L63 4.68
L79 7.66
L95 11.5

L111 16.1
L127 21.6
L143 28.1
L159 35.4
L175 43.7
L191 53.0
L207 63.2
L223 74.5
L239 86.7
L255 100

Ver. 0.0

19 /38

Product Specification

Measuring point for surface luminance & measuring point for luminance variation.

H

A

H / 2

B

②

V / 2

V

⑤

⑦

③

①

⑧

④

⑥

⑨

LC550EQD

A : H / 6 mm
B : V / 6 mm
@ H,V : Active Area

FIG. 2 9 Points for Luminance Measure

Response time is defined as the following figure and shall be measured by switching the input signal for
“Gray(N)” and “Gray(M)”.

100

90

Optical
Response

10

0

Gray(N)

TrR

Gray(M)

N,M = Black~White, N<M

FIG. 3 Response Time

TrD

Gray(N)

Ver. 0.0

20 /38

LC550EQD

Normal

Y

E







= 0, Right



= 180, Left



= 270, Down



= 90, Up

Product Specification

MPRT is defined as the 10% to 90% blur-edge with Bij(pixels) and scroll speed U(pixels/frame)at the moving
picture.

1

M =

Bij (i=j)

U

Example) Bij = 12pixels, U = 10pixels / 120Hz
M = 12pixels / (10pixels / 120Hz)
= 12pixels / {10pixels / (1/120)s}

= 12 / 1,200 s
= 10 ms

Dimension of viewing angle range

Lj

Li

FIG. 4 MPRT

90%

10%

Bij

Ver. 0.0

FIG. 5 Viewing Angle

21 /38

Product Specification

LC550EQD

LW-RW

LW-RB

LB-RW

LB-RB

(a) Test pattern image

< Figure 13. Measurement configuration>



< Figure 14. Positioning eyeglass >

2

6

4 5

7

1

9

(b) Measurement

position

Luminance

Lum( LE or RE, test pattern, number )

Measurement through
Left or Right eyeglass

< Figure 15. notation of luminance measurement >

3

LMS

8

Right or left eyeglass

3D display

( Circular polarizer )

(c) Setup

measurement

position

In order to measure 3D luminance, 3D crosstalk and 3D viewing angle, it need to be prepared as below;

1) Measurement configuration
4-Test pattern images. Refer to FIG 13.

-. LW-RW : White for left and right eye

-. LW-RB : White for left eye and Black for right eye

-. LB-RW : Black for left eye and white for right eye

-. LB-RB : Black for left eye and right eye
Image files where black and white lines are displayed on even or odd lines.
Luminance measurement system (LMS) with narrow FOV (field of view) is used. Refer to FIG 13.

2) Positioning Eyeglass (refer to appendix-VI for standard specification of eyeglass)
Find angle of minimum transmittance.
This value would be provided beforehand or measured by the following steps;

(i) Test image (LB-RW) is displayed.
(ii) Left eyeglass are placed in front of LMS and luminance is measured,
rotating right eyeglass such as FIG 14. The notation for luminance measurement is “Lum(LE, LB-RW,1)”.
(iii) Find the angle where luminance is minimum.

* Following measurements should be performed at the angle of minimum transmittance of eyeglass.

Ver. 0.0

22 /39 22 /38

LC550EQD

Product Specification

3) Measurement of 3D luminance
(i) Test image ( LW-RW ) is displayed.
(ii) Left or right eyeglass are placed in front of LMS successively and
luminance is measured at center 1 point where the notation for luminance measurement is
“Lum(LE, LW-RW,1)” or “Lum(RE, LW-RW,1).

4) Measurement of 3D crosstalk
(i) Test image ( LB-RW, LW-RB and LB-RB ) is displayed.
(ii) Right or left eyeglass are placed in front of LMS successively and
luminance is measured for position 1.
with rotating LMS or sample vertically.

or

Lum(LE, LB-RW,1) - Lum(LE, LB-RB,1)
Lum(LE, LW-RB,1) - Lum(LE, LB-RB,1)

Lum(RE, LW-RB,1) - Lum(RE, LB-RB,1)
Lum(RE, LB-RW,1) - Lum(RE, LB-RB,1)

5) Measurement of 3D Viewing Angle
3D viewing angle is the angle at which the 3D crosstalk is under 10%. The angles are
determined for the vertical or y axis with respect to the z axis which is normal to the LCD
module surface and measured for position 1. For more information , see the Fig 16

y axis

LB-RW LW-RB

LCM

Φyu(up)

Φyd (down)

z axis

LB-RB

(a) Test pattern image

(b) Measurement of 3D viewing angle (up/down)

LMS

Ver. 0.0

< Figure 16. Measurement of 3D crosstalk and 3D viewing angle >

23 /39 23 /38

Product Specification

5. Mechanical Characteristics

Table 9 provides general mechanical characteristics.

Table 9. MECHANICAL CHARACTERISTICS

Item Value

Horizontal 1223.4 mm

LC550EQD

Outline Dimension

Active Display Area

Weight 16.5 Kg (Typ.) TBD

Vertical 697.2 mm
Thickness 11.7 mm
Horizontal 1209.6 mm

Vertical 680.4 mm

Note : Please refer to a mechanic drawing in terms of tolerance at the next page.

Ver. 0.0

24 /38

[ FRONT VIEW ]

LC550EQD

Product Specification

SET : TOP

Ver. 0.0

SET : DOWN

25 /39

[ REAR VIEW ]

Product Specification

SET : TOP

SET : TOP

LC550EQD

Ver. 0.0

SET : DOWN

SET : DOWN

26 /39

Product Specification

6. Reliability

Table 10. ENVIRONMENT TEST CONDITION

No. Test Item Condition

LC550EQD

1 High temperature storage test

2 Low temperature storage test

3 High temperature operation test

4 Low temperature operation test

5 Humidity condition Operation

Altitude operating

6

storage / shipment

Ta= 60°C 240h

Ta= -20°C 240h

Ta= 50°C 50%RH 240h

Ta= 0°C 240h

Ta= 40 °C ,90%RH
0 - 16,400 ft

0 - 40,000 ft

notes : Before and after Reliability test, LCM should be operated with normal function.

Ver. 0.0

27 /38

Product Specification

7. International Standards

7-1. Safety

a) UL 60065, Underwriters Laboratories Inc.
Audio, Video and Similar Electronic Apparatus - Safety Requirements.
b) CAN/CSA-C22.2 No. 60065-03, Canadian Standards Association.
Audio, Video and Similar Electronic Apparatus - Safety Requirements.
c) EN 60065, European Committee for Electrotechnical Standardization (CENELEC).
Audio, Video and Similar Electronic Apparatus - Safety Requirements.
d) IEC 60065, The International Electrotechnical Commission (IEC).
Audio, Video and Similar Electronic Apparatus - Safety Requirements.

7-2. Environment

a) RoHS, Directive 2011/65/EU of the European Parliament and of the council of 8 June 2011

LC550EQD

Ver. 0.0

28 /38

8. Packing

8-1. Information of LCM Label

a) Lot Mark

A B C D E F G H I J K L M

A,B,C : SIZE(INCH) D : YEAR
E : MONTH F ~ M : SERIAL NO.

notes

1. YEAR

Year

Product Specification

2013 2012 2011

2014 E 2015

2016 G 2017 H 2018 J 2019

LC550EQD

2020

Mark

C B A

D

F

2. MONTH

Month

Mark

Apr 5 May

4

Jun 7 Jul 8 Aug 9 Sep

6

b) Location of Lot Mark

Serial NO. is printed on the label. The label is attached to the backside of the LCD module.
This is subject to change without prior notice.

8-2. Packing Form

a) Package quantity in one Pallet : 22 pcs
b) Pallet Size : 1440 mm(W) X 1140 mm(D) X 935 mm(H)

K

Oct

A

Nov

B

Dec Mar Feb Jan

C 3 2 1

Ver. 0.0

29 /38

LC550EQD

Product Specification

9. Precautions

Please pay attention to the followings when you use this TFT LCD module.

9-1. Mounting Precautions

(1) You must mount a module using specified mounting holes (Details refer to the drawings).
(2) You should consider the mounting structure so that uneven force (ex. Twisted stress, Concentrated stress)
is not applied to the module. And the case on which a module is mounted should have sufficient strength
so that external force is not transmitted directly to the module.
(3) Please attach the surface transparent protective plate to the surface in order to protect the polarizer.
Transparent protective plate should have sufficient strength in order to the resist external force.
(4) You should adopt radiation structure to satisfy the temperature specification.
(5) Acetic acid type and chlorine type materials for the cover case are not desirable because the former
generates corrosive gas of attacking the polarizer at high temperature and the latter causes circuit break
by electro-chemical reaction.
(6) Do not touch, push or rub the exposed polarizers with glass, tweezers or anything harder than HB
pencil lead. And please do not rub with dust clothes with chemical treatment.
Do not touch the surface of polarizer for bare hand or greasy cloth.(Some cosmetics are detrimental
to the polarizer.)
(7) When the surface becomes dusty, please wipe gently with absorbent cotton or other soft materials like
chamois soaks with petroleum benzine. Normal-hexane is recommended for cleaning the adhesives
used to attach front / rear polarizers. Do not use acetone, toluene and alcohol because they cause
chemical damage to the polarizer
(8) Wipe off saliva or water drops as soon as possible. Their long time contact with polarizer causes
deformations and color fading.
(9) Do not open the case because inside circuits do not have sufficient strength.
(10) Touching the LED Driver might cause an electric shock and damage to LED Driver. Please always use
antistatic tools when handling the LED Driver

9-2. Operating Precautions

(1) Response time depends on the temperature.(In lower temperature, it becomes longer.)
(2) Brightness depends on the temperature. (In lower temperature, it becomes lower.)
And in lower temperature, response time(required time that brightness is stable after turned on)
becomes longer
(3) Be careful for condensation at sudden temperature change.Condensation makes damage to polarizer or
electrical contacted parts. And after fading condensation, smear or spot will occur.
(4) When fixed patterns are displayed for a long time, remnant image is likely to occur.
(5) Module has high frequency circuits. Sufficient suppression to the electromagnetic interference shall be
done by system manufacturers. Grounding and shielding methods may be important to minimized the
interference.
(6) Please do not give any mechanical and/or acoustical impact to LCM. Otherwise, LCM can’t be operated
its full characteristics perfectly.
(7) A screw which is fastened up the steels should be a machine screw.
(if not, it can causes conductive particles and deal LCM a fatal blow)
(8) Please do not set LCD on its edge.
(9) The conductive material and signal cables are kept away from LED driver inductor to prevent abnormal
display, sound noise and temperature rising.

Ver. 0.0

30 /38

LC550EQD

Product Specification

9-3. Electrostatic Discharge Control

Since a module is composed of electronic circuits, it is not strong to electrostatic discharge. Make certain that
treatment persons are connected to ground through wrist band etc. And don’t touch interface pin directly.

9-4. Precautions for Strong Light Exposure

Strong light exposure causes degradation of polarizer and color filter.

9-5. Storage

When storing modules as spares for a long time, the following precautions are necessary.
(1) Store them in a dark place. Do not expose the module to sunlight or fluorescent light. Keep the temperature

between 5°C and 35°C at normal humidity.
(2) The polarizer surface should not come in contact with any other object.
It is recommended that they be stored in the container in which they were shipped.
(3) Storage condition is guaranteed under packing conditions.
(4) The phase transition of Liquid Crystal in the condition of the low or high storage temperature will be
recovered when the LCD module returns to the normal condition.

9-6. Operating condition guide

(1) The LCD product should be operated under normal conditions. Normal condition is defined as below;

- Temperature : 5 ~ 40 ℃, normal humidity

- Display pattern : continually changing pattern (Not stationary)
(2) If the product will be used in extreme conditions such as high temperature, display patterns or operation
time etc..,
It is strongly recommended to contact LGD for Qualification engineering advice. Otherwise, its reliability
and function may not be guaranteed. Extreme conditions are commonly found at Airports, Transit Stations,
Banks, Stock market, and Controlling systems. The LCD product should be applied by global standard
environment. (refer ETSI EN 300, IEC 60721)

Ver. 0.0

31 /38

Product Specification

# APPENDIX- I

■ Pallet Ass’y

ⓐ

① ② ③

ⓑ

ⓒ

LC550EQD

ⓓ

④ ⑤ ⑥

ⓔ

ⓙ

No. Description Material

ⓐ

⑦

ⓘ

ⓗ

ⓚ

ⓑ
ⓒ
ⓓ
ⓔ
ⓕ
ⓖ
ⓗ
ⓘ

Ⓙ
Ⓚ

Packing Bottom EPS

Angle Packing Double Wall

ⓕ

ⓖ

Packing Rib EPP

BAG AL

Packing,Top EPS

Tape Masking Tape

Angle Cover Single Wall

Band PP

Clip Steel
Pallet Plywood
Label Paper

Ver. 0.0

32 /38

# APPENDIX- II-1

■ LCM Label

LC550EQD

Product Specification

Model

UL, TUV Mark

LGD Logo

LC550EQD
(FG)(F2)

Serial No.

LIGHT GUIDE : >MS<

Origin

Ver. 0.0

33 /38

# APPENDIX- II-2

■ Pallet Label

LC550EQD

Product Specification

LC550EQD

FGF2

22 PCS

MADE IN KOREA

001/01-01

XXXXXXXXXXXXX XXX

RoHS Verified

Ver. 0.0

34 /38

# APPENDIX- III-1

LC550EQD

Product Specification

Ver. 0.0

35 /38

Product Specification

# APPENDIX- V-1

■ Option Pin Circuit Block Diagram

1) Circuit Block Diagram of Data format Selection pin

LC550EQD

Ver. 0.0

36 /38

Product Specification

# APPENDIX- V-2

■ Option Pin Circuit Block Diagram

3) I2C (SDA/SCL) Selection pin

LC550EQD

Ver. 0.0

37 /38

Product Specification

Polarizer

Retarder

Right eye

Left eye

+λ /4

-λ /4

Polarizer

Retarder

Right eyeRight eye

Left eyeLeft eye

+λ /4

-λ /4

a) Slow axis of retarder

Left Right

45˚

-45˚

a) Slow axis of retarder

Left Right

45˚

-45˚

b) Transmission axis of polarizer

Left Right

0˚

0˚

b) Transmission axis of polarizer

Left Right

0˚

0˚

0˚

90˚

45˚

135˚

Cell Patterned

retarder

Top

POL

Bottom

POL

0˚0˚

90˚90˚

45˚

135˚

45˚

135˚

Cell Patterned

retarder

Top

POL

Bottom

POL

# APPENDIX- VI

■ Standard specification of Eyeglasses

This is recommended data of Eyeglasses for LC550EQK-FGK1 model. (details refer to table 11)
For each item, depending on the eyeglass manufacturer tolerances may occur, this tolerance can

affect 3D performance. (3D Crosstalk, 3D luminance, 3D viewing angle)

<Table 11. Standard specification of Eyeglasses>

Design item of Eyeglasses Left Right Remark

LC550EQD

Optical

axis

Retardation

value

a) Slow axis of retarder
b) Transmission axis of polarizer

Retarder 125nm @550nm

※Recommended polarizer
Polarization efficiency: more than 99.90%

45

-45
135

45 ˚ 45

Patterned

Patterned

retarder

retarder

-45˚ 45˚
0˚ 0˚

˚

˚

˚

˚

Refer to
drawing

Direction from viewer

Ver. 0.0

(b) Configuration of Eyeglasses

<Drawing. Information of optical axis>

38 /38
